Page 1
EN User Manual
Oven
BE531400KM
Page 2
CONTENTS
1. SAFETY INFORMATION...........................................................................................2
2. SAFETY INSTRUCTIONS.......................................................................................... 4
3. PRODUCT DESCRIPTION........................................................................................ 6
4. BEFORE FIRST USE...................................................................................................7
5. DAILY USE..................................................................................................................7
6. CLOCK FUNCTIONS.............................................................................................. 10
7. USING THE ACCESSORIES....................................................................................11
8. ADDITIONAL FUNCTIONS....................................................................................13
9. HINTS AND TIPS..................................................................................................... 14
10. CARE AND CLEANING........................................................................................ 26
11. TROUBLESHOOTING...........................................................................................28
12. ENERGY EFFICIENCY.......................................................................................... 30
FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you
impeccable performance for many years, with innovative technologies that help
make life simpler features you might not find on ordinary appliances. Please
spend a few minutes reading to get the very best from it.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.aeg.com/webselfservice
Register your product for better service:
www.registeraeg.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.aeg.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the
following data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
1.
SAFETY INFORMATION
Before the installation and use of the appliance,
carefully read the supplied instructions. The
manufacturer is not responsible for any injuries or
www.aeg.com
2
Page 3
damages that are the result of incorrect installation or
usage. Always keep the instructions in a safe and
accessible location for future reference.
1.1 Children and vulnerable people safety
• This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning the use of the appliance in a
safe way and understand the hazards involved.
• Do not let children play with the appliance.
• Keep all packaging away from children and dispose of
it appropriately.
• Keep children and pets away from the appliance when
it operates or when it cools down. Accessible parts are
hot.
• If the appliance has a child safety device, this should
be activated.
• Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
• Children aged 3 years and under must be kept away
from this appliance when it is in operation at all times.
1.2
General Safety
• Only a qualified person must install this appliance and
replace the cable.
• WARNING: The appliance and its accessible parts
become hot during use. Care should be taken to
avoid touching heating elements. Children less than 8
years of age shall be kept away unless continuously
supervised.
• Always use oven gloves to remove or put in
accessories or ovenware.
• Before maintenance cut the power supply.
• Ensure that the appliance is switched off before
replacing the lamp to avoid the possibility of electric
shock.
ENGLISH
3
Page 4
• Do not use a steam cleaner to clean the appliance.
• Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the glass door since they can scratch
the surface, which may result in shattering of the glass.
• If the mains power supply cable is damaged, it must
be replaced by the manufacturer, its Authorised
Service Centre or similarly qualified persons to avoid
an electrical hazard.
• To remove the shelf supports first pull the front of the
shelf support and then the rear end away from the
side walls. Install the shelf supports in the opposite
sequence.
• The means for disconnection must be incorporated in
the fixed wiring in accordance with the wiring rules.
• Only use the core temperature sensor recommended
for this appliance.
2. SAFETY INSTRUCTIONS
2.1 Installation
WARNING!
Only a qualified person must
install this appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Follow the installation instruction
supplied with the appliance.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Do not pull the appliance by the
handle.
• Keep the minimum distance from the
other appliances and units.
• Make sure that the appliance is
installed below and adjacent safe
structures.
• The sides of the appliance must stay
adjacent to appliances or to units with
the same height.
2.2 Electrical connection
WARNING!
Risk of fire and electrical
shock.
• All electrical connections should be
made by a qualified electrician.
• The appliance must be earthed.
• Make sure that the electrical
information on the rating plate agrees
with the power supply. If not, contact
an electrician.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to
the mains plug and to the mains
cable. Should the mains cable need
to be replaced, this must be carried
out by our Authorised Service Centre.
• Do not let mains cables touch or
come near the appliance door,
especially when the door is hot.
• The shock protection of live and
insulated parts must be fastened in
such a way that it cannot be removed
without tools.
www.aeg.com
4
Page 5
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• If the mains socket is loose, do not
connect the mains plug.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
• Use only correct isolation devices: line
protecting cut-outs, fuses (screw type
fuses removed from the holder), earth
leakage trips and contactors.
• The electrical installation must have
an isolation device which lets you
disconnect the appliance from the
mains at all poles. The isolation
device must have a contact opening
width of minimum 3 mm.
• This appliance complies with the
E.E.C. Directives.
2.3 Use
WARNING!
Risk of injury, burns and
electrical shock or explosion.
• This appliance is for household use
only.
• Do not change the specification of
this appliance.
• Make sure that the ventilation
openings are not blocked.
• Do not let the appliance stay
unattended during operation.
• Deactivate the appliance after each
use.
• Be careful when you open the
appliance door while the appliance is
in operation. Hot air can release.
• Do not operate the appliance with
wet hands or when it has contact with
water.
• Do not apply pressure on the open
door.
• Do not use the appliance as a work
surface or as a storage surface.
• Open the appliance door carefully.
The use of ingredients with alcohol
can cause a mixture of alcohol and air.
• Do not let sparks or open flames to
come in contact with the appliance
when you open the door.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
• Do not use microwave function to
preheat the oven.
WARNING!
Risk of damage to the
appliance.
• To prevent damage or discoloration
to the enamel:
– do not put ovenware or other
objects in the appliance directly
on the bottom.
– do not put aluminium foil directly
on the bottom of the appliance.
– do not put water directly into the
hot appliance.
– do not keep moist dishes and
food in the appliance after you
finish the cooking.
– be careful when you remove or
install the accessories.
• Discoloration of the enamel has no
effect on the performance of the
appliance.
• Use a deep pan for moist cakes. Fruit
juices cause stains that can be
permanent.
• This appliance is for cooking
purposes only. It must not be used for
other purposes, for example room
heating.
• Always cook with the oven door
closed.
