Advantech Co TREK530LTE Users Manual

User Manual

TREK-530

Computer

TREK-530 User Manual

The documentation and the software included with this product are copyrighted 2017 by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to make improvements in the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. However, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringements of the rights of third parties, which may result from its use.

Acknowledgements

Qualcomm is trademarks of Qualcomm Incorporated. Android is registered trademarks of Google LLC.

All other product names or trademarks are properties of their respective owners.

Product Warranty (2 years)

Advantech warrants to you, the original purchaser, that each of its products will be free from defects in materials and workmanship for two years from the date of purchase.

This warranty does not apply to any products which have been repaired or altered by persons other than repair personnel authorized by Advantech, or which have been subject to misuse, abuse, accident or improper installation. Advantech assumes no liability under the terms of this warranty as a consequence of such events.

Because of Advantech’s high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If an Advantech product is defective, it will be repaired or replaced at no charge during the warranty period. For outof-warranty repairs, you will be billed according to the cost of replacement materials, service time and freight. Please consult your dealer for more details.

If you think you have a defective product, follow these steps:

1. Collect all the information about the problem encountered. (For example, CPU

speed, Advantech products used, other hardware and software used, etc.) Note anything abnormal and list any onscreen messages you get when the problem occurs.

2. Call your dealer and describe the problem. Please have your manual, product,

and any helpful information readily available.

3. If your product is diagnosed as defective, obtain an RMA (return merchandize

authorization) number from your dealer. This allows us to process your return more quickly.

4. Carefully pack the defective product, a

Order Card and a photocopy proof of purchase date (such as your sales receipt) in a shippable container. A product returned without proof of the purchase date is not eligible for warranty service.

5. Write the RMA number visibly on the outside of the package and ship it prepaid

to your dealer.

Part No. Edition 1 Apr 2018

fully-completed

Repair and Replacement

TREK-530 User Manual

Declaration of Conformity

This product has passed the CE test for environmental specifications. Test conditions for passing included the equipment being operated within an industrial enclosure. In order to protect the product from being damaged by ESD (Electrostatic Discharge) and EMI leakage, we strongly recommend the use of CE-compliant industrial enclo-

„

FCC Caution : Any changes or modifications not expressly approved by the party responsible for

FCC RF Radiation Exposure Statement :

This device meets the government`s requirements for exposure to radio waves. This device is designed and manufactured not to exceed the emission limits for

sure products.

FCC Class B Note: This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communicati ons. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna

Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 FCC Rules. Operation is subject to the following two conditions. (1) This device may not cause harmful interference , and (2) The device must accept any interference received, including

interference may cause undesired operation.

compliance could void the user's authority to operate this equipment.

exposure to radio frequency(RF) energy set by the Federal Communications Commission of the U.S. Government.

This device complies with FCC radiation exposure limits set forth for an uncontrolled environment. In order to avoid the possibility of exceeding the FCC radio frequency exposure limits, human proximity to the antenna shall not be less than 20cm (8 inches) during normal operation.

Changes or modifications not expressly approved by the party responsible for compliance could void the user`s authority to operate the equipment.

TREK-530 User Manual

Technical Support and Assistance

1. Visit the Advantech web site at

the latest information about the product.

2. Contact your distributor, sales representative, or Advantech's customer service

center for technical support if you need additional assistance. Please have the following information ready before you call:

– Product name and serial number – Description of your peripheral attachments – Description of your software (operating system, version, application software,

etc.)

– A complete description of the problem – The exact wording of any error messages

http://support.advantech.com

where you can find

TREK-530 User Manual

Description

Q`ty

TREK-530 Computer

Power cable (2M)

LAN adaptor cable

Warnings, Cautions and Notes

Warning! Warnings indicate conditions, which if not observed, can cause personal

injury!

Caution! Cautions are included to help you avoid damaging hardware or losing

data. e.g. There is a danger of a new battery exploding if it is incorrectly installed.

Do not attempt to recharge, force open, or heat the battery. Replace the battery only with the same or equivalent type recommended by the manufacturer. Discard used batteries according to the manufacturer's

Note! Notes provide optional additional information.

instructions.

Document Feedback

To assist us in making improvements to this manual, we would welcome comments and constructive criticism. Please send all such - in writing to: support@advantech.com

Packing List

Before setting up the system, check that the items listed below are included and in good condition. If any item does not accord with the table, please contact your dealer immediately.

Ordering Information

Part Number

Description

TREK-530-GWBADA20

TREK-530 Barebone w/ slot

TREK-530-LWBADA20

TREK-530 EU full config. w/ WLAN,BT,LTE,GNSS

TREK-530-LWBADB20

TREK-530 US full config. w/WLAN,BT,LTE,GNSS

Safety Instructions

1. Read these safety instructions carefully.

2. Keep this User Manual for later reference.

3. Disconnect this equipment from any AC outlet before cleaning. Use a damp cloth.

Do not use liquid or spray detergents for cleaning.

