Advantech PCA-6007 User Manual

PCA-6007

Full-sized PCI/ISA-bus socket
478 Pentium® 4 / Celeron®D /
Celeron® processor-based
CPU card

User Manual

Copyright Notice

This document is copyrighted, 2006, by Advantech Co., Ltd. All rights
are reserved. Advantech Co., Ltd. reserves the right to make improve­ments to the products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated or transmit­ted in any form or by any means without the prior written permission of
Advantech Co., Ltd. Information provided in this manual is intended to
be accurate and reliable. However, Advantech Co., Ltd. assumes no
responsibility for its use, nor for any infringements upon the rights of
third parties which may result from its use.
Acknowledgements

•AWARD is a trademark of Phoenix Technologies Ltd.

•IBM and PC are trademarks of International Business Machines Corpo­ration.

•Intel®, Pentium®4, Celeron®D, and Celeron® are trademarks of Intel
Corporation.

•WinBond is a trademark of Winbond Corporation.
All other product names or trademarks are the properties of their respec­tive owners.

Part No. 2002600700 1st Edition

Printed in Taiwan October 2006

PCA-6007 User Manual ii

1.0.1 A Message to the Customer

Advantech customer services

Each and every Advantech product is built to the most exacting specifica­tions to ensure reliable performance in the harsh and
demanding conditions typical of industrial environments. Whether your
new Advantech equipment is destined for the laboratory or the factory
floor, you can be assured that your product will provide the reliability and
ease of operation for which the name Advantech has come to be known.
Your satisfaction is our primary concern. Here is a guide to
Advantech’s customer services. To ensure you get the full benefit of our
services, please follow the instructions below carefully.

Technical support

We want you to get the maximum performance from your products. So if
you run into technical difficulties, we are here to help. For the most fre­quently asked questions, you can easily find answers in your product doc­umentation. These answers are normally a lot more detailed than the ones
we can give over the phone.

So please consult this manual first. If you still cannot find the answer,
gather all the information or questions that apply to your problem, and
with the product close at hand, call your dealer. Our dealers are well
trained and ready to give you the support you need to get the most from
your Advantech products. In fact, most problems reported are minor and
are able to be easily solved over the phone.

In addition, free technical support is available from Advantech engineers
every business day. We are always ready to give advice on application
requirements or specific information on the installation and operation of
any of our products.

iii

Table 1.1: PCA-6007 comparison table

Model PCA-6007VE-00A1E PCA-6007LV-00A1E

VGA: Intel 865GV
integrated

USB 2.0 port Max.6; 2 ports by inter-

LAN 1: Intel 82562EZ
10/100Base-T

Yes Yes

Max.6; 2 ports by
nal USB, 4 ports by
PCA-USB4-00A1E
module.

Yes No

internal USB, 4 ports

by PCA-USB4-00A1E

module.

PCA-6007 User Manual iv

512MB DDR333 DDR N/A Samsung K4H560838C-TCB3(32×8) N/A

512MB DDR333 DDR N /A Nanya NT5DS32MBAT-6 N/A

512MB DDR400 DDR 77.10736.19G Infineon HYB25D256807BT-5(32×8) V

512MB DDR400 DDR TS64MLD64V4F3 Samsung K4H560838F-TCCC(32×8) V

256MB DDR400 DDR 77.10636.33G Infineon HYB25D256800CE-5 V

256MB DDR333 DDR 77.10628.33G Infineon HYB25D256800CE-5 N/A

512MB DDR333 DDR 77.10728.33G Inifineon HYB25D256800CE-5 V

512MB DDR333 DDR 77.10728.56G Mosel V58C2256804SAT5B V

256MB DDR400 DDR 77.10636.465 Samsung K4H560838E-TCCC V

512MB DDR400 DDR 77.10736.464 Samsung K4H560838E-TCCC V

1GB DDR400 DDR 77.11136.464 Samsung K4H510838B-TCCC V

256MB DDR400 DDR 77.10736.115 Infineon HYB25D256800BT-5 V

512MB DDR400 DDR 77.10736.114 Infineon HYB25D256800BT-5 V

512MB DDR400 DDR 77.10736.56G Mosel V58C2256804SAT5B V

1GB DDR400 DDR N/A Samsung K4H510838B-TCCC V

512MB DDR333 DDR UG764D6688KN-DH ELPIDA 0419A9K1K-6B V

1GB DDR400 DDR UG7128D6688LP-GJ SAMSUNG K4H510838B-TCCC V

512MB DDR400 DDR UG764D6688KN-GJ ELPIDA 0411A9K4D-5B V

512MB DDR400 DDR UG764D6688KP-GJ ELPIDA 0407A9K1P-5B V

1GB DDR333 DDR UG7128D6688LP-DH SAMSUNG K4H510838B-TCB3 V

1GB DDR333 DDR UG7128D6688LP-DH ELPIDA DD5108ADTA-6B (04140E12P000) "V

512MB DDR333 DDR N/A ELPIDA DD2508AMTA V

1GB DDR333 DDR N/A Samsung K4H510838B-TCB3 V

1GB DDR333 DDR N/A Samsung K4H510838B-TCB3 V

256MB DDR400 DDR N/A Samsung K4H560838E-TCCC V

256MB DDR400 DDR N/A Hynix HY5DU56822BT-D43 V

Table 1.2: PCA-6007 DDR memory compatibility table

Brand Size Speed Type Part Number Memory Full Load*

Apacer 256MB DDR266 DDR 77.10603.112 Infineon HYB25D25680BT-7(32×8) N/A

Samsung (DSL) 256MB DDR333 DDR N/A Samsung K4H560838F-TCB3(32×8) V

Kingston 512MB DDR333 DDR KVR333X64C25/512 Kingston D328DM-60(32×8) N/A

Apacer 256MB DDR400 DDR 77.10639.535 PSC A2S56D30ATP -5(32×8) V

Transcend 256MB DDR400 DDR TS32MLD64V4F3 MOSEL V58C2256804SAT5(32×8) V

Samsung (DSL) 512MB DDR400 DDR N/A SAMSUNG K4H560838F-TCCC(32×8) V

Kingston 256MB DDR400 DDR KVR400X64C3/256 Hynix HY5DU56822BT-D43(32×8) V

Apacer 512MB DDR400 DDR 77.10736.33G Infineon HYB25D256800CE-5 V

v

Transcend 1GB DDR333 DDR N/A Samsung K4H560438E-TCB3 V

UG 512MB DDR400 DDR UG764D6688KN-GJ ELPIDA 0407A9K32-5B V

DSL 512MB DDR333 DDR N/A Samsung K4H560838F-TCB3 V

Kingston 256MB DDR400 DDR N/A Hynix HY5DU56822CT-D43 V

Full Load* : Supports 4 modules inserted in four slots as two pairs of Dual-channel memory configuration

1.0.2 Product warranty

Advantech warrants to you, the original purchaser, that each of its prod­ucts will be free from defects in materials and workmanship for two years
from the date of purchase.

This warranty does not apply to any products which have been repaired or
altered by persons other than repair personnel authorized by Advantech,
or which have been subject to misuse, abuse, accident or improper instal­lation. Advantech assumes no liability under the terms of this warranty as
a consequence of such events.

If an Advantech product is defective, it will be repaired or replaced at no
charge during the warranty period. For out-of-warranty repairs, you will
be billed according to the cost of replacement materials, service time and
freight. Please consult your dealer for more details.

If you think you have a defective product, follow these steps:

Step 1. Collect all the information about the problem encountered. (For

example, type of PC, CPU speed, Advantech products used,
other hardware and software used, etc.) Note anything abnormal
and list any on-screen messages you get when the problem
occurs.

Step 2. Call your dealer and describe the problem. Please have your man-

ual, product, and any helpful information readily available.

Step 3. If your product is diagnosed as defective, obtain an RMA (return

material authorization) number from your dealer. This allows us
to process your return more quickly.

Step 4. Carefully pack the defective product, a fully-completed Repair

and Replacement Order Card and a photocopy proof of purchase
date (such as your sales receipt) in a shippable container. A prod­uct returned without proof of the purchase date is not eligible for
warranty service.

Step 5. Write the RMA number visibly on the outside of the package and

ship it prepaid to your dealer.

PCA-6007 User Manual vi

1.0.3 Initial Inspection

Before you begin installing your single board computer, please make sure
that the following materials have been shipped:

1 PCA-6007 Pentium®4/Celeron®D/Celeron® processor-based single
board computer

1 PCA-6007 Startup Manual

1 CD with driver utility and manual (in PDF format)

1 FDD cable P/N: 1700340640

2 Ultra ATA 100 HDD cables P/N: 1701400452

2 Serial ATA HDD data cable P/N: 1700071000

2 Serial ATA HDD power cable P/N: 1703150102

1 ATX 12V power converter cable P/N: 170304015K

1 Printer (parallel) port & COM port cable kit P/N: 1700060305

1 Y cable for PS/2 keyboard and PS/2 mouse P/N: 1700060202

1 Two USB ports cable (optional) P/N 1700100170

If any of these items are missing or damaged, contact your distributor or
sales representative immediately.

We have carefully inspected the PCA-6007 mechanically and

electrically before shipment. It should be free of marks and scratches and
in perfect working order upon receipt.

As you unpack the PCA-6007, check it for signs of shipping damage.
(For example, damaged box, scratches, dents, etc.) If it is damaged or it
fails to meet the specifications, notify our service department or your
local sales representative immediately. Also notify the carrier. Retain the
shipping carton and packing material for inspection by the carrier. After
inspection, we will make arrangements to repair or replace the unit.

1.0.4 Release Note

Date Revision Description

October 2006 1st Edition Initial Release

vii

Important Safety Information

SAFETY INSTRUCTIONS

This device complies with the requirements in part 15 of the FCC rules: Operation is sub­ject to the following two conditions:

1. This device may not cause harmful interference, and

2. This device must accept any interference received, including interference
that may cause undesired operation

This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide rea­sonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio fre­quency energy and, if not installed and used in accordance with the instruction manual,
may cause harmful interference to radio communications. Operation of this device in a
residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his/her own expense. The user is advised that any
equipment changes or modifications not expressly approved by the party responsible for
compliance would void the compliance to FCC regulations and therefore, the user's
authority to operate the equipment.

CAUTION!!

There is a danger of a new battery exploding if it is incorrectly installed. Do not
attempt to recharge, force open, or heat the battery. Replace the battery only with
the same or equivalent type recommended by the manufacturer. Discard used bat­teries according to the manufacturer’s instructions.