• If the appliance is installed behind a
furniture panel (e.g. a door) make sure
the door is never closed when the
appliance is in operation. Heat and
moisture can build up behind a
closed furniture panel and cause
subsequent damage to the appliance,
the housing unit or the floor. Do not
close the furniture panel until the
appliance has cooled down
completely after use.
2.4 Care and cleaning
WARNING!
Risk of injury, fire, or damage
to the appliance.
• Before maintenance, deactivate the
appliance and disconnect the mains
plug from the mains socket.
ENGLISH
5
Page 6
• Make sure the appliance is cold.
There is the risk that the glass panels
can break.
• Replace immediately the door glass
panels when they are damaged.
Contact the Authorised Service
Centre.
• Be careful when you remove the door
from the appliance. The door is
heavy!
• Clean regularly the appliance to
prevent the deterioration of the
surface material.
• Clean the appliance with a moist soft
cloth. Only use neutral detergents. Do
not use any abrasive products,
abrasive cleaning pads, solvents or
metal objects.
• If you use an oven spray, obey the
safety instructions on the packaging.
• Do not clean the catalytic enamel (if
applicable) with any kind of
detergent.
2.5 Internal light
• The type of light bulb or halogen
lamp used for this appliance is only
for household appliances. Do not use
it for house lighting.
WARNING!
Risk of electrical shock.
• Before replacing the lamp, disconnect
the appliance from the power supply.
• Only use lamps with the same
specifications.
2.6 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains supply.
• Cut off the mains electrical cable
close to the appliance and dispose of
it.
• Remove the door catch to prevent
children or pets from becoming
trapped in the appliance.
2.7 Service
• To repair the appliance contact an
Authorised Service Centre.
• Use original spare parts only.
3. PRODUCT DESCRIPTION
3.1 General overview
12
8
7
10
5
4
3
2
1
4 6321 5
9
11
1
Control panel
2
Knob for the oven functions
3
Power lamp / symbol
4
Electronic programmer
5
Knob for the temperature
6
Temperature indicator / symbol
7
Socket for the core temperature
sensor
8
Heating element
9
Lamp
10
Fan
11
Shelf support, removable
12
Shelf positions
www.aeg.com
6
Page 7
3.2 Accessories
Nonstick wire shelf
For cookware, cake tins, roasts.
Grill- / Roasting pan
To bake and roast or as a pan to collect
fat.
Trivet
For roasting and grilling.
Use the trivet only with the
Grill- / Roasting pan.
Core temperature sensor
To measure how far the food is cooked.
Telescopic runners
For shelves and trays.
4. BEFORE FIRST USE
WARNING!
Refer to Safety chapters.
To set the Time of day refer
to "Clock functions"
chapter.
4.1 Initial Cleaning
Remove all accessories and removable
shelf supports from the appliance.
Refer to "Care and
cleaning" chapter.
Clean the appliance and the accessories
before first use.
Put the accessories and the removable
shelf supports back to their initial
position.
5. DAILY USE
WARNING!
Refer to Safety chapters.
ENGLISH 7
Page 8
5.1 Retractable knobs
To use the appliance, press the control
knob. The control knob comes out.
5.2 Activating and
deactivating the appliance
It depends on the model if
your appliance has lamps,
knob symbols or
indicators:
• The lamp comes on when
the appliance operates.
• The symbol shows
whether the knob
controls the oven
functions or the
temperature.
• The indicator comes on
when the oven heats up.
1. Turn the knob for the oven functions
to select an oven function.
2. Turn the knob for the temperature to
select a temperature.
3. To deactivate the appliance turn the
knobs for the oven functions and
temperature to the off position.
5.3 Oven functions
Oven function Application
Off position The appliance is off.
Fast Heat Up To decrease the heat-up time.
True Fan Cooking
To bake on up to three shelf positions at the same time
and to dry food. Set the temperature 20 - 40 °C lower
than for Top / Bottom Heat.
Pizza Setting To bake food on one shelf position for a more intensive
browning and a crispy bottom. Set the temperature 20
- 40 °C lower than for Top / Bottom Heat.
Top / Bottom
Heat
To bake and roast food on one shelf position.
Bottom Heat To bake cakes with crispy bottom and to preserve food.
Defrost This function can be used for defrosting frozen foods,
such as vegetables and fruits. The defrosting time depends on the amount and size of the frozen food.
Grilling To grill flat food and to toast bread.
www.aeg.com8
Page 9
Oven function Application
Fast Grilling To grill flat food in large quantities and to toast bread.
Turbo Grilling To roast larger meat joints or poultry with bones on
one shelf position. Also to make gratins and to brown.
The lamp may automatically
deactivate at a temperature
below 60 °C during some
oven functions.
5.4 Fast heat up function
The fast heat up function decreases the
heat up time.
Do not put food in the oven
when the Fast heat up
function operates.
1. Set the fast heat up function. Refer to
the Oven functions table.
2. Turn the knob for the temperature to
set the temperature.
An acoustic signal sounds when the
appliance is at the set temperature.
The fast heat up function
does not deactivate after the
acoustic signal. You must
deactivate the function
manually.
3. Set an oven function.
5.5 Display
A B C
D
EFG
A. Timer
B. Heat-up and residual heat indicator
C. Water drawer (selected models only)
D. Core temperature sensor (selected
models only)
E. Door lock (selected models only)
F. Hours / minutes
G. Clock functions
5.6 Buttons
Button Function Description
CLOCK To set a clock function.
MINUS To set the time.
MINUTE MINDER To set the MINUTE MINDER. Hold the
button for more than 3 seconds to activate or deactivate the oven lamp.
PLUS To set the time.
TEMPERATURE To check the oven temperature or the
temperature of the core temperature sensor (if applicable). Use only while an oven
function is in operation.
ENGLISH 9
Page 10
5.7 Heat-up indicator
When you activate an oven function, the
bars in the display come on one by
one. The bars show that the oven
temperature increases or decreases.