4. For plug-in equipment, the power outlet socket must be located near the equip- ment

and must be easily accessible.

5. Keep this equipment away from humidity.

6. Put this equipment on a reliable surface during installation. Dropping it or

may cause damage.

7. Do not leave this equipment in an environment unconditioned where the storage

temperature under -40° C (-40° F) or above 85° C (185° F), it may damage the equipment. Operating temperature: -20°C~65°C without battery.

8. Do not operate this equipment in an environment temperature may over

65°C(149° F). The surface temperature of plastic chassis may be hot.

9. Make sure the voltage of the power source is correct before connecting the

equipment to the power outlet.

10. Position the power cord so that people cannot step on it. Do not place anything over

the power cord. The voltage and current rating of the cord should be greater than the voltage and current rating marked on the product.

11. All cautions and warnings on the equipment should be noted.

12. If the equipment is not used for a long time, disconnect it from the power source to

avoid damage by transient overvoltage.

13. Never pour any liquid into an opening. This may cause fire or electrical shock.

14. Never open the equipment. For safety reasons, the equipment should be

opened only by qualified service personnel.

15. If one of the following situations arises, get the equipment checked by service

personnel:

„

The power cord or plug is damaged.

„

Liquid has penetrated into the equipment.

„

The equipment has been exposed to moisture.

„

The equipment does not work well, or you cannot get it to work according to the user's manual.

„

The equipment has been dropped and damaged.

„

The equipment has obvious signs of breakage.

16. CAUTION: The computer is provided with a battery-powered real-time clock cir- cuit.

There is a danger of explosion if battery is incorrectly replaced. Replace only with same or equivalent type recommended by the manufacture. Discard used batteries according to the manufacturers instructions.

17. This device complies with Part 15 of the FCC rules. Operation is subject to the

following two conditions: (1) this device may not cause harmful interference, and

letting it

fall

(2) this device must accept any interference received, including interference that may cause undesired operation.

18. CAUTION: Always completely disconnect the power cord from your chassis

whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges.

19. CAUTION: Always ground yourself to remove any static charge before touching the

motherboard, backplane, or add-on cards. Modern electronic devices are very sensitive to static electric charges. As a safety precaution, use a grounding wrist strap at all times. Place all electronic components on a static-dissipative surface or in a static-shielded bag when they are not in the chassis.

20. CAUTION: Any unverified component could cause unexpected damage. To ensure

the correct installation, please always use the components (ex. screws) provided with the accessory box.

Safety Precaution - Static Electricity

Follow these simple precautions to protect yourself from harm and the products from damage.

„

To avoid electrical shock, always disconnect the power from your PC chassis

before you work on it. Don't touch any components on the mainboard or other cards while the system is on.

„

Disconnect power before making any configuration changes. The sudden rush

of power as you connect a jumper or install a card may damage sensitive electronic components.

This product is intended to be supplied by a Listed DC power source, rated 932Vdc, 2A maximum and Tma 65 degree C, if need further assistance with purchasing the DC power source, please contact Advantech for further information.

Warning! 1. Input voltage rated: 9 - 32 Vdc.

2. Transport: carry the unit with both hands and handle with care.

3. Maintenance: to properly maintain and clean the surfaces, use only

approved products or clean with a dry applicator.

4. SD/SIM card: Turn off the power before inserting or removing

the storage cards.

1. Tension d'entrée nominale: 9 - 32 Vdc.

2. Transport: portez l'appareil avec les deux mains et manipulez-le avec

précaution.

3. Entretien: pour bien entretenir et nettoyer les surfaces, n'utilisez que des

produits approuvés ou nettoyez-les avec un applicateur sec.

4. Carte SD / SIM: Mettez l'appareil hors tension avant de l'insérer ou de le

retirerles cartes de stockage.

Chapter 1

1 General Information

This chapter gives background information on the TREK-530 Computer

Sections include:

„

Introduction

„

General Specifications

„

Dimensions

Chapter 1

General Information

1.1 Introduction

TREK-530 is a compact RISC-based in-vehicle computing box equipped with a Qualcomm® Snapdragon™ 212 quad-core ARM® Cortex™-A7 SoC, isolated DI/O, and two extension slots for optional expansion. Built-in WLAN, Bluetooth, and GNSS modules offer enhanced connectivity, while periodic, digital input and WWAN suspend/resume functionality Supports remote monitoring, making TREK-530 ideal for logistics and fleet management. Moreover, the system’s wide operating temperature range (-20 ~ 65 °C), support for 9-32Vdc power input, and compliance with MIL-STD-810G and 5M3 shock/vibration standards ensures TREK-530 can withstand operation in harsh environments.

