User Manual
EKI-1500-CE Series
1/2/4-port RS-232/422/485 Serial
Device Servers
Copyright
Part No. 2009015200 Edition 1
Printed in Taiwan March 2018
The documentation and the software included with this product are copyrighted 2018
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice. No part of this manual may be reproduced, copied, translated or transmitted
in any form or by any means without the prior written permission of Advantech Co.,
Ltd. Information provided in this manual is intended to be a ccurate and reliable. However, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringements of the rights of third parties, which may result from its use.
Acknowledgements
Intel and Pentium are trademarks of Intel Corporation.
Microsoft Windows and MS-DOS are registered trademarks of Microsoft Corp.
All other product names or trademarks are properties of their respective owners.
Product Warranty (5 years)
Advantech warrants to you, the original purchaser, that each of its products will be
free from defects in materials and workmanship for five years from the date of purchase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Advantech, or which have been
subject to misuse, abuse, accident or improper installation. Advantech assumes no
liability under the terms of this warranty as a consequence of such events.
Because of Advantech’s high quality-control standards and rigorous testing, most of
our customers never need to use our repair service. If an Advantech product is defective, it will be repaired or replaced at no charge during the warranty period. Fo r out ofwarranty repairs, you will be billed according to the cost of replacement materials,
service time and freight. Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU
speed, Advantech products used, other hardware and software used, etc.) Note
anything abnormal and list any on screen messages you get when the problem
occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return merchandize
authorization) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a fully-completed Repair and Replacement
Order Card and a photocopy proof of purchase date (such as your sales receipt)
in a shippable container. A product returned without proof of the purchase date
is not eligible for warranty service.
5. Write the RMA number visibly on the outside of the p ackage and ship it prepaid
to your dealer.
ii EKI-1500-CE Series User Manual
Declaration of Conformity
CE
This product has passed the CE test for environmental specifications. Test conditions
for passing included the equipment being operated within an industrial enclosure. In
order to protect the product from being damaged by ESD (Electrostatic Discharge)
and EMI leakage, we strongly recommend the use of CE-compliant industrial enclosure products.
FCC Class A
Note: This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in
which case the user will be required to correct the interference at his own expense.
Technical Support and Assistance
1. Visit the Advantech web site at www .advantech.com/support wh ere you can find
the latest information about the product.
2. Contact your distributor, sales representative, or Advantech's customer service
center for technical support if you need additional assistance. Please have the
following information ready before you call:
– Product name and serial number
– Description of your peripheral attachments
– Description of your software (operating system, version, application sof tware,
etc.)
– A complete description of the problem
– The exact wording of any error messages
EKI-1500-CE Series User Manual iii
Warnings, Cautions and Notes
Warning! Warnings indicate conditions, which if not observed, can cause personal
injury!
Caution! Cautions are included to help you avoid damaging hardware or losing
data. e.g.
There is a danger of a new battery exploding if it is incorrectly installed.
Do not attempt to recharge, force open, or heat the battery. Replace the
battery only with the same or equivalent type recommended by the manufacturer. Discard used batteries according to the manufacturer's
instructions.
Note! Notes provide optional additional information.
Document Feedback
To assist us in making improvements to this manual, we would welcome comments
and constructive criticism. Please send all such - in writing to: support@advantech.com
Packing List
Before setting up the system, check that the items listed below are included and in
good condition. If any item does not accord with the table , please contact your dealer
immediately.
1 x Gateway Server
1 x DIN-Rail Mounting Bracket and Screws
1 x Wall-mounting Bracket
iv EKI-1500-CE Series User Manual
Safety Instructions
Read these safety instructions carefully.
Keep this User Manual for later reference.
Disconnect this equipment from any DC outlet before cleaning. Use a damp
cloth. Do not use liquid or spray detergents for cleaning.
For plug-in equipment, the power outlet socket must be located near the equip-
ment and must be easily accessible.
Keep this equipment away from humidity.
Put this equipment on a reliable surface during installation. Dropping it or letting
it fall may cause damage.
The openings on the enclosure are for air convection. Protect the equipment
from overheating. DO NOT COVER THE OPENINGS.
Make sure the voltage of the power source is correct before connecting the
equipment to the power outlet.
Position the power cord so that people cannot step on it. Do not place anything
over the power cord.
All cautions and warnings on the equipment should be noted.
If the equipment is not used for a long time, disconnect it from the power source
to avoid damage by transient overvoltage.
Never pour any liquid into an opening. This may cause fire or electrical shock.
Never open the equipment. For safety reasons, the equipment should be
opened only by qualified service personnel.
If one of the following situations arises, get the equipment checked by service
personnel:
– The power cord or plug is damaged.
– Liquid has penetrated into the equipment.
– The equipment has been exposed to moisture.
– The equipment does not work well, or you cannot get it to work according to
the user's manual.
– The equipment has been dropped and damaged.
– The equipment has obvious signs of breakage.
DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE THE
STORAGE TEMPERATURE MAY GO -40°C (-40°F) ~ 85°C (185°F). THIS
COULD DAMAGE THE EQUIPMENT. THE EQUIPMENT SHOULD BE IN A
CONTROLLED ENVIRONMENT.
