Page 1
aeg.com/register
TR834E94E
aeg.com\register
EN User Manual | Tumble Dryer
Page 2
FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you impeccable
performance for many years, with innovative technologies that help make life simpler –
features you might not find on ordinary appliances. Please spend a few minutes reading
to get the very best from it.
Visit our website to:
Get usage advice, brochures, trouble shooter, service and repair information:
www.aeg.com/support
Register your product for better service:
www.registeraeg.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.aeg.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the following data
available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
CONTENTS
1. SAFETY INFORMATION................................................................................ 3
2. SAFETY INSTRUCTIONS.............................................................................. 6
3. PRODUCT DESCRIPTION............................................................................. 8
4. CONTROL PANEL.......................................................................................... 9
5. PROGRAMME ............................................................................................. 10
6. OPTIONS...................................................................................................... 14
7. BEFORE FIRST USE....................................................................................15
8. DAILY USE....................................................................................................16
9. HINTS AND TIPS.......................................................................................... 19
10. CARE AND CLEANING.............................................................................. 20
11. TROUBLESHOOTING................................................................................ 23
12. TECHNICAL DATA..................................................................................... 26
13. QUICK GUIDE............................................................................................ 27
14. PRODUCT INFORMATION SHEET IN REFERENCE TO E.U.
REGULATION 1369/2017................................................................................. 29
15. ENVIRONMENTAL CONCERNS................................................................30
2 ENGLISH
Page 3
1. SAFETY INFORMATION
Before beginning the installation and use of this
appliance, carefully read the supplied instructions.
The manufacturer is not responsible for any injuries or
damage that are the result of incorrect installation or usage.
Always keep the instructions in a safe and accessible location
for future reference.
Warning: Risk of fire / Flammable materials.
The appliance contains flammable gas, propane (R290), a
gas with a high level of environmental compatibility. Keep fire
and ignition sources away from the appliance. Be careful not
to cause damage to the refrigerant circuit containing propane.
1.1 Children and vulnerable people safety
WARNING!
Risk of suffocation, injury or permanent disability.
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
the use of the appliance in a safe way and understand the
hazards involved.
• Children between 3 and 8 years of age and persons with
very extensive and complex disabilities shall be kept away
from the appliance unless continuously supervised.
• Children of less than 3 years of age should be kept away
from the appliance unless continuously supervised.
• Do not let children play with the appliance.
• Keep all packaging away from children and dispose of it
appropriately.
• Keep detergents away from children.
ENGLISH 3
Page 4
• Keep children and pets away from the appliance when the
door is open.
• If the appliance has a child safety device, it should be
activated.
• Children shall not carry out cleaning and user maintenance
of the appliance without supervision.
1.2 General Safety
• This appliance is for drying domestic-type, machine-dryable
laundry only.
• Do not use the dryer function if laundry has been soiled with
industrial chemicals.
• This appliance is designed for single household domestic
use in an indoor environment.
• This appliance may be used in, offices, hotel guest rooms,
bed & breakfast guest rooms, farm guest houses and other
similar accommodation where such use does not exceed
(average) domestic usage levels.
• Do not change the specification of this appliance.
• If the tumble dryer is put on top of a washing machine, use
the stacking kit. The stacking kit, available from your
authorized vendor, can be used only with the appliance
specified in the instructions supplied with the accessory.
Read it carefully before installation (refer to the Installation
leaflet).
• The appliance can be installed as freestanding or below a
kitchen counter with correct space (refer to the Installation
leaflet).
• Do not install the appliance behind a lockable door, a sliding
door or a door with a hinge on the opposite side, that would
prevent the appliance door from being fully open.
• The ventilation opening in the base must not be covered by
a carpet, mat, or any floor covering.
• WARNING: The appliance must not be supplied through an
external switching device, such as a timer, or connected to
a circuit that is regularly switched on and off by a utility.
4 ENGLISH
Page 5
• Connect the mains plug to the mains socket only at the end
of the installation process. Make sure that the mains plug is
accessible after installation.
• Ensure good air ventilation in the room where the appliance
is installed to avoid the backflow of unwanted gases into the
room from appliances burning gas or other fuels, including
open fires.
• WARNING: Do not install the appliance in an environment
with no air exchange.
The appliance contains flammable gas, propane (R290), a
gas with a high level of environmental compatibility. Keep
fire and ignition sources away from the appliance. Be
careful not to cause damage to the refrigerant circuit
containing propane.
• WARNING: In the appliance enclosure or in the built -in
structure, keep ventilation opening clear of obstruction.
• WARNING: Do not damage the refrigerant circuit.
• If the mains power supply cable is damaged, it must be
replaced by the manufacturer, its Authorised Service Centre
or similarly qualified persons to avoid an electrical hazard.
• Do not exceed the maximum load of 9,0 kg (refer to the
"Programme chart" chapter).
• Wipe away lint or packaging debris that has accumulated
around the appliance.
• Do not run the appliance without a filter. Clean the lint filter
before or after each use.
• Do not dry unwashed items in the tumble dryer.
• Items that have been soiled with substances such as
cooking oil, acetone, alcohol, petrol, kerosene, spot
removers, turpentine, waxes and wax removers should be
washed in hot water with an extra amount of detergent
before being dried in the tumble dryer.
• Items such as foam rubber (latex foam), shower caps,
waterproof textiles, rubber backed articles and clothes or
pillows fitted with foam rubber pads should not be dried in
the tumble dryer.
ENGLISH 5
Page 6
• Fabric softeners, or similar products, should only be used
as specified by the product manufacturer’s instructions.
