AEG WASL2E 200, WASLEEV 200 User Manual [da]

WASL2E 200 WASLEEV 200
................................................ .............................................
EN WASHING MACHINE USER MANUAL 2 DE WASCHMASCHINE BENUTZERINFORMATION 28
2 electrolux
Electrolux. Thinking of you.
Share more of our thinking at www.electrolux.com
CONTENTS
Before first use 13 Using the appliance 13 Hints and tips 16 Care and cleaning 17 Troubleshooting 21 Installation 23 Environment concerns 26
Subject to change without notice.
SAFETY INFORMATION
Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use causes injuries and dam­ages. Always keep the instructions with the appliance for fu­ture reference.
CHILDREN AND VULNERABLE PEOPLE SAFETY
Warning! Risk of suffocation, injury or permanent disability.
• This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the haz­ards involved.
• Do not let children play with the appliance.
• Keep all packaging away from children.
• Keep all detergents away from children.
• Keep children and pets away from the appliance door when it is open.
• If the appliance has a child safety device, we recommend you activate it.
• Cleaning and user maintenance shall not be made by chil­dren without supervision.
electrolux 3
GENERAL SAFETY
• Before maintenance, deactivate the appliance and discon­nect the mains plug from the mains socket.
• Do not change the specification of this appliance.
• Obey the maximum load volume of 8 kg (refer to the “Pro­gramme chart” chapter).
• If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
• The operating water pressure (minimum and maximum) must be between 0,5 bar (0,05 MPa) and 8 bar (0,8 MPa)
• The ventilation openings in the base (if applicable) must not be obstructed by a carpet.
• The appliance is to be connected to the water mains using the new supplied hose-sets. Old hose sets must not be reused.
SAFETY INSTRUCTIONS
INSTALLATION
• Remove all the packaging and the transit
bolts.
• Keep the transit bolts. When you move
the appliance again you must block the drum.
• Do not install or use a damaged appli-
ance.
•Do not install or use the appliance where
the temperature is less than 0 °C or where it is exposed to the weather.
• Obey the installation instruction supplied
with the appliance.
• Make sure that the floor where you install
the appliance is flat, stable, heat resistant and clean.
• Do not install the appliance where the ap-
pliance door can not be fully opened.
• Always be careful when you move the
appliance because it is heavy. Always wear safety gloves.
• Make sure that there is air circulation be-
tween the appliance and the floor.
• Adjust the feet to have the necessary space between the appliance and the carpet.
Electrical connection
Warning! Risk of fire and electrical
shock.
• The appliance must be earthed.
• Make sure that the electrical information on the rating plate agrees with the power supply. If not, contact an electrician.
• Always use a correctly installed shock­proof socket.
• Do not use multi-plug adapters and ex­tension cables.
• Make sure not to cause damage to the mains plug and to the mains cable. Should the appliance power supply cable need to be replaced, this must be carried out by our Service Centre.
• Connect the mains plug to the mains socket only at the end of the installation. Make sure that there is access to the mains plug after the installation.
4 electrolux
• Do not pull the mains cable to disconnect the appliance. Always pull the mains plug.
• Do not touch the mains cable or the mains plug with wet hands.
• This appliance complies with the E.E.C. Directives.
Water connection
• Make sure not to cause damage to the water hoses.
• The appliance is to be connected to the water mains using the new supplied hose-sets. Old hose sets must not be reused.
• Before you connect the appliance to new pipes or pipes not used for a long time, let the water flow until it is clean.
• The first time you use the appliance, make sure that there is no leakage.
USE
Warning! Risk of injury, electrical
shock, fire, burns or damage to the appliance.
• Use this appliance in a household envi­ronment.
• Do not change the specification of this appliance.
• Obey the safety instructions on the deter­gent packaging.
• Do not put flammable products or items that are wet with flammable products in, near or on the appliance.
• Do not touch the glass of the door while a programme operates. The glass can be hot.
• Make sure that you remove all metal ob­jects from the laundry.
• Do not put a container to collect possible water leakage under the appliance. Con­tact the Service to ensure which acces­sories can be used.
CARE AND CLEANING
Warning! Risk of injury or damage to
the appliance.
• Before maintenance, deactivate the ap­pliance and disconnect the mains plug from the mains socket.
• Do not use water spray and steam to clean the appliance.