PCA-6007 User Manual viii

Contents

Chapter 1 Hardware Configuration .................................2

1.1 Introduction ....................................................................... 2

1.2 Features ............................................................................. 3

1.3 Specifications .................................................................... 3

1.3.1 System............................................................................. 3

1.3.2 Memory........................................................................... 4

1.3.3 Input/Output .................................................................... 4

1.3.4 VGA interface ................................................................. 4

1.3.5 Ethernet LAN.................................................................. 4

1.3.6 Industrial features ........................................................... 4

1.3.7 Mechanical and environmental specifications................ 5

1.4 Jumpers and Connectors.................................................... 6

Table 1.1:Jumpers ........................................................... 6

Table 1.2:Connectors...................................................... 6

1.5 Board Layout: Jumper and Connector Locations.............. 8

Figure 1.1:Jumper and Connector locations ................... 8

1.6 PCA-6007 Block Diagram ............................................... 9

Figure 1.2:PCA-6007 Block Diagram ............................ 9

1.7 Safety Precautions .......................................................... 10

1.8 Jumper Settings ............................................................... 11

1.8.1 How to set jumpers ....................................................... 11

1.8.2 CMOS clear (J1) ........................................................... 11

Table 1.3:CMOS (J1).................................................... 11

1.8.3 Watchdog timer output (J2) .......................................... 11

Table 1.4:Watchdog timer output (J2).......................... 12

1.9 System Memory .............................................................. 12

1.9.1 CPU FSB and memory speed ....................................... 13

Table 1.5:CPU FSB and memory speed ....................... 13

1.9.2 Dual channel configuration........................................... 13

1.10 Memory Installation Procedures ..................................... 14

1.11 Processor Installation ...................................................... 14

Chapter 2 Connecting Peripherals .................................16

2.1 Introduction ..................................................................... 16

2.2 1st & 2nd (CN1, CN2) IDE Connectors ......................... 16

2.3 Floppy Drive Connector (CN3)....................................... 17

2.4 Parallel Port (CN4).......................................................... 17

2.5 USB Ports (CN6)............................................................. 18

2.6 VGA Connector CN7 ...................................................... 18

ix

2.7 Ethernet Connector (CN8) .............................................. 19

2.8 Serial Ports (COM1 : CN9; COM2 : CN10 ) .................. 19

2.9 PS/2 Keyboard/Mouse Connector (CN11/CN33) ........... 20

2.10 External Keyboard Connector (CN12)............................ 20

2.11 CPU Fan Connector (CN14) ........................................... 21

2.12 Front Panel Connectors (CN16, 17, 18, 19, 21) .............. 21

2.12.1 Power LED (CN16) ...................................................... 21

2.12.2 External speaker (CN17) .............................................. 22

2.12.3 Reset (CN18) ................................................................ 22

2.12.4 HDD LED (CN19)........................................................ 22

2.12.5 ATX soft power switch (CN21).................................... 22

2.13 ATX feature connector (CN20)....................................... 23

2.14 AC-97 Audio interface (CN43)....................................... 23

2.15 Serial ATA interface (SA0 and SA1).............................. 24

2.16 Auxiliary 4-pin power connector (ATX1) ...................... 24

Chapter 3 Award BIOS Setup.........................................26

3.1 Introduction ..................................................................... 26

3.1.1 CMOS RAM Auto-backup and Restore ....................... 26

3.2 Entering Setup ................................................................. 27

Figure 3.1:Award BIOS Setup initial screen ................ 27

3.3 Standard CMOS Setup .................................................... 27

Figure 3.2:Standard CMOS features screen ................. 27

3.4 Advanced BIOS Features ................................................ 28

Figure 3.3:Advanced BIOS features screen.................. 28

3.4.1 CPU Features ................................................................ 28

3.4.2 Hard Disk Boot Priority................................................ 28

3.4.3 Virus Warning............................................................... 28

3.4.4 CPU L1 & L2 Cache..................................................... 28

3.4.5 Hyper-Threading Technology....................................... 29

3.4.6 Quick Power On Self Test ............................................ 29

3.4.7 First/Second/Third Boot Device ................................... 29

3.4.8 Boot Other Device ........................................................ 29

3.4.9 Swap Floppy Drive ....................................................... 29

3.4.10 Boot UP Floppy Seek ................................................... 29

3.4.11 Boot Up NumLock Status............................................. 29

3.4.12 Gate A20 Option........................................................... 29

3.4.13 Typematic Rate Setting................................................. 29

3.4.14 Typematic Rate (Chars/Sec) ......................................... 29

3.4.15 Typematic Delay (msec) ............................................... 30

3.4.16 Security Option ............................................................. 30

3.4.17 APIC Mode................................................................... 30

3.4.18 MPS Version Control For OS ....................................... 30

PCA-6007 User Manual x

3.4.19 OS Select For DRAM > 64MB .................................... 30

3.5 Advanced Chipset Features ............................................. 31

Figure 3.4:Advanced chipset features screen ............... 31

3.5.1 DRAM Timing Selectable ............................................ 31

3.5.2 CAS Latency Time ....................................................... 31

3.5.3 Active to Precharge Delay ............................................ 32

3.5.4 DRAM RAS# to CAS# Delay ..................................... 32

3.5.5 DRAM RAS# Precharge............................................... 32

3.5.6 Memory Frequency ....................................................... 32

3.5.7 System BIOS Cacheable............................................... 32

3.5.8 Video Bios Cacheable................................................... 32

3.5.9 Memory Hole At 15M-16M ......................................... 32

3.5.10 AGP Aperture Size (MB) ............................................. 32

3.5.11 Init Display First ........................................................... 32

3.5.12 On-Chip VGA............................................................... 33

3.5.13 On-Chip Frame Buffer Size.......................................... 33

3.6 Integrated Peripherals...................................................... 34

Figure 3.5:Integrated peripherals .................................. 34

Figure 3.6:On-Chip IDE Device ................................... 34

3.6.1 IDE HDD Block Mode ................................................. 35

3.6.2 On-Chip IDE Device .................................................... 35

3.6.3 On-Chip Serial ATA ..................................................... 35

3.6.4 Serial ATA Port0/Port1 Mode ...................................... 35

Figure 3.7:Onboard Device........................................... 35

3.6.5 USB Controller ............................................................. 36

3.6.6 USB 2.0 Controller ....................................................... 36

3.6.7 USB Keyboard/Mouse Support .................................... 36

3.6.8 AC97 Audio .................................................................. 36

3.6.9 Onboard LAN1 Control ................................................ 36

3.6.10 Onboard LAN1 Boot ROM .......................................... 36

3.7 SuperIO Device ............................................................... 37

Figure 3.8:SuperIO Device ........................................... 37

3.7.1 Onboard FDC Controller .............................................. 37

3.7.2 Onboard Serial Port 1 ................................................... 37

3.7.3 Onboard Serial Port 2 ................................................... 37

3.7.4 UART Mode Select ...................................................... 37

3.7.5 RxD, TxD Active .......................................................... 37

3.7.6 IR Transmission Delay ................................................. 37

3.7.7 UR2 Duplex Mode ........................................................ 38

3.7.8 Use IR Pins ................................................................... 38

3.7.9 Onboard Parallel Port.................................................... 38

3.7.10 Parallel Port Mode ........................................................ 38

3.7.11 EPP Mode Select .......................................................... 38

3.7.12 ECP Mode Use DMA ................................................... 38

3.7.13 PWRON After PWR-Fail ............................................. 38

xi

3.8 Power Management Setup............................................... 39

Figure 3.9:Power management setup screen (1)........... 39

3.8.1 Power-Supply Type ...................................................... 39

3.8.2 ACPI function ............................................................... 39

3.8.3 Video Off Method......................................................... 39

3.8.4 Video Off In Suspend .................................................. 39

3.8.5 Suspend Type................................................................ 39

3.8.6 Modem Use IRQ ........................................................... 39

3.8.7 Soft-Off by PWR-BTTN .............................................. 40

3.8.8 CPU THRM-Throttling................................................. 40

3.8.9 Resume on LAN/PCI PME#......................................... 40

3.8.10 Resume on Ring............................................................ 40

3.8.11 Resume on Alarm ......................................................... 40

3.8.12 Primary IDE 0 (1) and Secondary IDE 0 (1) ................ 40

3.8.13 FDD, COM, LPT PORT ............................................... 40

3.8.14 PCI PIRQ [A-D]# ........................................................ 40

3.9 PnP/PCI Configurations .................................................. 41

Figure 3.10:PnP/PCI configurations screen.................. 41

3.9.1 Reset Configuration Data.............................................. 41

3.9.2 Resources Controlled By .............................................. 41

3.9.3 PCI/VGA Palette Snoop ............................................... 41

3.10 PC Health Status.............................................................. 42

3.10.1 CPU Warning Temperature .......................................... 42

Figure 3.11:PC health status screen .............................. 42

3.10.2 Current System Temp ................................................... 42

3.10.3 Current CPU Temperature ............................................ 42

3.10.4 Current CPUFAN Speed............................................... 42

3.10.5 VCORE, +1.5V, VCC3, +5V, +12V, -12V, -5V,

VBAT(V), 5VSB(V)..................................................... 42

3.11 Spread Spectrum Control ................................................ 43

Figure 3.12:Spread Spectrum Control screen ............... 43

3.11.1 CPU Clock Ratio .......................................................... 43

3.11.2 Spread Spectrum ........................................................... 43

3.12 Password Setting ............................................................. 43

3.13 Save & Exit Setup ........................................................... 44

3.14 Exit Without Saving ........................................................ 44

Chapter 4 Chipset Software Install Utility.....................46

4.1 Before you begin ............................................................. 46

4.2 Introduction ..................................................................... 46

4.3 Windows XP Driver Setup .............................................. 47

PCA-6007 User Manual xii

Chapter 5 VGA Setup ......................................................52

5.1 Introduction ..................................................................... 52

5.2 Dynamic Video Memory Technology............................. 52

5.3 Windows XP Driver Setup .............................................. 53

Chapter 6 LAN Configuration ........................................58

6.1 Introduction ..................................................................... 58

6.2 Features ........................................................................... 58

6.3 Installation....................................................................... 59

6.4 Win XP Driver Setup (Intel 82562) ................................ 59

Chapter 7 USB 2.0 Configuration...................................64

7.1 Introduction ..................................................................... 64

7.2 Features ........................................................................... 64

7.3 Installation....................................................................... 64

Chapter 8 Onboard Security Setup ................................66

8.1 Introduction ..................................................................... 66

8.2 Windows XP Driver Setup .............................................. 67

8.3 Using the OBS Hardware Doctor Utility ........................ 70

Appendix A Programming the watchdog .........................74

A.1 Programming the Watchdog Timer ................................. 74

A.1.1 Watchdog timer overview............................................. 74

A.1.2 Reset/ Interrupt selection .............................................. 74

A.1.3 Programming the Watchdog Timer .............................. 74

A.1.4 Example Program ......................................................... 77

Appendix B Pin Assignments ............................................84

B.1 IDE Hard Drive Connector (CN1, CN2)......................... 84

B.2 Floppy Drive Connector (CN3)....................................... 85

B.3 Parallel Port Connector (CN4) ........................................ 86

B.4 USB Connector (CN6) .................................................... 87

B.5 VGA Connector (CN7) ................................................... 87

B.6 COM1/COM2 RS-232 Serial Port (CN9, CN10)............ 88

B.7 Keyboard and Mouse Connnector (CN11)...................... 89

B.8 External Keyboard Connector (CN12)............................ 89

B.9 CPU Fan Power Connector (CN14) ................................ 90

B.10 Power LED (CN16)......................................................... 90

xiii

B.11 External Speaker Connector (CN17)............................... 91

B.12 Reset Connector (CN18) ................................................. 91

B.13 HDD LED Connector (CN19)......................................... 92

B.14 ATX Feature Connector (CN20)..................................... 92

B.15 ATX Soft Power Switch (CN21)) ................................... 93

B.16 H/W Monitor Alarm (CN22)........................................... 93

B.17 AC-97 Audio Interface (CN43)....................................... 94

B.18 System I/O Ports.............................................................. 95

B.19 DMA Channel Assignments............................................ 96

B.20 Interrupt Assignments ..................................................... 96

B.21 1st MB Memory Map...................................................... 97

B.22 PCI Bus Map ................................................................... 97

PCA-6007 User Manual xiv

CHAPTER

General Information

1

1

Chapter 1 Hardware Configuration

1.1 Introduction

The PCA-6007 Series all-in-one industrial grade single board computer is
a high performance and full-featured computing engine. It follows the
PICMG 1.0 specification and meets most requirements for industrial
applications.