6. CLOCK FUNCTIONS
6.1 Clock functions table
Clock function Application
TIME OF DAY To show or change the time of day. You can change the
time of day only when the appliance is off.
DURATION To set how long the appliance operates. Use only when
an oven function is set.
END To set when the appliance deactivates. Use only when
an oven function is set.
TIME DELAY To combine DURATION and END function.
MINUTE MINDER Use to set a countdown time. This function has no ef-
fect on the operation of the appliance. You can set the
MINUTE MINDER at any time, also if the appliance is
off.
00:00 COUNT UP TIMER If you do not set any other clock function the COUNT
UP TIMER automatically monitor how long the appliance operates. It is on immediately when the oven
starts to heat.
The Count Up Timer cannot be used with the functions:
DURATION, END, core temperature sensor.
6.2 Setting and changing the
time
After the first connection to the mains,
wait until the display shows and
"12:00". "12" flashes.
1. Press or to set the hours.
2. Press to confirm and switch to set
the minutes.
The display shows and the set
hour. "00" flashes.
3.
Press
or to set the current
minutes.
4. Press to confirm or the set time of
day will be saved automatically after
5 seconds.
The display shows the new time.
To change the time of day press
again and again until the indicator for the
time of day flashes in the display.
6.3 Setting the DURATION
1. Set an oven function.
2. Press again and again until
starts to flash.
3. Press or to set the minutes and
the hours for DURATION time.
4. Press
to confirm.
When the time ends an acoustic signal
sounds for 2 minutes. and time
setting flash in the display. The appliance
deactivates automatically.
5. Press any button to stop the acoustic
signal.
www.aeg.com
10
Page 11
6. Turn the knob for the oven functions
to the off position.
6.4 Setting the END
1. Set an oven function.
2. Press again and again until
starts to flash.
3. Press
or to set the hours and
the minutes for END time.
4. Press to confirm.
At the set time an acoustic signal sounds
for 2 minutes. and time setting flash
in the display. The appliance deactivates
automatically.
5. Press any button to stop the acoustic
signal.
6. Turn the knob for the oven functions
to the off position.
6.5 Setting the TIME DELAY
function
1. Set an oven function.
2. Press
again and again until
starts to flash.
3. Press or to set the minutes and
the hours for DURATION time.
4. Press
to confirm. The display
shows flashing .
5. Press
or to set the hours and
the minutes for END time.
6. Press to confirm.
Appliance turns on automatically later
on, works for the set DURATION time
and stops at the set END time. At the set
time an acoustic signal sounds for 2
minutes. and time setting flash in the
display. The appliance deactivates.
7. Press any button to stop the acoustic
signal.
8. Turn the knob for the oven functions
to the off position.
6.6 Setting the MINUTE
MINDER
1. Press .
and "00" flash in the display.
2. Press or to set the MINUTE
MINDER.
First you set the seconds, then the
minutes.
When the time you set is longer than
60 minutes, flash in the display.
3. Set the hours.
4. The MINUTE MINDER starts
automatically after 5 seconds.
After 90% of the set time, an acoustic
signal sounds.
5. When the set time ends, an acoustic
signal sounds for 2 minutes. "00:00"
and flash in the display. Press any
button to stop the acoustic signal.
6.7 COUNT UP TIMER
To reset the Count Up Timer, press and
hold and . The timer starts to count
up again.
7.
USING THE ACCESSORIES
WARNING!
Refer to Safety chapters.
7.1 Inserting the accessories
Wire shelf:
Push the shelf between the guide bars of
the shelf support and make sure that the
feet point down.
Deep pan:
ENGLISH 11
Page 12
Push the deep pan between the guide
bars of the shelf support.
Wire shelf and the deep pan together:
Push the deep pan between the guide
bars of the shelf support and the wire
shelf on the guide bars above and make
sure that the feet point down.
Small indentation at the top
increase safety. The
indentations are also anti-tip
devices. The high rim
around the shelf prevents
cookware from slipping of
the shelf.
7.2 Telescopic runners inserting the accessories
With the telescopic runners you can put
in and remove the shelves more easily.
CAUTION!
Do not clean the telescopic
runners in the dishwasher.
Do not lubricate the
telescopic runners.
CAUTION!
Make sure you push back
the telescopic runners fully
in the appliance before you
close the oven door.
Wire shelf:
Put the wire shelf on the telescopic
runners so that the feet point
downwards.
The high rim around the wire
shelf is a special device to
prevent the cookware from
slipping.
Deep pan:
Put the deep pan on the telescopic
runners.
Wire shelf and deep pan together:
Place the wire shelf and the deep pan
together on the telescopic runner.
www.aeg.com
12
Page 13
7.3 Trivet and Grill- / Roasting
pan
WARNING!
Be careful when you remove
the accessories from a hot
appliance. There is a risk of
burns.
You can use the trivet to roast larger
pieces of meat or poultry on one shelf
position.
1. Put the trivet into the deep pan so
that the supports of the wire shelf
point up.
2. Put the deep pan into the oven on
the necessary shelf position.
You can use the trivet to grill flat dishes
in large quantities and to toast.
1. Put the trivet into the deep pan so
that the supports of the wire shelf
point down.
2. Put the deep pan into the oven on
the necessary shelf position.
8. ADDITIONAL FUNCTIONS
8.1 Using the Child Lock
When the Child Lock is on, the appliance
cannot be activated accidentally.
1. Ensure the knob for the oven
functions is in the off position.
2. Press and hold and at the
same time for 2 seconds.
An acoustic signal sounds. SAFE comes
on in the display.
To deactivate the Child Lock, repeat step
2.
8.2 Residual heat indicator
When you deactivate the appliance, the
display shows the residual heat indicator
if the temperature in the oven is more
than 40 °C. Turn the knob for the
temperature left or right to show the
oven temperature.
