LAVAMAT W 1050 ELECTRONIC
Washing Machine
User information
Dear Customer,
Please read this user information carefully.
Pay particular attention to the section "Safety" on the first Info pages.
Please keep this user information in a safe place for later reference.
Pass it on to any future owners of the unit.
The warning triangle and /or signal words (Warning!, Caution!, Impor-
1
tant!) emphasise information which is important for your safety or for
the unit's functional reliability. It is imperative that this information is
observed.
0 1. This symbol guides you step by step through the operation of the appli-
ance.
2. ...
Next to this symbol you will find additional information and practical
3
tips on using the appliance.
Tips and information on economical and environmentally responsible
2
use of the unit are identified with the clover leaf.
For any faults which occur, this user information contains information
on how to remedy these faults yourself. See the section "What to do
if ..."
Printed on recycled paper.
Thinking ecologically means acting ecologically.
2
Contents
Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Environmental tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Unit description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Front view . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Drawer for Detergent and Conditioners . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Programme selector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Programme Option Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Consumption Values and Programme Times . . . . . . . . . . . . . . . . . . . . . . 13
Before the First Wash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Prepare washing cycle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Sort washing and prepare . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Types of Washing and Care Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Washing Detergents and Care Agents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Which washing detergent and care agent? . . . . . . . . . . . . . . . . . . . . . . 16
How much washing detergent and care agent? . . . . . . . . . . . . . . . . . . . 16
Water softener . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Running a washing cycle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Brief instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Opening and closing the door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Add the washing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Adding detergent/conditioners . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Setting the washing programme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Changing Spin Speed/selecting RINSE HOLD . . . . . . . . . . . . . . . . . . . . . . . . 20
Starting the Wash Programme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Programme Progress . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Changing the washing programme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Washing cycle complete/removing the washing . . . . . . . . . . . . . . . . . . . . . 22
3
Programme Tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Washing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Separate Rinsing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Separate Spinning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Cleaning and Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Detergent Drawer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Washing Drum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Main door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Cleaning the drain pump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
What to do if ... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Remedying Faults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
If the washing results are not satisfactory . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Carrying out emergency drainage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Additional rinse cycles (RINSE+) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Child Safety Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Installation and connection instructions . . . . . . . . . . . . . . . . 36
Installation Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Installation of the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Transporting the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Remove transport packaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Prepare the installation place . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Installation on a concrete base . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Installation on vibrating floors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Compensate for floor unevenness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
4
Electrical connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Water connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Permissible water pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Water inflow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Water drain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Delivery heads over 1m . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Warranty conditions / Customer service centres . . . . . . . 45
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
5
Operating Instructions
Operating Instructions
1 Safety
The safety aspects of AEG electrical appliances comply with accepted
technical standards and the German Appliance Safety Law. However, as
manufacturers we regard it as our responsibility to inform you about
the following safety instructions.
Before Using for the First Time
• Refer to the "Installation and Connection Instructions" further on in
this user information.
• If units are delivered in the winter months at minus temperatures:
Store the washing machine at room temperature for a few hours before putting it into operation.
Correct Use
• The washing machine is only intended for washing normal domestic
washing. If the appliance is used for a wrong purpose or wrongly operated, the manufacturer cannot assume any liability for any damages.
• Additions or modifications to the washing machine are strictly for-
bidden due to safety reasons.
• Use only detergent which is suitable for washing machines. Refer to
the detergent manufacturer's instructions.
• The washing must not contain any flammable solvents. Also bear this
in mind when washing pre-cleaned washing.
• Do not use the washing machine for dry-cleaning.
• Dyes /dye-removing agents may only be used in the washing machine
if the manufacturer expressly permits use of these products. We cannot accept liability for any damage.
• Use only water from the water mains. Use rain water or service water
only if it meets the requirements defined in DIN 1986 and DIN 1988.
• Frost damage is not covered by the warranty! If the washing machine
is in a room subject to possible frost hazards, emergency emptying
must be carried out if there is a risk of frost (see the Section "Carrying out emergency emptying“).
6
Operating Instructions
Child Safety
• Packaging materials (e.g. films, polystyrene) can be dangerous for
children. Risk of suffocation! Keep packaging away from children.
• The appliance is not intendet for use by young children or infirm per-
sons without supervision.
• Children frequently cannot recognise hazards involved in handling
electrical appliances. Therefore, ensure that they are properly supervised during operation and never allow children to play with the
washing machine-there is arisk that they can lock themselves inside it.
• Ensure that children or small animals do not climb into the washing
machine's drum.
• When disposing of washing machines pull out the mains plug, destroy
the door lock, cut off the electrical supply lead and dispose of the
plug and remaining cable. This means that playing children cannot
shut themselves in and cannot encounter a potentially lethal hazard.
General Safety
• Repairs to the washing machine may only be carried out by qualified
specialists. Incorrect repairs may result in significant risk to the user.
If repairs are necessary, consult our customer service or your specialist dealer.
• Never use the washing machine if the mains cable is damaged or the
conrol panel, work surface or base panel area are so badly damaged
that the interior of the unit is openly accessible.
• Switch off the washing machine before carrying out cleaning, care
and maintenance work. Also pull the mains plug out of the socket or,
– if it is permanently connected, – switch off the circuit breaker at
the household power distribution box or completely remove the
screw-in fuse.
• If the appliance will be out of operation for an extended period of
time, unplug it from the mains.
• Never pull the cable to remove the plug from the socket. Always
pull the plug itself.
• Multiple connectors, couplings and extension cables must not be
used. There is a risk of fire with overheating!
• Do not spray down the washing machine with a water jet. Risk of
electric shock!
7
Operating Instructions
• The glass in the door becomes hot in the case of wash programmes
with high temperatures. Do not touch!
• Allow the washing solution to cool before carrying out an emergency
emptying operation or cleaning the drain pump.
• Small animals can chew the power cables and water hoses. Risk of
electric shock and danger of water damage! Keep small animals away
from the washing machine.
8
Operating Instructions
2 Disposal
Disposing of the Packaging Material!
Dispose of the packaging of your washing machine correctly. All pakkaging materials used are environmentally-compatible and recyclable.
• Plastic parts are identified with internationally standardised abbrevi-
ations:
>PE< for polyethylene, e.g. packing films.
>PS< for polystyrene, e.g. cushion parts (always CFC-free)
>POM< for polyoxymethylene, e.g. plastic clips.
• Cardboard packaging is manufactured from recycled paper and
should be deposited in the waste paper collection for recycling.
Disposing of your old appliance!
When you put your unit out of operation one day, please bring it to
your nearest recycling centre or to your dealer.
2 Environmental tips
• A pre-wash cycle is not necessary in the case of washing which is not
excessively dirt. This saves detergent, water and time (and is gentle on
the environment.)
• If the indicated load capacities are taken full advantage of, the wash-
ing machine is especially efficient.
• For small loads, use only one half to one third of the recommended
detergent quantity.
• Suitable pre-treatment enables marks and limited amounts of dirt to
be removed. You can then wash at a lower temperature.
• Wash slightly to normally dirty cottons with the energy-saving pro-
gram.