The PCA-6007 uses Intel's 865GV chipset to support Intel's Socket 478
Pentium®4, Celeron®D, and Celeron® processors with 800/533/400
MHz front side bus. The dual channel DDR 400 SDRAM interface pro­vides bottle neck free memory bandwidth up to 6.4GB/s. In addition to
the two EIDE interfaces (up to four devices), it features a high perfor­mance serial ATA interface (up to 150MB/s) which eases cabling to hard
drives in industrial chassis with thin and long cables. Other features
include chipset built-in high performance VGA interface, six USB 2.0
ports (up to 480 Mbps), and other standard PC functions like two RS-232
serial ports, one enhanced parallel port and floppy disk interface.

The PCA-6007 Series offers several impressive industrial features such
as: CMOS data backup, which is stored in the Flash memory, which pro­tects data even after battery failure. Also included is a 256-level watch­dog timer, which resets the CPU if a program cannot be executed
normally.

Note: Some of the features mentioned above are not

available with all models. For more information
about the specifications of a particular model,
see Table 1.1 : Comparison table and Section

1.3: Specifications.

PCA-6187 User’s Manual 2

1.2 Features

1. High performance: The PCA-6007 uses Intel 865GV chipset
which offers high-bandwidth interfaces such as dual-channel
DDR400 main memory, 800 MHz system bus, integrated graphics
controller with Intel® Extreme Graphics 2 Technology, Hi-Speed
USB 2.0 connectivity to ensure the flexibility and performance you
expect.

2. BIOS CMOS backup and restore: When BIOS CMOS setup has
been completed, data in the CMOS RAM is automatically backed
up to the Flash ROM. This is particularly useful in harsh environ­ments which may cause setup data loss such as battery failure.
Upon such an error occurring, BIOS will check the data, and auto­matically restore the original data for booting.

3. Supports Hyper-Threading : This allows a single HT-enabled
Pentium 4 processor to process two threads simultaneously. By
building two logical processors into a single physical processor, the
performance and utilization of the processor resource will both
increase. Users can obtain a higher CPU performance while Hyper­Threading is enabled.

1.3 Specifications

1.3.1 System

• CPU: CPU: Intel® socket 478 Pentium® 4 up to 3.4GHz FSB 533/

800MHz, Celeron®D up to 3.06GHz FSB 533MHz, Celeron® up to

2.8GHz FSB 400MHz; supports Intel Hyper Threading technology.
CPUs with 1.75V core voltage (Willamete) are not supported.

• L2 Cache: CPU built-in 128/256/512/1024 KB full-speed L2 cache

• BIOS: Award Flash BIOS (4Mb Flash Memory)

• System Chipset: Intel 865GV with ICH5

• SATA/EIDE hard disk drive interface: Supports up to two indepen-

dent Serial ATA hard drives (up to 150MB/s) and two IDE hard disk
drives or four enhanced IDE devices. Supports PIO mode 4 (16.67
MB/s data transfer rate) and ATA 33/66/100 (33/66/100MB/s data
transfer rate.) BIOS enabled/disabled.

• Floppy disk drive interface: Supports up to two floppy disk drives,

5¼" (360 KB and 1.2 MB) and/or 3½" (720 KB, 1.44 MB). BIOS
enabled/disabled

3

1.3.2 Memory

• RAM: Up to 4GB in four 184-pin DIMM sockets. Supports dual

channel DDR266/333/400 SDRAM

1.3.3 Input/Output

• Bus interface: PICMG 1.0 compliant PCI/ISA bus interface

• Enhanced parallel port: Configurable to LPT1, LPT2, LPT3, or dis-

abled. Standard DB-25 female connector provided. Supports EPP/SPP/
ECP

• Serial ports: Two RS-232 ports with 16C550 UARTs (or compatible)

with 16-byte FIFO buffer. Supports speeds up to 115.2 Kbps. Ports can
be individually configured to COM1, COM2 or disabled

• Keyboard and PS/2 mouse connector: One 6-pin mini-DIN connector

is located on the mounting bracket for easy connection to a keyboard or
PS/2 mouse. An on board keyboard pin header connector is also avail­able

• ISA bus: Support ISA high drive. PCI-to-ISA bridge: ITE 8888

• AC-97 Audio: PCA-6007 can provide audio function with the optional

audio extension module PCA-AUDIO-00A1E

• USB port: Supports up to six USB 2.0 and transmission rate up to

480Mbps; available on PCA-USB4 or through an optional two-USB­port cable kit, P/N : 1700100170

1.3.4 VGA interface

• Controller: Intel 865GV chipset integrated

• Display memory: Share system memory up to 64 MB, BIOS selectable

• Resolution: up to 2048 ×1536 @ 85Hz

1.3.5 Ethernet LAN

• Supports single/dual 10/100Base-T networking or single/dual10/100/

1000Base-T Ethernet networking

• Controller:

• Single 10/100Base-T: Intel 82562EZ

1.3.6 Industrial features

• Watchdog timer: Can generate a system reset or IRQ11. The watch-

dog timer is programmable, with each unit equal to one second or one
minute (255 levels). You can find programming detail in Appendix A

PCA-6187 User’s Manual 4

1.3.7 Mechanical and environmental specifications

• Operating temperature: 0°~60° C (32° ~ 140° F, Depending on CPU)

• Storage temperature: -20°~ 70° C (-4° ~ 158° F)

• Humidity: 20 ~ 95% non-condensing

• Power supply voltage: +5 V, ±12 V

• Power consumption: Typical : +5V:6.53A, +12V:4.57A (Intel Pen-

tium 4 3.0GHz with 800MHz FSB, 512MB DDR 400 SDRAM)

• Board size: 338 x 122 mm (13.3" x 4.8")

• Board weight: 0.5 kg (1.2 lb)

5

1.4 Jumpers and Connectors

Connectors on the PCA-6007 single board computer link it to external
devices such as hard disk drives and a keyboard. In addition, the board
has a number of jumpers used to configure your system for your applica­tion.

The tables below list the function of each of the board jumpers and con­nectors. Later sections in this chapter give instructions on setting jump­ers. Chapter 2 gives instructions for connecting external devices to your

single board computer.

Table 1.1: Jumpers

Label

J1 CMOS Clear

J2 Watchdog timer output selection

Table 1.2: Connectors

Label

CN1 Primary IDE connector

CN2 Secondary IDE connector

CN3 Floppy drive connector

CN4 Parallel port

CN6 USB port 4, 5

CN7 VGA connector

CN8 Ethernet connector 1

CN9 Serial port: COM1

CN10 Serial port: COM2

CN11 PS/2 keyboard and mouse connector

CN12 External keyboard connector

CN13 Reserved

CN14 CPU FAN connector

CN16 Power LED

CN17 External speaker

Function

Function

PCA-6187 User’s Manual 6

Table 1.2: Connectors

CN18 Reset connector

CN19 HDD LED connector

CN20 ATX feature connector

CN21 ATX soft power switch (PS_ON)

CN22 HW Monitor Alarm

Close: Enable OBS Alarm
Open: Disable OBS Alarm

CN43 AC97 Link connector

SA0 Serial ATA0

SA1 Serial ATA1

ATX1 ATX 12v Auxillary power connector

Notice: The 4-pin ATX 12V power connector "ATX1" must be connected to the
power supply to provide adequate power to the CPU card. Otherwise system might
be unstable.

7

1.5 Board Layout: Jumper and Connector Locations

CN19

CN16

CN21

CN17

CN13

J2

CN14

CN43

CN30

CN20

SA0

DIMM1

SA1

CN4

ATX 1

DIMM3

CN2

CN18

CN22

CN12

CN11

CN7

J1

CN8

Figure 1.1: Jumper and Connector locations

PCA-6187 User’s Manual 8

CN9

CN10

CN6

1.6 PCA-6007 Block Diagram

Process or

B
S
F
z
H
M
0
0
8

/
3
3
5

/
0
0
4

VGA port

Intel 82865G

LAN1 Intel

82562

2 ATA 100

ports

2 SATA ports

6 USB Ports

Audio Codec

CSA

266MB/s

LCI Bus

ATA 33/66/100

150MB/s

U

S

B

2

0

.

AC-97

1

1

.

/

266MB/s

Hub Link 1.5

Intel 82801EB

ICH5

Channel A

Channel B

32bit/ 33MHz PC I B us

DDR 266/333/400

DDR 266/333/400

PCI to ISA

Bridge

ITE8888

Backplane

LPC Bus

Super IO

BIOS

Winbond

W83627HG

Figure 1.2: PCA-6007 Block Diagram

9

1.7 Safety Precautions

Warning! Always completely disconnect the power cord

from your chassis whenever you work with the
hardware. Do not make connections while the
power is on. Sensitive electronic components
can be damaged by sudden power surges. Only
experienced electronics personnel should open
the PC chassis.

Caution! Always ground yourself to remove any static

charge before touching the single board com­puter. Modern electronic devices are very sen­sitive to static electric charges. As a safety
precaution, use a grounding wrist strap at all
times. Place all electronic components on a
static-dissipative surface or in a static-shielded
bag when they are not in the chassis.

Caution! The computer is provided with a battery-pow-

ered Real-time Clock circuit. There is a danger
of explosion if battery is incorrectly replaced.
Replace only with same or equivalent type rec­ommended by the manufacturer. Discard used
batteries according to manufacturer's instruc­tions.

Notice: Before install your PCA-6007 into a chassis, make sure that all components
on both sides of the CPU card do not touch any metal parts, especially the chassis
wall and add-on card at the adjacent slot.