• Clean the appliance with a moist soft cloth. Only use neutral detergents. Do not use abrasive products, abrasive cleaning pads, solvents or metal objects.
DISPOSAL
Warning! Risk of injury or suffocation.
• Disconnect the appliance from the mains supply.
• Cut off the mains cable and discard it.
• Remove the door catch to prevent chil­dren and pets to get closed in the appli­ance.
TECHNICAL INFORMATION
Dimensions Width / Height / Depth 600 / 850 / 605 mm
Total depth 640 mm
Electrical connection: Voltage
Level of protection against ingress of solid particles and moisture ensured by the protective cover, except where the low voltage equipment has no protection against moisture
Water supply pressure Minimum 0,5 bar (0,05 MPa)
Water supply Maximum load Cotton 8 kg
1)
Overall power Fuse Frequency
Maximum 8 bar (0,8 MPa) Cold water
230 V
2200 W
10 A
50 Hz
IPX4
electrolux 5
Spin speed Maximum 1600 rpm
1) Connect the water inlet hose to a water tap with a 3/4'' thread.
PRODUCT DESCRIPTION
1 2 3 8
Worktop
1
Detergent dispenser
2
Control panel
3
Door handle
4
Rating plate
5
Drain pump
6
Feet for the appliance level
7
Water drain hose
8
Water inlet valve
9
Mains cable
10
Transit bolts
11
Feet for the appliance level
12
ACCESSORIES
1 2
9
0
4
5
1
6
7
Spanner
1
2
To remove the transit bolts.
Plastic caps
2
To close the holes on the rear side of the cabinet after the removal of the transit bolts.
Anti-flood inlet hose
3
To prevent possible leakage
Plastic hose guide
4
To connect the drain hose on the edge of a sink.
CHILD SAFETY DEVICE
• When you activate this device, you can­not close the door. This prevents children or pets to be closed in the drum. To acti­vate the device, turn it clockwise, until the groove is horizontal. To deactivate the device, turn it counterclockwise, until the groove is vertical.
34
6 electrolux
CONTROL PANEL
1 2 3
Glätten
Défroissage
Auffrischen
Rafraîchir
Baumwolle Eco
Coton Eco
Super Eco
20 min - 3 kg
Outdoor
Blousons
Spülen
Rinçage
Schleudern/Pumpen
Essorage/Vidange
On/Off button (Auto Off)
1
Programme knob
2
Display
3
Start Pause button (Start/Pause —
4
Auto Off
Koch/Bunt
Blanc/Couleurs
Extra Leise
Extra Silence
Pflegeleicht
Synthétiques
Leichtbügeln
Repassage Facile
Feinwäsche
Délicats
Wolle/Seide
Laine/Soie
Daunen
Couette
Anti-Allergie
Anti-Allergies
Départ/Pause) Delay start button (Zeitvorwahl — Dé-
5
part Différé) Time saving button (Zeit Sparen —
6
Gain de Temps) Extra rinse button (Extra Spülen —
7
Rinçage+) Stain button (Flecken/Taches —
8
Vorw./Prélavage) Spin reduction button (U./Min. — T/
9
min.) Temperature button (Temp.)
10
Temp.
U./Min.
T/min.
Flecken
Taches/
Vorwäsche
Prélavage
Extra
Spülen
Rinçage +
Zeit Sparen
Gain de
Tem ps
Zeitvorwahl
Départ Différé
Start/Pause
Départ/Pause
45678910
The AUTO OFF function automatically de­activates the appliance to stop the energy consumption when:
• You do not use the appliance for 5 mi­nutes before you press button
– All settings are cancelled. –
Press button
1
to activate the appli-
ance again.
– Set again the washing programme and
all possible options.
• After 5 minutes from the end of the washing programme. Refer to 'At the end of programme'.
PROGRAMME KNOB
2
Turn this knob to set a programme. The re­lated programme indicator comes on.
4
.
AUTO OFF BUTTON
1
Press this button to activate or deactivate the appliance. A tune sounds when the ap­pliance is activated.
electrolux 7
DISPLAY
3
A H
C D E F GB
The display shows:
The temperature of the set programme
A
B
1) Only available for SPIN/DRAIN programme.
