AEG LR1851 User Manual
LAVAMAT
REGINA 1851
Washing machine
User information
Dear customer,
Please read this User Information carefully and keep it to refer to at a
later date.
Pass this User Information on to any subsequent owner of the appliance.
The following symbols are used in the text:
1 Safety instructions
Warning: Notes that concern your personal safety.
Attention: Notes that show how to avoid damage to the appliance.
3 Useful tips and hints
2 Environmental information
2
Contents
Operating Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Switching on the appliance for the first time – setting the language 7
Description of the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Control panel with display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Indicators in the display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Main control features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Programme overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Before the first wash. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Setting the time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Carrying out a wash programme prior to first use. . . . . . . . . . . . . . . . . . . . . 14
Preparing and sorting washing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Running a washing cycle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Switching on the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Setting a programme. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Changing the temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Changing the spin speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Selecting options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
TIME SAVING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
DELAY START . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
SENSITIVE/STAIN/PRE WASH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Opening the door/Loading the washing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
CURRENT LOAD/DETERGENT display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Adding detergent/conditioner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Starting a programme. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Programme progress . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Interrupting a programme/Adding washing . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Washing cycle complete/Removing the washing . . . . . . . . . . . . . . . . . . . . . . 22
Setting extra options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
MEMORY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Saving a programme setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Clearing a stored programme setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
RINSE+, GENTLE SPIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
LANGUAGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
TIMER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
VOLUME . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
3
Programme protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Child safety device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Cleaning and maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
What to do if.... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Remedying small malfunctions yourself . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
If the wash results are not satisfactory. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Carrying out an emergency drain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Drain pump. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Technical data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Consumption values. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Installation and connection instructions. . . . . . . . . . . . . . . . . 37
Safety information for the installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Installing the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Transporting the appliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Unpacking. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Where to install . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Making the appliance level. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Electrical connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Connecting to the water supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Water inlet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Water drainage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Guarantee/Customer Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
4
Operating Instructions
1 Safety
Prior to using for the first time
• Follow the ”Instructions for installation and connection”.
• If the appliance is delivered in the winter months when there are mi-
nus temperatures: Store the washing machine at room temperature
for 24 hours before using for the first time.
Correct use
• The washing machine is only designed for the washing of normal domestic laundry at home.
• Additions or modifications to the washing machine are not permitted.
• Use only detergents and additives that are suitable for use in domestic washing machines.
• The washing must not contain any inflammable solutions. Danger of
explosion!
• Do not use the washing machine for dry cleaning.
• Dyes/colour removers may only be used in the washing machine, if
the manufacturer of these products expressly permits this. We cannot
be held responsible for any damage arising.
Child safety
• Keep packaging away from children. There is a risk of suffocation.
• Children often do not recognise the hazards associated with electrical
appliances. Don’t allow children to use the washing machine unsupervised.
• Make sure that children and pets don’t climb into the drum of the
washing machine. Could endanger life!
5
General safety
• Repairs to the washing machine must only be carried out by qualified
service engineers.
• Never use the washing machine if the mains cable is damaged; or if
the control panel, work top or plinth area is damaged such that the
inside of the appliance is freely accessible.
• Switch off the washing machine before cleaning, maintenance and
servicing. In addition, pull the mains plug out of the socket or – in
the case of a permanent connection – switch off the cut-out in the
fuse box or remove the screw fuse completely.
• If operation is stopped, disconnect the appliance from the mains supply and shut off the water tap.
• Never unplug the appliance by pulling on the cable. Always pull the
plug.
• Multi-way plugs, connectors and extension cables must not be used.
This could constitute a fire hazard through overheating.
• Never wash the washing machine down with a water jet. Danger of
electric shock!
• In washing programmes with high temperatures the glass in the door
gets hot. Do not touch it.
• Before emergency emptying of the appliance, before cleaning the
drain pump or opening the door in an emergency, let the water cool
down.
• Small animals can nibble at the cables and water hoses. Danger of
electric shock and danger of water damage! Keep small animals away
from the washing machine.
6
Switching on the appliance for the first time
– setting the language
When switching on the appliance for the first time you should be sure
to set the language in which you want the indicators in the display to
appear.
1. Press the control knob.
The appliance is now
switched on. The languages
that can be chosen will appear in the display. In the
factory the language is preset to German.
Important: If the display is not showing any languages, the appliance
has been switched on before. If this happens, please see the section
“Setting extra options: Language”, if you want to change the language
setting.
2. Use the control knob to
highlight the desired language.
3. Press the SELECT key.
From now on all indicators in
the display will appear in this
language.
4. Press the control knob to
switch off the appliance.
