AEG BPK742320M User Manual
USER
MANUAL
BPK742320M
EN User Manual
Oven
www.aeg.com
2
CONTENTS
1. SAFETY INFORMATION.............................................................................................3
2. CONDITIONS OF USE................................................................................................4
3. SAFETY INSTRUCTIONS.............................................................................................4
4. PRODUCT DESCRIPTION...........................................................................................7
5. CONTROL PANEL....................................................................................................... 9
6. BEFORE FIRST USE................................................................................................... 11
7. DAILY USE..................................................................................................................11
8. CLOCK FUNCTIONS.................................................................................................15
9. AUTOMATIC PROGRAMMES.................................................................................. 16
10. USING THE ACCESSORIES....................................................................................17
11. ADDITIONAL FUNCTIONS.................................................................................... 20
12. HINTS AND TIPS..................................................................................................... 22
13. CARE AND CLEANING.......................................................................................... 37
14. TROUBLESHOOTING.............................................................................................40
15. INSTALLATION........................................................................................................42
16. ENERGY EFFICIENCY.............................................................................................44
17. WARRANTY .............................................................................................................45
FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you
impeccable performance for many years, with innovative technologies that help
make life simpler features you might not find on ordinary appliances. Please
spend a few minutes reading to get the very best from it.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.aeg.com/webselfservice
Register your product for better service:
www.registeraeg.com
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the
following data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
1. SAFETY INFORMATION
Before the installation and use of the appliance,
carefully read the supplied instructions. The
manufacturer is not responsible for any injuries or
damages that are the result of incorrect installation or
usage. Always keep the instructions in a safe and
accessible location for future reference.
1.1 Children and vulnerable people safety
• This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning the use of the appliance in a
safe way and understand the hazards involved.
• Do not let children play with the appliance.
• Keep all packaging away from children and dispose of
it appropriately.
• Keep children and pets away from the appliance when
it operates or when it cools down. Accessible parts are
hot.
• If the appliance has a child safety device, this should
be activated.
• Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
• Children aged 3 years and under must be kept away
from this appliance when it is in operation at all times.
ENGLISH
3
General Safety
1.2
• Only a qualified person must install this appliance and
replace the cable.
• WARNING: The appliance and its accessible parts
become hot during use. Care should be taken to
avoid touching heating elements. Children less than 8
years of age shall be kept away unless continuously
supervised.
www.aeg.com4
• Always use oven gloves to remove or put in
accessories or ovenware.
• Before carrying out any maintenance, disconnect the
appliance from the power supply.
• Ensure that the appliance is switched off before
replacing the lamp to avoid the possibility of electric
shock.
• Do not use a steam cleaner to clean the appliance.
• Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the glass door since they can scratch
the surface, which may result in shattering of the glass.
• If the mains power supply cable is damaged, it must
be replaced by the manufacturer, its Authorised
Service Centre or similarly qualified persons to avoid
an electrical hazard.
• Excessive spillage must be removed before the
pyrolytic cleaning. Remove all parts from the oven.
• To remove the shelf supports first pull the front of the
shelf support and then the rear end away from the
side walls. Install the shelf supports in the opposite
sequence.
• The means for disconnection must be incorporated in
the fixed wiring in accordance with the wiring rules.
• Use only the food sensor (core temperature sensor)
recommended for this appliance.
2.
CONDITIONS OF USE
This appliance is intended to be used in
household and similar applications such
as:
• Farm houses
3. SAFETY INSTRUCTIONS
3.1 Installation
WARNING!
Only a qualified person must
install this appliance.
• Remove all the packaging.
• By clients in serviced apartments,
holiday apartments and other
residential type environments.
• Do not install or use a damaged
appliance.
• Follow the installation instruction
supplied with the appliance.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
ENGLISH
5
• Do not pull the appliance by the
handle.
• Keep the minimum distance from the
other appliances and units.
• Make sure that the appliance is
installed below and adjacent safe
structures.
