AEG TR71A2G2CO User guide

TR71A2G2CO

USER
MANUAL

EN User Manual

Tumble Dryer

www.aeg.com2

CONTENTS

1. SAFETY INFORMATION......................................................................................3

2. SAFETY INSTRUCTIONS.................................................................................... 6

3. PRODUCT DESCRIPTION...................................................................................8

4. CONTROL PANEL................................................................................................9

5. PROGRAMME ................................................................................................... 10

6. OPTIONS............................................................................................................13

7. BEFORE FIRST USE..........................................................................................13

8. DAILY USE......................................................................................................... 15

9. HINTS AND TIPS................................................................................................17

10. CARE AND CLEANING.................................................................................... 18

11. TROUBLESHOOTING......................................................................................21

12. TECHNICAL DATA........................................................................................... 24

13. ACCESSORIES................................................................................................ 26

14. PRODUCT INFORMATION SHEET IN REFERENCE TO E.U. REGULATION

1369/2017............................................................................................................... 27

15. ENVIRONMENTAL CONCERNS......................................................................28

FOR PERFECT RESULTS

Thank you for choosing this AEG product. We have created it to give you
impeccable performance for many years, with innovative technologies that help
make life simpler – features you might not find on ordinary appliances. Please
spend a few minutes reading to get the very best from it.

Visit our website to:

Get usage advice, brochures, trouble shooter, service and repair information:

www.aeg.com/support

Register your product for better service:

www.registeraeg.com

Buy Accessories, Consumables and Original spare parts for your appliance:

www.aeg.com/shop

CUSTOMER CARE AND SERVICE

Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the
following data available: Model, PNC, Serial Number.
The information can be found on the rating plate.

Warning / Caution-Safety information
General information and tips
Environmental information

Subject to change without notice.

1. SAFETY INFORMATION

Before beginning the installation and use of this
appliance, carefully read the supplied instructions.
The manufacturer is not responsible for any injuries or
damage that are the result of incorrect installation or
usage. Always keep the instructions in a safe and
accessible location for future reference.

Warning: Risk of fire / Flammable materials.
The appliance contains flammable gas, propane (R290),
a gas with a high level of environmental compatibility.
Keep fire and ignition sources away from the appliance.
Be careful not to cause damage to the refrigerant circuit
containing propane.

1.1 Children and vulnerable people safety

WARNING!

Risk of suffocation, injury or permanent
disability.

ENGLISH 3

• This appliance can be used by children aged from 8

years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning the use of the appliance in a
safe way and understand the hazards involved.

• Children between 3 and 8 years of age and persons

with very extensive and complex disabilities shall be
kept away from the appliance unless continuously
supervised.

• Children of less than 3 years of age should be kept

away from the appliance unless continuously
supervised.

• Do not let children play with the appliance.

• Keep all packaging away from children and dispose of

it appropriately.

• Keep detergents away from children.

www.aeg.com4

• Keep children and pets away from the appliance when

the door is open.

• If the appliance has a child safety device, it should be

activated.

• Children shall not carry out cleaning and user

maintenance of the appliance without supervision.

1.2 General Safety

• This appliance is for drying domestic-type, machine-

dryable laundry only.

• Do not use the dryer function if laundry has been

soiled with industrial chemicals.

• This appliance is designed for single household

domestic use in an indoor environment.

• This appliance may be used in, offices, hotel guest

rooms, bed & breakfast guest rooms, farm guest
houses and other similar accommodation where such
use does not exceed (average) domestic usage levels.

• Do not change the specification of this appliance.

• If the tumble dryer is put on top of a washing machine,

use the stacking kit. The stacking kit, available from
your authorized vendor, can be used only with the
appliance specified in the instructions supplied with
the accessory. Read it carefully before installation
(refer to the Installation leaflet).

• The appliance can be installed as freestanding or

below a kitchen counter with correct space (refer to
the Installation leaflet).

• Do not install the appliance behind a lockable door, a

sliding door or a door with a hinge on the opposite
side, that would prevent the appliance door from being
fully open.

• The ventilation opening in the base must not be

covered by a carpet, mat, or any floor covering.

• WARNING: The appliance must not be supplied

through an external switching device, such as a timer,
or connected to a circuit that is regularly switched on
and off by a utility.

ENGLISH 5

• Connect the mains plug to the mains socket only at

the end of the installation process. Make sure that the
mains plug is accessible after installation.

• Ensure good air ventilation in the room where the

appliance is installed to avoid the backflow of
unwanted gases into the room from appliances
burning gas or other fuels, including open fires.

• WARNING: Do not install the appliance in an

environment with no air exchange.
The appliance contains flammable gas, propane
(R290), a gas with a high level of environmental
compatibility. Keep fire and ignition sources away from
the appliance. Be careful not to cause damage to the
refrigerant circuit containing propane.

