USER MANUAL
CCB6740ACB CCB6740ACM
EN User Manual
Cooker
www.aeg.com
2

CONTENTS

FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler - features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.aeg.com/webselfservice
Register your product for better service:
www.registeraeg.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.aeg.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts. When contacting our Authorised Service Centre, ensure that you have the following data available: Model, PNC, Serial Number. The information can be found on the rating plate.
Warning / Caution-Safety information General information and tips Environmental information
Subject to change without notice.

SAFETY INFORMATION

1.
Before the installation and use of the appliance, carefully read the supplied instructions. The
ENGLISH
manufacturer is not responsible for any injuries or damages that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference.

1.1 Children and vulnerable people safety

WARNING!
Risk of suffocation, injury or permanent disability.
• This appliance can be used by children aged from 8
years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved.
• Children between 3 and 8 years of age and persons
with very extensive and complex disabilities shall be kept away unless continuously supervised.
• Children of less than 3 years of age should be kept
away unless continuously supervised.
• Do not let children play with the appliance.
• Keep all packaging away from children and dispose of
it appropriately.
• Keep children and pets away from the appliance when
it operates or when it cools down. Accessible parts are hot.
• Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
3

General Safety

1.2
• Only a qualified person must install this appliance and
replace the cable.
• This appliance must be connected to the mains with a
H05VV-F type cable to withstand the temperature of the rear panel.
• This appliance is intended for use up to an altitude of
2000 m above sea level.
4
www.aeg.com
• This appliance is not intended to be used on a ships,
boats or vessels.
• Do not install the appliance behind a decorative door
in order to avoid overheating.
• Do not install the appliance on a platform.
• Do not operate the appliance by means of an external
timer or separate remote-control system.
• WARNING: Unattended cooking on a hob with fat or
oil can be dangerous and may result in fire.
• NEVER try to extinguish a fire with water, but switch
off the appliance and then cover flame e.g. with a lid
or a fire blanket.
• CAUTION: The cooking process has to be supervised.
A short term cooking process has to be supervised
continuously.
• WARNING: Danger of fire: Do not store items on the
cooking surfaces.
• Do not use a steam cleaner to clean the appliance.
• Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the glass door or the glass of hinged
lids of the hob since they can scratch the surface,
which may result in shattering of the glass.
• Metallic objects such as knives, forks, spoons and lids
should not be placed on the hob surface since they
can get hot.
• If the glass ceramic surface / glass surface is cracked,
switch off the appliance and unplug it from the mains.
In case the appliance is connected to the mains
directly using junction box, remove the fuse to
disconnect the appliance from power supply. In either
case contact the Authorised Service Centre.
• WARNING: The appliance and its accessible parts
become hot during use. Care should be taken to
avoid touching heating elements.
• Always use oven gloves to remove or put in
accessories or ovenware.
• Before maintenance cut the power supply.
ENGLISH
• Ensure that the appliance is switched off before
replacing the lamp to avoid the possibility of electric shock.
• If the mains power supply cable is damaged, it must
be replaced by the manufacturer, its Authorised Service Centre or similarly qualified persons to avoid an electrical hazard.
• To remove the shelf supports first pull the front of the
shelf support and then the rear end away from the side walls. Install the shelf supports in the opposite sequence.
• The means for disconnection must be incorporated in
the fixed wiring in accordance with the wiring rules.
• WARNING: Use only hob guards designed by the
manufacturer of the cooking appliance or indicated by the manufacturer of the appliance in the instructions for use as suitable or hob guards incorporated in the appliance. The use of inappropriate guards can cause accidents.
5

2. SAFETY INSTRUCTIONS

2.1 Installation

WARNING!
Only a qualified person must install this appliance.
• Remove all the packaging.
• Do not install or use a damaged appliance.
• Follow the installation instructions supplied with the appliance.
• Always take care when moving the appliance as it is heavy. Always use safety gloves and enclosed footwear.
• Do not pull the appliance by the handle.
• The kitchen cabinet and the recess must have suitable dimensions.
• Keep the minimum distance from other appliances and units.
• Install the appliance in a safe and suitable place that meets installation requirements.
• Parts of the appliance carry current. Close the appliance with furniture to
prevent touching the dangerous parts.
• The sides of the appliance must stay adjacent to appliances or units with the same height.
• Do not install the appliance adjacent to a door or under a window. This prevents hot cookware to fall from the appliance when the door or the window is opened.
• Make sure to install a stabilizing means in order to prevent tipping of the appliance. Refer to Installation chapter.

2.2 Electrical Connection

WARNING!
Risk of fire and electric shock.
• All electrical connections should be made by a qualified electrician.
• The appliance must be earthed.
6
www.aeg.com
• Make sure that the parameters on the rating plate are compatible with the electrical ratings of the mains power supply.
• Always use a correctly installed shockproof socket.
• Do not use multi-plug adapters and extension cables.
• Do not let mains cables touch or come near the appliance door, especially when the door is hot.
• The shock protection of live and insulated parts must be fastened in such a way that it cannot be removed without tools.
• Connect the mains plug to the mains socket only at the end of the installation. Make sure that there is access to the mains plug after the installation.
• If the mains socket is loose, do not connect the mains plug.
• Do not pull the mains cable to disconnect the appliance. Always pull the mains plug.
• Use only correct isolation devices: line protecting cut-outs, fuses (screw type fuses removed from the holder), earth leakage trips and contactors.
• The electrical installation must have an isolation device which lets you disconnect the appliance from the mains at all poles. The isolation device must have a contact opening width of minimum 3 mm.
• Fully close the appliance door, before you connect the mains plug to the mains socket.