• Remove all objects from items that could be a source of fire
ignition such as lighters or matches.
• WARNING: Never stop a tumble dryer before the end of the
drying cycle unless all items are quickly removed and
spread out so that the heat is dissipated.
• Before any maintenance operation, deactivate the
appliance and disconnect the mains plug from the socket.
2. SAFETY INSTRUCTIONS
2.1 Installation
Warning: Risk of fire / Flammable
materials.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Follow the installation instructions supplied
with the appliance.
• Do not install the appliance in an
environment with no air exchange
The appliance contains flammable gas,
propane (R290), a gas with a high level of
environmental compatibility. Keep fire and
ignition sources away from the appliance.
Be careful not to cause damage to the
refrigerant circuit containing propane.
• Always take care when moving the
appliance as it is heavy. Always use safety
gloves and enclosed footwear.
• Do not install or use the appliance where
the temperature can be lower than 5°C or
higher than 35°C.
• The floor area on which the appliance is to
be installed must be flat, stable, heat
resistant and clean.
• Make sure that there is air circulation
between the appliance and the floor.
• Always keep the appliance vertical when it
is being moved.
• The rear surface of the appliance must be
put against a wall.
• When the appliance is in its permanent
position, check if it is levelled correctly
with the aid of a spirit level. If it is not,
adjust the feet accordingly.
2.2 Electrical connection
WARNING!
Risk of fire and electric shock.
• Connect the mains plug to the mains
socket only at the end of the installation.
Make sure that there is access to the
mains plug after the installation.
• WARNING: This appliance is designed to
be installed / connected to a grounding
connection in the building.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Do not pull the mains cable to disconnect
the appliance. Always pull the mains plug.
• Do not touch the mains cable or the mains
plug with wet hands.
2.3 Use
WARNING!
Risk of injury, electric shock, fire, burns
or damage to the appliance.
6 ENGLISH
Page 7
Warning: Risk of fire / Flammable
materials. The appliance contains flammable
gas, propane (R290), a gas with a high level
of environmental compatibility. Keep fire and
ignition sources away from the appliance. Be
careful not to cause damage to the refrigerant
circuit containing propane.
• This appliance is for household (indoors)
use only.
• Do not dry damaged (torn, frayed) items
that contain padding or fillings.
• If laundry has been washed with a stain
remover, carry out an additional rinse
cycle before starting a drying cycle.
• Dry only fabrics that are suitable to dry in
the appliance. Follow the cleaning
instruction on the item label.
• Do not drink or prepare food with the
condensed water/distilled water. It can
cause health problems to people and pets.
• Do not sit or stand on the open door of the
appliance.
• Do not dry dripping wet clothes in the
appliance.
2.4 Internal lighting
WARNING!
Risk of injury.
• Visible LED radiation, do not look directly
into the beam.
• To replace the internal lighting, contact the
Authorised Service Centre.
2.5 Care and cleaning
WARNING!
Risk of injury or damage to the appliance.
Warning: Risk of fire / Flammable
materials. The appliance contains flammable
gas, propane (R290), a gas with a high level
of environmental compatibility. Keep fire and
ignition sources away from the appliance. Be
careful not to cause damage to the refrigerant
circuit containing propane.
• Do not use water spray and steam to
clean the appliance.
• Clean the appliance with a moist soft
cloth. Use only neutral detergents. Do not
use abrasive products, abrasive cleaning
pads, solvents or metal objects.
• Be careful when you clean the appliance
to prevent damage to the cooling system.
2.6 Compressor
WARNING!
Risk of damage to the appliance.
• The compressor and its system in the
tumble dryer is filled with a special agent
which is free from fluoro-chlorohydrocarbons. This system must stay
tight. The damage of the system can
cause a leakage.
2.7 Service
• To repair the appliance contact the
Authorised Service Centre.
• Use original spare parts only.
• Concerning the lamp(s) inside this product
and spare part lamps sold separately:
These lamps are intended to withstand
extreme physical conditions in household
appliances, such as temperature,
vibration, humidity, or are intended to
signal information about the operational
status of the appliance. They are not
intended to be used in other applications
and are not suitable for household room
illumination.
2.8 Disposal
WARNING!
Risk of injury or suffocation.
Warning: Risk of fire / Risk of material
damage and damage to the appliance.
• Disconnect the appliance from the mains
electrical and water supplies.
• Cut off the mains electrical cable close to
the appliance and dispose of it.
• The appliance contains flammable gas
(R290). Contact your municipal authority
for information on how to discard the
appliance correctly.
ENGLISH 7
Page 8
• Remove the door catch to prevent children
1 2
8
3
4
5
6
7
10
9
or pets from becoming trapped in the
drum.
• Dispose of the appliance in accordance
with local requirements for the disposal of
3. PRODUCT DESCRIPTION
Waste Electrical and Electronic Equipment
(WEEE).
Water container
1
Control panel
2
Internal lighting
3
Appliance door
4
Filter
5
Rating plate
6
For ease of loading laundry or ease of
installation the door is reversible (see the
separate leaflet).
8 ENGLISH
Airflow slots
7
Condenser lid
8
Condenser cover
9
Adjustable feet
10
Page 9
00000000
00A
Mod.
xxxxxxxxx
000V ~ 00Hz 0000 W
910000000
00
Prod.No.
