PCA-6144V
Half-size 486 CPU Card
with SVGA Controller
Copyright Notice
This document is copyrighted, 1996, by Advantech Co., Ltd. All
rights are reserved. Advantech Co., Ltd., reserves the right to make
improvements to the products described in this manual at any time
without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of Advantech Co., Ltd. Information provided in this
manual is intended to be accurate and reliable. However, Advantech Co., Ltd. assumes no responsibility for its use, nor for any
infringements upon the rights of third parties which may result
from its use.
Acknowledgements
AMD is a trademark of Advanced Micro Devices, Inc.
Award is a trademark of Award Software International, Inc.
IBM, PC AT and VGA are trademarks of International Business
Machines Corporation.
Microsoft Windows® and MS-DOS are trademarks of Microsoft
Corporation.
SMC is a trademark of Standard Microsystems Corporation.
TGUI 9440 is a trademark of Trident MicroSystems, Inc.
Cyrix is a trademark of Cyrix Corporation.
Intel is a trademark of Intel Corporation.
Part No. 2006144010 2nd Edition
Printed in Taiwan May 1996
A Message to the Customer....
Advantech Customer Services
Each and every Advantech product is built to the most exacting
specifications to ensure reliable performance in the unusual and
demanding conditions typical of industrial environments. Whether
your new Advantech equipment is destined for the laboratory or
the factory floor, you can be assured that it will provide the
reliability and ease of operation for which the name Advantech has
come to be known.
Your satisfaction is our number one concern. Here is a guide to
Advantech’s customer services. To ensure you get the full benefit
of our services, please follow the instructions below carefully.
Technical Support
We want you to get the maximum performance from your products. If you run into technical difficulties, we are here to help. But
please consult this manual first.
If you still can’t find the answer, gather all the information or
questions that apply to your problem and, with the product close at
hand, call your dealer. Our dealers are trained and ready to give
you the support you need to get the most from your Advantech
products. In fact, most problems reported are minor and are able to
be easily solved over the phone.
In addition, free technical support is available from Advantech
engineers every business day. We are always ready to give advice
on application requirements or specific information on the
installation and operation of any of our products.
Product warranty
Advantech warrants to you, the original purchaser, that each of its
products will be free from defects in materials and workmanship
for one year from the date of purchase.
This warranty does not apply to any products which have been
repaired or altered by other than repair personnel authorized by
Advantech, or which have been subject to misuse, abuse, accident
or improper installation. Advantech assumes no liability as a
consequence of such events under the terms of this Warranty.
Because of Advantech’s high quality-control standards and
rigorous testing, most of our customers never need to use our
repair and replacement service. If an Advantech product ever does
prove defective, it will be repaired at no charge during the warranty period. For out-of-warranty repairs, you will be billed according
to the cost of replacement materials, service time and freight.
Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered (e.g.
type of PC, CPU speed, Advantech products used, other
hardware and software used etc.). Note anything abnormal and
list any on-screen messages you get when the problem occurs.
2. Call your dealer and describe the problem. Please have your
manual, product and any other information readily available.
3. If your product is diagnosed as defective, obtain an RMA
(return material authorization) number from your dealer. This
allows us to process your return more quickly.
4. Carefully pack the defective product, a completely filled-out
Repair and Replacement Order Card and a photocopy of a
dated proof of purchase (such as your sales receipt) in a
shippable container. A product returned without dated proof of
purchase is not eligible for warranty service.
5. Write the RMA number visibly on the outside of the package
and ship it prepaid to your dealer.
Packing list
Before you begin installing your card, please make sure that the
following materials have been shipped:
• 1 PCA-6144V CPU card
• 1 6-pin mini-DIN keyboard & PS/2 mouse adapter
• 1 Hard disk drive (IDE) interface cable (40 pin)
• 1 Floppy disk drive interface cable (34 pin)
• 1 Parallel port adapter (26 pin) and COM2 adapter (9 pin) kit
• 3 Utility disks with SVGA utility programs and drivers
If any of these items are missing or damaged, contact your
distributor or sales representative immediately.
Contents
Chapter 1 Hardware Configuration ........................... 1
Introduction............................................................................ 2
Specifications.......................................................................... 3
System...................................................................................... 3
I/O ............................................................................................ 3
General..................................................................................... 4
Board layout............................................................................ 5
Jumpers and connectors........................................................ 6
Safety precautions.................................................................. 7
Jumper settings ...................................................................... 8
How to set jumpers .................................................................. 8
CPU type select (J1 - J16)........................................................ 9
RTC data erase On/Off (J17) ................................................. 11
Parallel port IRQ select (J18) ................................................ 12
Parallel port ECP/EPP DMA channel (J20, J21)................... 12
Watchdog timer (J28)............................................................. 12
COM2 settings for RS-232/485 (J23-27) .............................. 13
Installing DRAM (SIMMs) ................................................. 14
Chapter 2 Connecting peripherals .......................... 15
Enhanced IDE connectors (CN1) ....................................... 17
Floppy drive connector (CN4)............................................. 18
Parallel port (CN7)............................................................... 18
Keyboard & PS/2 mouse connectors (CN5)....................... 18
Reset switch (J29)................................................................. 19
Hard disk drive LED (D2)................................................... 19
VGA display connector (CN8)............................................. 19
Serial Ports............................................................................ 19
RS-232 connections (COM1) ................................................ 20
RS-232/485 connections (COM2) ......................................... 20
Power connectors (CN9, CN10)............................................. 21
External speaker connector (CN13)....................................... 21
Keyboard pin-header connector (CN14)................................ 22
Power LED and keylock (CN15) ........................................... 22
Chapter 3 AWARD BIOS SETUP ................................... 23
AWARD BIOS Setup............................................................ 24
Entering setup ........................................................................ 24
Standard CMOS setup ........................................................... 25
BIOS features setup ............................................................... 26
CHIPSET features setup ........................................................ 30
Power management setup....................................................... 31
Load BIOS defaults ............................................................... 32
Load setup defaults ................................................................ 32
Password setting..................................................................... 32
IDE HDD auto detection........................................................ 33
Save & Exit setup................................................................... 33
Exit without saving ................................................................ 33
Chapter 4 SVGA Setup ............................................... 35
SVGA driver installation ..................................................... 36
Installing from Windows........................................................ 36
Screen Control...................................................................... 38
Advanced features (Virtual Screen Control).......................... 40
DPMS (Display Power Management Signaling) ................ 43
Delay Time ............................................................................. 44
Activity Select........................................................................ 44
Clock ...................................................................................... 44
Alarm ..................................................................................... 45
Password Option .................................................................... 45
Startup On/Off ....................................................................... 45
Default ................................................................................... 45
Test ......................................................................................... 45
Save ........................................................................................ 45
Display driver Uninstallation .............................................. 46
Microsoft Windows NT........................................................ 47
Installation ............................................................................. 47
Microsoft Windows NT 3.5 Installation ................................ 47
Utilities installation .............................................................. 49
Utilities summary .................................................................. 50
Software drivers installation ............................................... 55
Appendix A Programming the Watchdog Timer .... 57
Appendix B Hardware Interrupt Information ........ 60
1
CHAPTER
Hardware
Configuration
This chapter gives background information on the PCA-6144V. It then shows you
how to configure the card to match your
application and prepare it for installation
into your PC.
Sections include:
• Card specifications
• Board layout
• Safety precautions
• Jumper settings
• Installing DRAM (SIMMs)
Chapter 1 Hardware Configuration 1
Introduction
The PCA-6144V is an all-in-one single board 486 computer that includes
an on-board SVGA controller. It packs all the functions of an industrial
computer, including display capabilities, on a single half-size card. The
PCA-6144V is fully PC/AT compatible, so your software will run without
modifications.
The on-board VL-bus SVGA controller uses the Trident TGUI 9440
chipset with 1 MB video memory. This chipset, used with the local bus,
enables 32-bit graphic throughput at up to 33 MHz. The TGUI 9440 also
offers Windows graphics acceleration. These features are excellent for
display-intensive applications.
Another feature of the PCA-6144V is the inclusion of a fast VL bus
enhanced IDE controller. This controller supports mode 4, which enables
data transfer rates in excess of 16 MB/second. Up to two IDE devices can
be connected, including large hard disks (up to 8 GB), CD-ROM drives,
Tape backup drives or other enhanced IDE devices.
