ÖKO_FAVORIT 6281 i
Dishwasher
User Instructions
Dear customer,
Pri
Please read these user instructions carefully.
Above all please observe the safety instructions on the first few pages
ofthese user instructions! Please keep these user instructions for later
reference. Pass them on to any subsequent owner of the appliance.
The warning triangle and/or specific words (Warning!, Caution!,
1
Important!) are used to highlight instructions that are important for
your safety or for the function of the appliance. It is imperative that
these instructions are observed.
0 This symbol or numbered instruction steps lead you step for step
through the operation of the appliance.
Next to this symbol you receive additional information and practical
3
tips on using the appliance.
Tips and instructions for the economical and environmentally conscious
2
use of the appliance are marked with a clover leaf.
In the event of a malfunction, these operating instructions contain
information on how to rectify faults yourself, see the "What to do, if..."
section.
If these instructions are insufficient, please contact your nearest customer service centre.
In the case of technical problems, our customer service organisation is
available to provide you with assistance at any time (you will find
addresses and telephone numbers in the "Customer Service Centres"
section).
In this respect please read the "Service" note on the rear of these user
instructions.
2
Your dishwasher is fitted with the new "PULSE WASH" wash system.
3
With this wash system, the motor speed and spray pressure are
varied during the wash programme to improve the cleaning of the
dishes. It is for this reason that the noise level changes during the
wash programme.
nted on paper manufactured with environmentally sound processes.
He who thinks ecologically acts accordingly ...
Contents
CONTENTS
Operating instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Economical and Ecological Dishwashing . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Appliance Features and Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Prior to using for the first time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Adjust the water softener . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Filling with Special Salt for the Water Softener . . . . . . . . . . . . . . . . . . . . . 12
Filling with Rinse Aid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Adjusting Rinse Aid Dosing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
In Daily Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Loading cutlery and dishes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Loading Cutlery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Loading Pans, Frying Pans and Large Plates . . . . . . . . . . . . . . . . . . . . . . 17
Loading Cups, Glasses and Coffee Services . . . . . . . . . . . . . . . . . . . . . . . 18
Adjusting the Height of the Upper Rack . . . . . . . . . . . . . . . . . . . . . . . . . 19
Filling with Detergent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Bio Wash Programmes and Concentrated Detergents . . . . . . . . . . . . . . 21
Selecting the Wash Programme (Programme Table) . . . . . . . . . . . . . . . . . . 22
Start the wash programme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Changing/Interrupting/Cancelling the Wash Programme . . . . . . . . . . . 23
Setting or Changing the Start Delay Timer . . . . . . . . . . . . . . . . . . . . . . . 24
Load Sensing – Sensor Logic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Switching Off the Dishwasher . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Emptying the Dishwasher . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Care and Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Cleaning the Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
What to do, when ... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
...Error Messages Are Displayed. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
...Problems Occur During Use of the Dishwasher. . . . . . . . . . . . . . . . . . . . . 29
...The Wash Results Are Not Satisfactory. . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Notes for Test Institutes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
3
Contents
Installation and Connection Instructions . . . . . . . . . . . . . . . . 32
Installing the Dishwasher . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Dishwashers That Can Be Integrated . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Built-In Dishwasher . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Free-Standing Appliances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Connecting the Dishwasher . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Water connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Permitted water pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Connect the inlet hose . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Water drain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Leak Prevention System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Electrical connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Service Departments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Guarantee Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
4
Operating instructions
OPERATING INSTRUCTIONS
1 Safety instructions
The safety features of AEG electrical appliances comply with accepted
technical standards and the German Appliance Safety Law. Nevertheless, as a manufacturer we consider it our obligation to make you
aware of the following safety information:
Installation, connection and initial use
• The dishwasher may only be transported upright.
• Check the dishwasher for transport damage. Under no circumstance
should a damaged appliance be connected up. In the event of damage, please contact your vendor.
• Before starting your appliance please ensure that the nominal voltage and type of current specified on the rating plate are the same as
those used at the place of installation. Please also refer to the type
plate for the type of fuse to be used.
• You will find details on how to correctly install and connect up your
dishwasher in the "Installation" section. Multi-way plugs / connectors
and extension cables must not be used. This could constitute a safety
hazard.
Child Safety
• Often children do not recognise the hazards present in the use of
household appliances. Please therefore ensure that children are adequately supervised and do not let children play with the dishwasher –
there is a danger that children may shut themselves in the appliance
(risk of asphyxiation!).
• Packaging materials (e.g. sheet and Styrofoam) can be dangerous for
children. Danger of asphyxiation! Keep packaging materials at a safe
distance from children.
• Detergents can cause burns to eyes, mouth and throat or even cause
asphyxiation! Please observe the detergent manufacturers safety
instructions.
• The water in the dishwasher is not drinking water. If there are still
remnants of detergent in the appliance, there is risk of burns!