2.3 Use

WARNING!
Risk of injury and burns. Risk of electrical shock.
• This appliance is for household use only.
• Do not change the specification of this appliance.
• Make sure that the ventilation openings are not blocked.
• Do not let the appliance stay unattended during operation.
• Deactivate the appliance after each use.
• Be careful when you open the appliance door while the appliance is in operation. Hot air can release.
• Do not operate the appliance with wet hands or when it has contact with water.
• Do not use the appliance as a work surface or as a storage surface.
WARNING!
Risk of fire and explosion
• Fats and oil when heated can release flammable vapours. Keep flames or heated objects away from fats and oils when you cook with them.
• The vapours that very hot oil releases can cause spontaneous combustion.
• Used oil, that can contain food remnants, can cause fire at a lower temperature than oil used for the first time.
• Do not put flammable products or items that are wet with flammable products in, near or on the appliance.
• Do not let sparks or open flames to come in contact with the appliance when you open the door.
• Open the appliance door carefully. The use of ingredients with alcohol can cause a mixture of alcohol and air.
WARNING!
Risk of damage to the appliance.
• To prevent damage or discoloration to the enamel:
– do not put ovenware or other
objects in the appliance directly on the bottom.
– do not put water directly into the
hot appliance.
– do not keep moist dishes and
food in the appliance after you finish the cooking.
– be careful when you remove or
install the accessories.
• Discoloration of the enamel or stainless steel has no effect on the performance of the appliance.
• Use a deep pan for moist cakes. Fruit juices cause stains that can be permanent.
• Do not keep hot cookware on the control panel.
• Do not let cookware boil dry.
ENGLISH 7
• Be careful not to let objects or cookware fall on the appliance. The surface can be damaged.
• Do not activate the cooking zones with empty cookware or without cookware.
• Do not put aluminium foil on the appliance or directly on the bottom of the appliance.
• Cookware made of cast iron, aluminium or with a damaged bottom can cause scratches. Always lift these objects up when you have to move them on the cooking surface.
• This appliance is for cooking purposes only. It must not be used for other purposes, for example room heating.

2.4 Care and Cleaning

WARNING!
Risk of injury, fire, or damage to the appliance.
• Before maintenance, deactivate the appliance. Disconnect the mains plug from the mains socket.
• Make sure the appliance is cold. There is the risk that the glass panels can break.
• Replace immediately the door glass panels when they are damaged. Contact the Authorised Service Centre.
• Be careful when you remove the door from the appliance. The door is heavy!
• Fat and food remaining in the appliance can cause fire.
• Clean regularly the appliance to prevent the deterioration of the surface material.
• Make sure the cavity and the door are wiped dry after each use. Steam produced during the operation of the appliance condensates on cavity walls
and can cause corrosion. To decrease the condensation operate the appliance for 10 minutes before cooking.
• Clean the appliance with a moist soft cloth. Only use neutral detergents. Do not use any abrasive products, abrasive cleaning pads, solvents or metal objects.
• If you use an oven spray, obey the safety instructions on the packaging.
• Do not clean the catalytic enamel (if applicable) with any kind of detergent.

2.5 Internal lighting

WARNING!
Risk of electric shock.
• The type of light bulb or halogen lamp used for this appliance is for household appliances only. Do not use it for house lighting.
• Before replacing the lamp, disconnect the appliance from the power supply.
• Only use lamps with the same specifications.

2.6 Service

• To repair the appliance contact an Authorised Service Centre.
• Use original spare parts only.

2.7 Disposal

WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the mains supply.
• Cut off the mains electrical cable close to the appliance and dispose of it.
• Remove the door catch to prevent children or pets from becoming trapped in the appliance.
3.

INSTALLATION

WARNING!
Refer to Safety chapters.
A
8
www.aeg.com

3.1 Technical data

Dimensions
Height 894 - 912 mm
Width 600 mm
Depth 600 mm

3.2 Location of the appliance

You can install your freestanding appliance with cabinets on one or two sides and in the corner.
Minimum distances
Dimension mm
A 685

3.4 Electrical installation

WARNING!
The manufacturer is not responsible if you do not follow the safety precautions from Safety chapters.
This appliance is supplied without a main plug or a main cable.
Applicable types of cables for different phases:
Phase Min. size cable
1 3x6.0 mm²
3 with neutral 5x1.5 mm²
WARNING!
The power cable must not touch the part of the appliance shaded in the illustration.

3.3 Levelling of the appliance

Use small feet on the bottom of appliance to set the appliance top surface level with other surfaces.

3.5 Covering terminal board

• The recommended cross-section area is six square millimetres (6 mm²).
• When you refit the mains terminal cover, make sure that the lower tabs are located inside the bottom edge of the aperture, before you fix the two screws into the top edge of the mains terminal cover.
N N N
LL
1 2 3
3
4
5
5
6
5
4
3
2
1
8
3
2
1
4
7
180 mm
145 mm210 mm
140 mm
145 mm
1
3
456
2
ENGLISH 9
• Make sure that the cover is securely fastened.
To open the cover of terminal board obey the procedure in opposite sequence.

3.6 Terminal board

Do not remove blanking plates.

4. PRODUCT DESCRIPTION

4.1 General overview

Make sure that the links are fitted as shown.
Control panel and hob
1
Air vents for the cooling fan
2
Heating element
3
Lamp
4
Shelf support, removable
5
Fan
6
Cavity embossment
7
Shelf positions
8

4.2 Cooking surface layout

Cooking zone 1200 W
1
Steam outlet - number and position
2
depends on the model Cooking zone 1800 W
3
Cooking zone 1200 W
4
Residual heat indicator
5
Cooking zone 1000 / 2200 W
6
67
1 2 543 1
10
www.aeg.com

4.3 Cooker control panel

Knobs for the hob
1
Knob for the top oven functions
2
Display
3
Knob for the main oven functions
4
Knob for the main oven temperature
5
Temperature indicator / symbol for
6
the main oven Temperature indicator / symbol for
7
the top oven

4.4 Accessories

• Wire shelf
For cookware, cake tins, roasts.
• Grill- / Roasting pan
To bake and roast or as pan to collect fat.