PCA-6187 User’s Manual 10

1.8 Jumper Settings

This section provides instructions on how to configure your single board
computer by setting the jumpers. It also includes the single board com­puter's default settings and your options for each jumper.

1.8.1 How to set jumpers

You can configure your single board computer to match the needs of your
application by setting the jumpers. A jumper is a metal bridge that closes
an electrical circuit. It consists of two metal pins and a small metal clip
(often protected by a plastic cover) that slides over the pins to connect
them. To “close” (or turn ON) a jumper, you connect the pins with the
clip. To “open” (or turn OFF) a jumper, you remove the clip. Sometimes
a jumper consists of a set of three pins, labeled 1, 2, and 3. In this case
you connect either pins 1 and 2, or 2 and 3. A pair of needle-nose pliers
may be useful when setting jumpers.

1.8.2 CMOS clear (J1)

The PCA-6007 single board computer contains a jumper that can erase
CMOS data and reset the system BIOS information. Normally this
jumper should be set with pins 1-2 closed. If you want to reset the CMOS
data, set J1 to 2-3 closed for just a few seconds, and then move the jumper
back to 1-2 closed. This procedure will reset the CMOS to its default set-

ting.

Table 1.3: CMOS (J1)

Function Jumper Setting

* Keep CMOS data

1 -2 closed

Clear CMOS data

2 3 closed

* default setting

1.8.3 Watchdog timer output (J2)

The PCA-6007 contains a watchdog timer that will reset the CPU or send
a signal to IRQ11 in the event the CPU stops processing. This feature
means the PCA-6007 will recover from a software failure or an EMI
problem. The J2 jumper settings control the outcome of what the com­puter will do in the event the watchdog timer is tripped.

11

Table 1.4: Watchdog timer output (J2)

Function

IRQ11

Jumper Setting

1

1-2 closed

* Reset

* default setting

1

2-3 closed

Note: The interrupt output of the watchdog timer is a

low level signal. It will be held low until the
watchdog timer is reset.

1.9 System Memory

The PCA-6007 has two sockets for 184-pin dual inline memory modules
(DIMMs) in two separated memory channels. It can operate with single
channel or dual channel modules. We recommend to use dual channel
mode to provide optimized performance.

All these sockets use 2.5 V unbuffered double data rate synchronous
DRAMs (DDR SDRAM). They are available in capacities of 128, 256,
512 and 1024 MB. The sockets can be filled in any combination with
DIMMs of any size, giving a total memory size between 128 MB and 4
GB.

PCA-6187 User’s Manual 12

1.9.1 CPU FSB and memory speed

The PCA-6007 can accept DDR SDRAM memory chips without parity.
Also note: The PCA-6007 accepts PC2100 (DDR266), PC2700 (DDR

333) and PC3200 (DDR 400) DDR SDRAM, depending on the CPU

front side bus frequency (FSB). Please refer below table for the relation­ship between the CPU FSB and memory speed.

Table 1.5: CPU FSB and memory speed

Memory
Speed

DDR400 Pentium 4 800 MHz 400 MHz

DDR333 Pentium 4 800 MHz 320 MHz

DDR266 Pentium 4 533 or 400 MHz 266 MHz

Processor FSB frequency Memory speed Outcome

Pentium 4 533MHz 333 MHz

Pentium 4
or Celeron

Celeron 400 MHz 266 MHz

400 MHz 266 MHz

The PCA-6007 does not support ECC (error checking and correction).
Memory modules with 9 SDRAM chips/side support ECC; modules with
8 chips/side do not support ECC.

1.9.2 Dual channel configuration

The two DIMM sockets are arranged in two channels: DIMM1 in channel
A; DIMM3 in channel B. To enable dual channel operation, please install
a matched pair of DIMMs in DIMM1 & DIMM3.

"Matched pair of DIMMs" means: same in speed (DDR266, DDR333,
DDR400), same in size (128MB, 256MB, 512MB or 1GB), same in chip
density (128 Mb, 256Mb or 512Mb and same in CSA latency). Any other
memory configuration will result in single channel memory operation.

13

1.10 Memory Installation Procedures

To install DIMMs, first make sure the two handles of the DIMM socket
are in the "open" position. i.e. The handles lean outward. Slowly slide the
DIMM module along the plastic guides on both ends of the socket. Then
press the DIMM module right down into the socket, until you hear a
click. This is when the two handles have automatically locked the mem­ory module into the correct position of the DIMM socket. To remove the
memory module, just push both handles outward, and the memory mod­ule will be ejected by the mechanism in the socket.

1.11 Processor Installation

The CPU on the board must have a fan or heat sink attached, to prevent
overheating.

Warning: Without a fan or heat sink, the CPU will over-heat and cause
damage to both the CPU and the single board computer. To install a CPU,
first turn off your system and remove its cover. Locate the processor
socket 478.

1. Make sure the socket 478 lever is in the upright position. To raise the

lever, pull it out to the side a little and raise it as far as it will go.

2. Place the CPU in the empty socket. Follow the instructions that came

with the CPU. If you have no instructions, complete the following proce­dure. Carefully align the CPU so it is parallel to the socket and the
notches on the corners of the CPU correspond with the notches on the
inside of the socket. Gently slide the CPU in. It should insert easily. If it
does not insert easily, pull the lever up a little bit more.

3. Press the lever down. The plate will slide forward. You will feel some

resistance as the pressure starts to secure the CPU in the socket. This is
normal and will not damage the CPU. When the CPU is installed, the
lever should snap into place at the side of the socket.

Note : The CPUs made with 0.18 micro-meter process technology
("Willamette") cannot be supported by PCA-6007.

PCA-6187 User’s Manual 14

2

CHAPTER

Connecting Peripherals

15 Chapter 2

Chapter 2 Connecting Peripherals

2.1 Introduction

You can access most of the connectors from the top of the board while it
is installed in the chassis. If you have a number of cards installed or have
a packed chassis, you may need to partially remove the card to make all
the connections.

2.2 1st & 2nd (CN1, CN2) IDE Connectors

CN1

CN2

You can attach up to four IDE (Integrated Drive Electronics) drives to the
PCA-6007’s built-in controller. The primary (CN1) and secondary (CN2)
connectors can each accommodate two drives.

Wire number 1 on the cable is red or blue and the other wires are gray.
Connect one end to connector CN1 or CN2 on the single board computer.
Make sure that the red/blue wire corresponds to pin 1 on the connector (in
the upper right hand corner). See Chapter 1 for help finding the connec­tor.

Unlike floppy drives, IDE hard drives can connect in either position on
the cable. If you install two drives to a single connector, you will need to
set one as the master and the other as the slave. You do this by setting the
jumpers on the drives. If you use just one drive per connector, you should
set each drive as the master. See the documentation that came with your
drive for more information.

Connect the first hard drive to the other end of the cable. Wire 1 on the
cable should also connect to pin 1 on the hard drive connector, which is
labeled on the drive circuit board. Check the documentation that came
with the drive for more information.

Connect the second hard drive to the remaining connector (CN2 or CN1),
in the same way as described above.

PCA-6007 User Manual 16

2.3 Floppy Drive Connector (CN3)

CN3

You can attach up to two floppy disk drives to the PCA-6007's on board
controller. You can use 3.5" (720 KB, 1.44 MB) drives.

The single board computer comes with a 34-pin daisy-chain drive con­nector cable. On one end of the cable is a 34-pin flat-cable connector. On
the other end are two sets of 34-pin flat-cable connector (usually used for

3.5" drives). The set on the end (after the twist in the cable) connects to

the A: floppy drive. The set in the middle connects to the B: floppy drive.

2.4 Parallel Port (CN4)

CN4

The parallel port is normally used to connect the single board computer to a
printer. The PCA-6007 includes an onboard parallel port, accessed through a 26­pin flat-cable connector, CN4. The card comes with an adapter cable which lets
you use a traditional DB-25 connector. The cable has a 26-pin connector on one
end and a DB-25 connector on the other, mounted on a retaining bracket. The
bracket installs at the end of an empty slot in your chassis, giving you access to
the connector.

The parallel port is designated as LPT1, and can be disabled or changed to LPT2
or LPT3 in the system BIOS setup.

17 Chapter 2

To install the bracket, find an empty slot in your chassis. Unscrew the plate that
covers the end of the slot. Screw in the bracket in place of the plate. Next, attach
the flat-cable connector to CN4 on the CPU card. Wire 1 of the cable is red or
blue, and the other wires are gray. Make sure that wire 1 corresponds to pin 1 of
CN4. Pin 1 is on the upper right side of CN4.

2.5 USB Ports (CN6)

The PCA-6007 provides up to six ports of USB (Universal Serial Bus)
interface, which gives complete Plug & Play and hot swapping for up to
127 external devices.The USB interface complies with USB Specification
Rev. 2.0 support transmission rate up to 480 Mbps and is fuse-protected.
The USB interface can be disabled in the system BIOS setup.

CN6

2.6 VGA Connector CN7

CN7

The PCA-6007 includes a VGA interface that can drive conventional
CRT displays. CN7 is a standard 15-pin D-SUB connector commonly
used for VGA. Pin assignments for CRT connector CN7 are detailed in
Appendix B.

PCA-6007 User Manual 18

2.7 Ethernet Connector (CN8)

The PCA-6007 is equipped with single high-performance 32-bit PCI-bus
Ethernet interface, which is fully compliant with IEEE 802.3/u 10/
100Mbps CSMA/CD and IEEE 802.3ab 1000Base-T standards. It is sup­ported by all major network operating systems and is 100% Novell NE­2000 compatible. An onboard RJ-45 jack provides convenient 10/
100Base-T operation.

2.8 Serial Ports (COM1 : CN9; COM2 : CN10 )

The PCA-6007 offers two serial ports, CN9 as COM1 and CN10 as
COM2. These ports can connect to serial devices, such as a mouse or a
printer, or to a communications network.

The IRQ and address ranges for both ports are fixed. However, if you
want to disable the port or change these parameters later, you can do this
in the system BIOS setup.

Different devices implement the RS-232 standard in different ways. If
you are having problems with a serial device, be sure to check the pin
assignments for the connector.

19 Chapter 2

2.9 PS/2 Keyboard/Mouse Connector (CN11/CN33)

CN11

Two 6-pin mini-DIN connectors (CN11 and CN33) on the card mounting
bracket provide connection to a PS/2 keyboard and a PS/2 mouse, respec­tively. CN11 can also be connected to an adapter cable (P/N:
1700060202, available from Advantech) for connecting to both a PS/2
keyboard and a PS/2 mouse.

2.10 External Keyboard Connector (CN12)

CN12

In addition to the PS/2 mouse/keyboard connector on the PCA-6007's
rear plate, there is also an extra onboard external keyboard connector.
This gives system integrators greater flexibility in designing their sys­tems.