A B C D
4. CONTROL PANEL
3
s
3
s
3s
2 3 41
6 5
The rating plate reports:
A. model name
B. product number
C. electrical ratings
D. serial number
Programmes
1
Programme dial
2
Display
3
4
Start/Pause button
4.1 Display
Options
5
On/Off button with
6
auto-off
function
ENGLISH 9
Page 10
Symbol on the display Symbol description
cycle time indication
maximum load
-
, ,
finish in selection (up to 24h)
+ Anti Crease option on
buzzer off
child lock on
laundry dryness: iron dry, cupboard dry, extra dry
Time Dry option on
indicator:
indicator:
indicator:
ECO
indicator:
indicator:
indicator:
Finish In option on
ProSense indicator
indicator:
drain the water container
clean the filter
check the condenser
mode drying
drying phase
cooling phase
crease guard phase
maximum load exceeded
5. PROGRAMME
Programme
MixDry 5,0 kg
3)
Cottons Eco
10 ENGLISH
Load
9,0 kg
1)
Designed for routine drying of what you wash
without sorting. Dries evenly clothes made of
cotton, cotton-synthetic blends and synthetic.
Cotton fabrics programme designed for maxi‐
mum energy saving.
Properties / Fabric mark
2)
/ , ,
/ ,
Page 11
Programme
Cottons 9,0 kg
Synthetics 4,0 kg
Delicates 2,0 kg
Load
1)
White and coloured cotton fabrics programme.
Default setting is for ready to store dryness
level.
Blended garments containing mostly synthetic
fibres like polyester, polyamide, etc.
Recommended for generic delicate fabrics
such as viscose, rayon, acrylic and their
blends.
Gently dries for machine and hand-washable woollens. Remove
immediately the items when the programme is completed.
Properties / Fabric mark
2)
/ ,
/ , ,
/ , ,
Wool
Silk 0,5 kg
Bedlinen XL 4,5 kg
Outdoor
Hygiene
1,0 kg
2,0 kg
5,0 kg
The wool drying cycle of this machine has been approved by The
Woolmark Company for the drying of wool garments labelled as
"hand wash" provided that the garments are dried according to
the instructions issued by the manufacturer of this machine. Fol‐
low the garment care label for other laundry instructions. M2001
The Woolmark symbol is a Certification mark in many countries.
Preserves the shape of delicate machine and
hand-washable silk clothes, minimizing crea‐
ses by using gentle warm air and soft move‐
ments.
Dries up to three bed linen sets at once. Mini‐
mises twists and tangles of large items to en‐
sure every bed linen reaches a uniform dry‐
ness without wet spots.
Maintains the functionality of outdoor fabrics
made of technical textile and restores water
repellency on waterproof jackets and shell
jackets with removable linings (suitable for
drying in tumble dryer).
Dries and sanitizes your garments and other
items maintaining the temperature above
60°C over time, removing 99.9% of bacteria
and viruses4).
Note: This cycle should only be used for wet
items. Not suitable for delicate items.
/ , ,
/ , ,
/ ,
/ ,
ENGLISH 11
Page 12
Programme
Easy Iron 2,0 kg
Sportswear 4,0 kg
1)
The maximum weight refers to dry items.
2)
For fabric mark meaning see chapter
3)
The Cottons ECO programme in combination with the
“Standard cotton programme” according to Commission Regulation EU No. 392/2012. It is suitable for drying nor‐
mal wet cotton laundry and it is the most efficient programme in terms of energy consumption for drying wet cotton
laundry.
4)
Tested for Candida albicans, MS2 Bacteriophage and Escherichia coli in external test performed by Swissatest
Testmaterialien AG in 2021 (Test Report No. 20212038).
1)
Load
Limits creases on small loads of cotton, syn‐
thetic and mixed-fabric garments for easy iron‐
ing. Features two drying levels: Iron leaves
garments slightly damp for ironing or hanging;
Cupboard fully dries items.
Dries generic sportswear made with synthetic
fibres including polyester, elastane blends,
and polyamide.
DAILY USE: Preparing the laundry.
Properties / Fabric mark
cupboard dry
Dryness Level selection is the
2)
/ , ,
/ , ,
5.1 Programme and options selection compatibility
Options
Programme
MixDry
1)
Cottons Eco
Dryness
Level
Time Dry
+ Anti
Crease
Silent Refresh
Cottons
Synthetics
Delicates
Wool
Silk
Bedlinen XL
Outdoor
Hygiene
Easy Iron
12 ENGLISH
2)
2)
2)
2)
3)
Page 13
Options
Programme
Sportswear
1)
Aside from the programme, you can set one or more options at the same time.
2)
Set by default
3)
See chapter OPTIONS: Time Dry on Wool programme
1)
Dryness
Level
2)
Time Dry
+ Anti
Crease
Silent Refresh
5.2 Consumption data
Stated values are obtained in laboratory conditions with relevant standards. Different pa‐
rameters can change the data, for example: the quantity of laundry, the type of laundry
and the ambient conditions. The initial moisture content of the laundry, the water type,
the supply voltage and if you change the default setting of a programme may also affect
the energy use and the duration of the drying programme.
Energy con‐
Program Spun at / residual humidity
Cottons Eco 9,0 kg
cupboardDry
1000 rpm / 60% 239 min 1,98 kWh
Iron Dry
1000 rpm / 60% 158 min 1,28 kWh
cupboardDry
1000 rpm / 60% 130 min 0,98 kWh
cupboardDry
800 rpm / 50% 87 min 0,65 kWh
1)
For partial loads, the cycle time is shorter and appliance uses less energy.
2)
Improper ambient temperature and/or poorly centrifuged laundry can prolong cycle time and increase the energy
consumption.