• There is often no need for the softener. Try it once! If you use a drier,
your washing will become soft and fluffy even without a softener.
• In the case of medium to high water hardness (hardness range runs to
upwards, see "Detergent and care agents“), you should use a water
softener. The detergent can then always be metered for hardness
range I (= soft).
9
Operating Instructions
Unit description
Front view
Drawer for detergent and
care agent
Control panel
Rating plate (behind filling door)
Main door
Screw feet
(height-adjustable)
Drawer for Detergent and Conditioners
Main wash detergent
(powder) and water
softener if required
10
Flap in front of
drain pump
Pre-wash detergent,
In-wash stain treatment products or
water softener
Liquid conditioners
(softeners, finishers,
starch)
Control Panel
Operating Instructions
Spin speed/RINSE HOLD button
Programme
option Buttons
START/PAUSE button
Programme Progress Display
DOOR indicator light
Programme selector
The programme selector is
used to select the wash cycle
(for example, water level, drum
movement, number of rinses,
spin speed) and the water temperature according to the type
of washing.
Programme selector
OFF
• Switches the washing machine off - at all other positions the ma-
chine is on.
• To amend programme settings selected by mistake, turn the selector
to OFF. This restores the original settings.
COTTONS/LINEN
Main wash cycle for Cottons/Coloureds (cottons/linens) from 30 °C to
95 °C.
11
Operating Instructions
EASY-CARES
Main wash cycle for easy-care fabrics (mixed fibres) at 40 °C or 60 °C.
EASY IRON position: main wash cycle at 40°C for easy-care fabrics
which, after washing with this programme, require only light ironing or
no ironing at all.
DELICATES
Main wash cycle for Delicates at 30 °C or 40°C.
WOOL/SILK P (Handwash)
Main wash cycle (cold or 30 °C) for machine-washable or hand-washable woollen items and silk, carrying the symbol ï (Handwash).
GENTLE RINSE
Separate gentle rinse, for example to rinse hand-washed items
(3 rinses, liquid conditioner washed in from æ compartment, spin).
DRAIN
Draining of the water after one rinse hold (without spinning).
The effect of Rinse Hold is that the washing is left to soak in the last
3
rinse water, without spinning.
SPIN
Draining of the water after Rinse Hold and Spin, or separate Spin for
hand-washed Cottons/Linen.
12
ENERGY SAVING
Energy and water saving wash at approx. 60 °C for lightly to normally
soiled Cottons/Coloureds (cottons/linen) with an extended wash time
(cannot be combined with the QUICK option).
Programme Option Buttons
The programme option buttons are used to adapt
the programme to suit the degree of soiling of the
wash. The programme options are not needed for
normally soiled washing.
The different functions can be combined together,
depending on the programme.
PRE-WASH
Warm pre-wash before the main wash, which follows automatically; intermediate spin in the COTTONS/LINEN and EASY CARES programme; no
intermediate spin in the DELICATES programme.
Operating Instructions
STAIN
For heavily soiled or stained washing. In-wash stain treatment products
are washed in at the optimum time as the programme progresses.
Can only be selected with wash temperatures of 40 °C and above, as
stain treatment products are only effective at higher temperatures.
QUICK
Shortened wash programme for lightly soiled washing.
With the WOOL/SILKP (Handwash) setting, the programme option
3
buttons cannot be used. (Any buttons that are pressed have no effect.)
Consumption Values and Programme Times
The following tables give the values for selected programmes under
standard conditions. The tables do, however, give a helpful guide for
normal household use.
Programme selector/Temperature
COTTONS/LINEN 95 5 56 1.90 130
ENERGY SAVING 60
COTTONS/ LINEN 40 5 52 0.55 11 2
EASY-CARES 40 2.5 56 0.45 76
DELICATES 30 2.5 58 0.35 64
WOOL/SILK P (Handwash) 30 2 52 0.35 52
1) Note: Programme setting for testing in accordance with standard EN60 456.
Actual consumption will vary from the indicated values depending on water
pressure, water hardness, inlet water temperature, room temperature, type and
quantity of washing, detergent used, variations in mains voltage and any option
functions selected.
1)
Load
in kg
5 49 0.94 125
Water
in litres
Energy
in kWh
Time
in minutes
13
Operating Instructions
Before the First Wash
0 1. Pull out the washing powder drawer slightly.
2. Pour about 1 litre of water through the washing powder drawer into
the washing machine. With the next program start, this will close the
solution container and the eco-sluice can function correctly.
3. Run the washing cycle without washing (COTTONS/ LINEN 95 °C, with
half the amount of washing detergent). This removes residues left over
from production on the drum and solution container.
Prepare washing cycle
Sort washing and prepare
• Sort the washing according to the care symbol and type (see "Wash-
ing types and care codes").
• Empty all pockets.
• Remove metal objects (paper clips, safety pins etc.).
• To prevent damage to the washing and tangled washing: Close zip
fasteners, button bed and pillow covers closed, tie up loose strings
e.g. of aprons.
• Turn articles with double layered textiles inside out (sleeping bags,
anoraks etc.).
• In the case of knitted coloured textiles and also with wool and tex-
tiles with jewelry attached: turn inside out.
• Wash small and sensitive items (e.g. baby socks, tights and stockings,
bras etc.) in a washing net, a cushion with a zip fastener or in larger
socks.
• Handle curtains with particular care. Metal rollers or burred, plastic
rollers must be removed or tied into a net or bag. We cannot accept
liability for damage.
• Coloureds and white items must not be washed together in a washing
cycle. This could discolour white washing or turn it grey.
• There is often excess dye in new, coloured items. It is best to wash
such items separately the first time.
• Mix small and large items. This improves the washing effect and the
washing is more favourably distributed during spinning.
• Fluff washing before placing into the washing machine.
14
Operating Instructions
• Do not place folded washing into the drum.
• Pay attention to the care instruction "wash separately" and "wash
separately several times".
Types of Washing and Care Symbols
Care symbols help you to choose the correct wash programme.
Washing should be sorted by type, and according to their care symbols.
The temperature indicated on the care symbol is the maximum wash
temperature.
Cottons ç
Cotton and linen items with this care symbol are not sensitive to machine washing or high temperatures. The COTTONS/LINEN programme is
suitable for this type of washing.
Linen èë
Cotton and linen items with this care symbol are not sensitive to machine washing. The COTTONS/LINEN programme is suitable for this type
of washing.
Easy-Cares êí
Materials such as fine cotton, wool-blend fabrics, viscose, and synthetics with these care symbols require gentler treatment. The EASY-CARES/
EASY IRON programmes are suitable for this type of washing.
Delicatesì
Materials such as layered fibres, microfibres, viscose, synthetics, and net
curtains with this care symbol require particularly careful treatment.
The DELICATES programme is suitable for this type of washing.
Wool/silk and especially sensitive materials 9ìï
Woollens, wool blends and silk with these care symbols are particularly
sensitive to machine washing. The WOOL/SILK P (Handwash) programme is suitable for this type of washing.
Important! Materials with the care symbol ñ (Not machine-washa-
ble!) should not be washed in the washing machine.
15
Operating Instructions
Washing Detergents and Care Agents
Which washing detergent and care agent?