On-board features also include two high-speed serial ports with 16C550
UARTs, one bidirectional SPP/EPP/ECP parallel port and a floppy drive
controller. In addition to the 486's 8 KB of on-chip cache memory, the
PCA-6144V includes an extra 128 KB of second level cache memory onboard.
If program execution is halted by a program bug or EMI, the board's 63level watchdog timer can automatically reset the CPU or generate an
interrupt. This ensures reliability in unmanned or standalone systems. The
timer interval of the watchdog timer is set by software, eliminating jumper
switch setting.
The PCA-6144V provides two 72-pin SIMM (Single In-line Memory
Module) sockets for its on-board system DRAM. These sockets give you
the flexibility to configure your system from 1 MB to 64 MB of DRAM
using the most economical combination of SIMMs.
2 PCA-6144V User's Manual
Specifications
System
• CPU: 80486SX/DX/DX2/DX4-25/33/40/50/66/75/100/120 MHz,
Cyrix 5x86-100/120 MHz, or AMD 5x86-133 MHz
• 2nd level cache: 128 KB on board
• Bus interface: ISA
• Chipset: VIA VT82C496G
• BIOS: AWARD
• Display controller: SVGA, VL bus, Trident TGUI chipset with
1 MB standard video memory. Provides 32-bit graphic throughput
with Windows acceleration. Supports resolutions up to 1280 x 1024
in 16 colors, 800 x 600 in 65536 colors, or 640 x 480 in 16.8
million colors.
• Processing ability: 32 bit
• Bus speed: 8 MHz (ISA)
• RAM memory: 1 MB to 64 MB. Uses two 72-pin SIMM sockets.
72-pin sockets accept 1, 2, 4, 8, 16 or 32 MB SIMMs
• Shadow RAM memory: Supports system and video BIOS of up to
256 KB in 16 KB blocks
I/O
• Enhanced IDE hard disk drive interface:
Fast VL bus. Supports up to two IDE (AT bus) large (up to 8 GB)
hard disk drives or other enhanced IDE devices. Supports mode 4
(16.6 MB/sec. data transfer rate). BIOS enabled/disabled
• Floppy disk drive interface: Supports up to two floppy disk drives,
5.25" (360 KB and 1.2 MB) and/or 3.5" (720 KB, 1.44 MB and 2.88
MB). BIOS enabled/disabled
Chapter 1 Hardware Configuration 3
• Enhanced bidirectional parallel port: Configurable to LPT1,
LPT2, LPT3, or disabled. Standard DB-25 female connector
provided. Supports SPP/EPP/ECP
• Serial ports: Two serial ports, both with 16C550 UARTs (or
compatible) with 16-byte FIFO buffer. COM1 is RS-232, COM2 is
RS-232 or RS-485. Support speeds up to 115 Kbps. Ports can be
individually configured as COM1, COM2 or disabled.
• Keyboard & PS/2 mouse connector: A 6-pin mini DIN keyboard
connector is located on the mounting bracket for easy connection of
a keyboard or a PS/2 mouse.
• Watchdog timer: Can generate a system reset or IRQ15. The timer
interval is 1 - 63 sec. (63 levels), set up by software.
General
• System performance (with 80486DX4-100 MHz CPU):
363 MHz, Landmark speed V2.0
• Max. power requirements: +5 V, 3.5 A
• Power supply voltage: +5 V (4.75 V to 5.25 V)
• Operating temperature: 32 to 140oF (0 to 60oC)
• Storage temperature: -40 to +176°F (-40 to +80oC)
• Humidity: 5 to 95%, non-condensing
• Board size: 7.3" (L) x 4.8" (W) (185 mm x 122 mm)
• Board weight: 1.2 lb. (0.5 kg)
4 PCA-6144V User's Manual
Board layout
CN8
CN9
CN10
1
1
1
J29
J28
J11 J13 J15 J16
CN1 CN4 CN7
+
D2
J12 J14
486
CPU
1
CN15
J23
J24
CN15
J9 J10
CN11
CN14
CN6
J25
J26
CN12
J27
J22
J20
CN13
1
J17
J6 J7 J8
CN5
J21
J18
J3
11
J1
Bank
1 0
J4
J2
J5
1
PCA-6144V PCB Layout
Chapter 1 Hardware Configuration 5
Jumpers and connectors
Connectors on the board link it to external devices such as hard disk
drives, a keyboard, or floppy drives. In addition, the board has a
number of jumpers which you use to configure it for your application.
The table below lists the function of each of the board jumpers and
connectors. Later sections in this chapter give instructions on setting
jumpers and detailed information on each jumper setting. Chapter 2
gives instructions for connecting external devices to your card.
PCA-6144V Jumpers
Number Function
J1-J8 CPU type select
J9 CPU voltage select
J10 CPU voltage select
J11 CPU type select
J12 CPU type select
J13 CPU type select
J14 Factory reserved
J15 CPU type select
J16 CPU type select
J17 RTC erase On/Off
J18 Parallel port IRQ select
J20 Parallel port DMA select
J21 Parallel port DMA select
J22 Factory reserved
J23 COM2 select
J24 COM2 select
J25 COM2 select
J26 COM2 select
J27 COM2 select
J28 Watchdog timer reset/IRQ15 select
J29 Reset
D2 HDD LED
6 PCA-6144V User's Manual
PCA-6144V Connectors
Number Function
CN1 EIDE connector
CN2 PC/104 connector (8 bit)
CN3 PC/104 connector (16 bit)
CN4 Floppy connector
CN5 Keyboard & PS/2 mouse DIN connector
CN6 COM2 pin-header connector
CN7 Parallel port connector
CN8 VGA DB-15 connector
CN9 Power connector (+5 V, +12 V)
CN10 Power connector (-5 V, -12 V)
CN11 COM1 DB-9 connector
CN13 External speaker connector
CN14 Keyboard pin-header connector
CN15 Power LED and keylock
Safety precautions
Follow these simple precautions to protect yourself from harm and
your PC from damage.
1. T o avoid electric shock, always disconnect the power from your PC
chassis before you work on it. Don’t touch any components on the
CPU card or other cards while the PC is on.
2. Disconnect power before making any configuration changes. The
sudden rush of power as you connect a jumper or install a card
may damage sensitive electronic components.
3. Always ground yourself to remove any static charge before you
touch your CPU card. Be particularly careful not to touch the chip
connectors. Modern integrated electronic devices, especially CPUs
and memory chips, are extremely sensitive to static electric
discharges and fields. Keep the card in its antistatic packaging
when it is not installed in the PC, and place it on a static dissipative
mat when you are working with it. Wear a grounding wrist strap
for continuous protection.
Chapter 1 Hardware Configuration 7
Jumper settings
This section tells how to set the jumpers to configure your card. It
gives the card default configuration and your options for each jumper.
After you set the jumpers and install the card, you will also need to
run the BIOS Setup program (discussed in Chapter 3) to configure the
serial port addresses, floppy/hard disk drive types and system operating parameters. Connections, such as hard disk cables, appear in
Chapter 2.
For the locations of each jumper, see the board layout diagram
depicted earlier in this chapter.
How to set jumpers
You configure your card to match the needs of your application by
setting jumpers. A jumper is the simplest kind of electric switch. It
consists of two metal pins and a small metal clip (often protected by a
plastic cover) that slides over the pins to connect them. T o “close” a
jumper you connect the pins with the clip. To “open” a jumper you
remove the clip. Sometimes a jumper will have three pins, labeled 1, 2
and 3. In this case you connect either pins 1 and 2 or 2 and 3.
3
2
1
OpenOpen
Open
OpenOpen
ClosedClosed
Closed
ClosedClosed
Closed 2-3Closed 2-3
Closed 2-3
Closed 2-3Closed 2-3
You may find pair of needle-nose pliers useful for setting the jumpers.
If you have any doubts about the best hardware configuration for your
application, contact your local distributor or sales representative
before you make any changes.
8 PCA-6144V User's Manual
CPU type select (J1 - J16)
In order for the system to function properly, the jumpers must be set to
accommodate the CPU installed on the CPU card.
CPU type select (J1 - J16)
CPU \ J1 2 345678 9 10 11 1213141516
AMD
DX2-66
(5 V)
AMD
DX2-66
(3.3 V)
AMD
DX4-100
(Standard)
AMD
DX4-100
(Enhanced)
AMD
DX4-120
Chapter 1 Hardware Configuration 9
CPU type select (J1 - J16), cont.