• When disposing of the dishwasher: Pull out the mains plug, cut off
the mains cable and dispose of it. Break the door lock so that the do
no longer shuts.
5
Operating instructions
General safety
• Repairs to the dishwasher may only be performed by qualified service
engineers. Improper repairs can give rise to significant hazards for
the user. If your appliance needs repairing, please contact customer
service or your dealer.
• Never use the dishwasher if the mains cable, inlet / drain hose are
damaged or the control panel, work surface or plinth area are damaged such that internal components of the appliance are openly
accessible.
• If the mains cable for the appliance is damaged, it must be replaced
with special cable (obtainable from AEG customer service) by an AEG
authorised customer service centre.
• Never unplug the appliance by pulling on the cable, always pull on
the plug.
• Additions or modifications to the dishwasher are not permitted for
safety reasons.
• Ensure that the door of the dishwasher is always closed, except during loading and emptying. By this means you will avoid anyone tripping over the open door and injuring themselves.
• Sharp knives and other item of cutlery with sharp edges must be laid
in the upper rack or placed in the cutlery rack with the point facing
downwards.
Intended use
• Only wash household dishes with the dishwasher. If the appliance is
used for purposes other than those intended or used incorrectly, no
liability will be accepted by the manufacturer for any damage that
may be caused.
• Prior to use ensure that the manufacturer’s of the special salt, detergent and rinse aid employed specifically permit the usage of their
products in household dishwashers.
• Do not put solvents in the dishwasher. There is a risk of an explosion!
6
Operating instructions
• The leak prevention system provides reliable protection from damage
due to water leaks. For this system to function the following prerequisites must be met:
– The appliance must remain connected to the mains even when it is
switched off.
– The dishwasher must be correctly installed.
– Always shut off the water supply at the tap when the dishwasher is
not to be used for longer periods, e.g. when you are away on holiday.
• Do not sit or stand on the open door, the appliance may tip over.
• In the event of a fault, shut off the water supply at the tap, then
switch off the appliance and unplug. In the case of a permanent connection: pull or unscrew the fuse(s).
2 Disposal
Disposing of the Packaging Material
Dispose of the dishwasher packaging material correctly. All the packaging materials used are harmless to the environment and can be recycled.
• Plastic parts are marked with standard international abbreviations:
– >PE< for polyethylene, e.g. sheet wrapping material
– >PS< for polystyrene, e.g. padding material (always CFC-free)
– >POM< for polyoxymethylene, e.g. plastic clips
• Cardboard packaging is manufactured from recycled paper and
should be deposited in the waste paper collection for recycling.
Disposal of old appliances
As and when you cease to use your dishwasher, please take it to a recycling centre or to your dealer who will, for a small contribution to the
costs, dispose of it for you.
7
Operating instructions
2 Economical and Ecological Dishwashing
• Only connect the dishwasher to the hot water supply if your hot
water is not electrically heated.
• Ensure that the water softener is correctly adjusted.
• Do not pre-rinse dishes under running water.
• When you wash a small load, the load sensor calculates the amount
of water necessary and shortens the programme. It is more economical to always wash with a full load.
• Select the wash programme to suit the nature and degree of the soiling on the dishes.
• Do not use more detergent, special salt or rinse aid than is recommended in these operating instructions and by the manufacturer of
the respective product.
8
Operating instructions
Appliance Features and Control Panel
Top Spray
Nozzle
Rubber Seal for
Connecting the
Water Feed to
the Upper Spray
Arm
Spray Arms
Container for
Special Salt
Container
for Rinse Aid
Detergent
Dispenser
Suction Opening for Fan
Assisted Drying
Rating
plate
Filters
9
Operating instructions
Control panel
Water Softener Button
Door Handle
Set
Start Delay
Indicators
Control Field
Air Outlet for Fan
Assisted Drying
Multi-Display
The Control Field comprises the ON/OFF switch M and the programme buttons with LED indicators.
Water Softener Button: In addition to setting the wash programme
indicated on the control field, this button can be used in combination
with the ON/OFF switch
M to adjust the water softener.
The Multi-Display can display,
– the hardness setting to which the water softener is set.
– the start delay that is set.
– how long the current wash programme can be expected to last.
– which fault has occurred on the dishwasher.
The Indicators have the following meanings :
J
K
^
\
Refill with special salt
Refill with rinse aid
Open the tap
Clean the
dishwasher’s filter system
Prior to using for the first time
Prior to using for the first time, remove all the clips with which the dish
racks are secured for transport.
Then perform the following steps:
0 1. Adjust the water softener
2. Filling with Special Salt for the Water Softener
3. Filling with Rinse Aid
10
Operating instructions
Adjust the water softener
To avoid the scale deposits on the dishes and in the dishwasher, the
dishes must be washed with soft, i.e. low lime content, water. The dishwasher therefore has a built-in water softener, in which tap water from
a hardness of 4 °d (German degree) is softened with the aid of special
salt.
