AEG S41540TSW2 User Manual [de]
EN User Manual 2
Refrigerator
FR Notice d'utilisation 18
Réfrigérateur
DE Benutzerinformation 36
Kühlschrank
IT Istruzioni per l’uso 54
Frigorifero
S41540TSW2
www.aeg.com
2
CONTENTS
1. SAFETY INFORMATION...........................................................................................3
2. SAFETY INSTRUCTIONS.......................................................................................... 4
3. OPERATION.............................................................................................................. 5
4. FIRST USE.................................................................................................................. 6
5. DAILY USE..................................................................................................................6
6. HINTS AND TIPS....................................................................................................... 7
7. CARE AND CLEANING............................................................................................ 9
8. TROUBLESHOOTING.............................................................................................10
9. INSTALLATION....................................................................................................... 12
10. NOISES.................................................................................................................. 15
11. TECHNICAL INFORMATION...............................................................................17
FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you
impeccable performance for many years, with innovative technologies that help
make life simpler features you might not find on ordinary appliances. Please
spend a few minutes reading to get the very best from it.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.aeg.com
Register your product for better service:
www.registeraeg.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.aeg.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the
following data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
1. SAFETY INFORMATION
Before the installation and use of the appliance,
carefully read the supplied instructions. The
manufacturer is not responsible if an incorrect
installation and use causes injuries and damages. Always
keep the instructions with the appliance for future
reference.
1.1 Children and vulnerable people safety
• This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved.
• Do not let children play with the appliance.
• Cleaning and user maintenance shall not be made by
children without supervision.
• Keep all packaging away from children.
ENGLISH
3
1.2
General Safety
•
This appliance is intended to be used in household
and similar applications such as:
– Farm houses; staff kitchen areas in shops, offices
and other working environments
– By clients in hotels, motels, bed and breakfast and
other residential type environments
• Keep ventilation openings, in the appliance enclosure
or in the built-in structure, clear of obstruction.
• Do not use mechanical devices or other means to
accelerate the defrosting process, other than those
recommended by the manufacturer.
• Do not damage the refrigerant circuit.
• Do not use electrical appliances inside the food
storage compartments of the appliance, unless they
are of the type recommended by the manufacturer.
www.aeg.com4
• Do not use water spray and steam to clean the
appliance.
• Clean the appliance with a moist soft cloth. Only use
neutral detergents. Do not use abrasive products,
abrasive cleaning pads, solvents or metal objects.
• Do not store explosive substances such as aerosol
cans with a flammable propellant in this appliance.
• If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
2. SAFETY INSTRUCTIONS
2.1 Installation
WARNING!
Only a qualified person must
install this appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Obey the installation instruction
supplied with the appliance.
• Always be careful when you move the
appliance because it is heavy. Always
wear safety gloves.
• Make sure the air can circulate around
the appliance.
• Wait at least 4 hours before
connecting the appliance to the
power supply. This is to allow the oil
to flow back in the compressor.
• Do not install the appliance close to
radiators or cookers, oven or hobs.
• The rear of the appliance must stand
against the wall.
• Do not install the appliance where
there is direct sunlight.
• Do not install this appliance in areas
that are too humid or too colds, such
as the construction appendices,
garages or wine cellars.
• When you move the appliance, lift it
by the front edge to avoid scratching
the floor.
2.2 Electrical connection
WARNING!
Risk of fire and electrical
shock.
• The appliance must be earthed.
• Make sure that the electrical
information on the rating plate agrees
with the power supply. If not contact
an electrician.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to
the electrical components (e.g. mains
plug, mains cable, compressor).
Contact the Service or an electrician
to change the electrical components.
• The mains cable must stay below the
level of the mains plug.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
2.3 Use
WARNING!
Risk of injury, burns,
electrical shock or fire.
ENGLISH 5
• Do not change the specification of
this appliance.
• Do not put electrical appliances (e.g.
ice cream makers) in the appliance
unless they are stated applicable by
the manufacturer.
• Be careful not to cause damage to
the refrigerant circuit. It contains
isobutane (R600a), a natural gas with a
high level of environmental
compatibility. This gas is flammable.
• If damage occurs to the refrigerant
circuit, make sure that there are no
flames and sources of ignition in the
room. Ventilate the room.