CPU \ J1 2 345678 9 10 11 1213141516
AMD
5x86-133
Cyrix
DX2-66
(5 V)
Cyrix
DX2-80
(3.45 V)
Cyrix
DX4-100
10 PCA-6144V User's Manual
CPU type select (J1 - J16), cont.
CPU \ J1 2 345678 9 10 11 1213141516
Cyrix
5x86-100
Cyrix
5x86-120
Intel
DX2-66
Intel
DX4-100
(3.3 V)
Chapter 1 Hardware Configuration 11
RTC data erase On/Off (J17)
R TC data is either kept or erased, depending upon J17's setting status.
RTC data erase On/Off (J17)
On (keep data) Off (lose data)
1 2 3 1 2 3
J17
Parallel port IRQ select (J18)
Parallel port IRQ select (J18)
IRQ5 IRQ7 (default)
1 2 3
1 2 3
J18
Parallel port ECP/EPP DMA channel (J20, J21)
You can set the DMA channel of the parallel port to either DMA 1 or
DMA 3.
Parallel port ECP/EPP DMA channel (J20, J21)
DMA 1 (default) DMA 3
1 2 3 1 2 3
J20
J21
12 PCA-6144V User's Manual
Watchdog timer (J28)
Watchdog timer system reset/IRQ15 select (J28)
Reset (default) IRQ15
J28
COM2 settings for RS-232/485 (J23-27)
COM2 settings for RS-232/485 (COM2)
RS-232 RS-485
1 2 3 1 2 3
J23
J24
J25
J26
J27
Chapter 1 Hardware Configuration 13
Installing DRAM (SIMMs)
On the left end of the card (away from the mounting bracket) are the
two SIMM (Single In-line Memory Module) sockets that hold the
card’s DRAM memory. See the board layout diagram depicted earlier
in this chapter.
You can use anywhere from 1 MB to 64 MB of DRAM with your
PCA-6144V. The card provides two 72-pin SIMM (Single In-Line
Memory Module) sockets that accept from 1 to 32 MB DRAM each.
The sockets (numbered from 1 to 2) are arranged into two banks. The
following table shows the bank assignments for the SIMM sockets:
Bank SIMM socket(s) Size
1 SIMM1 72-pin
2 SIMM2 72-pin
The PCA-6144V's memory sockets accept any combination of SIMMs
(up to 64 MB), inserted in any order.
14 PCA-6144V User's Manual
2
CHAPTER
Connecting
peripherals
This chapter tells how to connect peripherals, switches and indicators to the PCA6144V board. You can access most of the
connectors from the top of the board
while it is installed in the chassis. If you
have a number of cards installed, or your
chassis is very tight, you may need to
partially remove the card to make all the
connections.
Chapter 2 Connecting peripherals 15
The following table lists the connectors on the PCA-6144V. See
Chapter 1 for help locating the connectors.
Connectors
Label Component
CN1 EIDE connector
CN2 PC/104 connector (8 bit)
CN3 PC/104 connector (16 bit)
CN4 Floppy connector
CN5 Keyboard & PS/2 mouse DIN connector
CN6 COM2 pin-header connector
CN7 Parallel port connector
CN8 VGA DB-15 connector
CN9 Power connector (+5 V, +12 V)
CN10 Power connector (-5 V, -12 V)
CN11 COM1 DB-9 connector
CN13 External speaker connector
CN14 Keyboard pin-header connector
CN15 Power LED and keylock
JP29 Reset
D2 HDD LED
The following sections tell how to make each connection. In most
cases, you will simply need to connect a standard cable.
Warning! Always completely disconnect the power cord
from your chassis whenever you are working on
it. Do not make connections while the power is
on. Sensitive electronic components can be
damaged by the sudden rush of power . Only
experienced electronics personnel should open
the PC chassis.
Caution! Always ground yourself to remove any static
charge before touching the CPU card. Modern
electronic devices are very sensitive to static
electric charges. Use a grounding wrist strap at
all times. Place all electronic components on a
static-dissipative surface or in a static-shielded
bag when they are not in the chassis.
16 PCA-6144V User's Manual
Enhanced IDE connectors (CN1)
You can attach two IDE (Integrated Device Electronics) drives to
the PCA-6144V's internal controller. The PCA-6144V CPU card
has an EIDE connector, CN1.
Wire number 1 on the cable is red or blue, the other wires are gray.
Connect one end to connector CN1 on the CPU card. Make sure
that the red (or blue) wire corresponds to pin 1 on the connector
(on the right side). See Chapter 1 for help finding the connector.
Unlike floppy drives, IDE hard drives can connect in either
position on the cable. If you install two drives, you will need to set
one as the master and one as the slave. You do this by setting the
jumpers on the drives. If you use just one drive, you should set it
as the master. See the documentation that came with your drive for
more information.
Connect the first hard drive to the other end of the cable. Wire 1 on
the cable should also connect to pin 1 on the hard drive connector,
which is labeled on the drive circuit board. Check the documentation that came with the drive for more information.
Connect the second drive as described above on CN1.
Floppy drive connector (CN4)
You can attach up to two floppy disk drives to the PCA-6144V's
on-board controller. You can use any combination of 5.25"
(360 KB and 1.2 MB) and/or 3.5" (720 KB and 1.44 MB) drives.
The card comes with a 34-pin daisy-chain drive connector cable.
On one end of the cable is a 34-pin flat-cable connector. On the
other end are two sets of floppy disk drive connectors. Each set
consists of a 34-pin flat-cable connector (usually used for 3.5"
drives) and a printed-circuit-board connector (usually used for
5.25" drives). You can use only one connector in each set. The set
on the end (after the twist in the cable) connects to the A: floppy.
The set in the middle connects to the B: floppy.
Chapter 2 Connecting peripherals 17
Parallel port (CN7)
The parallel port is normally used to connect the CPU card to a
printer. The PCA-6144V includes an on-board parallel port,
accessed through a 26-pin flat-cable connector, CN7. The card
comes with an adapter cable which lets you use a traditional DB25 connector. The cable has a 26-pin connector on one end and a
DB-25 connector on the other, mounted on a retaining bracket.
The bracket installs at the end of an empty slot in your chassis,
giving you access to the connector.
To install the bracket, find an empty slot in your chassis. Unscrew
the plate that covers the end of the slot. Screw in the bracket in
place of the plate. Next, attach the flat-cable connector to CN7 on
the CPU card. Wire 1 of the cable is red or blue, and the other
wires are gray. Make sure that wire 1 corresponds to pin 1 of CN7.
Pin 1 is on the right side of CN7.
Keyboard & PS/2 mouse connectors
(CN5)
The PCA-6144V board provides a keyboard connector. A 6-pin
mini-DIN connector (CN5) on the card mounting bracket supports
single-board computer applications. The card comes with an
adapter to convert from the 6-pin mini-DIN connector to a
standard DIN connector and to a PS/2 mouse connector.
18 PCA-6144V User's Manual
Reset switch (J29)
You can connect an external switch to easily reset your computer.
This switch restarts your computer as if you had turned off the
power, then turned it back on. Install the switch so that it closes the
two pins of J29.
Hard disk drive LED (D2)
You can connect a LED to connector D2 to indicate when the HDD
is active. Marks on the circuit board indicate LED polarity.
VGA display connector (CN8)
The PCA-6144V provides a VGA controller for high resolution
VGA interface. CN8 is a DB-15 connector for VGA monitor input.
Serial Ports
The PCA-6144V offers two serial ports: COM1 in RS-232, COM2
in RS-232/485. These ports let you connect to serial devices (a
mouse, printers, etc.) or a communication network.
You can select the address for each port (3F8H [COM1], 2F8H
[COM2] or 3E8H) or disable it, using the BIOS Advanced Setup
program, covered in Chapter 3.
The card mounting bracket holds the serial port connector for the
one port, and the parallel port and serial port adapter kit (supplied
with the card) holds the connector for the other port. This lets you
connect and disconnect cables after you install the card. The DB-9
connector on the bottom of the bracket is the first RS-232 port,
COM1. The DB-9 connector on the adapter kit is the second serial
port, COM2.
