WISE-3610

Wireless IoT LoRa Network Gateway

User Manual

Chapter1 General Introduction

The documentation and the software included with this product are copyrighted 2015 by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to make improvements in the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. However, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringements of the rights of third parties, which may result from its use.

Acknowledgements

ARM is trademarks of ARM Corporation. NXP is trademarks of NXP Corporation. All other product names or trademarks are properties of their respective owners.

Product Warranty (2 years)

Advantech warrants to you, the original purchaser, that each of its products will be free from defects in materials and workmanship for two years from the date of purchase.

This warranty does not apply to any products which have been repaired or altered by persons other than repair personnel authorized by Advantech, or which have been subject to misuse, abuse, accident or improper installation. Advantech assumes no liability under the terms of this warranty as a consequence of such events.

Because of Advantech’s high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If an Advantech product is defective, it will be repaired or replaced at no charge during the warranty period. For outof-warranty repairs, you will be billed according to the cost of replacement materials, service time and freight. Please consult your dealer for more details. If you think you have a defective product, follow these steps:

1. Collect all the information about the problem encountered. (For example, CPU speed,

Advantech products used other hardware and software used, etc.) Note anything abnormal and list any onscreen messages you get when the problem occurs.

2. Call your dealer and describe the problem. Please have your manual, product, and any

helpful information readily available.

3. If your product is diagnosed as defective, obtain an RMA (return merchandise

authorization) number from your dealer. This allows us to process your return more quickly.

4. Carefully pack the defective product, a fully-completed Repair and Replacement Order

Card and a photocopy proof of purchase date (such as your sales receipt) in a shippable container. A product returned without proof of the purchase date is not eligible for warranty service.

5. Write the RMA number visibly on the outside of the package and ship it prepaid to your

dealer.

Declaration of Conformity

1 WISE-3610 User Manual

Chapter1 General Introduction

Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

FCC Caution:Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. For operation within 5.15 ~ 5.25GHz frequency range, it is restricted to indoor environment. This device meets all the other requirements specified in Part 15E, Section

15.407 of the FCC Rules.

Radiation Exposure Statement:

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 35cm between the radiator & your body.

Industry Canada statement:

This device complies with ISED’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Le présent appareil est conforme aux CNR d’ ISED applicables aux appareils radio

exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1) le

dispositif ne doit pas produire de brouillage préjudiciable, et (2) ce dispositif doit accepter tout brouillage reçu, y compris un brouillage susceptible de provoquer un fonctionnement indésirable.

Caution:

(i) the device for operation in the band 5150-5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems;

2 WISE-3610 User Manual

Chapter1 General Introduction

Déclaration d'exposition aux radiations:

Cet équipement est conforme aux limites d'exposition aux rayonnements ISED établies pour un environnement non contrôlé. Cet équipement doit être installé et utilisé avec un minimum de 44m de distance entre la source de rayonnement et votre corps.

This radio transmitter (IC: IC: 9404A-WISE3610 / Model: WISE-3610) has been approved by ISED to operate with the antenna type listed below with maximum permissible gain indicated. Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited for use with this device.

Le présent émetteur radio (IC: IC: 9404A-WISE3610 / Model: WISE-3610) a été approuvé par ISED pour fonctionner avec les types d'antenne énumérés ci-dessous et ayant un gain admissible maximal. Les types d'antenne non inclus dans cette liste, et dont le gain est supérieur au gain maximal indiqué, sont strictement interdits pour l'exploitation de l'émetteur.

(ii) the maximum antenna gain permitted for devices in the band 5725-5850 MHz shall be such that the equipment still complies with the e.i.r.p. limits specified for point-to-point and non-point-to-point operation as appropriate; and (iii) Users should also be advised that high-power radars are allocated as primary users (i.e. priority users) of the bands 5650-5850 MHz and that these radars could cause interference and/or damage to LE-LAN devices.

Avertissement:

(i) les dispositifs fonctionnant dans la bande 5150-5250 MHz sont réservés uniquement

pour une utilisation à l’intérieur afin de réduire les risques de brouillage préjudiciable

aux systèmes de satellites mobiles utilisant les mêmes canaux; (ii) le gain maximal d'antenne permis (pour les dispositifs utilisant la bande de 5725 à 5 850 MHz) doit être conforme à la limite de la p.i.r.e. spécifiée pour l'exploitation point à point et l’exploitation non point à point, selon le cas; (iii) De plus, les utilisateurs devraient aussi être avisés que les utilisateurs de radars de haute puissance sont désignés utilisateurs principaux (c.-à-d., qu’ils ont la priorité) pour les bandes 5650-5850 MHz et que ces radars pourraient causer du brouillage et/ou des dommages aux dispositifs LAN-EL.

