Aeg FSE62400P User Manual
USER
MANUAL
FSE62400P
EN User Manual 2
Dishwasher
ET Kasutusjuhend 23
Nõudepesumasin
FR Notice d'utilisation 44
Lave-vaisselle
www.aeg.com2
CONTENTS
1. SAFETY INFORMATION.............................................................................................3
2. SAFETY INSTRUCTIONS.............................................................................................4
3. PRODUCT DESCRIPTION...........................................................................................5
4. CONTROL PANEL....................................................................................................... 6
5. PROGRAMMES............................................................................................................7
6. SETTINGS.....................................................................................................................8
7. OPTIONS....................................................................................................................11
8. BEFORE FIRST USE................................................................................................... 12
9. DAILY USE..................................................................................................................13
10. HINTS AND TIPS..................................................................................................... 15
11. CARE AND CLEANING.......................................................................................... 16
12. TROUBLESHOOTING.............................................................................................18
13. TECHNICAL INFORMATION................................................................................. 21
FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you
impeccable performance for many years, with innovative technologies that help
make life simpler features you might not find on ordinary appliances. Please
spend a few minutes reading to get the very best from it.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.aeg.com/webselfservice
Register your product for better service:
www.registeraeg.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.aeg.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the
following data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
1. SAFETY INFORMATION
Before the installation and use of the appliance,
carefully read the supplied instructions. The
manufacturer is not responsible for any injuries or
damages that are the result of incorrect installation or
usage. Always keep the instructions in a safe and
accessible location for future reference.
1.1 Children and vulnerable people safety
• This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning the use of the appliance in a
safe way and understand the hazards involved.
• Do not let children play with the appliance.
• Keep detergents away from children.
• Keep children and pets away from the appliance door
when it is open.
• Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
ENGLISH
3
General Safety
1.2
• This appliance is intended to be used in household
and similar applications such as:
– farm houses; staff kitchen areas in shops, offices
and other working environments;
– by clients in hotels, motels, bed & breakfast and
other residential type environments.
• Do not change the specification of this appliance.
• The operating water pressure (minimum and
maximum) must be between 0.5 (0.05) / 8 (0.8) bar
(MPa)
• Obey the maximum number of 9 place settings.
• If the supply cord is damaged, it must be replaced by
the manufacturer, its Authorised Service Centre or
similarly qualified persons in order to avoid a hazard.
www.aeg.com4
• Put knives and cutlery with sharp points in the cutlery
basket with the points down or in a horizontal
position.
• Do not keep the appliance door open without
supervision to prevent to fall on it.
• Before any maintenance operation, deactivate the
appliance and disconnect the mains plug from the
socket.
• Do not use high pressure water sprays and/or steam
to clean the appliance.
• The ventilation openings in the base (if applicable)
must not be obstructed by a carpet.
• The appliance is to be connected to the water mains
using the new supplied hose-sets. Old hose sets must
not be reused.
2. SAFETY INSTRUCTIONS
2.1 Installation
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Do not install or use the appliance
where the temperature is less than 0
°C.
• Follow the installation instruction
supplied with the appliance.
• Make sure that the appliance is
installed below and adjacent to safe
structures.
2.2 Electrical connection
WARNING!
Risk of fire and electrical
shock.
• The appliance must be earthed.
• Make sure that the electrical
information on the rating plate agrees
with the power supply. If not, contact
an electrician.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to
the mains plug and to the mains
cable. Should the mains cable need
to be replaced, this must be carried
out by our Authorised Service Centre.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
• This appliance complies with the
E.E.C. Directives.
• Only for UK and Ireland. The
appliance has a 13 amp mains plug. If
it is necessary to change the fuse in
the mains plug, use fuse: 13 amp
ASTA (BS 1362).
2.3 Water connection
• Do not cause damage to the water
hoses.
• Before connection to new pipes,
pipes not used for a long time, where
repair work has been carried out or
new devices fitted (water meters,
etc.), let the water flow until it is clean
and clear.
4
3
7
9
8
10
56
11
1
2
ENGLISH
5
• Ensure that there are no visible water
leaks during and after the first use of
the appliance.