• WARNING: In the appliance enclosure or in the built -

in structure, keep ventilation opening clear of
obstruction.

• WARNING: Do not damage the refrigerant circuit.

• If the mains power supply cable is damaged, it must

be replaced by the manufacturer, its Authorised
Service Centre or similarly qualified persons to avoid
an electrical hazard.

• Do not exceed the maximum load of 8,0 kg (refer to

the "Programme chart" chapter).

• Wipe away lint or packaging debris that has

accumulated around the appliance.

• Do not run the appliance without a filter. Clean the lint

filter before or after each use.

• Do not dry unwashed items in the tumble dryer.

• Items that have been soiled with substances such as

cooking oil, acetone, alcohol, petrol, kerosene, spot
removers, turpentine, waxes and wax removers
should be washed in hot water with an extra amount of
detergent before being dried in the tumble dryer.

• Items such as foam rubber (latex foam), shower caps,

waterproof textiles, rubber backed articles and clothes
or pillows fitted with foam rubber pads should not be
dried in the tumble dryer.

www.aeg.com6

• Fabric softeners, or similar products, should only be

used as specified by the product manufacturer’s
instructions.

• Remove all objects from items that could be a source

of fire ignition such as lighters or matches.

• WARNING: Never stop a tumble dryer before the end

of the drying cycle unless all items are quickly
removed and spread out so that the heat is dissipated.

• Before any maintenance operation, deactivate the

appliance and disconnect the mains plug from the
socket.

2. SAFETY INSTRUCTIONS

2.1 Installation

Warning: Risk of fire / Flammable

materials.

• Remove all the packaging.

• Do not install or use a damaged
appliance.

• Follow the installation instructions
supplied with the appliance.

• Do not install the appliance in an
environment with no air exchange
The appliance contains flammable
gas, propane (R290), a gas with a
high level of environmental
compatibility. Keep fire and ignition
sources away from the appliance. Be
careful not to cause damage to the
refrigerant circuit containing propane.

• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.

• Do not install or use the appliance
where the temperature can be lower
than 5°C or higher than 35°C.

• The floor area on which the appliance
is to be installed must be flat, stable,
heat resistant and clean.

• Make sure that there is air circulation
between the appliance and the floor.

• Always keep the appliance vertical
when it is being moved.

• The rear surface of the appliance
must be put against a wall.

• When the appliance is in its
permanent position, check if it is

levelled correctly with the aid of a
spirit level. If it is not, adjust the feet
accordingly.

2.2 Electrical connection

WARNING!

Risk of fire and electric
shock.

• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.

• WARNING: This appliance is
designed to be installed / connected
to a grounding connection in the
building.

• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.

• Always use a correctly installed
shockproof socket.

• Do not use multi-plug adapters and
extension cables.

• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.

• Do not touch the mains cable or the
mains plug with wet hands.

ENGLISH 7

2.3 Use

WARNING!

Risk of injury, electric shock,
fire, burns or damage to the
appliance.

Warning: Risk of fire / Flammable
materials. The appliance contains
flammable gas, propane (R290), a gas
with a high level of environmental
compatibility. Keep fire and ignition
sources away from the appliance. Be
careful not to cause damage to the
refrigerant circuit containing propane.

• This appliance is for household

(indoors) use only.

• Do not dry damaged (torn, frayed)

items that contain padding or fillings.

• If laundry has been washed with a

stain remover, carry out an additional
rinse cycle before starting a drying
cycle.

• Dry only fabrics that are suitable to

dry in the appliance. Follow the
cleaning instruction on the item label.

• Do not drink or prepare food with the

condensed water/distilled water. It can
cause health problems to people and
pets.

• Do not sit or stand on the open door

of the appliance.

• Do not dry dripping wet clothes in the

appliance.

2.4 Care and cleaning

WARNING!

Risk of injury or damage to
the appliance.

not use abrasive products, abrasive
cleaning pads, solvents or metal
objects.

• Be careful when you clean the
appliance to prevent damage to the
cooling system.

2.5 Compressor

WARNING!

Risk of damage to the
appliance.

• The compressor and its system in the
tumble dryer is filled with a special
agent which is free from fluoro-chloro­hydrocarbons. This system must stay
tight. The damage of the system can
cause a leakage.

2.6 Service

• To repair the appliance contact the
Authorised Service Centre.

• Use original spare parts only.

• Concerning the lamp(s) inside this
product and spare part lamps sold
separately: These lamps are intended
to withstand extreme physical
conditions in household appliances,
such as temperature, vibration,
humidity, or are intended to signal
information about the operational
status of the appliance. They are not
intended to be used in other
applications and are not suitable for
household room illumination.

2.7 Disposal

WARNING!

Risk of injury or suffocation.

Warning: Risk of fire / Flammable
materials. The appliance contains
flammable gas, propane (R290), a gas
with a high level of environmental
compatibility. Keep fire and ignition
sources away from the appliance. Be
careful not to cause damage to the
refrigerant circuit containing propane.