Radiation Exposure Statement:

This equipment complies with ISED radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 44 between the radiator & your body.

Déclaration d'exposition aux radiations: Cet équipement est conforme aux limites

d'exposition aux rayonnements ISED établies pour un environnement non contrôlé. Cet équipement doit être installé et utilisé avec un minimum de 44m de distance entre la source de rayonnement et votre corps.

This device complies with Directive 2014/53/EU issued by the Commission of the European Community.

Declaration of Conformity

Hereby, [Advantech Co., Ltd.] declares that the radio equipment type [designation of type of radio equipment] is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: The frequency and maximum transmitted power in EU are listed as belows, 2412 - 2472 MHz: XX.XX dBM 5180 - 5240 MHz: XX.XX dBM 5260 - 5230 MHz: XX.XX dBM 5500 - 5700 MHz: XX.XX dBM

- WLAN 5GHz: Operations in the 5.15-5.35GHz band are restricted to indoor usage only.

3 WISE-3610 User Manual

Chapter1 General Introduction

VCCI Certification

This is a Class B product based on the standard of the Voluntary Control Council for Interference from Information Technology Equipment (VCCI). If this is used near a radio or television receiver in a domestic environment, it may cause interference. Install and use the equipment according to the instruction manual.

NCC Certification:

NCC 警語: 經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻率、加大功率或變更原設計之特性及功能。低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即停用，並改善至無干擾時方得繼續使用。前項合法通信，指依電信法規定作業之無線電通信。低功率射頻電機須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。

Safety Instructions

1. Read these safety instructions carefully.

2. Keep this User Manual for later reference.

3. Disconnect this equipment from any AC outlet before cleaning. Use a damp

cloth. Do not use liquid or spray detergents for cleaning.

4. For plug-in equipment, the power outlet socket must be located near the

equipment and must be easily accessible.

5. Keep this equipment away from humidity.

6. Put this equipment on a reliable surface during installation. Dropping it or

letting it fall may cause damage.

7. The openings on the enclosure are for air convection. Protect the equipment

from overheating. DO NOT COVER THE OPENINGS.

8. Make sure the voltage of the power source is correct before connecting the

equipment to the power outlet.

9. Position the power cord so that people cannot step on it. Do not place

anything over the power cord.

10. All cautions and warnings on the equipment should be noted.

11. If the equipment is not used for a long time, disconnect it from the power

source to avoid damage by transient overvoltage.

12. Never pour any liquid into an opening. This may cause fire or electrical shock.

13. Never open the equipment. For safety reasons, the equipment should be

opened only by qualified service personnel.

14. If one of the following situations arises, get the equipment checked by service

4 WISE-3610 User Manual

Chapter1 General Introduction

Part No.

Description

1700001524

Power Cable 3-pin 180cm, USA type

170203183C

Power Cable 3-pin 180cm, Europe type

170203180A

Power Cable 3-pin 180cm, UK type

1700008921

Power Cable 3-pin PSE Mark 183cm

1750008424-01

3G/LTE Antenna Dipole 4dBi Full Band

1750008669-01

3G/LTE RX Diversity Antenna Cable IPEX to IPEX Connector

968EMW0093

Mini PCIE HSPA 3G Card with Rx Diversity

1700001524

Power Cable 3-pin 180cm, USA type

170203183C

Power Cable 3-pin 180cm, Europe type

170203180A

Power Cable 3-pin 180cm, UK type

Part No.

Description

WISE-3610ILS-51A1N

WISE-3610 Private LoRa Network IoT Gateway NA915

WISE-3610ILS-51A1E

WISE-3610 Private LoRa Network IoT Gateway EU868

WISE-3610ILS-51A1J

WISE-3610 Private LoRa Network IoT Gateway JP923

WISE-3610ILS-51A1T

WISE-3610 Private LoRa Network IoT Gateway TW920

WISE-3610ILS-51A1C

WISE-3610 Private LoRa Network IoT Gateway CN470

personnel:

 The power cord or plug is damaged.  Liquid has penetrated into the equipment.  The equipment has been exposed to moisture.  The equipment does not work well, or you cannot get it to work according to

the user’s manual.