PCA-6007 User Manual 20

2.11 CPU Fan Connector (CN14)

CN14

If fan is used, this connector supports cooling fans of 500mA (6W) or
less.

2.12 Front Panel Connectors (CN16, 17, 18, 19, 21)

There are several external switches to monitor and control the PCA-6007

CN21

CN18
CN19
CN17
CN16

2.12.1 Power LED (CN16)

CN16 is a 5-pin connector for the power on LED. Refer to Appendix B
for detailed information on the pin assignments. If a PS/2 or ATX power
supply is used, the system's power LED status will be as indicated below:

Table 2.1: PS/2 or ATX power supply LED status

Power mode LED (PS/2 power) LED (ATX power)
System On On On
System Suspend Fast flashes Fast flashes
System Off Off Slow flashes

21 Chapter 2

2.12.2 External speaker (CN17)

CN17 is a 4-pin connector for an external speaker. If there is no external
speaker, the PCA-6007 provides an onboard buzzer as an alternative. To
enable the buzzer, set pins 3-4 as closed

2.12.3 Reset (CN18)

Many computer cases offer the convenience of a reset button. Connect the
wire from the reset button

1

2.12.4 HDD LED (CN19)

You can connect an LED to connector CN19 to indicate when the HDD is
active.

1

2.12.5 ATX soft power switch (CN21)

If your computer case is equipped with an ATX power supply, you should
connect the power on/off button on your computer case to CN21. This
connection enables you to turn your computer on and off.

PCA-6007 User Manual 22

2.13 ATX feature connector (CN20)

CN20

Connect to the CN1 on the Advantech backplane to enable the ATX func­tion, 5V stand-by.

2.14 AC-97 Audio interface (CN43)

CN43

The PCA-6007 provides AC-97 audio through PCA-AUDIO-00A1
module from Advantech.

23 Chapter 2

2.15 Serial ATA interface (SA0 and SA1)

SA0 & SA1

In addition to the two EIDE interfaces (up to four devices), the PCA-6007
features high performance serial ATA interface (up to 150MB/s) which
eases cabling to hard drives with thin and long cables.

2.16 Auxiliary 4-pin power connector (ATX1)

To ensure the sufficiency of power supply for Pentium® 4 single board
computer, one auxiliary 4 pin power connector is available on PCA-6007.
This connector must be connected to the power supply, otherwise system
might be unstable.

PCA-6007 User Manual 24

Award BIOS Setup

CHAPTER

3

25 Chapter 3

Chapter 3 Award BIOS Setup

3.1 Introduction

Award’s BIOS ROM has a built-in setup program that allows users to
modify the basic system configuration. This type of information is stored
in battery-backed memory (CMOS RAM) so that it retains the setup
information when the power is turned off.

3.1.1 CMOS RAM Auto-backup and Restore

The CMOS RAM is powered by an onboard button cell battery. When
you finish BIOS setup, the data in CMOS RAM will be automatically
backed up to Flash ROM. If operation in harsh industrial environment
cause a soft error, BIOS will recheck the data in CMOS RAM and auto­matically restore the original data in Flash ROM to CMOS RAM for
booting.

Note: If you intend to change the CMOS setting with-

out restoring the previous backup, you have to
click on "DEL" within two seconds of the
"CMOS checksum error..." display screen mes­sage appearing. Then enter the "Setup" screen
to modify the data. If the "CMOS checksum
error..."message appears again and again,
please check to see if you need to replace the
battery in your system.

PCA-6007 User Manual 26

3.2 Entering Setup

Turn on the computer and press <Del> to allow you to enter the BIOS
setup.

Figure 3.1: Award BIOS Setup initial screen

3.3 Standard CMOS Setup

Choose the “Standard CMOS Features” option from the “Initial Setup
Screen” menu, and the screen below will be displayed. This menu allows
users to configure system components such as date, time, hard disk drive,
floppy drive, display, and memory.

Figure 3.2: Standard CMOS features screen

27 Chapter 3

3.4 Advanced BIOS Features

The “Advanced BIOS Features” screen appears when choosing the
“Advanced BIOS Features” item from the “Initial Setup Screen” menu. It
allows the user to configure the PCA-6007 according to his particular
requirements. Below are some major items that are provided in the
Advanced BIOS Features screen. A quick booting function is provided
for your convenience. Simply enable the Quick Booting item to save
yourself valuable time

Figure 3.3: Advanced BIOS features screen

3.4.1 CPU Features

While using Prescott core CPU, the "CPU Features" will show up for user to
adjust the value of "Delay Prior to Thermal" and "Limit CPUID MaxVal". The
"Delay Prior to Thermal" can select the period if user wants to lower the CPU
speed when CPU temperature is too high. The choices are: "4 Min", "8 Min", "16
Min" and "32 Min". The suitable selections of "Limit CPUID MaxVal" are "Dis­abled" in WinXP, and "Enabled" in NT 4.0.

3.4.2 Hard Disk Boot Priority

Select hard disk boot device priority.

3.4.3 Virus Warning

Enable virus warning, the commands are "Enabled" or "Disabled".

3.4.4 CPU L1 & L2 Cache

Enabling this feature speeds up memory access. The commands are
“Enabled” or “Disabled.”

PCA-6007 User Manual 28

3.4.5 Hyper-Threading Technology

While using CPU with Hyper-Threading technology, you can select
"Enabled" to enable Hyper Threading Technology in OS which supports
Hyper-Threading Technology or select "Disabled" for other OS which do
not support HT technology.

3.4.6 Quick Power On Self Test

Allows the system to skip certain tests while booting. This will decrease
the time needed to boot the system.

3.4.7 First/Second/Third Boot Device

The BIOS tries to load the OS with the devices in the sequence selected.
Choices are: "Floppy", "LS120", "HDD-0", "SCSI", "CDROM", "HDD­1", "HDD-2", "HDD-3", "ZIP100", "USB-FDD", "USB-ZIP", "USB­CDROM", "USB-HDD", "LAN", "Disabled".

3.4.8 Boot Other Device

Choose other device to boot, the choice is "Enabled" or "Disabled".

3.4.9 Swap Floppy Drive

If the system has two floppy drives, choose "Enabled" to assign physical
drive B to logical drive A and vice-versa. The commands are “Enabled”
or “Disabled.”

3.4.10 Boot UP Floppy Seek

Selection of the command “Disabled” will speed the boot up. Selection of
“Enabled” searches disk drives during boot up.

3.4.11 Boot Up NumLock Status

This feature selects the “power on” state for NumLock. The commands
are “Off” or “On.”

3.4.12 Gate A20 Option

"Normal": A pin in the keyboard controller controls GateA20.

"Fast" (Default): Lets chipset control GateA20.

3.4.13 Typematic Rate Setting

The typematic rate is the rate key strokes repeat as determined by the key­board controller. The commands are “Enabled” or “Disabled”. Enabling
allows the typematic rate and delay to be selected.

3.4.14 Typematic Rate (Chars/Sec)

BIOS accepts the following input values (characters/second) for type­matic rate: 6, 8, 10, 12, 15, 20, 24, 30.

29 Chapter 3

3.4.15 Typematic Delay (msec)

Typematic delay is the time interval between the appearance of two con­secutive characters, when holding down a key. The input values for this
category are: 250, 500, 750, 1000 (msec).

3.4.16 Security Option

Select whether the password is required every time the system boots or
only when you enter setup.

"System" The system will not boot, and access to Setup will be denied
if the correct password is not entered at the prompt.

"Setup" The system will boot, but access to Setup will be denied if
the correct password is not entered at the prompt.

Note: To disable security, select “PASSWORD SET-

TING” in the main menu. At this point, you will
be asked to enter a password. Simply press
<Enter> to disable security. When security is
disabled, the system will boot, and you can
enter Setup freely.

3.4.17 APIC Mode

This setting allows to enable the APIC mode, the choice is “Disabled” or
“Enabled.”

3.4.18 MPS Version Control For OS

This reports if an FDD is available for Windows 95. The selections are

"1.1" or "1.4."

3.4.19 OS Select For DRAM > 64MB

Select OS2 only if you are running OS/2 operating system with greater
than 64MB of RAM on the system. Commands are “Non-OS2” or “OS2.”

PCA-6007 User Manual 30

3.5 Advanced Chipset Features

By choosing the “Advanced Chipset Features” option from the “Initial
Setup Screen” menu, the screen below will be displayed. This sample
screen contains the manufacturer’s default values for the PCA-6007, as
shown in Figure 3-4:

Note: DRAM default timings have been carefully cho-

sen and should ONLY be changed if data is
being lost. Please first contact technical sup­port.

Figure 3.4: Advanced chipset features screen

3.5.1 DRAM Timing Selectable

This item allows you to control the DRAM speed. The selections are
"Manual" or "By SPD".

3.5.2 CAS Latency Time

This controls the latency between DDR RAM read command and the
time that the data actually becomes available. Leave this on the default
setting. The options are "2", "2.5" or "3".

31 Chapter 3

3.5.3 Active to Precharge Delay

This item allows you to select the value in this field, depending on
whether the board has paged DRAMs or EDO (extended data output)
DRAMs. The Choice: "8", "7", "6" and "5".

3.5.4 DRAM RAS# to CAS# Delay

In order to improve performance, certain space in memory is reserved for
ISA cards. This memory must be mapped into the memory space below
16MB. The Choice: "4", "3" and ''2".

3.5.5 DRAM RAS# Precharge

This controls the idle clocks after issuing a precharge command to
DRAM. Leave this on the default setting. The choice : "4", "3" and "2".

3.5.6 Memory Frequency

To adjust the frequency of memory. The choice : "DDR266", "DDR333",
"DDR400" and "Auto".

3.5.7 System BIOS Cacheable

Selecting Enabled allows caching of the system BIOS ROM at F0000h­FFFFFh, resulting in better system performance. However, if any pro­gram writes to this memory area, a system error may occur. The Choices:
"Enabled", "Disabled".

3.5.8 Video Bios Cacheable

Selecting Enabled allows caching of the video BIOS, resulting in better
system performance. However, if any program writes to this memory
area, a system error may occur. The Choices: "Enabled", "Disabled".

3.5.9 Memory Hole At 15M-16M

Enabling this feature reserves 15 MB to 16 MB memory address space
for ISA expansion cards that specifically require this setting. This makes
memory from 15 MB and up unavailable to the system. Expansion cards
can only access memory up to 16 MB. The default setting is “Disabled.”

3.5.10 AGP Aperture Size (MB)

Select the size of Accelerated Graphics Port (AGP) aperture. The aper­ture is a portion of the PCI memory address range dedicated for graphics
memory address space. Host cycles that hit the aperture range are for­warded to the AGP without any translation. The Choice : "4", "8", "16",
"32", "64", "128", and "256".

3.5.11 Init Display First

Choose the first display interface to initiate while booting. The choice is
"PCI Slot" or "Onboard".

