AEG BPK556320M User Manual
USER
MANUAL
BPE556120M
BPK556320M
EN User Manual
Oven
www.aeg.com2
CONTENTS
1. SAFETY INFORMATION.............................................................................................
2. CONDITIONS OF USE................................................................................................4
3. SAFETY INSTRUCTIONS.............................................................................................4
4. PRODUCT DESCRIPTION...........................................................................................7
5. BEFORE FIRST USE..................................................................................................... 8
6. DAILY USE....................................................................................................................9
7. CLOCK FUNCTIONS.................................................................................................12
8. USING THE ACCESSORIES...................................................................................... 13
9. ADDITIONAL FUNCTIONS...................................................................................... 17
10. HINTS AND TIPS..................................................................................................... 18
11. CARE AND CLEANING.......................................................................................... 33
12. TROUBLESHOOTING.............................................................................................36
13. INSTALLATION........................................................................................................39
14. ENERGY EFFICIENCY.............................................................................................42
15.
WARRANTY ............................................................................................................. 44
FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you
impeccable performance for many years, with innovative technologies that help
make life simpler features you might not find on ordinary appliances. Please
spend a few minutes reading to get the very best from it.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.aeg.com/webselfservice
Register your product for better service:
www.registeraeg.com
2
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the
following data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
1. SAFETY INFORMATION
Before the installation and use of the appliance,
carefully read the supplied instructions. The
manufacturer is not responsible for any injuries or
ENGLISH
damages that are the result of incorrect installation or
usage. Always keep the instructions in a safe and
accessible location for future reference.
1.1 Children and vulnerable people safety
• This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning the use of the appliance in a
safe way and understand the hazards involved.
• Do not let children play with the appliance.
• Keep all packaging away from children and dispose of
it appropriately.
• Keep children and pets away from the appliance when
it operates or when it cools down. Accessible parts are
hot.
• If the appliance has a child safety device, this should
be activated.
• Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
• Children aged 3 years and under must be kept away
from this appliance when it is in operation at all times.
3
General Safety
1.2
• Only a qualified person must install this appliance and
replace the cable.
• WARNING: The appliance and its accessible parts
become hot during use. Care should be taken to
avoid touching heating elements. Children less than 8
years of age shall be kept away unless continuously
supervised.
• Always use oven gloves to remove or put in
accessories or ovenware.
• Before carrying out any maintenance, disconnect the
appliance from the power supply.
www.aeg.com4
• Ensure that the appliance is switched off before
replacing the lamp to avoid the possibility of electric
shock.
• Do not use a steam cleaner to clean the appliance.
• Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the glass door since they can scratch
the surface, which may result in shattering of the glass.
• If the mains power supply cable is damaged, it must
be replaced by the manufacturer, its Authorised
Service Centre or similarly qualified persons to avoid
an electrical hazard.
• Excessive spillage must be removed before the
pyrolytic cleaning. Remove all parts from the oven.
• To remove the shelf supports first pull the front of the
shelf support and then the rear end away from the
side walls. Install the shelf supports in the opposite
sequence.
• The means for disconnection must be incorporated in
the fixed wiring in accordance with the wiring rules.
• Use only the food sensor (core temperature sensor)
recommended for this appliance.
2.
CONDITIONS OF USE
This appliance is intended to be used in
household and similar applications such
as:
• Farm houses
3. SAFETY INSTRUCTIONS
3.1 Installation
WARNING!
Only a qualified person must
install this appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Follow the installation instruction
supplied with the appliance.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• By clients in serviced apartments,
holiday apartments and other
residential type environments.
• Do not pull the appliance by the
handle.
• Keep the minimum distance from the
other appliances and units.
• Make sure that the appliance is
installed below and adjacent safe
structures.
• The sides of the appliance must stay
adjacent to appliances or to units with
the same height.
• The appliance is equipped with an
electric cooling system. It must be
operated with the electric power
supply.
ENGLISH
5
3.2 Electrical connection
WARNING!
Risk of fire and electrical
shock.
• All electrical connections should be
made by a qualified electrician.
• The appliance must be earthed.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to
the mains plug and to the mains
cable. Should the mains cable need
to be replaced, this must be carried
out by our Authorised Service Centre.
• Do not let mains cables touch or
come near the appliance door,
especially when the door is hot.