 The equipment has been dropped and damaged.  The equipment has obvious signs of breakage.

DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech

disclaims all responsibility for the accuracy of any statements contained herein.

Packing List

Before installation, please ensure the following items have been shipped.

 1 WISE-3610 (refer to ordering information for different region)  1 Power Adapter (P/N: 96PSA-A36W12R1)  2 Wi-Fi Dual Band Antenna (P/N: 1750008001-01)  2 LoRa Antenna (Different region will pack different LoRa antenna)  2 Wall Mount Becket (P/N: 1960082071N001)  4 Wall Mount Becket Screw (P/N: 1930000071)

Optional Accessories

Ordering Information

5 WISE-3610 User Manual

Chapter

............................................................................................................................ 2

1.1 Product Features ............................................................................................................ 4

1.2 Mechanical Specifications .............................................................................................. 5

1.3 Electrical Specifications .................................................................................................. 6

1.4 Environmental Specifications ......................................................................................... 6

1.5 Block Diagram ............................................................................ 錯誤! 尚未定義書籤。

Chapter 2 ............................................................................................................................ 7

2.1 Jumpers .......................................................................................................................... 8

2.1.1 Jumper Description ................................................. 錯誤! 尚未定義書籤。

2.1.2 Jumper List .............................................................. 錯誤! 尚未定義書籤。

2.1.3 Jumper Setting ......................................................... 錯誤! 尚未定義書籤。

2.2 Connectors ................................................................................................................... 14

2.2.1 Connector list ............................................................................................. 14

2.2.2 Connector Settings ..................................................................................... 14

2.3 Mechanical .............................................................................. 錯誤! 尚未定義書籤。

2.3.1 Jumper and Connector Location ................................................................ 18

2.3.2 Board Dimension ..................................................... 錯誤! 尚未定義書籤。

2.4 Quick Start Guide ...................................................................... 錯誤! 尚未定義書籤。

2.4.1 Debug Port Connection ............................................... 錯誤! 尚未定義書籤。

2.4.2 Debug Port Setting ...................................................... 錯誤! 尚未定義書籤。

Chapter 3 .......................................................................................................................... 21

Chapter 4 ....................................................................................... 錯誤! 尚未定義書籤。

Chapter 5 .......................................................................................................................... 69

5.1 RISC Design-in Services .......................................................... 錯誤! 尚未定義書籤。

5.2 Contact Information .................................................................................................. 70

5.3 Global Service Policy ................................................................................................. 70

5.3.1 Warranty Policy .............................................................................................. 70

5.3.2 Repair Process ................................................................................................ 71

Chapter1 General Introduction

Chapter

General Introduction

This chapter gives background information on the WISE-3610. Sections include:

 Introduction  Specification

2 WISE-3610 User Manual

Chapter1 General Introduction

Introduction

WISE-3610 is Qualcomm Atheros (QCA) ARM Cortex-A based hardware platform, which is operating at OpenWRT, described as a Linux distribution for embedded networking devices. The Advantech WISE-3610 Industrial Gateway is Advantech LPWAN IoT gateway design for smart city, Industrial 4.0 applications, even those in harsh environment, leveraging wireless sensor technology. This LPWAN IoT gateway can aggregate both the wireless sensor networks (WSN), including Low Power WAN (LPWAN) technology by Advantech Private LoRa technology – WISE-Link, wired sensors and ties them into an IP network. With modular slot design, it can agilely adapt to a variety of wireless technologies at regional RF bands, wireless communication protocol by various uplink requirement and quickly go to market.

The main features of WISE-3610 are:

 Qualcomm Atheros Quad-Core ARM Cortex-A7 SoC  Built-in Dual Band Concurrent Wi-Fi MU-MIMO (2x2)  LPWAN Private LoRa (WISE-Link) Connectivity  WAN x1 / LAN x1 Gigabit Ethernet  Integration of Modbus TCP and Modbus RTU network Translator  IPSec / L2TP VPN Traffic Encryption  Rich Network Scenario by S/W Configuration  WAN / WWAM Failover backup support  WWAN Dual SIM Failover backup support  Modularization hardware design  OpenWRT BSP embedded  Web UI user interface  Support wide temperature -20 ~ 70 °C