• The sides of the appliance must stay
adjacent to appliances or to units with
the same height.
• The appliance is equipped with an
electric cooling system. It must be
operated with the electric power
supply.
3.2 Electrical connection
WARNING!
Risk of fire and electrical
shock.
• All electrical connections should be
made by a qualified electrician.
• The appliance must be earthed.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to
the mains plug and to the mains
cable. Should the mains cable need
to be replaced, this must be carried
out by our Authorised Service Centre.
• Do not let mains cables touch or
come near the appliance door,
especially when the door is hot.
• The shock protection of live and
insulated parts must be fastened in
such a way that it cannot be removed
without tools.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• If the mains socket is loose, do not
connect the mains plug.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
• Use only correct isolation devices: line
protecting cut-outs, fuses (screw type
fuses removed from the holder), earth
leakage trips and contactors.
• The electrical installation must have
an isolation device which lets you
disconnect the appliance from the
mains at all poles. The isolation
device must have a contact opening
width of minimum 3 mm.
• This appliance complies with the
E.E.C. Directives.
3.3 Use
WARNING!
Risk of injury, burns and
electrical shock or explosion.
• Do not change the specification of
this appliance.
• Make sure that the ventilation
openings are not blocked.
• Do not let the appliance stay
unattended during operation.
• Deactivate the appliance after each
use.
• Be careful when you open the
appliance door while the appliance is
in operation. Hot air can release.
• Do not operate the appliance with
wet hands or when it has contact with
water.
• Do not apply pressure on the open
door.
• Do not use the appliance as a work
surface or as a storage surface.
• Open the appliance door carefully.
The use of ingredients with alcohol
can cause a mixture of alcohol and air.
• Do not let sparks or open flames to
come in contact with the appliance
when you open the door.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
WARNING!
Risk of damage to the
appliance.
• To prevent damage or discoloration
to the enamel:
– do not put ovenware or other
objects in the appliance directly
on the bottom.
– do not put aluminium foil directly
on the bottom of cavity of the
appliance.
6
www.aeg.com
– do not put water directly into the
hot appliance.
– do not keep moist dishes and
food in the appliance after you
finish the cooking.
– be careful when you remove or
install the accessories.
• Discoloration of the enamel or
stainless steel has no effect on the
performance of the appliance.
• Use a deep pan for moist cakes. Fruit
juices cause stains that can be
permanent.
• This appliance is for cooking
purposes only. It must not be used for
other purposes, for example room
heating.
• Always cook with the oven door
closed.
• If the appliance is installed behind a
furniture panel (e.g. a door) make sure
the door is never closed when the
appliance is in operation. Heat and
moisture can build up behind a
closed furniture panel and cause
subsequent damage to the appliance,
the housing unit or the floor. Do not
close the furniture panel until the
appliance has cooled down
completely after use.
3.4 Care and cleaning
WARNING!
Risk of injury, fire, or damage
to the appliance.
• Before maintenance, deactivate the
appliance and disconnect the mains
plug from the mains socket.
• Make sure the appliance is cold.
There is the risk that the glass panels
can break.
• Replace immediately the door glass
panels when they are damaged.
Contact the Authorised Service
Centre.
• Be careful when you remove the door
from the appliance. The door is
heavy!
• Clean regularly the appliance to
prevent the deterioration of the
surface material.
• Clean the appliance with a moist soft
cloth. Only use neutral detergents. Do
not use any abrasive products,
abrasive cleaning pads, solvents or
metal objects.
• If you use an oven spray, follow the
safety instruction on it's packaging.
• Do not clean the catalytic enamel (if
applicable) with any kind of
detergent.
3.5 Pyrolytic cleaning
WARNING!
Risk of Injury / Fires /
Chemical Emissions (Fumes)
in Pyrolytic Mode.
• Before carrying out a Pyrolitic selfcleaning function or the First Use
please remove from the oven cavity:
– any excess food residues, oil or
grease spills / deposits.