• Do not let hot items to touch the
plastic parts of the appliance.
• Do not put soft drinks in the freezer
compartment. This will create
pressure on the drink container.
• Do not store flammable gas and
liquid in the appliance.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
• Do not touch the compressor or the
condenser. They are hot.
• Do not remove or touch items from
the freezer compartment if your hands
are wet or damp.
• Do not freeze again food that has
been thawed.
• Obey the storage instructions on the
packaging of frozen food.
2.4 Internal light
• The type of lamp used for this
appliance is not suitable for
household room illumination
• Before maintenance, deactivate the
appliance and disconnect the mains
plug from the mains socket.
• This appliance contains hydrocarbons
in the cooling unit. Only a qualified
person must do the maintenance and
the recharging of the unit.
• Regularly examine the drain of the
appliance and if necessary, clean it. If
the drain is blocked, defrosted water
collects in the bottom of the
appliance.
2.6 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains supply.
• Cut off the mains cable and discard it.
• Remove the door to prevent children
and pets to be closed inside of the
appliance.
• The refrigerant circuit and the
insulation materials of this appliance
are ozone-friendly.
• The insulation foam contains
flammable gas. Contact your
municipal authority for information on
how to discard the appliance
correctly.
• Do not cause damage to the part of
the cooling unit that is near the heat
exchanger.
2.5 Care and cleaning
3.
OPERATION
3.1 Switching on
Insert the electrical plug into a wall
socket.
Turn the temperature regulator clockwise
to a medium setting.
WARNING!
Risk of injury or damage to
the appliance.
3.2 Switching off
To turn off the appliance, turn the
temperature regulator to the "O"
position.
6
www.aeg.com
3.3 Temperature regulation
The temperature is automatically
regulated.
To operate the appliance, proceed as
follows:
• turn the Temperature regulator
towards lower settings to obtain the
minimum coldness.
• turn the Temperature regulator
towards higher settings to obtain the
maximum coldness.
However, the exact setting should be
chosen keeping in mind that the
temperature inside the appliance
depends on:
4. FIRST USE
4.1 Cleaning the interior
Before using the appliance for the first
time, the interior and all internal
accessories should be washed with
lukewarm water and some neutral soap
to remove the typical smell of a brandnew product, then dried thoroughly.
A medium setting is
generally the most suitable.
• room temperature
• how often the lid is opened
• the quantity of food stored
• the location of the appliance.
If the ambient temperature
is high or the appliance is
fully loaded, and the
appliance is set to the lowest
temperature, it may run
continuously causing frost to
form on the rear wall. In this
case the dial must be set to
a higher temperature to
allow automatic defrosting
and therefore reduced
energy consumption.
CAUTION!
Do not use detergents or
abrasive powders, as these
will damage the finish.
5. DAILY USE
WARNING!
Refer to Safety chapters.
5.1 Freezing fresh food
The freezer compartment is suitable for
freezing fresh food and storing frozen
and deep-frozen food for a long time.
To freeze fresh foods it is not necessary
to change the medium setting.
However, for a faster freezing operation,
turn the temperature regulator toward
higher settings to obtain the maximum
coldness.
CAUTION!
In this condition, the
refrigerator compartment
temperature might drop
below 0°C. If this occurs
reset the temperature
regulator to a warmer
setting.
5.2 Storage of frozen food
When first starting-up or after a period
out of use, before putting the products
in the compartment let the appliance run
at least 2 hours on the higher settings.
ENGLISH 7
In the event of accidental
defrosting, for example due
to a power failure, if the
power has been off for
longer than the value shown
in the technical
characteristics chart under
"rising time", the defrosted
food must be consumed
quickly or cooked
immediately and then refrozen (after cooling).
5.3 Thawing
Deep-frozen or frozen food, prior to
being used, can be thawed in the
refrigerator compartment or at room
temperature, depending on the time
available for this operation.
Small pieces may even be cooked still
frozen, directly from the freezer: in this
case, cooking will take longer.
5.4 Movable shelves
The walls of the refrigerator are
equipped with a series of runners so that
the shelves can be positioned as desired.
5.5 Positioning the door shelves
To permit storage of food packages of
various sizes, the door shelves can be
placed at different heights.
1. Gradually pull the shelf in the
direction of the arrows until it comes
free.