The sound pressure level at the operator's position according to IEC 704-1:1982
is no more than 70 dB (A).
DISCLAIMER: This set of instructions is given according to IEC 704-1. Advan-
tech disclaims all responsibility for the accuracy of any statements contained
herein.
EKI-1500-CE Series User Manual v
Safety Precaution - Static Electricity
Static electricity can cause bodily harm or damage electronic devices. To avoid damage, keep static-sensitive devices in the static-protective packaging until the installation period. The following guidelines are also recommended:
Wear a grounded wrist or ankle strap and use gloves to prevent direct cont act to
the device before servicing the device. Avoid nylon gloves or work clothes,
which tend to build up a charge.
Always disconnect the power from the device before servicing it.
Before plugging a cable into any port, discharge the voltage stored on the cab le
by touching the electrical contacts to the ground surface.
vi EKI-1500-CE Series User Manual
Contents
Chapter 1 Introduction.........................................1
1.1 Overview................................................................................................... 2
1.2 Device Features................................ .... ... ... .......................................... ... . 2
Chapter 2 Getting Started....................................3
2.1 Specifications............................................................................................ 4
2.2 Hardware .................................................................................................. 6
2.2.1 Front View..................................................................................... 6
2.2.2 Rear View..................................................................................... 9
2.2.3 Top View..................................................................................... 10
2.2.4 LED Indicators............................................................................ 11
2.2.5 Dimensions................................................................................. 11
2.3 Connecting Hardware............................................................................. 13
2.3.1 DIN Rail Mounting....................................................................... 13
2.3.2 Wall-Mounting............................................................................. 15
2.3.3 Serial Connection ....................................................................... 17
2.3.4 Power Connection ............................................. .... ... ... ... ... .... ... .. 18
Chapter 3 Utility Configuration .........................19
3.1 Installing the Configuration Utility.......................... ... ... ... .... ... ... ... ... .... ... .. 20
3.2 Starting the Configuration Utility ............................................................. 23
3.3 Discovering Your Device Server............................................................. 24
3.3.1 Auto Searching........................................................................... 24
3.3.2 Network Settings......................................................................... 26
3.4 Administrator Settings....................... .... ... ... ... ... .... .................................. 28
3.4.1 Locate the Serial Device Server ................................................. 28
3.4.2 Securing the Serial Device Server.............................................. 29
3.4.3 Restore to Factory Default Settings................................... .... ... .. 31
3.4.4 Resetting the Device................................................................... 32
3.4.5 Add to Favorite ............................................... ... .... ... ... ... ... .... ... .. 33
3.4.6 Auto Mapping.............................................................................. 33
3.4.7 Manual Mapping................ ... .... ... ... ... ... .... ... ... ... .... ... ... ... ... .... ... .. 33
3.4.8 Update Firmware............... ... .... ... ... ... ... .... ... ... ... .... ... ... ... ... .... ... .. 34
Chapter 4 Selecting An Operating Mode.......... 35
4.1 Overview................................................................................................. 36
4.2 COM Port Redirector (Virtual COM Port)................................................ 36
4.2.1 Normal mode.............................................................................. 37
4.2.2 Round-Robin mode............................... .... ... ... ... .... ... ... ... ... .... ... .. 37
4.3 USDG Data Mode.......................................... ... .... ... ... ... .... ... ... ... ... .... ... .. 38
4.3.1 USDG TCP Client Mode............................................................. 38
4.3.2 USDG Data TCP Server mode................................................... 39
4.3.3 USDG UDP Server/Client mode........................................ .... ... .. 40
4.4 USDG Control Mode...................................... ... .... ... ... ... .... ... ... ... ... .... ... .. 41
4.4.1 Hangup Character ...................................................................... 41
4.4.2 Guard Time................................................................................. 41
4.5 RFC2217 Mode....................................................................................... 42
EKI-1500-CE Series User Manual vii
Chapter 5 Setting up Virtual COM Port .............43
5.1 Setting COM Port Redirector .......................... ... ... ... ... .... ... ... ... ...............44
5.2 Virtual COM Port Mapping ......................................................................44
5.2.1 Auto Mapping......................... ... ... ....................................... ... ... .. 44
5.2.2 Manual Mapping ......................................................................... 46
5.2.3 Configuration Wizard ................................ ... ... .... ... ... ... .... ... ... ... .. 47
5.2.4 Confirming Virtual COM Settings.............................. ... .... ... ... ... .. 48
5.2.5 Removing VCOM Ports................ ... .... ........................................ 50
5.2.6 Exporting and Importing VCOM Mapping ...................................51
5.3 Running a Diagnostic Test...................................................................... 51
Chapter 6 Web Interface.....................................52
6.1 Overview.................................................................................................53
6.2 Accessing the Web Page........................................................................ 53
6.2.1 Accessing the Web Page via Configuration Utility......................53
6.2.2 Accessing the Web Page via Web Browser................................ 54
6.3 System ....................................................................................................54
6.4 Ethernet Configuration............................................................................55
6.5 Port Configuration.... ... ............................................................................ 56
6.5.1 Basic...........................................................................................56
6.5.2 Operation....................................................................................57
6.5.3 Advanced....................................................................................58
6.6 Monitor....................................................................................................59
6.6.1 Setting......................................................................................... 59
6.6.2 Statistic .......................................................................................60
6.6.3 Connected IP......................................... ... ... ... .... ... ..................... 61
6.7 Auto Warning (Alarm).................. ... .... ... ... ... .... ... ... ... ... .... ........................ 62
6.7.1 Setting......................................................................................... 62