Cold water
The spin speed of the set programme
No Spin symbol
Rinse Hold symbol
Prewash phase
M L
1)
I
K J
Washing phase
Rinses phase
C
The phase symbols
• When a programme is set, all the symbols of the phases related to the pro­gramme come on.
• When the programme starts, only the symbol of the phase in operation flashes.
• When the programme is completed, the symbol of the last phase is on.
D
E
F
Spin phase
The steam symbol comes on when you set a Steam programme.
The detergent overdosing symbol comes on at the end of the cycle when the appliance detects too much detergent.
You cannot open the appliance door when the symbol is on. You can open the door only when the symbol goes off.
If the programme is completed but the symbol stays on:
• The 'Rinse Hold' function is on.
• There is water in the drum.
8 electrolux
G
H
I
When the door is open - Refer to 'Loading the laundry' paragraph
J
When the door is closed
The delay start symbol comes on when you set the delay start func­tion.
The child safety lock symbol comes on when this device is activated.
• The programme time When the programme starts, the programme time decreases with steps of 1 minute.
•The delay start When you press the delay start button, the display shows the delay start time.
•Alarm codes If the appliance has a malfunction, the display shows alarm codes. Refer to 'Troubleshooting'.
• The display shows this message for some seconds when:
– You cannot set a function with the washing programme. – You try to change the washing programme while it operates.
• When the programme is completed.
• The maximum programme load The symbols shows the maximum load for the set programme.
• The weight of laundry The symbol shows the weight of the laundry inside the drum. When you load the laundry, the weight updates by steps of 0.5 kg.
•The symbol of detergent
• The percentage of the detergent quantity. The symbols shows the quantity of detergent to use for the laundry in the drum. When you press the Start/ Pause button, these symbols go off.
Graphic bars
The empty indicator bar appears only if the related function is availa­ble for the set programme.
The indicator bar fills accordingly to the set functions.
If you make a wrong selection the message Err indicates that the selection is not possible.
The time save symbol comes on when you set one of the pro­gramme duration.
K
L
• Shortened time
•Extra Quick
The extra rinse symbol comes on when this function is activated.
The value shows the total number of the rinses.
electrolux 9
The indicator bar is fully filled when you set the maximum number of rinses.
The Stain symbol comes on when you activate the function.
The Prewash symbol comes on when this function is activated.
M
The indicator bar is not fully filled when you set only one of the func­tions.
The indicator bar is fully filled when you set the two functions.
START/PAUSE BUTTON
Press button
4
to start or interrupt a pro-
4
gramme.
DELAY START BUTTON
Press button
5
to delay the start of a pro-
5
gramme from 30 minutes to 20 hours.
TIME SAVE BUTTON
6
Press button 6 to decrease the duration of the programme. – Press one time to set 'Shortened dura-
tion' for items with daily soil.
– Press two times to set 'Extra Quick' for
items with light soil.
Some programmes accept only one of the two functions.
EXTRA RINSE BUTTON
Press button
7
to add rinsing phases to a
7
programme. Use this function for persons allergic to de­tergents and in areas where the water is soft.
THE STAIN-PREWASH BUTTON
Press button
8
to add the stain and/or a
8
prewash phase to a programme. Press the button again and again to acti­vate one or two options. The related sym­bol and the indicator bar comes on in the display.
STAIN
• Use this function for laundry with hard stains to remove. When you set this function, put the stain remover into compartment
. This
function increases the programme dura­tion.
This function is not available with a temperature lower than 40° C.
PREWASH
• Use this function to add a prewash phase before the washing phase. We recommend that you use this function when you have laundry with a high level of soil.
The set of this function increases the programme duration.
SPIN BUTTON
9
Press this button to:
• Decrease the maximum speed of the spin phase of the programme.
The display shows only the spin speeds available with the set pro­gramme.
• Deactivate the spin phase.
• Activate the 'Rinse Hold' function. Set this function to prevent fabric creases. The appliance does not drain the water when the programme is completed.
TEMPERATURE BUTTON
Press button
10
to change the default tem-
perature. When the display shows
10
- -,
the appliance does not heat the water.
ACOUSTIC SIGNALS FUNCTION
You can hear the acoustic signals when:
• You activate the appliance.
• You deactivate the appliance.
• You press the buttons.
• The programme is completed.
• The appliance has a malfunction.
10 electrolux
To deactivate/activate the acoustic sig-
8
nals, press button
and button 7 at the
same time for 6 seconds.