8.3 Automatic Switch-off
For safety reasons the appliance
deactivates automatically after some
time if an oven function operates and
you do not change any settings.
Temperature (°C) Switch-off time (h)
30 - 115 12.5
120 - 195 8.5
200 - 245 5.5
250 - maximum 1.5
After an automatic switch-off, press any
button to operate the appliance again.
The Automatic switch-off
does not work with the
functions: core temperature
sensor, Light, Duration, End.
ENGLISH 13
Page 14
8.4 Cooling fan
When the appliance operates, the
cooling fan activates automatically to
keep the surfaces of the appliance cool.
If you deactivate the appliance, the
cooling fan can continue to operate until
the appliance cools down.
9. HINTS AND TIPS
WARNING!
Refer to Safety chapters.
The temperature and baking
times in the tables are
guidelines only. They
depend on the recipes and
the quality and quantity of
the ingredients used.
9.1 Inner side of the door
In some models, on the inner side of
the door you can find:
• the numbers of the shelf positions.
• information about the oven functions,
recommended shelf positions and
temperatures for typical dishes.
9.2 Baking
• Your oven may bake or roast
differently to the appliance you had
before. Adapt your usual settings
(temperature, cooking times) and
shelf positions to the values in the
tables.
• The manufacturer recommends that
you use the lower temperature the
first time.
• If you cannot find the settings for a
special recipe, look for the one that is
almost the same.
• You can extend baking times by 10 –
15 minutes if you bake cakes on more
than one shelf position.
• Cakes and pastries at different
heights do not always brown equally
at first. If this occurs, do not change
the temperature setting. The
differences equalize during the
baking procedure.
• With longer baking times, you can
deactivate the oven approximately 10
minutes before the end of the baking
time and then use the residual heat.
When you cook frozen food, the trays in
the oven can twist during baking. When
the trays become cold again, the
distortions are gone.
9.3 Tips on baking
Baking results Possible cause Remedy
The bottom of the cake is
not browned sufficiently.
The shelf position is incorrect.
Put the cake on a lower
shelf.
The cake sinks and becomes
soggy, lumpy or streaky.
The oven temperature is too
high.
The next time you bake, set
a slightly lower oven temperature.
The cake sinks and becomes
soggy, lumpy or streaky.
The baking time is too short. Set a longer baking time.
You cannot decrease baking times by setting higher
temperatures.
The cake sinks and becomes
soggy, lumpy or streaky.
There is too much liquid in
the mixture.
Use less liquid. Be careful
with mixing times, especially
if you use a mixing machine.
www.aeg.com14
Page 15
Baking results Possible cause Remedy
The cake is too dry. The oven temperature is too
low.
The next time you bake, set
a higher oven temperature.
The cake is too dry. The baking time is too long. The next time you bake, set
a shorter baking time.
The cake browns unevenly. The oven temperature is too
high and the baking time is
too short.
Set a lower oven temperature and a longer baking
time.
The cake browns unevenly. The mixture is unevenly dis-
tributed.
Spread the mixture evenly
on the baking tray.
The cake is not ready in the
baking time given.
The oven temperature is too
low.
The next time you bake, set
a slightly higher oven temperature.
9.4 Baking on one level:
Baking in tins
Food Function Temperature
(°C)
Time (min) Shelf position
Ring cake / Brioche
True Fan Cooking
150 - 160 50 - 70 1
Madeira cake /
Fruit cakes
True Fan Cooking
140 - 160 70 - 90 1
Fatless sponge
cake / Fatless
sponge cake
True Fan Cooking
140 - 150 35 - 50 2
Fatless sponge
cake / Fatless
sponge cake
Top / Bottom
Heat
160 35 - 50 2
Flan base - short
pastry
True Fan Cooking
170 - 180
1)
10 - 25 2
Flan base sponge mixture
True Fan Cooking
150 - 170 20 - 25 2
Apple pie / Apple pie (2 tins
Ø20 cm, diagonally off set)
True Fan Cooking
160 60 - 90 2
Apple pie / Apple pie (2 tins
Ø20 cm, diagonally off set)
Top / Bottom
Heat
180 70 - 90 1
ENGLISH 15
Page 16
Food Function Temperature
(°C)
Time (min) Shelf position
Cheesecake Top / Bottom
Heat
170 - 190 60 - 90 1
1)
Preheat the oven.
Cakes / pastries / breads on baking trays
Food Function Temperature
(°C)
Time (min) Shelf position
Plaited bread /
Bread crown
Top / Bottom
Heat
170 - 190 30 - 40 3
Christmas stollen
Top / Bottom
Heat
160 - 180
1)
50 - 70 2
Bread (rye
bread):
1. First part of
baking procedure.
2. Second part
of baking
procedure.
Top / Bottom
Heat
1. 230
1)
2. 160 - 180
1. 20
2. 30 - 60
1
Cream puffs /
Eclairs
Top / Bottom
Heat
190 - 210
1)
20 - 35 3
Swiss roll Top / Bottom
Heat
180 - 200
1)
10 - 20 3
Cake with crumble topping (dry)
True Fan Cooking
150 - 160 20 - 40 3
Buttered almond cake /
Sugar cakes
Top / Bottom
Heat
190 - 210
1)
20 - 30 3
Fruit flans (made
with yeast
dough / sponge
mixture)
2)
True Fan Cooking
150 35 - 55 3
Fruit flans (made
with yeast
dough / sponge
mixture)
2)
Top / Bottom
Heat
170 35 - 55 3
Fruit flans made
with short pastry
True Fan Cooking
160 - 170 40 - 80 3
www.aeg.com16
Page 17
Food Function Temperature
(°C)
Time (min) Shelf position
Yeast cakes with
delicate toppings (e.g.
quark, cream,
custard)
Top / Bottom
Heat
160 - 180
1)
40 - 80 3
1)
Preheat the oven.