PCA-6007 User Manual 32

3.5.12 On-Chip VGA

User can disable onboard VGA controller by selecting "Disabled"

3.5.13 On-Chip Frame Buffer Size

User can select frame buffer size. Option is :"1MB", "8MB" and "16MB".

33 Chapter 3

3.6 Integrated Peripherals

Figure 3.5: Integrated peripherals

Figure 3.6: On-Chip IDE Device

PCA-6007 User Manual 34

3.6.1 IDE HDD Block Mode

If your IDE hard drive supports block mode select Enabled for automatic
detection of the optimal number of block read/writes per sector the drive
can support.

3.6.2 On-Chip IDE Device

IDE Primary (Secondary) Master/Slave PIO/UDMA Mode (Auto) Each
channel (Primary and Secondary) has both a master and a slave, making
four IDE devices possible. Because each IDE device may have a different
Mode timing (0, 1, 2, 3, 4), it is necessary for these to be independent.
The default setting “Auto” will allow auto detection to ensure optimal
performance.

3.6.3 On-Chip Serial ATA

Choose the status of serial ATA, the default setting is "Auto" which let
system to arrange all parallel and serial ATA resource automatically. The
"Disabled" will disable SATA controller. The "Combined Mode" will
combine PATA and SATA, and max of 2 IDE drives in each channel.
The "Enhanced Mode" will enable both SATA and PATA, and max of 6
IDE drives are supported. The "SATA Only" means SATA is operating in
legacy mode.

3.6.4 Serial ATA Port0/Port1 Mode

Select the mode for SATA port0 and SATA port1. The choices are "Pri­mary Master", "Primary Slave", "Secondary Master", "Secondary Slave",

"SATA0 Master" and "SATA1 Master".

Figure 3.7: Onboard Device

35 Chapter 3

3.6.5 USB Controller

Select Enabled if your system contains a Universal Serial Bus (USB) con­troller and you have USB peripherals. The choices: "Enabled", "Dis­abled".

3.6.6 USB 2.0 Controller

This entry is for disable/enable USB2.0 controller only. The BIOS itself
may/may not have high speed USB support. If the BIOS has high speed
USB support built in, the support will be automatically turn on when high
speed device were attached. The Choice : "Enabled" and "Disabled".

3.6.7 USB Keyboard/Mouse Support

Select Enabled if user plan to use an USB keyboard. The choice:
"Enabled", "Disabled".

3.6.8 AC97 Audio

Select Disable if you do not want to use AC-97 audio. Option is "Auto",
"Disabled".

3.6.9 Onboard LAN1 Control

Options are "Enabled" and "Disabled" Select Disable if user does not
want to use onboard LAN controller1

3.6.10 Onboard LAN1 Boot ROM

Decide whether to invoke the boot ROM of the onboard LAN chip. The
Choice : "Disabled", "Enabled".

PCA-6007 User Manual 36

3.7 SuperIO Device

Figure 3.8: SuperIO Device

3.7.1 Onboard FDC Controller

When enabled, this field allows you to connect your floppy disk drives to
the onboard floppy disk drive connector instead of a separate controller
card. If you want to use a different controller card to connect the floppy
disk drives, set this field to Disabled.

3.7.2 Onboard Serial Port 1

The settings are "3F8/IRQ4", "2F8/IRQ3", "3E8/IRQ4", "2E8/ IRQ3"
and "Disabled" for the on-board serial connector.

3.7.3 Onboard Serial Port 2

The settings are "3F8/IRQ4", "2F8/IRQ3", "3E8/IRQ4", "2E8/ IRQ3"
and "Disabled" for the on-board serial connector.

3.7.4 UART Mode Select

This item allows you to select UART mode. The choices: "IrDA",
"ASKIR", "Normal".

3.7.5 RxD, TxD Active

This item allows you to determine the active of RxD, TxD. The Choices:
“Hi, Hi,” “Lo, Lo,” “Lo, Hi,” “Hi, Lo.”

3.7.6 IR Transmission Delay

This item allows you to enable/disable IR transmission delay. The
choices: "Enabled", "Disabled".

37 Chapter 3

3.7.7 UR2 Duplex Mode

This item allows you to select the IR half/full duplex function. The
choices: "Half", "Full".

3.7.8 Use IR Pins

The Choice : "RxD2, TxD2", "IR-Rx2Tx2".

3.7.9 Onboard Parallel Port

This field sets the address of the on-board parallel port connector. You
can select either "378/IRQ7", "278/IRQ5", "3BC/IRQ7", or "Disabled". If
you install an I/O card with a parallel port, make sure there is no conflict
in the address assignments. The single board computer can support up to
three parallel ports, as long as there are no conflicts for each port.

3.7.10 Parallel Port Mode

This field allows you to set the operation mode of the parallel port. The
setting “Normal” allows normal speed operation, but in one direction
only. “EPP” allows bidirectional parallel port operation at maximum
speed. “ECP” allows the parallel port to operate in bi-directional mode
and at a speed faster than the maximum data transfer rate. “ECP + EPP”
allows normal speed operation in a two-way mode.

3.7.11 EPP Mode Select

This field allows you to select EPP port type 1.7 or 1.9. The choices:

"EPP1.9", "EPP1.7".

3.7.12 ECP Mode Use DMA

This selection is available only if you select “ECP” or “ECP + EPP” in
the Parallel Port Mode field. In ECP Mode Use DMA, you can select
DMA channel 1, or DMA channel 3. Leave this field on the default set­ting.

3.7.13 PWRON After PWR-Fail

To setup the status of system after power fail. The "Off" will keep system
power off after power fail, the "On" will boot up the system after fail, and
the "Former-Sts" will return to the status before power fail.

PCA-6007 User Manual 38

3.8 Power Management Setup

The power management setup controls the single board computer's
“green” features to save power. The following screen shows the manufac-

turer’s defaults.

Figure 3.9: Power management setup screen (1)

3.8.1 Power-Supply Type

Choose the power-supply type, the choices are "AT" and "ATX".

3.8.2 ACPI function

The choice: "Enabled", "Disabled".

3.8.3 Video Off Method

To select the method to off the video. The Choice : "Blank Screen", "V/H
SYNC+ Blank", "DPMS".

3.8.4 Video Off In Suspend

When system is in suspend, video will turn off. The choices are "No" and
"Yes".

3.8.5 Suspend Type

The Choice : "Stop Grant", "PwrOn Suspend".

3.8.6 Modem Use IRQ

This determines the IRQ in which the MODEM can use.The choices: "3",
"4", "5", "7", "9", "10", "11", "NA".

39 Chapter 3

3.8.7 Soft-Off by PWR-BTTN

If you choose “Instant-Off”, then pushing the ATX soft power switch but­ton once will switch the system to “system off” power mode. You can
choose “Delay 4 sec.” If you do, then pushing the button for more than 4
seconds will turn off the system, whereas pushing the button momentarily
(for less than 4 seconds) will switch the system to “suspend” mode.

3.8.8 CPU THRM-Throttling

This field allows you to select the CPU THRM-Throttling rate. The
choices: "75.0%", "50.0%", and "25.0%".

3.8.9 Resume on LAN/PCI PME#

To enabled or disable the function to resume the system by PCI card or
LAN. The Choice : "Enabled", "Disabled".

3.8.10 Resume on Ring

This item allows you to wake up the system via COM port from the
remotehost. The choices: "Enabled", "Disabled".

3.8.11 Resume on Alarm

The Choice : "Enabled", "Disabled".

3.8.12 Primary IDE 0 (1) and Secondary IDE 0 (1)

When Enabled, the system will resume from suspend mode if Primary
IDE 0 (1) or Secondary IDE 0 (1) is active. The choice: "Enabled", "Dis­abled".

3.8.13 FDD, COM, LPT PORT

When Enabled, the system will resume from suspend mode if FDD, COM
port, or LPT port is active. The choice: "Enabled", "Disabled".

3.8.14 PCI PIRQ [A-D]#

When Enabled, the system will resume from suspend mode if interrupt
occurs. The choice: "Enabled", "Disabled".

PCA-6007 User Manual 40

3.9 PnP/PCI Configurations

Figure 3.10: PnP/PCI configurations screen

3.9.1 Reset Configuration Data

Default is Disable. Select Enable to reset Extended System Configuration
Data (ESCD) if you have installed a new add-on and system configura­tion has caused such a conflict that OS cannot boot.

3.9.2 Resources Controlled By

The commands here are "Auto(ESCD)" or “Manual.” Choosing “manual”
requires you to choose resources from each following sub-menu.
"Auto(ESCD)" automatically configures all of the boot and Plug and Play
devices but you must be using Windows 95 or above.

3.9.3 PCI/VGA Palette Snoop

This is left at “Disabled.”

41 Chapter 3

3.10 PC Health Status

3.10.1 CPU Warning Temperature

This item will prevent the CPU from overheating. The choices are: "Dis­abled", "50C/122F", "53C/127F", "56C/133F", "60C/140F", "63C/145F",

"66C/151F", "70C/158F".

Figure 3.11: PC health status screen

3.10.2 Current System Temp

This shows you the current temperature of system.

3.10.3 Current CPU Temperature

This shows you the current CPU temperature.

3.10.4 Current CPUFAN Speed

This shows you the current CPUFAN operating speed.

3.10.5 VCORE, +1.5V, VCC3, +5V, +12V, -12V, -5V,
VBAT(V), 5VSB(V)

This shows you the voltage of VCORE, +1.5V, VCC3, +5V, +12V, -12V,

-5V, VBAT(V), and 5VSB(V).

PCA-6007 User Manual 42

3.11 Spread Spectrum Control

Figure 3.12: Spread Spectrum Control screen

3.11.1 CPU Clock Ratio

Key in a DEC number to setup the CPU Clodk Ratio. (Min=8; Max=50).
This item only shows up under some special situations.

3.11.2 Spread Spectrum

To enable/disable the spread spectrum. The Choice : "Disabled", "-

0.40%", "- 0.50%", "- 0.60%" and "- 1.00%".

3.12 Password Setting

To change the password:

1. Choose the “Set Password” option from the “Initial Setup Screen”
menu and press <Enter>.

The screen will display the following message:

Please Enter Your Password

Press <Enter>.

2. If the CMOS is good or if this option has been used to change the
default password, the user is asked for the password stored in the CMOS.
The screen will display the following message:

43 Chapter 3

Please Confirm Your Password

Enter the current password and press <Enter>.

3. After pressing <Enter> (ROM password) or the current password
(user-defined), you can change the password stored in the CMOS. The
password must be no longer than eight (8) characters.

Remember, to enable the password setting feature, you must first select
either “Setup” or “System” from the “Advanced BIOS Features” menu.

3.13 Save & Exit Setup

If you select this and press <Enter>, the values entered in the setup utili­ties will be recorded in the CMOS memory of the chipset. The micropro­cessor will check this every time you turn your system on and compare
this to what it finds as it checks the system. This record is required for the
system to operate.