5. BEFORE FIRST USE

WARNING!
Refer to Safety chapters.

5.1 Initial Cleaning

Remove all accessories and removable shelf supports from the oven.
Refer to "Care and cleaning" chapter.
Clean the oven and the accessories before first use. Put the accessories and the removable shelf supports back to their initial position.

5.2 Setting the time

You must set the time before you operate the oven.
Only the top oven works without the set time.
The flashes when you connect the appliance to the electrical supply, when there was a power cut or when the timer is not set.
• Trivet
For roasting and grilling.
Use the trivet only with the Grill- / roasting pan.
Press the or to set the correct time. After approximately five seconds, the flashing stops and the display shows the time of day you set.

5.3 Changing the time

You cannot change the time of day if the Duration or End function operates.
Press again and again until the indicator for the Time of Day function flashes. To set a new time, refer to "Setting the time".

5.4 Preheating

Preheat the empty oven before first use.
Preheat the two ovens. Heat up one oven at a time. Set the functions listed below, if applicable.
1. Set the function and the
maximum temperature.
ENGLISH 11
2. Let the oven operate for 1 hour.
3. Set the function and set the
maximum temperature.
4. Let the oven operate for 15 minutes.
5. Turn off the oven and let it cool
down.

6. HOB - DAILY USE

WARNING!
Refer to Safety chapters.

6.1 Heat setting

Symbols Function
Off position
Double zone
1 - 9 Heat settings
Use the residual heat to decrease energy consumption. Deactivate the cooking zone approximately 5 - 10 minutes before the cooking process is completed.
Turn the knob for the selected cooking zone to a necessary heat setting. To complete the cooking process, turn the knob to the off position.
Accessories can become hotter than usual. The oven can emit an odour and smoke. Make sure that the airflow in the room is sufficient.

6.2 Activating and deactivating the outer rings

You can adjust the surface you cook to the dimension of the cookware.
To activate the outer ring: turn the knob clockwise through a light resistance
to
. Then turn the knob counterclockwise to the correct heat setting.
To deactivate the outer ring: turn the knob to the off position. The indicator goes out.

6.3 Residual heat indicator

WARNING!
There is a risk of burns from residual heat.
The indicator comes on when a cooking zone is hot, but it does not function if mains power is disconnected.

7. HOB - HINTS AND TIPS

WARNING!
Refer to Safety chapters.

7.1 Cookware

The bottom of the cookware must be as thick and flat as possible. Ensure pan bases are clean and dry before placing on the hob surface.
Cookware made of enamelled steel and with aluminium or copper bottoms can cause a colour change on the glass-ceramic surface.

7.2 Examples of cooking applications

The data in the table is for guidance only.
12
www.aeg.com
Heat setting Use to: Time
(min)
1 Keep cooked food warm. as nec-
essary
1 - 2 Hollandaise sauce, melt: but-
ter, chocolate, gelatine.
1 - 2 Solidify: fluffy omelettes,
baked eggs.
2 - 3 Simmer rice and milkbased
dishes, heat up ready-cooked meals.
3 - 4 Steam vegetables, fish, meat. 20 - 45 Add a couple of tablespoons
4 - 5 Steam potatoes. 20 - 60 Use max. ¼ l of water for 750 g
4 - 5 Cook larger quantities of food,
stews and soups.
6 - 7 Gentle fry: escalope, veal cor-
don bleu, cutlets, rissoles, sausages, liver, roux, eggs, pancakes, doughnuts.
7 - 8 Heavy fry, hash browns, loin
steaks, steaks.
9 Boil water, cook pasta, sear meat (goulash, pot roast), deep-fry chips.
5 - 25 Mix from time to time.
10 - 40 Cook with a lid on.
25 - 50 Add at least twice as much liq-
60 - 150 Up to 3 l of liquid plus ingredi-
as nec­essary
5 - 15 Turn halfway through.
Hints
Put a lid on the cookware.
uid as rice, mix milk dishes halfway through the proce­dure.
of liquid.
of potatoes.
ents.
Turn halfway through.

8. HOB - CARE AND CLEANING

WARNING!
Refer to Safety chapters.

8.1 General information

• Clean the hob after each use.
• Always use cookware with a clean base.
• Scratches or dark stains on the surface have no effect on how the hob operates.
• Use a special cleaner suitable for the surface of the hob.
• Use a special scraper for the glass.

8.2 Cleaning the hob

• Remove immediately: melted plastic,
plastic foil, sugar and food with sugar, otherwise, the dirt can cause damage to the hob. Take care to avoid burns. Use a special hob scraper on the glass surface at an acute angle and move the blade on the surface.
• Remove when the hob is sufficiently cool: limescale rings, water rings, fat stains, shiny metallic discoloration. Clean the hob with a moist cloth and a non-abrasive detergent. After cleaning, wipe the hob dry with a soft cloth.
• Remove shiny metallic discoloration: use a solution of water
with vinegar and clean the glass surface with a cloth.

9. OVEN - DAILY USE

WARNING!
Refer to Safety chapters.

9.1 Top oven functions

Symbol Oven function Application
Off position The oven is off.
Oven Lamp To turn on the lamp without a cooking function.
ENGLISH 13
100 - 250 Conventional Cook-
ing
Dual Circuit Grill To grill food items in medium quantities in the mid-
Full Grill To grill flat food and to toast bread.
To bake and roast food on one shelf position.
dle of the shelf. To make toasts.