If you deactivate the acoustic signals, they continue operate only when you press the buttons and when a malfunc­tion occurs.
CHILD LOCK FUNCTION
This function prevents children to play with the control panel.
To activate the function, press button and button 9 at the same time until the
display shows the symbol
.
• To deactivate the function, press button
10
and button 9 at the same time until
the symbol
goes off.
PROGRAMMES
Programme
Temperature
Koch/Bunt Blanc/Couleurs
Cottons 95° - Cold
Extra Leise Extra Silence
Extra Silent 95° - Cold
Pflegeleicht Synthétiques
Synthetics 60° - Cold
Leichtbügeln Repassage Fac-
4)
ile
Easy iron 60° - Cold
Feinwäsche Délicats
Delicates 40° - Cold
Type of load
Max. weight of load
White and coloured cot­ton with normal soil. max. load 8 kg
White and coloured cot­ton with normal soil. max. load 8 kg
Synthetic or mixed fabric items with normal level of soil. max. load 4 kg
Synthetic fabrics with nor­mal soil. max. load 4 kg
Delicate fabrics as acryl­ics, viscose, polyester items with normal soil. max. load 4 kg
You can activate the function:
• Before you press the Start/Pause button
4
: the appliance cannot start.
• After you press the Start/Pause button
4
, all the buttons and the programme
knob are deactivated.
PERMANENT EXTRA RINSE FUNCTION
With this function you can keep the extra rinse function permanently on when you set a new programme.
10
To activate the function press button and button 5 at the same time until the
display shows the symbol
• To deactivate the function press button
6
and button 5 at the same time until
the symbol
Cycle description Functions
Wash Rinses Long spin
Wash Rinses Stop with water in the drum
Wash Rinses Short spin
Wash Rinses Short spin
Wash Rinses Short spin
goes off.
SPIN REDUCTION RINSE HOLD
PREWASH STAINS
EXTRA RINSE TIME SAVING
PREWASH STAINS
EXTRA RINSE TIME SAVING
SPIN REDUCTION RINSE HOLD
PREWASH STAINS
EXTRA RINSE TIME SAVING
SPIN REDUCTION RINSE HOLD PREWASH EXTRA RINSE TIME SAVING
SPIN REDUCTION RINSE HOLD
PREWASH STAINS
EXTRA RINSE TIME SAVING
1)
2)
1)
2)
1)
2)
1)
2)
6
.
3)
3)
3)
electrolux 11
Programme
Temperature
Wolle/Seide
Laine/Soie
Wool / Silk 40° - Cold
Type of load
Max. weight of load
Machine washable wool. Hand washable wool and delicate fabrics with «hand washing» care symbol.
Cycle description Functions
Wash Rinses
SPIN REDUCTION RINSE HOLD
Short spin
max. load 2 kg
Daunen Couette
Duvets 60° - 30°
Anti-Allergie Anti-Allergies
Anti allergy 60°
One synthetic blanket, duvet, bedspread and so on. max. load 3 kg
White cotton items. This programme removes micro-organisms thanks to the washing by 60° C and adds one rinse. In this way the wash is more
Wash Rinses Short spin
Wash Rinses Long spin
SPIN REDUCTION
SPIN REDUCTION RINSE HOLD
PREWASH STAINS
1)
2)
TIME SAVING
effective. Put a special additive for hygiene in the Stain com­partment and set the Stain function. max. load 8 kg
Schleudern/ Pumpen Essorage/Vi-
5)
dange
Spin/Drain
Spülen Rinçage
Rinse
Outdoor Blousons
Outdoor 40° - Cold
20 Min. - 3 kg
40° - 30°
All fabrics. The maximum load of the laundry is related to the type of laundry. max. load 8 kg
All fabrics. max. load 8 kg
Waterproof, sports and outdoor items. Do not use any fabric softener! max. load 2.5 kg
Cotton and synthetic items with light soil or worn only one time.
Drainage of the wa­ter Spin phase
One rinse with ad­ditive Spin phase
Wash Rinses Short spin
Wash Rinses Short spin
SPIN REDUCTION NO SPIN
SPIN REDUCTION RINSE HOLD
EXTRA RINSE
6)
SPIN REDUCTION RINSE HOLD EXTRA RINSE
SPIN REDUCTION
max. load 3 kg
Super Eco
7)
Cold
Baumwolle
Eco Coton Eco
8)
Cottons Eco 60° - 40°
1) If you use liquid detergent, set a programme without PREWASH.