1.2 General Specifications

Features

 Qualcomm® Snapdragon™ 212 quad-core ARM® Cortex™-A7 SoC with Android 6.0 Marshmallow  Built-in WLAN, Bluetooth, and GNSS (including BeiDou) modules with external antenna via FAKRA

connector.

 Modularized design with two extension slots for optional expansion (such as LTE 4G module or

battery) according to application requirements.

 Multiple isolated DI/O; DI supports dry/wet contact and speed sensor inputs for measuring distance.  Compliant with MIL-STD-810G and 5M3 standards for shock/vibration tolerance.  Equipped with Advantech’s industrial Mobile Android Remote General Utilities for remote

management.

Qualcomm® Snapdragon™ 212 APQ8009 quad-core ARM® Cortex™-A7 (1.3 GHz) SoC

Memory

2 GB

16 GB eMCP 1 x Externally accessible MicroSD (push-push type) with cover

Watchdog

Yes

RTC

Yes

O.S

Android 6.0 Marshmallow

IEEE 802.11 a/b/g/n dual band (2.4/5 GHz) (with external antenna via FAKRA connector)

Bluetooth

Bluetooth V4.1 Class 1 (with external antenna via FAKRA connector)

GPS, GLONASS, and AGPS (BeiDou upon request) support (with external antenna via FAKRA connector)

Sierra Wireless MC7304 via extension module (EU)

GPRS 850,1900,EGPRS 850,1900

Voice call

N/A

Wake-on-WWAN

N/A

SIM

1 SIM slot

External Antenna

1 x WLAN, 1 x WWAN Main, 1 x WWAN AUX & GPS (FAKRA connector)

Sensor

G-Sensor

Triple-axis accelerometer (±2g/4g/8g)

Generic I/O Port

1 x Mic-In, 1 x Line-Out

1 x 4-wire RS-232/RS-485 (software configurable)

Standard I/O Port

1 x Micro USB OTG (Mini USB) with cover (for debugging) 1 x MicroSD slot with cover

Indicator

1x LED (Power)

Button

1x reset button with cover

Reset

Yes

Input Voltage

9-32V DC

Backup Battery (Optional)

3.6 V 2100 mAh Dimensions (W x H x D)

140 x 110 x 50 mm (5.51 x 4.33 x 1.96 in)

Weight

410 g

IP Rating

IP54 with I/O cover

Regulation

E-Mark, ISO 7637-2, SAE J1455, PTCRB

EMC

CE,FCC

Safety

UL/cUL, CB, CCC

Operating Temperature

-20° C ~ 65 °C (-4 ~ 149 °F)

0° C ~ 45° C (with battery charge)

Storage Temperature

-40~85C (-40~185F) (without battery)

Shock/Vibration

MIL-STD-810G, SAE J1455

Specifications

Processor

System

I/O

Storage

WiFi

GNSS

WWAN

(via automotive connector)

LTE: B1, B3, B7, B8, B20 Sierra Wireless MC7354 via extension module (US) LTE: B2, B4, B5, B13, B17, B25 (external antenna via FAKRA connector) WCDMA Band II, Band V, Band IV.

4 x Isolated DI (dry/wet contact) 2 x Isolated DO (open-collector output with relay driver) 1 x CAN bus (supports raw CAN, J1939, OBD-II/ISO 15765; firmware configurable) 1 x J1708 (J1587) 1 x USB 2.0 Host 1 x 4-wire RS-232

Power

Mechanical

Environment

-10° C ~ 60° C (with battery discharge)

Chapter 1

General Information

1.3 Dimensions

Figure 1.1 TREK-530 dimensions

Warning! Use suitable mounting apparatus to avoid risk of injury.ÚTTENTION:

Veuillez utiliser un système de montage approprié afin d'éviter tout risque de

blessure.Ð

Fixed VESA screw specification: M4 ; Screws depth: 10 mm. (Min)_

Chapter 2

2 System Setup

This chapter details system setup on TREK-530

Sections include:



A Quick Tour of the Computer

Box



Installation Procedures



Quick Start to access TREK-530

Chapter 2

System Setup

2.1 A Quick Tour of the TREK-530 Computer

Before starting to set up TREK-530, take a moment to become familiar with the locations and functions of the connectors and ports, which are illustrated in the figures below.

Figure 2.1 Rear view of TREK-530

2.2 Installation Procedures

2.2.1 Installing SIM card

door on left side. Then can install SIM Card directly.

