MDPC-4090
Medical grade desktop computer
User Manual
Copyright
The documentation and the software included with this product are copyrighted 2004 by Advantech Co., Ltd. All rights are reserved. Advantech
Co., Ltd. reserves the right to make improvements in the products
described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated or transmitted in any form or
by any means without the prior written permission of Advantech Co., Ltd.
Information provided in this manual is intended to be accurate and reliable. However, Advantech Co., Ltd. assumes no responsibility for its use,
nor for any infringements of the rights of third parties, which may result
from its use.
Acknowledgements
Intel and Pentium are trademarks of Intel Corporation.
Microsoft Windows and MS-DOS are registered trademarks of
Microsoft Corp.
All other product names or trademarks are properties of their respective
owners.
Part No. 2006409000 1st Edition
Printed in Taiwan December 2004
MDPC-4090 User Manual ii
FCC Class B
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a residential environment. This equipment generates, uses and can radiate radio frequency
energy. If not installed and used in accordance with this user's manual, it
may cause harmful interference to radio communications.
Note that even when this equipment is installed and used in accordance
with this user's manual, there is still no guarantee that interference will
not occur. If this equipment is believed to be causing harmful interference
to radio or television reception, this can be determined by turning the
equipment on and off. If interference is occurring, the user is encouraged
to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and the receiver
• Connect the equipment to a power outlet on a circuit different from that
to which the receiver is connected
• Consult the dealer or an experienced radio/TV technician for help
Warning Any changes or modifications made to the equip-
ment which are not expressly approved by the
relevant standards authority could void your
authority to operate the equipment.
Packing List
Before installing your medical grade desktop computer, ensure that the
following materials have been received:
• MDPC-4090 medical grade desktop computer
• User's manual
• Accessories for MDPC-4090
• Power cord (1.8 m) - USA type (other types are available on request)
iii
• "Drivers and Utilities" CD-ROM disc
If any of these items are missing or damaged, contact your distributor or
sales representative immediately.
Warning To prevent electric shock, Do not remove cover.
No user serviceable parts inside, refer servicing to a qualified person
Additional Information and Assistance
1. Visit the Advantech websites at www.advantech.com or www.advan-
tech.com.tw where you can find the latest information about the product.
2. Contact your distributor, sales representative, or Advantech's customer
service center for technical support if you need additional assistance.
Please have the following information ready before you call:
• Product name and serial number
• Description of your peripheral attachments
• Description of your software (operating system, version, application
software, etc.)
• A complete description of the problem
• The exact wording of any error messages
• This equipment is a source of electromagnetic waves. Before use
please, make sure that there are not EMI sensitive devices in its surrounding which may malfunction therefore.
MDPC-4090 User Manual iv
Warning 1. Input voltage rated 100-240 VAC, 50-60 Hz, 4-2
A (AC Mode)
2. Use a 3 V @ 195 mA lithium battery (Model
No. BR2032)
3. Packing: please carry the unit with both hands,
handle with care
4. Our European representative:
Advantech Europe GmbH
Kolberger Straße 7
D-40599 Düsseldorf, Germany
Tel: 49-211-97477350
Fax: 49-211-97477300
5. Maintenance: to properly maintain and clean
the surfaces, use only approved products or clean
with a dry applicator
Safety Instructions
1. Read these safety instructions carefully.
2. Keep this User's Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a
damp cloth. Do not use liquid or spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near
the equipment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it
or letting it fall may cause damage.
7. The openings on the enclosure are for air convection. Protect the equip-
ment from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before connecting
the equipment to the power outlet.
v
9. Position the power cord so that people cannot step on it. Do not place
anything over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the
power source to avoid damage by transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or electri-
cal shock.
13. Never open the equipment. For safety reasons, the equipment should
be opened only by qualified service personnel.
14. If one of the following situations arises, get the equipment checked by
service personnel:
• a. The power cord or plug is damaged.
• b. Liquid has penetrated into the equipment.
• c. The equipment has been exposed to moisture.
• d. The equipment does not work well, or you cannot get it to work
according to the user's manual.
• e. The equipment has been dropped and damaged.
• f. The equipment has obvious signs of breakage.
15. DO NOT LEAVE THIS EQUIPMENT IN AN UNCONTROLLED
ENVIRONMENT WHERE THE STORAGE TEMPERATURE IS
BELOW -20° C (-4° F) OR ABOVE 60° C (140° F). THIS MAY DAMAGE THE EQUIPMENT.
16. If your computer is losing dramatic time or the BIOS configuration
reset to default, the battery has no power.