2. Reposition as required.
6. HINTS AND TIPS
6.1 Normal operating sounds
The following sounds are normal during
operation:
• A faint gurgling and bubbling sound
from coils sound when refrigerant is
pumped.
• A whirring and pulsating sound from
the compressor when refrigerant is
pumped.
• A sudden cracking noise from inside
appliance caused by thermic
dilatation (a natural and not
dangerous physical phenomenon).
• A faint click noise from the
temperature regulator when the
compressor switches on or off.
8
www.aeg.com
6.2 Hints for energy saving
• Do not open the door frequently or
leave it open longer than absolutely
necessary.
• If the ambient temperature is high
and the Temperature Regulator is set
to low temperature and the appliance
is fully loaded, the compressor may
run continuously, causing frost or ice
on the evaporator. If this happens, set
the Temperature Regulator toward
warmer settings to allow automatic
defrosting and so a saving in
electricity consumption.
• If foreseen, do not remove the cold
accumulators from the freezer basket.
6.3 Hints for fresh food
refrigeration
To obtain the best performance:
• do not store warm food or
evaporating liquids in the refrigerator
• do cover or wrap the food, particularly
if it has a strong flavour
• position food so that air can circulate
freely around it
6.4 Hints for refrigeration
Useful hints:
• Meat (all types) : wrap in polythene
bags and place on the glass shelf
above the vegetable drawer.
• For safety, store in this way only one
or two days at the most.
• Cooked foods, cold dishes, etc..:
these should be covered and may be
placed on any shelf.
• Fruit and vegetables: these should be
thoroughly cleaned and placed in the
special drawer(s) provided.
• Butter and cheese: these should be
placed in special airtight containers or
wrapped in aluminium foil or
polythene bags to exclude as much
air as possible.
• Bottles: these need a cap and should
be stored on the door bottle shelf.
• Bananas, potatoes, onions and garlic,
if not packed, must not be kept in the
refrigerator.
6.5 Hints for freezing
To help you make the most of the
freezing process, here are some
important hints:
• the maximum quantity of food which
can be frozen in 24 hrs. is shown on
the rating plate;
• the freezing process takes 24 hours.
No further food to be frozen should
be added during this period;
• only freeze top quality, fresh and
thoroughly cleaned, foodstuffs;
• prepare food in small portions to
enable it to be rapidly and completely
frozen and to make it possible
subsequently to thaw only the
quantity required;
• wrap up the food in aluminium foil or
polythene and make sure that the
packages are airtight;
• do not allow fresh, unfrozen food to
touch food which is already frozen,
thus avoiding a rise in temperature of
the latter;
• lean foods store better and longer
than fatty ones; salt reduces the
storage life of food;
• water ices, if consumed immediately
after removal from the freezer
compartment, can possibly cause the
skin to be freeze burnt;
• it is advisable to show the freezing in
date on each individual pack to
enable you to keep tab of the storage
time.
6.6 Hints for storage of frozen
food
To obtain the best performance from this
appliance, you should:
• make sure that the commercially
frozen foodstuffs were adequately
stored by the retailer;
• be sure that frozen foodstuffs are
transferred from the foodstore to the
freezer in the shortest possible time;
• not open the door frequently or leave
it open longer than absolutely
necessary;
• once defrosted, food deteriorates
rapidly and cannot be refrozen;
• do not exceed the storage period
indicated by the food manufacturer.
7. CARE AND CLEANING
ENGLISH 9
WARNING!
Refer to Safety chapters.
7.1 General warnings
CAUTION!
Unplug the appliance before
carrying out any
maintenance operation.
This appliance contains
hydrocarbons in its cooling
unit; maintenance and
recharging must therefore
only be carried out by
authorized technicians.
The accessories and parts of
the appliance are not
suitable for washing in a
dishwasher.
7.2 Periodic cleaning
CAUTION!
Do not pull, move or
damage any pipes and/or
cables inside the cabinet.
Take care of not to damage
the cooling system.
When moving the cabinet,
lift it by the front edge to
avoid scratching the floor.
The equipment has to be cleaned
regularly:
1. Clean the inside and accessories with
lukewarm water and some neutral
soap.
2. Regularly check the door seals and
wipe clean to ensure they are clean
and free from debris.
3. Rinse and dry thoroughly.
4. If accessible, clean the condenser
and the compressor at the back of
the appliance with a brush.