– any removable objects (including
shelves, side rails etc., provided
with the product) particularly any
non-stick pots, pans, trays,
utensils etc.
• Read carefully all the instructions for
Pyrolytic cleaning.
• Keep children away from the
appliance while the Pyrolytic cleaning
is in operation.
The appliance becomes very hot and
hot air is released from the front
cooling vents.
• Pyrolytic cleaning is a high
temperature operation that can
release fumes from cooking residues
and construction materials, as such
consumers are strongly advised to:
– provide good ventilation during
and after each Pyrolytic cleaning.
– provide good ventilation during
and after the first use at maximum
temperature operation.
• Unlike all humans, some birds and
reptiles can be extremely sensitive to
potential fumes emitted during the
cleaning process of all Pyrolytic
Ovens.
– Remove any pets (especially birds)
from the vicinity of the appliance
location during and after the
Pyrolytic cleaning and first use
maximum temperature operation
to a well ventilated area.
• Small pets can also be highly sensitive
to the localized temperature changes
2
7
1
8
4
3
5
6
5
4
3
2
1
ENGLISH 7
in the vicinity of all Pyrolytic Ovens
when the Pyrolytic self cleaning
program is in operation.
• Non-stick surfaces on pots, pans,
trays, utensils etc., can be damaged
by the high temperature Pyrolytic
cleaning operation of all Pyrolytic
Ovens and can be also a source for
low level harmful fumes.
• Fumes released from all Pyrolytic
Ovens / Cooking Residues as
described are not harmful to humans,
including infants or persons with
medical conditions.
3.6 Internal light
• The type of light bulb or halogen
lamp used for this appliance is only
for household appliances. Do not use
it for house lighting.
WARNING!
Risk of electrical shock.
4. PRODUCT DESCRIPTION
4.1 General overview
• Before replacing the lamp, disconnect
the appliance from the power supply.
• Only use lamps with the same
specifications.
3.7 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains supply.
• Cut off the mains electrical cable
close to the appliance and dispose of
it.
• Remove the door catch to prevent
children or pets from becoming
trapped in the appliance.
3.8 Service
• To repair the appliance contact an
Authorised Service Centre.
• Use original spare parts only.
Control panel
1
Electronic programmer
2
Socket for the core temperature
3
sensor
Heating element
4
Lamp
5
Fan
6
Shelf support, removable
7
Shelf positions
8
8
www.aeg.com
4.2 Accessories
Wire shelf
For cookware, cake tins, roasts.
Baking tray
For cakes and biscuits.
Grill- / Roasting pan
For roasting and grilling.
Use the trivet only with the
Grill- / Roasting pan.
Food Sensor
To measure the temperature inside the
food.
Telescopic runners
For shelves and trays.
To bake and roast or as a pan to collect
fat.
Trivet
5. CONTROL PANEL
21 3 4 5 8 9 10 1176
5.1 Electronic programmer
Use the sensor fields to operate the appliance.
Sensor
field
1
2
Function Comment
- Display Shows the current settings of the appliance.
ON / OFF To turn on and off the appliance.
ENGLISH 9
Heating Functions
or Assisted Cook-
3
4
5
6
7
8
9
ing
Favourites To save and access your favourite programmes.
Temperature selection
Down key To move down in the menu.
Up key To move up in the menu.
OK To confirm the selection or setting.
Back key To go back one level in the menu. To show the
Press the sensor field to choose the menu: Assisted Cooking or Heating Functions. To turn on or
turn off the light, press the field for 3 seconds. You
can turn on the light also when the appliance is
turned off.
To set the temperature or show the current temperature in the appliance. Press the field for 3 seconds to turn on or turn off the function: Fast heat
up.
main menu, press the field for 3 seconds.
A
DE
B C
www.aeg.com10
Sensor
field
10
11
Function Comment
Time and additional functions
Minute Minder To set the function: Minute Minder.