2)
Use a deep pan.
Biscuits
Food Function Temperature
(°C)
Time (min) Shelf position
Short pastry biscuits
True Fan Cooking
150 - 160 10 - 20 3
Short bread /
Short bread /
Pastry stripes
True Fan Cooking
140 20 - 35 3
Short bread /
Short bread /
Pastry stripes
Top / Bottom
Heat
160
1)
20 - 30 3
Biscuits made
with sponge
mixture
True Fan Cooking
150 - 160 15 - 20 3
Pastries made
with egg white /
Meringues
True Fan Cooking
80 - 100 120 - 150 3
Macaroons True Fan Cook-
ing
100 - 120 30 - 50 3
Biscuits made
with yeast
dough
True Fan Cooking
150 - 160 20 - 40 3
Puff pastries True Fan Cook-
ing
170 - 180
1)
20 - 30 3
Rolls True Fan Cook-
ing
160
1)
10 - 25 3
Rolls Top / Bottom
Heat
190 - 210
1)
10 - 25 3
Small cakes /
Small cakes (20
per tray)
True Fan Cooking
150
1)
20 - 35 3
ENGLISH 17
Page 18
Food Function Temperature
(°C)
Time (min) Shelf position
Small cakes /
Small cakes (20
per tray)
Top / Bottom
Heat
170
1)
20 - 30 3
1)
Preheat the oven.
9.5 Bakes and gratins
Food Function Temperature
(°C)
Time (min) Shelf position
Pasta bake Top / Bottom
Heat
180 - 200 45 - 60 1
Lasagne Top / Bottom
Heat
180 - 200 25 - 40 1
Vegetables au
gratin
1)
Turbo Grilling 160 - 170 15 - 30 1
Baguettes topped with melted
cheese
True Fan Cooking
160 - 170 15 - 30 1
Sweet bakes Top / Bottom
Heat
180 - 200 40 - 60 1
Fish bakes Top / Bottom
Heat
180 - 200 30 - 60 1
Stuffed vegetables
True Fan Cooking
160 - 170 30 - 60 1
1)
Preheat the oven.
9.6 Multilevel Baking
Use the function True Fan Cooking.
Cakes / pastries / breads on baking trays
Food Temperature
(°C)
Time (min) Shelf position
2 positions 3 positions
Cream puffs /
Eclairs
160 - 180
1)
25 - 45 1 / 4 -
Dry streusel
cake
150 - 160 30 - 45 1 / 4 -
1)
Preheat the oven.
www.aeg.com18
Page 19
Biscuits / small cakes / small cakes / pastries / rolls
Food Temperature
(°C)
Time (min) Shelf position
2 positions 3 positions
Short pastry biscuits
150 - 160 20 - 40 1 / 4 1 / 3 / 5
Short bread /
Short bread /
Pastry Stripes
140 25 - 45 1 / 4 1 / 3 / 5
Biscuits made
with sponge
mixture
160 - 170 25 - 40 1 / 4 -
Biscuits made
with egg white,
meringues
80 - 100 130 - 170 1 / 4 -
Macaroons 100 - 120 40 - 80 1 / 4 -
Biscuits made
with yeast
dough
160 - 170 30 - 60 1 / 4 -
Puff pastries
170 - 180
1)
30 - 50 1 / 4 -
Rolls 180 20 - 30 1 / 4 -
Small cakes /
Small cakes (20
per tray)
150
1)
23 - 40 1 / 4 -
1)
Preheat the oven.
9.7 Pizza Setting
Food Temperature (°C) Time (min) Shelf position
Pizza (thin crust)
200 - 230
1)2)
15 - 20 2
Pizza (with a lot of
topping)
180 - 200 20 - 30 2
Tarts 180 - 200 40 - 55 1
Spinach flan 160 - 180 45 - 60 1
Quiche Lorraine 170 - 190 45 - 55 1
Swiss Flan 170 - 190 45 - 55 1
Cheesecake 140 - 160 60 - 90 1
Apple cake, covered 150 - 170 50 - 60 1
Vegetable pie 160 - 180 50 - 60 1
ENGLISH 19
Page 20
Food Temperature (°C) Time (min) Shelf position
Unleavened bread
230 - 250
1)
10 - 20 2
Puff pastry flan
160 - 180
1)
45 - 55 2
Flammekuchen (Pizza-like dish from Alsace)
230 - 250
1)
12 - 20 2
Piroggen (Russian
version of calzone)
180 - 200
1)
15 - 25 2
1)
Preheat the oven.
2)
Use a deep pan.
9.8 Roasting
• Use heat-resistant ovenware to roast
(refer to the instructions of the
manufacturer).
• You can roast large roasting joints
directly in the deep pan (if present) or
on the wire shelf above the deep pan.
• Roast lean meats in the roasting tin
with the lid. This keeps the meat more
succulent.
• All types of meat that can be browned
or have crackling can be roasted in
the roasting tin without the lid.
• We recommend that you cook meat
and fish weighing 1 kg and above in
the appliance.
• To prevent the meat juices or fat from
burning onto the pan, put some liquid
into the deep pan.
• If necessary, turn the roast (after 1/2 2/3 of the cooking time).
• Baste large roasts and poultry with
their juices several times during
roasting. This gives better roasting
results.
• You can deactivate the appliance
approximately 10 minutes before the
end of the roasting time, and use the
residual heat.