Serial port connections (CN6, CN11)
Connector Address
CN6 COM2
CN11 COM1
Chapter 2 Connecting peripherals 19
RS-232 connection (COM1)
Different devices implement the RS-232 standard in different
ways. If you are having problems with a serial device, be sure to
check the pin assignments for the connector. The following table
shows the pin assignments for the card's RS-232 port:
RS-232 connector pin assignments
Pin Signal
1 DCD
2RX
3TX
4 DTR
5 GND
6 DSR
7RTS
8 CTS
9RI
1
5
COM1
6
9
RS-232/485 connection (COM2)
COM2 is an RS-232/485 serial port. The specific port type is
determined by jumper settings J23 - J27, as detailed in Chapter 1.
The following table shows the pin assignments for COM2.
RS-232/485 connector pin assignments
Pin RS-232 RS-485
1 DCD DATA2RX DATA+
3TX 4 DTR 5 GND GND
6 DSR 7RTS 8 CTS 9RI -
20 PCA-6144V User's Manual
1
5
DB-9 COM2 adapter CN6 pin-header
6
9
9 7 5 3 1
10 8 6 4 2
Power connectors (CN9, CN10)
V
If you prefer not to acquire power through PCA-6144V's backplane via the gold H-connectors, CN9 and CN10 also provide
power input connectors for +5 V, +12 V , -5 V, and -12 V.
Warning! Before making the connection, make sure the
voltage is absolutely correct and matched with
the right connector.
1 + 12 V
1 + 12 V
2 GND
2 GND
3 GND
3 GND
4 +5 V
4 +5 V
CN9 CN10
1 GND
2 +5 V
3 GND
4 + 12
External speaker connector (CN13)
The CPU card has its own buzzer. However, you can also connect
to the external speaker on your computer chassis. Connect leads to
connector CN13 as shown below:
External speaker connector (CN13)
Pin Function
1 Speaker out
2NC
3 GND
4 +5 VDC
Chapter 2 Connecting peripherals 21
Keyboard pin-header connector (CN14)
The PCA-6144V has a pin-header connector to support passive
backplane applications. Pin functions are as follows:
Keyboard pin-header connector (CN14)
Pin Function
1 KB clock
2 KB data
3NC
4 GND
5 +5 VDC
Power LED and keylock (CN15)
You can connect an LED to indicate when the CPU card is on. Pin
1 of CN15 supplies power to the LED, and Pin 3 is the ground.
You can use a switch (or a lock) to disable the keyboard. In this
state the PC will not respond to any input. This is useful if you do
not want anyone to change or stop a running program. Simply
connect the switch between Pins 4 and 5 of CN15. The pin
assignments for CN15 are as listed below:
Power LED and keylock (CN15)
Pin Function
1 LED power (+5 V)
2 VCC
3 GND
4 Keyboard lock
5 GND
22 PCA-6144V User's Manual
CHAPTER
3
AWARD BIOS SETUP
This chapter describes how to set the
card’s BIOS configuration data.
Chapter 3 Award BIOS setup 23
AWARD BIOS Setup
ROM PCI/ISA BIOS (2A4IBAK1)
CMOS SETUP UTILITY
AWARD SOFTWARE, INC.
ΣΤΑΝ∆ΑΡ∆ ΧΜΟΣ ΣΕΤΥΠ
ΒΙ ΟΣ ΦΕΑΤΥΡΕΣ ΣΕΤΥΠ
ΧΗΙ ΠΣΕΤ ΦΕΑΤΥΡΕΣ ΣΕΤΥΠ
ΠΟΩΕΡ ΜΑΝΑΓΕΜΕΝΤ ΣΕΤΥΠ
ΛΟΑ∆ ΒΙ ΟΣ ∆ΕΦΑΥΛΤΣ
ΛΟΑ∆ ΣΕΤΥΠ ∆ΕΦΑΥΛΤΣ
ESC : Quit : Select Item
F1 : Help (Shift)F2 : Change Color
Time, Date, Hard Disk Type...
Setup program initial screen
Award's BIOS ROM has a built-in Setup program that allows users
to modify the basic system configuration. This type of information
is stored in battery-backed RAM so that it retains the Setup
information when the power is turned off.
ΠΑΣΣΩΟΡ∆ ΣΕΤΤΙ ΝΓ
Ι∆Ε Η∆∆ ΑΥΤΟ ∆ΕΤΕΧΤΙ ΟΝ
ΣΑς Ε & ΕΞΙ Τ ΣΕΤΥΠ
ΕΞΙ Τ ΩΙ ΤΗΟΥΤ ΣΑςΙΝΓ
Entering setup
Turning on the computer and pressing <DEL> immediately will
allow you to enter Setup.
24 PCA-6144V User's Manual
Standard CMOS setup
Choose the "ST ANDARD CMOS SETUP" option from the
INITIAL SETUP SCREEN Menu, and the screen below is
displayed. This standard Setup Menu allows users to configure
system components such as date, time, hard disk drive, floppy
drive, display, and memory.
R OM PCI /IS A BIO S (2A 4IB AK1)
C MOS SE TUP UT ILI TY
A WAR D SOF TWARE, INC .
∆ ατε ( µµ:δδ:ψψ) : Μον, ϑ υλψ 17, 1995
Τ ιµε (ηη: µµ :σσ ) : 17 : 13 : 24
ΗΑΡ∆ ∆ΙΣΚ ΤΨΠΕ ΣΙΖΕ ΧΨΛΣ ΗΕ Α∆ ΠΡΕ ΧΟΜΠ ΛΑΝ∆Ζ ΣΕΧ ΤΟΡ ΜΟ∆Ε
Πριµαρψ Μαστερ : Υσερ 547 1060 16 65535 1059 63 Νορµαλ
Πριµαρψ Σλ αϖε : Νονε 0 0 0 0 0 0 −−−−−
∆ ριϖε Α : 1. 44Μ, 3.5 ιν.
∆ ριϖε Β : 1. 2Μ, 5. 25 ιν.
ςι δεο : ΕΓΑ/ ςΓΑ
Ηαλτ Ον : Αλλ Ε ρρορσ
E SC : Quit : Selec t Ite m
F 1 : Help (Sh ift)F2 : C han ge Col or
CMOS setup screen
Βασε Μεµ ορψ: 640Κ
Ε ξτενδεδ Μεµ ορψ: 15360Κ
Οτηερ Μεµορ ψ: 384Κ
Τ οταλ Μεµορψ: 16384Κ
P U/P D/+ /-: Mo dify
Chapter 3 Award BIOS setup 25
BIOS features setup
By choosing the "BIOS FEATURES SETUP" option from the
INITIAL SETUP SCREEN Menu, the screen below is displayed.
This sample screen contains the manufacturer's default values for
the PCA-6144V.
RO M PC I /I S A BI O S (2 A 4 IB A K 1 )
ςιρυσΩαρνινγ : Ενα βλεδ
ΧΠ ΥΙ ντερνα λΧ α χη ε : Εναβλεδ
ΕξτερναλΧ αχηε : Εναβ λεδ
Θυι χκ Ποωερ Ον Σελφ Τεστ : Ενα βλεδ
Β οοτ Σεθυ ενχε : Α , Χ
Σωαπ Φ λοπ πψ∆ρι ϖ ε : ∆ισα βλεδ
Β οοτ Υ πΦλοππψΣεεκ : Ενα βλ εδ
Β οοτ υπ Ν υµ Λοχκ Στα τυσ : Ο ν
Β οοτ Υ πΣψ σ τεµΣπεεδ : Η ιγη
Ι∆ΕΗ∆∆Β λοχκ Μοδε : Ενα βλεδ
Γα τε Α20 Οπτιον : Ν ορµ α λ
ΜεµορψΠα ριτψΧ η εχκ : Ενα βλεδ
Τψπεµα τι χ Ρατε Σεττι νγ : ∆ισα βλεδ
Τψπεµα τι χ Ρατε (Χ η α ρ / Σεχ) : 6
Τψπεµα τι χ ∆ελαψ(Μσεχ) : 250
Σεχυρι τψΟπτιον : Σετυπ
BIOS features setup
Virus Warning
During and after the system boots up, any attempt to write to the
boot sector or partition table of the hard disk drive will halt the
system. In this case, if Virus Warning is enabled, the following
error message will automatically appear:
ςιδεο ΒΙΟΣ Σηα δοω : Εναβλεδ
Χ8000ς−ΧΒΦΦΦΣηα δοω : ∆ισ α βλεδ
ΧΧ 000−ΧΦΦΦΦ : ∆ισα βλεδ
∆0000−∆ 3ΦΦΦ : ∆ι σαβλ εδ
∆4000−∆ 7ΦΦΦ : ∆ι σαβλ εδ
∆8000−∆ ΒΦΦ Φ : ∆ισ α βλεδ
∆Χ000−∆ ΦΦΦΦ : ∆ισαβλεδ
ES C: Qui t
F1 :He l p
F5 :Ol dVa l u e s
F6 :Lo a dBI O SDe f a ul t s
F7 :Lo a dSe t u pDe f au l t s
:S e le c tIt e m
PU / PD / + / -:M o d if y
Disk boot sector is to be modified
!WARNING!