Use only washing detergents and care agents which are suitable for use
in washing machines. Always follow the manufacturer's instructions.
How much washing detergent and care agent?
The amount to be used depends on:
• the dirtiness of the washing
• the hardness category of the mains water supply
• the filling quantity
If the detergent manufacturer gives no details of the dosing quantities
2
for minimum loads, add one third less for half loads and, in the case of
very small loads and for EASY IRON, only half the amount of detergent
recommended for a full load.
Refer to the detergent/care agent manufacturer's instructions on use
and dosage.
Water softener
For medium to high water hardness (hardness class II upwards), you
should use softener. Refer to the manufacturer's instructions. Then always add the appropriate amount of detergent for hardness class I
(= soft). The responisable water works will provide information on the
local water hardness.
Since the water softener is rinsed in before the main detergent (water
2
pre-softening), 80% of the stated quantity of softener shown on the
package is sufficient.
Water hardness details
16
Hardness class
I - soft 0 - 7 to 1.3
II - medium hard 7 - 14 1.3 - 2.5
III - hard 14 - 21 2.5 - 3.8
IV - very hard greater than 21 greater than 3.8
Water hardness in °dH
(German hardness scale)
Water hardness in mmol
(millimol per litre)
Operating Instructions
Running a washing cycle
Brief instructions
A washing cycle consists of the following steps:
0 1. Open the door and load the washing.
2. Close the door.
3. Add detergent/conditioner.
4. Set the appropriate washing programme:
– Set the programme and temperature using the programme selector
– Set programme options as required.
5. Change the Spin Speed /select RINSE HOLD as necessary.
6. Start the washing programme by pressing the START/PAUSE button.
After the washing programme has ended:
Important! If the washing cycle has ended with a Rinse Hold, select
DRAIN or SPIN before opening the door.
7. Open the door and remove the washing.
The door can be opened after the DOOR light goes off and the END
light has come on.
8. To switch off the washing machine: turn the programme selector to
OFF.
17
Operating Instructions
Opening and closing the door
0 To open: pull the door by the handle.
0 To close: push the door firmly shut.
When the machine is switched on,
the DOOR light and the START/
PAUSE light indicate whether the
door can be opened
DOOR indicator START/PAUSE indicator Can the door be opened?
flashes flashes yes, after about 2 minutes
lit lit
is off flashes yes
1) Door is locked due to high water level or high temperature.
If the END light flashes 4 times and an acoustic signal is emitted 4
3
times, it means there was an attempt to start a wash programme without closing the door properly. If this happens, push the door firmly shut
and start the wash programme again.
no
1)
Add the washing
For the maximum filling quantities, see the "Program tables".
3
See "Sort and prepare washing" for information on correctly preparing
the washing.
0 1. Sort and prepare the washing according to type.
2. Open the filling door: Pull on the handle of the filling door.
3. Fill with washing.
Important! When closing the door, make
sure no items of washing get stuck! This
could damage textiles and the unit.
4. Close the filling door securely.
18
Operating Instructions
Adding detergent/conditioners
For instructions concerning detergent and conditioners, see Section
3
"Detergents and conditioners“.
0 1. Open the detergent dispenser drawer:
press the flap on the drawer so as to be
able to grasp the handle (1), and pull
out the drawer (2).
2. Add the detergent/conditioners.
Compartment for main
wash powder detergents
(If you use a water softener and need
the right-hand compartment for the
pre-wash/stain treatment product, add
the water softener to the left-hand
compartment with the main wash detergent.)
Compartment for liquid conditioners
(softeners, finishers, starch)
Important! Do not fill the compartment past the MAX mark. If required,
dilute concentrated fluids up to the MAX mark,
dissolve powdered starches.
Note: A small amount of water remaining in the liquid
conditioner compartment is normal and does not affect
rinse results.
Compartment for Pre-wash detergent
or in-wash stain treatment products
(for the PRE WASH or STAIN programme options only)
or for water softener
3. Push the drawer in fully.
If using liquid detergents/tablets:
3
Add liquid detergent or tablets using the dosage container provided by
the detergent manufacturer. Follow the instructions on the detergent
packaging.
19
Operating Instructions
Setting the washing programme
For the appropriate pro-
3
gramme, temperature and possible programme options
suitable for any type of washing, see "Programme Tables".
0 1. Select the desired wash pro-
gramme and temperature with
the programme selector.
2. If required, select the appropriate programme option(s):
The indicator of the selected programme option
illuminates.
– To change the selection, press another button.
– To cancel a selection, press the button again.
Changing Spin Speed/selecting RINSE HOLD
0 To change the Spin Speed for the final rinse or se-
lect RINSE HOLD:
Keep pressing the Spin Speed/RINSE HOLD button
until the indicator light for the desired speed
(or RINSE HOLD) comes on.
If RINSE HOLD is selected, the washing is left to
soak in the last rinse water, without spinning.
If the Spin Speed is not changed, the final spin is automatically ad-
3
justed to suit the washing programme:
– COTTONS/LINEN 1000 revolutions per minute
– ENERGY SAVING 1000 revolutions per minute
– EASY-CARES/EASY IRON 1000 revolutions per minute
– DELICATES 1000 revolutions per minute
– WOOL/SILKP (Handwash) 1000 revolutions per minute
The speed of intermediate spins depends on the selected programme
and cannot be changed.
20
Operating Instructions
Starting the Wash Programme
0 1. Check that the water tap is open.
2. To start the wash programme, press the START/
PAUSE button. The wash programme starts.
If END flashes 4 times and and an acoustic signal is
3
emitted 4 times when the START/PAUSE button is pressed, the door is
not closed properly. In this case, push the door in firmly, and press
START/PAUSE again.
Programme Progress
Programme Progress Display
Prior to the start, the programme steps chosen
are displayed by the programme progress display.
During the wash programme, the current programme
step is displayed.
Changing the washing programme
Changing or cancelling the programme
0 1. Press the START/PAUSE button.
2. Turn the programme selector to OFF. The washing programme is cancelled.
3. Set another washing programme, if required.
Otherwise, turn the programme selector to DRAIN or SPIN and press the
START/PAUSE button.
(The water is drained or the washing is spun.)
The washing programme can be temporarily interrupted at any time
3
by pressing the START/ PAUSE button. It is then re-started by pressing
the button again. A washing programme can only be changed after the
programme selector has been turned to OFF.
Selecting a programme option
The programme options QUICK or STAIN can still be selected after the
programme has started.
0 1. Press the START/PAUSE button.
2. Press the QUICK or STAIN button.
3. Press the START/PAUSE button. The washing programme continues.
21
Operating Instructions
Changing the Spin Speed
The Spin Speed can still be changed or RINSE HOLD set, while the programme is running.
0 1. Press the START/PAUSE button.
2. Change the spin speed with the Spin Speed/RINSE HOLD button.
3. Press the START/PAUSE button again. The washing programme contin-
ues.
Washing cycle complete/removing the washing
Once a washing programme cycle has come to an end, END illuminates
on the Programme Progress Display.
If RINSE HOLD was selected, the indicator lights beside DOOR and END
come on.