9.9 Roasting tables
Beef
Food Quantity Function Tempera-
ture (°C)
Time (min) Shelf posi-
tion
Pot roast 1 - 1.5 kg Top / Bot-
tom Heat
230 120 - 150 1
Roast beef or fillet: rare
per cm of
thickness
Turbo Grilling
190 - 200
1)
5 - 6 1
Roast beef or fillet: medium
per cm of
thickness
Turbo Grilling
180 - 190
1)
6 - 8 1
Roast beef or fillet: well done
per cm of
thickness
Turbo Grilling
170 - 180
1)
8 - 10 1
1)
Preheat the oven.
www.aeg.com20
Page 21
Pork
Food Quantity
(kg)
Function Tempera-
ture (°C)
Time (min) Shelf posi-
tion
Shoulder /
Neck / Ham
joint
1 - 1.5 Turbo Grill-
ing
160 - 180 90 - 120 1
Chop / Spare
rib
1 - 1.5 Turbo Grill-
ing
170 - 180 60 - 90 1
Meatloaf 0.75 - 1 Turbo Grill-
ing
160 - 170 50 - 60 1
Pork knuckle
(precooked)
0.75 - 1 Turbo Grilling
150 - 170 90 - 120 1
Veal
Food Quantity
(kg)
Function Temperature
(°C)
Time (min) Shelf posi-
tion
Roast veal 1 Turbo Grill-
ing
160 - 180 90 - 120 1
Knuckle of
veal
1.5 - 2 Turbo Grilling
160 - 180 120 - 150 1
Lamb
Food Quantity
(kg)
Function Temperature
(°C)
Time (min) Shelf posi-
tion
Leg of lamb /
Roast lamb
1 - 1.5 Turbo Grill-
ing
150 - 170 100 - 120 1
Saddle of
lamb
1 - 1.5 Turbo Grill-
ing
160 - 180 40 - 60 1
Game
Food Quantity
(kg)
Function Temperature
(°C)
Time (min) Shelf posi-
tion
Saddle / Leg
of hare
up to 1 Top / Bottom
Heat
230
1)
30 - 40 1
Saddle of
venison
1.5 - 2 Top / Bottom
Heat
210 - 220 35 - 40 1
Haunch of
venison
1.5 - 2 Top / Bottom
Heat
180 - 200 60 - 90 1
1)
Preheat the oven.
ENGLISH 21
Page 22
Poultry
Food Quantity
(kg)
Function Temperature
(°C)
Time (min) Shelf posi-
tion
Poultry portions
0.2 - 0.25
each
Turbo Grilling
200 - 220 30 - 50 1
Half chicken 0.4 - 0.5 each Turbo Grill-
ing
190 - 210 35 - 50 1
Chicken,
poulard
1 - 1.5 Turbo Grill-
ing
190 - 210 50 - 70 1
Duck 1.5 - 2 Turbo Grill-
ing
180 - 200 80 - 100 1
Goose 3.5 - 5 Turbo Grill-
ing
160 - 180 120 - 180 1
Turkey 2.5 - 3.5 Turbo Grill-
ing
160 - 180 120 - 150 1
Turkey 4 - 6 Turbo Grill-
ing
140 - 160 150 - 240 1
Fish (steamed)
Food Quantity
(kg)
Function Temperature
(°C)
Time (min) Shelf posi-
tion
Whole fish 1 - 1.5 Top / Bottom
Heat
210 - 220 40 - 60 1
9.10 Grilling
• Always grill with the maximum
temperature setting.
• Set the shelf into the shelf position as
recommended in the grilling table.
• Always set the pan to collect the fat
into the first shelf position.
• Grill only flat pieces of meat or fish.
• Always preheat the empty oven with
the grill functions for 5 minutes.
CAUTION!
Always grill with the oven
door closed.
Grilling
Food Temperature
(°C)
Time (min) Shelf position
1st side 2nd side
Roast beef 210 - 230 30 - 40 30 - 40 2
Filet of beef 230 20 - 30 20 - 30 3
Back of pork 210 - 230 30 - 40 30 - 40 2
Back of veal 210 - 230 30 - 40 30 - 40 2
Back of lamb 210 - 230 25 - 35 20 - 25 3
www.aeg.com22
Page 23
Food Temperature
(°C)
Time (min) Shelf position
1st side 2nd side
Whole Fish, 500
- 1000 g
210 - 230 15 - 30 15 - 30 3 / 4
Fast Grilling
Food Time (min) Shelf position
1st side 2nd side
Burgers / Burgers 8 - 10 6 - 8 4
Pork fillet 10 - 12 6 - 10 4
Sausages 10 - 12 6 - 8 4
Fillet / Veal steaks 7 - 10 6 - 8 4
Toast / Toast 1 - 3 1 - 3 5
Toast with topping 6 - 8 - 4
9.11 Frozen foods
Use the function True Fan Cooking.
Food Temperature (°C) Time (min) Shelf position
Pizza, frozen 200 - 220 15 - 25 2
Pizza American, frozen
190 - 210 20 - 25 2
Pizza, chilled 210 - 230 13 - 25 2
Pizza Snacks, frozen 180 - 200 15 - 30 2
French Fries, thin 200 - 220 20 - 30 3
French Fries, thick 200 - 220 25 - 35 3
Wedges / Croquettes
220 - 230 20 - 35 3
Hash Browns 210 - 230 20 - 30 3
Lasagne / Cannelloni, fresh
170 - 190 35 - 45 2
Lasagne / Cannelloni, frozen
160 - 180 40 - 60 2
Oven baked cheese 170 - 190 20 - 30 3
Chicken Wings 190 - 210 20 - 30 2
ENGLISH 23
Page 24
Frozen ready meals
Food Function Temperature
(°C)
Time (min) Shelf position
Frozen pizza Top / Bottom
Heat
as per manufacturer’s instructions
as per manufacturer’s instructions
3
French fries
1)
(300 - 600 g)
Top / Bottom
Heat or Turbo
Grilling
200 - 220 as per manufac-
turer’s instructions
3
Baguettes Top / Bottom
Heat
as per manufacturer’s instructions
as per manufacturer’s instructions
3
Fruit flans Top / Bottom
Heat
as per manufacturer’s instructions
as per manufacturer’s instructions
3
1)
Turn the French fries 2 or 3 times during cooking.