2) The Stain function is not available with a temperature lower than 40°C.
3) If you set the Extra Quick duration, we recommend that you decrease the quantity of the load. It is possible to load fully the appliance, however the washing results are reduced.
Mixed fabrics (cotton and synthetic items). max. load 3 kg
White and fast coloured cotton with normal soil. max. load 8 kg
Wash Rinses Short spin
Wash Rinses Long spin
SPIN REDUCTION RINSE HOLD EXTRA RINSE
SPIN REDUCTION RINSE HOLD
PREWASH STAINS
EXTRA RINSE TIME SAVING
1)
2)
3)
12 electrolux
4) The wash and spin phase of this programme is soft to prevent the creases of the laundry. The appliance adds some rinses.
5) The default phase of the spin speed is related to cotton items. Set the spin speed. Make sure that it agrees with the laundry. To select the DRAIN programme only, set the function NO SPIN.
6) Press EXTRA RINSE button to add rinses. With a low spin speed the appliance performs delicate rinses and a short spin.
7) Set this programme to decrease the time and the consumption of energy and water. Use a special detergent for very low temperature.
8) STANDARD PROGRAMMES for the Energy Label consumption values. According to regulation 1061/2010, these programmes are respectively the «standard 60° C cotton programme» and the «standard 40° C cotton programme». They are the most efficient programmes in terms of combined energy and water consumption for washing normally soiled cotton laundry. Set this programme to have a good washing results and decrease the energy consumption. The time of the washing programme is extended.
The washing temperature of the washing phase may differ from the temperature declared for the selected pro­gramme.
STEAM PROGRAMMES
Programme
1)
Auffrischen - Rafraîchir
Steam Refresh This cycle removes odours from the laundry.
Steam does not remove animal odours.
Glätten - Défroissage
Steam Dewrinkler This cycle helps to dewrinkle the laun­dry.
Steam can be used for dried, washed or worn once laundry. These programmes can reduce creases and odours and make your laundry more soft Do not use any detergent. If necessary, remove stains by washing or using localized stain re­moval. Steam programmes do not perform any hygienic cycle.
Do not set the Steam programme for this type of items:
• items where it is not specified on the care label as being suitable for tumble-drying
• all items that have plastic, metal, wooden parts or alike.
1) If you set a Steam programme with dried laundry, at the end of the cycle the laundry feels humid. It is better to expose items to the fresh air for about 10 minutes to let the humidity dry. When the programme is completed, quickly remove the laundry from the drum. After a steam cycle, items may to be ironed anyway, but with less effort!
Type of load Max. load
Cotton and synthetic items. up to 1.5 Kg
Cotton and synthetic items. up to 1.5 Kg
CONSUMPTION VALUES
At programme start the display shows the duration programme for the maximum load capacity. During the washing phase the programme duration is automatically calculated and can greatly be reduced if the laundry load is lower than the maximum load capacity (e.g. Cotton 60°C, maximum load capacity 8 kg, the programme duration exceeds 2 hours; real load 1 kg, the programme duration don’t reach 1 hour). When the appliance is calculating the real programme duration a dot blinks in the display.
The data of this table are approximate. Different causes can change the data: the quantity and type of laundry, the water and ambient temperature.
electrolux 13
Programmes Load
(Kg)
Cottons 60 °C 8 1.5 66 179 43 Cottons 40 °C 8 0.9 66 175 43 Synthetics 40 °C 4 0.6 48 110 35 Delicates 40 °C 4 0.7 58 91 35 Wool/Hand wash
30 °C
Standard cotton programmes
Standard 60 °C cotton
Standard 60 °C cotton
Standard 40 °C cotton
1) At the end of spin phase.
Off Mode (W) Left On Mode (W)
0.05 0.05
The information given in the charts above are in compliance with the EU Commission regulation 1015/2010 implementing directive 2009/125/EC.
Energy con-
sumption
(kWh)
2 0.35 57 60 30
8 0.89 60 223 43
4 0.74 37 190 43
4 0.49 37 171 43
Water con-
sumption (li-
tre)
Approximate
programme
duration (mi-
nutes)
Remaining
moisture
(%)
BEFORE FIRST USE
1. To activate the drain system, put 2 litre
of water in the main wash compartment of the detergent dispenser.