• Do not use water spray and steam to

clean the appliance.

• Clean the appliance with a moist soft

cloth. Use only neutral detergents. Do

Warning: Risk of fire / Risk of
material damage and damage to the
appliance.

• Disconnect the appliance from the

mains electrical and water supplies.

• Cut off the mains electrical cable

close to the appliance and dispose of
it.

• The appliance contains flammable

gas (R290). Contact your municipal
authority for information on how to
discard the appliance correctly.

1 2

7

3

4

5

6

9

8

00000000

00A

Mod.

xxxxxxxxx

000V ~ 00Hz 0000 W

910000000

00

Prod.No.

A B C D

www.aeg.com8

• Remove the door catch to prevent
children or pets from becoming
trapped in the drum.

• Dispose of the appliance in
accordance with local requirements

3. PRODUCT DESCRIPTION

for the disposal of Waste Electrical
and Electronic Equipment (WEEE).

Water container

1

Control panel

2

Appliance door

3

Filter

4

Rating plate

5

For ease of loading laundry
or ease of installation the
door is reversible. (see
separate leaflet).

Airflow slots

6

Condenser lid

7

Condenser cover

8

Adjustable feet

9

The rating plate reports:

A. model name
B. product number
C. electrical ratings
D. serial number

4. CONTROL PANEL

2

3

56

1

4

4

ENGLISH 9

Program dial

1

Display

2

Départ/Pause button

3

Options

4

Marche/Arrêt button

5

Programs

6

4.1 Display

Symbol on the display Symbol description

-

cycle time indication

maximum load

delay start selection (30min-20h)

Anti-Froissage option on

www.aeg.com10

Symbol on the display Symbol description

buzzer off

child lock on

, ,

5. PROGRAMME

Programme

MixDry 5,0 kg Cotton and synthetic fabrics.

3)

Coton Eco

Coton 8,0 kg

Synthétiques 4,0 kg

Délicats 2,0 kg

Draps XL 4,5 kg

laundry dryness: iron dry, cupboard dry, extra dry

Minuterie option on

indicator:

indicator:

indicator:

indicator:

indicator:

indicator:

Départ Différé option on

1)

Load

8,0 kg

drain the water container

clean the filter

check the condenser

drying phase

cooling phase

crease guard phase

Properties / Fabric mark

Cotton fabrics programme de‐
signed for maximum energy sav‐
ing.

White and coloured cotton fabrics
programme. Default setting is for
ready to store dryness level.

Blended garments containing
mostly synthetic fibres like polyest‐
er, polyamide, etc.

Recommended for generic delicate
fabrics such as viscose, rayon,
acrylic and their blends.

Dries up to three bed linen sets at
once. Minimises twists and tangles
of large items to ensure every bed
linen reaches a uniform dryness
without wet spots.

2)

, ,

/

,

/

/

,

/

, ,

/

, ,

/ , ,

ENGLISH 11

Programme

Load

1)

Properties / Fabric mark

2)

Dries generic sportswear made

SportWear 4,0 kg

with synthetic fibres including poly‐
ester, elastane blends, and polya‐

, ,

/

mide.

Ensures proper drying of inner

Duvet 3,0 kg

parts through single or double du‐

/

, ,

vets, pillows, and padded blankets.

Limits creases on small loads of cotton, synthetic
and mixed-fabric garments for easy ironing. Fea‐

Repassage facile 2,0 kg

tures two drying levels: Iron leaves garments
slightly damp for ironing or hanging; Cupboard
fully dries items.

/

, ,

Short low temperature cycle that
helps in removing odours from a

Rafraîchir 1,0 kg

small amount of garments. Indica‐

/

, ,

ted also for dry clothes that were in
storage for long time.

1)
The maximum weight refers to dry items.

2)
For fabric mark meaning see chapter

3)
The

ulation EU No. 392/2012. It is suitable for drying normal wet cotton laundry and it is the most efficient
programme in terms of energy consumption for drying wet cotton laundry.

Coton Eco programme is the “Standard cotton programme” according to Commission Reg‐

DAILY USE: Preparing the laundry.

5.1 Programmes and options selection

Options

Programmes

1)

MixDry

Coton Eco

Coton

Synthétiques

Délicats

Draps XL

SportWear

Degré de séch‐

age

2)

2)

Anti-Froissage Minuterie

www.aeg.com12

Options

Programmes

1)

Degré de séch‐

age

Anti-Froissage Minuterie

Duvet

Repassage facile

Rafraîchir

1)
Together with the programme you can set 1 or more options.