1400 rpm / 50% 206 min 1,72 kWh
Cottons 9,0 kg
1400 rpm / 50% 130 min 1,04 kWh
Cottons Eco 4,5 kg
1400 rpm / 50% 107 min 0,82 kWh
Synthetics 4,0 kg
1200 rpm / 40% 71 min 0,51 kWh
Drying time
1)
sumption
2)
ENGLISH 13
Page 14
6. OPTIONS
3s
3
s
3s
6.1 Dryness Level
This option helps to achieve requested laundry dry‐
ness. You can select the level of dryness:
ready to iron - iron dry level
ready to store - cupboard dry lev‐
1)
el
ready to store - extra dry level
1)
Default selection which is related to the programme
6.2 Time Dry
For: Cottons, Bedlinen XL, Synthetics and
MixDry programs. Lets the user to set drying
time from minimum 10 min to maximum of 2
hours (in 10 min steps). When this option is
maximum, load indicator disappears.
The cycle lasts as long as set drying time
regardless of the size of a load and its
dryness.
TIME DRYING RECOMMENDATION
up 10 min action of cool air only (no heater).
10 - 40
> 40 min
additional drying to improve dryness af‐
min
ter previous drying cycle.
full drying of the small laundry loads up
to 4 kg, well spun (>1200 rpm).
6.4 Silent
The appliance operates with low noise
without effect on the drying quality. The
appliance operates slowly with longer cycle
time.
6.5 Refresh
To refresh clothes that were in storage.
Maximal load cannot exceed 1 kg.
6.6 Buzzer
The acoustic signal sounds at the following:
• cycle end
• start and end of crease guard phase
The acoustic signal is by default always on.
You can use this option to activate or
deactivate the sound.
Buzzer option off:
1. Turn the dryer on.
2. Select 1 of the available programs.
3. Touch and hold down Refresh button by
around 3 seconds.
The symbol appears on the display.
4. To activate the Buzzer, touch the above
button again until the symbol disappears.
6.7 Finish In
Time Dry on Wool program
Option applicable to Wool program to adjust
final dryness level to more dry or less dry.
6.3 + Anti Crease
Extends up to 120 minutes the anti-crease
phase (30 minutes) at the end of the drying
cycle. After drying phase drum rotates from
time to time to prevent creases. Laundry can
be removed during the anti-crease phase.
14 ENGLISH
This option allows choosing the time at
which a programme should terminate.
Once activated the machine waits for the
right moment to begin the drying process.
Finish In time is the sum of stand by time and
drying time.
To set the Finish In option:
1. Set the drying programme and options.
Page 15
2. Touch Finish In repeatedly until the
Brrrr
display shows the desired time within the
programme should end (e.g. if
the programme has to finish within 12
hours.)
3. Touch the Start/Pause button. The drum
starts rotating to perform the ProSense
7. BEFORE FIRST USE
Rear drum locks are removed
automatically when dryer is activated for
the first time. Possible to hear some
noise.
To unlock the rear drum locks:
1. Switch on the appliance.
2. Set any programme.
3. Press the Start/Pause button.
Drum starts to rotate. Rear drum locks are
automatically deactivated.
Before you use the appliance to dry items:
• Clean the tumble dryer drum with a moist
cloth.
• Start a 1 hour programme with moist
laundry.
estimation, if foreseen in the selected
programme.
4. The appliance starts the countdown to the
end of the programme and the
programme will start at the right moment
for ending.
7.2 Noises
Different noises may be heard at different
times during the drying cycle. They are
perfectly normal operating sounds.
Working compressor.
Rotating drum.
At the beginning of the drying cycle (first
3-5 min) there could be a slightly higher
sound level. This is due to the
compressor starting up. This is normal for
compressor powered appliances such as
refrigerators and freezers.
7.1 Unusual smell
The appliance is tightly packed.
After product unpacking you can feel an
unusual smell. This is normal for brand new
products.
Appliance is built of several different types of
material which all together can generate
unusual smell.
Over usage time, after few drying cycles
unusual smell gradually disappears.
Working fans.
ENGLISH 15
Page 16
Working pump and transferring
condensation to the tank.
8. DAILY USE
8.1 Preparing the laundry
Very often the clothes after washing
cycle are kneaded and tangled
altogether.
Drying kneaded and tangled clothes is
inefficient.
To assure proper air flow and even
drying it is recommended to shake and
load one by one the clothes to the tumble
dryer.
To assure proper drying process:
• Close the zips.
• Close the fasteners of duvet covers.
• Do not dry ties or ribbons loose (e.g.
apron ribbons). Tie them before you start
a programme.
• Remove all items from pockets.
• Turn items with the internal layer made of
cotton inside out. Cotton layer must be
faced outwards.
Fabric label Description
Laundry is suitable for tumble drying.
Laundry is suitable for tumble drying at higher temperatures.
• Always set the programme suitable for the
type of laundry.
• Do not put light and dark colours together.
• Use suitable programme for cottons,
jersey and knitwear to reduce shrinkage.
• Do not exceed the maximum load stated
in the programmes chapter or shown on
the display.
• Dry only the laundry that is suitable for
tumble drying. Refer to the fabric label on
the items.
• Do not dry large and small items together.
Small items can be trapped inside the
large items and remain wet.
• Shake the large clothes, fabrics before
placing in the tumble dryer. It is to avoid
moist places inside the fabric after the
drying cycle.
16 ENGLISH
Laundry is suitable for tumble drying at low temperatures only.
Laundry is not suitable for tumble drying.
Page 17
8.2 Loading the laundry
3
s
3
s
3s
CAUTION!
Ensure the laundry is not trapped
between the appliance door and the
rubber seal.
1. Pull open the appliance door.
2. Load the laundry one item at a time.
3. Close the appliance door.
8.3 Turning on the appliance
8.5 Setting a programme
Use the programme dial to set the
programme.