• The shock protection of live and
insulated parts must be fastened in
such a way that it cannot be removed
without tools.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• If the mains socket is loose, do not
connect the mains plug.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
• Use only correct isolation devices: line
protecting cut-outs, fuses (screw type
fuses removed from the holder), earth
leakage trips and contactors.
• The electrical installation must have
an isolation device which lets you
disconnect the appliance from the
mains at all poles. The isolation
device must have a contact opening
width of minimum 3 mm.
• This appliance complies with the
E.E.C. Directives.
3.3 Use
WARNING!
Risk of injury, burns and
electrical shock or explosion.
• Do not change the specification of
this appliance.
• Make sure that the ventilation
openings are not blocked.
• Do not let the appliance stay
unattended during operation.
• Deactivate the appliance after each
use.
• Be careful when you open the
appliance door while the appliance is
in operation. Hot air can release.
• Do not operate the appliance with
wet hands or when it has contact with
water.
• Do not apply pressure on the open
door.
• Do not use the appliance as a work
surface or as a storage surface.
• Open the appliance door carefully.
The use of ingredients with alcohol
can cause a mixture of alcohol and air.
• Do not let sparks or open flames to
come in contact with the appliance
when you open the door.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
WARNING!
Risk of damage to the
appliance.
• To prevent damage or discoloration
to the enamel:
– do not put ovenware or other
objects in the appliance directly
on the bottom.
– do not put aluminium foil directly
on the bottom of cavity of the
appliance.
– do not put water directly into the
hot appliance.
– do not keep moist dishes and
food in the appliance after you
finish the cooking.
– be careful when you remove or
install the accessories.
• Discoloration of the enamel or
stainless steel has no effect on the
performance of the appliance.
6
www.aeg.com
• Use a deep pan for moist cakes. Fruit
juices cause stains that can be
permanent.
• This appliance is for cooking
purposes only. It must not be used for
other purposes, for example room
heating.
• Always cook with the oven door
closed.
• If the appliance is installed behind a
furniture panel (e.g. a door) make sure
the door is never closed when the
appliance is in operation. Heat and
moisture can build up behind a
closed furniture panel and cause
subsequent damage to the appliance,
the housing unit or the floor. Do not
close the furniture panel until the
appliance has cooled down
completely after use.
3.4 Care and cleaning
WARNING!
Risk of injury, fire, or damage
to the appliance.
• Before maintenance, deactivate the
appliance and disconnect the mains
plug from the mains socket.
• Make sure the appliance is cold.
There is the risk that the glass panels
can break.
• Replace immediately the door glass
panels when they are damaged.
Contact the Authorised Service
Centre.
• Be careful when you remove the door
from the appliance. The door is
heavy!
• Clean regularly the appliance to
prevent the deterioration of the
surface material.
• Clean the appliance with a moist soft
cloth. Only use neutral detergents. Do
not use any abrasive products,
abrasive cleaning pads, solvents or
metal objects.
• If you use an oven spray, follow the
safety instruction on it's packaging.
• Do not clean the catalytic enamel (if
applicable) with any kind of
detergent.
3.5 Pyrolytic cleaning
WARNING!
Risk of Injury / Fires /
Chemical Emissions (Fumes)
in Pyrolytic Mode.
Do not start the Pyrolysis if
the Plus Steam button is
pressed in.
• Before carrying out a Pyrolitic selfcleaning function or the First Use
please remove from the oven cavity:
– any excess food residues, oil or
grease spills / deposits.
– any removable objects (including
shelves, side rails etc., provided
with the product) particularly any
non-stick pots, pans, trays,
utensils etc.
• Read carefully all the instructions for
Pyrolytic cleaning.
• Keep children away from the
appliance while the Pyrolytic cleaning
is in operation.
The appliance becomes very hot and
hot air is released from the front
cooling vents.
• Pyrolytic cleaning is a high
temperature operation that can
release fumes from cooking residues
and construction materials, as such
consumers are strongly advised to:
– provide good ventilation during
and after each Pyrolytic cleaning.
– provide good ventilation during
and after the first use at maximum
temperature operation.
• Unlike all humans, some birds and
reptiles can be extremely sensitive to
potential fumes emitted during the
cleaning process of all Pyrolytic
Ovens.