• The water inlet hose has a safety valve
and a sheath with an inner mains
cable.
WARNING!
Dangerous voltage.
• If the water inlet hose is damaged,
immediately close the water tap and
disconnect the mains plug from the
mains socket. Contact the Authorised
Service Centre to replace the water
inlet hose.
2.4 Use
• Do not sit or stand on the open door.
• Dishwasher detergents are
dangerous. Obey the safety
instructions on the detergent
packaging.
• Do not drink and play with the water
in the appliance.
• Do not remove the dishes from the
appliance until the programme is
completed. There can be detergent
on the dishes.
• The appliance can release hot steam
if you open the door while a
programme operates.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
2.5 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains supply.
• Cut off the mains cable and discard it.
• Remove the door catch to prevent
children and pets to get closed in the
appliance.
3. PRODUCT DESCRIPTION
Upper spray arm
1
Lower spray arm
2
1
2
3
4
5
6
7
8
9
www.aeg.com6
Filters
3
Rating plate
4
Salt container
5
Air vent
6
Rinse aid dispenser
7
3.1 Beam-on-Floor
The Beam-on-Floor is a light that is
displayed on the floor below the
appliance door.
• When the programme starts, a red
light comes on and stays on for the
duration of the programme.
• When the programme is completed, a
green light comes on.
• When the appliance has a
malfunction, the red light flashes.
4. CONTROL PANEL
Detergent dispenser
8
Cutlery basket
9
Lower basket
10
Upper basket
11
The Beam-on-Floor goes off
when the appliance is
deactivated.
When AirDry is activated
during the drying phase, the
projection on the floor may
not be completely visible. To
see if the cycle has ended,
check the control panel.
On/off button
1
Display
2
Delay button
3
Program button
4
ExtraHygiene button
5
4.1 Indicators
Indicator Description
End indicator.
Rinse aid indicator. It is always off while the programme operates.
Salt indicator. It is always off while the programme operates.
TimeSaver button
6
XtraDry button
7
RESET button
8
Indicators
9
5. PROGRAMMES
ENGLISH
7
Programme Degree of soil
Programme phases Options
Type of load
P1
1)
• Normal soil
• Crockery and
cutlery
• Prewash
• Wash 50 °C
• Rinses
• ExtraHygiene
• TimeSaver
• XtraDry
• Dry
P2
2)
• All
• Crockery, cutlery, pots and
pans
• Prewash
• Wash from 45 °C to 70
°C
• Rinses
• ExtraHygiene
• XtraDry
• Dry
P3 • Heavy soil
• Crockery, cutlery, pots and
pans
P5
P6
3)
• Fresh soil
• Crockery and
• Normal soil
• Crockery and
4)
cutlery
cutlery
• Prewash
• Wash 70 °C
• Rinses
• Dry
• Wash 60 °C or 65 °C
• Rinses
• Prewash
• Wash 50 °C
• Rinses
• ExtraHygiene
• TimeSaver
• XtraDry
• ExtraHygiene
• XtraDry
• XtraDry
• Dry
P4 • Normal or light
soil
• Delicate crock-
• Wash 45 °C
• Rinses
• Dry
• XtraDry
ery and glassware
1)
With this programme you have the most efficient use of water and energy consumption for crockery
and cutlery with normal soil. (This is the standard programme for test institutes).
2)
The appliance senses the degree of soil and the quantity of items in the baskets . It automatically ad-
justs the temperature and the quantity of water, the energy consumption and the programme duration.
3)
With this programme you can wash a load with fresh soil. It gives good washing results in a short time.
4)
This is the most silent programme. The pump works at a very low speed to decrease the level of noise.
Because of the low speed, the programme duration is long.
5.1 Consumption values
Programme
1)
Water
(l)
P1 9.9 0.700 243
Energy
(kWh)
Duration
(min)
www.aeg.com8
Programme
P2 6 - 12 0.5 - 1.2 40 - 150
P3 11 - 13 1.0 - 1.2 130 - 150
P5 8 0.6 - 0.8 30
P6 9 - 11 0.9 - 1.1 220 - 230
P4 10 - 12 0.8 - 0.9 60 - 80
1)
The pressure and the temperature of the water, the variations of the mains supply, the options and the
quantity of dishes can change the values.
