Installation and Operating
Instructions Monteringsog brugsanvisning
EHS6610K
|
k |
822 90 299-A-210306-01 |
g |
Dear Customer,
Please read these user instructions carefully and keep them to refer to later. Please pass the user instructions on to any future owner of the appliance.
The following symbols are used in the text:
1 Safety instructions
Warning! Information that affects your personal safety. Important! Information that prevents damage to the appliance.
3 Useful tips and hints
2 Environmental information
2
Contents |
|
Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
4 |
Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
4 |
Description of the Appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
6 |
Cooking surface layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
6 |
Control panel layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
6 |
Touch Control sensor fields . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
7 |
Displays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
7 |
Residual heat indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
7 |
Operating the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
8 |
Switching the appliance on and off. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
8 |
Selecting the cooking zone. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
8 |
Setting the heat setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
8 |
Using the child safety device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
9 |
Switching on the child safety device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
9 |
Overriding the child safety device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
9 |
Switching off the child safety device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
9 |
Safety cut-out . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
10 |
Tips on Cooking and Frying . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
11 |
Cookware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
11 |
Energy saving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
11 |
Examples of cooking applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
12 |
Cleaning and Care. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
14 |
What to do if … . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
15 |
Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
17 |
Installation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
18 |
Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
19 |
Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
38 |
3
Operating Instructions
1 Safety instructions
3 Please comply with these instructions. If you do not, any damage resulting is not covered by the warranty.
5 This appliance conforms with the following EU Directives:
–73/23/EEC dated 19.02.1973 Low Voltage Directive
–89/336/EEC dated 03.05.1989 EMC Directive inclusive of Amending Directive 92/31/EEC
–93/68/EEC dated 22.07.1993 CE Marking Directive
Correct use
•This appliance should be used only for normal domestic cooking and frying of food.
•The appliance must not be used as a work surface or as a storage surface.
•Additions or modifications to the appliance are not permitted.
•Do not place or store flammable liquids, highly inflammable materials or fusible objects (e.g. plastic film, plastic, aluminium) on or near the appliance.
Children’s safety
•Small children must be kept away from the appliance.
•Only let bigger children work on the appliance under supervision.
General safety
•The appliance may only be installed and connected by trained, registered service engineers.
•Built-in appliances may only be used after they have built in to suitable built-in units and work surfaces that meet standards.
•In the event of faults with the appliance or damage to the glass ceramic (cracks, scratches or splits), the appliance must be switched off and disconnected from the electrical supply, to prevent the possibility of an electric shock.
•Repairs to the appliance must only be carried out by trained registered service engineers.
4
Safety during use
•Remove stickers and film from the glass ceramic.
•There is the risk of burns from the appliance if used carelessly.
•Cables from electrical appliances must not touch the hot surface of the appliance or hot cookware.
•Overheated fats and oils can ignite quickly. When cooking with fat or oil (e.g. chips) do not leave the appliance unattended.
•Switch the cooking zones off after each use.
Safety when cleaning
•For cleaning, the appliance must be switched off and cooled down.
•For safety reasons, the cleaning of the appliance with steam jet or highpressure cleaning equipment is not permitted.
How to avoid damage to the appliance
•The glass ceramic can be damaged by objects falling onto it.
•The edge of the glass ceramic can be damaged by being knocked by the cookware.
•Cookware made of cast iron, cast aluminium or with damaged bottoms can scratch the glass ceramic if pushed across the surface.
•Objects that melt and things that boil over can burn onto the glass ceramic and should be removed straightaway.
•To avoid damaging cookware and glass ceramics, do not allow saucepans or frying pans to boil dry.
•Do not use the cooking zones with empty cookware or without cookware.
5
Description of the Appliance
Cooking surface layout
Single cooking zone |
Single cooking zone |
1200W |
1800W |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Single cooking zone Control panel |
|
Single cooking zone |
||||||||
|
2300W |
|
|
1200W |
Control panel layout
Cooking zone and heat setting selection
Display
On/Off
6
Touch Control sensor fields
The appliance is operated using the Touch Control sensor fields. Functions are controlled by touching sensor fields and confirmed by displays.