2)
Set by default

2)

5.2 Consumption data

Energy

consump‐

Program Spun at / residual humidity

Drying time

Coton Eco 8,0 kg

prêt à ranger

1400 rpm / 50% 145 min 1,59 kWh

1000 rpm / 60% 178 min 1,93 kWh

Coton 8,0 kg

prêt à repasser

1400 rpm / 50% 110 min 1,18 kWh

1000 rpm / 60% 140 min 1,45 kWh

Coton Eco 4,0 kg

prêt à ranger

1400 rpm / 50% 89 min 0,90 kWh

1000 rpm / 60% 104 min 1,08 kWh

Synthétiques 4,0 kg

1)

tion

2)

prêt à ranger

1200 rpm / 40% 66 min 0,68 kWh

800 rpm / 50% 80 min 0,85 kWh

1)
For partial loads, the cycle time is shorter and appliance uses less energy.

2)
Improper ambient temperature and/or poorly centrifuged laundry can prolong cycle time and increase

the energy consumption.

6. OPTIONS

ENGLISH 13

6.1 Degré de séchage

This option helps to achieve requested
laundry dryness. You can select the level
of dryness:

ready to iron - iron dry level

ready to store - cupboard

dry level

ready to store - extra dry
level

1)
Default selection which is related to the pro‐

gramme

1)

6.2 Anti-Froissage

Extends up to 120 minutes the anti­crease phase (30 minutes) at the end of
the drying cycle. After drying phase drum
rotates from time to time to prevent
creases. Laundry can be removed during
the anti-crease phase.

6.3 Signal sonore

The acoustic signal sounds at the
following:

• cycle end

• start and end of crease guard phase

The acoustic signal is by default always
on. You can use this option to activate or
deactivate the sound.

6.4 Minuterie

For: Coton, Draps XL, Synthétiques and
MixDry programs. Lets the user to set

drying time from minimum 10 min to
maximum of 2 hours (in 10 min steps).
When this option is maximum, load
indicator disappears.

The cycle lasts as long as
set drying time regardless of
the size of a load and its
dryness.

TIME DRYING RECOMMENDATION

up 10

10 - 40

action of cool air only (no heat‐

min

er).

additional drying to improve dry‐
ness after previous drying cy‐

min

cle.

full drying of the small laundry

> 40

loads up to 4 kg, well spun

min

(>1200 rpm).

6.5 Départ Différé

Lets to delay the start of a
drying program from
minimum of 30 minutes to
maximum of 20 hours.

1. Set the drying program and options.

2. Touch Départ Différé button again
and again.

Time of delay is on the display (e.g.

if the program has to start after 12

hours.)

3. To activate Départ Différé option,
touch the Départ/Pause button.

Time to start decreases on the display.

7. BEFORE FIRST USE

Rear drum locks are
removed automatically when
dryer is activated for the first
time. Possible to hear some
noise.

It is highly recommended
to start any programme for
the first time without the
load for a few seconds to
ensure that the rear drum
locks are removed
properly.

A

B

A

B

Brrrr

www.aeg.com14

To unlock the rear drum locks:

1. Switch on the appliance.

2. Set any programme.

3. Press the Start/Pause button.
Drum starts to rotate. Rear drum locks
are automatically deactivated.

If the drum still does not
rotate, please release the
rear drum locks manually (to
do that, please use provided
key).

7.1 Unusual smell

The appliance is tightly packed.

After product unpacking you can feel an
unusual smell. This is normal for brand
new products.

Appliance is built of several different
types of material which all together can
generate unusual smell.

Over usage time, after few drying cycles
unusual smell gradually disappears.

7.2 Noises

Different noises may be
heard at different times
during the drying cycle. They
are perfectly normal
operating sounds.

Working compressor.

Rotating drum.

Before you use the appliance to dry
items:

• Clean the tumble dryer drum with a
moist cloth.

• Start a 1 hour programme with moist
laundry.

At the beginning of the
drying cycle (first 3-5 min)
there could be a slightly
higher sound level. This is
due to the compressor
starting up. This is normal
for compressor powered
appliances such as
refrigerators and freezers.

Working fans.

Working pump and transferring
condensation to the tank.

8. DAILY USE

ENGLISH 15

8.1 Preparing the laundry

Very often the clothes after
washing cycle are kneaded
and tangled altogether.
Drying kneaded and tangled
clothes is inefficient.
To assure proper air flow
and even drying it is
recommended to shake and
load one by one the clothes
to the tumble dryer.

To assure proper drying process:

• Close the zips.

• Close the fasteners of duvet covers.

• Do not dry ties or ribbons loose (e.g.
apron ribbons). Tie them before you
start a programme.

• Remove all items from pockets.

• Turn items with the internal layer
made of cotton inside out. Cotton
layer must be faced outwards.

Fabric label Description

Laundry is suitable for tumble drying.

Laundry is suitable for tumble drying at higher temperatures.

• Always set the programme suitable
for the type of laundry.

• Do not put light and dark colours
together.

• Use suitable programme for cottons,
jersey and knitwear to reduce
shrinkage.