To set different functions. When a heating function operates, press the sensor field to set the timer or the functions: Function Lock, Favourites,
Heat + Hold, Set + Go. You can also change the
settings of the core temperature sensor.
5.2 Display
Other indicators of the display:
Symbol Function
Minute Minder The function operates.
Time of day The display shows the current time.
Duration The display shows the necessary time
End Time The display shows when the cooking
Temperature The display shows the temperature.
A. Heating function
B. Time of day
C. Heat-up indicator
D. Temperature
E. Duration time or end time of a
function
for cooking.
time is complete.
Time Indication The display shows how long the heat-
ing function operates. Press and
at the same time to reset the time.
Calculation The appliance calculates the time for
cooking.
Heat-up Indicator The display shows the temperature in
the appliance.
Fast Heat Up Indicator The function is active. It decreases the
heat up time.
Symbol Function
Weight Automatic The display shows that the automatic
Heat + Hold The function is active.
6. BEFORE FIRST USE
ENGLISH 11
weight system is active or that weight
can be changed.
WARNING!
Refer to Safety chapters.
6.1 Initial Cleaning
Remove all accessories and removable
shelf supports from the appliance.
Refer to "Care and
cleaning" chapter.
Clean the appliance and the accessories
before first use.
Put the accessories and the removable
shelf supports back to their initial
position.
7. DAILY USE
WARNING!
Refer to Safety chapters.
7.1 Navigating the menus
1. Activate the appliance.
2. Press or to select the menu
option.
7.2 The menus in overview
Main menu
Symbol
Menu item Application
Heating Functions Contains a list of heating functions.
6.2 First Connection
When you connect the appliance to the
mains or after the power cut, you have to
set the language, the display contrast,
the display brightness and the time of
the day.
1. Press
2. Press to confirm.
3. Press to move to the submenu or
accept the setting.
or to set the value.
At each point you can go
back to the main menu with
.
Assisted Cooking Contains a list of automatic programmes.
Favourites Contains a list of favourite cooking programmes
created by the user.
www.aeg.com12
Sym-
Menu item Application
bol
Pyrolysis Pyrolytic cleaning.
Basic Settings Used to set the appliance configuration.
Specials Contains a list of additional heating functions.
Submenu for: Basic Settings
Sym-
Submenu Description
bol
Set Time of Day Sets the current time on the clock.
Time Indication When ON, the display shows the current time
Fast heat up When ON, the function decreases the heat-up
Set + Go To set a function and activate it later with a press
Heat + Hold Keeps the prepared food warm for 30 minutes af-
Time Extension Activates and deactivates the time extension
Display Contrast Adjusts the display contrast by degrees.
when you deactivate the appliance.
time.
of any symbol on the control panel.
ter a cooking cycle finished.
function.
Display Brightness Adjusts the display brightness by degrees.
Set Language Sets the language for the display.
Buzzer Volume Adjusts the volume of press-tones and signals by
degrees.
Key Tones Activates and deactivates the tone of the touch
fields. It is not possible to deactivate the tone of
the ON / OFF touch field.
Alarm/Error Tones Activates and deactivates the alarm tones.
Cleaning Reminder Reminds you when to clean the appliance.
DEMO mode Activation / deactivation code: 2468
Service Shows the software version and configuration.
Factory Settings Resets all settings to factory settings.
7.3 Heating Functions
Heating function Application
True Fan Cooking To bake on up to three shelf positions at the same
time and to dry food. Set the temperature 20 - 40
°C lower than for the function: Conventional
Cooking.
Pizza Setting To bake food on one shelf position for a more in-
tensive browning and a crispy bottom. Set the
temperature 20 - 40 °C lower than for the function: Conventional Cooking.
Conventional Cooking
(Top / Bottom Heat)
Frozen Foods To make convenience food like e.g. french fries,
Grilling To grill flat food and to toast bread.
Turbo Grilling To bake cakes with crispy bottom and to preserve
Bottom Heat To bake cakes with crispy bottom and to preserve
To bake and roast food on one shelf position.
potato wedges or spring rolls crispy.
food.
food.
