Aeg-electrolux E3000-5-M EU R08, E3000-5-B EU R08, E3000-5-W EU R08 User Manual
E3000-5
User manual Built-In Electric Oven
2
1
Dear Customer
Thank you for choosing one of our high-quality products.
With this appliance you will experience the perfect combination of functional
design and cutting edge technology.
Convince yourself that our appliances are engineered to deliver the best performance and control - indeed we are setting the highest standards of excellence.
In addition to this you find environmental and energy saving aspects as an integral part of our products.
To ensure optimal and regular performance of your appliance please read this
instruction manual carefully. It will enable you to navigate all processes perfectly and most efficiently.
To refer to this manual any time you need to, we recommend you to keep it in a
safe place. And please pass it to any future owner of the appliance.
We wish you much joy with your new appliance.
The following symbols are used in this user manual:
Important information concerning your personal safety and information on
3 General information and tips
how to avoid damaging the appliance.
2 Environmental information
Contents
Operating Instructions 5
Safety instructions 5
Description of the Appliance 7
General Overview 7
Control Panel 8
Oven Features 9
Oven accessories 10
Before Using for the first time 11
Initial Cleaning 11
Using the Rings 12
Setting the heat setting 13
Using the Oven 14
Switching the Oven On and Off 14
Oven Functions 15
Inserting the Oven Shelf and the Baking Tray 16
Uses, Tables and Tips 18
Cooking table 18
Baking 19
Baking table 21
Table for Bakes and Gratins 25
Frozen Ready Meals Table 26
Roasting 27
Roasting table 28
Grill Sizes 30
Grilling table 30
Defrosting 31
Defrosting table 31
Drying 32
Making Preserves 33
Cleaning and Care 34
Outside of the appliance 34
Oven interior 34
Accessories 34
Shelf Support Rails 35
Oven Lighting 36
Oven Ceiling 37
3Contents
Contents4
Oven door 38
Oven door glass 40
What to do if … 44
Disposal 46
Installation Instructions 47
Safety information for the installer 47
Guarantee/Customer Service 52
Service 55
Operating Instructions
1 Safety instructions
Electrical safety
• This appliance must be only connected by a registered electrician.
• In the event of a fault or damage to the appliance: Take the fuses out or
switch off.
• Repairs to the appliance must only be carried out by qualified service engi-
neers. Considerable danger may result from improper repairs. If repairs be-
come necessary, please contact our Customer Services or your dealer.
Child Safety
• Never leave children unsupervised when the appliance is in use.
Safety whilst Using
• People (including children) who, because of their physical, sensory or mental
capabilities or their inexperience or ignorance are not able to use the device
safely, should not use this device without supervision or instruction by a responsible person.
• This appliance is intended to be used for cooking, roasting and baking food in
the home.
• Take care when connecting electric appliances to sockets nearby. Do not allow
connecting leads to come into contact with or to catch beneath the hot oven
door.
• Warning: Risk of burns! The interior of the oven becomes hot during use.
• Using ingredients containing alcohol in the oven may create an alcohol-air
mixture that is easily ignited. In this case, open the door carefully. Do not have
embers, sparks or naked flames in the vicinity when opening the door.
5Operating Instructions
3 Information on acrylamides
According to the latest scientific knowledge, intensive browning of food, especially in products containing starch, can constitute a health risk due to acrylamides. Therefore we recommend cooking at the lowest possible temperatures
and not browning foods too much.
Safety instructions6
How to avoid damage to the appliance
• Do not line the oven with aluminium foil and do not place baking trays, pots,
etc. on the oven floor, as the heat that builds up will damage the oven enamel.
• Fruit juices dripping from the baking tray will leave stains, which you will not
be able to remove. For very moist cakes, use a deep tray.
• Do not put any strain on the oven door when open.
• Never pour water directly into the oven when it is hot. This could cause dam-
age to or discoloration of the enamel.
• Rough handling, especially around the edges of the front panel, can cause the
glass to break.
• Do not store any flammable materials inside the oven. These could ignite
when the oven is switched on.
• Do not store any moist foods inside the oven. This could damage the oven
enamel.
• After switching off the cooling fan, do not keep uncovered dishes in the oven.
Moisture may condense in the oven interior or on the glass doors and may get
into the units.