9.12 Defrost
• Remove the food packaging and put
the food on a plate.
• Use the first shelf position from the
bottom.
• Do not cover the food with a bowl or
a plate, as this can extend the defrost
time.
Food Quantity
(kg)
Defrosting
time (min)
Further defrosting time
(min)
Comments
Chicken 1 100 - 140 20 - 30 Put the chicken on an upturned
saucer in a big plate. Turn halfway
through.
Meat 1 100 - 140 20 - 30 Turn halfway through.
Meat 0.5 90 - 120 20 - 30 Turn halfway through.
Trout 0.15 25 - 35 10 - 15 -
Strawberries
0.3 30 - 40 10 - 20 -
Butter 0.25 30 - 40 10 - 15 -
Cream 2 x 0.2 80 - 100 10 - 15 Whip the cream when still slightly
frozen in places.
Gateau 1.4 60 60 -
9.13 Preserving - Bottom Heat
• Use only preserve jars of the same
dimensions available on the market.
• Do not use jars with twist-off and
bayonet type lids or metal tins.
• Use the first shelf from the bottom for
this function.
www.aeg.com24
Page 25
• Put no more than six one-litre
preserve jars on the baking tray.
• Fill the jars equally and close with a
clamp.
• The jars cannot touch each other.
• Put approximately 1/2 litre of water
into the baking tray to give sufficient
moisture in the oven.
• When the liquid in the jars starts to
simmer (after approximately 35 - 60
minutes with one-litre jars), stop the
oven or decrease the temperature to
100 °C (see the table).
Soft fruit
Food Temperature (°C) Cooking time until
simmering (min)
Continue to cook at
100 °C (min)
Strawberries / Blueberries / Raspberries / Ripe gooseberries
160 - 170 35 - 45 -
Stone fruit
Food Temperature (°C) Cooking time until
simmering (min)
Continue to cook at
100 °C (min)
Pears / Quinces /
Plums
160 - 170 35 - 45 10 - 15
Vegetables
Food Temperature (°C) Cooking time until
simmering (min)
Continue to cook at
100 °C (min)
Carrots
1)
160 - 170 50 - 60 5 - 10
Cucumbers 160 - 170 50 - 60 -
Mixed pickles 160 - 170 50 - 60 5 - 10
Kohlrabi / Peas / Asparagus
160 - 170 50 - 60 15 - 20
1)
Leave standing in the oven after it is deactivated.
9.14 Drying - True Fan
Cooking
• Cover trays with grease proof paper
or baking parchment.
• For a better result, stop the oven
halfway through the drying time, open
the door and let it cool down for one
night to complete the drying.
Vegetables
Food Temperature
(°C)
Time (h) Shelf position
1 position 2 positions
Beans 60 - 70 6 - 8 3 1 / 4
Peppers 60 - 70 5 - 6 3 1 / 4
ENGLISH 25
Page 26
Food Temperature
(°C)
Time (h) Shelf position
1 position 2 positions
Vegetables for
sour
60 - 70 5 - 6 3 1 / 4
Mushrooms 50 - 60 6 - 8 3 1 / 4
Herbs 40 - 50 2 - 3 3 1 / 4
Fruit
Food Temperature
(°C)
Time (h) Shelf position
1 position 2 positions
Plums 60 - 70 8 - 10 3 1 / 4
Apricots 60 - 70 8 - 10 3 1 / 4
Apple slices 60 - 70 6 - 8 3 1 / 4
Pears 60 - 70 6 - 9 3 1 / 4
10. CARE AND CLEANING
WARNING!
Refer to Safety chapters.
10.1 Notes on cleaning
• Clean the front of the appliance with a
soft cloth with warm water and a
cleaning agent.
• To clean metal surfaces, use a
dedicated cleaning agent.
• Clean the appliance interior after
each use. Fat accumulation or other
food remains may result in a fire. The
risk is higher for the grill pan.
• Clean stubborn dirt with a special
oven cleaner.
• Clean all accessories after each use
and let them dry. Use a soft cloth with
warm water and a cleaning agent.
• If you have nonstick accessories, do
not clean them using aggressive
agents, sharp-edged objects or a
dishwasher. It can cause damage to
the nonstick coating.
10.2 Removing the shelf
supports
To clean the oven, remove the shelf
supports.
1. Pull the front of the shelf support
away from the side wall.
2. Pull the rear end of the shelf support
away from the side wall and remove
it.
2
1
www.aeg.com
26
Page 27
Install the shelf supports in the opposite
sequence.
The retaining pins on the
telescopic runners must
point to the front.
10.3 Oven ceiling
WARNING!
Deactivate the appliance
before you remove the
heating element. Make sure
that the appliance is cold.
There is a risk of burns.
Remove the shelf supports.
You can fold down the heating element
on the oven ceiling to clean the oven
ceiling easily.
1. Hold the heating element with two
hands at the front.
2. Pull it forwards against the spring
pressure and out along the supports
on the two sides.
The heating element folds down.
3. Clean the oven ceiling.
4. Install the heating element in the
opposite sequence.
Install the heating element
correctly above the supports
on the inner walls of the
appliance.
5. Install the shelf supports.
10.4 Removing and installing
the door
You can remove the door and the
internal glass panels to clean it. The
number of glass panels is different for
different models.
WARNING!
Be careful when you remove
the door from the appliance.
The door is heavy.
1. Open the door fully.
2. Fully press the clamping levers (A) on
the two door hinges.
A
A
3. Close the oven door to the first
opening position (approximately 70°
angle).
4. Hold the door with one hand on each
side and pull it away from the
appliance at an upwards angle.
5. Put the door with the outer side
down on a soft cloth on a stable
surface. This is to prevent scratches.
6. Hold the door trim (B) on the top
edge of the door at the two sides
and push inwards to release the clip
seal.
