We were thinking of you when we made this product
electrolux 3
Welcome to the world of Electrolux
Thank you for choosing a first class product from Electrolux, which hopefully will provide you with lots of pleasure in the future. The Electrolux ambition is to offer a wide variety of quality products that make your life more comfortable. You will find some examples on the cov­er in this manual. Please take a few min­utes to study this manual so that you can take advantage of the benefits of your new machine. We promise that it will provide a superior User Experience delivering Ease-of-Mind. Good luck!
T
1
4 electrolux
Contents
Safety instructions 5 Description of the Appliance 7 Operating the appliance 10 Tips on Cooking and Frying 19 Cleaning and Care 22 What to do if … 24
Disposal 26 Installation Instructions 27 Service 28 Assembly 89 Rating Plate 92
he following symbols are used in this user manual:
Important information concerning your personal safety and information on how to avoid damaging the appliance.
3 General information and tips
2 Environmental information
safety instructions electrolux 5
Safety instructions
Please comply with these instruc­tions. If you do not, any damage re­sulting is not covered by the warranty.
5
This appliance conforms with the following EU Directives:
– 73/23/EEC dated 19.02.1973 Low
Voltage Directive
– 89/336/EEC dated 03.05.1989 EMC
Directive inclusive of Amending Di­rective 92/31/EEC
– 93/68/EEC dated 22.07.1993 CE
Marking Directive
Correct use
This appliance should be used only for normal domestic cooking and fry­ing of food.
The appliance must not be used as a work surface or as a storage surface.
Additions or modifications to the ap­pliance are not permitted.
Do not place or store flammable liq­uids, highly inflammable materials or fusible objects (e.g. plastic film, plas­tic, aluminium) on or near the appli­ance.
Children’s safety
Small children must be kept away from the appliance.
Only let bigger children work on the appliance under supervision.
To avoid small children and pets un­intentionally switching the appliance on, we recommend activation of the child safety device.
General safety
The appliance may only be installed and connected by trained, registered service engineers.
Built-in appliances may only be used after they have built in to suitable built-in units and work surfaces that meet standards.
In the event of faults with the appli­ance or damage to the glass ceramic (cracks, scratches or splits), the ap­pliance must be switched off and disconnected from the electrical supply, to prevent the possibility of an electric shock.
Repairs to the appliance must only be carried out by trained registered service engineers.
Safety during use
Overheated fats and oils can ignite very quickly. When cooking with fat or oil (e.g. chips) do not leave the ap­pliance unattended.
There is the risk of burns from the appliance if used carelessly.
Remove stickers and film from the glass ceramic.
Cables from electrical appliances must not touch the hot surface of the appliance or hot cookware.
Switch the cooking zones off after each use.
Safety when cleaning
For cleaning, the appliance must be switched off and cooled down.
For safety reasons, the cleaning of the appliance with steam jet or high­pressure cleaning equipment is not permitted.
6 electrolux safety instructions
How to avoid damage to the appli­ance
The glass ceramic can be damaged by objects falling onto it.
The edge of the glass ceramic can be damaged by being knocked by the cookware.
Cookware made of cast iron, cast aluminium or with damaged bottoms can scratch the glass ceramic if pushed across the surface.
Objects that melt and things that boil over can burn onto the glass ceramic and should be removed straighta­way.
To avoid damaging cookware and glass ceramics, do not allow sauce­pans or frying pans to boil dry.
Do not use the cooking zones with empty cookware or without cook­ware.
description of the appliance electrolux 7
Description of the Appliance
Cooking surface layout
Single cooking zone
1200 W
Control panel
Triple cooking zone
800/1600/2300 W
Multi-purpose zone
1400/2200
W
Single cooking zone
1800 W
Control panel
Control panel layout
Cooking zone indicators
Timer function
Timer
Timer display
Display
Outside/middle ring
On/Off
Triple ring pilot light
Lock with pilot light
On/Off with power indicator
Multi-purpose zone pilot
Outside ring On/Off
Heat setting selection
8 electrolux description of the appliance
Touch Control sensor fields
The appliance is operated using Touch Control sensor fields. Functions are controlled by touching sensor fields and confirmed by displays and acoustic sig­nals. Touch the sensor fields from above, without covering other sensor fields.