6.7.2 Event........................................................................................... 64
6.8 Syslogd ................................................................................................... 65
6.8.1 Syslogd Setting............................... .... ... ... ... ... .... ........................ 65
6.8.2 Syslogd Message...................... ... ... .... ... ... .................................. 66
6.9 Tools ....................................................................................................... 67
6.9.1 Ping............................................................................................. 67
6.9.2 Reboot ........................................................................................68
6.10 Management........................................................................................... 68
6.10.1 Log File....................................................................................... 68
6.10.2 Change Password.......................................................................69
6.10.3 Secure access IP...................................... ... ... .... ... ..................... 69
6.10.4 Export Device Settings................................................................69
6.10.5 Import Device Settings................................................................70
Chapter 7 Telnet/Serial Console Configuration71
7.1 Overview.................................................................................................72
7.2 Telnet Console........................................................................................ 72
7.2.1 Create a new connection............................................................72
7.2.2 Input the IP address....................................................................73
7.2.3 Connection Success ........................................................ ... ... ... .. 73
7.3 Command List.........................................................................................74
7.3.1 system.........................................................................................74
7.3.2 port.............................................................................................. 74
7.3.3 portadv........................................................................................75
7.3.4 mvcom ........................................................................................75
7.3.5 mctrl............................................................................................76
7.3.6 mdata..........................................................................................76
viii EKI-1500-CE Series User Manual
7.3.7 net............................................................................................... 76
7.3.8 password .................................................................................... 77
7.3.9 alarm........................................................................................... 77
7.3.10 monitor........................................................................................ 77
7.3.11 time............................................................................................. 77
7.3.12 service ........................................................................................ 78
7.3.13 mrfc2217..................................................................................... 78
7.3.14 apply........................................................................................... 78
7.3.15 exit.............................................................................................. 78
7.3.16 help............................................................................................. 78
7.3.17 reboot.......................................................................................... 78
Chapter 8 TCP and UDP Port Numbers............79
8.1 List of Known TCP and UDP Port Numbers ........................................... 80
EKI-1500-CE Series User Manual ix
List of Figures
Figure 2.1 Front View ..................................................................................................................... 6
Figure 2.2 Front View ..................................................................................................................... 7
Figure 2.3 Front View ..................................................................................................................... 8
Figure 2.4 Rear View...................................................................................................................... 9
Figure 2.5 Rear View.................................................................................................................... 10
Figure 2.6 Top View......................................................................................................................10
Figure 2.7 Top View......................................................................................................................11
Figure 2.8 System LED Panel ......................................................................................................11
Figure 2.9 Dimensions.................................................................................................................. 11
Figure 2.10 Dimensions.................................................................................................................. 12
Figure 2.11 Dimensions.................................................................................................................. 12
Figure 2.12 Installing the DIN-Rail Mounting Kit.............................................................................13
Figure 2.13 Correctly Installed DIN Rail Kit .................................................................................... 14
Figure 2.14 Removing the DIN-Rail................................................................................................14
Figure 2.15 Installing Wall Mount Plates ........................................................................................ 15
Figure 2.16 Securing Wall Mounting Screws.................................................................................. 16
Figure 2.17 Wall Mount Installation ................................................................................................16
Figure 2.18 DB9 Pin Assignment.................................................................................................... 17
Figure 2.19 Power Wiring for EKI-1500-CE Series.........................................................................18
Figure 3.1 InstallShield Wizard 1 of 4...........................................................................................20
Figure 3.2 InstallShield Wizard 2 of 4...........................................................................................21
Figure 3.3 InstallShield Wizard 3 of 4...........................................................................................21
Figure 3.4 InstallShield Wizard 4 of 4...........................................................................................22
Figure 3.5 Configuration Utility Overview ..................................................................................... 23
Figure 3.6 Open View of Serial Device Configuration Utility.........................................................24
Figure 3.7 Selecting a Group........................................................................................................ 25
Figure 3.8 Selecting a Device.......................................................................................................25
Figure 3.9 Viewing Basic Settings................................................................................................25
Figure 3.10 Utility Overview............................................................................................................26