1
2
B
7. Pull the door trim to the front to
remove it.
8. Hold the door glass panels on their
top edge one by one and pull them
up out of the guide.
ENGLISH
27
Page 28
9. Clean the glass panel with water and
soap. Dry the glass panel carefully.
When the cleaning is completed, install
the glass panels and the door. Do the
above steps in the opposite sequence.
Install the smaller panel first, then the
larger.
10.5 Replacing the lamp
Put a cloth on the bottom of the interior
of the appliance. It prevents damage to
the lamp glass cover and the cavity.
WARNING!
Danger of electrocution!
Disconnect the fuse before
you replace the lamp.
The lamp and the lamp glass
cover can be hot.
1. Deactivate the appliance.
2. Remove the fuses from the fuse box
or deactivate the circuit breaker.
The top lamp
1. Turn the lamp glass cover
counterclockwise to remove it.
2. Clean the glass cover.
3. Replace the lamp with a suitable 300
°C heat-resistant lamp.
4. Install the glass cover.
The side lamp
1. Remove the left shelf support to get
access to the lamp.
2. Use a narrow, blunt object (e.g. a
teaspoon) to remove the glass cover.
3. Clean the glass cover.
4. Replace the lamp with a suitable 300
°C heat-resistant lamp.
5. Install the glass cover.
6. Install the left shelf support.
11.
TROUBLESHOOTING
WARNING!
Refer to Safety chapters.
11.1 What to do if...
Problem Possible cause Remedy
You cannot activate or operate the oven.
The oven is not connected
to an electrical supply or it is
connected incorrectly.
Check if the oven is correctly
connected to the electrical
supply (refer to the connection diagram if available).
The oven does not heat up. The oven is deactivated. Activate the oven.
The oven does not heat up. The clock is not set. Set the clock.
www.aeg.com28
Page 29
Problem Possible cause Remedy
The oven does not heat up. The necessary settings are
not set.
Make sure that the settings
are correct.
The oven does not heat up. The automatic switch-off is
activated.
Refer to "Automatic switchoff".
The oven does not heat up. The Child Lock is on. Refer to "Using the Child
Lock".
The oven does not heat up. The fuse is blown. Make sure that the fuse is
the cause of the malfunction.
If the fuse is blown again
and again, contact a qualified electrician.
The lamp does not operate. The lamp is defective. Replace the lamp.
The core temperature sensor
does not operate.
The plug of the core temperature sensor is not correctly installed into the socket.
Put the plug of the core temperature sensor as far as
possible into the socket.
It takes too long to cook the
dishes or they cook too
quickly.
The temperature is too low
or too high.
Adjust the temperature if
necessary. Follow the advice
in the user manual.
Steam and condensation
settle on the food and in the
cavity of the oven.
You left the dish in the oven
for too long.
Do not leave the dishes in
the oven for longer than 15 20 minutes after the cooking
process ends.
The display shows "C2". You want to start the Defrost
function, but you did not remove the core temperature
sensor plug from the socket.
Remove the core temperature sensor plug from the
socket.
The display shows an error
code that is not in this table.
There is an electrical fault. • Deactivate the oven with
the house fuse or the
safety switch in the fuse
box and activate it again.
• If the display shows the
error code again, contact
the Customer Care Department.
11.2 Service data
If you cannot find a solution to the
problem yourself, contact your dealer or
an Authorised Service Centre.
The necessary data for the service centre
is on the rating plate. The rating plate is
on the front frame of the appliance
cavity. Do not remove the rating plate
from the appliance cavity.
ENGLISH 29
Page 30
We recommend that you write the data here:
Model (MOD.) .........................................
Product number (PNC) .........................................
Serial number (S.N.) .........................................
12. ENERGY EFFICIENCY
12.1 Product Fiche and information according to EU 65-66/2014
Supplier's name AEG
Model identification BE531400KM
Energy Efficiency Index 103.5
Energy efficiency class A
Energy consumption with a standard load, conventional mode
0.99 kWh/cycle
Energy consumption with a standard load, fan-forced
mode
0.88 kWh/cycle
Number of cavities 1
Heat source Electricity
Volume 71 l
Type of oven Built-In Oven
Mass 36.5 kg
EN 60350-1 - Household electric cooking
appliances - Part 1: Ranges, ovens, steam
ovens and grills - Methods for measuring
performance.
12.2 Energy saving
The appliance contains
features which help you save
energy during everyday
cooking.
General hints
Make sure that the oven door is closed
properly when the appliance operates
and keep it closed as much as possible
during the cooking.
Use metal dishes to improve energy
saving.
When possible, do not preheat the oven
before you put the food inside.
When the cooking duration is longer
than 30 minutes, reduce the oven
temperature to minimum 3 - 10 minutes
before the end of the cooking time,
depending on the duration of the
cooking. The residual heat inside the
oven will continue to cook.
Use the residual heat to warm up other
dishes.
Cooking with fan
When possible, use the cooking
functions with fan to save energy.
Residual heat
If a programme with the Duration or End
Time selection is activated and the
cooking time is longer than 30 minutes,
the heating elements deactivate
www.aeg.com
30
Page 31
automatically 10% faster in some oven
functions.
The fan and lamp continue to operate.
Keep food warm
Choose the lowest possible temperature
setting to use residual heat and keep a
meal warm. The display shows the
residual heat indicator or temperature.
Cooking with the lamp off
Deactivate the lamp during cooking and
activate only when you need it.
13. ENVIRONMENTAL CONCERNS
Recycle the materials with the symbol .
Put the packaging in applicable
containers to recycle it. Help protect the
environment and human health and to
recycle waste of electrical and electronic
appliances. Do not dispose appliances
marked with the symbol with the
household waste. Return the product to
your local recycling facility or contact
your municipal office.
*
ENGLISH
31
Page 32
www.aeg.com/shop
867309304-C-332016
Loading...