EXTRAS
SPRACHE
¿
ANWÄHLEN
ZURÜCK
EXTRAS
LANGUAGE
SELECT
BACK
EXTRAS
LANGUAGE
SELECT
BACK
§
ENGLISH§
DEUTSCH)
ITALIANO§
FRANÇAIS§
¿
§§
ENGLISH!)
DEUTSCH§§
ITALIANO§§
FRANÇAIS§§
¿
§§
ENGLISH!)
DEUTSCH§§
ITALIANO§§
FRANÇAIS§§
7
Description of the appliance
Drawer for
detergent and
conditioner
Three screw feet
(height adjustable);
rear left:
Automatic foot
Control panel with display
LINEN/EASY-C. 60°C
1800 RPM 10:17-12:16
START
60°
1800
OPTIONS WOOLLENS
Control panel with display
î
LINEN/EASY-C.)
ENERGY SAVING
COTTONS
DELICATES
Door
Rating plate
(behind door)
Drain pump cover
Control knobButtons
Display
Indicators in the display
Information panel
shows programme,
temperature and spin
speed
Symbol row
shows options selected
and extras
8
1800 RPM 10:17-12:16
START
60°
1800
OPTIONS
LINEN/EASY-C. 60°C
LINEN/EASY-C.)
ENERGY SAVING
COTTONS
DELICATES
WOOLLENS
î
Current time –
end time of selected
programme
Navigation
display
Selection
Programme,
options,
extras
Main control features
Control knob
Switching the appliance on and off
Press the control knob to
switch the appliance on and
off.
Highlighting
You can highlight the entries
on the right of the display by
turning the control knob.
Cancelling settings
If you would like to cancel settings that have been made by mistake,
switch the appliance off and on again using the control knob. You are
now able to re-set the programme.
WOOLLENS 40°C
1200 RPM 10:17-10:54
START
40°
1200
OPTIONS WOOLLENS )
î
LINEN/EASY-C.
ENERGY SAVING
COTTONS
DELICATES
Keys
Using the keys you can:
– activate an entry on the
left-hand side of the display, e.g. START
– change the temperature
and the spin speed
– select OPTIONS and
EXTRAS.
LINEN/EASY-C. 60°C
1400 RPM 10:17-12:16
START
60°
1400
OPTIONS WOOLLENS
î
LINEN/EASY-C.)
ENERGY SAVING
COTTONS
DELICATES
3 You can set one or more options for each programme.
The basic rule: First set the programme, then set the option.
3 The programmes and functions are divided into different levels and
pages. In the navigation display you can see the level and the page you
are currently on (e.g. ì: level 3, page 1 of 2).
9
Programme overview
Programme
max. load
(dry washing)
1)
LINEN/EASY-CARES
60, 50, 40, 30, 20
5kg
or
2,5kg
TIME SAVING
QUICK
2)
•
•2)• • •
Options Spin speed
DELAY START
SENSITIVE
STAIN
PRE WASH
1800/1600/ 1400
VERY QUICK
3)
• • • •
1200/ 1000/
800/600/400
RINSE HOLD
ENERGY SAVING
4)
COTTONS 95 5kg1)•
DELICATES
40, 30, 20
WOOLLENS (Handwash)
40, 30, COLD
1)
5kg
2)
• • • • • • •
•2)• • • • • • •
2,5kg • • •3)• • •
2kg • • •
SILK (Handwash) 30 1kg • • •
LINGERIE 40 1kg • • •
40 -60 MIX 5kg
EASY IRON
60, 50, 40, 30, 20
1)
• • • • • • •
1kg • • • •3)• • •
REFRESH 30 2,5kg • • •
FASHION 40 2,5kg • • • • • •
1) In the case of excessively large volume washing of a fleecy nature, e.g. terry towelling, flannelette, it may be
that the drum is already full before the maximum load is reached.
2) Recommended load for short progammes is 2,5 kg; full loading is possible however with somewhat reduced
cleaning results.
3) STAIN can only be selected with wash temperatures of 40°C and above, as stain treatment products are only
effective at higher temperatures.
4) Programme settings for tests in accordance with or support of EN 60 456 and IEC 60 456 are described in
the section “Consumption values”.
10
Use/Features
Care-
symbols
1)
General programme for coloured and easy-care items made of cotton/linen as
well as for easy-care mixed fibres and synthetics. The wash programme is adjusted according to the different fabric types and load sizes. If loading only with
easy-care washing, do not load more than 2,5kg.
Energy-saving and water-saving programme which washes at 60 °C for lightly to
normally soiled whites/coloureds made of cotton/linen.
Programme for normally to heavily soiled whites made of cotton/linen.