This operation will improve the
performance of the appliance and
save electricity consumption.
7.3 Defrosting of the refrigerator
Frost is automatically eliminated from the
evaporator of the refrigerator
compartment every time the motor
compressor stops, during normal use.
The defrost water drains out through a
trough into a special container at the
back of the appliance, over the motor
compressor, where it evaporates.
It is important to periodically clean the
defrost water drain hole in the middle of
the refrigerator compartment channel to
prevent the water overflowing and
dripping onto the food inside.
7.4 Defrosting the freezer
CAUTION!
Never use sharp metal tools
to scrape off frost from the
evaporator as you could
damage it. Do not use a
mechanical device or any
artificial means to speed up
the thawing process other
than those recommended by
the manufacturer. A
temperature rise of the
frozen food packs, during
defrosting, may shorten their
safe storage life.
About 12 hours prior to
defrosting, set a lower
temperature, in order to
build up sufficient chill
reserve for the interruption
in operation.
www.aeg.com10
A certain amount of frost will always form
on the freezer shelves and around the
top compartment.
Defrost the freezer when the frost layer
reaches a thickness of about 3-5 mm.
1. Switch off the appliance, or pull out
electrical plug from the wall socket.
2. Remove any stored food, wrap it in
several layers of newspaper and put
it in a cool place.
WARNING!
Do not touch frozen
goods with wet hands.
Hands can freeze to the
goods.
3. Leave the door open.
In order to speed up the defrosting
process, place a pot of warm water in
the freezer compartment. In addition,
remove pieces of ice that break away
before defrosting is complete.
4. When defrosting is completed, dry
the interior thoroughly.
5. Switch on the appliance.
8. TROUBLESHOOTING
WARNING!
Refer to Safety chapters.
After three hours reload the previously
removed food into the freezer
compartment.
7.5 Periods of non-operation
When the appliance is not in use for long
periods, take the following precautions:
1. Disconnect the appliance from
electricity supply.
2. Remove all food.
3. Defrost (if necessary) and clean the
appliance and all accessories.
4. Leave the door/doors open to
prevent unpleasant smells.
WARNING!
If the cabinet will be kept on,
ask somebody to check it
once in a while to prevent
the food inside from spoiling
in case of a power failure.
8.1 What to do if...
Problem Possible cause Solution
The appliance does not operate.
The mains plug is not con-
There is no voltage in the
The appliance is noisy. The appliance is not suppor-
The lamp does not work. The lamp is in stand-by. Close and open the door.
The appliance is switched
off.
nected to the mains socket
correctly.
mains socket.
ted properly.
The lamp is defective. Refer to "Replacing the
Switch on the appliance.
Connect the mains plug to
the mains socket correctly.
Connect a different electrical
appliance to the mains socket. Contact a qualified electrician.
Check if the appliance
stands stable.
lamp".
Problem Possible cause Solution
The compressor operates
continually.
Many food products to be
The room temperature is too
Food products placed in the
Water flows into the refrigerator.
Door is misaligned or interferes with ventilation grill.
The temperature in the appliance is too low/too high.
Temperature is set incorrectly.
frozen were put in at the
same time.
high.
appliance were too warm.
The water outlet is clogged. Clean the water outlet.
Food products prevent that
water flows into the water
collector.
The appliance is not levelled.
The temperature regulator is
not set correctly.
The door is not closed correctly.
The food products' temperature is too high.
Many food products are
stored at the same time.
The door has been opened
often.
Refer to "Operation" chapter.
Wait some hours and then
check the temperature
again.
Refer to climate class chart
on the rating plate.
Allow food products to cool
to room temperature before
storing.
Make sure that food products do not touch the rear
plate.
Refer to "Levelling".
Set a higher/lower temperature.
Refer to "Closing the door".
Let the food products temperature decrease to room
temperature before storage.
Store less food products at
the same time.
Open the door only if necessary.
ENGLISH 11
If the advice does not lead
to the desired result, call the
nearest brand-mark service.
8.2 Replacing the lamp
Disconnect the plug from the mains
socket.
1. Remove the screw from the lamp
cover.
2. Remove the lamp cover (refer to the
illustration).