The approximate programme duration
appears on the display.
Real drying time will depend on type of
the load (quantity and composition), the
room temperature and the humidity of
your laundry after spin drying phase.
8.6 Options
Together with the programme you can set 1
or more options.
To turn on the appliance:
Push the On/Off button.
If the appliance is on, some indicators appear
on the display.
8.4 auto-off function
To decrease the energy consumption, the
auto-off function turns the appliance off
automatically:
• if the Start/Pause touch button is not
touched within 5 minutes.
• 5 minutes after a cycle ends.
Push the On/Off button to turn on the
appliance.
If the appliance is on, some indications
appear on the display.
To activate or deactivate an option touch the
relevant button.
its symbol appears on the display or the led
above the corresponding button lights up.
8.7 Child lock option
The child lock can be set to prevent children
from playing with the appliance. The child
lock option locks all touch buttons and the
program dial (this option does not lock the
On/Off button).
ENGLISH 17
Page 18
You can activate the child lock option:
3s
3s
3s
3s
3
s
3s
• before you touch the Start/Pause button the appliance cannot start
• after you touch the Start/Pause button programs and option selection is
unavailable.
Child lock option activation:
After setting a drying programme, the
icon lights up on the display if
the programme supports it.
Touching the Start/Pause button, the
ProSense starts the laundry load detection:
1. The appliance detects the load in the first
minute: the indicator flashes, the bars
under the icon move back and forth
1. Turn the dryer on.
2. Select 1 of the available programs.
3. Touch and hold down + Anti Crease
button by around 3 seconds.
The symbol appears on the display.
4. To deactivate the child lock, touch the
above button again until the symbol
disappears.
8.8 Starting a program
To start the program:
Touch the Start/Pause button.
The appliance starts and the LED above the
button stops flashing and stays on.
2. When the drum stops rotating, the display
and the drum rotates shortly.
shows the new programme duration
adjusted according to the detected load.
The number of bars, from 1 to 4,
represents the estimated load amount. 4
bars represent the maximum load amount
for the selected programme.
In case of drum overload, the maximum
declared load indicator comes on again
with the indicator blinking. In
this case, during these 30 seconds, it is
possible to open the door and remove
the exceeding garments. Once removed,
touch the Start/Pause button to start the
programme again. If the laundry amount
will not be reduced, the programme starts
anyway. In this case, it will be not
possible to guarantee the best results.
8.10 Program change
To change a program:
1. Push the On/Off button to turn the
appliance off.
2. Push the On/Off button again to turn on
the appliance.
3. Set a new program.
8.11 Programme end
8.9 The ProSense load detection
The ProSense The ProSense technology
detects the laundry load size defining the
programme duration.
18 ENGLISH
Clean the filter and drain the water
container after each drying cycle. (See
chapter CARE AND CLEANING.)
If the drying cycle is finished, the symbol
appears on the display. If the Buzzer option is
Page 19
activated, the acoustic signal sounds
3s
3s
3s
intermittently for 1 minute.
If you do not turn off the appliance, the
anti-crease phase starts (not active with
all programmes). Flashing symbol
signals the execution of the anti-crease
phase. Laundry can be removed during
this phase.
To remove the laundry:
1. Push the On/Off button for 2 seconds to
turn the appliance off.
2. Open the appliance door.
3. Remove the laundry.
4. Close the appliance door.
Possible causes of unsatisfactory drying
results:
• Inadequate default dryness level settings.
See chapter
Adjustment of default dryness
level
• Room temperature is too low or too high.
Optimal room temperature is between
18°-25°C.
9. HINTS AND TIPS
8.12 Drum light on
Touch and hold down Silent button by
around 3 seconds.
The light inside the drum is on.
8.13 Possible causes of unsatisfactory drying results:
• The filter is clogged. Clogged filter makes
drying inefficient.
• The airflow slots are clogged.
• The humidity sensor is dirty.
• The drum is dirty.
• Inadequate default dryness level settings.
See chapter
level
• Room temperature is too low or too high.
Optimal room temperature is between
18°-25°C.
Adjustment of default dryness
9.1 Ecological hints
• Spin the laundry well before drying.
• Do not exceed the load sizes which are
specified in the programmes chapter.
• Clean the filter after each drying cycle.
• Do not use fabric softener to wash and
then dry. In the tumble dryer laundry
becomes soft automatically.
• The water from the water container can be
used to iron the clothes. You must first
filter the water to eliminate remaining
textile fibres (simple coffee filter is
suitable).
• Always keep the airflow slots at the bottom
of the appliance clear.
• Make sure there is good airflow where the
appliance is to be installed.
9.2 Adjustment of default dryness
level
To change the default dryness level:
1. Turn the appliance on.
2. Select 1 of the available programmes.
3. Touch and hold down the Time Dry and +
Anti Crease buttons at the same time.
One of the symbols appears on the display:
- Maximum dryness
- Extra dryness
- Standard dryness
4. Touch the Start/Pause button repeatedly
until you reach the desired dryness level.
Dryness level Display symbol
Maximum dry‐
ness
Extra dryness
Standard dry‐
ness
5. To memorise the setting touch and hold
down the Time Dry and + Anti Crease
ENGLISH 19
Page 20
buttons at the same time for
approximately 2 seconds.
9.3 Deactivating the tank indicator
The water container indicator is activated by
default. It illuminates at the end of the drying
cycle or during the cycle if the water reservoir
is full. If the draining kit is installed the water
container is drained automatically and the
indicator can be deactivated.