Type "Y" to accept write or "N" to abort write
Award Software, Inc.
You can run the anti-virus program to locate the problem.
If Virus Warning is Disabled, no warning message will appear if
anything attempts to access the boot sector or hard disk partition.
26 PCA-6144V User's Manual
CPU Internal Cache/External Cache
Depending on the CPU/chipset design, these options can speed up
memory access when enabled.
Quick Power On Self Test
This option speeds up the Power-On Self T est (POST) conducted
as soon as the computer is turned on. When enabled, BIOS
shortens or skips some of the items during the test. When disabled,
normal POST procedures assumes.
Boot Sequence
This function determines the sequence in which the computer will
search the drives for the disk operating system (i.e. DOS). The
default value is "A, C".
C,A System will first search the hard drive, then the floppy drive.
A,C System will first search the floppy drive, then the hard drive.
Boot Up Floppy Seek
During POST, BIOS will determine if the floppy disk drive
installed is 40 or 80 tracks. 360 KB type is 40 tracks while 720
KB, 1.2 MB, and 1.44 MB are all 80 tracks.
Enabled BIOS searches the floppy drive to determine if it is 40 or 80
tracks. Note that BIOS cannot differentiate 720 KB, 1.2 MB,
and 1.44 MB type drives as they are all 80 tracks.
Disabled BIOS will not search for the floppy drive type by track
number. Note that there will not be any warning message if
the drive installed is 360 KB.
Boot Up NumLock Status
The default is "On".
On Keypad boots up to number keys.
Off Keypad boots up to arrow keys.
Chapter 3 Award BIOS setup 27
Boot Up System Speed
High Sets the speed to high
Low Sets the speed to low
IDE HDD Block Mode
Enabled Enable IDE HDD Block Mode. BIOS will detect the block size
of the HDD and send a block command automatically.
Disabled Disable IDE HDD Block Mode
Gate A20 option
Normal The A20 signal is controlled by the keyboard controller or
chipset hardware
Fast Default: Fast. The A20 signal is controlled by Port 92 or
chipset specific method.
Memory parity check
Enabled Normal memor y parity check. If system DRAM has no parity
bit, the the system will display "RAM parity error".
Disabled Ignores memory parity check even if DRAM has no parity
bit. The the system will display "RAM parity error".
Typematic Rate setting
The typematic rate determines the characters per second accepted
by the computer. Typematic Rate setting enables or disables the
typematic rate.
Typematic Rate (Char/Sec)
BIOS accepts the following input values (character/second) for
Typematic Rate: 6, 8, 10, 12, 15, 20, 24, 30.
Typematic Delay (msec)
When holding down a key, the Typematic Delay is the time interval
between the appearance of the first and second characters. The
input values (msec) for this category are: 250, 500, 750, 1000.
28 PCA-6144V User's Manual
Security Option
This setting determines whether the system will boot if the
password is denied, while limiting access to Setup.
System The system will not boot, and access to Setup will be denied
if the correct password is not entered at the prompt.
Setup The system will boot, but access to Setup will be denied if
the correct password is not entered at the prompt.
Note: T o disable security , select PASSWORD SETTING in the
main menu. At this point, you will be asked to enter a password.
Simply hit the <ENTER> key to disable security. When security is
disabled, the system will boot, and you can enter Setup freely.
Video BIOS Shadow
This determines whether video BIOS will be copied to RAM,
which is optional according to the chipset design. When enabled,
Video Shadow increases the video speed.
C8000 - CFFFF Shadow/DC000-DFFFF Shadow
These determine whether optional ROM will be copied to RAM in
blocks of 16 KB.
Enabled Optional shadow is enabled
Disabled Optional shadow is disabled
Chapter 3 Award BIOS setup 29
CHIPSET features setup
By choosing the "CHIPSET FEATURES SETUP" option from the
INITIAL SETUP SCREEN Menu, the screen below is displayed.
This sample screen contains the manufacturer's default values for
the PCA-6144V.
RO M PC I / I S A BI O S ( 2 A4 I B A K 1 )
CH I P S E T FE A T U R E S SE T U P
AW A R D SO F T W A R E , IN C .
ΑυτοΧ ο νφιγυρα τι ον : Εναβλεδ
ΙΣΑΒυ σΧλοχκ : 1/ 4 ΠΧ ΛΚ
Λ Β∆# Σα µ πλε Ποι ντ : Ενδ οφ Τ2
Χαχη ε Ωρι τε Χψ χλε : 2 ΧΧ ΛΚ
Χαχη ε Βυ ρσ τ Ρεαδ Χ ψχλε : 1 Χ ΧΛ Κ
Λ 2Χ αχηε/∆ΡΑΜ Χψ χλε ΩΣ : 2 Χ ΧΛ Κ
∆Ρ ΑΜΡΑΣ τοΧ ΑΣ∆ελαψ : 3 ΧΧΛΚ
∆Ρ ΑΜΩριτε Χ ψχλε : 1 ΩΣ
∆Ρ ΑΜΩριτε Χ ΑΣΠυλσε : 2 ΧΧ ΛΚ
∆Ρ ΑΜΧΑ ΣΠρεχηα ργε Τιµε : 1 ΧΧΛΚ
∆Ρ ΑΜΡΑΣ τοΜΑ∆ελαψ : 1 ΧΧΛΚ
∆Ρ ΑΜΣ πεεδ : Φαστερ
∆Ρ ΑΜΣ λοωΡεφρεση : ∆ισ α βλ εδ
ΧΠΥΒυ ρσ τ Ω ριτε : ∆ισ α βλεδ
Λ 2Χ αχηε Π ολιχψ : Ωρι τε Τη ρυ
Λ 2Χ αχηε Ταγ Βιτσ : 8 βι τσ
CHIPSET features setup
Note: If you enable the IDE HDD block mode, the enhanced IDE
driver will be enabled.
Ονβοαρδ 496ΒΙ∆ΕΠορτ : Βο τη
Ι∆Ε0 Μα στερ Μοδε : Α υτο
Ι∆Ε0 Σλαϖε Μοδε : Αυτο
Ι∆Ε1 Μα στερ Μοδε : Α υτο
Ι∆Ε1 Σλαϖε Μοδε : Αυτο
Ι∆ΕΠρεφετχηΡεαδ Βυ φφερ : ∆ι σα βλεδ
Ι∆ΕΗ∆∆Β λο χκΜοδε : ∆ισαβλεδ
Ονβοαρδ Φ ∆ ΧΧοντρολλερ : Εναβ λεδ
Ονβοαρδ Σερια λΠορτ 1 : ΧΟ Μ1
Ονβοαρδ Σερια λΠορτ 2 : ΧΟ Μ2
ΧΟ Μ3 &Χ ΟΜ4 Α δδρεσ σ : 338Η, 238Η
Ονβοαρδ Π αραλλελ Πορτ : 278Η
Παραλλελ Πορτ Μοδε : Ν ορµ α λ
ES C :Qu i t
F1 :He l p
F5 :Ol dV a lues
F6 :Lo a dB IOS De f a ul t s
: Se le c tI t e m
PU / P D / + / - : Mo d i fy
(S h i f t ) F 2 : Co l o r
30 PCA-6144V User's Manual
Power management setup
The power management setup controls the CPU cards' "green"
features. The following screen shows the manufacturer's default.
ROM PCI/I SA BI OS (2A4IBAK1)
POWER MAN AGEMENT SETU P
AWARD SOFTWARE, INC.