9.2 Main oven functions

Symbol Oven function Application
Off position The oven is off.
Thermaflow® To bake on up to two shelf positions at the same
time and to dry food.
Steam Bake To add humidity during the cooking. To get the
right colour and crispy crust during baking. To give more juiciness during reheating.
14
www.aeg.com
Symbol Oven function Application
Moist Fan Baking This function is designed to save energy during
cooking. For the cooking instructions refer to "Hints and tips" chapter, Moist Fan Baking. The oven door should be closed during cooking so that the func­tion is not interrupted and to ensure that the oven operates with the highest energy efficiency possi­ble. When you use this function, the temperature in the cavity may differ from the set temperature. The heating power may be reduced. For general energy saving recommendations refer to "Energy Efficien­cy" chapter, Energy Saving. This function was used to comply with the energy efficiency class according to EN 60350-1.

9.3 Activating and deactivating the top / main oven

It depends on the model if your appliance has knob symbols, indicators or lamps:
• The indicator comes on when the oven heats up.
• The lamp comes on when the oven operates.
• The symbol shows whether the knob controls one of the cooking zones, the oven functions or the temperature.
1. Turn the knob for the top / main
oven functions to select an oven function.
2. Turn the knob for the temperature to
select a temperature.
3. To deactivate the oven turn the knob
for the top / main oven functions to the off position.

9.4 Activating the function: Steam Bake

This function allows to have an improvement of humidity during the cooking.
WARNING!
Risk of burns and damage to the appliance.
Released humidity can cause burns:
• Do not open the appliance door when using the function: Steam Bake.
• Open the appliance door with care after using the function: Steam Bake.
Refer to “Hints and tips” chapter.
1. Open the oven door.
2. Fill the cavity embossment with tap
water. The maximum capacity of the cavity embossment is 250 ml. Fill the cavity embossment with water only when the oven is cold.
3. Turn the knob for the function: Steam
Bake .
4. Turn the knob for the temperature to
select a temperature.
5. Put food in the appliance and close
the oven door.
CAUTION!
Do not refill the cavity embossment with water during cooking or when the oven is hot.
6. To deactivate the appliance, turn the
knobs for the oven functions and temperature to the off position.
7. Remove water from the cavity
embossment.
WARNING!
Make sure that the appliance is cool before you remove the remaining water from the cavity embossment.

9.5 Cooling fan

When the oven operates, the cooling fan turns on automatically to keep the surfaces of the oven cool. If you turn off the oven,

9.6 Inserting the oven accessories

Deep pan:
Push the deep pan between the guide bars of the shelf support.
ENGLISH
• All accessories have small indentations at the top of the right and left side to increase safety. The indentations are also anti­tip devices.
• The high rim around the shelf is a device which prevents cookware from slipping.

9.7 Trivet and Grill- / Roasting pan

WARNING!
Be careful when you remove the accessories from a hot oven. There is a risk of burns.
You can use the trivet to roast larger pieces of meat or poultry on one shelf position.
1. Put the trivet into the deep pan so
that the supports of the wire shelf point up.
15
Wire shelf and the deep pan together:
Push the deep pan between the guide bars of the shelf support and the wire shelf on the guide bars above.
2. Put the deep pan into the oven on
the necessary shelf position. You can use the trivet to grill flat dishes in large quantities and to toast.
1. Put the trivet into the deep pan so
that the supports of the wire shelf
point down.
A B C
www.aeg.com16

10. OVEN - CLOCK FUNCTIONS

2. Put the deep pan into the oven on
the necessary shelf position.

10.1 Display

The electronic programmer works only with the main oven.
A. Function indicators B. Time display C. Function indicator

10.2 Buttons

Button Function Description
MINUS To set the time.
CLOCK To set a clock function.
PLUS To set the time.

10.3 Clock functions table

Clock function Application
TIME OF DAY To set, change or check the time of day.
DURATION To set how long the appliance operates.
END To set when the appliance deactivates.
TIME DELAY To combine DURATION and END function.
Clock function Application
MINUTE MINDER To set countdown time. This function has no effect on the
operation of the appliance. You can set the MINUTE MIND­ER at any time, also when the appliance is off.
ENGLISH
17

10.4 Setting the DURATION

1. Set an oven function and
temperature.
2. Press again and again until
starts to flash.
3. Press or to set the DURATION
time.
The display shows .
4. When the time ends, flashes and
an acoustic signal sounds. The appliance deactivates automatically.
5. Press any button to stop the acoustic
signal.
6. Turn the knob for the oven functions
and the knob for the temperature to the off position.
DURATION works only for the main oven.

10.5 Setting the END

1. Set an oven function and
temperature.
2. Press
starts to flash.
3. Press The display shows .
4. When the time ends,
an acoustic signal sounds. The appliance deactivates automatically.
5. Press any button to stop the signal.
6. Turn the knob for the oven functions
and the knob for the temperature to the off position.
again and again until
or to set the time.
flashes and
The function works only for the main oven.

10.6 Setting the TIME DELAY

1. Set an oven function and
temperature.
2. Press again and again until
starts to flash.
3. Press or to set the time for
DURATION.
4. Press .
5. Press or to set the time for
END.
6. Press Appliance turns on automatically later on, works for the set DURATION time and stops at the set END time. At the set time an acoustic signal sounds.
7. The appliance deactivates
automatically. Press any button to
stop the signal.
8. Turn the knob for the oven functions
and the knob for the temperature to
the off position.
to confirm.
TIME DELAY works only for the main oven.

10.7 Setting the MINUTE MINDER

1.
Press
starts to flash.
2. Press
time. The Minute Minder starts automatically after 5 seconds.
3. When the set time ends, an acoustic
signal sounds. Press any button to
stop the acoustic signal.
4. Turn the knob for the oven functions
and the knob for the temperature to
the off position.
again and again until
or to set the necessary

10.8 Cancelling the clock functions

1. Press the again and again until
the necessary function indicator
starts to flash.
2. Press and hold The clock function goes out after some seconds.
.
www.aeg.com18

11. OVEN - HINTS AND TIPS

WARNING!
Refer to Safety chapters.