3. Replace the used lamp with a new
lamp of the same power and
specifically designed for household
12
www.aeg.com
appliances (the maximum power is
shown on the lamp cover).
4. Install the lamp cover.
5. Tighten the screw to the lamp cover.
6. Connect the plug to the mains
socket.
7. Open the door.
Make sure that the light comes on.
9. INSTALLATION
WARNING!
Refer to Safety chapters.
9.1 Positioning
This appliance can be installed in a dry,
well ventilated indoor where the ambient
temperature corresponds to the climate
class indicated on the rating plate of the
appliance:
Climate
class
SN +10°C to + 32°C
N +16°C to + 32°C
ST +16°C to + 38°C
T +16°C to + 43°C
9.2 Levelling
When placing the appliance ensure that
it stands level. This can be achieved by
two adjustable feet at the bottom in
front.
Ambient temperature
Some functional problems
might occur for some types
of models when operating
outside of that range. The
correct operation can only
be guaranteed within the
specified temperature
range. If you have any
doubts regarding where to
install the appliance, please
turn to the vendor, to our
customer service or to the
nearest Service Centre
8.3 Closing the door
1. Clean the door gaskets.
2. If necessary, adjust the door. Refer to
"Installation".
3. If necessary, replace the defective
door gaskets. Contact the Service
Center.
9.3 Location
It must be possible to
disconnect the appliance
from the mains power
supply; the plug must
therefore be easily
accessible after installation.
The appliance should be installed well
away from sources of heat such as
radiators, boilers, direct sunlight etc.
Ensure that air can circulate freely around
the back of the cabinet. To ensure best
performance, if the appliance is
positioned below an overhanging wall
unit, the minimum distance between the
top of the cabinet and the wall unit must
be at least 100 mm . Ideally, however, the
appliance should not be positioned
below overhanging wall units. Accurate
levelling is ensured by one or more
adjustable feet at the base of the
cabinet.
100 mm
15 mm 15 mm
9.4 Door reversibility
WARNING!
Before carrying out any
operations, remove the plug
from the power socket.
CAUTION!
To carry out the following
operations, we suggest that
this be made with another
person that will keep a firm
hold on the doors of the
appliance during the
operations.
ENGLISH
3. Unscrew the left foot.
4. Unscrew the screws of the door
bottom hinge. Remove the hinge.
Put over the pin in the direction of
the arrow.
13
1. Unscrew both screws on the rear
side.
2. Push back the top and lift it.
5. Unscrew and install the screw on the
opposite side.
6. Install the hinge on the opposite
side.
7. Screw the right foot.
8. Unscrew the screws of the door top
hinge.
3
1
2
1
2
3
14
www.aeg.com
9. Remove the hinge. Put over the pin
in the direction of the arrow. Install
the hinge on the opposite side.
WARNING!
Reposition, level the
appliance, wait for at least
four hours and then connect
it to the power socket.
Do a final check to make
sure that:
• All screws are tightened.
• The magnetic seal
adheres to the cabinet.
• The door opens and
closes correctly.
If the ambient temperature
is cold (i.e. in Winter), the
gasket may not fit perfectly
to the cabinet. In that case,
wait for the natural fitting of
10. Tighten the hinge.
11. Put the top in position.
12. Push front the top.
13. Screw both screws on the rear side.
14. Remove and install the handle on the
opposite side.
the gasket.
In case you do not want to
carry out the above
mentioned operations,
contact the nearest After
Sales Service Force. The
After Sales Service specialist
will carry out the reversibility
of the doors at your cost.
9.5 Reversibility of the freezer
180˚
door
ENGLISH 15
9.6 Electrical connection
• Before plugging in, ensure that the
voltage and frequency shown on the
rating plate correspond to your
domestic power supply.
• The appliance must be earthed. The
power supply cable plug is provided
with a contact for this purpose. If the
domestic power supply socket is not
earthed, connect the appliance to a
separate earth in compliance with
current regulations, consulting a
qualified electrician.
• The manufacturer declines all
responsibility if the above safety
precautions are not observed.
• This appliance complies with the
E.E.C. Directives.
10.
NOISES
There are some sounds during normal running (compressor, refrigerant circulation).
BRRR!
HISSS!
CLICK!
BLUBB!
CRACK!
SSSRR
R!
OK
CLICK!
CLICK!
SSSRRR!
SSSRRR!