Caution Do not replace battery yourself. Please contact a
qualified technician or your retail.
17. IMPROPER INSTALLATION OF VESA MOUNTING CAN
RESULT IN SERIOUS PERSONAL INJURY! VESA mount installation
should be operated by professional technician, please contact the service
technician or your retail if you need this service.
18. THE COMPUTER IS PROVIDED WITH CD DRIVES COMPLY
WITH APPROPRIATE SAFETY STANDARDS INCLUDING IEC
60825.
MDPC-4090 User Manual vi
19. CLASSIFICATION:
• Class I Equipment
• No applied part
• Continuous Operation
• Not AP or APG category
20. Disconnect device: Appliance inlet.
21. Follow the national requirement to dispose unit.
22. Maintenance: to properly maintain and clean the surfaces, use only
approved products or clean with a dry applicator.
23. Contact information:
No.1, Alley 20, Lane 26, Reuiguang Road Neihu District, Taipei,
Taiwan 114, R.O.C.
TEL: (02)27927818
vii
24.
25. This equipment shall not be used for life support system.
26. This equipment shall be interconnected only to IEC 60601-1
approved equipment.
27. The sound pressure level at the operator's position according to IEC
704-1:1982 is no more than 70dB(A).
DISCLAIMER This set of instructions is given according to
IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained
Product Warranty (1 year)
Advantech warrants to you, the original purchaser, that each of its products will be free from defects in materials and workmanship for two years
from the date of purchase.
This warranty does not apply to any products which have been repaired or
altered by persons other than repair personnel authorized by Advantech,
or which have been subject to misuse, abuse, accident or improper installation. Advantech assumes no liability under the terms of this warranty as
a consequence of such events.
Because of Advantech’s high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If an
Advantech product is defective, it will be repaired or replaced at no
charge during the warranty period. For out-of-warranty repairs, you will
MDPC-4090 User Manual viii
be billed according to the cost of replacement materials, service time and
freight. Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For
example, CPU speed, Advantech products used, other hardware
and software used, etc.) Note anything abnormal and list any
onscreen messages you get when the problem occurs.
2. Call your dealer and describe the problem. Please have your man-
ual, product, and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return
merchandize authorization) number from your dealer. This allows
us to process your return more quickly.
4. Carefully pack the defective product, a fully-completed Repair and
Replacement Order Card and a photocopy proof of purchase date
(such as your sales receipt) in a shippable container. A product
returned without proof of the purchase date is not eligible for warranty service.
5. Write the RMA number visibly on the outside of the package and
ship it prepaid to your dealer.
CE
This product has passed the CE test for environmental specifications
when shielded cables are used for external wiring. We recommend the use
of shielded cables. This kind of cable is available from Advantech. Please
contact your local supplier for ordering information.
CE
This product has passed the CE test for environmental specifications. Test
conditions for passing included the equipment being operated within an
industrial enclosure. In order to protect the product from being damaged
by ESD (Electrostatic Discharge) and EMI leakage, we strongly recommend the use of CE-compliant industrial enclosure products.
ix
Technical Support and Assistance
Step 1. Visit the Advantech web site at www.advantech.com/support
where you can find the latest information about the product.
Step 2. Contact your distributor, sales representative, or Advantech's cus-
tomer service center for technical support if you need additional
assistance. Please have the following information ready before
you call:
- Product name and serial number
- Description of your peripheral attachments
- Description of your software (operating system, version, application software, etc.)
- A complete description of the problem
- The exact wording of any error messages
Wichtige Sicherheishinweise
1. 1. Bitte lesen sie Sich diese Hinweise sorgfältig durch.
2. Heben Sie diese Anleitung für den späteren Gebrauch auf.
3. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen. Ver-
wenden Sie Keine Flüssig-oder Aerosolreiniger. Am besten dient
ein angefeuchtetes Tuch zur Reinigung.
4. Die NetzanschluBsteckdose soll nahe dem Gerät angebracht und
leicht zugänglich sein.
5. Das Gerät ist vor Feuchtigkeit zu schützen.
6. Bei der Aufstellung des Gerätes ist auf sicheren Stand zu achten.
Ein Kippen oder Fallen könnte Verletzungen hervorrufen.
7. Die Belüftungsöffnungen dienen zur Luftzirkulation die das Gerät
vor überhitzung schützt. Sorgen Sie dafür, daB diese Öffnungen
nicht abgedeckt werden.
8. Beachten Sie beim. AnschluB an das Stromnetz die AnschluBw-
erte.
