Contents

Important safety information ......................3

Disposal ..............................................................3

Tips for environmental protection ............4

Technical specifications................................4

Description of the appliance ......................4

Installation ..........................................................5

• Unpacking ............................................................5

• Positioning ............................................................5

• Electrical connection ............................................5

• Stacking kit ..........................................................5

• Door reversal ........................................................5

Use ........................................................................6

• The control panel ..............................................6-7

• Programme chart ..................................................8

• Operating sequence..............................................9

• Useful hints ........................................................10

Maintenance and Cleaning ........................11

• External cleaning ................................................11

• Cleaning the door ..............................................11

• Cleaning the filters ..............................................11

• Cleaning the condenser unit ..............................11

• Emptying the water reservoir..............................12

• Cleaning the air intake grille................................12

• Cleaning the drum ..............................................12

Something not working? ............................13

Dear customer,

Please read these operating instructions carefully and pay particular attention to the safety notes indicated in the first pages.

We recommend that you keep this instruction booklet for future reference and pass it on to any future owners.

Transport damages

After unpacking the machine please check it is not damaged. If in doubt, do not start it but contact your local Service Centre.

The symbols you will see on some paragraphs of this booklet have the following meaning:

The warning triangle emphasize information that is particularly important for your safety or correct functioning of the appliance.

The information marked with this symbol provides additional instructions and practical tips on the use of the appliance.

Tips and information about economical and ecological use of the machine are marked with this symbol.

Our contribution to the protection of the

environment: we use recycled paper.

125992320 gb.qxd 16/10/2003 10:41 Pagina 2

ENGLISH

Important safety information

Installation

• Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person.

• Care must be taken to ensure that the appliance does not stand on the electrical supply cable.

• If the machine is situated on a carpeted floor, please adjust the feet in order to allow air to circulate freely.

Use

• This appliance is designed for domestic use only. If the machine is used for any other purposes or is not used correctly, the manufacturer accepts no responsibility for any damage that might occur.

• Always unplug the appliance after use.

• Clothes which are dripping wet should not be placed in the dryer.

• Danger of explosion: Never tumble dry items that have been in contact with inflammable solvents (petrol, methylated spirits, dry cleaning fluid and the like). As these substances are volatile, they could cause an explosion. Tumble dry only items washed with water.

• Please make sure that no gas lighters have accidentally been left in pockets of garments to be loaded into appliance.

• Do not dry canvas shoes or sports shoes, as they could get stuck between the door and the drum, thus blocking this latter.

• Leave the door slightly ajar when the appliance is not being used. This will allow the seal to be preserved.

• Clean fluff filters after using the tumble dryer. To prevent fire risks, do not use the appliance if the

fluff filters are damaged or without filters.

• Do not allow fluff to accumulate around the dryer.

General safety

• It is dangerous to alter the specifications or attempt to modify this product in any way.

• Under no circumstances should you attempt to repair the machine yourself. Repairs carried out by inexperienced persons may cause injury or serious malfunctioning. Contact your local Service Centre. Always insist on genuine spare parts.

Child safety

• Children are often not aware of how dangerous electrical appliances can be. When the machine is working, children should be carefully supervised and not be allowed to play with the appliance.

• The packaging components (e.g. plastic film, polystyrene) can be dangerous to children danger of suffocation! Keep them out of children’s reach.

• Make sure that children or pets do not climb into the drum.

• When the appliance is to be scrapped, cut off the electrical supply cable and destroy the plug with the remaining cable. Disable the door catch in order to prevent children from becoming trapped inside while playing.

These warnings have been provided in the interest of safety. You MUST read them carefully before installing or using the appliance.

• Packaging materials

The materials marked with the symbol are recyclable.

This means that they can be recycled by disposing of them properly in appropriate collection containers.

• Machine

Use authorised disposal sites for your old appliance. Help to keep your country tidy!