ΠοωερΜανα γεµεντ : ∆ισαβλεδ
ΠΜΧοντρολβψΑΠΜ : Ψεσ
ςιδεοΟφφ Οπτιον : Συσπ, Στβψ−> Οφφ
ςιδεοΟφφ Μετηοδ : ς/ΗΣΨΝΧ+Βλανκ
Συ σπενδ Σωι τχη : Εναβλεδ
Η∆∆Οφφ Αφτερ : ∆ισαβλεδ
∆οζε Μοδε : ∆ισαβλεδ
ΣτανδβψΜοδε : ∆ι σα βλεδ
Συ σπενδ Μοδε : ∆ισαβλεδ
ΠΧΙ ΜαστερΑχτι ϖι τψ: Εναβλεδ
ΧΟΜΠορτσ Αχτιϖι τψ : Εναβλεδ
ΛΠΤ ΠορτσΑχτιϖιτψ : Εναβλεδ
Η∆∆ΠορτσΑχτιϖι τψ : Εναβλεδ
∆ΜΑΠορτσ Αχτιϖι τψ : Εναβλεδ
ςΓΑΑχ τιϖιτψ : ∆ισαβλεδ
ΙΡΘ3 ( ΧΟ Μ2) : Εναβλ εδ
∗∗ ΠΜΤιµερσ ∗∗
∗∗ ΠΜΕϖεντσ ∗∗
Power management
Power Management
This option allows you to determine if the values in power management are disabled, user-defined, or predefined.
ΙΡΘ4 ( ΧΟΜ 1) : Εναβλεδ
ΙΡΘ5 ( ΛΠΤ2) : Εναβλεδ
ΙΡΘ6 ( Φλοππψ∆ι σκ) : Εναβλεδ
ΙΡΘ7 ( ΛΠΤ1) : Εναβλεδ
ΙΡΘ8 ( ΡΤΧΑ λαρµ) : ∆ισ αβλεδ
ΙΡΘ9 ( Ι ΡΘ2 Ρεδι ρ) : Εναβλεδ
ΙΡΘ10 ( Ρεσερϖεδ) : Εναβλεδ
ΙΡΘ11 ( Ρεσερϖεδ) : Εναβλεδ
ΙΡΘ12 ( ΠΣ/2 Μουσε) : Εναβλεδ
ΙΡΘ13 ( Χο προχεσσορ) : Εναβλεδ
ΙΡΘ14 ( Ηαρδ δισκ) : Ενα βλ εδ
ΙΡΘ15 ( Ρεσερϖεδ) : Εναβλεδ
ESC:Quit
F1 : Help
F5 : Old Values
F6 : LoadBIOSDefaul ts
F7 : LoadSetup Defau lts
: Se lect Item
PU/PD/+/- : Modify
(Shift)F2 : Color
PM Control by APM
This option is only effective if APM (Advanced Power Management) is installed. If under APM control, system BIOS will wait
for APM's prompt before entering any power management mode.
Note: If there is a task running, the APM will not prompt BIOS to
activate any power saving mode.
Video Off Option
This option allows you to determine if the screen will always stay
on, or turn off when in SUSPEND and/or STANDBY modes.
Chapter 3 Award BIOS setup 31
Video Off Method
This option controls to what degree will the video be downed:
1. Blank screen only turns off the screen
2. V/H SYNC + Blank will also turn off the V-SYNC and HSYNC signals from the VGA cards to the monitor
3. DPMS is enabled only for VGA cards that support DPMS.
Suspend Switch
This enables or disables the External Suspend Switch.
PM Timers
The options under this category allow you to disable or set the
duration of time that the system is inactive before entering the
listed modes.
HDD Off After
You can choose to turn the HDD off after a one of the time interval
listed, or when the system is in Suspend mode. If in a power saving
mode, any access to the HDD will wake it up.
Doze Mode and Standby Mode
These modes will put the system into low speed or 8 MHz. Screen
may turn off depending on the setting for Video Off method.
Suspend Mode
Suspend mode puts the system into low speed or 8 MHz, and the
system clock is stopped. Screen may turn off depending on the
setting for Video Off method.
Note: System Doze, Standby Doze, and System
Suspend will be loaded with predefined values if
the Power Management option is not set to "User
defined".
Note: HDD will not power down if the Power Manage-
ment option is disabled.
32 PCA-6144V User's Manual
PM Events
Each of the options in this category can be enabled or disabled.
If a particular option is enabled, the activity of the specified
event will cause the PM timers for Doze, Standby, and Suspend
modes to reload. If disabled, the specified event will have no
effect on the PM timers, and the prevailing power saving mode
continues.
Chapter 3 Award BIOS setup 33
Load BIOS defaults
"LOAD BIOS DEF AULTS" indicates the most appropriate
values for the system parameters for minimum performance.
These default values are loaded automatically if the stored
record created by the Setup program becomes corrupted (and
therefore unusable).
Load setup defaults
"LOAD SETUP DEF AULTS" loads the values required by the
system for maximum performance.
Password setting
To change, confirm, or disable the password, choose the
"PASSWORD SETTING" option form the Setup main menu
and press [Enter]. The password can be at most 8 characters
long.
Remember, to enable this feature. You must first select the
Security Option in the BIOS FEATURES SETUP to be either
"Setup" or "System."
IDE HDD auto detection
"IDE HDD AUTO DETECTION" automatically self-detect for
the correct hard disk type.
Save & Exit setup
If you select this and press the [Enter] key, the values entered in
the setup utilities will be recorded in the CMOS memory of the
chipset. The microprocessor will check this every time you turn
your system on and compare this to what it finds as it checks
the system. This record is required for the system to operate.
34 PCA-6144V User's Manual
Exit without saving
Selecting this option and pressing the [Enter] key lets you exit the
Setup program without recording any new values or changing old
ones.
Chapter 3 Award BIOS setup 35
36 PCA-6144V User's Manual
CHAPTER
4
SVGA Setup
The PCA-6144V features an on-board
VGA interface. This chapter provides
information about:
• SVGA installation
• Display utilities and drivers
• Software installation
Chapter 4 SVGA Setup 37
SVGA driver installation
Installing from Windows
The graphic installation program (TINSTALL) supports a simple
6 step installation procedure for the display driver setup program,
the power management program and the UNinstall program.
To use TINSTALL, follow the 6 steps below:
1. Ensure that MS Windows 3.1 is up and running properly,
using the standard VGA driver.
2. Select the MAIN group in Program Manager.
3. Select RUN from the FILE menu on the menu bar.
5. Type in A:TINSTALL (if the display driver disk is in the B
drive, type in B:TINSTALL instead), as shown below, and
then press <ENTER>.
6. A menu will appear, presenting a choice of Express or
Custom Installation.
38 PCA-6144V User's Manual
Express Installation
Express Installation automatically copies the display drivers into
the TRIDENT.AGI directory and the Utility files into the
TRIDENT.UTL directory. Once all files are copied, a program
group called DISPLAY DRIVER AND UTILITIES will be
created.
Custom Installation
Custom Installation allows control over where files are stored and
in what program group the icons are placed. The first dialog box
that appears shows the default directory to which the display
drivers will be copied.
To change the directory name:
1. Delete the default name.
2. Enter the desired directory name.
3. Once the desired directory name is selected, continue the
installation procedure by selecting Continue, or by pressing
<ENTER>.
The next dialog box displays a summary of where files are stored.
4. Select Continue to copy the drivers and utilities files.
When all files are copied, the program will present a choice of
program groups where the icons will be created. Create a new
group to place the utility icons or select from pre-existing groups
(e.g. Main, Applications, Accessories, etc.).
Tinstall icons
The Tinstall program creates three icons:
a. Screen Control (Used to configure display drivers)
b. DPMS (Used for power management configurations)
c. UNinstall (Used to delete the installed TRIDENT drivers)
NOTE: Different “display driver set” versions cannot be
installed to the same directory name.
“Display driver sets” of the same version number ( e.g. UA6.0 )
will replace the existing one.
Chapter 4 SVGA Setup 39
Screen Control
The Screen Control panel contains controls for setting screen
resolution, color depth, font size, refresh rates. Not all
combinations of screen resolution, color depth, font size and
refresh rate are attainable.
Color depths of 16, 256, 64K, or 16.7M colors can be selected
by clicking next to the desired option. Color depth determines
the number of colors that may be simultaneously displayed on
the screen. The selected color depth determines the possible
resolutions.
Screen resolutions of 640x480, 800x600, 1024x768,
1280x1024, or 1600x1200 can be selected by clicking next to
the available options. The virtual screen size is automatically
adjusted to be at least as large as the selected screen resolution.
Available refresh rates are dependent on the selected color
depth and resolution. The “Back to Default” option is used to
reset the refresh rate to the factory default value.