9. Verlegen Sie die NetzanschluBleitung so, daB niemand darüber
fallen kann. Es sollte auch nichts auf der Leitung abgestellt werden.
10. Alle Hinweise und Warnungen die sich am Geräten befinden sind
zu beachten.
11. Wird das Gerät über einen längeren Zeitraum nicht benutzt, sollten
Sie es vom Stromnetz trennen. Somit wird im Falle einer Überspannung eine Beschädigung vermieden.
MDPC-4090 User Manual x
12. Durch die Lüftungsöffnungen dürfen niemals Gegenstände oder
Flüssigkeiten in das Gerät gelangen. Dies könnte einen Brand bzw.
elektrischen Schlag auslösen.
13. Öffnen Sie niemals das Gerät. Das Gerät darf aus Gründen der ele-
ktrischen Sicherheit nur von authorisiertem Servicepersonal geöffnet werden.
14. Wenn folgende Situationen auftreten ist das Gerät vom Stromnetz
zu trennen und von einer qualifizierten Servicestelle zu überprüfen:
a - Netzkabel oder Netzstecker sind beschädigt.
b - Flüssigkeit ist in das Gerät eingedrungen.
c - Das Gerät war Feuchtigkeit ausgesetzt.
d - Wenn das Gerät nicht der Bedienungsanleitung entsprechend funk-
tioniert oder Sie mit Hilfe dieser Anleitung keine Verbesserung erz-
ielen.
e - Das Gerät ist gefallen und/oder das Gehäuse ist beschädigt.
f - Wenn das Gerät deutliche Anzeichen eines Defektes aufweist.
15. VOSICHT: Explisionsgefahr bei unsachgemaben Austausch der
Batterie.Ersatz nur durch densellben order einem vom Hersteller
empfohlene-mahnlichen Typ. Entsorgung gebrauchter Batterien
navh Angaben des Herstellers.
16. ACHTUNG: Es besteht die Explosionsgefahr, falls die Batterie auf
nicht fach-männische Weise gewechselt wird. Verfangen Sie die
Batterie nur gleicher oder entsprechender Type, wie vom Hersteller
empfohlen. Entsorgen Sie Batterien nach Anweisung des Herstell-
ers.
Der arbeitsplatzbezogene Schalldruckpegel nach DIN 45 635 Teil 1000
beträgt 70dB(A) oder weiger.
Haftungsausschluss: Die Bedienungsanleitungen wurden entsprechend
der IEC-704-1 erstellt. Advantech lehnt jegliche Verantwortung für die
Richtigkeit der in diesem Zusammenhang getätigten Aussagen ab.
Safety Precaution - Static Electricity
Follow these simple precautions to protect yourself from harm and the
products from damage.
xi
1. To avoid electrical shock, always disconnect the power from your
PC chassis before you work on it. Don't touch any components on
the CPU card or other cards while the PC is on.
2. Disconnect power before making any configuration changes. The
sudden rush of power as you connect a jumper or install a card may
damage sensitive electronic components.
MDPC-4090 User Manual xii
Contents
Chapter 1 General Information ....................................... 2
1.1 Introduction ....................................................................... 2
1.2 Specifications .................................................................... 2
1.2.1 General ........................................................................... 2
1.2.2 Standard PC Functions ................................................... 2
1.2.3 Display Controller Interface .......................................... 3
1.2.4 Audio Function .............................................................. 3
1.2.5 PCI bus Ethernet Interface ............................................. 4
1.2.6 PCI bus 1394 interface ................................................... 4
1.2.7 Environment ................................................................... 4
1.2.8 Cleaning and Disinfecting ............................................. 5
1.3 Dimensions........................................................................ 6
Chapter 2 System Setup.................................................... 8
2.1 A Quick Tour of the MDPC-4090..................................... 8
2.2 Installation Procedures .................................................... 10
2.3 Running the BIOS Setup Program .................................. 12
2.4 Installing System Software.............................................. 12
2.5 Installing the Drivers....................................................... 13
Chapter 3 MCH Chipset Setup ...................................... 16
3.1 Introduction ..................................................................... 16
3.2 Installation of Chipset Driver.......................................... 16
3.3 Further Information......................................................... 18
Chapter 4 ATI Graphic Controller Setup..................... 20
4.1 Introduction ..................................................................... 20
Figure 1.1: Dimensions of the MDPC-4090 ............... 6
Figure 2.1: Front View of the MDPC-4090 ................... 8
Figure 2.2:CD-ROM drive of the MDPC-4090 ............. 9