5.2 Information for test institutes
For all the necessary information for test
performance, send an email to:
6. SETTINGS
6.1 Programme selection
mode and user mode
When the appliance is in programme
selection mode it is possible to set a
programme and to enter the user mode.
In user mode, the following settings
can be changed:
• The level of the water softener
according to the water hardness.
• The activation or the deactivation of
the acoustic signal for end of
programme.
• The activation or deactivation of the
rinse aid empty notification.
• The activation or the deactivation of
AirDry.
These settings will be saved until you
change them again.
1)
Water
(l)
Energy
(kWh)
info.test@dishwasher-production.com
Write down the product number (PNC)
that is on the rating plate.
Duration
(min)
How to set the programme selection mode
The appliance is in programme selection
mode when the display shows the
programme number P1.
When you activate the appliance, usually
it is in programme selection mode.
However, if this does not happen, you
can set the programme selection mode
in the following way:
Press and hold RESET until the appliance
is in programme selection mode.
6.2 The water softener
The water softener removes minerals
from the water supply, which would have
a detrimental effect on the washing
results and on the appliance.
The higher the content of these minerals,
the harder your water is. Water hardness
is measured in equivalent scales.
ENGLISH
9
The water softener should be adjusted
according to the hardness of the water in
your area. Your local water authority can
in your area. It is important to set the
right level of the water softener to assure
good washing results.
advise you on the hardness of the water
Water hardness
German de-
grees (°dH)
47 - 50 84 - 90 8.4 - 9.0 58 - 63 10
43 - 46 76 - 83 7.6 - 8.3 53 - 57 9
37 - 42 65 - 75 6.5 - 7.5 46 - 52 8
29 - 36 51 - 64 5.1 - 6.4 36 - 45 7
23 - 28 40 - 50 4.0 - 5.0 28 - 35 6
19 - 22 33 - 39 3.3 - 3.9 23 - 27
15 - 18 26 - 32 2.6 - 3.2 18 - 22 4
11 - 14 19 - 25 1.9 - 2.5 13 - 17 3
4 - 10 7 - 18 0.7 - 1.8 5 - 12 2
<4 <7 <0.7 < 5
1)
Factory setting.
2)
Do not use salt at this level.
Whether you use a standard detergent
or multi-tabs (with or without salt), set
the proper water hardness level to
keep the salt refill indicator active.
Multi-tabs containing salt
are not effective enough to
French degrees
(°fH)
mmol/l Clarke de-
grees
• The display shows the current
setting: e.g.
3. Press again and again to change
the setting.
4. Press the on/off button to confirm
the setting.
soften hard water.
6.3 The rinse aid empty
How to set the water softener level
The appliance must be in programme
selection mode.
1. To enter the user mode, press and
hold simultaneously
the indicators , , and
start to flash and the display is blank.
2. Press
.
• The indicators , and go
off.
• The indicator
flash.
and until
continues to
notification
The rinse aid helps to dry the dishes
without streaks and stains.
The rinse aid is automatically released
during the hot rinse phase.
When rinse aid chamber is empty, the
rinse aid indicator is turned on notifying
to refill rinse aid. If you are using multitabs containing rinse aid and you are
satisfied with the drying result, you can
deactivate the notification for refilling
rinse aid. However, we recommend that
you always use rinse aid for best drying
performance.
Water softener lev-
el
1)
5
2)
1
= level 5.
www.aeg.com10
If you use standard detergent or multitablets without rinse aid, activate the
notification to keep the rinse aid refill
indicator active.
How to deactivate the rinse aid empty notification
The appliance must be in programme
selection mode.
1. To enter the user mode, press and
hold simultaneously and until
the indicators , , and
start to flash and the display is blank.
2. Press
• The indicators , and go
• The indicator
• The display shows the current
3. Press to change the setting.
= the rinse aid empty notification is
deactivated.
4. Press the on/off button to confirm
the setting.
.
off.
continues to
flash.
setting:
= the rinse aid empty
notification is activated (factory
setting).
the indicators , , and
start to flash and the display is blank.