Remove WWAN extension module enclosed I/O door screw then open the rubber

Figure 2.3 Installing SIM card

[鍵入文字]

Black

Red

Ignition

Orange

2.2.2 Connecting Power

Connect the power cord to the DC inlet of the Computing Box. On the open-wire end, one pin is reserved for positive voltage and is marked, "+"; one pin is reserved for ground and is marked, "-"; and, one pin is reserved for the ignition signal with an “ignition” mark.

Note! Ignition on/off setting: The TREK-530 supports an ignition on/off function

so that you can power on/off the TREK-530 via the ignition signal/volt-

age and connect the TREK-530 ignition switch.

Table 2.1: Pin Definition of Power Cord

Pin Definition Color

2.2.3 Quick Start to access TREK-530

through WiFi or Ethernet.

There are 2 method to access TREK-530, one is through USB cable, the other one is

2.2.3.1 USB driver installation

Before access TREK-530, you need to install ADB driver on your PC for ADB connection to TREK-530. Before TREK-530 power on, unplug USB cable, make sure USB switch are switch to “debug mode”, by removing the plate cover and switch to right

Qualcomm ADB driver install

Environment setup

- Windows 7/8 32 / 64bit

- Android_USB_Driver.7z

- Unzip Android_USB_Driver.7z

- [TREK-530] Make sure device is off.

- [TREK-530] Switch USB switch to USB debug side

- Power on device

- After 10 sec, plug-in USB cable

- Check DeviceManager in your PC, found a un-known device as following pic.

Right click it and select “Updated driver” than select “Browse my computer…”

Browse to driver folder and click “Next”

Select “Install” and driver will be installed.

Check Device Manager

Open a window console and type “adb device” to confirm TREK-530 recognized.

Establish screencast connection to TREK-530 Run androidscreencast.bat on PC to launch Android screencast. Then you can look the desktop of TREK-530 remotely.

2.2.3.2 WiFi & Ethernet auto configure

Download a file “trek530_adv.cfg” from Advantech support website.

Change file setting in trek530_adv.cfg Save trek530_adv.cfg in USB or SDCard storage Plug storage into TREK530

WiFi Setting – [WIFI] => Setting for WiFi

– SSID: => SSID name

– WTYPE: => Security Mode  OPEN

WEP  WPAPSK (Include WPA/WPA2 - AES/TKIP)

– PW: => Password (No Need if type is “OPEN”)  Ex:

Ethernet Setting – [ETH] => Setting for Ethernet

– ETYPE: => Type of Ethernet

 STATIC  DHCP (below setting can be ignore)

– IP: => STATIC IP

– NM: => NetMask

– GW: => GateWay

– DNS1: => DNS1(Option for static)

– DNS2: => DNS2(Option for static)  Ex:

Note : Line ignore with “#” mark at first character  If there are same setting in file, value of last line will be used.

– Ex: Same SSID  [WIFI]

SSID:ABCD SSID:5678 <- 5678 will be used WTYPE:WEP

 Setting also will be applied when boot up if storage is put in device before power on.  WiFi will be triggered to create connection with dedicated AP, but can’t guarantee the

connection will be successful. Connection can be created or not is depends on the signal strength in current environment.

Chapter 3

4 I/O Connector

This chapter explains how to set up the Computing Box hardware, including instructions on setting.

Sections include:  I/O connectors pin assignment

Function

GND

9~32V

IGNITION

Function

ISO Digital Input 1

USB D-

ISO Digital Input 2

GND

RS-232_2 RXD

RS-485 Data +

RS-232_2 DCD

RS-485 Data -

GNDof ISO DI/O

RS-232_2 CTS

RS-232_2 RTS

ISO Digital Output 2

RS-232_2 TXD

J1708+(J+)

GND

GND(G)

RS-232_1 RTS

3.1 I/O Connectors Pin Assignment

3.3.1 Power connector

1 GND

5 9~32V

3.3.2 High Density Connector

3 ISO Digital Input 3

4 ISO Digital Input 4

6 ISO Digital Output 1

J1708-(J-)

RS-232_1 CTS

RS-232_1 TXD

GND(G)

RS-232_1 RXD

CAN L

GND of Audio

USB VBUS

Line Out

Line In

USB D+

MIC Input

Function

LAN_TX-

LAN_RX+

(Pair C+)

LAN_RX-

(Pair D+)

(Pair D-)

11 CAN H

15 GND

3.3.3 LAN Connector

1 LAN_TX+

5 (Pair C-)

Chapter 4

6 Software Demo Utility

Setup

This chapter explains the software demo utility for TREK-530

Sections include:

„

Introduction

„

How to Set up Demo Utility

+ 53 hidden pages