11.2 Main oven

The main oven is particularly suitable for cooking larger quantities of food.
The temperature and baking times in the tables are guidelines only. They depend on the recipes and the quality and quantity of the ingredients used. Always preheat an empty oven at the temperature required for the food for 20 minutes before you start cooking.

11.1 Top oven

The top oven is the smaller of the two ovens. It has 3 shelf positions. Use it to cook smaller quantities of food. It gives

11.3 Baking

• Use the lower temperature the first time.
• You can extend baking times by 10 – 15 minutes if you bake cakes on more than one shelf position.
• Cakes and pastries at different heights do not always brown equally. There is no need to change the temperature setting if an unequal browning occurs. The differences equalize during baking.
• Trays in the oven can twist during baking. When the trays become cold again, the distortions disappear.
especially good results when used to cook fruitcakes, sweets and savoury flants or quiche.

11.4 Tips on baking

Baking results Possible cause Remedy
The bottom of the cake is not browned suffi­ciently.
The cake sinks and be­comes soggy, lumpy or streaky.
The cake is too dry. The oven temperature is
The shelf position is incor­rect.
The oven temperature is too high.
The baking time is too short.
There is too much liquid in the mixture.
too low.
The baking time is too long. The next time you bake, set a
Put the cake on a lower shelf.
The next time you bake, set a slightly lower oven temperature.
Set a longer baking time. You cannot decrease baking times by setting higher temperatures.
Use less liquid. Be careful with mixing times, especially if you use a mixing machine.
The next time you bake, set a higher oven temperature.
shorter baking time.
ENGLISH 19
Baking results Possible cause Remedy
The cake browns un­evenly.
The cake is not ready in the baking time given.
The oven temperature is too high and the baking time is too short.
The mixture is unevenly dis­tributed.
The oven temperature is too low.
Set a lower oven temperature and a longer baking time.
Spread the mixture evenly on the baking tray.
The next time you bake, set a slightly higher oven temperature.

11.5 Conventional Baking - Top Oven

Food Temperature (°C) Time (min) Shelf posi-
tion
Biscuits 170 - 190 10 - 20 2
Bread 200 - 220 30 - 35 2
Bread rolls / buns 200 - 220 10 - 15 2
Cakes: Small & Queen 160 - 180 18 - 25 2
Cakes: Sponges 160 - 175 20 - 30 2
Cakes: Victoria Sandwich 160 - 170 18 - 25 2
Cakes: Madeira 140 - 150 75 - 90 2
Cakes: Rich Fruit 140 - 150 120 - 150 2
Cakes: Gingerbread 140 - 150 80 - 90 2
Cakes: Meringues 90 - 100 150 - 180 2
Cakes: Flapjack 160 - 170 25 - 30 2
Cakes: Shortbread 130 - 150 45 - 60 2
Cakes: Apple Pie 170 - 180 50 - 60 2
Casseroles: Beef / Lamb 160 - 170 150 - 180 2
Casseroles: Chicken 160 - 180 80 - 90 2
Convenience Foods Follow manufacturer`s instructions. 2
Fish 170 - 190 20 - 30 2
Fish Pie (Potato Topped) 190 - 200 20 - 30 2
Fruit Pies, Crumbles 190 - 200 30 - 50 2
Milk Puddings 150 - 170 90 - 120 2
Pasta Lasagne etc. 170 - 180 40 - 50 2
www.aeg.com20
Food Temperature (°C) Time (min) Shelf posi-
Pastry: Choux 180 - 190 30 - 40 2
Pastry: Eclairs, Profiteroles 180 - 190 30 - 40 2
Pastry: Flaky / Puff Pies 210 - 220 30 - 40 2
Shortcrusts: Mince Pies 190 - 200 15 - 20 2
Shortcrusts: Meat Pies 190 - 210 25 - 35 2
Shortcrusts: Quiche, Tarts, Flans 180 - 200 25 - 50 2
Scones 220 - 230 8 - 12 3
Shepard`s Pie 190 - 200 30 - 40 2
Souffles 170 - 180 20 - 30 2
Vegetables: Baked Jacket Pota­tos
Vegetables: Roast Potatos 180 - 190 60 - 90 2
Yorkshire Pudding Large 220 - 210 25 - 40 2
Yorkshire Pudding Individual 210 - 220 15 - 25 2
Roasting Meat, Poultry Refer to the Roasting table. 2
180 - 190 60 - 90 2
tion
11.6 Thermaflow® Baking -
Main Oven
Shelf positions are not critical but ensure that the oven accessories are evenly spaced when more than one is used.
Food Temperature (°C) Time (min) Shelf posi-
tion
Biscuits 180 - 190 10 - 20 1 – 3
Bread 190 - 210 30 - 35 2
Cakes: Small & Queen 150 - 170 18 - 25 1 – 3
Cakes: Sponges 160 - 170 20 - 25 3
Cakes: Madeira 140 - 160 60 - 80 3
Cakes: Rich Fruit 130 - 140 120 - 150 3
Cakes: Christmas 130 - 140 180 - 270 3
ENGLISH 21
Food Temperature (°C) Time (min) Shelf posi-
tion
Cakes: Apple Pie 160 - 170 50 - 60 3
- Shortbread 130 - 150 45 - 60 1 – 3
Fish 160 - 180 30 - 40 3
Fruit Pies, Crumbles 170 - 180 30 - 50 3
Milk Puddings 140 - 160 60 - 90 3
Pastry: Choux 180 - 190 30 - 40 3
Pastry: Shortcrust 180 - 190 25 - 35 3
Pastry: Flaky 180 - 190 30 - 40 3
Pastry: Puff Follow manufacturer`s instructions. Re-
duce the temperature for Fan oven by 20 °C.
Plate Tarts 180 - 190 25 - 45 3
Quiches / Flans 170 - 180 25 - 45 3
Scones 210 - 230 8 - 12 1 – 3
Roasting: Meat, Poultry 160 - 180 Refer to the
Roasting table.
3
2