Disposal

125992320 gb.qxd 16/10/2003 10:41 Pagina 3

Description of the appliance

01 Control panel 02 Water reservoir 03 Fluff filters 04 Rating Plate 05 Condenser Unit 06 Adjustable feet

9 0 

60

3 0



B C

D E

- 6

- 9

0

G H J K

To save energy and to help protect the environment, we recommend that you follow these hints:

• Try to load the maximum capacity of the machine

as small loads are uneconomical.

• Always load well spun laundry. The higher the spin speed, the lower the electricity consumption and the shorter the drying times.

• Do not over-dry laundry, this avoids creasing and saves energy. Select the drying programme according to the type of laundry and the required degree of dryness.

• To utilize the maximum load, laundry which is to be dried ready to put away (store dry) can be dried together with items to be ironed. To do this, select the programme for iron-dry, remove the iron-dry items at the end of the programme and then finish-dry the rest of the load.

• Clean the filters regularly to avoid excessive drying times and high electricity consumption.

• Ventilate the room well. The room temperature should not exceed +35°C during drying.

Tips for environmental protection

Technical specifications

DIMENSIONS: Height 85 cm

Width 60 cm Depth 58 cm

ELECTRICAL CONNECTION: 220/230 V/50 Hz MAX. POWER ABSORBED: 2400 W MIN. FUSE RATING: 16 A

MAX. DRYING CAPACITY: Cotton, linen 5 kg

Synthetics 2.5 kg

CONSUMPTION: Cotton, linen 3.64 kWh (5.5 kg store dry)

Cotton, linen 3.64 kWh (5.5 kg iron dry) Synthetics 1.40 kWh (2.5 kg store dry)

This appliance complies with the following E.E.C. Directives:

- 73/23 EEC of 19.2.73 (Low Voltage Directive) and subsequent modifications;

- 89/336 EEC of 3.5.89 (Electromagnetic Compatibility Directive) and subsequent modifications.

125992320 gb.qxd 16/10/2003 10:41 Pagina 4

ENGLISH

Installation

Warning! Unpacking

Slide out the polythene bag with the polystyrene stuffing before using the appliance.

Should the appliance be moved, it must be transported vertically.

Positioning

It is recommended that, for your convenience, the machine is positioned close to your washing machine. The tumble dryer must be installed in a clean place, where dirt does not build up.

Air must be able to circulate freely all round the appliance. Do not obstruct the front ventilation grille or the air intake grille at the back of the machine.

To keep vibration and noise to a minimum when the dryer is in use, it should be placed on a firm, level surface. Once in its permanent operating position, check that the dryer is absolutely level with the aid of a spirit level. If it is not, raise or lower the feet until it is.

The feet must never be removed. Do not restrict the floor clearance through deep-

pile carpets, strips of wood or similar. This might cause heat build-up which would interfere with the operation of the appliance.

Important

The hot air emitted by the tumble dryer can reach temperatures of up to 60°C. The appliance must therefore not be installed on floors which are not resistant to high temperatures.

P1106

When operating the tumble dryer, the room temperature must not be lower than +5°C and higher than +35°C, as it may affect the performance of the appliance.

Electrical connection

This machine is designed to operate on a 220-230 V, single-phase, 50 Hz supply.

Check that your domestic electrical installation can take the maximum load required (2.4 kW), also taking into account any other appliances in use.

Connect the machine to an earthed socket, in accordance with current wiring regulations.

The manufacturer declines any responsibility for damage or injury through failure to comply with the above safety precaution. Should the appliance power supply cable need to be replaced, this must be carried out by our Service Centre.

Important!

The power supply cable must be accessible after installing the machine.

Stacking kit

A special stacking kit is available through your dealer, to enable the mounting of the dryer on top of a front loading washing machine with cover’s depth between 48 and 60 cm.

Read carefully the instructions supplied with the kit.

Door reversal

To make it easier to load or unload the laundry the door can be reversed.

This operation must be carried out by qualified personnel.

Please contact the nearest Service Centre.

P1148

125992320 gb.qxd 16/10/2003 10:41 Pagina 5