3 WISE-3610 User Manual

Chapter1 General Introduction

Processor System

CPU

QCA Quad-core ARM Cortex A7 CPU 716 MHz

Memory Technology

DDR3L 1066MHz

Capacity

On-board 256MB

Flash

128MB

Ethernet

WAN

1 x 10/100/1000Mbps

LAN

1 x 10/100/1000 Mbps

COM (Serial) H/W Selection

RS-232/RS-422/RS-485 (default configures as RS-485)

ModBus

ModBus TCP / RTU Translator

Security

VPN Engine

IPSec, L2TP

Connectivity Wi-Fi

2x2 Concurrent Dual Band 2.4Ghz/5Ghz

LoRa

2x2 Private LoRa Network – WISE-Link

Antenna Wi-Fi

2 2.4Ghz / 5Ghz @ 5dBi

LoRa

2 433Mhz / 868Mhz / 915Mhz @ 1dBi

Expansion Slot Mini-PCIe

1 Full size mini PCie slot for 3G WWAN module

SD Card

1 Micro SD Socket up-to 128GB

SIM

2 Micro SIM Slot for WWAN dual SIM Failover

Wi-Fi

Standard

IEEE802.11a/b/g/n/ac

Multiplexing

OFDM

Modulation

BPSK, QPSK, 16QAM, 64QAM, 256QAM (11ac)

Media Access

CSMA/CA with ACK

Associated STA

100 stations per radio

Channel

2.4Ghz:

 CH1 – 11: North America, Taiwan  CH1- 13: EU, Japan, China

5Ghz:

 CH36, 40, 44, 48 (Band 1):

North America, EU, Japan, China

 CH149, 153, CH157, 161, 165 (Band4):

North America, Taiwan, China

Bandwidth

HT20/HT40/HT80

Max TX Power

The maximum allowable RF power level is subject to specified nation regulation

 2.4Ghz < 20dBm  5Ghz < 23dBm

RX Sensitivity

2.4Ghz:

 HT20 (11n): -64 dBm at MCS 7/15  HT40 (11n): -61dBm at MCS 7/15

5Ghz:

 HT20 (11n): -64dBm at MCS7/15  HT40 (11n): -61dBm at MCS 7/15  HT20 (11ac): -57dBm at MCS9  HT40 (11ac): -54dBm at MCS9  HT80 (11ac): -51dBm at MCS9

LoRa

Standard

Sub-Ghz radio station regulation

1.1 Product Features

4 WISE-3610 User Manual

Chapter1 General Introduction

Bandwidth

125Khz / 250Khz / 500Khz

Multiplexing

TDMA

Modulation

LoRa

Freq. Band

CN 470Mhz, EU 868Mhz, NA 915Mhz, AS 923Mhz

Media Access

WISE-Link semi-persistent scheduling (SPS) with ACK

Associated Node

500 nodes Data Rate

Spread Factor (SF) 7 - 12

Max TX Power

The maximum allowable RF power level is subject to specified nation regulation

 LoRa < 18dBm

RX Sensitivity

 LoRa > -136dBm at SF = 12 / 125KHz  LoRa > -133dBm at SF = 12 / 250KHz  LoRa > -130dBm at SF = 12 / 500KHz

O.S

Linux

V 3.14

Dimensions

W x L x T

187.9mm x 150mm x 39mm

Weight

Net Weight (g)

990 gram

Power

DC-In

12V DC-In

Power Consumption

Watt

18 watt (Max)

Environment Operational

Temperature

-20 ~ 70°C

Operating Humidity

10% ~ 95% relative humidity, non-condensing Certifications

Level

CE / FCC / Class B / TELEC / SRRC / NCC

1.2 Mechanical Specifications

 Dimension: 187.9mm x 150mm

 Height: 39mm  Reference Weight: 990g (including wall mounting kits)

5 WISE-3610 User Manual

Chapter1 General Introduction

1.3 Electrical Specifications

 Power supply type: DC-in 12V  RTC Super Capacitor: Panasonic (P/N: EECS0HD224)

---Typical voltage: 4.3V

---Nominal capacity: 0.22F

1.4 Environmental Specifications

 Operating temperature: -20~70°C (-4~157°F)  Operating humidity: 10% ~ 95% relative humidity, non-condensing  Storage temperature: -40~85°C (-40~185°F)

 Storage humidity: 60°C @ 95% RH Non-condensing  Vibration Loading During Operation (Automotive grade): 3 Gms, random, 5

~ 500 Hz

6 WISE-3610 User Manual

Chapter 2

H/W Installation

This chapter gives mechanical and connector information on the WISE-3610 Sections include:

 Information of WISE-3610 I/O Indication  On Board Connectors and Switches  WISE-3610 Hardware Installation

Chapter2 H/W Installation

2.1 Introduction

The following sections show the internal / external connectors and pin assignments for applications.