To deactivate the indicator:
1. Turn the appliance on.
2. Select 1 of the available programmes.
3. Touch and hold down Silent and Refresh
buttons at the same time.
One of 2 configurations is possible:
• the Water container indicator: is on
if the symbol appears - the
water container indicator is
permanently activated
• the Water container indicator: is off
if the symbol appears - the
water container indicator is
permanently deactivated
9.4 Operating hours counter
This function gives a possibility to display the
total operating time of the appliance in hours,
which is counted from the moment it is first
switched on. The actual operating time of the
cycles is shown (does not include pauses or
delayed start time).
To visualise this value, proceed as follows:
1. Switch the appliance on by pressing the
On/Off button.
2. Press and hold the Dryness Level and
Time Dry buttons for some seconds.
3. After 3 seconds the total hours operated
by the appliance are shown in the display:
e.g. if the operating time is 1276 hours,
the display shows the text Hr for 2
seconds then 12 for 2 seconds followed
by 76. This value is displayed with a
sequence of two digits at a time: the first
two digits indicate thousands and
hundreds, the second two digits indicate
tens and units.
To exit this mode, either press any button,
turn the selector knob or switch the appliance
off.
9.5 Factory Defaults
This function allows to restore the factory
default settings. The saved options and
working modes will be reset.
To activate this option follow steps below:
1. Switch the appliance on by pressing
On/Off button.
2. Wait approximately 8 seconds.
3. Press and hold the + Anti-crease and
Silent buttons for some seconds.
4. The appliance will acknowledge the
operation by displaying
If the procedure does not work (this could
be due to timeout or wrong keys
combination), switch the appliance off
and repeat the sequence from the
beginning.
.
10. CARE AND CLEANING
10.1 Cleaning the filter
At the end of each cycle the
comes on the display and you must clean the
filter.
20 ENGLISH
Filter
symbol
The filter collects the lint during the
drying cycle.
Page 21
To achieve the best drying performance
clean the filter regularly. The clogged
filter causes the longer drying cycle and
as a consequence the energy
consumption increase.
Clean the filter by hand. Use a vacuum
cleaner if necessary.
CAUTION!
Do not use the water to clean the filter.
Manually gather lint and throw it away
into the dustbin (avoid throwing the
plastic fibres into the water environment).
1. Open the door. Pull the filter up.
2. Push the hook to open the filter.
3. Gather lint with hand from both internal
parts of the filter.
Throw the lint in the dustbin.
4. If necessary, clean the filter with a
vacuum cleaner. Close the filter.
5. If necessary, remove lint from the filter
socket and gasket. You can use a
vacuum cleaner. Place the filter back
inside the filter socket.
10.2 Emptying the water container
Empty the condensed water container after
each drying cycle.
If the condensed water container is full, the
programme stops automatically. The
Water container
and you must empty the water container.
To empty the water container:
1. Pull the water container out keeping it in a
horizontal position.
symbol comes on the display
ENGLISH 21
Page 22
2. Pull the plastic connection out and drain
the water into a basin or equivalent
receptacle.
3. Push the plastic connection back in and
place the water container back into
position.
4. To continue the programme press the
Start/Pause button.
10.3 Cleaning the condenser
2. Open the condenser cover.
3. Turn the lever to unlock the condenser
lid.
4. Lower the condenser lid.
If the symbol
the display, inspect the condenser and its
compartment. If it is dirty, clean it. Do the
check not less than once a 6 months.
WARNING!
Do not touch the metal surface with bare
hands. Risk of injury. Wear protective
gloves. Clean carefully to avoid
damaging the metal surface.
To inspect:
1. Open the door. Pull the filter up.
Heat exchanger
flashes on
22 ENGLISH
5. If necessary, remove the fluff from the
condenser and its compartment. You can
use a vacuum cleaner with the brush
attachment.
6. Close the condenser lid.
7. Turn the lever until it clicks into position.
8. Put the filter back.
Page 23
10.4 Cleaning the humidity sensor
CAUTION!
Risk of humidity sensor damage. Do not
use abrasive materials or steel wool to
clean the sensor.
To assure best drying results the appliance is
equipped with metal humidity sensor. It is
placed on the inner side of the door area.
Over usage time the surface of the sensor
may get dirty which deteriorates the drying
performance.
We recommend to clean the sensor at least 3
or 4 times or if you observe the drop of drying
performance.
To clean you can use harder side of dishwashing sponge and bit of vinegar or dish
soap.
To clean the sensor:
1. Open the loading door.
2. Clean the surfaces of the humidity sensor
wiping off the metal surface several
times.
10.5 Cleaning the drum
WARNING!
Disconnect the appliance before you
clean it.
Use a standard neutral soap detergent to
clean the inner surface of the drum and drum
lifters. Dry the cleaned surfaces with a soft
cloth.
CAUTION!
Do not use abrasive materials or steel
wool to clean the drum.
10.6 Cleaning the control panel and housing
Use a standard neutral soap detergent to
clean the control panel and housing.
Use a moist cloth to clean. Dry the cleaned
surfaces with a soft cloth.
CAUTION!
Do not use furniture cleaning agents or
cleaning agents which can cause
corrosion.
10.7 Cleaning the airflow slots
Use a vacuum cleaner to remove fluff from
the airflow slots.
11. TROUBLESHOOTING
WARNING!
Refer to Safety chapters.
11.1 Error Codes
The appliance does not start or it stops during operation.
First try to find a solution to the problem (refer to the table). If the problem persists, contact the
Authorised Service Centre.
ENGLISH 23
Page 24
WARNING!