2. Put a small quantity of detergent in the main wash compartment of the deter­gent dispenser. Set and start a pro­gramme for cotton at the highest tem­perature without laundry. This removes all possible dirt from the drum and the tub.
1)
USING THE APPLIANCE
1. Open the water tap.
2. Connect the mains plug to the mains socket.
LOADING THE LAUNDRY
1. Open the appliance door.
2. The display (J) shows the maximum load for the programme (MAX) and the weight of the laundry (KG).
3. Put the laundry in the drum, one item at time. Shake the items before you put them in the drum.
4. On the display the weight of the laundry updates by steps of kg 0.5. The weight is indicative and changes with the type of the laundry.
If you put in the drum more laundry than the maximum load, the symbols MAX and the value 0.0 start to flash. You can wash your laundry but the wa­ter and energy consumption increase. To have the best consumption and washing performance remove some items until the symbols stop to flash. The overload indication is available only for programmes with a maximum load
14 electrolux
lower than the appliance maximum load.
USING THE DETERGENT AND ADDITIVES
5. Close the door. The value 0.0 near the symbol % on the display shows the quantity of the detergent to use. This data is indicative and refers to the detergent quantity for a maximum load that the manufacturer recommends.
Caution! Make sure that no laundry stays between the seal and the door. There is a risk of water leakage or damage to the laundry.
The detergent compartment for the prewash phase and the soak programme. Add the detergent for prewash and soak before the start of the programme.
The detergent compartment for the washing phase. If you use a liquid detergent, put it immediately before you start the programme.
Liquid additives compartment (fabric conditioner, starch). Put the product in the compartment before you start the programme.
This is the maximum level for the quantity of liquid additives.
The compartment for the stain remover. Put the product in the compartment and set the stain function before you start the programme.
Flap for powder or liquid detergent Turn it (up or down) in the correct position to use powder or liquid detergent.
Always obey the instructions that you find on the packaging of the detergent products.
electrolux 15
Check the position of the flap
1. Pull out the detergent dispenser until it stops.
2. Press the lever down to remove the dispenser.
3. To use powder detergent, turn the flap up.
4. To use liquid detergent, turn the flap down.
5. Measure out the detergent and the fab­ric conditioner.
6. Carefully close the detergent dispenser. Make sure that the flap does not cause a blockage when you close the drawer.
With the flap in the position DOWN:
– Do not use gelatinous or thick liquid
detergents.
– Do not put more liquid detergent
than the limit showed in the flap. – Do not set the prewash phase. – Do not set the delay start function.
SET THE DELAY START
1.
Press button
5
again and again until the display shows the number of mi­nutes or hours. The related symbols comes on.
2.
Press button
4
, the appliance starts the countdown of the delay start. When the countdown is completed, the programme starts automatically.
Before you press button 4 to start the appliance, you can cancel or change the set of the delay start. You cannot set the delay start with the
Steam programme.
CANCEL THE DELAY START
1.
Press button
4
. The related indicator flashes.
2.
Press button
5
again and again until the display shows 0’.
3.
Press button
4
. The programme starts.
STARTING THE PROGRAMME
Press button
4
to start the programme.
The related indicator flashes no more.
• On the display all symbols related to the load and to the quantity of detergent go off.
If a delayed start is set, the appliance starts the countdown.
The appliance adjust automatically the cy­cle time to the laundry you have put in the drum to have perfect washing results in the minimum necessary time. After ap­proximately 15 minutes from the start of the programme, the display shows the new time value.
INTERRUPT A PROGRAMME
1.
Press button
4
. The indicator flashes.
16 electrolux
2.
Press button
4
again. The washing
programme continues.
CANCEL A PROGRAMME
1.
Press button
1
to cancel the pro­gramme and to deactivate the appli­ance.
2.
Press button
1
again to activate the appliance. Now, you can set a new washing programme.
The appliance does not drain the wa­ter.
CHANGE A FUNCTION
You can change only some functions be­fore they operate.
1.
Press button
4
. The indicator flashes.
2. Change the function set.
OPEN THE DOOR
While a programme or the delay start oper­ates, the appliance door is locked.
To open the appliance door:
1.