Figure 2.3:Rear view of the MDPC-4090 ...................... 9
2.2.1 Connecting the Power Cord ........................................ 10
Figure 2.4:Connecting the power cord ........................ 10
2.2.2 Connecting the Keyboard and Mouse .......................... 11
Figure 2.5:Connecting the mouse and keyboard .........11
2.2.3 Switching on Power ..................................................... 11
2.2.4 Connecting the COM Ports 1, 2, & 3 ........................... 11
Figure 2.6:Connecting the device to COM ports ......... 11
2.2.5 Install the Ground Safety Cable ................................... 11
Figure 2.7:Insert the disk to CD-ROM drive ............... 13
Figure 2.8:The file directory on the CD-ROM ............ 14
3.2.1 Installation for Windows 2000/XP ..............................17
Figure 3.1:Chipset installation Wizard .................... 17
4.1.1 Graphic Controller ....................................................... 20
4.1.2 Display Memory .......................................................... 20
xiii
4.2 Installation of VGA Driver ............................................. 21
4.2.1 Installation for Windows 2000/XP ..............................22
Figure 4.1:Installation Wizard for ATI Driver ............ 22
4.3 Further Information......................................................... 23
Chapter 5 Audio Interface.............................................. 26
5.1 Introduction ..................................................................... 26
5.2 Installation of Audio Driver ............................................ 26
5.2.1 Installation for Windows 2000/XP ..............................27
Figure 5.1:Installation Wizard for Audio Driver ......... 27
5.3 Further Information......................................................... 27
Chapter 6 LAN Setup...................................................... 30
6.1 Introduction ..................................................................... 30
6.2 Installation of LAN Drivers ............................................ 30
6.2.1 Installation of Gigabit LAN Driver ............................. 31
Figure 6.1:InstallationWizard for Gigabit Driver ........ 31
6.2.2 Installation of Realtek 10/100M LAN Driver .............. 32
Figure 6.2:Installation Wizard for Realtek Driver ....... 32
6.3 Further information ......................................................... 32
XXX-XXXX User Manual xiv
2
1
CHAPTER
General Information
This chapter includes introductory
information about the MDPC-4090 as
well as instructions about its care and
usage.
Sections include:
• Introduction
• Specifications
• Dimensions
Chapter 1 General Information
1.1 Introduction
MDPC-4090 is an Intel Pentium 4 Mobile processor-based computer that
is designed to serve as a medical-grade computer for image processing
and analysis. It is a PC-based system with on-board high-performance
graphic controller, dual display DVI ports, multi-COM port interfaces,
PCI extended bus and a 16-bit stereo audio controller. With a built-in CDROM drive, CompactFlash card sockets and high speed Gigabit LAN, the
MDPC-4090 is a powerful medical computing device. For system integrators, this simple, complete, and highly integrated multimedia system,
easily processes and analyses images. MDPC-4090 is a reliable, costeffective solution for your application's processing requirements.
1.2 Specifications
1.2.1 General
• Dimensions (W x H x D): 431.6 x 109.1 x 370.5 mm (17" x 4.3" x
14.58")
• Wei ght: 12.2 Kg (26.87lb)
• Power Supply: 180 watts (Model No. FSP180-50MP (ISR040 6017) )
Input voltage: 100- 240V
Output voltages: +5 V @ 12 A, +12 V @ 12 A, +3.3 V @ 16.8 A,
+5 Vsb @ 2.0 A, -12 V @ 0.8 A
• Cooling Fan Dimensions (L x W x H): CPU fan: 60 x 60 x 10 mm
(2.4" x 2.4" x 0.4")
• Disk Drive Housing: Space for one 3.5" IDE HDD or one 2.5” compact type HDD, and one 5.25” CD-ROM drive
, 4-2 A max. @ 50 - 60Hz
AC
1.2.2 Standard PC Functions
• CPU: Socket 478 Intel® Pentium® 4 Mobile/Celeron™ up to 2.4 GHz
(1.7 and 2.2 GHz provided for long term support)
• BIOS: Award 256 KB Flash BIOS, supports Plug & Play.
• Chipset: Intel 845E
MDPC-4090 User Manual 2
• 2nd Level Cache: On-die 512 KB
• RAM: Max.to 2GB; DDR 200/266 SDRAM, 184-pin low-profile
angled DIMM socket X 2.
• PCI Bus Master IDE Interface: Supports two connectors. Each connector has one channel and supports two IDE devices. Each channel
supports PIO modes 0 ~ 4, DMA mode 0 ~ 2, and Ultra DMA 100
simultaneously. The secondary connector is designated for the CDROM drive. BIOS supports IDE CD-ROM boot-up
• Keyboard Interface: Support PS/2 mouse (Green) and keyboard interface (Blue)
• Parallel Port: One parallel port, supports SPP/EPP/ECP parallel mode.