0 1. After a Rinse Hold, the water must first be drained:
– Either turn the programme selector to OFF, then turn to DRAIN and
press the START/ PAUSE button (the water is drained without spinning),
or
– turn the programme selector to OFF, then turn to SPIN and press the
START/ PAUSE button (the water is drained and the washing given a
spin. The spin speed can also be changed during the spin cycle).
When this stage of the programme is completed, the END light
comes on.
2. Open the door.
The door can be opened after the DOOR light goes off and the END
light has come on.
3. Remove the washing.
4. Turn the programme selector to OFF.
5. Close the water tap.
6. After the washing cycle is completed, pull out the detergent dispenser
drawer slightly, to allow it to dry. Leave the door slightly open, to air
the inside of the washing machine.
Important! If the washing machine is not used for a long time:
Close the water tap and disconnect the washing machine from the
electricity mains.
22
Operating Instructions
Programme Tablesbles
Washing
The tables do not show all the possible settings, only those most likely
to be selected for everyday purposes.
Type of washing,
Care symbol
Cottons
ç
Cottons/Coloureds
è ç
Coloureds
èë
Easy-cares
êí
Delicates
ì
Wool/Silk (Handwash)
9ìï
3)
Max. Load
(Dry weight)
(or 15-20m
net curtains)
1)
Programme selector
2)
Temperature [in °C]
5kg
5kg ENERGY SAVING
5kg
2.5kg
1kg
2.5kg
2kg
COTTONS/LINEN
95
COTTONS/LINEN
30 to 60
EASY-CARES
40, 60
EASY IRON
40
DELICATES
2
30, 40
P
WOOL/SILK
COLD, 30
Possible
programme
options
PRE WASH
or STAIN
QUICK
PRE WASH
or STAIN
PRE WASH
or STAIN
QUICK
PRE WASH
5)
or STAIN
QUICK
PRE WASH
QUICK
4)
1) The load amount inquiry operates in accordance with the EN 60456 standard
load.
2) A 10 litre bucket holds around 2.5 kg of dry clothes (cotton).
3) Programme settings for testing in accordance with or in support of EN 60 456
and IEC 60 456 are described in the chapter "Consumption Values and Programme Times“.
4) A temperature of at least 40 °C is needed for the STAIN programme, to make
stain treatment products effective.
5) Creasing can largely be avoided, but only by keeping wash loads under 1 kg,
About 1 kg of dry clothes is equivalent to between 5 and 7 easy-care men's
shirts.
23
Operating Instructions
Separate Rinsing
Type of washing
Cottons/ Coloureds 5kg
Easy-Cares/Delicates
1) Reduced spin speed
Separate Spinning
Type of washing
Cottons/Coloureds 5kg
Easy-Cares
Delicates
Wool/Silk (Handwash)
1) Reduced spin speed.
1)
1)
Max. load
(dry weight)
1)
1)
2.5kg
Max. load
(dry weight)
2.5kg
2.5kg
2kg
Programme selector
GENTLE RINSE
Programme selector
SPIN
24
Operating Instructions
Cleaning and Care
Control panel
Important! Do not use any furniture cleaning agents or aggressive
cleaning agents in order to clean panel and control parts.
0 Wipe control panels with a damp cloth. When doing so, use warm wa-
ter.
Detergent Drawer
The detergent drawer should be cleaned from time to time.
0 1. Pull the detergent drawer out as far as it will go.
2. Remove the detergent drawer by pulling sharply.
3. Take the conditioner insert out of the
middle compartment.
4. Clean the conditioner insert under
running water.
5. Clean the compartments with warm
water from the rear side. It is best to
use a flat brush.
6. Push on the conditioner insert as far as it will go so that it is securely in
place.
25
Operating Instructions
7. Use a brush to clean the entire
rinsing-in section of the washing
machine, particularly also the nozzles on the top side of the rinsingin chamber.
8. Set the detergent drawer into the
guide tracks and push in.
Washing Drum
The washing drum is made of stainless steel. Rusting foreign bodies in
the washing can cause rust deposits on the drum.
Important! Do not clean the stainless steel drum with decalcifying
agents containing acids, scouring agents containing chlorine or iron, or
steel wool. Our Customer Service can provide suitable agents.
0 Remove any rust deposits on the drum using a stainless steel cleaning
agent.
Main door
0 Check on a regular basis to see if deposits or foreign objects are present
in or at the rubber sleeve behind the door, and remove.
Cleaning the drain pump
Paper clips, nails and so on can sometimes get into the washing machine with the washing and remain in the drain pump casing. Fluff and
strands of fabric can gather on these items and block the drain pump.
Therefore the drain pump should be cleaned at least once a year.
26
Operating Instructions
Warning! Switch off the washing machine and pull out the mains plug
1
before cleaning the drain pump!
0 1. First carry out emergency emptying (see section "Carrying out emer-
gency emptying").
2. Place a towel on the floor in front of the cover of the drain pump. Residual water can run out.
3. Unscrew the drain pump cover anticlockwise and pull it out.
4. Remove any foreign objects, fluff and
strands of fabric from the drain pump.
5. Check that you are able to turn the
pump wheel at the very rear of the
pump housing. (If the wheel rotates
with a jerky motion, this is normal.) If
you cannot turn the pump wheel, contact customer service.
6. Replace the cover. Insert the webs on
the cover laterally into the guide slots
and screw on the cover securely clockwise.
7. Close the emergency emptying hose and
place it in the holder.
8. Close the flap.
27
Operating Instructions
What to do if ...
Remedying Faults
In the event of a fault, try to solve the problem yourself with the aid of
the information provided here. If you call Customer Service to deal
with one of the faults listed here or to remedy an operating fault, the
customer service technician's visit will not be free of charge, even during the warranty period.
Problem Possible cause Remedy
The mains plug is not inserted. Insert the mains plug.
The house fuse has blown. Replace the fuse.
The washing machine does not
work.
The door cannot be
closed.
The display flashes
4 times and and an
acoustic signal is
emitted 4 times
The END light
flashes once an
acoustic signal is
emitted once.
The door is not closed properly.
The START/ PAUSE button was
not pressed for long enough.
The child safety feature is engaged.
The door is not closed properly.
The water tap is closed.
The filter in the socket of the
inlet hose is blocked.
Water tap is blocked with
limescale or is faulty.
Close the door.
There should be an audible
click.
Press and hold the START /
PAUSE button until the pro-
gramme starts.
Release child safety feature
(see Section "Child Safety Feature").
Close the door properly.
Start the programme again.
Open the water tap.
Start the programme again.
Close the water tap.
Disconnect the hose from the
water tap, remove the filter
and clean under running water.
Check the water tap and have
it repaired if necessary.
28
Operating Instructions
Problem Possible cause Remedy
The washing machine vibrates when
operating, or is
noisy.
Excessive foaming
during the main
wash.
Transit packaging was not removed.
The machine is not level.
There is very little washing in
the drum (for example one
dressing gown).
Water could not be fully
drained out before spinning
because the drain hose is
kinked or the water pump is
blocked.
Probably too much detergent
has been used
The screw connection of the
inlet hose is leaking.