BRRR!
BRRR!
HISSS!
HISSS!
BLUBB!
BLUBB!
CRACK!CRACK!
www.aeg.com16
11. TECHNICAL INFORMATION
11.1 Technical data
Height mm 850
Width mm 550
Depth mm 612
Rising time Hours 11
Voltage Volts 230-240
Frequency Hz 50
The technical information are situated in
the rating plate on the external right side
of the appliance and in the energy label.
12. ENVIRONMENT CONCERNS
ENGLISH 17
Recycle the materials with the symbol .
Put the packaging in applicable
containers to recycle it. Help protect the
environment and human health and to
recycle waste of electrical and electronic
appliances. Do not dispose appliances
marked with the symbol with the
household waste. Return the product to
your local recycling facility or contact
your municipal office.
www.aeg.com
18
TABLE DES MATIÈRES
1. CONSIGNES DE SÉCURITÉ................................................................................... 19
2. INSTRUCTIONS DE SÉCURITÉ.............................................................................. 20
3. FONCTIONNEMENT..............................................................................................22
4. PREMIÈRE UTILISATION........................................................................................ 22
5. UTILISATION QUOTIDIENNE................................................................................22
6. CONSEILS................................................................................................................24
7. ENTRETIEN ET NETTOYAGE................................................................................ 25
8. EN CAS D'ANOMALIE DE FONCTIONNEMENT................................................27
9. INSTALLATION....................................................................................................... 29
10. BRUITS................................................................................................................... 33
11. CARACTÉRISTIQUES TECHNIQUES.................................................................. 34
POUR DES RÉSULTATS PARFAITS
Merci d'avoir choisi ce produit AEG. Nous l'avons conçu pour qu'il vous offre des
performances irréprochables pour longtemps, en intégrant des technologies
innovantes qui vous simplifient la vie grâce à des caractéristiques que vous ne
trouverez pas forcément sur des appareils ordinaires. Veuillez prendre quelques
instants pour lire cette notice afin d'utiliser au mieux votre appareil.
Visitez notre site Internet pour :
Obtenir des conseils d'utilisation, des brochures, de l'aide, des informations :
www.aeg.com
Enregistrez votre produit pour obtenir un meilleur service :
www.registeraeg.com
Acheter des accessoires, consommables et pièces de rechange d'origine pour
votre appareil :
www.aeg.com/shop
SERVICE APRÈS-VENTE
Utilisez toujours des pièces d'origine.
Avant de contacter le service, assurez-vous de disposer des informations
suivantes : Modèle, PNC, numéro de série.
Vous trouverez ces informations sur la plaque signalétique.
Avertissement/Consignes de sécurité
Informations générales et conseils
Informations en matière de protection de l'environnement
Sous réserve de modifications.
1. CONSIGNES DE SÉCURITÉ
Avant d'installer et d'utiliser cet appareil, lisez
soigneusement les instructions fournies. Le fabricant ne
peut être tenu pour responsable des dommages et
blessures liés à une mauvaise installation ou utilisation.
Conservez toujours cette notice avec votre appareil
pour vous y référer ultérieurement.
1.1 Sécurité des enfants et des personnes vulnérables
• Cet appareil peut être utilisé par des enfants âgés
d'au moins 8 ans et par des personnes ayant des
capacités physiques, sensorielles ou mentales réduites
ou dénuées d’expérience ou de connaissance, s’ils (si
elles) sont correctement surveillé(e)s ou si des
instructions relatives à l’utilisation de l'appareil en
toute sécurité leur ont été données et si les risques
encourus ont été appréhendées.
• Les enfants ne doivent pas jouer avec l’appareil.
• Le nettoyage et l’entretien par l'usager ne doivent pas
être effectués par des enfants sans surveillance.
• Ne laissez pas les emballages à la portée des enfants.
FRANÇAIS
19
1.2
Consignes générales de sécurité
•
Cet appareil est conçu uniquement pour un usage
domestique et des utilisations telles que :
– dans les bâtiments de ferme, dans des cuisines
réservées aux employés dans des magasins,
bureaux et autres lieux de travail ;
– pour une utilisation privée, par les clients, dans des
hôtels et autres lieux de séjour.
• Veillez à ce que les orifices de ventilation, situés dans
l'enceinte de l'appareil ou dans la structure intégrée,
ne soient pas obstrués.