• Serial ports: All ports are compatible with 16C550 UARTs; RS232 x
3(COM1/3/4), RS-232/422/485 x 1(COM2); Two RS-232 ports with
optical isolation (COM1/2).
• Universal Serial Bus (USB) port: Supports up to four USB 2.0 ports
• Watchdog Timer: 62-level, interval 1 ~ 62 seconds. Automatically
generates system reset or IRQ11 when the system stops due to a program error or EMI.
• CF Card Connector: CompactFlash Type I, II x 1
• SSD: 6 in 1 card reader (Optional)
• CMOS Battery (BIOS): 3.0 V @ 195 mA lithium battery
1.2.3 Display Controller Interface
• Integrated Graphics Chip: ATI MOB ILI TY
• Integrated Video RAM: 64 MB
• Resolution: 1600 x 1200 at 60 Hz
• Display port: Support 24 bits digital output (DVI port X 2)
• Dual Independent Display Support
TM
9000 (M9)
1.2.4 Audio Function
• Chipset: Realtek ALC202
• Audio Controller: 16-bit codec, Full-Duplex stereo single-chip PCI
audio solution
• Speaker: 5 W speakers x 2
3 Chapter 1
• Stereo Sound: 100% DOS GAME compatible (Sound Blaster or Sound
Blaster Pro)
• Audio Interface: Microphone-in (pink), Line-in (blue), Line-out
(Green)
1.2.5 PCI bus Ethernet Interface
• Chipset: Realtek RTL 8100BL / Intel 82540 (Gigabit LAN)
• Ethernet Interface: Full compliance with IEEE 802.3u 100Base-T and
10 Base-T specifications, includes software drivers and boot ROM x 1;
Gigabit LAN x 1
• 100/10Base-T auto-sensing capability
1.2.6 PCI bus 1394 interface
• IEEE 1394 port: VIA VT6306 controller, supports one IEEE-1394
port
1.2.7 Environment
• Operating Temperature: 0 ~ 40° C (32 ~ 104° F)
• Operating Relative Humidity: 10 ~ 40° C / 20 ~ 90% RH ( Non-condensing )
• Storage Relative Humidity: -20 ~ 50 °C/ 10 ~ 95% RH ( Non-condensing )
• Shock: 30 G, half sine, 11 ms duration
• Vibration: 0.047 double amplitude displacement ( 5~32Hz), 2G Peak
(32 ~500 Hz )
• Power MTBF: 100,000 hrs
• Altitudes: Operational : 6,000 feet ; shipping : 40,000 feet
• Certifications: EMC: CE, FCC approved
Safety: UL60601-1 and EN60601-1 approved.
Note This device bears the CE label in accordance with the
provisions of the EMC Directive 89/336/EMC and the
Low Voltage Directive 73/23/EEC.
MDPC-4090 User Manual 4
1.2.8 Cleaning and Disinfecting
During normal use, MDPC-4090 may become soiled and should, therefore, be cleaned regularly. Agents: Green tinctured soap and enzymatic
detergents
Steps:
1. Wipe MDPC-4090 with a clean cloth that has been moistened in the
cleaning solution.
2. Prepare agent per manufacturer’s instructions or hospital protocol.
3. Wipe thoroughly with a clean cloth
Cautions Do not immerse or rinse the MDPC-4090 and its
peripherals. If you accidentally spill liquid on the
device, disconnect the unit from the power source.
Contact your Biomed regarding the continued safety of
the unit before placing it back in operation.
Do not spray cleaning agent on the chassis.
Do not use disinfectants that contain phenol. Do not
autoclave or clean the MDPC-4090 or its peripherals
with strong aromatic, chlorinated, ketone, ether, or
Esther solvents, sharp tools or abrasives. Never
immerse electrical connectors in water or other liquids.
5 Chapter 1
1.3 Dimensions
Figure 1.1: Dimensions of the MDPC-4090
MDPC-4090 User Manual 6
2
2
CHAPTER
System Setup
This sections explains how to install the
hardware and software for MDPC4090, and how to configure the system.
Sections include:
• A quick tour of the MDPC-4090
• Installation procedures
• Running the BIOS setup program
• Installing system software
• Installing the drivers
Chapter 2 System Setup
2.1 A Quick Tour of the MDPC-4090
Before you start to set up the MDPC-4090, take a moment to become
familiar with the locations and purposes of the controls, drives, connections and ports, which are illustrated in the figures below.