2. Press .
• The indicators , and go
off.
• The indicator
flash.
• The display shows the current
setting:
= Acoustic signal off.
–
– = Acoustic signal on.
3. Press to change the setting.
4. Press the on/off button to confirm
the setting.
continues to
6.5 AirDry
AirDry improves the drying results with
less energy consumption.
6.4 Acoustic signals
Acoustic signals sound when a
malfunction of the appliance occurs. It is
not possible to deactivate these acoustic
signals.
There is also an acoustic signal that
sounds when the programme is
completed. By default this acoustic
signal is deactivated but it is possible to
activate it.
How to activate the acoustic signal for the end of programme
The appliance must be in programme
selection mode.
1. To enter the user mode, press and
hold simultaneously and until
While the drying phase
operates, a device opens the
appliance door. The door is
then kept ajar.
CAUTION!
Do not try to close the
appliance door within 2
minutes after automatic
open. This can cause
damage to the appliance.
AirDry is automatically activated with all
programmes excluding and
(if applicable).
To improve the drying performance refer
to the XtraDry option or activate AirDry.
ENGLISH
11
CAUTION!
If children have access to the
appliance, it is advised to
deactivate AirDry as opening
the door may pose a danger.
How to deactivate AirDry
The appliance must be in programme
selection mode.
1. To enter the user mode, press and
hold simultaneously and until
the indicators , , and
start to flash and the display is blank.
7. OPTIONS
Desired options must be
activated every time before
you start a programme.
It is not possible to activate
or deactivate options while a
programme is running.
Not all options are
compatible with each other.
If you have selected non
compatible options, the
appliance will automatically
deactivate one or more of
them. Only the indicators of
the options still active will
stay on.
7.1 ExtraHygiene
With this option you have better hygiene
results. During the last rinsing phase, the
temperature stays at 70 °C for at least 10
minutes.
How to activate ExtraHygiene
2. Press .
• The indicators , and go
off.
• The indicator
flash.
• The display shows the current
setting: = AirDry activated.
3. Press to change the setting:
= AirDry deactivated.
4. Press the on/off button to confirm
the setting.
continues to
7.2 XtraDry
Activate this option when you want to
boost the drying performance. With the
use of this option, the duration of some
programmes, water consumption and
the last rinse temperature can be
affected.
The XtraDry option is a permanent
option for all programmes other than
and need not to be selected at
every cycle.
In other programmes the setting of
XtraDry is permanent and it is
automatically used in next cycles. This
configuration can be changed at any
time.
Activating XtraDry option deactivates
TimeSaver and vice versa.
How to activate XtraDry
Press . The related indicator comes
on.
Press , the related indicator comes on
If the option is not applicable to the
programme, the related indicator does
not come on or it flashes quickly for a
few seconds and then goes off.
The display shows the updated
programme duration.
7.3 TimeSaver
This option increases the pressure and
the temperature of the water. The
washing and the drying phases are
shorter.
The total programme duration decreases
by approximately 50%.
www.aeg.com12
The washing results are the same as with
the normal programme duration. The
drying results can decrease.
How to activate TimeSaver
Press , the related indicator comes on.
8. BEFORE FIRST USE
1. Make sure that the current level of
the water softener agrees with the
hardness of the water supply. If
not, adjust the level of the water
softener.
2. Fill the salt container.
3. Fill the rinse aid dispenser.
4. Open the water tap.
5. Start a programme to remove any
processing residuals that can still be
inside the appliance. Do not use
detergent and do not load the
baskets.
When you start a programme, the
appliance can take up to 5 minutes to
recharge the resin in the water softener.
It seems that the appliance is not
working. The washing phase starts only
after this procedure is completed. The
procedure will be repeated periodically.
8.1 The salt container
CAUTION!
Only use salt specifically
designed for dishwashers.
The salt is used to recharge the resin in
the water softener and to assure good
washing results in the daily use.
How to fill the salt container
1. Turn the cap of the salt container
counterclockwise and remove it.
2. Put 1 litre of water in the salt
container (Only for the first time).