The drainage hose is leaking.
Remove the transit packaging
as described in the Installation
and Connection instructions.
Adjust the feet according to
the Installation and Connection instructions.
This does not affect the operation of the machine.
Check the drain hose and remove any kinks if necessary or
clean the water pump and if
necessary remove any foreign
bodies from the pump housing.
It may be necessary to reduce
the amount of detergent used.
Follow the detergent manufacturer's recommendations.
Tighten the inlet hose screw
connection.
Check the drainage hose and
replace if necessary.
Water leaks out
of the washing machine.
Fabric softener was
not rinsed in, the
æ compartment is
filled with water.
The drain pump cover is not
correctly closed.
Washing is caught in the door.
The emergency emptying hose
is not correctly closed or is
leaking.
The insert in the conditioner
compartment is not correctly
attached or is blocked.
Close the cover correctly.
Stop the programme, remove
the washing caught in the
door. Restart the programme.
Close the emergency emptying hose (see Section "Carry
out emergency emptying“).
Call your local Service Force
Centre if the emergency emptying hose is leaking.
Clean the detergent dispenser
drawer and attach the conditioner insert correctly.
29
Operating Instructions
Problem Possible cause Remedy
Washing is heavily
creased.
Pay attention to the maximum
Probably too much washing
has been put in the drum.
The drain hose is kinked. Remove the kink.
load quantity (see Programme
Tables). In the case of easycare fabrics, select the EASY
IRON programme.
Washing is not
thoroughly spun,
water remains visible in the drum.
The END light
flashes twice, an
acoustic signal is
emitted twice.
The door cannot be
opened when the
washing machine
is on.
START/PAUSE
and DOOR lights
come on.
Power failure during a wash programme (all
indicator lights
are off).
The maximum pump height
(outlet height 1 m from
the base of the appliance)
is exceeded.
The drain pump is blocked.
For siphon attachments:
the siphon is blocked.
Door is locked due to high
water level, or high temperature.
The failure may be caused by
a blown house fuse or by a
mains supply fault into the
house.
(For safety reasons, the door
remains locked for around
2minutes.)
Contact your local Service
Force Centre. For pumping
heights over 1 m a conversion
kit is available as a special accessory.
Switch off the machine and
disconnect the mains plug.
Clean the drain pump.
Clean the siphon.
Wait until the programme has
ended, the DOOR light goes off
and the END light is lit.
If it is necessary to open the
door immediately,
Turn the programme selector
to OFF; then turn it to DRAIN.
Press the START/PAUSE button.
When the water has been
pumped out, the door can be
opened.
The programme continues
when power is restored.
If washing has to be taken out
during a power cut:
Turn the control knob to OFF.
Carry out emergency emptying
(see Section "Carry out emergency emptying“).
After about 2 minutes,
the door can be opened by
pulling on the handle.
30
Operating Instructions
Problem Possible cause Remedy
Remnants of detergent are building
up in the detergent
drawer.
The rinse water is
cloudy.
When pressing
a programme option button,
the corresponding
indicator does not
light up.
The water tap is not fully
opened.
The inlet hose filter in the in
coupling of the inlet hose at
the tap is blocked.
The cause is probably a detergent with a high silicate content.
The selected programme option cannot be combined with
the set programme.
Open the water tap fully.
Close the water tap. Unscrew
the inlet hose from the water
tap and from the machine.
Clean the filter.
This has no negative effects on
rinse results; use a liquid detergent if necessary.
Make another selection.
31
Operating Instructions
If the washing results are not satisfactory
If the washing has turned grey and if limescale is deposited in the
drum, then
• Too little detergent was used.
• The wrong detergent was used.
• Special soiling was not pre-treated.
• Program or temperature not set correctly.
• If multi-component detergents are used, the individual components
were not used in the correct ratio.
If there are still grey spots on the washing,
• Washing soiled with ointments, grease or oils was washed with too
little detergent.
• Too lower temperature was used for washing.
• A frequent cause is that softener - particularly that in concentrated
form - has reached the washing. Wash out such spots quickly and use
the softener concerned carefully.
If at the end of the last rinse foam is still visible
• Modern detergents can also cause foam in the last rinse. However,
the washing is still sufficiently rinsed.
32
If there are white remnants on the washing
• These are insoluble components of modern detergents. They are not
the result of an insufficient rinsing effect.
Shake or brush out the washing. In future, perhaps you should turn
the washing inside out before washing it. Examine your choice of detergent and if necessary use liquid detergent.
Operating Instructions
Carrying out emergency drainage
• If the washing machine no longer pumps off the washing solution,
emergency drainage must be performed.
• If the washing machine is in a room where there is a risk of frost,
emergency drainage must be performed if there is a possibility of
frost.
In addition: unscrew the inlet hose form the water tap and place it on
the floor. Empty the drainage hose.
Warning! Switch off the washing machine before performing emer-
1
gency drainage and pull out the mains plug.
Caution! The washing solution escaping from the emergency drainage
hose may be hot. There is a risk of scalding! Allow the washing solution
to cool down before performing emergency drainage.
0 1. Place a flat collecting vessel in order to collect the washing solution
which is draining off.
2. Fold open the flap in the right section
of the base outwards and pull it off.
3. Remove the emergency drainage hose
from its holder.
4. Place the container under the hose.
5. Detach the plug of the emergency
drainage hose by turning it anticlockwise and pull it out.
The washing solution runs out. Depending on the amount of solution, it may
be necessary to empty the collecting
vessel several times. To do this, close the
emergency drainage hose temporarily
with the plug.
33
Operating Instructions
When the water is completely drained:
6. Push the plug securely into the emergency drainage hose and turn it
clockwise to secure it.
7. Replace the emergency drainage hose in its holder.
8. Put on the flap and close.
Additional rinse cycles (RINSE+)
The washing machine is set for very economical water consumption.
However, for people who suffer from allergies, it can be helpful to rinse
with extra water.
If RINSE+ is set, two extra rinse cycles are added to the COTTONS/
3
LINEN, EASY-CARES/EASY IRON and DELICATES programmes.
When the machine is delivered, no additional rinse cycles are set.
To set additional rinse cycles:
1. Turn programme knob to COTTONS/LINEN, EASY-CARES/EASY IRON or
DELICATES (any temperature).
2. Press and hold the PRE WASH and QUICK buttons at the same time for
at least 2 seconds. RINSE and RINSE+ light up on the programme
progress display. The additional rinse cycles are now set. They remain
stored until cancelled again.
Additional rinse cycles increase both water consumption and pro-
3
gramme duration.
To cancel the additional rinse cycles:
1. Turn the programme knob to COTTONS/LINEN, EASY-CARES/EASY IRON
or DELICATES again.
2. Press and hold the PRE WASH and QUICK buttons at the same time for
at least 2 seconds. RINSE+ lights up on the programme progress display.
The additional rinse cycles are now cancelled.
34
Child Safety Feature
If the child safety feature is set,
the filling door can no longer be
closed and no washing program
can be started.
Setting the child safety feature
0 Use a coin to turn the rotary knob
on the inside of the filling door
clockwise as far as it will go.