The LED in the front bezel indicates the power on and off status. When
MDPC-4090 is on, the LED will be green, and if power is off, the LED
will not be lit.
When you place MDPC-4090 upright on a desktop, the front cover and
power switch will be as shown in Figure 2-1.
Figure 2.1: Front View of the MDPC-4090
When you open the slide cover downwards, you will see the CD-ROM
drive behind the slide cover, as shown in Figure 2-2.
MDPC-4090 User Manual 8
Figure 2.2: CD-ROM drive of the MDPC-4090
When you turn the MDPC-4090 around and look at its rear cover, you
will find the PCI/ISA expansion slot located on the right side. This slot is
covered by a side panel cover. The I/O section is distributed in the rear
side of the MDPC-4090, as shown in Figure 2-3. (The I/O section
includes various I/O ports, including serial ports, parallel port, the Ethernet port, USB ports, the microphone jack, 1394 port and so on.)
Figure 2.3: Rear view of the MDPC-4090
9 Chapter 2
2.2 Installation Procedures
2.2.1 Connecting the Power Cord
The MDPC-4090 can only be powered by an AC electrical outlet (100 240 volts, 50 - 60 Hz). Be sure to always handle the power cords by holding the plug ends only.
Follow these procedures in order:
1. Connect the female end of the power cord to the AC inlet of the
MDPC-4090. (See Figure 2-4.)
2. Connect the 3-pin male plug of the power cord to an electrical outlet.
Figure 2.4: Connecting the power cord
MDPC-4090 User Manual 10
2.2.2 Connecting the Keyboard and Mouse
Connect the PS/2 mouse and keyboard to the I/O section of the MDPC-
4090. (See Figure 2-5.)
Figure 2.5: Connecting the mouse and keyboard
2.2.3 Switching on Power
Switch on the power switch on the front cover. (See Figure 2-1.)
2.2.4 Connecting the COM Ports 1, 2, & 3
Figure 2.6: Connecting the device to COM ports
2.2.5 Install the Ground Safety Cable
MDPC-4090 provides an Earth Ground connector (See Figure 2-3.). This
connector provides earth ground to the unit if the AC power receptacle
you are plugging into does not contain a ground prong.
11 Chapter 2
2.3 Running the BIOS Setup Program
MDPC-4090 is likely to have been properly set up and configured by
your dealer prior to delivery. You may still find it necessary to use the
BIOS (Basic Input-Output System) setup program to change system configuration information, such as the current date and time or your type of
hard drive. The setup program is stored in read-only memory. It can be
accessed either when you turn on or reset the MDPC-4090, by pressing
the "Crtl+Alt+Del" key on your keyboard immediately after powering on
the computer.
The settings you specify with the setup program are recorded in a special
area of memory called CMOS RAM. This memory is backed up by a battery so that it will not be erased when you turn off or reset the system.
Whenever you turn on the power, the system reads the settings stored in
CMOS RAM and compares them to the equipment check conducted during the power on self-test (POST). If an error occurs, an error message
will be displayed on screen, and you will be prompted to run the setup
program.
2.4 Installing System Software
Recent releases of operating systems from major vendors include setup
programs which load automatically and guide you through hard disk
preparation and operating system installation. The guidelines below will
help you determine the steps necessary to install your operating system
on the MDPC’s hard drive.
Note Some distributors and system integrators may
have already pre-installed system software prior to
shipment of your MDPC-4090.
If required, insert your operating system's installation or setup diskette
into the diskette drive until the release button pops out. (See Figure 2-7)
BIOS supports system boot-up directly from the CD-ROM drive. You
may also insert your system installation CD-ROM disk into the CD-ROM
drive. (See Figure 2-7).
MDPC-4090 User Manual 12
Power on or reset the system by pressing the "Ctrl"+"Alt"+"Del" keys
simultaneously. The MDPC-4090 will automatically load the operating
system from the diskette or CD-ROM.
If you are presented with the opening screen of a setup or installation program, follow the instructions on screen. The setup program will guide
you through preparation of your hard drive, and installation of the operating system.
Figure 2.7: Insert the disk to CD-ROM drive
2.5 Installing the Drivers
After installing your system software, you will be able to set up the
Chipset, VGA, audio, USB and Ethernet functions. All the drivers are
stored in a CD-ROM disc entitled "Drivers and Utilities" that can be
found in your accessory box.