3.14 Exit Without Saving

Selecting this option and pressing <Enter> lets you exit the setup program
without recording any new values or changing old ones.

PCA-6007 User Manual 44

4

CHAPTER

Chipset Software
Installation Utility

45 Chapter 4

Chapter 4 Chipset Software Install Utility

4.1 Before you begin

To facilitate the installation of the enhanced display device drivers and
utility software, you should read the instructions in this chapter carefully
before you attempt installation. The device drivers for the PCA-6007
board are located on the software installation CD. The auto-run function
of the driver CD will guide and link you to the utilities and device drivers
under a Windows system. The Intel® Chipset Software Installation Util­ity is not required on any systems running Windows NT 4.0. Updates are
provided via Service Packs from Microsoft*.

Note: The files on the software installation CD are

compressed. Do not attempt to install the driv­ers by copying the files manually. You must use
the supplied SETUP program to install the driv­ers.

Before you begin, it is important to note that most display drivers need to
have the relevant software application already installed in the system
prior to installing the enhanced display drivers. In addition, many of the
installation procedures assume that you are familiar with both the rele­vant software applications and operating system commands. Review the
relevant operating system commands and the pertinent sections of your
application software’s user’s manual before performing the installation.

4.2 Introduction

The Intel® Chipset Software Installation (CSI) utility installs to the target
system the Windows INF files that outline to the operating system how
the chipset components will be configured. This is needed for the proper
functioning of the following features:

• Core PCI and ISA PnP services.

• AGP support.

• IDE Ultra ATA 100/66/33 and Serial ATA interface support.

• USB 1.1/2.0 support (USB 2.0 driver needs to be installed separately

for Win98)

PCA-6187 User’s Manual 46

• Identification of Intel ® chipset components in the Device Manager.

• Integrates superior video features. These include filtered sealing of

720 pixel DVD content, and MPEG-2 motion compensation for soft-

ware DVD

Note: This utility is used for the following versions of

Windows system, and it has to be installed
before installing all the other drivers:

Windows 98SE

Windows 2000

Windows Me

Windows XP

4.3 Windows XP Driver Setup

1. Insert the driver CD into your system's CD-ROM drive. In a few
seconds, the software installation main menu appears. Move the
mouse cursor over the "Auto" button under the "CSI UTILITY"
heading, a message pops up telling you to install the CSI utility
before other device drivers, as shown in the following figure. Click
on this button. Taking Windows XP as example.

47 Chapter 4

2. Click "Next" when you see the following message.

3. Click "Yes" when you see the following message.

PCA-6187 User’s Manual 48

4. Click "Next" when you see the following message.

5. When the following message appears, click "Finish" to complete
the installation and restart Windows.

49 Chapter 4

PCA-6187 User’s Manual 50

VGA Setup

CHAPTER

5

51 Chapter 5

Chapter 5 VGA Setup

5.1 Introduction

The PCA-6007 has VGA onboard, you need to install the VGA driver to
enable the function.

The Intel® 865GV Graphics Memory Controller Hub (the 865GV
GMCH) provides an integrated graphics accelerator delivering cost com­petitive 3D, 2D, and video capabilities. The GMCH contains an extensive
set of instructions for 3D operations, BLT and Stretch BLT operations,
motion compensation, overlay, and display control. The 865GV GMCH’s
video engines support video conferencing and other video applications.
The GMCH does not support a dedicated local graphics memory inter­face; it may only be used in a UMA configuration. The features include:

• Built-in 2D/3D VGA controller.

• Use Intel® Extreme Graphics Architecture

• Integrated 350MHz RAMDAC that can directly drive a progressive

scan analog monitor up to a resolution of 2048x1536 at 75Hz

• Maximum 3D resolution supported : 1600 x 1200 x 32 @ 85Hz.

• H/W motion compensation assistance for s/w MPEG 2 decoding.

• Software DVD at 30 fps Full Screen.

5.2 Dynamic Video Memory Technology

The following is quoted from "Intel® 865GV Chipset Dynamic Video
Memory Technology", document number : 253144-001 :

The method of memory allocation where the Operating System, Applica­tion and Graphics Memory come from a unified System Memory pool
known as Unified Memory Architecture (UMA).

Dynamic Video Memory Technology (DVMT) is an enhancement of the
UMA concept, wherein the optimum amount of memory is allocated for
balanced graphics and system performance, through Direct AGP (known
as Non-Local Video Memory, or NLVM), and a highly efficient memory
utilization scheme. DVMT ensures the most efficient use of available
memory – regardless of frame buffer or main memory sizing – for maxi­mum 2D/3D graphics performance.

PCA-6007 User Manual 52

DVMT dynamically responds to system requirements, and application
demands, by allocating the proper amount of display, texturing and buffer
memory after the operating system has booted. For example, a 3D appli­cation when launched may require more vertex buffer memory to
enhance the complexity of objects, or more texture memory to enhance
the richness of the 3D environment. The operating system views the inte­grated graphics driver as an application, which uses Direct AGP to
request allocation of additional memory for 3D applications, and returns
the memory to the operating system (OS) when no longer required.

The Intel Extreme Graphics Driver determines the size of the pre-allo­cated memory needed and will make additional Non-Local Video Mem­ory requests to achieve the amount needed for the display and application
requirement. The video memory size in the Intel® 865GV chipset varies
and is determined using several factors. The key factors are system
resources and system activity. The maximum video memory is up to
64MB SDRAM

5.3 Windows XP Driver Setup

Note: Before installing this driver, make sure the CSI

utility has been installed in your system. See
Chapter 4 for information on installing the CSI
utility

1. Insert the driver CD into your system's CD-ROM drive. In a few

seconds, the software installation main menu appears, as shown in the
following figure. Under the "VGA DRIVERS" heading, click on one of
the buttons (labeled "W2K XP", "WIN9X ME", and "WIN NT" respec­tively) according to the operating system you are using. The following

53 Chapter 5

installation procedure is for Windows XP. For other operating systems,
please follow the on-screen installation guide

1. Please click on "Next" to continue the installation

PCA-6007 User Manual 54

2. You will see a welcome window. Please chick on "Next" to con­tinue the installation.

3. Click "Yes" when you see the following message.

55 Chapter 5

4. Click on "Yes" to continue the installation

5. Click "Finish" to complete the installation and restart the computer
now or later.

PCA-6007 User Manual 56

6

CHAPTER

LAN Configuration

57 Chapter 6

Chapter 6 LAN Configuration

6.1 Introduction

The PCA-6007 features the 32-bit 10/100 Mbps Ethernet network inter­face. This interface supports bus mastering architecture and auto-negotia­tion features. Therefore standard twisted-pair cabling with RJ-45
connectors for 10 Mbps, 100 Mbps connections can be used. Extensive
driver support for commonly-used network systems is also provided.

6.2 Features

• Optional single/dual Intel 82562 10/100Base-T Ethernet LAN control-

ler

• Supports Wake-on-LAN remote control function.

• PCI Bus Master complies with PCI Rev. 2.2

• MAC & PHY (10/100/1000 Mbps) interfaces.

• Complies with 100Base-TX, and 10Base-T applications.

• Fully supports 100Base-TX, and 10Base-T operation.

• Single RJ-45 connector gives auto-detection of 10 Mbps or 100 Mbps

network data transfer rates and connected cable types.

• Plug and Play.

• Enhancements on ACPI & APM.

• Complies with PCI Bus Power Management Interface Rev. 1.1,

• ACPI Rev. 2.0, and Device Class Power Management Rev. 1.0.

PCA-6007 User Manual 58

6.3 Installation

Note: Before installing the LAN drivers, make sure the

CSI utility has been installed in your system.
See Chapter 4 for information on installing the
CSI utility.

The PCA-6007's onboard Ethernet interface supports all major network
operating systems. However, the installation procedure varies with differ­ent operating systems. In the following sections, refer to the one that pro­vides driver setup procedure for the operating system you are using.

6.4 Win XP Driver Setup (Intel 82562)

1. Insert the driver CD into your system's CD-ROM drive. In a few
seconds, the software installation main menu appears, as shown in
the following figure. Under the "LAN Drivers" heading, click on
the "Manual" to open file manager, then click "SETUP.EXE" to
run the installation procedure.

59 Chapter 6

2. Select "I accept the terms in the license agreement" and click
"Next" to continue.

3. Click "Next" to continue.

PCA-6007 User Manual 60

4. Click "Install Software" to start the installation procedure.

5. The driver will be installed automatically and the LAN function
will be enabled after the installation.

61 Chapter 6

PCA-6007 User Manual 62

7

CHAPTER

USB 2.0 Configuration

63 Chapter 7

Chapter 7 USB 2.0 Configuration

7.1 Introduction

The PCA-6007 is designed with Intel ICH5 which supports both USB1.1
and USB 2.0 high-speed transmission. It still remains the compatibility
with today's USB device. High-speed USB 2.0 provides data transfer up
to 480Mb/s which is 40 times faster than USB 1.1. It is ideal for today's
speed-demanding I/O peripherals.

7.2 Features

• Provides data transmission rate up to 480Mb/s

• Offer 40 greater bandwidth than USB 1.1

• Offers complete compatibility with current USB device

7.3 Installation

Note: Before installing this driver, make sure the CSI utility

has been installed in your system. See Chapter 4 for
information on installing the CSI utility.

Note: USB 2.0 driver is not available for Windows 98SE/ME

from PCA-6007 driver CD. Under these operating sys­tems, the USB device will operate at USB 1.1 speeds.

Note: Install service pack 4 under Windows 2000 to enable

USB 2.0.

Note: Install service pack 1 under Windows XP to enable

USB 2.0.

PCA-6007 User Manual 64

8

CHAPTER

Onboard Security Setup

65 Chapter 8

Chapter 8 Onboard Security Setup

8.1 Introduction

The PCA-6007's hardware monitor is designed with Winbond W83627HF.
Onboard security (OBS) functions monitor key hardware. They help you
maintain your system's stability and durability. The PCA-6007 can monitor
5 sets of system positive voltages, 2 sets of system negative voltages, CPU
cooling fan speed, and CPU temperature. The positive system voltage sets
which can be monitored include:

• CPU core voltage: 1.3 V ~ 3.3 V, according to Intel specifications.

• Transmission voltage from CPU to chipset: typically 1.8 V.

• Chipset voltage: typically 3.3 V.

• Main voltage: +5 V, +12 V.

The negative system voltage sets which can be monitored include:

• Main voltage: -5 V, -12 V.

PCA-6007 User Manual 66

8.2 Windows XP Driver Setup

1. Insert the driver CD into your system's CD-ROM drive. In a few
seconds, the software installation main menu appears, as shown in
the following figure. Click on the "Install" button under the "OBS

DRIVERS" heading.