– Remove any pets (especially birds)
from the vicinity of the appliance
location during and after the
Pyrolytic cleaning and first use
maximum temperature operation
to a well ventilated area.
• Small pets can also be highly sensitive
to the localized temperature changes
in the vicinity of all Pyrolytic Ovens
when the Pyrolytic self cleaning
program is in operation.
• Non-stick surfaces on pots, pans,
trays, utensils etc., can be damaged
1
2
3
4
5
2 3 5
8
14
11
9
10
641
12
7
13
ENGLISH
7
by the high temperature Pyrolytic
cleaning operation of all Pyrolytic
Ovens and can be also a source for
low level harmful fumes.
• Fumes released from all Pyrolytic
Ovens / Cooking Residues as
described are not harmful to humans,
including infants or persons with
medical conditions.
3.6 Internal light
WARNING!
Risk of electrical shock.
• The type of light bulb or halogen
lamp used for this appliance is only
for household appliances. Do not use
it for house lighting.
• Before replacing the lamp, disconnect
the appliance from the power supply.
• Only use lamps with the same
specifications.
4. PRODUCT DESCRIPTION
4.1 General overview
3.7 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains supply.
• Cut off the mains electrical cable
close to the appliance and dispose of
it.
• Remove the door catch to prevent
children or pets from becoming
trapped in the appliance.
3.8 Service
• To repair the appliance contact an
Authorised Service Centre.
• Use original spare parts only.
Control panel
1
Knob for the oven functions
2
Power lamp / symbol
3
Electronic programmer
4
Knob for the temperature
5
Temperature indicator / symbol
6
Plus Steam button
7
Socket for the core temperature
8
sensor
Heating element
9
Lamp
10
Fan
11
Shelf support, removable
12
Cavity embossment
13
Shelf positions
14
www.aeg.com8
4.2 Accessories
Wire shelf
For cookware, cake tins, roasts.
Baking tray
For cakes and biscuits.
Grill- / Roasting pan
For roasting and grilling.
Use the trivet only with the
Grill- / Roasting pan.
Food Sensor
To measure the temperature inside the
food.
Telescopic runners
For shelves and trays.
To bake and roast or as a pan to collect
fat.
Trivet
5. BEFORE FIRST USE
WARNING!
Refer to Safety chapters.
To set the Time of day refer
to "Clock functions"
chapter.
5.1 Initial Cleaning
Remove all accessories and removable
shelf supports from the oven.
ENGLISH 9
Refer to "Care and
cleaning" chapter.
Clean the oven and the accessories
before first use.
6. DAILY USE
WARNING!
Refer to Safety chapters.
6.1 Retractable knobs
To use the appliance, press the control
knob. The control knob comes out.
6.2 Activating and deactivating the appliance
It depends on the model if
your appliance has lamps,
knob symbols or
indicators:
• The lamp turns on when
the appliance operates.
• The symbol shows
whether the knob
controls the oven
functions or the
temperature.
• The indicator turns on
when the oven heats up.
Put the accessories and the removable
shelf supports back to their initial
position.
1. Turn the knob for the oven functions
to select an oven function.
2. Turn the knob for the temperature to
select a temperature.
3. To deactivate the appliance, turn the
knobs for the oven functions and
temperature to the off position.
6.3 Oven functions
Oven function Application
Off position The appliance is off.
Fast Heat Up To decrease the heat-up time.
True Fan Cooking
True Fan Cooking PLUS
To bake on up to three shelf positions at the same time
and to dry food. Set the temperature 20 - 40 °C lower
than for Top / Bottom Heat.
To add humidity during the cooking. To get the right
colour and crispy crust during baking. To give more
juiciness during reheating.
10
www.aeg.com
Oven function Application
Pizza Setting To bake food on one shelf position for a more intensive
browning and a crispy bottom. Set the temperature 20
- 40 °C lower than for Top / Bottom Heat.
Conventional
Cooking (Top /
Bottom Heat)
Bottom Heat To bake cakes with crispy bottom and to preserve food.
Defrost This function can be used for defrosting frozen foods,
Moist Fan Baking To bake breads, cakes and cookies. To save energy
Grilling To grill flat food and to toast bread.