3. Fill the salt container with dishwasher
salt.
If the option is not applicable to the
programme, the related indicator does
not come on or it flashes quickly for a
few seconds and then goes off.
The display shows the updated
programme duration.
4. Remove the salt around the opening
of the salt container.
5. Turn the cap of the salt container
clockwise to close the salt container.
CAUTION!
Water and salt can come out
of the salt container when
you fill it. After you fill the
salt container, immediately
start a programme to
prevent corrosion.
A
B
D
C
M
A
X
1
2
3
4
+
-
A
B
D
C
30
20
A BD
C
ENGLISH
13
8.2 How to fill the rinse aid dispenser
9. DAILY USE
CAUTION!
Only use rinse aid
specifically designed for
dishwashers.
1. Press the release button (D) to open
the lid (C).
2. Pour the rinse aid in the dispenser (A)
until the liquid reaches the fill level
'max'.
3. Remove the spilled rinse aid with an
absorbent cloth to prevent too much
foam.
4. Close the lid. Make sure that the
release button locks into position.
You can turn the selector of
the released quantity (B)
between position 1 (lowest
quantity) and position 4 or 6
(highest quantity).
1. Open the water tap.
2. Press the on/off button to activate
9.1 Using the detergent
the appliance.
Make sure that the appliance is in
programme selection mode.
• If the salt indicator is on, fill the
salt container.
• If the rinse aid indicator is on, fill
the rinse aid dispenser.
3. Load the baskets.
4. Add the detergent.
5. Set and start the correct programme
for the type of load and the degree
of soil.
20
30
B
A D
C
www.aeg.com14
1. Press the release button (B) to open
the lid (C).
2. Put the detergent, in powder or
tablets, in the compartment (A).
3. If the programme has a prewash
phase, put a small quantity of
detergent in the compartment (D).
4. Close the lid. Make sure that the
release button locks into position.
9.2 Setting and starting a
programme
The Auto Off function
This function decreases energy
consumption by deactivating
automatically the appliance when it is not
operating.
The function comes into operation:
• 5 minutes after the completion of the
programme.
• After 5 minutes if the programme has
not started.
Starting a programme
1. Keep the appliance door ajar.
2. Press the on/off button to activate
the appliance. Make sure that the
appliance is in programme selection
mode.
3. Press repeatedly
shows the number of the programme
you want to start. The display will
show the programme number for
approximately 3 seconds and then
show the programme duration.
4. Set the applicable options.
5. Close the appliance door to start the
programme.
until the display
Starting a programme with delay start
1. Set a programme.
2. Press again and again until the
display shows the delay time you
want to set (from 1 to 24 hours).
The delay indicator comes on.
3. Close the appliance door to start the
countdown.
While a countdown is running it is
possible to increase the delay time but
not to change the selection of the
programme and options.
When the countdown is completed, the
programme starts.
Opening the door while the appliance operates
If you open the door while a programme
is running, the appliance stops. It may
affect the energy consumption and the
programme duration. When you close
the door, the appliance continues from
the point of interruption.
If the door is opened for
more than 30 seconds
during the drying phase, the
running programme ends.
This does not happen if the
door is opened by AirDry
function.
Do not try to close the
appliance door within 2
minutes after AirDry
automatically opens it, as
this may cause damage to
the appliance.
If, afterwards, the door is
closed for another 3
minutes, the running
programme ends.
Cancelling the delay start while the countdown operates
When you cancel the delay start you
have to set the programme and options
again.
Press and hold RESET until the appliance
is in programme selection mode.
ENGLISH
15
Cancelling the programme
Press and hold RESET until the appliance
is in programme selection mode.
Make sure that there is detergent in the
detergent dispenser before you start a
new programme.
End of the programme
When the programme is completed the
display shows 0:00 and the end indicator
is on.
10. HINTS AND TIPS
10.1 General
The following hints will ensure optimal
cleaning and drying results in daily use
and also help to protect the
environment.
• Remove larger residues of food from
the dishes into the waste bin.
• Do not pre-rinse dishes by hand.
When needed, use the prewash
programme (if available) or select a
programme with a prewash phase.
• Always use the whole space of the
baskets.