• Do not exceed the maximum load
stated in the programmes chapter or
shown on the display.

• Dry only the laundry that is suitable
for tumble drying. Refer to the fabric
label on the items.

• Do not dry large and small items
together. Small items can be trapped
inside the large items and remain wet.

• Shake the large clothes, fabrics
before placing in the tumble dryer. It is
to avoid moist places inside the fabric
after the drying cycle.

Laundry is suitable for tumble drying at low temperatures only.

Laundry is not suitable for tumble drying.

www.aeg.com16

8.2 Loading the laundry

CAUTION!

Ensure the laundry is not
trapped between the
appliance door and the
rubber seal.

1. Pull open the appliance door.

2. Load the laundry one item at a time.

3. Close the appliance door.

8.3 Turning on the appliance

8.5 Setting a programme

Use the programme dial to set the
programme.

The approximate programme duration
appears on the display.

Real drying time will depend
on type of the load (quantity
and composition), the room
temperature and the
humidity of your laundry
after spin drying phase.

8.6 Options

Together with the programme you can
set 1 or more special options.

To turn on the appliance:

Push the Marche/Arrêt button.

If the appliance is on, some indicators
appear on the display.

8.4 Auto Off function

To decrease the energy consumption,
the Auto Off function turns the appliance
off automatically:

• if the Départ/Pause touch button is
not touched within 5 minutes.

• 5 minutes after a cycle ends.

Push the Marche/Arrêt button to turn on
the appliance.

If the appliance is on, some indications
appear on the display.

To activate or deactivate an option touch
the relevant button or a two button
combination.

its symbol appears on the display or the
led above the corresponding button lights
up.

8.7 Child lock option

The child lock can be set to prevent
children from playing with the appliance.
The child lock option locks all touch

3

s

ENGLISH 17

buttons and the program dial (this option
does not lock the Marche/Arrêt button).

You can activate the child lock option:

• before you touch the Départ/Pause
button - the appliance cannot start

• after you touch the Départ/Pause
button - programs and option
selection is unavailable.

Child lock option activation:

1. Turn the dryer on.

2. Select 1 of the available programs.

3. Touch and hold down Anti-Froissage

button by around 3 seconds.

The symbol appears on the display.

4. To deactivate the child lock, touch

the above button again until the
symbol disappears.

8.8 Starting a program

To start the program:

Touch the Départ/Pause button.

The appliance starts and the LED above
the button stops flashing and stays on.

8.9 Program change

To change a program:

1. Push the Marche/Arrêt button to turn
the appliance off.

2. Push the Marche/Arrêt button again
to turn on the appliance.

3. Set a new program.

8.10 Programme end

Clean the filter and drain the
water container after each
drying cycle. (See chapter
CARE AND CLEANING.)

If the drying cycle is finished, the symbol

appears on the display. If the Signal
sonore option is activated, the acoustic
signal sounds intermittently for 1 minute.

If you do not turn off the
appliance, the anti-crease
phase starts (not active with
all programmes). Flashing

symbol signals the
execution of the anti-crease
phase. Laundry can be
removed during this phase.

To remove the laundry:

1. Push the Marche/Arrêt button for 2
seconds to turn the appliance off.

2. Open the appliance door.

3. Remove the laundry.

4. Close the appliance door.

Possible causes of unsatisfactory drying
results:

• Inadequate default dryness level

settings. See chapter

default dryness level

• Room temperature is too low or too

high. Optimal room temperature is
between 18°-25°C.

Adjustment of

9. HINTS AND TIPS

9.1 Ecological hints

• Spin the laundry well before drying.

• Do not exceed the load sizes which
are specified in the programmes
chapter.

• Clean the filter after each drying
cycle.

• Do not use fabric softener to wash
and then dry. In the tumble dryer
laundry becomes soft automatically.

www.aeg.com18

• The water from the water container
can be used to iron the clothes. You
must first filter the water to eliminate
remaining textile fibres (simple coffee
filter is suitable).

• Always keep the airflow slots at the
bottom of the appliance clear.

• Make sure there is good airflow where
the appliance is to be installed.

9.2 Adjustment of default

dryness level

To change the default dryness level:

1. Turn the appliance on.

2. Select 1 of the available

programmes.

3. Touch and hold down the Degré de

séchage and Anti-Froissage

buttons at the same time.

One of the symbols appears on the
display:

- Maximum dryness

- Extra dryness

- Standard dryness

4. Touch the Départ/Pause button

repeatedly until you reach the

desired dryness level.

Dryness

level

Maximum
dryness

Extra dry‐
ness

Display symbol

Dryness

level

Standard
dryness

5. To memorise the setting touch and
hold down the Degré de séchage
and Anti-Froissage buttons at the
same time for approximately 2
seconds.