2.1.1 WISE-3610 I/O Indication

Figure 2.1 WISE-3610 Front view

Figure 2.2 WISE-3610 Rear view

2.1.2 WISE-3310 Antenna Connectors

The WISE-3610 provides 6 SMA antenna connectors; all are assembled by default on housing. Wi-Fi, LoRa antennas (total are four) are packed in the package. To enable WWAN feature, need to have following table materials and assemble manually by the guides (refer to hardware installation guide 2.3.2):

8 WISE-3610 User Manual

Chapter2 H/W Installation

Table 2.1 : WWAN related materials

968EMW0093

Mini PCIE HSPA 3G Card with Rx Diversity

1750008424-01

3G/LTE Antenna Dipole 4dBi

1750008669-01

3G/LTE RX Diversity Antenna Cable IPEX to IPEX Connector

193B0204C0

Mini-PCI Express Card Screw

Name

Description

PWR

Steady ON = Power Up

OFF = Power Down

USB

Steady ON = USB device detected

Blinking = TX / RX Transmission

OFF = No USB device connected

LoRa

Steady ON = LoRa Module detected

Blinking = TX / RX Transmission

OFF = LoRa Module disabled

WWAN

Steady ON = WWAN Module detected

Blinking = TX / RX Transmission

OFF = No WWAN Module detected

Figure 2.3 Antenna SMA in front panel

Figure 2.4 Antenna SMA in rear panel

2.1.3 LED Indication

9 WISE-3610 User Manual

Chapter2 H/W Installation

2.4Ghz

Blinking = TX / RX Transmission

OFF = 2.4G Wi-Fi interface disabled

5Ghz

Blinking = TX / RX Transmission

OFF = 5G Wi-Fi interface disabled

WAN

Brown LED Blinking = 10M/100Mbps TX / RX Transmission

Green LED Blinking = 1000Mbps TX / RX Transmission

LAN

Brown LED Blinking = 10M/100Mbps TX / RX Transmission

Green LED Blinking = 1000Mbps TX / RX Transmission

Table 2.2 WISE-3610 LED Indication

Figure 2.5 WISE-3610 LED locations

2.1.4 Reset Button

The WISE-3610 has a reset button on the front side. Press this button to activate the hardware reset function for more than 8 seconds.

Figure 2.6 Rest button location

2.1.5 Ethernet Connector (WAN, LAN)

The WISE-3610 provides one RJ45 WAN and one RJ45 LAN interface connectors, they are fully compliant with IEEE802.3ab / IEEE 802.3u and

10 WISE-3610 User Manual

Chapter2 H/W Installation

IEEE 802.3x Flow Control 10/100/1000 Base-T CSMA/CD standards. These Ethernet ports provide standard RJ-45 connector with LED indicators to show Active/Link status.

2.1.6 USB 3.0 Port

The WISE-3310 provides one USB 3.0 interface.

2.1.7 COM Port

The WISE-3610 provides one serial D-sub 9 COM port which could be configured either one RS-232 / RS-422 / RS-485 interface for Modbus RTU feature. Open the housing to change hardware switch (Location at SW6) on PCBA for corresponding demand interface (default setup is RS-485).

11 WISE-3610 User Manual

Chapter2 H/W Installation

RS-232 (1000)

RS-422 (1100)

Default: RS-485 (0100)

2.1.8 Power Input Connector

The WISE-3610 comes with a DC-jack header for 12V DC external power input. The Maximum power consumption is around 18 Watt.

2.1.9 Micro SD Connector

The WISE-3610 provides a Micro SD slot. Users can insert a Micro SD card easily by open the housing regarding to security concern (probably, users may save sensitive LoRa node collected data or other application into this Micro SD card supports up-to 128GB).

12 WISE-3610 User Manual

Chapter2 H/W Installation

2.1.10 Micro SIM Connector

The WISE-3610 has two micro SIM slots. Users can insert two micro SIM cards manually. Two telecomm operating SIMs for backup each other if the connection loss. The SIM slot locations are on top and bottom of PCBA. The 1st priority SIM slot (Primary) is on top size of PCBA and the 2nd priority is on bottom side of PCBA. Refer to the following figures for indication.