• When loading the appliance, make
sure that the dishes can be
completely reached and washed by
the water released from the spray arm
nozzles. Make sure that items do not
touch or cover each other.
• You can use dishwasher detergent,
rinse aid and salt separately or you
can use the multi-tablets (e.g. ''3in1'',
''4in1'', ''All in 1''). Follow the
instructions written on the packaging.
• Select the programme according to
the type of load and degree of soil.
With the ECO programme you have
the most efficient use of water and
energy consumption for crockery and
cutlery with normal soil.
10.2 Using salt, rinse aid and
detergent
• Only use salt, rinse aid and detergent
for dishwasher. Other products can
cause damage to the appliance.
• In areas with hard and very hard water
we recommend to use plain
All buttons are inactive except for the
on/off button.
1. Press the on/off button or wait for
the Auto Off function to
automatically deactivate the
appliance.
If you open the door before the
activation of Auto Off, the appliance
is automatically deactivated.
2. Close the water tap.
dishwasher detergent (powder, gel,
tablets containing no additional
agents), rinse aid and salt separately
for optimal cleaning and drying
results.
• At least once a month run the
appliance with the use of appliance
cleaner which is particularly suitable
for this purpose.
• Detergent tablets do not fully dissolve
with short programmes. To prevent
detergent residues on the tableware,
we recommend that you use the
tablets with long programmes.
• Do not use more than the correct
quantity of detergent. Refer to the
instructions on the detergent
packaging.
10.3 What to do if you want to
stop using multi-tablets
Before you start to use separately
detergent, salt and rinse aid do the
following procedure.
1. Set the highest level of the water
softener.
2. Make sure that the salt and rinse aid
containers are full.
3. Start the shortest programme with a
rinsing phase. Do not add detergent
and do not load the baskets.
4. When the programme is completed,
adjust the water softener according
to the water hardness in your area.
5. Adjust the released quantity of rinse
aid.
6. Activate the rinse aid empty
notification.
C
B
A
www.aeg.com16
10.4 Loading the baskets
• Only use the appliance to wash items
that are dishwasher-safe.
• Do not put in the appliance items
made of wood, horn, aluminium,
pewter and copper.
• Do not put in the appliance items that
can absorb water (sponges,
household cloths).
• Remove remaining food from the
items.
• Make soft the remaining burned food
on the items.
• Put hollow items (cups, glasses and
pans) with the opening down.
• Make sure that cutlery and dishes do
not bond together. Mix spoons with
other cutlery.
• Make sure that glasses do not touch
other glasses.
• Put small items in the cutlery basket.
• Put light items in the upper basket.
Make sure that the items do not
move.
• Make sure that the spray arm can
move freely before you start a
programme.
10.5 Before starting a
programme
Make sure that:
• The filters are clean and correctly
installed.
• The cap of the salt container is tight.
• The spray arms are not clogged.
• There is dishwasher salt and rinse aid
(unless you use multi- tablets).
• The position of the items in the
baskets is correct.
• The programme is applicable for the
type of load and for the degree of
soil.
• The correct quantity of detergent is
used.
10.6 Unloading the baskets
1. Let the tableware cool down before
you remove it from the appliance.
Hot items can be easily damaged.
2. First remove items from the lower
basket, then from the upper basket.
At the end of the program
water can still remain on the
sides and on the door of the
appliance.
11. CARE AND CLEANING
WARNING!
Before maintenance,
deactivate the appliance and
disconnect the mains plug
from the main socket.
Dirty filters and clogged
spray arms decrease the
washing results. Make a
11.1 Cleaning the filters
The filter system is made of 3 parts.
check regularly and, if
necessary, clean them.
1. Turn the filter (B) counterclockwise
and remove it.
2. Remove the filter (C) out of filter (B).
3. Remove the flat filter (A).
4. Wash the filters.
ENGLISH
7. Reassemble the filters (B) and (C).
8. Put back the filter (B) in the flat filter
(A). Turn it clockwise until it locks.
CAUTION!
An incorrect position of the
filters can cause bad
washing results and damage
to the appliance.