Figure 3.11 Network Settings Overview .........................................................................................27
Figure 3.12 Locate the Serial Device Server..................................................................................28
Figure 3.13 Lock the Serial Device Server ..................................................................................... 29
Figure 3.14 Enter a Password........................................................................................................29
Figure 3.15 Reset Device............................................................................................................... 30
Figure 3.16 Unlock the Serial Device Server..................................................................................30
Figure 3.17 Restore to Factory Default Settings............................................................................. 31
Figure 3.18 Reset Device............................................................................................................... 32
Figure 3.19 Add to Favorite ............................................................................................................ 33
Figure 3.20 Update Firmware.........................................................................................................34
Figure 4.1 Virtual COM Mode....................................................................................................... 36
Figure 4.2 Configuring Virtual COM Mode.................................................................................... 37
Figure 4.3 USDG TCP Client Mode.............................................................................................. 38
Figure 4.4 Peers for Receiving Data.............................................................................................39
Figure 4.5 USDG TCP Server Mode ............................................................................................ 39
Figure 4.6 USDG Data Mode........................................................................................................39
Figure 4.7 USDG Control Mode....................................................................................................41
Figure 4.8 RFC2217 Mode...........................................................................................................42
Figure 5.1 Selecting Auto Mapping...............................................................................................44
Figure 5.2 Selecting Auto Mapping...............................................................................................45
Figure 5.3 Mapping Selected Ports .............................................................................................. 45
Figure 5.4 Viewing VCOM Mapping Results ................................................................................45
Figure 5.5 Selecting Manual Mapping.......................................................................................... 46
Figure 5.6 Viewing Manual VCOM Mapping Results....................................................................46
Figure 5.7 Viewing Manual VCOM Mapping Results....................................................................47
Figure 5.8 Selecting the Configuration Wizard .............................................................................47
Figure 5.9 Serial Port Listing on EKI-1500-CE Series Device...................................................... 48
x EKI-1500-CE Series User Manual
Figure 5.10 System Port VCOM Mapping Configuration................................................................ 49
Figure 5.11 Verifying VCOM Mapping Configuration ...................................... ... ... .... ... ... ............... 49
Figure 5.12 Remove VCOM Port.............. ... ... .... ... ... ... .... ... ... ... .... ... .......................................... ... .. 50
Figure 6.1 Accessing the Web Page via Configuration Utility ............................................. .... ... .. 53
Figure 6.2 System ............................... ... ... ... ....................................... ... .... ... ... ... .... ... .................. 54
Figure 6.3 Ethernet Configuration ................................. ... ... ... .... ... ... .......................................... ..55
Figure 6.4 Port Configuration > Basic........................................................................................... 56
Figure 6.5 Port Configuration > Operation.................................................................................... 57
Figure 6.6 Port Configuration > Operation.................................................................................... 58
Figure 6.7 Monitor > Setting...................... ... .... ... ... ... .... ... ... ... .... ......................................... ......... 59
Figure 6.8 Monitor > Statistic..... ... .... ... ... ... .......................................... ... .... .................................. 60
Figure 6.9 Monitor > Connected IP .............. .... ... ... ... .... ... ... ... .... ... ... ... ......................................... 61
Figure 6.10 Alarm > Setting............ .... ... ... ... ... .... ... ... ... .... ... ... ... .... ... ... ... ... ...................................... 62
Figure 6.11 Alarm > Event........ ... ... .... ... .......................................... ... ... ... .... ... ... ... ......................... 64
Figure 6.12 Syslogd > Syslogd Setting .................... ... .... ... ... ... .... ... ... ... ... .... ... ... ... .... ... ... ... ............ 65
Figure 6.13 Syslogd > Syslogd Message.................... .... ... ... ... .... ... ... ... ... .... ... ... ... .... ... ... ... ... .... ... .. 66
Figure 6.14 Tools > Ping ................................................................................................................ 67
Figure 6.15 Tools > Reboot............................................................................................................ 68
Figure 6.16 Management > Log File ........................ ... .... ... ... ... .... ... ... ... ... .... ... ... ... .... ... .................. 68
Figure 6.17 Management > Change Password.................. ... ... .... ... ... ... ... .... ... ... ... .... ... ... ... ... .... ... .. 69
Figure 6.18 Management > Secure access IP ............................................................................... 69
Figure 6.19 Management > Import................................................................................................. 70
Figure 7.1 Creating a Telnet Connection...................................................................................... 72
Figure 7.2 Creating a Telnet Connection...................................................................................... 73
Figure 7.3 Telnet Connection Console....................................... ... ... ... ... .... ... ... ... .... ... ... ... ... .... ... .. 73
EKI-1500-CE Series User Manual xi
Chapter 1
1Introduction
1.1 Overview
The EKI-1500-CE Series are network-based serial device servers that connect RS232/422/485 serial devices, such as PLC, meters, sensors, and barcode readers,
directly to a TCP/IP network.
Once connected through a EKI-1500-CE Series serial server, devices are able to
send and receive data through a network. This extends the tra ditional COM port s of a
PC, with access over a TCP/IP network. Through networking, you can control and
monitor remote serial devices over either a LAN or WAN. Since the EKI-1500-CE
Series is connected through a TCP/IP network, you may need to know some basic
facts about networking in order to connect the server correctly.
The EKI-1500-CE Series features two independent Ethernet ports and MAC
addresses to provide a redundant network mechanism to avoid data loss. The EKI1500-CE Series provides various operations: COM port redirection mode (Virtual
COM Port mode), TCP Server/ Client mode, UDP mode, Control mode and RFC2217
mode. Detailed descriptions of each operation are provided in a later chapter.