Press button
4
. The door lock sym­bol in the display goes off.
2. Open the appliance door.
3. Close the appliance door and press
4
button
. The programme or the de-
lay start continues.
If the temperature and level of the wa­ter in the drum are too high, the door lock symbol stays on and you cannot open the door. To open the door do the steps that follow:
1. Deactivate the appliance.
2. Wait for some minutes.
3. Make sure that no water is in the drum.
Important! If you deactivate the appliance, it is necessary to set the programme again.
AT THE END OF THE PROGRAMME
• The appliance stops automatically.
• The acoustic signals operate.
In the display
comes on.
• The indicator of the Start/Pause button
4
goes off.
• The door lock symbol goes off.
Press button
1
to deactivate the appli­ance. After five minutes from the end of the programme, the energy saving func­tion automatically deactivates the appli­ance.
When you activate the appliance again, the display show the end of the last set programme. Turn the programme knob to set a new cycle.
• Remove the laundry from the appliance. Make sure that the drum is empty.
• Keep the door ajar, to prevent mildew and odours.
• Close the water tap.
The washing programme is completed, but there is water in the drum:
– The drum turns regularly to prevent the
creases in the laundry.
– The door stays locked. – You must drain the water to open the
door.
To drain the water:
1. If necessary, decrease the spin speed.
2.
Press the Start/Pause button
4
. The
appliance drain the water and spin.
3. When the programme is completed
and the door lock symbol goes off, you can open the door
4. Deactivate the appliance.
The appliance drain and spin automati­cally after approximately 18 hours.
HINTS AND TIPS
THE LAUNDRY LOAD
• Divide the laundry in: white, coloured, synthetics, delicates and wool.
• Obey the washing instructions that are on the laundry care labels.
• Do not wash together white and coloured items.
• Some coloured items can discolour with the first wash. We recommend that you wash them separately for the first times.
• Button up pillowcases, close zippers, hooks and poppers. Tie up belts.
• Empty the pockets and unfold the items.
• Turn inside out multilayered fabrics, wool and items with painted illustrations.
electrolux 17
• Remove hard stains.
• Wash with a special detergent heavy soil stains.
• Be careful with the curtains. Remove the hooks or put the curtains in a washing bag or pillowcase.
•Do not wash in the appliance : – Laundry without hems or with cuts – Underwired bras. – Use a washing bag to wash small
items.
• A very small load can cause balance problems with the spin phase. If this oc­curs, adjust manually the items in the tub and start the spin phase again.
STUBBORN STAINS
For some stains, water and detergent is not sufficient. We recommend that you remove these stains before you put the items in the appli­ance. Special stain removers are available. Use the special stain remover that is applicable to the type of stain and fabric.
DETERGENTS AND ADDITIVES
• Only use detergents and additives spe-
• Obey the instructions that you find on the on packaging of these products.
• Use the correct products for the type and colour of the fabric, the programme tem­perature and the level of soil.
• If you use liquid detergents, do not set the prewash phase.
• If your appliance has not the detergent dispenser with the flap device, add the liquid detergents with a dosing ball.
WATER HARDNESS
If the water hardness in your area is high or moderate, we recommend that you use a water softener for washing machines. In areas where the water hardness is soft it is not necessary to use a water softener. To know the water hardness in your area, contact your local water authority. Obey the instructions that you find on the packaging of the products. Equivalent scales measure the water hard­ness:
• German degrees (°dH).
• French degrees (°TH).
• mmol/l (millimol for each litre - interna­tional unit for the hardness of water).
• Clarke degrees.
cially made for washing machines.
• Do not mix different types of detergents.
• To help the environment, do not use more than the correct quantity of deter­gent.
Water hardness table
Level Type
1 soft 0-7 0-15 0-1.5 0-9 2 medium 8-14 16-25 1.6-2.5 10-16 3 hard 15-21 26-37 2.6-3.7 17-25 4 very hard > 21 > 37 >3.7 >25
°dH °T.H. mmol/l Clarke
Water hardness
CARE AND CLEANING
Warning!
Disconnect the appliance from the mains supply before you clean it.
DESCALING
The water we use contains limescale. If it becomes necessary, use a water softener to remove limescales. Use a special product made for washing machines. Obey the instructions that you find on the packaging of the manufacturer.
Loading...
+ 39 hidden pages