You water supplier will be able to inform you on the hardness and
3
hardness range of the water in your area.
0 Adjust the water softener to the setting given in the table that corre-
sponds to the hardness of the water in your area. The water softener
can be adjusted in 10 steps.
Water Hardness
1
in °d
) in mmol/l 2)Range
41-50
35-40
31-34
27-30
23-26
19-22
15-18
11-14 1.9-2.5 II 2 H 2
4-10 0.7-1.8 I/II 1 H 1
under 4 under 0.7 I
1)(°d) German degree, measure of the hardness of water
2)(mmol/l) millimol per litre, international unit for the hardness of water
*factory setting
7.3-9.0
6.3-7.2
5.5-6.2
4.8-5.4
4.1-4.7
3.3-4.0
2.6-3.2
IV
III
Adjust
to Hardness Setting
9
8
7
6
5
4
3*
0
no salt necessary
Indication on the
Multi-Display
H 9
H 8
H 7
H 6
H 5
H 4
H 3
H 0
0 1. Hold the water softener button pressed and press the ON/OFF switch
M.
The multi-display indicates the hardness setting.
2. Pressing the water softener button increases the hardness setting by 1.
(Exception: hardness setting 0 follows hardness setting 9).
3. When the hardness setting is correct, press the ON/OFF switch
The hardness setting is then saved.
M.
11
Operating instructions
Filling with Special Salt for the Water Softener
Use only special salt for dishwashers. Never fill the salt container with
1
any another type of salt (e.g. culinary salt) or dishwasher detergent.
This would irreparably damage the water softener.
Prior to filling with salt, please check each time that you really do have
a packet of special salt in your hand.
Fill with special salt:
– Prior to using the dishwasher for the first time
– When the SALT indicator
If the water hardness in your area is less than 4 °d, you do not need to
3
use special salt.
0 1. Open the door, remove the lower
rack.
2. Undo the lid on the salt container by
turning it anticlockwise.
3. Only when using for the first time:
fill the salt container with water.
4. Place the funnel supplied on the container opening.
Fill the container with special salt
through the funnel; the capacity of
the container is approx. 1.0-1.5 kg
depending on the grain size. Do not
overfill the salt container with special salt.
J on the control panel is illuminated.
SALE
SALT
SALZ
SEL
The water expelled by filling the salt container with special salt runs
3
out of the salt container onto the base of the washing compartment.
This is not a cause for concern, the water will be pumped out at the
start of the next wash programme.
5. Clean any salt remnants on the container opening.
6. Turn the lid clockwise to the stop, otherwise special salt will leak into
the wash water. Dull glasses may result.
7. If you are not going to wash your dishes immediately, you should run
12
the Pre Wash programme
run out of the container and any grains of salt that have been spilt.
Depending on the size of the salt grains, it can take several hours for
3
the salt to dissolve in the water and the special salt indicator
extinguish. The setting of the water softener and thus the consumption
of salt are dependent on the hardness of the local water.
A. This will wash away salt water that has
J to
Operating instructions
Filling with Rinse Aid
Rinse aid ensures that your dishes gleam and are free from spots, and
that you glasses are clear.
Use only branded rinse aid for dishwashers. Never fill the rinse aid con-
1
tainer with any another substance (e.g. concentrated vinegar). This
would damage the appliance.
Fill with rinse aid:
– Prior to using the dishwasher for the first time
– When the RINSE AID indicator
The rinse aid container is on the inside of the dishwasher door.
0 1. Open the door
2. Turn the lid of the container
¼ of a turn anticlockwise and
remove.
H on the control panel is illuminated.
3. Fill with rinse aid, up to the broken
line as a maximum; this line corresponds to a quantity of approx.
150 ml
4. Replace the lid and tighten by turning clockwise.
5. If rinse aid has been spilt, wipe up
with a cloth. Otherwise there will be
too much foam during washing.
6
5
x
4
a
m
3
2
1
13
Operating instructions
Adjusting Rinse Aid Dosing
Rinse aid is added to the wash water from the container when the
3
dishes are rinsed. The dose can be adjusted from 1-6, corresponding to
1-6 cm
dose when streaks, milky spots or dried water drops are to be seen on
glasses and dishes.
(see under "What to do, if...").
0 1. Turn the lid of the container
¼ of a turn anticlockwise and
remove.
2. Adjust the dose setting with a tea
spoon.
3. Replace the lid and tighten by turning clockwise.
4. If rinse aid has run out, wipe up with
a cloth.
3
rinse aid. The dose is set to "4" in the factory. Only change the
In Daily Use
• Is it necessary to refill with special salt or rinse aid?
• Load cutlery and dishes into the dishwasher
• Fill with dishwasher detergent
• Select a wash programme suitable for the cutlery and dishes
• Start the wash programme
14
Loading...