11.7 Moist Fan Baking

Food Temperature (°C) Time (min) Shelf posi-
tion
Lasagne 190 - 210 60 - 80 3
Cannelloni 180 - 200 70 - 85 3
Potato gratin 190 - 210 70 - 85 3
Pasta gratin 190 - 210 45 - 55 3
Moussaka 180 - 200 60 - 75 3
White bread 190 - 210 55 - 70 3
Rice pudding 180 - 200 45 - 55 2
Bread pudding 190 - 210 55 - 70 3
Apple cake 180 - 190 60 - 75 2
www.aeg.com22

11.8 Steam Bake

Bakery
Food Temperature
(°C)
White bread 180 150 10 35 - 45 2
Bread rolls 200 150 5 20 - 25 2
Focaccia 190 150 10 20 - 25 2
Homemade piz-za230 100 10 15 - 20 2
Water in the cavity emboss­ment (ml)
Preheating time (min)
Time (min) Shelf
posi­tion
Cookies, scones, croissant
Plum cake, cin­namon rolls
160 150 10 10 - 20 2
160 150 10 70 - 80 2
Frozen foods
Food Temperature
(°C)
Pizza 200 100 10 15 - 20 2
Croissant 160 50 10 15 - 30 2
Lasagne 200 200 10 35 - 45 2
Water in the cavity emboss­ment (ml)
Preheating time (min)
Time (min) Shelf
Food regeneration
Food Temperature
(°C)
White bread 110 100 10 15 - 25 2
Bread rolls 110 100 10 10 - 20 2
Homemade piz-za110 100 10 15 - 25 2
Focaccia 110 100 10 15 - 25 2
Vegetables 110 100 10 15 - 25 2
Rice 110 100 10 15 - 25 2
Pasta 110 100 10 15 - 25 2
Water in the cavity emboss­ment (ml)
Preheating time (min)
Time (min) Shelf
posi­tion
posi­tion
ENGLISH 23
Food Temperature
(°C)
Meat 110 100 10 15 - 25 2
Water in the cavity emboss­ment (ml)
Preheating time (min)
Time (min) Shelf
Roasting
Food Tempera-
ture (°C)
Chicken 210 200 - 65 - 75 2
Half chicken 210 200 - 35 - 50 2
Roast pork 180 200 - 65 - 70 2
Roast beef 1 - 1,5 kg
1. Rare
2. Medium
3. Well done
Roast turkey 200 200 - 70 - 85 2
200 200 - 1. 50 - 55

11.9 Roasting

Use heat-resistant ovenware. Roast large roasting joints directly in the
tray or on the wire shelf placed above the tray.
Put some water in the tray to prevent the meat juices or fat from burning.
Water in the cavity em­bossment (ml)
Preheat­ing time (min)
Time (min) Shelf
2. 60 - 65
3. 65 - 75
Turn the roast after 1/2 - 2/3 of the cooking time.
To keep meat more succulent:
• roast lean meat in the roasting tin with the lid or use roasting bag.
• baste large roasts and poultry with their juices several times during roasting.
Meat with crackling can be roasted in the roasting tin without the lid.
posi­tion
posi­tion
2

11.10 Thermaflow® - Main Oven

Roasting
Food Temperature (°C) Time (min)
Beef / Beef boned 170 - 190 20 - 35 minutes per 0.5 kg (1 lb) and 20 - 30 mi-
nutes over
Mutton / Lamb 170 - 190 20 - 35 minutes per 0.5 kg (1 lb) and 25 - 35 mi-
nutes over
Pork / Veal / Ham 170 - 190 30 - 40 minutes per 0.5 kg (1 lb) and 30 - 40 mi-
nutes over
www.aeg.com24
Food Temperature (°C) Time (min)
Chicken 180 - 200 20 - 25 minutes per 0.5 kg (1 lb) and 20 minutes
over
Turkey / Goose 170 - 190 15 - 20 minutes per 0.5 kg (1 lb) up to 3.5 kg (7
lb) then 10 minutes per 0.5 kg (1 lb) over 3.5 kg (7 lb)
Duck 180 - 200 25 - 35 minutes per 0.5 kg (1 lb) and 25 - 30 mi-
nutes over
Pheasant 170 - 190 35 - 40 minutes per 0.5 kg (1 lb) and 35 - 40 mi-
nutes over
Rabbit 170 - 190 20 minutes per 0.5 kg (1 lb) and 20 minutes over

11.11 Grilling in general

• Grill only flat pieces of meat or fish.
WARNING!
Always grill with the oven door closed.
• Always grill with the maximum
temperature setting.
• Set the shelf into the shelf position as recommended in the grilling table.
The grilling area is set in centre of the shelf.
• Always set the deep pan to collect the fat into the first shelf position.

11.12 Dual Grill - Top Oven

Food Time (min) Shelf position
Bacon Rashers 5 - 6 3
Beefburgers 10 - 20 3
Chicken Joints 20 - 40 2
Chops - Lamb 15 - 25 2 - 3
Chops - Pork 20 - 25 2 - 3
Fish - Whole / Trout / Makarel 10 - 12 2
Fillets - Plaice / Cod 4 - 6 2
Kebabs 12 - 18 2 - 3
Kidneys - Lamb / Pig 6 - 10 2 - 3
Sausages 20 - 30 3
Steaks: Rare 4 - 6 3
Steaks: Medium 6 - 8 3
ENGLISH 25
Food Time (min) Shelf position
Steaks: Well Done 12 - 15 3
Toasted Sandwiches 3 - 4 3