Gentle programme for delicate fabrics such as bonded fabrics, microfibres, synthetics, net curtains (max. load for net curtains 15 to 20m
also suitable for fabrics with climate membrane, e.g. outdoor clothing.
Particularly delicate programme for machine washable and hand washable wool
or wool mixtures.
Specially gentle programme for machine and hand-washable silk. Wash very delicate items individually.
Gentle programme for fine, sensitive fabrics.
IMPORTANT: Place lingerie containing wires in a washing net or bag.
Programme for coloureds, which are labelled for different wash temperatures.
Items, which according to the care symbols are normally to be washed separately
at 40°C or at 60°C, can be washed together in this programme. Achieves the
washing results of a normal 60° programme.
Special programme for easy-care fabrics, which afterwards are to be ironed only
lightly or not at all.
Special programme, approx. 20 minutes long, for quickly washing through slightly dirty or new clothes.
Gentle special programme for fabrics such as viscose, modal, cupro, lyocell, with
a more gentle machine action than in the Delicates programme and a more intensive cleaning action than the Handwash programme.
1) The figures in the care symbols indicate the maximum temperatures.
2
). With RINSE HOLD
I K N
J M
M O
O
I K
Q L H
Q L H
K L
J M
K N
J M O
I K N
K L
11
Options Spin speed
TIME SAVING
Programme
max. load
(dry washing)
QUICK
SHORT SPIN 2,5kg • •
SPIN 5kg • • •
STARCH 5kg • • • •
DRAIN •
VERY QUICK
DELAY START
SENSITIVE
STAIN
PRE WASH
1800/1600/ 1400
1200/ 1000/
800/600/400
RINSE HOLD
12
Use/Features
Care-
symbols
1)
Drain and short spin after a rinse hold, or separate short spin of handwashed delicates, woollens, silk.
Drain and spin, e.g. after a rinse hold, or separate spin for hand-washed cottons/
linens and easy-cares.
Separate starching, conditioning, stiffening, treating of damp washing.
Draining of the water after a rinse hold.
1) The figures in the care symbols indicate the maximum temperatures.
I K N
Q L
H
J M O
J M O
I K N
13
Before the first wash
Setting the time
So that the current time and the end of the programme are correctly
displayed, please check the display and set the current time, if necessary. (See “Setting extra options: Timer”.)
Carrying out a wash programme prior to first use
Before doing your first wash, run a washing cycle without any washing
in the machine (programme COTTONS 95°, option TIME SAVING/VERY
QUICK, use approx. 1/4 measuring cup of washing powder). This will remove any residues from the drum and water container which have
been left as a result of the production process.
Preparing and sorting washing
Preparing washing
• Empty pockets. Remove foreign bodies (e. g. coins, paper clips, nails,
etc.).
• Do up zips, button up covers to prevent damage to washing.
• Remove the runners from net curtains or cover them with a net or a
bag.
• Wash sensitive and small items in a net or a pillow case, e.g. net curtains, tights, socks, handkerchiefs, bras.
Important! Bras and other items containing wires should only be
washed in a net bag. The wires can work loose and damage the appliance.
14
Sorting washing
• By colour: Wash white and coloured washing separately. Washing can
run.
• By temperature, type of washing and care symbol.
Important! Do not wash fabrics with care symbol G (= do not wash!)
in the washing machine.
Running a washing cycle
Switching on the appliance
Press the control knob.
The appliance is now
switched on.
3 Before switching the appli-
ance on, make sure that the
drum is empty. If you do not,
the washing will subsequently not be registered properly by the load sensor.
Setting a programme
1. Highlight the desired pro-
gramme, e.g. DELICATES.
Changing the temperature
2. Press the temperature key
repeatedly, until the desired
temperature appears, e.g.
30°C.
DELICATES 40°C
1200 RPM 11:25-12:36
START
40°
1200
OPTIONS WOOLLENS
DELICATES 30°C
1200 RPM 11:25-12:36
START
30°
1200
OPTIONS WOOLLENS
LINEN/EASY-C.
ENERGY SAVING
COTTONS
DELICATES)
LINEN/EASY-C.
ENERGY SAVING
COTTONS
DELICATES)
î
î
Changing the spin speed
3. Press the key for the spin
speed repeatedly until the
desired spin speed appears
e.g. 1000 or the RINSE HOLD.
3 RINSE HOLD means: the
washing is left to soak in the
last rinse water and is not
spun.
If required, set options.
DELICATES 30°C
1000 RPM 11:25-12:36
START
30°
1000
OPTIONS WOOLLENS
î
LINEN/EASY-C.
ENERGY SAVING
COTTONS
DELICATES)
.
15
Loading...