To bake and roast food on one shelf position.
such as vegetables and fruits. The defrosting time depends on the amount and size of the frozen food.
during cooking. This function must be used in accordance with the Moist Fan Baking table in order to achieve the desired cooking result. To get more information about the recommended settings, refer to the
Hints and Tips chapter, Moist Fan Baking table. This
function was used to define the energy efficiency class
acc. to EN 60350-1.
Turbo Grilling To roast larger meat joints or poultry with bones on
one shelf position. Also to make gratins and to brown.
Pyrolysis To activate the automatic pyrolytic cleaning of the
oven. This function burns off residual dirt in the oven.
The lamp may automatically
deactivate at a temperature
below 60 °C during some
oven functions.
6.4 Activating the True Fan Cooking PLUS function
This function allows to have an
improvement of humidity during the
cooking.
WARNING!
Risk of burns and damage to
the appliance.
Released humidity can cause burns:
• Do not open the appliance door
when the function True Fan Cooking
PLUS operates, with the exception of
preheating.
• Open the appliance door with care
after the True Fan Cooking PLUS
function stops.
Refer to “Hints and tips”
chapter.
1. Open the oven door.
2. Fill the cavity embossment with tap
water.
The maximum capacity of the cavity
embossment is 250 ml.
Fill the cavity embossment with water
only when the oven is cold.
A B C
D
EH FG
ENGLISH 11
3. Put food in the appliance and close
the oven door.
4. Set the True Fan Cooking PLUS
function: .
5. Press the Plus Steam button .
The Plus Steam button works only
with the True Fan Cooking PLUS
function.
The indicator turns on.
6. Turn the knob for the temperature to
select a temperature.
CAUTION!
Do not refill the cavity
embossment with water
during cooking or when
the oven is hot.
7. To deactivate the appliance, press
the Plus Steam button , turn the
knobs for the oven functions and
temperature to the off position.
The indicator of the Plus Steam button
turns off.
8. Remove water from the cavity
embossment.
WARNING!
Make sure that the
appliance is cool before
you remove the
remaining water from
the cavity embossment.
6.5 Fast heat up function
The fast heat up function decreases the
heat up time.
Do not put food in the oven
when the Fast heat up
function operates.
1. Set the fast heat up function. Refer to
the Oven functions table.
2. Turn the knob for the temperature to
set the temperature.
An acoustic signal sounds when the
appliance is at the set temperature.
The fast heat up function
does not deactivate after the
acoustic signal. You must
deactivate the function
manually.
3.
Set an oven function.
6.6 Display
A. Timer
B. Heat-up and residual heat indicator
C. Water drawer (selected models only)
D. Core temperature sensor (selected
models only)
E. Door lock (selected models only)
F. Hours / minutes
G. Demo mode (selected models only)
H. Clock functions
6.7 Buttons
Sensor field / Button Function Description
MINUTE MIND-ERTo set the MINUTE MINDER. Hold it for
more than 3 seconds to turn on or turn off
the oven lamp.
www.aeg.com12
Sensor field / Button Function Description
CLOCK To set a clock function.
TEMPERATURE To check the oven temperature or the
temperature of the core temperature sensor (if applicable). Use only while a heating function operates.
PLUS STEAM To turn on the True Fan Cooking PLUS
function.
6.8 Heat-up indicator
When you activate an oven function, the
bars in the display come on one by
7. CLOCK FUNCTIONS
7.1 Clock functions table
Clock function Application
TIME OF DAY To show or change the time of day. You can change the
DURATION To set how long the oven operates. Use only when an
END To set when the oven turns off. Use only when an oven
TIME DELAY Combination of DURATION and END function.
MINUTE MINDER Use to set a countdown time. This function has no ef-
7.2 Setting and changing the time
After the first connection to the mains,
wait until the display shows and
"12:00". "12" flashes.
1. Turn the knob for the temperature
right or left to set the hours.
2. Press
the minutes.
The display shows and the set
hour. "00" flashes.
to confirm and switch to set
one. The bars show that the oven
temperature increases or decreases.
time of day only when the oven is off.
oven function is set.
function is set.
fect on the operation of the oven. You can set the MINUTE MINDER at any time, also if the appliance is off.
3. Press to confirm or the set time of
day will be saved automatically after
5 seconds.
The display shows the new time.
To change the time of day press
again and again until the indicator for the
time of day
flashes in the display.