Sensor field Function
On / Off To switch the appliance on and off
Increase settings Increasing heat setting/time Decrease settings Decreasing heat setting/time
Timer Timer selection
Lock Locking/unlocking the control panel
Triple ring switch To switch outer rings
Multi-purpose zone switch To switch the outside ring on and off
on and off
description of the appliance electrolux 9
Displays
Display Description
Cooking zone is switched off Keep warm setting Keep warm setting is set
- Heat settings Heat setting is set Automatic warm up function Automatic warm-up function is activat-
ed Fault Malfunction has occurred Residual heat Cooking zone is still hot Child safety device Lock/child safety device is engaged Safety cut-out Safety cut-out has been activated
Residual heat indicator
Warning! Risk of burns from residu­al heat. After being switched off, the cooking zones need some time to cool down. Look at the residual heat indicator
.
Residual heat can be used for melt­ing and keeping food warm.
10 electrolux operating the appliance
Operating the appliance
Switching the appliance on and off
Control panel Display Pilot light
Switch on Touch for 2 seconds / lights up Switch off Touch for 1 second / none goes out
After switching on, within approx. 10 seconds a heat setting or a func­tion must be set, otherwise the ap­pliance automatically switches itself off.
Setting the heat setting
Control panel Indicator
To increase Touch to To decrease Touch to To switch off Touch and at the same time
The keep warm setting lies be­tween and . It is used to keep food warm.
operating the appliance electrolux 11
Switching the outside ring on and off
By switching the outside rings on or off, the effective heating surface can be matched to the size of the cookware.
Before an outside ring can be switched on, the inside ring must be switched on.
Triple cooking zone
To switch on middle ring Touch for 1-2 seconds
To switch on outside ring Touch for 1-2 seconds.Two power indicators are lit.
To switch off outside ring Touch for 1-2 seconds
To switch off middle ring Touch for 1-2 seconds.First power indicator goes out.
Roasting zone
To switch on outside ring
To switch off outside ring
Sensor panel Power indicator
.
One power indicator is lit.
Second power indicator goes
.
Sensor panel Power indicator
Touch
seconds
Touch for 1-2
seconds
for 1-2
goes out
out.
is lit
Locking/unlocking the control panel
The control panel, with the exception of the “On/Off” sensor field, can be locked at any time in order to prevent the set­tings being changed e.g. by wiping over the panel with a cloth.
Control panel Display
Switch on Touch (for 5 seconds) Switch off Touch previously set heat setting
When you switch the appliance off, the locking function is automatically switched off.
12 electrolux operating the appliance
Using the automatic warm-up function
All cooking zones are equpped with an automatic warm up function When set­ting a heat setting using , when start­ing from , the cooking zone switches to full power for a certain amount of time and then automatically switches back to the heat setting set.
Switch on
Control panel
Touch to (after 5 seconds)
possible heat settings
Display
(only when starting at
)
Switch off Touch to / to Not used Touch to to
If during the automatic warm up a higher heat setting is selected, e.g. from to , the automatic warm up is adjusted.
If there is still residual heat on the cooking zone (display ), the auto­matic warm up is not performed.
operating the appliance electrolux 13
The length of time that the automatic warm up function operates depends on the heat setting selected.
Heat setting Length of the automatic warm up [min : sec]
v
1
2
3
4
5
6
7
8
9
0:30
1:00
1:40
4:50
6:30
10:10
2:00
3:30
4:30
---
14 electrolux operating the appliance
Using the child safety device
The child safety device prevents unin­tentional use of the appliance.
Setting the child safety device
Step Control panel Display/Signal
1. Switch on the appliance
(Do not set a heat setting)
2. Touch until the signal sounds Acoustic signal
3. To uc h
Appliance switches off. The child safety device is engaged.
Overriding the child safety device
The child safety device can be released in this way for a single cooking session; it remains activated afterwards.
Step Control panel Display/Signal
1. Switch on the appliance
2. Touch and at the same time / acoustic signal
Until the appliance is next switched off, it can used as normal.
After overriding the child safety de­vice, a heat setting or a function must be set within approx. 10 seconds, otherwise the appliance automatically switches it­self off.
operating the appliance electrolux 15
Releasing the child safety device
Step Control panel Display/Signal
1. Switch on the appliance
2. Touch until the signal sounds Acoustic signal
3. To uc h
Appliance switches off. The child safety device is released.
Using the timer
Function Condition Outcome after the
time has elapsed
Automatic cut-out a heat setting is set acoustic signal
00 flashes
Cooking zone switches
off
Countdown timer cooking zones not in use acoustic signal
00 flashes
If a heat setting is set on this cook­ing zone in addition to a countdown timer, the cooking zone is switched off after the time set has elapsed.