17
5. Make sure that there are no residues
of food or soil in or around the edge
of the sump.
6. Put back in place the flat filter (A).
Make sure that it is correctly
positioned under the 2 guides.
11.2 Cleaning the spray arms
Do not remove the spray arms. If the
holes in the spray arms are clogged,
remove remaining parts of soil with a thin
pointed object.
11.3 External cleaning
• Clean the appliance with a moist soft
cloth.
• Only use neutral detergents.
• Do not use abrasive products,
abrasive cleaning pads or solvents.
11.4 Internal cleaning
• Carefully clean the appliance,
including the rubber gasket of the
door, with a soft damp cloth.
www.aeg.com18
• If you regularly use short duration
programmes, these can leave
deposits of grease and limescale
inside the appliance. To prevent this,
we recommend to run long duration
programmes at least 2 times per
month.
12. TROUBLESHOOTING
If the appliance does not start or it stops
during operation. Before you contact an
Authorised Service Centre, check if you
can solve the problem by yourself with
the help of the information in the table.
WARNING!
Repairs not properly done
may result in serious risk to
the safety of the user. Any
repairs must be performed
by qualified personnel.
Problem and alarm code Possible cause and solution
You cannot activate the appliance.
The program does not start. • Make sure that the appliance door is closed.
The appliance does not fill
with water.
The display shows .
The appliance does not
drain the water.
The display shows .
The anti-flood device is on.
The display shows .
• Make sure that the mains plug is connected to the
• Make sure that there is no damaged fuse in the fuse
• If the delay start is set, cancel the setting or wait for the
• The appliance has started the procedure to recharge
• Make sure that the water tap is open.
• Make sure that the pressure of the water supply is not
• Make sure that the water tap is not clogged.
• Make sure that the filter in the inlet hose is not clogged.
• Make sure that the inlet hose has no kinks or bends.
• Make sure that the sink spigot is not clogged.
• Make sure that the filter in the outlet hose is not clog-
• Make sure that the interior filter system is not clogged.
• Make sure that the drain hose has no kinks or bends.
• Close the water tap and contact an Authorised Service
• To maintain the performance of your
appliance at its best, we recommend
to use monthly a specific cleaning
product for dishwashers. Follow
carefully the instructions on the
packaging of the product.
With some problems, the display
shows an alarm code.
The majority of problems that can
occur can be solved without the need
to contact an Authorised Service
Centre.
mains socket.
box.
end of the countdown.
the resin inside the water softener. The duration of the
procedure is approximately 5 minutes.
too low. For this information, contact your local water
authority.
ged.
Centre.
ENGLISH
Problem and alarm code Possible cause and solution
The appliance stops and
starts more times during operation.
The program lasts too long. • Select the TimeSaver option to shorten the program
The remaining time in the
display increases and skips
nearly to the end of program
time.
Small leak from the appliance door.
The appliance door is difficult to close.
Rattling/knocking sounds
from inside the appliance.
The appliance trips the circuit-beaker.
• It is normal. It provides optimal cleaning results and energy savings.
time.
• If the delayed start option is set, cancel the delay setting
or wait for the end of the countdown.
• This is not a defect. The appliance is working correctly.
• The appliance is not levelled. Loosen or tighten the adjustable feet (if applicable).
• The appliance door is not centred on the tub. Adjust the
rear foot (if applicable).
• The appliance is not levelled. Loosen or tighten the adjustable feet (if applicable).
• Parts of the tableware are protruding from the baskets.
• The tableware is not properly arranged in the baskets.
Refer to basket loading leaflet.
• Make sure that the spray arms can rotate freely.
• The amperage is insufficient to supply simultaneously all
the appliances in use. Check the socket amperage and
the capacity of the meter or turn off one of the appliances in use.
• Internal electrical fault of the appliance. Contact an Authorised Service Centre.
19
Refer to "Before first use",
"Daily use", or "Hints and
tips" for other possible
causes.
the problem occurs again, contact an
Authorised Service Centre.
For alarm codes not described in the
table, contact an Authorised Service
Centre.