11.13 Information for test institutes

Main oven
Food Function Temper-
ature (°C)
Small cakes (20 small cakes per tray)
Small cakes (20 small cakes per tray)
Apple pie, 2 tins (ø 20 cm) on the grid,
diagonally shifted
Fatless sponge cake, 1 tin (ø 26 cm) on the grid
Fatless sponge cake, 1 tin (ø 26 cm) on the grid
Shortbread/Pastry strip
Shortbread/Pastry strip
1)
Add 200 ml of water to the cavity embossment.
Thermaflow® 150 20 - 30 Tray 3
Thermaflow® 150 20 - 35 Tray 1 / 4
Steam Bake 160 80 - 100 Grid 2
1)
Thermaflow® 150 25 - 35 Grid 2
Thermaflow® 150 30 - 40 Grid 1 / 4
Thermaflow® 140 20 - 30 Tray 3
Thermaflow® 140 15 - 25 Tray 1 / 4
Top oven
Food Function Temper-
ature (°C)
Small cakes (20 small cakes per tray)
Apple pie, 2 tins (ø 20 cm) on the grid, diagonally shifted
Fatless sponge cake, 1 tin (ø 26 cm) on the grid
Conventional Cooking
Conventional Cooking
Conventional Cooking
150 20 - 30 Tray 2
170 20 - 35 Grid 1
150 80 - 100 Grid 2
Time (min) Accesso-
ries
Time (min) Accesso-
ries
Shelf position
Shelf position
www.aeg.com26
Food Function Temper-
ature (°C)
Shortbread/Pastry strip
Toast Full Grill - 30 - 40 Grid 2
Beef burger Dual Circuit Grill - 20 - 30 Grid /
Conventional Cooking
140 25 - 35 Tray 2

12. OVEN - CARE AND CLEANING

WARNING!
Refer to Safety chapters.

12.1 Notes on cleaning

Clean the front of the oven with a soft cloth with warm water and a mild cleaning agent.
To clean metal surfaces, use a dedicated cleaning agent.
Clean the oven interior after each use. Fat accumulation or other food remains may result in a fire. The risk is higher for the grill pan.
Clean all accessories after each use and let them dry. Use a soft cloth with warm water and a cleaning agent. Do not clean the accessories in the dishwasher.
Clean stubborn dirt with a special oven cleaner. Do not apply oven cleaner on the catalytic surfaces.
If you have nonstick accessories, do not clean them using aggressive agents, sharp-edged objects or a dishwasher. It can cause damage to the nonstick coating.
Clean the moisture from the cavity after each use.
12.2 Stainless steel or
aluminium ovens
Clean the oven door with a damp cloth or sponge only. Dry it with a soft cloth.
Do not use steel wool, acids or abrasive materials as they can damage the oven surface. Clean the oven control panel with the same precautions.

12.3 Catalytic cleaning

Time (min) Accesso-
ries
Roasting pan
CAUTION!
Do not clean the catalytic surface with oven sprays, abrasive cleaning agents, soap or other cleaning agents. This will damage the catalytic surface.
Spots or discolouration of the catalytic surface have no effect on catalytic properties.
WARNING!
Keep children away when you clean the oven at a high temperature. The oven surface becomes very hot and there is a risk of burns.
CAUTION!
Always turn the oven light on while using the catalytic cleaning (if applicable).
Before activating the catalytic cleaning remove all the accessories from the oven.
Shelf position
2
2
1
1
2
1
ENGLISH
27
The walls with a catalytic coating are self­cleaning. They absorb fat which collects on the walls while the appliance operates.
To support the self-cleaning procedure, heat the empty oven on a regular basis.
1. Clean the oven floor with warm water
and washing up liquid, then dry it.
2. Set the oven temperature to 250 °C
and let the oven operate for 1 hour.
3. When the appliance is cool, clean it
with a soft and moist sponge.

12.4 Cleaning the cavity embossment

The cleaning procedure removes limestone residue from the cavity embossment after cooking with steam.
For the function: Steam Bake we recommend to do the cleaning procedure at least every 5 - 10 cooking cycles.
1. Put 250 ml of white vinegar into the
cavity embossment at the bottom of the oven. Use maximum 6% vinegar without any additives.
2. Let the vinegar dissolve the residual
limestone at the ambient temperature for 30 minutes.
3. Clean the cavity with warm water and
a soft cloth.

12.5 Removing the shelf supports

To clean the oven, remove the shelf supports.
1. Pull the front of the shelf support
away from the side wall.
2. Pull the rear end of the shelf support
away from the side wall and remove it.
Install the shelf supports in the opposite sequence.
CAUTION!
Make sure that the longer fixing wire is in the front. The ends of the two wires must point to the rear. Incorrect installation can cause damage to the enamel.

12.6 Removing and cleaning the door glasses - top oven

The door glass in your product can be different in type and shape from the examples you see in the image. The number of glasses can also be different.
1. Open the door.
2. Hold the door trim on the top edge
of the door at the two sides and push inwards to release the clip seal.
3. Pull the door trim to the front to
remove it.
4. Remove the glass panels.
1
2
A
www.aeg.com28
To install the panels, do the same steps in reverse.
12.7 Removing and cleaning
the door glasses - main oven
The door glass in your product can be different in type and shape from the example you see in the image. The number of glasses can also be different.
1. Push the door trim at one side to
remove it.
2. Pull up the trim.
3. Remove the glass panels.
To replace the glass panels, do the same steps in reverse. Before you lower the trim, attach the A trim part to the door. Refer to the image.

12.8 Replacing the lamp

WARNING!
Risk of electric shock. The lamp can be hot.
1. Turn off the oven. Wait until the oven is cooled down.
2. Disconnect the oven from the mains.
3. Put a cloth on the bottom of the
cavity.

The back lamp

The lamp glass cover is at the back of the cavity.
1. Turn the lamp glass cover
counterclockwise to remove it.
2. Clean the glass cover.
3. Replace the oven lamp with a
suitable 300 °C heat-resistant oven lamp. Use the same oven lamp type.
4. Install the glass cover.