If a cooking zone is switched off, the timer function set is also switched off.
16 electrolux operating the appliance
Selecting a cooking zone
Step Control panel Display
1. Touch once Pilot light of the first cooking
zone flashes
2. Touch once Pilot light of the second cook-
ing zone flashes
3. Touch once Pilot light of the third cooking
zone flashes
4. Touch once Pilot light of the fourth cooking
zone flashes
If the pilot light is flashing more slowly, the heat setting can be set or modified.
If other timer functions are set, after a few seconds the shortest remain­ing time of all the timer functions is displayed and the corresponding pi­lot light flashes.
Setting the time
Step Control panel Indicator
1. Select cooking zone Pilot light for the cooking zone selected
flashes
2. Touch or 00 to 99 minutes After a few seconds the pilot light flashes more slowly.
The time is set. The time counts down.
operating the appliance electrolux 17
Switching off the timer function
Step Control panel Indicator
1. Select cooking zone Pilot light of cooking zone selected flashes
faster Time remaining is displayed
2. To uc h The time remaining counts backwards to 00. The pilot light goes out.
The Timer function for the selected cooking zone is switched off.
Changing the time
Step Control panel Indicator
1. Select cooking zone Pilot light of the selected cooking zone
flashes faster Time remaining is displayed
2. Touch or 01 to 99 minutes After a few seconds, the pilot light flashes more slowly.
The time is set. The time counts down.
Displaying the time remaining for a cooking zone
Step Control panel field Display
1. Select cooking zone Pilot light of the cooking zone selected
flashes faster The time remaining is displayed
After a few seconds the pilot light flashes more slowly.
Switching off the acoustic signal
Step Control panel field Acoustic signal
1. To uc h Acoustic signal to acknowledge. Acoustic signal stops.
18 electrolux operating the appliance
Safety cut-out
Cooking surface
If after switching on the cooking sur­face, a heat setting is not set for a cooking zone within approx. 10 sec­onds, the cooking surface automati­cally switches itself off.
If one or more sensor fields are cov­ered by objects (a pan, cloths, etc.) for longer than approx. 10 seconds, a signal sounds and the cooking sur­face switches off automatically.
If all cooking zones are switched off, the cooking surface automatically switches itself off after approx. 10 seconds.
Control panel
When the appliance is switched off, if one or more of the sensor fields on the control panel are covered for more that 10 seconds, an acoustic signal sounds. The acoustic signal switches itself off automatically when the sensor fields are no longer cov­ered.
Cooking zones
If one of the cooking zones is not switched off after a certain time, or if the heat setting is not modified, the relevant cooking zone switches off automatically. is displayed. Before being used again, the cooking zone must be set to 0.
Heat setting Switches off after
v, 1 - 2 6 hours 3 - 4 5 hours 5 4 hours 6 - 9 1.5 hours
tips on cooking and frying electrolux 19
Tips on Cooking and Frying
Information on acrylamides According to the latest scientific
knowledge, intensive browning of food, especially in products con­taining starch, can constitute a health risk due to acrylamides. Therefore we recommend cooking at the lowest possible temperatures and not browning foods too much.
Cookware
You can recognise good cookware from the bottoms of the pans. The bottom should be as thick and flat as possible.
Cookware made of enamelled steel or with aluminium or copper bottoms can leave discolorations on the glass ceramic surface which are difficult or impossible to remove.
20 electrolux tips on cooking and frying
Energy saving
Always place cookware on the cooking zone before it is switched on.
If possible, always place lids on the pans.
Switch cooking zones off before the end of the cooking time, to take ad­vantage of residual heat.
Bottom of pans and cooking zones should be the same size.
tips on cooking and frying electrolux 21
Examples of cooking applications
The information given in the following table is for guidance only.
Heat
Cooking-
set­ting
1-2
2-3
3-4
4-5
6-7
7-8
process
0 Residual heat, Off position
Keeping
V
9
food
warm
Melting
Solidi-
fying
Simmer-
ing on low
heat
Steaming
Braising
Boiling
Gentle Frying
Heavy Frying
Boiling
Searing
Deep
frying
suitable for
Keeping cooked foods warm as required Cover
Hollandaise sauce,
melting butter, chocolate,
gelatine
Fluffy omelettes, baked eggs 10-40 mins. Cook with lid on
Simmering rice and milk-
based dishes
Heating up ready-cooked
meals
Steaming vegetables, fish
braising meat
Steaming potatoes 20-60 mins.