7.3 Setting the DURATION
1. Set an oven function.
2. Press
starts to flash.
again and again until
ENGLISH 13
3. Turn the knob for the temperature
right or left to set the minutes and
press to confirm. Turn the knob
for the temperature right or left to
set the hours and press to
confirm.
When the set Duration time ends the
signal sounds for 2 minutes. and time
setting flash in the display. The oven
turns off automatically.
4. Press any button or open the oven
door to stop the signal.
5. Turn the knob for the oven functions
to the off position.
7.4 Setting the END
1. Set an oven function.
2. Press
starts to flash.
3. Turn the knob for the temperature
right or left to set the hours and
press to confirm. Turn the knob
for the temperature right or left to
set the minutes and press
confirm.
At the set End time the signal sounds for
2 minutes. and time setting flash in
the display. The oven turns off
automatically.
4. Press any button or open the oven
door to stop the signal.
5. Turn the knob for the oven functions
to the off position.
again and again until
to
7.5 Setting the TIME DELAY function
1. Set an oven function.
2. Press
starts to flash.
3. Turn the knob for the temperature
right or left to set the minutes for
DURATION time and press to
confirm. Turn the knob for the
again and again until
temperature right or left to set the
hours for DURATION time and press
to confirm.
The display shows flashing .
4. Turn the knob for the temperature
right or left to set the hours for END
time and press
the knob for the temperature right or
left to set the minutes for END time
and press to confirm.
Oven turns on automatically later on,
works for the set DURATION time and
stops at the set END time.
At the set END time the signal sounds
for 2 minutes. and time setting flash
in the display. The oven turns off.
5. Press any button or open the oven
door to stop the signal.
6. Turn the knob for the oven functions
to the off position.
to confirm. Turn
7.6 Setting the MINUTE MINDER
Minute minder can be both set when the
oven is turned on and off.
1. Press .
and "00" flash in the display.
2. Turn the knob for the temperature
right or left to set the seconds and
than the minutes.
When the time you set is longer than
60 minutes,
3. Set the hours.
4. The MINUTE MINDER starts
automatically after 5 seconds.
After 90% of the set time the signal
sounds.
5. When the set time ends the signal
sounds for 2 minutes. "00:00" and
flash in the display. Press any
button to stop the signal.
flash in the display.
USING THE ACCESSORIES
8.
WARNING!
Refer to Safety chapters.
8.1 Core temperature sensor
The core temperature sensor measures
temperature inside the food. When the
www.aeg.com14
food is at the set temperature, the oven
turns off.
There are two temperatures to be set:
•
the oven temperature (minimum 120
°C),
• the food core temperature.
CAUTION!
Use only the core
temperature sensor supplied
and the original replacement
parts.
Directions for the best results:
•
Ingredients should be at room
temperature.
• Core temperature sensor cannot be
used for liquid dishes.
• During cooking the core temperature
sensor must remain in the dish and
the plug in the socket.
• Use recommended food core
temperature settings. Refer to "Hints
and tips" chapter.
Every time you put the core
temperature sensor in the
socket, you need to set the
core temperature time
again. You cannot select the
duration and end time.
The aoven calculates the
approximate cooking time, it
may change.
Food categories: meat, poultry and fish
1. Set the oven function and
temperature.
2. Insert the tip of the core temperature
sensor into the centre of meat or fish,
in the thickest part if possible. Make
sure that at least 3/4 of the core
temperature sensor is inside of the
dish.
3. Put the plug of the core temperature
sensor into the socket located in the
front frame of the appliance.
The display shows the core temperature
sensor symbol.
When you use the core temperature
sensor for the first time, the default core
temperature is 60 °C.
While
for the temperature to change the
default core temperature. The display
shows the symbol of the core
temperature sensor and the default core
temperature.
4. Press to save the new core
The new default core temperature is
displayed during the next use of the core
temperature sensor.
When the food is at the set core
temperature, the default core
temperature and flashes. An acoustic
signal sounds for 2 minutes.
5. Press any button or open the oven
6. Remove the core temperature sensor
flashes, you can use the knob
temperature, or wait 10 seconds for
the setting to be saved automatically.
door to stop the acoustic signal.
plug from the socket and remove the
dish from the appliance.
Loading...