1.2 Device Features
Provides 2 x 10/100 Mbps Ethernet ports for LAN redundancy
Provides COM port redirection (Virtual COM), TCP and UDP operation modes
Supports up to 921.6 kbps, and any baud rate setting
Allows a max. of 5 hosts to access one serial port
Allows a max. of 16 hosts to be accessed as TCP client mode
Built-in 15 KV ESD protection for all serial signals
Provides rich configuration access, including: Windows utility, Telnet console,
and Web Browser
Supports 32-bit/64-bit Windows 2000/XP/Vista/7/8/8.1/10, Windows Server
2003/2008/2012, and Linux
Automatic RS-485 data flow control
Supports surge protection for D.C. power ports with line to line 2 KV, and line to
earth 4 KV; for signal ports with 4 KV.
Supports a wide operating temperature (I models only)
Supports isolation and wide operating temperature (CI models only)
EKI-1500-CE Series User Manual 2
Chapter 2
2Getting Started
2.1 Specifications
Specifications Description
Interface I/O Port
Power Connector Terminal block
Physical Enclosure Metal with solid mounting hardware
Installation DIN-Rail and Wall mount
Dimensions
(W x H x D)
LED Display System LED Power 1, Power 2, Status
Port LED LAN: Speed, Link/Active
Environment Operating
Temperature
Storage
Temperature
Ambient Relative
Humidity
Ethernet
Communications
Serial
Communications
Power Power
Compatibility IEEE 802.3, IEEE 802.3u
Speed 10/100 Mbps
Port Connector 8-pin RJ45
Protection Built- in 1.5 KV magnetic isolation
Port Type RS-232/422/485, software selectable
Port Connector DB9 male
Data Bits 5, 6, 7, 8
Stop Bits 1, 1.5, 2
Parity None, Odd, Even, Space, Mark
Flow Control XON/XOFF, RTS/CTS
Baud Rate 50 bps ~ 921.6 kb ps, any baud rat e se ttin g
Protection Built-in 15 KV ESD for all signals
Consumption
Power Input 12 ~ 48V
EKI-1521: 2 x RJ45 + 1 x RS-232/422/485
EKI-1521I: 2 x RJ45 + 1 x RS-232/422/485
EKI-1521CI: 2 x RJ45 + 1 x RS-422/485
EKI-1522: 2 x RJ45 + 2 x RS-232/422/485
EKI-1522I: 2 x RJ45 + 2 x RS-232/422/485
EKI-1522CI: 2 x RJ45 + 2 x RS-422/485
EKI-1524: 2 x RJ45 + 4 x RS-232/422/485
EKI-1524I: 2 x RJ45 + 4 x RS-232/422/485
EKI-1524CI: 2 x RJ45 + 4 x RS-422/485
EKI-1521/EKI-1522:
30 x 140 x 95mm (1.18" x 5.51" x 3.74")
EKI-1524: 42 x 140 x 95mm (1.65" x 5.51" x 3.74")
Serial: Tx, Rx
EKI-1521/EKI-1522/EKI-1524:
-10°C ~ 60°C (14°F ~ 140°F)
‘CI & I’ models: -40°C ~ 75°C (-40°F ~ 167°F)
-40°C ~ 85°C (-40°F ~ 185°F)
10 ~ 95% RH
'CI' models: 2KV Isolation for RS-422/485 signals
EKI-1521: 3.2W
EKI-1522: 3.2W
EKI-1524: 4.1W
, redundant dual inputs
DC
EKI-1500-CE Series User Manual 4
Specifications Description
Software Driver Support 32-bit/64-bit Windows XP/Vista/7/8/8.1/10, Windows
Server 2003/2008/2008 R2/2012/2012 R2, and Linux
Utility Advantech EKI Device Configuration Utility
Operation Modes
COM port redirection mode (Virtual COM)
TCP/UDP server (polling) mode
TCP/UDP client (event handling) mode
Pair connection (peer to peer) mode
Configuration Windows utility, Telnet console, Web Browser
Management SNMP MIB-II
Regulatory
Approvals
EMC CE, FCC Part 15 Subpart B (Class A)
5 EKI-1500-CE Series User Manual
2.2 Hardware
1
2
Default
LAN
TxRx
P1 P2 Status
Serial ports
EKI-1521-CE
1
2
3
2.2.1 Front View
The following view shows the EKI-1521.
Figure 2.1 Front View
No. Item Description
1 System LED panel See “LED Indicators” on page 11 for further details.
2 ETH port RJ45 ports x 2
3 Serial port DB9 pinout, supports RS-232/422/485
EKI-1500-CE Series User Manual 6
The following view shows the EKI-1522.
1
1
2
Default
LAN
TxRx
TxRx
P1 P2 Status
Serial ports
EKI-1522-CE
2
1
2
3
Figure 2.2 Front View
No. Item Description
1 System LED panel See “LED Indicators” on page 11 for further details.
2 ETH port RJ45 ports x 2
3 Serial port DB9 pinout, supports RS-232/422/485
7 EKI-1500-CE Series User Manual
The following view shows the EKI-1524.
EKI-1524-CE
1
1
2
3
4
2
Default
LAN
TxRx
TxRx
TxRx
TxRx
P1 P2 Status
Serial ports
1
2
3
Figure 2.3 Front View
No. Item Description
1 System LED panel See “LED Indicators” on page 11 for further details.
2 ETH port RJ45 ports x 2
3 Serial port DB9 pinout, supports RS-232/422/485
EKI-1500-CE Series User Manual 8
2.2.2 Rear View
1
The following view is valid for the EKI-1521 and EKI-1522.