Deactivate the appliance before carrying out any check.
In case of major problems, the acoustic signals operate, the display shows an error
code and the Start/Pause button may flash continuously:
Error code Possible cause Remedy
E50
E90 or E91
EH0
Appliance motor overloaded.
Too much laundry or entrap in the drum.
Internal fail. No communication between
electronic elements of the appliance.
The mains supply is unstable. When the appliance is showing EH0, please
The programme was not completed. Re‐
move the laundry from the drum, set the
programme and restart the cycle.
The programme was not finished properly
or the appliance stoped too early. Switch
the appliance off and on again.
If the error code appears again, contact the
Authorised Service Centre.
wait until main supply is stable than press
start. If the appliance pause the cycle with‐
out any indication then press the cycle start.
If the warning will occur check the power
cord / socket integrity or main supply.
If the display shows other error codes, deactivate and activate the appliance. If the problem
continues, contact the Authorised Service Centre.
In case of different problem with the tumble dryer check the table below for possible solutions.
11.2 Troubleshooting
Problem Possible cause Remedy
The tumble dryer
does not operate.
The tumble dryer is not connected to the
mains supply.
The door is open. Close the door.
The On/Off button was not pushed. Push the On/Off button.
The Start/Pause button was not touched. Touch the Start/Pause button.
The appliance is in standby mode. Push the On/Off button.
Connect it to the mains socket. Check the
fuse in the fuse box (domestic installation).
24 ENGLISH
Page 25
Problem Possible cause Remedy
Unsatisfactory drying
result.
The loading door
does not close
It is not possible to
change the program
or option.
It is not possible to
select an option. An
acoustic signal is
emitted.
There is no drum
light
Unexpected duration
time appears on the
display.
A program is inac‐
tive.
The drying cycle is
too short.
Incorrect program selection.
The filter is clogged.
Dryness Level option was set to
3)
Dry
.
The load was too large. Do not exceed the maximum load size.
The airflow slots are clogged. Clean the airflow slots at the bottom of the
There is some dirt on the humidity sensor in
the drum.
The dryness level was not set to the desired
level.
The condenser is clogged.
The filter is not locked into position. Put the filter in the correct position.
Laundry is trapped between the door and
the seal.
After a cycle starts it is not possible to
change the program or option.
The option you tried to select is not availa‐
ble for the selected program.
Defective drum lamp. Contact the service centre to replace the
The drying duration is calculated according
to load size and dampness.
The water container is full. Drain the water container, push the Start/
The load size is small. Select a time program. The time value must
The laundry is too dry. Select an appropriate time program or a
Select a suitable program.
Clean the filter.
Change Dryness Level option to a higher
Iron
level.
appliance.
Clean the front surface of the drum.
Adjust the dryness level.
Clean the condenser.
Remove trapped items and close the door.
Turn the tumble dryer off and on. Change
the program or option as required.
Turn the tumble dryer off and on. Change
the program or option as required.
drum lamp.
This is automated - the appliance is working
correctly.
Pause button.
be related to the load. To dry one item or a
small amount of laundry we recommend
short drying times.
higher dryness level (e.g.
1)
2)
4)
2)
2)
extra dry
)
ENGLISH 25
Page 26
Problem Possible cause Remedy
The filter is clogged. Clean the filter.
The load is too large. Do not exceed the maximum load size.
Drying cycle too
5)
long
1)
Follow the program description — see the PROGRAMS chapter .
2)
See the
3)
4)
5)
CARE AND CLEANING
Only dryers with the Dryness Level option.
See the HINTS AND TIPS chapter .
Note: After a maximum of 5 hours the drying cycle ends automatically.
The laundry was not spun sufficiently. Spin the laundry well in the washing ma‐
Too low or too high room temperature - this
is not the appliance malfunction.
chapter.
chine.
Ensure a room temperature higher than
+5°C and lower than +35°C. Optimal room
temperature to achieve best drying results
is between 18°-25°C.
11.3 Possible causes of
unsatisfactory drying results:
• The filter is clogged. Clogged filter makes
drying inefficient.
• The airflow slots are clogged.
• The humidity sensor is dirty.
• Inadequate default dryness level settings.
See chapter
Adjustment of default dryness
level
• Room temperature is too low or too high.
Optimal room temperature is between
18°-25°C.
• The drum is dirty.
12. TECHNICAL DATA
Height x Width x Depth 850 x 596 x 638 mm (maximal 663 mm)
Max. depth with the appliance door open 1108 mm
Max. width with the appliance door open 958 mm
Adjustable height 850 mm (+ 15 mm - feet regulation)
Drum volume 118 l
Maximum load volume 9,0 kg
Voltage 230 V
Frequency 50 Hz
Sound power level 64 dB
Total power 700 W
Energy efficiency class A++
Energy consumption on the standard cotton pro‐
gramme with the full load.
Energy consumption on the standard cotton pro‐
gramme with the partial load.
1)
2)
1,98 kWh
0,98 kWh
26 ENGLISH
Page 27
Annual energy consumption
1 2
3
5
4
3
s
3s
3s
3s
3
s
3s
3)
Left-on mode power absorption
Off mode power absorption
4)
4)
226,10 kWh
0,05 W
0,05 W
Type of use Household
Allowed ambient temperature + 5°C to + 35°C
Level of protection against ingress of solid particles and
IPX4
moisture ensured by the protective cover, except where
the low voltage equipment has no protection against
moisture
Gas designation R290
Weight 0,149 kg
1)
With reference to EN 61121. 9,0 kg of cotton centrifuged at 1000 rpm.