Once you have checked the appliance,
deactivate and activate the appliance. If
12.1 The washing and drying results are not satisfactory
Problem Possible cause and solution
Poor washing results. • Refer to "Daily use", "Hints and tips" and basket
loading leaflet.
• Use more intensive washing programmes.
• Clean spray arm jets and filter. Refer to "Care and
Cleaning".
www.aeg.com20
Problem Possible cause and solution
Poor drying results. • Tableware has been left for too long inside a closed
appliance.
• There is no rinse aid or the dosage of rinse aid is not
enough. Set the rinse aid dispenser to a higher level.
• Plastic items may need to be towel dried.
• For the best drying performance activate the option
XtraDry and set AirDry.
• We recommend to always use rinse aid, even in combination with multi-tablets.
There are whitish streaks or
bluish layers on glasses and
dishes.
There are stains and dry water
drops on glasses and dishes.
• The release quantity of rinse aid is too much. Adjust
the rinse aid level to a lower level.
• The quantity of detergent is too much.
• The released quantity of rinse aid is not sufficient. Adjust the rinse aid level to a higher level.
• The quality of the rinse aid can be the cause.
The dishes are wet. • For the best drying performance activate the option
XtraDry and set AirDry .
• The programme does not have a drying phase or has
a drying phase with low temperature.
• The rinse aid dispenser is empty.
• The quality of the rinse aid can be the cause.
• The quality of the multi-tablets can be the cause. Try a
different brand or activate the rinse aid dispenser and
use rinse aid and multi-tablets together.
The interior of the appliance is
wet.
• This is not a defect of the appliance. it is caused by
the humidity in the air that condenses on the walls.
Unusual foam during washing. • Use the detergent for dishwashers only.
• There is a leak in the rinse aid dispenser. Contact an
Authorised Service Centre.
Traces of rust on cutlery. • There is too much salt in the water used for washing.
Refer to "The water softener".
• Silver and stainless steel cutlery were placed together.
Avoid to put silver and stainless steel items close together.
There are residues of detergent in the dispenser at the
end of the programme.
• The detergent tablet got stuck in the dispenser and
therefore was not completely washed away by water.
• Water cannot wash away the detergent from the dispenser. Make sure that the spray arm is not blocked or
clogged.
• Make sure that items in the baskets do not impede the
lid of the detergent dispenser from opening.
Odours inside the appliance. • Refer to "Internal cleaning".
Problem Possible cause and solution
Limescale deposits on the tableware, on the tub and on
the inside of the door.
Dull, discoloured or chipped
tableware.
• The level of salt is low, check the refill indicator.
• The cap of the salt container is loose.
• Your tap water is hard. Refer to "The water softener".
• Even using multi-functional tabs use salt and set re-
generation of the water softener. Refer to "The water
softener".
• If lime scale deposits still remain, clean the appliance
with appliance cleaners which are particularly suitable
for this purpose.
• Try different detergent.
• Contact the detergent manufacturer.
• Make sure that only dishwasher-safe items are washed
in the appliance.
• Load and unload the basket carefully. Refer to basket
loading leaflet.
• Place delicate items in the upper basket.
Refer to "Before first use",
"Daily use" or "Hints and
tips" for other possible
causes.
13. TECHNICAL INFORMATION
ENGLISH
21
Dimensions Width / height / depth (mm) 446 / 818 - 898 / 550
Electrical connection
Water supply pressure Min. / max. bar (MPa) 0.5 (0.05) / 8 (0.8)
Water supply
Capacity Place settings 9
Power consumption Left-on mode (W) 5.0
Power consumption Off-mode (W) 0.10
1)
Refer to the rating plate for other values.
2)
If the hot water comes from alternative source of energy, (e.g. solar panels, aeolian energy), use the
hot water supply to decrease energy consumption.
1)
Voltage (V) 200 - 240
Frequency (Hz) 50 / 60
Cold water or hot water
14. ENVIRONMENTAL CONCERNS
Recycle the materials with the symbol .
Put the packaging in applicable
containers to recycle it. Help protect the
environment and human health and to
recycle waste of electrical and electronic
appliances. Do not dispose appliances
marked with the symbol with the
household waste. Return the product to
2)
max 60 °C
Loading...