• N'utilisez aucun dispositif mécanique ou autre
appareil pour accélérer le processus de dégivrage
que ceux recommandés par le fabricant.
20
www.aeg.com
• N'endommagez pas le circuit frigorifique.
• N'utilisez pas d'appareils électriques à l'intérieur des
compartiments de conservation des aliments de
l'appareil, sauf s'ils sont du type recommandé par le
fabricant.
• Ne pulvérisez pas d'eau ni de vapeur pour nettoyer
l'appareil.
• Nettoyez l'appareil avec un chiffon doux humide.
Utilisez uniquement des produits de nettoyage
neutres. N'utilisez pas de produits abrasifs, de
tampons à récurer, de solvants ni d'objets métalliques.
• Ne conservez aucune substance explosive dans cet
appareil, comme des aérosols contenant un produit
inflammable.
• Si le câble d'alimentation est endommagé, il doit être
remplacé par le fabricant, son service après-vente ou
des personnes de qualification similaire afin d'éviter
un danger.
2. INSTRUCTIONS DE SÉCURITÉ
2.1 Installation
AVERTISSEMENT!
L'appareil doit être installé
uniquement par un
professionnel qualifié.
• Retirez l'intégralité de l'emballage
• N'installez pas et ne branchez pas un
appareil endommagé.
• Suivez scrupuleusement les
instructions d'installation fournies
avec l'appareil.
• Soyez toujours vigilants lorsque vous
déplacez l'appareil car il est lourd.
Portez toujours des gants de sécurité.
• Assurez-vous que l'air circule autour
de l'appareil.
• Attendez au moins 4 heures avant de
brancher l'appareil sur le secteur.
Cela permet à l'huile de refouler dans
le compresseur.
• N'installez pas l'appareil à proximité
d'un radiateur, d'une cuisinière, d'un
four ou d'une table de cuisson.
• La surface arrière de l'appareil doit
être positionnée contre un mur.
• N'installez pas l'appareil dans un
endroit exposé à la lumière directe du
soleil.
• N'installez pas l'appareil dans un
endroit trop humide ou trop froid,
comme une dépendance extérieure,
un garage ou une cave.
• Lorsque vous déplacez l'appareil,
veillez à le soulever par l'avant pour
éviter de rayer le sol.
2.2 Connexion électrique
AVERTISSEMENT!
Risque d'incendie ou
d'électrocution.
• L'appareil doit être relié à la terre.
• Vérifiez que les données électriques
figurant sur la plaque signalétique
correspondent à celles de votre
réseau. Si ce n'est pas le cas,
contactez un électricien.
FRANÇAIS
21
• Utilisez toujours une prise antichoc
correctement installée.
• N'utilisez pas d'adaptateurs
multiprises ni de rallonges.
• Veillez à ne pas endommager les
composants électriques tels que la
fiche secteur, le câble d'alimentation
ou le compresseur. Contactez le
service après-vente ou un électricien
pour changer les composants
électriques.
• Le câble d'alimentation doit rester en
dessous du niveau de la fiche secteur.
• Ne branchez la fiche d'alimentation à
la prise de courant qu'à la fin de
l'installation. Assurez-vous que la
prise de courant est accessible une
fois l'appareil installé.
• Ne tirez jamais sur le câble
d'alimentation pour débrancher
l'appareil. Tirez toujours sur la fiche.
2.3 Usage
AVERTISSEMENT!
Risque de blessures, de
brûlures, d'électrocution ou
d'incendie.
• Ne modifiez pas les caractéristiques
de cet appareil.
• Ne placez aucun appareil électrique
(sorbetière, etc.) dans l'appareil, en
l'absence d'indications du fabricant.
• Veillez à ne pas endommager le
circuit frigorifique. Il contient de
l'isobutane (R600a), un gaz naturel
ayant un niveau élevé de
compatibilité environnementale. Ce
gaz est inflammable.
• Si le circuit frigorifique est
endommagé, assurez-vous de
l'absence de flammes et de sources
d'ignition dans la pièce. Aérez la
pièce.
• Évitez tout contact d'éléments chauds
avec les parties en plastique de
l'appareil.
• Ne placez jamais de boissons
gazeuses dans le congélateur. Cela
engendrerait une pression sur le
récipient de la boisson.