To open Screen Control, double click on its icon. The following figure shows the Screen Control interface:
40 PCA-6144V User's Manual
Configuring the Display Driver
1. Select the color depth first. If the current driver does not
support the selected color depth, then Windows will have to
be restarted.
2. Select the resolution.
3. Select the font size (if available as an option).
4. Select the refresh rate.
5. Click on OK. If the current driver does not support the
selected configuration, Windows will have to be restarted.
Note: Hot Key Control should be enabled before
going into advanced setup. There is no virtual
screen support for 16 colors. 1280x1024 is only
available for 16 colors.
Chapter 4 SVGA Setup 41
Advanced features (Virtual Screen Control)
Virtual Screen Control
Standard display resolutions are 640x480, 800x600, 1024x768,
1280x1024. The amount of display memory used depends on the
selected resolution and color depth. A substantial amount of
display memory is left unused for lower resolutions. The Virtual
Screen features take advantage of this unused memory by “expanding” the display area into the off-screen area.
Virtual Screen Control allows the user to make effective use of a
display screen larger than the standard 640x480, 800x600 or
1024x768, and the standard resolution is the center of the screen.
The user can “pan” around the larger Virtual Screen area by the
use of a standard mouse or a set of “HOT KEYS.” For example, it
is possible to select a resolution of 640x480 and set the Virtual
Screen size to 800 x 600. Thus, the 640 x 480 screen sits at the
center of a 800 x 600 matrix, and the user can “pan” through the
entire 800x600 matrix in a 640x480 window, as shown below.
Panning allows trav ersing a larger screen through a smaller window .
VIRTUAL SCREEN AREA ACTUAL DISPLAY AREA
42 PCA-6144V User's Manual
The advanced features can be accessed by pressing <ALT> + D
or by clicking on the Advanced... button on the Screen Control
interface. This opens up an extension of the Main Panel that
presents the following features:
1. Hot Key selection, which allows you to set up predefined
key strokes for specific virtual screen related actions.
2. Turn On virtual screen, which allows the use of the
predefined virtual screen sizes. The predefined virtual screen
sizes are selected by clicking next to available options. The
sizes of the available predefined virtual screens are dependent on the selected color depth and resolution.
3. Customize virtual screen area, which opens up a new screen
titled Virtual Screen Advanced Settings:
Chapter 4 SVGA Setup 43
Virtual Screen Advanced Settings
• Freeze Screen: Disables the panning feature, giving the
illusion of a frozen screen but keeping other virtual screen
functions available. Hot key functions are available for this
feature.
• Linear Frame Buffer Address: The Linear Addressing
driver automatically detects the system’s memory size and sets
the frame buffer to an unused area above the system memory.
The Linear Frame Buffer Address setting is useful in avoiding
conflicts with Windows applications, which use the same
linear frame buffer address as the Display Driver. Addresses
between 18 and 63 MB can be selected. If there is no conflict,
the default setting is highly recommended.
• Border Space: The Border Space option is used to set up a
border (thickness measured in pixels) within the displayable
area. The border is used as a marker for panning the screen,
i.e. when the cursor hits against this border, screen panning
occurs as shown below:
• Pan Set Hot Key: Hot keys can be set up to pan the virtual
screen left, right, up and down. The feature has to be enabled
by clicking on the Enable box before hot keys can be selected.
Once all selections are made, click on OK or press <ALT> + O
to exit the advanced setup.
44 PCA-6144V User's Manual
DPMS (Display Power Management
Signaling)
The POWER MANAGEMENT program is designed for energysaving monitors that conform to the VESA Display Power
Management Signaling (DPMS) standard.
WARNING:
The program offers three power-down modes:
1. Standby (minimum power savings)
2. Suspend (substantial power savings)
3. Off state (maximum power savings)
THE USE OF THIS PROGRAM IS NOT RECOMMENDED FOR MONITORS THAT DO NOT
SUPPORT THE VESA DPMS STANDARD.
Chapter 4 SVGA Setup 45
The program monitors for mouse and/or keyboard activity. When
activity is not detected for a specified delay period (controlled by
the Delay Time parameter), the program signals the
TGUI9440AGi to enter the selected power-down modes.
The Display Power Management program offers several options to
customize the DPMS operation.
Delay Time
The delay time to enter each mode can be set by entering the
value (in minutes) in the Delay Time parameters. Values can be
entered by either clicking on the count-up or count-down button,
or by clicking on the number, deleting it, and typing in the
desired time in minutes, as shown below.
Activity Select
The Activity Select option selects which activity the program
senses in order to restore the display to the monitor. For example,
if both mouse and keyboard are selected, then either activity will
re-establish the powered down signals.
Clock
Turning on the clock enables the digital count down display.
46 PCA-6144V User's Manual
Alarm
If the Alarm option is enabled, then the last 5 seconds of countdown to Stand by mode is synchronized with beeps from the PC
speaker.
Password Option
The Password Option sets up a password to get back onto the
screen.
• A password is set up by first clicking on the box marked
PASSWORD PROTECTED or by pressing <ALT> + P (this is
confirmed by the presence of an “X” in the box).
• Press <ALT> + S or click on the box marked SET PASSWORD.
• Type in the selected password (twice) and select OK, or press
<ENTER>.
Startup On/Off
This option installs the Display Power Management program onto
the Windows Startup file, so that DPMS is active upon entering
Windows.
Default
The default button sets all parameters back to the factory default
values.
Test
The test feature is used to give a demonstration of the DPMS
power down function.
Save
This feature is used to save all the current settings. Once all
settings are selected, the program is activated by pressing <ALT>
+ O or by clicking on the box marked Turn On DPMS.
Chapter 4 SVGA Setup 47
Display driver Uninstallation
The UNinstall program enables the user to safely delete specific
display drivers or an entire display driver set.
To remove an entire Display Driver Set, complete the following
steps:
1. Using the arrow keys or mouse, select the Display Driver
Set that is to be removed (the set to be deleted should be
highlighted).
2. Once the desired Driver Set is selected, simply select the
Delete button or press <ENTER>.
NOTE: The UNinstall program will not permit the
deletion of a Display Driver set that is currently
used.
To remove an individual driver from a Display Driver Set,
complete the following steps:
1. Using the arrow keys or mouse, select the Display Driver
Set that is to be removed (the set to be deleted should be
highlighted).
2. Once the desired Driver Set is selected, click on the Enter
button. This will pull up a list of available display drivers.
3. Select the display driver to be deleted by using the mouse or
the up/down arrow keys to scroll through the list.
4. Click on the Delete button or press <ALT> + D to delete the
selected display driver.
48 PCA-6144V User's Manual
Microsoft Windows NT
Installation
1. Run the Microsoft Windows NT Setup program located in
the Main group of Program Manager.
2. Select Change System Settings from the Options pull-
down menu.
3. Select Other from the display options.
4. Microsoft Windows NT 3.1 will prompt you for the correct
path where the Trident drivers are located. Enter the
path “X:\TVGAUTIL\NTDRV\NT31\” where X is the
drive where Disk 2 of the Trident Utility and DOS
Application drivers have been installed .
5. A list of all Trident drivers will appear. Select the resolu-
tion and color depth desired.
6. Restart Microsoft Windows NT. The desired Trident driver
will then be in effect.
NOTE: If you select a color depth or resolution that is
not supported by your card, NT will substitute
640x480 in 256 colors for the display.
Microsoft Windows NT 3.5 Installation
1. Run the Microsoft Windows NT display Setup program
located in the Control Panel of the Main group.
2. Select Change Display Type... button from the Display
Settings options.
3. Select Change... button from the Display Type options.
4. Select Other... button from the Select Device options.
Chapter 4 SVGA Setup 49
5. Microsoft Windows NT 3.1 will prompt you for the correct
path where the Trident drivers are located. Enter the
path “X:\TVGAUTIL\NTDRV\NT31\” where X is the drive
where Disk 2 of the Trident Utility and DOS Application
drivers have been installed.
6. A list of all Trident drivers will appear. Select the resolution
and color depth desired.
7. Restart Microsoft Windows NT. The desired Trident driver
will then be in effect.
NOTE: If you select a color depth or resolution that is
not supported by your card, NT will substitute
640x480 in 256 colors for the display.
50 PCA-6144V User's Manual
Utilities installation
The Utility Installation program is used to install and retrieve
instructions on:
a) Utility programs.
b) Non-Windows applications display drivers.