After finishing the Windows 2000/XP installation, the system will automatically detect the CD-ROM hardware and install the CD-ROM driver
from the driver database from Windows 2000/XP when the system
reboots. Users are not required to install the CD-ROM driver themselves.
The standard procedures for installing the Chipset, VGA, audio, and
Ethernet drivers are described in Chapters 3, 4, 5 and 6 respectively.
The utility directory includes multimedia programs. Refer to the
README.TXT file inside the VGA folders for more detailed information.
The various drivers and utilities in the CD-ROM disc have their own text
files which help users install the drivers and understand their functions.
13 Chapter 2
These files are a very useful supplement to the information in this manual.
For your reference, the directory of drivers on the "Drivers and Utilities"
CD-ROM is:
Figure 2.8: The file directory on the CD-ROM
Note The drivers and utilities used for the MDPC-4090 are
subject to change without notice. If in doubt, check
Advantech's website or contact our application engineers for the latest information regarding drivers and
utilities.
MDPC-4090 User Manual 14
2
3
CHAPTER
MCH Chipset Setup
The section explains how to install the
MCH chipset and driver.
Sections include:
• Introduction
• Installation of chipset driver
Chapter 3 MCH Chipset Setup
3.1 Introduction
MDPC-4090 has an Intel 82845 Memory Controller Hub (MCH), which
is designed for use with the Intel
age. The Intel
82845 Memory Controller Hub (MCH) for the host bridge and the Intel
82801DB I/O Controller Hub (ICH4) for the I/O subsystem. The MCH
provides the processor interface, system memory interface, AGP interface, and hub interface in an 845E chipset desktop platform.
845E chipset contains two main components: the Intel
Pentium 4 processor in a 478-pin pack-
3.2 Installation of Chipset Driver
Complete the following steps to install the chipset driver. Follow the procedures in the flow chart that apply to the operating system that you are
using within your MDPC-4090.
Important The following windows illustrations are examples
only. You must follow the flow chart instructions
and pay attention to the instructions which appear
on your screen.
Note1 The CD-ROM drive is designated as “D” through-
out this chapter.
Note2 <Enter> means pressing the “Enter” key on the
keyboard.
Note3 Before you install the AGP bus driver of MDPC-
4090, please ensure you have installed the INF
driver of the Intel 845E chipset. You can find this
driver in the Utility CD-ROM.
MDPC-4090 User Manual 16
3.2.1 Installation for Windows 2000/XP
Figure 3.1: Chipset installation Wizard
17 Chapter 3
3.3 Further Information
For further information about the Chipset installation in your MDPC4090, including driver updates, troubleshooting guides and FAQ lists
please visit the following web resources.
Intel website: www.intel.com.tw
Advantech websites: www.advantech.com
MDPC-4090 User Manual 18
2
4
CHAPTER
ATI Graphic Controller
Setup
This chapter explains the installation of
the graphic controller and VGA driver.
Sections include:
• Introduction
• Installation of VGA driver
• Further information
Chapter 4 ATI Graphic Controller Setup
4.1 Introduction
MDPC-4090 has an onboard graphic controller. The specifications and
features are described in the following sections.
4.1.1 Graphic Controller
Mobility M9 provides fast and advanced 2D, 3D, and multimedia graphics performance. Its architecture features the latest achievements in the
graphics industry, and enables the use of the progressive new features in
upcoming applications, without compromising performance. ATI’s support of DirectX 8.1 features, highly optimized OpenGL support, and flexible memory configurations allow implementations of graphically
demanding applications.
4.1.2 Display Memory
With onboard 64 MB display memory, the VGA controller can drive Dual
display with resolutions up to 1600 x 1200 at 24-bit color.
MDPC-4090 User Manual 20
4.2 Installation of VGA Driver
Complete the following steps to install the VGA driver. Follow the procedures in the flow chart that apply to the operating system that you are
using within your MDPC-4090.
Important The following Windows illustrations are examples
only. You must follow the flow chart instructions and
pay attention to the instructions which appear on your
screen.
Note1 The CD-ROM drive is designated as “D” throughout
this chapter.
Note2 <Enter> means pressing the “Enter” key on the key-
board.
Note3 Before you install the graphic driver of MDPC-4090,
please ensure you have installed the INF driver of
the Intel 845E chipset. You can find this driver in the
Utility CD-ROM.
21 Chapter 4
4.2.1 Installation for Windows 2000/XP
Figure 4.1: Installation Wizard for ATI Driver
MDPC-4090 User Manual 22
4.3 Further Information
For further information about the AGP/SVGA installation in your
MDPC-4090, included Driver updates, troubleshooting guides and FAQ
lists please visit the following web resources.