3 Note on enamel coating
Changes in the colour of the oven’s enamel coating as a result of use do not affect the appliance’s suitability for normal and correct use. They therefore do not
constitute a defect in the sense of the warranty law.
Description of the Appliance
General Overview
Control panel
7Description of the Appliance
Door
handle
Full glass door
Description of the Appliance8
Control Panel
Oven Power Indicator Temperature Pilot Light
Oven Functions Temperature selector
Hob Cooking Zone Control
Hob Cooking Zone Control
Oven Features
9Description of the Appliance
Top heat and heating elements
Shelf positions
Oven shelf runners,
removable
Oven steam vent
The steam from the oven is fed directly upwards via the duct in the rear of the cooking surface.
Oven lighting
Fan
Bottom Heat
Description of the Appliance10
Oven accessories
Oven shelf
For cookware, cake tins, roasts and grilled
foods.
Baking tray
For cakes and biscuits.
11Before Using for the first time
Before Using for the first time
Initial Cleaning
Before using the oven for the first time you should clean it thoroughly.
1 Caution: Do not use any caustic, abrasive cleaners! The surface could be dam-
aged.
3 To clean metal fronts use commercially available cleaning agents.
1. Turn the oven function switch to oven lighting .
2. Remove all accessories and the shelf support rails and wash them with warm
water and washing up liquid.
3. Then wash out the oven with warm water and washing-up liquid, and dry.
4. Wipe the front of the appliance with a damp cloth.
Using the Rings12
Using the Rings
3
Also refer to the operating instructions for your built-in hob. It contains important information on ovenware, operation, cleaning and care.
Heat settings
• You may select the heat settings within the range of settings 1-9.
• Intermediate positions may be selected between settings 2 and 7.
1 = lowest heat setting
9 = highest heat setting
2 Switch the cooking zone off approx. 5-10 minutes before cooking is finished to
make use of the residual heat. This saves electricity.
front left
rear left
rear right front right
Hob Cooking Zone Control Knobs
Setting the heat setting
1. Select the heat setting.
2. To end the cooking process, turn back to the
Off position.
3 The power indicator light is lit as long as a
ring is on.
13Using the Rings
Using the Oven14
Using the Oven
Switching the Oven On and Off
Oven Power Indicator
Oven Functions
1. Turn the oven functions dial to the desired function.
2. Turn the temperature selector to the desired temperature.
The power indicator is lit as long as the oven is in operation.
The temperature pilot light is lit as long as the oven is heating up.
3. To turn the oven off, turn the oven functions dial and the temperature selector
to the Off position.
Temperature Pilot Light
Temperature selector
3 Cooling fan
The fan switches on automatically in order to keep the appliance’s surfaces cool.
When the oven is switched off, the fan continues to run to cool the appliance
down, then switches itself off automatically.
Oven Functions
The oven has the following functions:
Oven function Application
Light Using this function you can light up the oven interior, e.g. for
Fan-assisted
circulation
Conventional For baking and roasting on one oven level.
Bottom heat For baking cakes with crispy or crusty bases.
Defrost For defrosting e. g. flans and gateaux, butter, bread, fruit or
Grill For grilling flat foodstuffs placed in the middle of the grill
Dual gril For grilling flat foodstuffs in large quantities and for toast-
Rotitherm For roasting larger joints of meat or poultry on one level.
15Using the Oven
cleaning.
For baking on up to two oven levels.
Set the oven temperatures 20-40 °C lower than when using
Conventional.
other frozen foods.
and for toasting.
ing.
The function is also suitable for gratinating and browning.
Using the Oven16
Inserting the Oven Shelf and the Baking Tray
3 Shelf runner safety and anti-tip device
As a shelf runner safety device, all insertable components have a small curved
indentation at the bottom on the right and left-hand edge.
Always insert insertable components so that this indentation is at the back of
the oven interior. This indentation is also important for preventing the insertable
components from tipping.
Inserting the baking tray
Push the baking tray between the guide
bars of the selected oven level.
Inserting the oven shelf:
Insert the oven shelf so that the feet point
downwards.
Push the oven shelf between the guide bars
of the selected oven level.
3 The high rim around the oven shelf is an
additional device to prevent cookware from
slipping.
Inserting the oven shelf and the baking
tray together:
Lay the oven shelf on the baking tray.
Push the baking tray between the guide
bars of the selected oven level.
17Using the Oven