Cooking larger quantities of
food, stews and soups
Frying escalopes, veal cor-
don bleu, cutlets, rissoles,
sausages, liver, roux, eggs,
pancakes, doughnuts
Hash browns, loin steaks,
steaks, Flädle (pancakes for
garnishing soup)
Boiling large quantities of water, cooking pasta, searing meat (goulash,
pot roast), deep frying chips
Cooking
time
5-25 mins. Stir occasionally
25-50 mins.
20-45 mins.
60-150 mins.
Steady frying
5-15 mins.
per pan
much liquid as rice, stir
With vegetables add only
a little liquid (a few table-
Use only a little liquid, e.
g.: max.
Up to 3 l liquid plus ingre-
Tips/Hints
Add at least twice as
milk dishes part way
through cooking
spoons)
¼
750 g potatoes
Turn halfway through
Turn halfway through
l water for
dients
cooking
cooking
22 electrolux cleaning and care
Cleaning and Care
Take care! Risk of burns from resid­ual heat.
Warning! Sharp objects and abra­sive cleaning materials will damage the appliance. Clean with water and washing up liquid.
Warning! Residues from cleaning agents will damage the appliance. Remove residues with water and washing up liquid.
Cleaning the appliance after each use
1. Wipe the appliance with a damp cloth and a little washing up liquid.
2. Rub the appliance dry using a clean cloth.
cleaning and care electrolux 23
Removing deposits
1. Place a scraper on the glass ceramic surface at an angle.
2. Remove residues by sliding the blade over the surface.
3. Wipe the appliance with a damp cloth and a little washing up liquid.
4. Rub the appliance dry using a clean cloth.
im-
Type of dirt
medi-
ately
sugar, food containing sugar yes ---
plastics, tin foil yes ---
limescale and water rings --- yes
fat splashes --- yes
shiny metallic discolouration --- yes
*Scrapers and cleaners for glass ceramic and
stainless steel can be purchased in specialist shops
when the appliance
has cooled down
Remove
using
a scraper*
cleaner for glass ce-
ramic or stainless
steel*
Remove stubborn residues with a cleaner for glass ceramic or stain­less steel.
Scratches or dark stains on the glass ceramic that cannot be re­moved do not however affect the functioning of the appliance.
24 electrolux what to do if …
What to do if
Problem Possible cause Remedy
The cooking zones will not switch on or are not function­ing
Acoustic signal sounds when appliance is switched off
The residual heat indicator is not displaying anything
The automatic warm up func­tion is not switching itself on
Acoustic signal sounds and appliance switches itself on and then off again; after 5 sec­onds another acoustic signal sounds
is lit Overheating protection for the
More than 10 seconds have passed since the appliance was switched on
The child safety device is switched on
Several sensor fields were touched at the same time
Safety cut-out has been trig­gered
The lock is switched on Switch off the lock (See the
The control panel is wholly or partly covered by objects.
The cooking zone was only on for a short time and is therefore not hot
There is still residual heat on the cooking zone
The highest heat setting is set The highest heat setting has
The heat setting was set using the sensor field
The On/Off sensor field has been covered up, e.g. by a cloth
cooking zone has been trig­gered
Safety cut-out has been trig­gered
Switch the appliance on again.
Deactivate the child safety de­vice (See the section “Child safety device”)
Only touch one sensor field
Remove any objects (pan, cloths, etc.) that are lying on the control panel. Switch the appliance on again
section “Locking/unlocking the control panel”)
Remove objects.
If the cooking zone is sup­posed to be hot, call the Cus­tomer Service Department.
Let the cooking zone cool down
the same power as the auto­matic warm up function
1.
Switching off the cooking zone
1.
Set the cooking zone using the sensor field
Do not place any objects on the control panel
Switch off the cooking zone. Switch the cooking zone on again
Switch off the cooking zone. Switch the cooking zone on again
what to do if … electrolux 25
Problem Possible cause Remedy
and number are displayed Electronics fault Disconnect the appliance from
the electrical supply for a few minutes (Take the fuse out of the house’s wiring system) If after switching on again, is displayed again, call the customer service department
and minus are displayed Light rays that are too strong
on the control panel, for exam­ple bright sunlight
Briefly shade the control panel, for example with the hand Acoustic signal sounds, appli­ance switches itself off Switch appliance on (again)
If you are unable to remedy the problem by following the above suggestions, please contact your dealer or the Customer Care De­partment.