• Ne stockez jamais de gaz ou de
liquide inflammable dans l'appareil.
• Ne placez pas de produits
inflammables ou d'éléments imbibés
de produits inflammables à l'intérieur
ou à proximité de l'appareil, ni sur
celui-ci.
• Ne touchez pas le compresseur ni le
condenseur. Ils sont chauds.
• Ne retirez pas et ne touchez pas les
éléments du compartiment
congélateur avec les mains mouillées
ou humides.
• Ne recongelez jamais un aliment qui a
été décongelé.
• Respectez les instructions de
stockage figurant sur l'emballage des
aliments surgelés.
2.4 Éclairage interne
• Le type d'ampoule utilisé dans cet
appareil n'est pas adapté à l'éclairage
de votre habitation.
2.5 Entretien et nettoyage
AVERTISSEMENT!
Risque de blessure
corporelle ou de dommages
matériels.
• Avant toute opération d'entretien,
éteignez l'appareil et débranchez la
fiche de la prise secteur.
• Cet appareil contient des
hydrocarbures dans son circuit de
réfrigération. L'entretien et la
recharge du circuit de réfrigération
doivent être effectués par un
professionnel qualifié.
• Examinez régulièrement l'écoulement
de l'appareil et si nécessaire,
nettoyez-le. Si l'orifice est bouché,
l'eau provenant du dégivrage
s'écoulera en bas de l'appareil.
2.6 Mise au rebut
AVERTISSEMENT!
Risque de blessure ou
d'asphyxie.
• Débranchez l'appareil de
l'alimentation électrique.
• Coupez le câble d'alimentation et
mettez-le au rebut.
• Retirez la porte pour empêcher les
enfants et les animaux de s'enfermer
dans l'appareil.
www.aeg.com22
• Le circuit frigorifique et les matériaux
d'isolation de cet appareil préservent
la couche d'ozone.
• La mousse isolante contient un gaz
inflammable. Contactez votre service
municipal pour obtenir des
3. FONCTIONNEMENT
3.1 Mise en marche
Insérez la fiche dans la prise murale.
Tournez le thermostat vers la droite sur
une position médiane.
3.2 Mise à l'arrêt
Pour éteindre l'appareil, tournez le
thermostat sur la position « O ».
3.3 Réglage de la température
La température est régulée
automatiquement.
Pour utiliser l'appareil, procédez comme
suit :
• tournez le thermostat vers le réglage
minimal pour obtenir le niveau de
froid minimal.
• tournez le thermostat vers le réglage
maximal pour obtenir le niveau de
froid maximal.
Un réglage intermédiaire est
généralement le plus
indiqué.
informations sur la marche à suivre
pour mettre l'appareil au rebut.
• N'endommagez pas la partie du
circuit de réfrigération située à
proximité du condenseur thermique.
Toutefois, on obtiendra le réglage exact
en tenant compte du fait que la
température à l'intérieur de l'appareil
dépend de plusieurs facteurs :
• la température ambiante
• la fréquence d'ouverture du couvercle
• la quantité d'aliments stockés
• l'emplacement de l'appareil.
Si la température ambiante
est élevée ou l'appareil très
rempli et si le thermostat est
réglé sur la température la
plus basse, il est possible
que le compresseur
fonctionne en régime
continu, d'où un risque de
formation de givre sur la
paroi arrière. Pour éviter cet
inconvénient, modifiez la
position du thermostat pour
obtenir moins de froid, de
façon à permettre un
dégivrage automatique et,
par conséquent, des
économies d'énergie.
4. PREMIÈRE UTILISATION
4.1 Nettoyage de l'intérieur
Avant d'utiliser l'appareil pour la
première fois, nettoyez l'intérieur et tous
les accessoires avec de l'eau tiède
savonneuse (pour supprimer toute odeur
de neuf), puis séchez-les soigneusement.
5. UTILISATION QUOTIDIENNE
AVERTISSEMENT!
Reportez-vous aux chapitres
concernant la sécurité.
ATTENTION!
N'utilisez jamais de produits
abrasifs ou caustiques car ils
pourraient endommager le
revêtement.
5.1 Congélation d'aliments
frais
Le compartiment congélateur est idéal
pour congeler des aliments frais et
Loading...