TROUBLESHOOTING

13.
WARNING!
Refer to Safety chapters.

13.1 What to do if...

Problem Possible cause Remedy
You cannot activate the ap­pliance.
You cannot activate the ap­pliance.
The appliance is not connec­ted to an electrical supply or it is connected incorrectly.
The fuse is blown. Make sure that the fuse is
Check if the appliance is cor­rectly connected to the elec­trical supply.
the cause of the malfunction. If the fuse is blown again and again, contact a quali­fied electrician.
ENGLISH 29
Problem Possible cause Remedy
Residual heat indicator does not come on.
You cannot activate the out­er ring.
The oven does not heat up. The oven is deactivated. Activate the oven.
The oven does not heat up. The clock is not set. Set the clock.
The oven does not heat up. The necessary settings are
The lamp does not operate. The lamp is defective. Replace the lamp.
The display shows "12.00". There was a power cut. Reset the clock.
Steam and condensation settle on the food and in the cavity of the oven.
There is no good cooking performance using the Steam Bake function.
The water in the cavity em­bossment does not boil.
The water comes out of the cavity embossment.
The zone is not hot because it operated only for a short time.
Activate the inner ring first.
not set.
You left the dish in the oven for too long.
You did not fill the cavity embossment with water.
The temperature is too low. Set the temperature at least
There is to much water in the cavity embossment.
If the zone operated suffi­ciently long to be hot, speak to an Authorised Service Centre.
Make sure that the settings are correct.
Do not leave the dishes in the oven for longer than 15 ­20 minutes after the cooking process ends.
Refer to "Activating the Steam Bake function".
to 110°C. Refer to "Hints and Tips" chapter.
Deactivate the oven and make sure that the appliance is cold. Wipe the water with a cloth or sponge. Add the correct amount of water to the cavity embossment. Re­fer to "Activating the Steam Bake function".

13.2 Service data

If you cannot find a solution to the problem yourself, contact your dealer or
on the front frame of the oven cavity. Do not remove the rating plate from the oven cavity.
an Authorised Service Centre. The necessary data for the service centre
is on the rating plate. The rating plate is
We recommend that you write the data here:
Model (MOD.) .........................................
www.aeg.com30
We recommend that you write the data here:
Product number (PNC) .........................................
Serial number (S.N.) .........................................

14. ENERGY EFFICIENCY

14.1 Product information for hob according to EU 66/2014

Model identification CCB6740ACB
CCB6740ACM
Type of hob Hob inside Freestanding Cooker
Number of cooking zones 4
Heating technology Radiant Heater
Diameter of circular cooking zones (Ø)
Energy consumption per cooking zone (EC electric cooking)
Energy consumption of the hob (EC electric hob) 183.7 Wh/kg
Left front Left rear Right front Right rear
Left front Left rear Right front Right rear
14.0 cm / 21.0 cm
14.5 cm
14.5 cm
18.0 cm
178.9 Wh/kg
181.8 Wh/kg
181.8 Wh/kg
192.3 Wh/kg
EN 60350-2 - Household electric cooking appliances - Part 2: Hobs - Methods for measuring performance.
• Before you activate the cooking zone put the cookware on it.
• The cookware bottom should have the same diameter as the cooking

14.2 Hob - Energy saving

You can save energy during everyday cooking if you follow below hints.
• When you heat up water, use only the amount you need.
• If it is possible, always put the lids on
zone.
• Put the smaller cookware on the smaller cooking zones.
• Put the cookware directly in the centre of the cooking zone.
• Use the residual heat to keep the food warm or to melt it.
the cookware.

14.3 Product Fiche and information for ovens according to EU 65-66/2014

Supplier's name AEG
Model identification
CCB6740ACB CCB6740ACM
ENGLISH 31
Energy Efficiency Index
Energy efficiency class
Energy consumption with a standard load, conven­tional mode
Energy consumption with a standard load, fan-forced mode
Number of cavities 2
Heat source Electricity
Volume
Type of oven Oven inside Freestanding Cooker
Mass
EN 60350-1 - Household electric cooking appliances - Part 1: Ranges, ovens, steam ovens and grills - Methods for measuring performance.
Top oven: 105.6 Main oven: 95.3
Top oven: A Main oven: A
Top oven: 0.75 kWh/cycle Main oven: not applicable
Top oven: not applicable Main oven: 0.82 kWh/cycle
Top oven: 39 l Main oven: 73 l
CCB6740ACB 59.2 kg
CCB6740ACM 59.0 kg
temperature to minimum 3 - 10 minutes before the end of the cooking time, depending on the duration of the cooking. The residual heat inside the oven will continue to cook.

14.4 Oven - Energy saving

The oven contains features which help you save energy during everyday cooking.
General hints
Make sure that the oven door is closed properly when the oven operates. Do not open the door too often during cooking. Keep the door gasket clean and make sure it is well fixed in its position.
Use metal dishes to improve energy saving.
When possible, do not preheat the oven before you put the food inside.
When the cooking duration is longer
Use the residual heat to warm up other dishes.
Keep breaks between baking as short as possible when you prepare few dishes at one time.
Cooking with fan
When possible, use the cooking functions with fan to save energy.
Keep food warm
Choose the lowest possible temperature setting to use residual heat and keep a meal warm.
Moist Fan Baking
Function designed to save energy during cooking.
than 30 minutes, reduce the oven
15. ENVIRONMENTAL CONCERNS
Recycle materials with the symbol . Put the packaging in relevant containers to recycle it. Help protect the
environment and human health by recycling waste of electrical and electronic appliances. Do not dispose of
32
www.aeg.com
appliances marked with the symbol with the household waste. Return the
product to your local recycling facility or contact your municipal office.
*
ENGLISH 33
www.aeg.com34
ENGLISH 35
www.aeg.com/shop
867337946-C-252019
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