The Utility installation program is run by executing the follow-
ing steps:
1. Insert the UA 6.0 disk # 2 in the floppy drive.
2. Type in README at the floppy drive prompt.
3. A numbered list of available destination drives will be
displayed on the screen. Select the destination drive by
typing in the corresponding number, e.g. to select drive C,
type in 1, as shown below.
Chapter 4 SVGA Setup 51
4. Files and subdirectories will be expanded into the newly
created directory TVGAUTIL. A new menu will then be
displayed on the screen, showing a list of on-line instructions:
5. Selecting A will display the contents of all drivers in the
list.
6. Selecting B will display instructions on the available utility
programs.
7. Selecting C will display instructions on how to install
display drivers for non-Windows applications.
Utilities summary
SVM. EXE
SVM is a menu-driven program designed to select and test all
video modes available to the adapter.
How To Use SVM
The SVM program can be executed in either of two ways: by
calling up the menu and selecting from the menu choices, or by
entering the desired mode directly with a specific command line.
52 PCA-6144V User's Manual
How To Use SVM From The Menu
1. Switch directory to “X:\TVGAUTIL\UTILITY” where X is the
drive where Disk 2 of the Trident Utility and DOS Application
drivers have been installed .
2. Type SVM to pull up the menu. You will see the following
screen:
The top bar shows the available color depths. Move through the
options with the right/left arrow keys.
The program provides all the different resolutions supported by the
chip under each color depth. These resolutions are traversed by the
up/down arrow keys.
The graphics adapter can be tested for each resolution/mode by first
highlighting the selection by use of the arrow keys, then pressing
the F5 key.
The graphics adapter can be run at a selected mode by first selecting
Chapter 4 SVGA Setup 53
the mode, and then pressing <ENTER>.
How to Use SVM From The Command Line
The SVM program may be used to select a mode directly
from the command line following two simple steps:
1. Switch directory to “X:\TVGAUTIL\UTILITY” where
X is the drive where Disk 2 of the Trident Utility and
DOS Application drivers have been installed.
2. Type in: SVM [mode number]ENTER.
For example, to run the graphics adapter in mode 62H, the
command for item 2 above would be:
SVM 62 ENTER
SMONITOR
SMONITOR is designed to set the monitor group and the
monitor type:
Usage: SMONITOR <GROUP|OPTION>
Set Monitor Group
The graphics extended modes set by the graphics card’s
BIOS are sorted into six groups categorized by the monitor’s refresh rate. The group setting as below:
Resolution Group
01 23 45 67
640X400 70 70 70 70 70 70 70 70
640x480 60 60 75 85 95 95 95 95
800x600 56 60 75 75 85 85 95 95
1024x768 87i 87i 60 70 75 85 95 95
1280x1024 87i 87i 87i 87i 60 60 60 60
54 PCA-6144V User's Manual
1600x1200 87i 87i 87i 87i 87i 87i 87i 87i
OPTION:
C SET COLOR MONITOR
M SET MONOCHROME MONITOR
The default group number is 4.
If you want set the monitor group, type:
SMONITOR GROUP
where GROUP is one of the group number listed above.
Set Monitor Color
Switches between color and monochrome display. Some monitors
(most notably Samsung monitors manufactured before 2/8/91) do
not adhere to the standard IBM pinout definitions, which causes
the VGA card to boot up in monochrome instead of color. This
utility may be used to correct the problem.
To set the monitor as color, type: SMONITOR C
or type: SMONITOR M
to set monochrome monitor.
TVGACRTC
The TVGACRTC program allows the adjustment of video display
parameters so that images are optimally sized and centered on the
screen. Adjustable parameters include:
• Horizontal size and position.
• Vertical size and position.
• Pixel frequency.
The program is started from the DOS prompt by typing in
TVGACRTC from the C:\TVGAUTIL\UTILITY directory.
The first section of the program is used to define a given name for
the adjustments to be made.
Chapter 4 SVGA Setup 55
1. Press <ENTER> to add a new monitor entry and type in the
name of the manufacturer, followed by <ENTER> keystroke.
The program will allow any name to be typed in.
2. Type in the associated comments for the monitor settings
and press <ENTER>.
3. A mode table will be displayed, presenting all the adjustable
modes as shown below:
4. This table is traversed through the use of the up/down
arrow keys. The mode highlighted is the selected mode for
adjustment.
5. Select the mode to be adjusted and press <ENTER>.
56 PCA-6144V User's Manual
6. Select the desired pixel rate by scrolling the list using the up/
down arrow keys, followed by pressing <ENTER> twice.
7. The screen alignment test pattern will then be displayed.
The up/down arrow keys are used to adjust the vertical
positioning of the screen. The left/right arrow keys are
used for horizontal alignment of the screen. The Home/End
keys are used for horizontal screen sizing and the Page
Up/Down keys are used for vertical screen sizing. Once the
screen position and size is adjusted, press <ENTER>,
followed by the <ESC> keystroke.
8. To save the settings, type Y and press <ENTER>. The
program will then modify the Config.sys file.
9. At this point press <ESC> and reboot the system to enable the
parameter changes.
Software drivers installation
After selecting Drivers from the Main Menu in Program Manager, you will be presented with a list of possible drivers to install.
Select the driver(s) you wish to install. A version list will be given
for the given application. Choose the appropriate version for the
application. Once you have selected the driver, the installation
program will provide you with further instructions. For details on
installing each available driver, refer to the README.TEXT file
on the provide Utiltiy disk.
The following is a list of drivers supported by the PCA-6144V.
• AutoCAD • Autoshade
• VersaCAD • GEM Desktop
• Lotus • MS Windows
TM
• MS Word • OS/2 Presentation Manager
• Symphony • Ventura
• WordPerfect • SCO
• Quattro Pro • VESA BIOS Extension (for VESA
standard SVGA drivers)
Chapter 4 SVGA Setup 57
58 PCA-6144V User's Manual
Appendix
A
Programming the
Watchdog Timer
The PCA-6144V is equipped with a
watchdog timer that resets the CPU or
generates an interrupt if processing comes
to a standstill for whatever reason. This
feature ensures system reliability in
industrial stand-alone and unmanned
environments.
Appendix A Programming the Watchdog Timer 59
Programming the watchdog timer
If you decide to program the watchdog timer, you must write a
program which reads I/O port address 443 (hex) at regular
intervals. The first time your program reads the port, it enables the
watchdog timer. After that your program must read the port at time
intervals less than 2.0 seconds (as set in the BIOS). Otherwise, the
watchdog timer will activate and reset the CPU or generate an
interrupt on IRQ11. When you want to disable the watchdog timer,
your program should read I/O port 043 (hex).
If CPU processing comes to a standstill because of EMI or a
software bug your program's signals to I/O port address 443 to the
timer will be interrupted. The timer will then automatically reset
the CPU or invoke an IRQ, and data processing will continue
normally.
The following program shows how you might program the
watchdog timer in BASIC:
10 REM Watchdog timer example program
15 REM Watchdog timer interval set to 2 sec in BIOS
20 X=INP(&H443) REM Enable and refresh the watchdog
30 GOSUB 1000 REM Task #2, takes 2 sec to complete
40 X=INP(&H443) REM Refresh the watchdog
50 GOSUB 2000 REM Task #2, takes 2 sec to complete
60 X=INP(&H043) REM Disable the watchdog
70 END
1000 REM Subroutine #2, takes 2 seconds to complete
1070 RETURN
2000 REM Subroutine #2, takes 2 seconds to complete
2090 RETURN
.
.
.
.
.
.
60 PCA-6144V User's Manual
B
APPENDIX
Hardware Interrupt
Information
Appendix B Hardware Interrupt Information 61
Interrupt assignments
Priority Interrupt# Interrupt source
- IRQ2 Interrupt from controller 2 (cascade)
1 NMI Parity error detected
2 IRQ0 Interval timer, counter 0 output
3 IRQ1 Keyboard
4 IRQ8 Real-time clock
5 IRQ9 Reserved
6 IRQ10 Reserved
7 IRQ11 Watchdog IRQ
8 IRQ12 PS/2 mouse
9 IRQ13 INT from co-processor
10 IRQ14 IDE 0 driver
11 IRQ15 IDE 1 driver
12 IRQ3 Serial communication port 2
13 IRQ4 Serial communication port 1
14 IRQ5 Reserved
15 IRQ6 Diskette controller (FDC)
16 IRQ7 Parallel port 1 (print port)
62 PCA-6144V User's Manual
Loading...