Figure 2.4 Rear View
No. Item Description
1 DIN-Rail mounting
plate
Mounting plate used for the installation to a standar d DIN rail
9 EKI-1500-CE Series User Manual
The following view shows the EKI-1524.
1
1
3
2
No. Item Description
1 DIN-Rail mounting
plate
2.2.3 Top View
The following view is valid for the EKI-1521 and EKI-1522.
No. Item Description
1 Terminal block Connect cabling for power and alarm wiring
2 Ground terminal Screw terminal used to ground chassis
3 Wall mounting holes Screw holes (x4) used in the installation of a wall mounting plate
Figure 2.5 Rear View
Mounting plate used for the installation to a standard DIN rail
P-Fail
V2- V2+ V1- V1+
1A@24V
DC12-48V
PWR1
PWR2
Figure 2.6 Top View
EKI-1500-CE Series User Manual 10
The following view is valid for the EKI-1524.
PWR2
P-Fail
DC12-48V
PWR1
V2- V2+ V1- V1+
1A@24V
1
3
2
P1 P2 Status
12
3
EKI-1521-CE
140 [5.512]
140 [5.512]
149.80 [5.898]
47.05 [1.852]47.95 [1.888]
14.70
[0.579]
95 [3.740]
104 [4.094]
95 [3.740]
95 [3.740]
30 [1.181]
68 [2.677] 39 [1.535]
No. Item Description
1 Terminal block Connect cabling for power and alarm wiring
2 Ground terminal Screw terminal used to ground chassis
3 Wall mounting holes Screw holes (x4) used in the installation of a wall mounting plate
2.2.4 LED Indicators
Figure 2.7 Top View
No. LED Name LED Color Description
1 P1 Green Power 1 is on
2 P2 Green Power 2 is on
3 Status Amber The device server has been located by utility’s loca-
2.2.5 Dimensions
The following view is valid for the EKI-1521.
Figure 2.8 System LED Panel
Off Power 1 is off, or power error condition exists
Off Power 2 is off, or power error condition exists
tion function
Amber, blinking System is ready (1cycle/sec.)
Off System is not working
Figure 2.9 Dimensions
11 EKI-1500-CE Series User Manual
The following view is valid for the EKI-1522.
EKI-1522-CE
140 [5.512]
140 [5.512]
149.80 [5.898]
47.05 [1.852]47.95 [1.888]
14.70
[0.579]
95 [3.740]
104 [4.094]
95 [3.740]
95 [3.740]
30 [1.181]
68 [2.677] 39 [1.535]
EKI-1524-CE
Figure 2.10 Dimensions
The following view is valid for the EKI-1524.
33
[1.299]
15
[0.591]
35
[1.378]
42 [1.656] 42 [1.656]
104 [4.094]
95 [3.740]
30.50
[1.201]40[1.575]
95 [3.740]
20.53
[0.808]
11.40 [0.449]
9.80 [0.386]
140 [5.512]
Figure 2.11 Dimensions
47.05 [1.852]47.95 [1.888]
149.80 [5.898]
EKI-1500-CE Series User Manual 12
2.3 Connecting Hardware
DIN rail clip
DIN rail
DIN rail clip
release tab
2.3.1 DIN Rail Mounting
The DIN rail mount option is the quickest installation option. Additionally, it optimizes
the use of rail space.
The metal DIN rail kit is secured to the rear of th e switch. The device can be mounted
onto a standard 35 mm (1.37”) x 7.5 mm (0.3”) height DIN rail. The devices can be
mounted vertically or horizontally. Refer to the following guidelines for further information.
Note! A corrosion-free mounting rail is advisable.
When installing, make sure to allow for enough space to properly install
the cabling.
2.3.1.1 Installing the DIN-Rail Mounting Kit
1. Position the rear panel of the switch directly in front of the DIN rail, ma kin g su re
that the top of the DIN rail clip hooks over the top of the DIN rail, as shown in th e
following illustration.
Warning! Do not install the DIN rail under or in front of the spring mechanism on
the DIN rail clip to prevent damage to the DIN rail clip or the DIN rail.
Make sure the DIN rail is inserted behind the spring mechanism.
2. Once the DIN rail is seated correctly in the DIN rail clip, press the front of the
switch to rotate the switch down and into the release tab on the DIN rail clip.
If seated correctly, the bottom of the DIN rail should be fully inserted in the
release tab.
Figure 2.12 Installing the DIN-Rail Mounting Kit
13 EKI-1500-CE Series User Manual
See the following figure for an illustration of a completed DIN installation procedure.
Figure 2.13 Correctly Installed DIN Rail Kit
3. Grasp the bottom of the switch and slightly rotate it upwards. If there is resis-
tance, the switch is correctly installed. Otherwise, re-attempt the inst allatio n process from the beginning.
2.3.1.2 Removing the DIN-Rail Mounting Kit
1. Ensure that power is removed from the switch, and disconnect all cables and
connectors from the front panel of the switch.