Touch the sensor fields from above, without covering other sensor fields.
|
|
Sensor field |
Function |
|
|
|
|
|
|
On / Off |
To switch the appliance on and off |
|
|
|
|
|
|
Increase settings |
To select the cooking zone |
|
|
|
To increase heat settings |
|
|
|
|
|
|
Reduce settings |
To reduce heat settings |
|
|
|
|
Displays |
|
|
|
|
|
|
|
|
|
Display |
Description |
|
|
|
|
|
|
|
Cooking zone is switched off |
|
|
|
|
- |
|
Heat settings |
Heat setting is set |
|
|
|
|
ER |
|
Fault |
Malfunction has occurred |
|
|
|
|
|
|
Residual heat |
Cooking zone is still hot |
|
|
|
|
|
|
Child safety device |
Lock/child safety device is engaged |
|
|
|
|
Residual heat indicator
1 Warning! Risk of burns from residual heat. After being switched off, the cooking zones need some time to cool down. Look at the residual heat indicator .
3 Residual heat can be used for melting and keeping food warm.
7
Operating the appliance
Switching the appliance on and off
|
|
Control panel |
Display |
|
|
|
|
Switch on |
Touch |
for 2 seconds |
/ decimal point flashes |
|
|
|
|
Switch off |
Touch |
for 1 second |
/ none |
|
|
|
|
Selecting the cooking zone
|
Control panel |
Display |
|
|
|
Select |
Touch |
Decimal point lights up |
|
|
|
3 The decimal point is displayed by the selected cooking zone. Then a heat setting must be set for this cooking zone within 6 seconds, otherwise it must be re-selected.
Setting the heat setting
3 After selecting the cooking zone, briefly release the sensor field .
|
|
Control field |
Display |
|
|
|
|
|
|
Increase |
Touch |
|
|
to |
|
|
|
|
|
Decrease |
Touch |
|
|
to |
|
|
|
|
|
Switch off |
Touch |
and |
at the same time |
|
|
|
|
|
|
3 After 6 seconds with no input the selection is cancelled and the decimal point goes out. To set a new setting, select the required cooking zone again.
8
Using the child safety device
The child safety device prevents unintentional use of the appliance.
3 The child safety device can only be activated immediately after the appliance has been switched on.
Switching on the child safety device
Step |
|
Control panel |
|
Display |
|
|
|
|
|
1. |
Switch on appliance. |
/ |
(if hot) |
|
(Do not set a heat setting.) |
|
|
||
|
|
|
||
|
|
|
|
|
2. |
Touch |
for 5 seconds |
is displayed. |
|
|
|
|
|
|
Appliance switches off. |
|
|
||
|
|
|
|
|
3 To override or switch the child safety device off sucessfully, the steps must be performed immediately one after the other. No other sensor fields must be touched between the steps described.
Overriding the child safety device
The child safety device can be switched off in this way for a single cooking session; it remains activated afterwards.
Step |
Control panel |
|
Display |
|
|
|
|
|
|
1. |
Switch appliance on |
/ |
(if hot) |
|
|
|
|
|
|
|
Touch the two |
of the front |
or |
|
2. |
cooking zones at the same |
Decimal points flash |
||
|
time |
|
|
|
|
|
|
|
|
Until the appliance is next switched off, it can used as normal.
Switching off the child safety device
Step |
|
Control panel |
|
Display |
|
|
|
|
|
1. |
Switch appliance on |
/ |
(if hot) |
|
|
|
|
|
|
2. |
Touch |
for 5 seconds |
or |
|
|
|
Decimal points flash |
||
|
|
|
||
|
|
|
|
|
Appliance switches off. |
|
|
||
|
|
|
|
|
9
Safety cut-out
Cooking surface
•If after switching on the appliance a heat setting is not set for a cooking zone within approx. 10 seconds, the appliance automatically switches itself off.
•If one or more sensor fields are touched for longer than approx. 10 seconds, the cooking surface is automatically switched off. ER03 flashes on the display or changes to if there is still residual heat.