Display symbol

9.3 Deactivating the tank

indicator

The water container indicator is activated
by default. It illuminates at the end of the
drying cycle or during the cycle if the
water reservoir is full. If the draining kit is
installed the water container is drained
automatically and the indicator can be
deactivated.

To deactivate the indicator:

1. Turn the appliance on.

2. Select 1 of the available
programmes.

3. Touch and hold down Anti-
Froissage and Signal sonore
buttons at the same time.

One of 2 configurations is possible:

• the réservoir indicator:

the symbol
water container indicator is
permanently activated

• the réservoir indicator:

the symbol
water container indicator is
permanently deactivated

is on if

appears - the

is off if

appears - the

10. CARE AND CLEANING

10.1 Cleaning the filter

At the end of each cycle the
symbol comes on the display and you
must clean the filter.

The filter collects the lint
during the drying cycle.

filtre

To achieve the best drying
performances clean the filter
regularly , clogged filter lead
to longer cycles and energy
consumption increase.
Use your hand to clean the
filter , and if necessary , a
vacuum cleaner .

CAUTION!

Avoid the use of water to
clean the filter. Instead throw
away lint in the dustbin
( avoid dispersion of plastic
fiber in water ambient).

1. Open the door. Pull the filter up.

2. Push the hook to open the filter.

ENGLISH 19

10.2 Emptying the water container

Empty the condensed water container
after each drying cycle.

If the condensed water container is full,
the programme stops automatically. The

réservoir

display and you must empty the water
container.

To empty the water container:

1. Pull the water container out keeping
it in a horizontal position.

symbol comes on the

3. Gather lint with hand from both
internal parts of the filter.

Throw the lint in the dustbin.

4. If necessary, clean the filter with a
vacuum cleaner. Close the filter.

5. If necessary, remove lint from the
filter socket and gasket. You can use
a vacuum cleaner. Place the filter
back inside the filter socket.

2. Pull the plastic connection out and
drain the water into a basin or
equivalent receptacle.

3. Push the plastic connection back in
and place the water container back
into position.

4. To continue the programme press
the Départ/Pause button.

www.aeg.com20

10.3 Cleaning the condenser

If the symbol
the display, inspect the condenser and
its compartment. If it is dirty, clean it. Do
the check not less than once a 6 months.

WARNING!

Do not touch the metal
surface with bare hands.
Risk of injury. Wear
protective gloves. Clean
carefully to avoid damaging
the metal surface.

To inspect:

1. Open the door. Pull the filter up.

2. Open the condenser cover.

condenseur

flashes on

4. Lower the condenser lid.

5. If necessary, remove the fluff from
the condenser and its compartment.
You can use a vacuum cleaner with
the brush attachment.

6. Close the condenser lid.

7. Turn the lever until it clicks into
position.

8. Put the filter back.

3. Turn the lever to unlock the
condenser lid.

10.4 Cleaning the humidity sensor

CAUTION!

Risk of humidity sensor
damage. Do not use
abrasive materials or steel
wool to clean the sensor.

To assure best drying results the
appliance is equipped with metal
humidity sensor. It is placed on the inner
side of the door area.

Over usage time the surface of the
sensor may get dirty which deteriorates
the drying performance.

We recommend to clean the sensor at
least 3 or 4 times or if you observe the
drop of drying performance.

ENGLISH 21

To clean you can use harder side of
dish-washing sponge and bit of vinegar
or dish soap.

To clean the sensor:

1. Open the loading door.

2. Clean the surfaces of the humidity
sensor wiping off the metal surface
several times.

10.5 Cleaning the drum

WARNING!

Disconnect the appliance
before you clean it.

Use a standard neutral soap detergent to
clean the inner surface of the drum and

11. TROUBLESHOOTING

drum lifters. Dry the cleaned surfaces
with a soft cloth.

CAUTION!

Do not use abrasive
materials or steel wool to
clean the drum.

10.6 Cleaning the control panel and housing

Use a standard neutral soap detergent to
clean the control panel and housing.

Use a moist cloth to clean. Dry the
cleaned surfaces with a soft cloth.

CAUTION!

Do not use furniture cleaning
agents or cleaning agents
which can cause corrosion.

10.7 Cleaning the airflow slots

Use a vacuum cleaner to remove fluff
from the airflow slots.

WARNING!

Refer to Safety chapters.

11.1 Error Codes

The appliance does not start or it stops during operation.

First try to find a solution to the problem (refer to the table). If the problem persists,
contact the Authorised Service Centre.

WARNING!

Deactivate the appliance before carrying out any check.

In case of major problems, the acoustic signals operate, the display shows an
error code and the Départ/Pause button may flash continuously:

Error code Possible cause Remedy

E50

Appliance motor overloaded.
Too much laundry or entrap in the
drum.

The programme was not comple‐
ted. Remove the laundry from the
drum, set the programme and re‐
start the cycle.

www.aeg.com22

Error code Possible cause Remedy

Internal fail. No communication be‐
tween electronic elements of the
appliance.