Warning! The rotary knob must
1
not be in a vertical position after
adjustment, otherwise the child
safety feature is not active. The rotary knob must project as shown in
the diagram
Cancelling the child safety
feature
0 Turn the rotary knob anticlockwise
as far as it will go.
Operating Instructions
35
Installation and connection instructions
Installation and connection instructions
Installation Safety Precautions
• Do not tilt the washing machine onto its front or onto its right side
(viewed from the front). Electronic components can get wet.
• Check the washing machine for transport damages. A damaged unit
must never be put into operation under any circumstances. In the
event of damage, please contact your supplier.
• Ensure that all parts of the transport safeguard are removed and that
the unit is splash protected, see "Removing transport safeguard".
Otherwise, the units or neighbouring furniture can be damaged when
spinning.
• Always insert the plug into a correctly installed earthed socket.
• In the case of permanent connection: A permanent connection may
only be made by an authorised specialist.
• Before putting the machine into operation, ensure that the mains
voltage and current type shown on the unit's rating plate correspond
with those at the place where the machine is being installed. The fuse
rating is also found on the rating plate.
• Should work be carried out on the water supply installations in order
to allow the machine to be connected properly to the water supply,
this work must be carried out by an authorised installer.
• Should work be carried out on the mains supply in order to allow the
machine to be connected properly to the electricity supply, this work
must be carried out by an authorised electrician.
• The mains lead may only be replaced by the customer service or by an
authorised electrician.
36
Installation and connection instructions
Installation of the appliance
Washing machines with curved panels are not suitable for installing
3
under units.
Transporting the appliance
• Do not place the washing machine on its front or on its right side
(viewed from the front). Otherwise, electrical components can get
wet.
• Never transport the unit without the transport safeguard. Do not re-
move the transport safeguard until the appliance is at the installation
location. Transporting the unit without the transport safeguard can
damage it.
• Lift the appliance neither by an open filling door nor by the base.
• When transporting the unit with a sack trolley: Attach the sack trol-
ley only at the side.
Remove transport packaging
Important! It is essential to re-
move the transport packaging before putting the appliance into
operation. Keep all parts of the
transport packaging in a safe
place for future use.
0 1. Open both hose holders on the
appliance's rear side and remove
the hoses and mains cable.
2. Pull both hose holders off the appliance with a strong pull.
37
Installation and connection instructions
The special spanner (A) and the
3
caps (B) (2 each) and (C) (1 each)
are supplied with it.
3. Remove the screw D, including
the compression spring with the
special spanner A.
4. Cover the hole with the cap C.
Important! When fitting the
plastic caps, press until they snap
into the rear panel securely.
5. Remove the two screws (E) with
the special spanner (A).
6. Remove the 4 screws (F).
7. Remove the transit bar (G).
8. Screw the 4 screws (F) back in for
safe keeping.
9. Close the 2 large holes with the
caps (B).
Important! When fitting the
plastic caps, press until they snap
into the rear panel securely.
38
Installation and connection instructions
Prepare the installation place
• The installation surface must be clean and dry, free of floor polish
residues and other greasy coatings so that the unit does not slip
away. Do not use lubricants as a sliding aid.
• Installation on a high-veil carpet or floor tiles with soft sponge backs
is not recommended because the standing safety of the appliance is
then no longer ensured.
• By installation surfaces with small-format tiles, lay a conventional
rubber mat underneath.
• Minor unevenness of the floor surface should never be levelled out by
laying pieces of wood, card or similar materials, but rather should always be compensated for by adjusting the screw feet.
• If, for space reasons, it is not possible to avoid setting up the unit di-
rectly next to a gas or coal-fired cooker: install a thermal insulation
panel between the cooker and washing machine (85 x 57cm) which
must have an aluminium film on the side against the cooker.
• The washing machine must not be set up in a room where there is a
danger of frost. Frost hazard!
• Flexible feed and drain tubings may not be crinkled or squeezed.
Installation on a concrete base
If the unit is set up on a concrete base,
for safety reasons it is essential to fit
stand plates in which the washing machine is adjusted. The stand plates are
available from Customer Service under
the spare parts number 645 425 058.
Installation on vibrating floors
Where the floor vibrates, particularly in the case of wooden beam
floors with pliable boards, securely screw a water-resistant wooden
panel at least 15mm thick onto at least 2 floor planks. If possible, set up
the unit in the corner of a room, as the wooden floor is optimally restrained there and is therefore least likely to be subject to resonance vibrations.
39
Installation and connection instructions
Compensate for floor unevenness
Floor unevenness can be compensated for and the height can be corrected with the four adjustable screw feet. The height can be adjusted
in the range +10 .. -5mm.
To adjust the feet use the special spanner supplied for removing the
transport braces.
0 1. Slide the special key firmly onto
the hexagon head of the threaded foot as far as it will go.
2. Adjust the screw feet so that the
unit is horizontal and stable. The
unit must not wobble over when
loaded.
3. If necessary, check the setting
with a spirit level.
Important! Minor unevenness of
the floor surface should never be
levelled out by laying pieces of
wood, card or similar materials,
but rather should always be compensated for by adjusting the adjustable feet.
40
Installation and connection instructions
Electrical connection
Details of the mains voltage, current
type and required fuses can be
found on the rating plate. The rating plate is located at the top
above the filling door.
For permanent electrical connection
within the electrical circuit, provisions must be made which allow for electrical disconnection of the appliance from the mains with a contact opening of at least 3 mm at all
poles. Suitable devices include circuit breakers, fuses (threaded fuses
must be entirely removed from the socket), ground fault circuit interrupters and contactors. Permanent connection may only be carried out
by an authorised electrician.
This appliance complies with the following EC directives:
;
– The "Low Voltage Directive" 72/23/EU with changes
– The "EMC Directive" 89/336/EU with changes
Water connection
The washing machine has safety features which prevent back-contami-
3
nation of the drinking water and which conform to the national regulations of the water authorities (e.g. for Germany: DVGW guidelines).
This means that additional protective measures in the installation are
not necessary.
Important!
– Units for connecting to cold water must not be connected to hot wa-
ter.
– Use only new hose sets for the connection.
Permissible water pressure
The water pressure must be at least 1 bar (= 10 N/cm2 = 0.1 Mpa), maximum 10 bar = 100 N/cm
• If more than 10 bar: Connect a pressure-reduction valve upstream.
• If less than 1 bar: Unscrew the inlet hose on the unit side at the sole-
noid intake valve and remove the flow regulator (to do this, remove
the filter with pointed pliers and take out the rubber washer behind).
Replace the filter.
2
= 1 Mpa).
41
Installation and connection instructions
Water inflow
A pressure hose of 1.35m in length is supplied.
If a longer inflow hose is required, only a VDE-approved, complete set
of hoses with fitted hose screw connections offered by our Customer
Service is permissible.
– Hose sets in lengths of 2.2m, 3.5m and 5m are available for washing
machines without Aqua-Control.
– Hose sets in lengths of 2.0m, 2.9m and 3.5m are available for washing
machines with Aqua-Control.
Important! Never cut into pieces in order to extend the hoses!