Warning! Repairs to the appliance are only to be carried out by quali­fied service engineers. Considera­ble danger to the user may result from improper repairs.
If the appliance has been wrongly operated, the visit from the custom­er service technician or dealer may not take place free of charge, even during the warranty period.
26 electrolux disposal
Disposal
Packaging material The packaging materials are envi-
ronmentally friendly and can be re­cycled. The plastic components are identified by markings, e.g. >PE<, >PS<, etc. Please dispose of the packaging materials in the appro­priate container at the community waste disposal facilities.
Old appliance
The symbol its packaging indicates that this product may not be treated as household waste. Instead it shall be handed over to the applicable col­lection point for the recycling of electrical and electronic equipment. By ensuring this product is dis­posed of correctly, you will help pre­vent potential negative consequences for the environment and human health, which could oth­erwise be caused by inappropriate waste handling of this product. For more detailed information about re­cycling of this product, please con­tact your local city office, your household waste disposal service or the shop where you purchased the product.
W on the product or on
installation instructions electrolux 27
Installation Instructions
Safety instructions
The laws, ordinances, directives and standards in force in the country of use are to be followed (safety regulations, proper recycling in accordance with the regulations, etc.) Installation may only be carried out by a qualified electrician. The minimum distances to other appli­ances and units are to be observed. Anti-shock protection must be provided by the installation, for example drawers may only be installed with a protective floor directly underneath the appliance. The cut surfaces of the worktop are to be protected against moisture using a suitable sealant. The sealant seals the appliance to the work top with no gap. Avoid installing the appliance next to doors and under windows. Otherwise hot cookware may be knocked off the rings when doors and windows are opened.
WARNING! Risk of injury from electrical cur­rent.
The electrical mains terminal is live.
Make electrical mains terminal free of
voltage.
Observe connection schematic.
Observe electrical safety rules.
Ensure anti-shock protection
through correct installation by a qualified electrician.
The appliance must be connected to the electrical supply by a qualified electrician.
IMPORTANT! Risk of injury from electrical cur­rent.
Loose and inappropriate plug and sock­et connections can make the terminal overheat.
Have the clamping joints correctly in­stalled by a qualified electrician.
Use strain relief clamp on cable.
In the event of single-phase or two-
phase connection, the appropriate mains cable of type H05BB-F Tmax 90°C(or higher) must be used.
If this appliance’s mains cable is damaged, it must be replaced by a special cable (type H05BB-F Tmax 90°C; or higher). The latter is availa­ble from the Customer Care Depart­ment.
A device must be provided in the electri­cal installation which allows the appli­ance to be disconnected from the mains at all poles with a contact opening width of at least 3 mm. Suitable isolation devices include line protecting cut-outs, fuses (screw type fuses are to be removed from the hold­er), earth leakage trips and contactors.
Sticking on the seal
Clean the worktop around the cut­out area.
Stick the single-sided adhesive seal­ing tape provided on the underside of the hob around the outside edge ensuring that it is not stretched. The two ends of the tape should join in the middle of one side. After trim­ming the tape (allow it to overlap by 2-3 mm), press the two ends togeth­er.
28 electrolux service
Service
In the event of technical faults, please first check whether you can remedy the problem yourself with the help of the op­erating instructions (section “What to do if…”).
If you were not able to remedy the prob­lem yourself, please contact the Cus­tomer Care Department or one of our service partners.
In order to be able to assist you quickly, we require the following information:
Model descriptionProduct number (PNC)Serial number (S No.)
(for numbers see rating plate)
Type of faultAny error messages displayed by the
appliance
– three digit letter-number combina-
tion for glass ceramic
So that you have the necessary refer­ence numbers from your appliance at hand, we recommend that you write them in here:
Model description: ..........................
...........
PNC: ..........................
...........
S No: ..........................
...........
Assembly / Montaggio / Montering
assembly / montaggio / montering electrolux 89
90 electrolux
electrolux 91
92 electrolux
Rating Plate / Targhetta di omolo­gazione / Typeskilt
EHS68200P
55HDD70AO
ELECTROLUX
230 V 50 Hz
949 592 655
7,5 kW
electrolux 93
94 electrolux
www.electrolux.com
www.electrolux.co.uk www.electrolux.it www.electrolux.dk
822 930 565-A-180906-01
Loading...