E90 or E91

The mains supply is unstable. When the appliance is showing

EH0

The programme was not finished
properly or the appliance stoped
too early. Switch the appliance off
and on again.
If the error code appears again,
contact the Authorised Service
Centre.

EH0, please wait until main supply
is stable than press start. If the ap‐
pliance pause the cycle without
any indication then press the cycle
start. If the warning will occur
check the power cord / socket in‐
tegrity or main supply.

If the display shows other error codes, deactivate and activate the appliance. If the
problem continues, contact the Authorised Service Centre.

In case of different problem with the tumble dryer check the table below for possible
solutions.

11.2 Troubleshooting

Problem Possible cause Remedy

The tumble dry‐
er does not op‐
erate.

The tumble dryer is not connected
to the mains supply.

The door is open. Close the door.

The Marche/Arrêt button was not
pushed.

The Départ/Pause button was not
touched.

The appliance is in standby mode. Push the Marche/Arrêt button.

Connect it to the mains socket.
Check the fuse in the fuse box (do‐
mestic installation).

Push the Marche/Arrêt button.

Touch the Départ/Pause button.

Problem Possible cause Remedy

Incorrect program selection.

The filter is clogged.

Degré de séchage option was set

to

prêt à repasser

3)

.

Select a suitable program.

Clean the filter.

Change Degré de séchage option
to a higher level.

The load was too large. Do not exceed the maximum load

Unsatisfactory
drying result.

The airflow slots are clogged. Clean the airflow slots at the bot‐

size.

tom of the appliance.

The loading

There is some dirt on the humidity
sensor in the drum.

The dryness level was not set to
the desired level.

The condenser is clogged.

The filter is not locked into posi‐
tion.

Clean the front surface of the
drum.

Adjust the dryness level.

Clean the condenser.

Put the filter in the correct position.

door does not
close

It is not possible
to change the
program or op‐

Laundry is trapped between the
door and the seal.

After a cycle starts it is not possi‐
ble to change the program or op‐
tion.

Remove trapped items and close
the door.

Turn the tumble dryer off and on.
Change the program or option as
required.

tion.

It is not possible
to select an op‐
tion. An acoustic

The option you tried to select is not
available for the selected program.

Turn the tumble dryer off and on.
Change the program or option as

required.
signal is emit‐
ted.

Unexpected du‐
ration time ap‐
pears on the

The drying duration is calculated
according to load size and damp‐
ness.

This is automated - the appliance

is working correctly.

display.

A program is in‐
active.

The water container is full. Drain the water container, push the

Départ/Pause button.

ENGLISH 23

1)

2)

4)

2)

2)

www.aeg.com24

Problem Possible cause Remedy

The load size is small. Select a time program. The time

The drying cycle
is too short.

The laundry is too dry. Select an appropriate time pro‐

The filter is clogged. Clean the filter.

The load is too large. Do not exceed the maximum load

Drying cycle too

5)

long

1)
Follow the program description — see the PROGRAMS chapter .

2)
See the

3)

4)

5)

CARE AND CLEANING

Only dryers with the Degré de séchage option.

See the HINTS AND TIPS chapter .

Note: After a maximum of 5 hours the drying cycle ends automatically.

The laundry was not spun suffi‐
ciently.

Too low or too high room tempera‐
ture - this is not the appliance mal‐
function.

chapter.

value must be related to the load.
To dry one item or a small amount
of laundry we recommend short
drying times.

gram or a higher dryness level

(e.g.

très sec

)

size.

Spin the laundry well in the wash‐
ing machine.

Ensure a room temperature higher
than +5°C and lower than +35°C.
Optimal room temperature to ach‐
ieve best drying results is between
18°-25°C.

11.3 Possible causes of

unsatisfactory drying results:

• The filter is clogged. Clogged filter

makes drying inefficient.

• The airflow slots are clogged.

• The drum is dirty.

12. TECHNICAL DATA

Height x Width x Depth 850 x 596 x 638 mm (maximal 663 mm)

Max. depth with the appliance door open 1108 mm

Max. width with the appliance door open 958 mm

Adjustable height 850 mm (+ 15 mm - feet regulation)

Drum volume 118 l

Maximum load volume 8,0 kg

• Inadequate default dryness level
settings. See chapter

Adjustment of

default dryness level

• Room temperature is too low or too
high. Optimal room temperature is
between 18°-25°C.

ENGLISH 25

Voltage 230 V

Frequency 50 Hz

Sound power level 66 dB

Total power 800 W

Energy efficiency class A++

Energy consumption on the standard cotton

programme with the full load.

1)

Energy consumption on the standard cotton

programme with the partial load.