Sealing rings are supplied either in the plastic
3
nuts of the hose screw connection or in the enclosed pack. Do not use other seals!
0 1. Connect the hose with the angled connection to
the machine.
Important!
– Do not lay the inlet hose verti-
cally downwards, instead run it
to the right or left as shown in
the diagram.
– Tighten the hose screw connec-
tion only by hand.
2. Connect the hose with the
straight connection to a water valve with a
screw thread R 3/4 (inches).
Important! Only tighten the screw connection
manually.
3. By slowly opening the water valve before
putting the washing machine into operation,
check that the connection is free of leaks.
42
Installation and connection instructions
Water drain
The drainage hose can either be connected to a siphon or hung in a
wash basin or discharge basin or a bath tub.
Only original hoses may be used for extensions (max. 3m laid on the
floor and then up to 80cm high). Customer Service stocks drainage
hoses in lengths of 2.7 and 4m.
Important! It is essential to lay the drainage hose without kinks.
Water drain-off inside a siphon
The grommet on the hose end fits all
standard siphon types.
0 Secure the connection between the
grommet and siphon with a hose clamp.
Water drain-off inside a basin
Important!
– Small basins are not suitable for
drainage. Water could overflow!
– The end of the drainage hose must not
be submerged in the pumped-out water. Otherwise, the water could be
sucked back into the unit.
– When hanging in a wash basin or a
bath tub, the drainage hose must be
secured with the supplied attachable
bend to prevent it slipping. The backsurge force of the escaping water
could otherwise force the hose out of
the basin.
0 Tie the bend to the tap or the wall using
a piece of string.
Delivery heads over 1m
To pump off the washing / rinsing solution, every washing machine has
a drain pump which carries liquids up to a height of 1m via the drainage hose, calculated from the machine's standing surface.
Please contact Customer Service for delivery heads of over 1m.
43
Installation and connection instructions
Technical data
Adjustment possibility Approx. +10 / -5mm
Filling quantity (program-dependent) max. 5kg
Area of use Domestic
Drum speed, spinning See rating plate
Water pressure 1-10 bar (= 10 - 100 N/cm
= 0.1 - 1.0 Mpa)
Dimensions
2
44
(dimensions in mm)
Warranty conditions / Customer service centres
Warranty conditions / Customer service
centres
Weitere Kundendienststellen im Ausland
In diesen Ländern gelten die Garantiebedingungen der örtlichen Partner. Diese können
dort eingesehen werden.
Further after-sales service agencies overseas
In these countries our AEG agents’ own guarantee conditions are applicable. Please obtain further details direct.
Autres agences étrangères assurant le service après-vente
Dans ces pays, les conditions de garantie des concessionnaires de la région sont valables. Vous pouvez les consulter sur place.
Otros puntos de Postventa en el extranjero
En estos países rigen las condiciones de nuestros representantes locales. las cuales
pueden ser consultadas allí mismo.
Ulteriori uffici del servizio tecnico assistenza clienti all’estero
In questi paesi sono valide le condizioni di garanzia dei partner locali. Queste condizioni
possono essere esaminante sul luogo.
Serviços de assistência técnica no estrangeiro
Nestes países são válidas as condições de garantia dos concessionários locais, podendo
aí ser consultadas.
U.A.E. Abu Dhabi
Universal Trading Company
P.O. Box 43 99
Tel.: 335331
Egypt
Middle East Commercial
Center
P.O. Bo x 19
Kairo-Heliopolis
Tel.: 29917/31634
Australia
ANDI-Co Pty. Ltd
9 Kingston Town Close
Oakleigh VIC 3166
Tel.: (03) 9569 1235
Fax: (03) 9569 1450
Jordan
Jordan Household
Supply Co. Ltd.
P.O. Box 3/68
Amman/Tel.: 69 70 50
Kanada
EURO-LINE Appliances
2150 Winston PARK Drive 20
Oakville, Ontario L6H 5V1
Tel.: 905 829 3980
Fax: 905 829 3985
Korea (South)
Core Incorp.
3/F Chewoo Bldg.
200 Nonhyun-Dong
Kangnam-Ku
Seoul
Telefon 82 2 549 89 61
Malta
ITC
International Trading Company
White House Building
Mountbatte Street
Blata L-Bajda/Tel.: 220644
Mauritius
Happy World Centre Ltd.
P.O. 7 54
1 Chausee Street
Port Louis
Tel.: 25355
Namibia
AEG NAMIBIA (PTY) LIMITED-Jeppe Street
Northern Industrial Area
Windhoek
Tel.: (061) 21-6082/4
Fax: (061) 217838
45
Warranty conditions / Customer service centres
Bahrain/Arabian Gulf
A.A. Zayani & Sons
P.O. Box 9 32
Bahrain
Tel.: 261060
Bulgaria
Electrolux Bulgaria E.O.O.D.
91 Levski Blvd.
1000 Sofia
Tel.: 2 806676
Fax. 2 980 5276
Cyprus
Hadjikyrlakos & Sons Ltd.
Prodromou 121
P.O. Box 21587
Nicosia 1511
Service Telephones:
Nicosia 02 481226
Limassol 05 562182
Larnaca 04 633929
Paphos 06 932 699
Estonia
Electrolux Estonia Ltd.
Mustamäe tee 24
EE0006 Tallinn
Tel.: (372) 6 650 090
Fax: (372) 6 650 092
Croatia
Electrolux D.O.O.
Suplova 7
10000 Zagreb
Tel.: 1 61 19512
Fax: 1 61 19513
Kuwait/Arabian Gulf
Ali Al-Ghanim Est.
P.O. Box 10 83
Tel.: 5322463
Fax: 5242114
Lebanon
Adib & Assaferi
P.O. Box 539
Tripoli
Latavia
Electrolux Latavia Ltd.
Terlaton Street 42/44
1011 Riga
Tel.: 371 2 297821
Fax: 371 2 821286
New Zealand
Euro-Life New Zealand Ltd.
Privat Bag
58 Symonds Street
Auckland
Tel.: (09) 525 2222
Nouvelle Caledonie
Socometra N.C.
B.P. 483
Nouman
Tel.: 275444
Oman
Moshin Haider Darwish
P.O. Box 1 35
Muscat
Tel.: 703743
Poland
Electrolux Poland Sp. zo.o.
ul. Domaniewska 41
02-034 Warszawa
tel.: 022 874 33 33
fax: 022 874 33 00
46
Hongkong
Wo Kee Services Ltd.
585-609 Castle Peak Road
Kwai Chung N.T.
Hongkong
Tel.: 2494 4000
Lthuania
Electrolux Lthuania
Verkui 29
2600 Vilnus
Tel.: 372 272 3326
Fax: 372 272 3366
Russia
Electrolux Russia Ltd.
16 Olympiysky prospekt
129090 Moscow
Tel.: (095) 937 7837
Fax: (095) 926 5513
Warranty conditions / Customer service centres
Israel
Electricity & Electronic
Services-Evis LTD.
19 Hataasia st.
Raanana,
Industrial area 43654
Tel: 972-9-7448118
Fax: 972-9-7603618
e-mail:evis@evis.co.il
Japan
Electrolux Japan Ltd.