2)
With reference to EN 61121. 4,5 kg of cotton centrifuged at 1000 rpm.
3)
Energy consumption per year in kWh, based on 160 drying cycles of the standard cotton programme at full and
partial load, and the consumption of the low-power modes. Actual energy consumption per cycle will depend on
how the appliance is used (REGULATION (EU) No. 392/2012).
4)
With reference to EN 61121.
The information given in the chart above is compliant with the EU Commission regulation 392/2012
implementing directive 2009/125/EC.
13. QUICK GUIDE
13.1 Daily use
ENGLISH 27
Page 28
1. Push the On/Off button to turn on the
1 2
3
appliance.
2. Use the programme dial to set the
programme.
3. To activate or deactivate an option touch
the relevant button or 2 buttons
combination.
13.2 Cleaning the filter
4. Touch the Start/Pause button.
5. The appliance starts.
At the end of each cycle the
comes on the display and you must clean the
filter.
1. Open the door. Pull the filter up.
2. Push the hook to open the filter.
13.3 Programme
Programme
MixDry 5,0 kg
Cottons Eco
Cottons 9,0 kg
Synthetics 4,0 kg
Delicates 2,0 kg
Wool
Silk 0,5 kg
Bedlinen XL 4,5 kg
Load
9,0 kg Cotton fabrics programme designed for maximum energy saving.
1,0 kg
Filter
symbol
3. Gather lint with hand from both internal
parts of the filter. Throw the lint in the
dustbin.
1)
Designed for routine drying of what you wash without sorting. Dries
evenly clothes made of cotton, cotton-synthetic blends and synthet‐
ic.
White and coloured cotton fabrics programme. Default setting is for
ready to store dryness level.
Blended garments containing mostly synthetic fibres like polyester,
polyamide, etc.
Recommended for generic delicate fabrics such as viscose, rayon,
acrylic and their blends.
Gently dries for machine and hand-washable woollens. Remove
immediately the items when the programme is completed.
Preserves the shape of delicate machine and hand-washable silk
clothes, minimizing creases by using gentle warm air and soft
movements.
Dries up to three bed linen sets at once. Minimises twists and tan‐
gles of large items to ensure every bed linen reaches a uniform
dryness without wet spots.
Properties / Fabric mark , ,
28 ENGLISH
Page 29
Programme
Outdoor
Hygiene
Easy Iron 2,0 kg
Sportswear 4,0 kg
1)
The maximum weight refers to dry items.
2)
Tested for Candida albicans, MS2 Bacteriophage and Escherichia coli in external test performed by Swissatest
Testmaterialien AG in 2021 (Test Report No. 20212038).
Load
2,0 kg
5,0 kg
1)
Maintains the functionality of outdoor fabrics made of technical tex‐
tile and restores water repellency on waterproof jackets and shell
jackets with removable linings (suitable for drying in tumble dryer).
Dries and sanitizes your garments and other items maintaining the
temperature above 60°C over time, removing 99.9% of bacteria
and viruses2).
Note: This cycle should only be used for wet items. Not suitable for
delicate items.
Limits creases on small loads of cotton, synthetic and mixed-fabric
garments for easy ironing. Features two drying levels: Iron leaves
garments slightly damp for ironing or hanging; Cupboard fully dries
items.
Dries generic sportswear made with synthetic fibres including poly‐
ester, elastane blends, and polyamide.
Properties / Fabric mark , ,
14. PRODUCT INFORMATION SHEET IN REFERENCE TO E.U.
REGULATION 1369/2017
Product Information Sheet
Trade Mark AEG
Model TR834E94E PNC916099657
Rated capacity in kg 9,0
Air vented or condenser tumble dryer Condenser
Energy efficiency class A++
Energy consumption in kWh per year, based on 160 drying cycles of the standard
cotton programme at full and partial load, and the consumption of the low-power
modes. Actual energy consumption per cycle will depend on how the appliance is
used.
Automatic tumble drier or non-automatic tumble drier Automatic
Energy consumption of the standard cotton programme at full load in kWh 1,98
Energy consumption of the standard cotton programme at partial load in kWh 0,98
Power consumption of the off-mode in W 0,05
Power consumption in left-on mode in W 0,05
Duration of the left on mode in minutes 10
The 'standard cotton programme' used at full and partial load is the standard dry‐
ing programme to which the information in the label and the fiche relates, this
programme is suitable for drying normal wet cotton laundry and it is the most effi‐
cient programme in terms of energy consumption for cotton.
226,10
ENGLISH 29
Page 30
Weighted programme time of the 'standard cotton programme at full and partial
load' in minutes
Programme time of the 'standard cotton programme at full load' in minutes 239
Programme time of the 'standard cotton programme at partial load' in minutes 130
Condensation efficiency class on a scale from G (least efficient) to A (most effi‐
cient)
Average condensation efficiency of the standard cotton programme at full load as
a percentage
Average condensation efficiency of the standard cotton programme at partial load
as a percentage
Weighted condensation efficiency for the 'standard cotton programme at full and
partial load'
Sound power level in dB 64
Built in appliance Y/N No
177
B
85
85
85
The information given in the chart above is compliant with the EU Commission regulation 392/2012
implementing directive 2009/125/EC.
15. ENVIRONMENTAL CONCERNS
Recycle materials with the symbol . Put the
packaging in relevant containers to recycle it.
Help protect the environment and human
health by recycling waste of electrical and
electronic appliances. Do not dispose of
appliances marked with the symbol with
the household waste. Return the product to
your local recycling facility or contact your
municipal office.
30 ENGLISH
*
Page 31
Page 32
136999071-A-252023
Loading...