Annual energy consumption

Left-on mode power absorption

Off mode power absorption

2)

3)

4)

4)

1,93 kWh

1,08 kWh

234,7 kWh

0,50 W

0,50 W

Type of use Household

Allowed ambient temperature + 5°C to + 35°C

Level of protection against ingress of solid

IPX4

particles and moisture ensured by the pro‐
tective cover, except where the low voltage
equipment has no protection against mois‐
ture

Gas designation R290

Weight 0,140 kg

1)
With reference to EN 61121. 8,0 kg of cotton centrifuged at 1000 rpm.

2)
With reference to EN 61121. 4,0 kg of cotton centrifuged at 1000 rpm.

3)
Energy consumption per year in kWh, based on 160 drying cycles of the standard cotton programme

at full and partial load, and the consumption of the low-power modes. Actual energy consumption per cy‐
cle will depend on how the appliance is used (REGULATION (EU) No. 392/2012).

4)
With reference to EN 61121.

The information given in the chart above is compliant with the EU Commission regulation
392/2012 implementing directive 2009/125/EC.

www.aeg.com26

13. ACCESSORIES

13.1 Condenser slots brush

Accessory name: M4YM3001

Available from your authorised vendor.

Special brush to clean the condenser
slots from the fluff. Helps to keep optimal
drying efficiency.

Read carefully the instructions supplied
with the accessory.

13.2 Drain kit

Read carefully the instructions supplied
with the accessory.

13.3 Dryer rack

Accessory name: E4YH200 (A049509),
A4YH200 (A049509).

Dryer rack accessory lets to dry safely in
the tumble dryer:

• delicates

• lingerie

• soft toys

• sport shoes

• sweaters/blouses

13.4 Pedestal with drawer

Accessory name: E2YH01.

Available from your authorised vendor
(can be attached to some types of
tumble dryer)

For thorough draining of the condensed
water into a basin, siphon, gully, etc.
After installation, the water container is
drained automatically. The water
container must stay in the appliance.

The installed hose must be minimum 50
cm to maximum 100 cm from floor level.
The hose cannot be in a loop. Decrease
the length of the hose if necessary.

Accessory name: E6WHPED4.

Available from your authorised vendor.

For increasing the height of the
appliance in order to ease loading and
unloading of laundry.

ENGLISH 27

The drawer can be used for laundry
storage e.g. : towels, cleaning products
etc.

Read carefully the instructions supplied
with the accessory.

13.5 Stacking kit

Accessory name: SKP11GW3,
STA9GW3

Available from your authorised vendor.

Stacking kit can be used only between
washing machines and tumble dryers
specified in the leaflet. See the leaflet
attached.

Read carefully the instructions supplied
with the accessory.

14. PRODUCT INFORMATION SHEET IN REFERENCE TO E.U. REGULATION 1369/2017

Product Information Sheet

Trade Mark AEG

Model TR71A2G2CO

PNC916099240

Rated capacity in kg 8,0

Air vented or condenser tumble dryer Condenser

Energy efficiency class A++

Energy consumption in kWh per year, based on 160 drying cy‐
cles of the standard cotton programme at full and partial load,
and the consumption of the low-power modes. Actual energy
consumption per cycle will depend on how the appliance is
used.

Automatic tumble drier or non-automatic tumble drier Automatic

Energy consumption of the standard cotton programme at full
load in kWh

Energy consumption of the standard cotton programme at par‐
tial load in kWh

234,7

1,93

1,08

www.aeg.com28

Power consumption of the off-mode in W 0,50

Power consumption in left-on mode in W 0,50

Duration of the left on mode in minutes 10

The 'standard cotton programme' used at full and partial load
is the standard drying programme to which the information in
the label and the fiche relates, this programme is suitable for
drying normal wet cotton laundry and it is the most efficient
programme in terms of energy consumption for cotton.

Weighted programme time of the 'standard cotton programme
at full and partial load' in minutes

Programme time of the 'standard cotton programme at full
load' in minutes

Programme time of the 'standard cotton programme at partial
load' in minutes

Condensation efficiency class on a scale from G (least effi‐
cient) to A (most efficient)

Average condensation efficiency of the standard cotton pro‐
gramme at full load as a percentage

Average condensation efficiency of the standard cotton pro‐
gramme at partial load as a percentage

Weighted condensation efficiency for the 'standard cotton pro‐
gramme at full and partial load'

Sound power level in dB 66

Built in appliance Y/N No

136

178

104

B

81

81

81

The information given in the chart above is compliant with the EU Commission regulation
392/2012 implementing directive 2009/125/EC.

15. ENVIRONMENTAL CONCERNS

appliances marked with the symbol

Recycle materials with the symbol
Put the packaging in relevant containers
to recycle it. Help protect the
environment and human health by
recycling waste of electrical and
electronic appliances. Do not dispose of

.

with the household waste. Return the
product to your local recycling facility or
contact your municipal office.

*

www.aeg.com/shop

136988590-A-202022