Domestic Appliances Department
Maruzen Showa Warehouse
Building
Tookai 4-5-12, Ota-ku
143-006 Tokyo
Tel.: 0120-13-7117
Fax: 03-3790-5257
Thailand
OLYMPIA Thai Ltd.
44 Ratchadapisek Road
10320 Bangkok
Tel.: 2 513 6111
Fax: 2 513 2574
Malaysia
Arzbergh Engineering
No. 49A/B, Jalan Petaling
Utama 7
4600 Petaling Jaya
Tel.: 3 795 1084
Fax: 3 795 1082
Singapore
Arzbergh Engineering
19 Tanglin Road 06-07
Singapore 247909
Tel.: 65 7356572
Fax: 7351124
Slovakia Rep.
Electrolux Slovakia S.R.O.
Seberiniho 1
821 03 Bratislava
Tel.: 02 4333 4322, 4355
Fax: 02 4333 6976
Saudi Arabia
Alia Trading Corporation
P.O. Box 4101
King Abdul Aziz Street
Riyadh
Tel.: 4645977
Al Nahas Est.
Musaidia Market I
P.O. Box 1 15 29
Jeddah
Tel.: 6606852
Slovenia
Electrolux Slovenia D.O.O.
Traska Ul. 132
1000 Ljubljana
Tel.: 61 1234 137
Fax: 61 1234 238
South Africa
AEG (Pty) Ltd.
55, 12th Road
P.O. Box 1 02 64
Kew/Johannesburg 2000
Tel.: 8069111
Hungary
Electrolux Lehel KFT
(AEG Div)
Erzsebet’Kiralyne Utja 87
1142 Budapest
Tel.: 00361/251 84 44
USA
ANDI Co. Appl. Inc. East
65 Campus Plaza
Edison, New Jersey 0837
USA/Tel.: (201) 2258839
Syria
Masri & Shami
P.O. Box 24 96
Damascus
Tel.: 214080
47
48
49
Index
Index
C
Cancelling the programme . . . . . . . . . . . . 21
Care agent
Changing the programme
Child safety feature
Coloureds
Conditioner
Cottons
Curtains
Customer Service
. . . . . . . . . . . . . . . . . . . . . . . . . . 16
. . . . . . . . . . . . . 21
. . . . . . . . . . . . . . .28, 35
. . . . . . . . . . . . . . . . . . . . . . . .11, 23
. . . . . . . . . . . . . . . . . . 10, 17, 19
. . . . . . . . . . . . . . . . . . . . . . 11, 15, 23
. . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
. . . . . . . . . . . . . 26, 28, 51
D
Delicates . . . . . . . . . . . . . . . . . . . . . 12, 15, 23
Detergent
Detergent dispenser drawer
Drain
Drain pump
. . . . . . . . . . . . . . . . . 10, 16, 17, 19
. . . . . . . . .10, 19
. . . . . . . . . . . . . . . . . . . . . . . . 12, 21, 22
. . . . . . . . . . . . . . . . . . . . . .10, 26
E
Easy iron . . . . . . . . . . . . . . . . . . . . . . . . .12, 23
Easy-cares
Emergency drainage
Energy saving
. . . . . . . . . . . . . . . . . . . 12, 15, 23
. . . . . . . . . . . . . . . . . . 33
. . . . . . . . . . . . . . . . . . . . . . . 12
G
Gentle rinse . . . . . . . . . . . . . . . . . . . . . .12, 24
H
Handwash . . . . . . . . . . . . . . . . . . . 12, 23, 24
I
In-wash stain treatment . . . . . . . . . . . . . . 10
L
Linen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Load
. . . . . . . . . . . . . . . . . . . . . . . . . . . .13, 23
N
Net curtains . . . . . . . . . . . . . . . . . . . . . . . . . 23
O
Opening the door . . . . . . . . . . . . . . . . .18, 30
P
Pre-wash . . . . . . . . . . . . . . . . .12, 19, 20, 23
detergent
Programme progress display
. . . . . . . . . . . . . . . . . . . . . .10, 19
. . . . . . . . . . . 21
Q
Quick . . . . . . . . . . . . . . . . . . . .13, 20, 21, 23
R
Rating plate . . . . . . . . . . . . . . . . . .10, 41, 51
Rinse hold
Rinse+
Risk of frost
. . . . . . . . . . . . . . . . . . . .12, 20, 22
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
. . . . . . . . . . . . . . . . . . . . . . 6, 33
S
Silk . . . . . . . . . . . . . . . . . . . . . . . . . .12, 15, 24
Sluice
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Softener
Spin
Spinning
Stain
. . . . . . . . . . . . . . . . . . . . . . . . 10, 19
. . . . . . . . . . . . . . . . . . . . . . . . . . . . 17, 22
. . . . . . . . . . . . . . . . . . . . .12, 20, 24
. . . . . . . . . . . . . . 9, 13, 20, 21, 23, 32
W
Warranty . . . . . . . . . . . . . . . . . . . . . .6, 28, 45
Washing
coloureds
lightly soiled
normally dirty
Washing powder
Water
hardness
softener
Wool
hand washable
. . . . . . . . . . . . . . . . . . . . . . . . .14
. . . . . . . . . . . . . . . . . . . . . . . .9
. . . . . . . . . . . . . . . . . . . . . . . 9
. . . . . . . . . . . . . . . . . . . . .16
. . . . . . . . . . . . . . . . . . . . . . . 9, 16
. . . . . . . . . . . . . . . . . . . . . 9, 16, 19
. . . . . . . . . . . . . . . . . . . . 12, 15, 23, 24
. . . . . . . . . . . . . . . . . 12, 23
50
Service
In the chapter "What to do if...“ , some faults are listed which you can
remedy yourself. Look there first if a fault occurs. If you do not find any
information there, please consult your Customer Service. (You can find
the addresses and telephone numbers in the section "Customer Service
Centres“.)
Always prepare in advance for the discussion. By doing so you will simplify the diagnosis and the decision on whether customer service is
necessary.
Note the PNC number and
S. number. You will find both on the
rating plate on the inside of the door
of your washing machine.
PNC .....................................................
S. No. .....................................................
Answer as precisely as possible:
• What form does the fault take?
• Under what circumstances does the fault occur?
Service
When do you incur costs even during the warranty period?
– If you could have remedied the fault yourself with the aid of the fault
table (see the section "What to do if..."),
– If several journeys by the customer service technician are necessary
because for example he did not receive all the important information
before his visit and must collect spare parts. These multiple trips can
be avoided if you prepare your phone call as described above.
51
From the Electrolux Group. The world´s No.1 choice.
The Electrolux Group is the world´s largest producer of powered appliances for kitchen, cleaning and outdoor
use. More than 55 million Electrolux Group products (such as refrigerators, cookers, washing machines,
vacuum cleaners, chain saws and lawn mowers) are sold each year to a value of approx. USD 14 billion in more
than 150 countries around the world.
AEG Hausgeräte GmbH
Postfach 1036
D-90327 Nürnberg
http://www.aeg.hausgeraete.de
© Copyright by AEG
822 943 530-01-220103-01
Subject to change without notice
Loading...