ENGLISH 13
Moist Fan Baking To bake breads, cakes and cookies. To save ener-
gy during cooking. This function must be used in
accordance with the Moist Fan Baking table in order to achieve the desired cooking result. To get
more information about the recommended settings, refer to the Hints and Tips chapter, Moist
Fan Baking table. This function was used to define
the energy efficiency class acc. to EN 60350-1.
The lamp may automatically
deactivate at a temperature
below 60 °C during some
oven functions.
7.4 Specials
Heating function Application
Keep Warm To keep food warm.
14
www.aeg.com
Heating function Application
Plate Warming To preheat plates for serving.
Preserving To make vegetable preserves such as pickles.
Drying To dry sliced fruit (e.g. apples, plums, peaches)
and vegetables (e.g. tomatoes, zucchini, mushrooms).
Dough Proving For controlled rising of yeast dough before bak-
ing.
Slow Cooking To prepare tender, succulent roasts.
Bread Baking To bake bread.
Defrost This function can be used for defrosting frozen
foods, such as vegetables and fruits. The defrosting time depends on the amount and size of the
frozen food.
7.5 Activating a heating function
1. Activate the appliance.
2. Select the menu: Heating Functions.
3. Press to confirm.
4. Select a heating function.
5. Press to confirm.
6. Set the temperature.
7. Press
to confirm.
7.6 Heat-up indicator
When you activate a heating function,
the bar on the display comes on. The bar
shows that the temperature increases.
When temperature is reached the buzzer
sounds 3 times and the bar flashes and
then disappears.
7.7 Fast Heat Up Indicator
This function decreases the heat-up time.
Do not put food in the oven
when the Fast heat up
function operates.
To activate the function, hold for 3
seconds. The heat-up indicator
alternates.
7.8 Residual heat
When you deactivate the appliance, the
display shows the residual heat. You can
use the heat to keep the food warm.
8. CLOCK FUNCTIONS
8.1 Clock functions table
Clock function Application
Minute Minder To set a countdown (max. 2 h 30 min). This
Duration To set the length of an operation (max. 23 h
End Time To set the switch-off time for a heating func-
ENGLISH
function has no effect on the operation of the
appliance. You can also activate it when the
appliance is deactivated.
Use to activate the function. Press or
to set the minutes and to start.
59 min).
tion (max. 23 h 59 min).
15
If you set the time for a clock function,
the time starts to count down after 5
seconds.
If you use the clock
functions: Duration, End
Time, the appliance
deactivates the heating
elements after 90 % of the
set time. The appliance uses
the residual heat to continue
the cooking process until the
time ends (3 - 20 minutes).
8.2 Setting the clock functions
Before you use the
functions: Duration, End
Time, you must set a heating
function and temperature
first. The appliance
deactivates automatically.
You can use the functions:
Duration and End Time at
the same time if you want to
automatically activate and
deactivate the appliance on
a given time later.
The functions: Duration and
End Time do not work when
you use the core
temperature sensor.
1. Set a heating function.
2. Press again and again until the
display shows the necessary clock
function and the related symbol.
3. Press
time.
4. Press
When the time ends, an acoustic signal
sounds. The appliance deactivates. The
display shows a message.
5. Press any symbol to stop the signal.
or to set the necessary
to confirm.
8.3 Heat + Hold
Conditions for the function:
• The set temperature is more than 80
°C.
• The function: Duration is set.
The function: Heat + Hold keeps
prepared food warm at 80 °C for 30
minutes. It activates after the baking or
roasting procedure ends.
You can activate or deactivate the
function in the menu: Basic Settings.
1. Activate the appliance.
2. Select the heating function.
3. Set the temperature above 80 °C.
4. Press
display shows: Heat + Hold.
5. Press
When the function ends, an acoustic
signal sounds.
again and again until the
to confirm.
Loading...