13 WISE-3610 User Manual

Chapter2 H/W Installation

CN12

SD Card Slot

CN28

Micro SIM Card Slot 1 (Primary)

CN27

Micro SIM Card Slot 2 (Secondary)

CN22

Mini-PCIe Card Slot

SW6

RS-232 / RS-422 / RS-485 hardware switch

CN18

WWAN IPEX Connector

2.2 On Board Connectors and Switches

2.2.1 Connector and switch lists

2.2.2 Connector Settings

2.2.2.1 CN12 Micro SD Card Slot

WISE-3610 support a Micro SD card slot up-to 128GB stored space

14 WISE-3610 User Manual

Chapter2 H/W Installation

SD Slot

2.2.2.2 Micro SIM Card Primary Slot (CN28)

2.2.2.3 Micro SIM Card Secondary Slot (CN27)

2.2.2.4 Mini PCIE (CN5)

WISE-3610 supports mini-pcie interface. Default support WWAN 3G module that are listed in “Table 2.1”. The detailed pin definition is listed as below.

15 WISE-3610 User Manual

Chapter2 H/W Installation

mini-PCIe

CN22

mini-PCIe

WAKE#

+V_LTE

+3p3Vaux_1

COEX1#

GND

GND_1

4 5 COEX2#

+1p5V_1

CLKREQ#

LTE_UIM_PWR

UIM_PWR

GND_2

GND

LTE_UIM_DATA

UIM_DATA

REFCLK-

LTE_UIM_CLK

UIM_CLK

REFCLK+

LTE_UIM_RESET

UIM_RESET

GND_3

GND

UIM_VPP

Reserved_6/UIM_C8

GND

GND_4

Reserved_5/UIM_C4

LTE_W_DIS#

W_DISABLE#

GND_5

GND

LTE_RTS#

PERST#

PERn0

+V_LTE

+3p3Vaux_2

PERp0

GND

GND_6

GND_7

GND

+1p5V_2

GND_8

GND

SMB_CLK

PETn0

SMB_DATA

PETp0

GND

GND_9

GND_10

GND

LTE_USB_D-

USB_D-

GND_11

GND

LTE_USB_D+

USB_D+

+3p3Vaux_3

+V_LTE

GND

GND_12

+3p3Vaux_4

+V_LTE

LTE_LED

LED_WWAN#

GND_13

GND

LED_WLAN#

Reserved_1

LED_WPAN#

Reserved_2

+1p5V_3

Reserved_3

GND

GND_14

Reserved_4

+V_LTE

+3p3Vaux_5

Mini-PCIE CONNECTOR

16 WISE-3610 User Manual

Chapter2 H/W Installation

RS-232 (1000)

RS-422 (1100)

Default: RS-485 (0100)

2.2.2.5 Hardware switch (SW6)

WISE-3610 supports a hardware switch to change RS-232 / RS-422 / RS-485 for selection. Default is RS-485 by manufacturer setting.

Hardware Switch for serial type selection

2.2.2.6 WWAN IPEX Connector (CN18)

If there is WWAN 2nd antenna demand to have 3G Rx diversity feature by connecting CN18 IPEX to mini-PCie IPEX connector on the 3G module.

17 WISE-3610 User Manual

CN18 and 3G module connection guidance

Chapter2 H/W Installation

Content

Description

Qty

Remark

968EMW0093

Mini PCIE HSPA 3G Card with Rx Diversity

Frequency Band: 800/850, 900, AWS1700, 1900, 2100

EWM-C117FL02 E

LTE Card for Cat. 4 (150Mbps / 50Mbps)

LTE Bands: 1, 3, 5, 7, 8, 20 (EU, Asia)

1750008424-01

3G/LTE Antenna Dipole 4dBi Full Band

1750008669-01

3G/LTE RX Diversity Antenna Cable IPEX to

IPEX Connector

193B0204C0

Mini-PCI Express Card Screw

2.3 WISE-3610 Hardware Installation

2.3.1 Mounting Assembly Method

You can fix WISE-3310 to a wall by using wall mounting kit, as following figure.

2.3.2 Enable WWAN feature with hardware installation

WISE-3610 has native support 3G and 4G LTE backhaul for WWAN card installation and accessories by the following order list and procedures:

1. Open WISE-3610 top case by releasing 6 screws around housing (from top and side view)

18 WISE-3610 User Manual

+ 56 hidden pages