2. Push down on the top of the DIN rail clip release tab with your fing er. As the clip
releases, lift the bottom of the switch, as shown in the following illustration.
\
Figure 2.14 Removing the DIN-Rail
EKI-1500-CE Series User Manual 14
2.3.2 Wall-Mounting
The wall mounting option provides better shock and vibration resistance than the DIN
rail vertical mount.
Note! When installing, make sure to allow for enough space to properly install
the cabling.
Before the device can be mounted on a wall, you will need to remove the DIN rail
plate.
1. Rotate the device to the rear side and locate the DIN mounting plate.
2. Remove the screws securing the DIN mounting plate to the rear panel of the
switch.
3. Remove the DIN mounting plate. Store the DIN mounting plate and provided
screws for later use.
4. Align the wall mounting plates on the rear side. The screw holes on the device
and the mounting plates must be aligned, see the following illustration.
5. Secure the wall mount plates with M3 screws, see the following figure.
Figure 2.15 Installing Wall Mount Plates
Once the wall mounting plates are secure on the device, you will need to attach
the wall screws (x4).
6. Locate the installation site and place the switch against the wall, making sure it
is the final installation location.
7. Use the wall mount plates as a guide to mark the locations of the screw holes.
8. Drill four holes over the four marked locations on the wall, keeping in mind that
the holes must accommodate wall sinks in addition to the screws.
9. Insert the wall sinks into the walls.
15 EKI-1500-CE Series User Manual
10. Insert the screws into the wall sinks. Leave a 2 mm gap between the wall and
8.0 mm
4.0 mm
2.0 mm
2
2
1
the screw head to allow for wall mount plate insertion.
Figure 2.16 Securing Wall Mounting Screws
Note! Make sure the screws dimensions are suitable for use with the wall
mounting plate.
Do not completely tighten the screws into the wall. A final adjust-
ment may be needed before fully securing the wall mounting plates
on the wall.
11. Align the wall mount plate over the screws on the wall.
12. Install the wall mount plate on the screws and slide it forward to lock in place,
see the following figure.
Figure 2.17 Wall Mount Installation
13. Once the device is installed on the wall, tighten the screws to secure the device.
EKI-1500-CE Series User Manual 16
2.3.3 Serial Connection
1
9
6
5
EKI-1500-CE Series provides up to four ports DB9 (male) connectors. RS-232/422/
485 pin assignments as below:
Pin 1 2 3 4 5 6 7 8 9
RS-232 DCD RX TX DTR GND DSR RTS CTS RI
RS-422 TX- TX+ GND RX+ RXRS-485 DATA- DATA+ GND
Figure 2.18 DB9 Pin Assignment
17 EKI-1500-CE Series User Manual
2.3.4 Power Connection
Load
External
Power
2.3.4.1 Overview
Warning! Power down and disconnect the power cord before servicing or wiring
the serial device server.
Caution! Do not disconnect modules or cabling unless the power is first switched
off.
The device only supports the voltage outlined in the type plate. Do not
use any other power components except those specifically designated
for the serial device server.
Caution! Disconnect the power cord before installation or cable wiring.
The EKI-1500-CE Series supports dual 12 to 48 VDC power inputs and power-fail
relay output.
The following figure illustrates a P-Fail alarm application example. The P-Fail alarm
contacts are visible on the front view of the terminal block.
DC12-48V
PWR2
V2- V2+ V1- V1+
1A@24V
P-Fail
PWR1
Figure 2.19 Power Wiring for EKI-1500-CE Series
You can connect an alarm indicator, buzzer or other signaling equipment through the
relay output. The relay opens if power input 1 or 2 fails. In a wiring example where an
LED is connected to the relay output, the LED would be off in an Open state.
EKI-1500-CE Series User Manual 18
Chapter 3
3Utility Configuration
3.1 Installing the Configuration Utility
Note! Microsoft.NET Framework version 2.0 or greater is required for this
application.
1. Insert the Advantech EKI Device Configuration Utility CD-ROM into the CD-
ROM drive (whereas E:\ is the drive name of your CD-ROM) on the host PC.
2. Use Windows explorer or the Windows Run command to execute the setup pro-
gram, the path for the setup program on the CD-ROM is as follows:
E:\EKI_Device_Configuration_Utility_v2.01.exe
3. If there is an existing COM port mapping utility on the host PC, remove it at this
time. A system reboot may be necessary before continuing the installation.
4. Once the InstallShield Wizard screen displays, click Next to proceed with the
installation.
Figure 3.1 InstallShield Wizard 1 of 4
EKI-1500-CE Series User Manual 20
5. The Software License Agreement displays, press I Agree to continue or Cancel
to stop the installation.
Figure 3.2 InstallShield Wizard 2 of 4
The InstallShield continues and a status screen displays. The default installation
path is C:\Program Files\EKI Device Configuration Utility.
Figure 3.3 InstallShield Wizard 3 of 4
21 EKI-1500-CE Series User Manual
6. Once the installation of the package is finished a Configuration Utility Setup
screen displays. Click Finish to conclude the process and exit the InstallShield
Wizard.