2. Click "Next" when you see the following message.

67 Chapter 8

3. Click "Next" when you see the following message.

4. Click "Next" when you see the following message.

PCA-6007 User Manual 68

5. Click "Next" to continue.

6. Click "Finish" when you see the following message.

69 Chapter 8

8.3 Using the OBS Hardware Doctor Utility

After completing the setup, all the OBS functions are permanently
enabled. When a monitored reading exceeds safe limits, a warning mes­sage will be displayed and an error beep tone will activate to attract your
attention.

OBS Hardware Doctor will show an icon on the right side of the bottom
window bar. This icon is the "Terminate and Stay Resident" (TSR) icon.
It will permanently remain in the bottom window bar, and will activate
warning signals when triggered by the onboard security

system.

You can view or change values for various OBS settings by running this
utility:

1. From the desktop of Windows, click on "Start" and select "Pro­grams" , select "Winbond HWDoctor" and click "HWDOCTOR."

2. It is recommended that you load the default values for all the OBS
settings. However, if desired, you can establish new conditions for
voltage, fan speed, and temperature.

PCA-6007 User Manual 70

71 Chapter 8

PCA-6007 User Manual 72

Programming the
Watchdog Timer

Appendix

A

73 Appendix A

Appendix A Programming the watchdog

A.1 Programming the Watchdog Timer

The PCA-6007's watchdog timer can be used to monitor system software
operation and take corrective action if the software fails to function after
the programmed period. This section describes the operation of the
watchdog timer and how to program it.

A.1.1 Watchdog timer overview

The watchdog timer is built-in the super I/O controller W83627HF. It
provides the following functions for user programming:

• Can be enabled and disabled by user's program.

• Timer can be set from 1 to 255 seconds or 1 to 255 minutes.

• Generates an interrupt or resets signal if the software fails to reset the

timer after time-out.

A.1.2 Reset/ Interrupt selection

The J2 jumper is used to select reset or interrupt (IRQ 11) in the event the
watchdog timer is tripped. See Chapter 1 for detailed jumper settings.

Note: The interrupt output of the watchdog timer is a low

level signal. It will be held low until the watchdog timer
is reset.

A.1.3 Programming the Watchdog Timer

The I/O port address of the watchdog timer is 2E(hex) and 2F(hex).

2E (hex) is the address port. 2F(hex) is the data port.

You must first assign the address of register by writing address value

into address port 2E(hex), then write/read data to/from the assigned

register through data port 2F (hex).

PCA-6007 User Manual 74

Unlock W83627H

Select register of

watchdog timer

Enable the function of

the watchdog timer

Use the function of
the watchdog timer

Lock W83627HF

75 Appendix A

Watchdog Timer Registers

Address of register (2E) Attribute

Read/Write Value (2F) and

description

87 (hex) ----- Write this address to I/O

address port 2E (hex) twice
to unlock theW83627HF

07 (hex) write Write 08 (hex) to select reg-

ister of watchdog timer.

30 (hex) write Write 01 (hex) to enable

the function of the watch­dog timer. Disabled is set
as default.

F5 (hex) write Set seconds or minutes as

units for the timer.

Write 0 to bit 3: set sec­ond as counting unit.
[default]

Write 1 to bit 3: set
minute as counting unit

F6 (hex) write 0: stop timer [default]

01~FF (hex): The amount
of the count, in seconds or
minutes, depends on the
value set in register F5
(hex). This number decides
how long the watchdog
timer waits for strobe
before generating an inter­rupt or reset signal. Writing
a new value to this register
can reset the timer to count
with the new value.

PCA-6007 User Manual 76

F7 (hex) read/write Bit 6: Write 1 to enable key-

board to reset the timer, 0
to disable.[default]
Bit 5: Write 1 to generate a
timeout signal immediately
and automatically return to

0. [default=0]
Bit 4: Read status of watch­dog timer, 1 means timer is
""time out""."

AA (hex) ----- Write this address to I/O

port 2E (hex) to lock the
watchdog timer.2

Table A.1: Watchdog timer registers

A.1.4 Example Program

1. Enable watchdog timer and set 10 sec. as timeout interval

;-----------------------------------------------------------

Mov dx,2eh ; Unlock W83627HF

Mov al,87h

Out dx,al

Out dx,al

;-----------------------------------------------------------

Mov al,07h ; Select registers of watchdog timer

Out dx,al

Inc dx

Mov al,08h

Out dx,al

;-----------------------------------------------------------

Dec dx ; Enable the function of watchdog timer

Mov al,30h

Out dx,al

Inc dx

Mov al,01h

Out dx,al

77 Appendix A

;-----------------------------------------------------------

Dec dx ; Set second as counting unit

Mov al,0f5h

Out dx,al

Inc dx

In al,dx

And al,not 08h

Out dx,al

;-----------------------------------------------------------

Dec dx ; Set timeout interval as 10 seconds and start counting

Mov al,0f6h

Out dx,al

Inc dx

Mov al,10

Out dx,al

;-----------------------------------------------------------

Dec dx ; lock W83627HF

Mov al,0aah

Out dx,al

2. Enable watchdog timer and set 5 minutes as timeout interval

;-----------------------------------------------------------

Mov dx,2eh ; unlock W83627H

Mov al,87h

Out dx,al

Out dx,al

;-----------------------------------------------------------

Mov al,07h ; Select registers of watchdog timer

Out dx,al

Inc dx

Mov al,08h

Out dx,al

PCA-6007 User Manual 78

;-----------------------------------------------------------

Dec dx ; Enable the function of watchdog timer

Mov al,30h

Out dx,al

Inc dx

Mov al,01h

Out dx,al

;-----------------------------------------------------------

Dec dx ; Set minute as counting unit

Mov al,0f5h

Out dx,al

Inc dx

In al,dx

Or al,08h

Out dx,al

;-----------------------------------------------------------

Dec dx ; Set timeout interval as 5 minutes and start counting

Mov al,0f6h

Out dx,al

Inc dx

Mov al,5

Out dx,al

;-----------------------------------------------------------

Dec dx ; lock W83627HF

Mov al,0aah

Out dx,al

3. Enable watchdog timer to be reset by mouse

;-----------------------------------------------------------

Mov dx,2eh ; unlock W83627H

Mov al,87h

Out dx,al

79 Appendix A

Out dx,al

;-----------------------------------------------------------

Mov al,07h ; Select registers of watchdog timer

Out dx,al

Inc dx

Mov al,08h

Out dx,al

;-----------------------------------------------------------

Dec dx ; Enable the function of watchdog timer

Mov al,30h

Out dx,al

Inc dx

Mov al,01h

Out dx,al

;-----------------------------------------------------------

Dec dx ; Enable watchdog timer to be reset by mouse

Mov al,0f7h

Out dx,al

Inc dx

In al,dx

Or al,80h

Out dx,al

;-----------------------------------------------------------

Dec dx ; lock W83627HF

Mov al,0aah

Out dx,al

4. Enable watchdog timer to be reset by keyboard

;-----------------------------------------------------------

Mov dx,2eh ; unlock W83627H

Mov al,87h

Out dx,al

PCA-6007 User Manual 80

Out dx,al

;-----------------------------------------------------------

Mov al,07h ; Select registers of watchdog timer

Out dx,al

Inc dx

Mov al,08h

Out dx,al

;-----------------------------------------------------------

Dec dx ; Enable the function of watchdog timer

Mov al,30h

Out dx,al

Inc dx

Mov al,01h

Out dx,al

;-----------------------------------------------------------

Dec dx ; Enable watchdog timer to be strobed reset by keyboard

Mov al,0f7h

Out dx,al

Inc dx

In al,dx

Or al,40h

Out dx,al

;-----------------------------------------------------------

Dec dx ; lock W83627HF

Mov al,0aah

Out dx,al

5. Generate a time-out signal without timer counting

;-----------------------------------------------------------

Mov dx,2eh ; unlock W83627H

Mov al,87h

Out dx,al

81 Appendix A

Out dx,al

;-----------------------------------------------------------

Mov al,07h ; Select registers of watchdog timer

Out dx,al

Inc dx

Mov al,08h

Out dx,al

;-----------------------------------------------------------

Dec dx ; Enable the function of watchdog timer

Mov al,30h

Out dx,al

Inc dx

Mov al,01h

Out dx,al

;-----------------------------------------------------------

Dec dx ; Generate a time-out signal

Mov al,0f7h

Out dx,al ;Write 1 to bit 5 of F7 register

Inc dx

In al,dx

Or al,20h

Out dx,al

;-----------------------------------------------------------

Dec dx ; lock W83627HF

Mov al,0aah

Out dx,al

PCA-6007 User Manual 82

Appendix

B

I/O Pin Assignments

83 Appendix B

Appendix B Pin Assignments

B.1 IDE Hard Drive Connector (CN1, CN2)

Table B.1: IDE hard drive connector (CN1, CN2)
Pin Signal Pin Signal

1 IDE RESET* 2 GND
3DATA 7 4DATA 8
5DATA 6 6DATA 9
7DATA 5 8DATA 10
9 DATA 4 10 DATA 11
11 DATA 3 12 DATA 12
13 DATA 2 14 DATA 13
15 DATA 1 16 DATA 14
17 DATA 0 18 DATA 15
19 SIGNAL GND 20 N/C
21 DISK DMA REQUEST 22 GND
23 IO WRITE 24 GND
25 IO READ 26 GND
27 IO CHANNEL READY 28 CSEL
29 HDACKO* 30 GND
31 IRQ14 32 IDSC16­33 ADDR 1 34 PDIAG
35 ADDR 0 36 ADDR 2
37 HARD DISK SELECT 0* 38 HARD DISK SELECT 1*
39 IDE ACTIVE* 40 GND
* low active

PCA-6007 User Manual 84

B.2 Floppy Drive Connector (CN3)

33

31

3

1

32

434

2

Table B.2: Floppy drive connector (CN3)
Pin Signal Pin Signal

1 GND 2 FDHDIN*
3GND4N/C
5 N/C 6 FDEDIN*
7 GND 8 INDEX*
9 GND 10 MOTOR 0*
11 GND 12 DRIVE SELECT 1*
13 GND 14 DRIVE SELECT 0*
15 GND 16 MOTOR 1*
17 GND 18 DIRECTION*
19 GND 20 STEP*
21 GND 22 WRITE DATA*
23 GND 24 WRITE GATE*
25 GND 26 TRACK 0*
27 GND 28 WRITE PROTECT*
29 GND 30 READ DATA*
31 GND 32 HEAD SELECT*
33 GND 34 DISK CHANGE*
* low active

85 Appendix B

B.3 Parallel Port Connector (CN4)

13 2

12 1

25

1526

14

Table B.3: Parallel port connector (CN4)
Pin Signal Pin Signal

1 STROBE* 14 AUTOFD*
2D015ERR
3D116INIT*
4D217SLCTINI*
5D318GND
6D419GND
7D520GND
8D621GND
9D722GND
10 ACK* 23 GND
11 BUSY 24 GND
12 PE 25 GND
13 SLCT 26 N/C
* low active

PCA-6007 User Manual 86