Intel website: www.ati.com.tw
Advantech website: www.advantech.com
23 Chapter 4
MDPC-4090 User Manual 24
2
5
CHAPTER
Audio Interface
This chapter introduces the audio interface and explains the installation of the
audio driver.
Sections include:
• Introduction
• Installation of audio driver
• Further information
Chapter 5 Audio Interface
5.1 Introduction
MDPC-4090's on-board audio interface provides high-quality stereo
sound and FM music synthesis (ESFM) by using the ALC202 audio controller from Realtek. The audio interface can record, compress, and play
back voice, sound, and music with a built-in mixer control. The
MDPC-4090's onboard audio interface also supports the Plug & Play
(PnP) standard and provides PnP configuration for audio, FM, and MPU104 logical devices. It is compatible with Sound Blaster, Sound Blaster
Pro version 3.01, voice, and music functions. The ESFM synthesizer is
register compatible with OPL3 and has extended capabilities.
5.2 Installation of Audio Driver
Before installing the audio driver, please take note of the procedures
detailed below. You must know which operating system you are using in
your MDPC-4090, and then refer to the corresponding installation flow
chart. Just follow the steps in the flow chart. You can quickly and successfully complete the installation, even though you are not familiar with
instructions for Windows.
Important The following Windows illustrations are examples
only. You must follow the flow chart instructions
and pay attention to the instructions which appear
on your screen.
Note1 The CD-ROM drive is designated as “D” through-
out this chapter.
Note2 <Enter> means pressing the “Enter” key on the
keyboard.
MDPC-4090 User Manual 26
5.2.1 Installation for Windows 2000/XP
Figure 5.1: Installation Wizard for Audio Driver
5.3 Further Information
For further information about the audio interface installation for your
MDPC-4090, including driver updates, troubleshooting guides and FAQ
lists please visit the following web resources.
Realtek website: www.realtek.com.tw
Advantech website: www.advantech.com
27 Chapter 5
MDPC-4090 User Manual 28
2
6
CHAPTER
LAN Setup
This chapter introduces the Gigabit
Ethernet controller and network card,
and explains how to install the LAN
drivers.
Sections include:
• Introduction
• Installation of LAN drivers
• Further information
Chapter 6 LAN Setup
6.1 Introduction
MDPC-4090 is equipped with the Intel 82540EM Gigabit Ethernet controller with Intel's fourth generation Gigabit MAC design. It has fully
integrated, physical-layer circuitry to provide a standard IEEE 802.3
Ethernet interface for 1000Base-T, 100Base-TX, and 10Base-T applications (802.3, 802.3u, 802.3ab). The controller is capable of transmitting
and receiving data at 1000 Mb/s, 100 Mb/s, or 10 Mb/s data rates. In addition, the controller provides a direct Peripheral Component Interconnect
(PCI) 2.2 compliant bus up to 66 MHz.
MDPC-4090 has a Realtek 8100 network card with a high performance
32-bit Ethernet chipset which is fully compliant with IEEE 802.3 100
Mbps CSMA/CD standards. It is supported by major network operating
systems. It is also both 100Base-T and 10Base-T compatible.
The Ethernet port has a standard RJ-45 jack. The network boot feature
can be utilized by incorporating the boot ROM image files for the appropriate network operating system. The boot ROM BIOS files are combined
with system BIOS, which can be enabled/disabled in the BIOS setup.
6.2 Installation of LAN Drivers
Complete the following steps to install the LAN drivers on Windows
2000/XP. Follow the procedures in the flow chart that apply to the operating system that you are using within your MDPC-4090.
Important The following Windows illustrations are examples
only. You must follow the flow chart instructions and
pay attention to the instructions which appear on
your screen.
Note1 The CD-ROM drive is designated as “D” throughout
this chapter.
Note2 <Enter> means pressing the “Enter” key on the key-
board.
MDPC-4090 User Manual 30
6.2.1 Installation of Gigabit LAN Driver
Figure 6.1: InstallationWizard for Gigabit Driver
31 Chapter 6
6.2.2 Installation of Realtek 10/100M LAN Driver
Figure 6.2: Installation Wizard for Realtek Driver
6.3 Further information
For further information about the LAN installation in your MDPC-4090,
including driver updates, troubleshooting guides and FAQ lists please
visit the following web resources.
Intel website: www.intel.com.tw
Realtek website: www.realtek.com.tw
Advantech website: www.advantech.com
MDPC-4090 User Manual 32
Loading...