•If all cooking zones are switched off, the cooking surface automatically switches itself off after approx. 10 seconds.
Control panel
3 Moisture (e.g. a wet cloth) or liquid boiling over onto the control panel switches all cooking zones off.
Cooking zones
•If one of the cooking zones is not switched off after a certain time, or if the
heat setting is not modified, the relevant cooking zone switches off automatically. is displayed.
Heat setting |
Switches off after |
|
|
1 - 2 |
6 hours |
|
|
3 - 4 |
5 hours |
|
|
5 |
4 hours |
|
|
6 - 9 |
1.5 hours |
|
|
10
Tips on Cooking and Frying
3 Information on acrylamides
According to the latest scientific knowledge, intensive browning of food, especially in products containing starch, can constitute a health risk due to acrylamides. Therefore we recommend cooking at the lowest possible temperatures and not browning foods too much.
Cookware
•You can recognise good cookware from the bottoms of the pans. The bottom should be as thick and flat as possible.
•Cookware made of enamelled steel or with aluminium or copper bottoms can leave discolorations on the glass ceramic surface which are difficult or impossible to remove.
Energy saving
2
2
Always place cookware on the cooking zone before it is switched on.
If possible, always place lids on the pans.
2 Switch cooking zones off before the end of the cooking time, to take advantage of residual heat.
2 Bottom of pans and cooking zones should be the same size.
11
Examples of cooking applications
The information given in the following table is for guidance only.
Heat |
Cooking |
|
Cooking |
|
|
set- |
suitable for |
Tips/Hints |
|||
ting |
process |
|
time |
|
|
|
|
|
|
||
|
|
|
|
|
|
0 |
|
Residual heat, Off po- |
|
|
|
|
sition |
|
|
||
|
|
|
|
||
|
|
|
|
|
|
|
Keep- |
Keeping cooked foods |
as re- |
|
|
1 |
ing food |
Cover |
|||
|
warm |
warm |
quired |
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
Hollandaise sauce, |
|
|
|
|
Melting |
melting butter, |
5-25 mins. |
Stir occasionally |
|
1-2 |
|
chocolate, gelatine |
|
|
|
|
Solidi- |
Fluffy omelettes, |
10-40 |
Cook with lid on |
|
|
fying |
baked eggs |
mins. |
||
|
|
||||
|
|
|
|
|
|
|
|
Simmering rice and |
|
Add at least twice |
|
|
Simmer- |
|
as much liquid as |
||
|
milk-based dishes |
25-50 |
|||
2-3 |
ing on |
rice, stir milk dish- |
|||
Heating up ready- |
mins. |
||||
|
low heat |
es part way through |
|||
|
cooked meals |
|
|||
|
|
|
cooking |
||
|
|
|
|
||
|
|
|
|
|
|
|
Steam- |
Steaming vegetables, |
|
With vegetables |
|
|
20-45 |
add only a little liq- |
|||
3-4 |
ing |
fish |
|||
mins. |
uid (a few table- |
||||
|
Braising |
braising meat |
|||
|
|
spoons) |
|||
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
Use only a little |
|
|
|
Steaming potatoes |
20-60 |
liquid, e. g.: max. |
|
|
|
mins. |
¼ l water for |
||
|
|
|
|||
4-5 |
Boiling |
|
|
750 g potatoes |
|
|
|
Cooking larger quanti- |
60-150 |
Up to 3 l liquid plus |
|
|
|
ties of food, stews and |
|||
|
|
mins. |
ingredients |
||
|
|
soups |
|||
|
|
|
|
||
|
|
|
|
|
|
|
|
Frying escalopes, veal |
|
|
|
|
Gentle |
cordon bleu, cutlets, |
Steady |
Turn halfway |
|
6-7 |
rissoles, sausages, liv- |
||||
Frying |
frying |
through cooking |
|||
|
er, roux, eggs, |
||||
|
|
|
|
||
|
|
pancakes, doughnuts |
|
|
|
|
|
|
|
|
12