Figure 3.4 InstallShield Wizard 4 of 4
EKI-1500-CE Series User Manual 22
3.2 Starting the Configuration Utility
5
4
3
2
6
1
Advantech EKI-1500-CE Series device servers provide an easy-to-use utility to configure your serial device server through an Ethernet connection. For secure administration, it can also restrict the access rights for configuration to only one host PC.
With this secure function enabled, other PCs will not have permission for configuration. After the installation program on the Advantech IEDG Series Driver Utility CDROM is finished, the serial device servers are ready for use and configuration.
Advantech Serial Device Server Configuration Utility is an excellent device server
management tool. You can connect and configure the local and remote Advantech
serial device servers easily. The utility provides access to the following functions:
Configure the network settings (you can set the IP address, Gateway address,
and Subnet mask)
View and set the serial port parameters (configure operating mode, baud rate,
serial port settings and operating mode settings)
Perform diagnostic tests (virtual COM port testing, port status list)
Perform administrative functions (export and import the serial device server set-
ting, manage access IP, a descriptive name, upgrade firmware)
You can open the Configuration Utility from the Windows Start Menu by clicking Start
> All Programs > EKI Device Configuration Utility > EKI Device Configuration
Utility. The Configuration Utility displays as shown in the following figure.
Figure 3.5 Configuration Utility Overview
No Item Description
1 Menu Bar Displays File, View, Management, Tools and Help.
2 Quick Tool Bar Useful management functions shortcuts.
3 Serial Device Server
List Area
4 Information Panel Click on the devices or move cursor to the devices, the related
5 Status Bar Displays the current time.
6 Configuration Area Click on the item on the Device Server List Area, the configura-
Available devices are listed in this area. Devices and COM port s
can be organized or grouped in this area.
information is shown in this area.
tion page displays.
23 EKI-1500-CE Series User Manual
3.3 Discovering Your Device Server
3.3.1 Auto Searching
Advantech Serial Device Server Configuration Utility will automatically search all the
EKI-1500-CE Series device servers on the network and show them on the Serial
Device Server List Area of the utility. The utility provides an auto-search function to
show your device (s) by simply executing the configuration utility program from the
Start Menu.
From here all device on the same network domain will be searched and displayed on
Device Server List Area. You can click on the device name to show the features of
the specific device.
Click on the “+” before the model name, and the utility will expand the tree structure
to show the individual device name. Click on the “-” before the model name, and the
utility will collapse the tree structure.
Figure 3.6 Open View of Serial Device Configuration Utility
In the previous figure, the EKI-1500-CE Series device server is listed as EKI-1524BE-04FFAB.
Note! When you run the configuration utility for the first time, the default device
name is obtained from the serial device’s MAC identification number.
The name can be altered through the configuration utility.
Select the device in this sub-tree. The first tab on the Configuration Area shows the
summary of “Basic Information” included device type, version, and name, “Ethernet
EKI-1500-CE Series User Manual 24
Information”, and “Serial Port Information”. The serial port information frame displays
the operation mode, status and connected host IP.
Figure 3.7 Selecting a Group
Click on the “+” before the device name, and the utility will expand the interfaces on
this device server.
Figure 3.8 Selecting a Device
Click on each item to enter the configuration page to change the setting. The configuration will be introduced on following sections.
Figure 3.9 Viewing Basic Settings
25 EKI-1500-CE Series User Manual
3.3.2 Network Settings
Prior to setting up the server’s IP address determine the IP address mode.
There are four mode types available:
Static IP: mode to assign a specific assigned address
DHCP / AutoIP: mode to automatically assign IP addresses through a DHCP
server
BOOTP / AutoIP: mode to automatically assign an IP address through the con-
figuration server
DHCP/BOOTP/AutoIP: mode to automatically assign an IP address using a
Bootstrap Protocol or DHCP server.
The server is set with the following default IP configuration:
10.0.0.1 (Eth1)
10.0.0.2 (Eth2)
The EKI-1500-CE Series includes a software utility option, which you can install on
your system, for configuration through computer-based software. The EKI-1500-CE
Series also includes a web interface option for configuration through a standard web
browser.
Figure 3.10 Utility Overview
EKI-1500-CE Series User Manual 26
You can choose from four possible IP Configuration modes --- Static, DHCP, BOOTP,
and DHCP/BOOTP.
Figure 3.11 Network Settings Overview
Item Description
Sta tic IP Static IPUser defined IP address, Subn et Ma sk, an d Defaul t Gatewa y.
DHCP + Auto-IP DHCP Server assigned IP address, Subnet Mask, Default Gateway,
and DNS.
BOOTP + Auto-IP BOOTP Server assigned IP address.
DHCP + BOOTP +
Auto-IP
DNS Setting In order to use DNS feature, you need to set the IP addre ss of the
DHCP Server assigned IP address, Subnet Mask, Default Gateway,
and DNS, or BOOTP Server assigned IP address. (If the DHCP
Server does not respond)
DNS server to be able to access the ho st with the domain name. The
EKI-1500-CE Series device server provides Primary DNS Server
and Secondary DNS Server configuration items to set the IP address
of the DNS server. Secondary DNS Server is included for use when
Primary DNS server is unavailable.
DHCP Advanced
Setting
When you enabling DHCP protocol to get IP address, it will be waited
DHCP server to give IP within DHCP time out. The default value is
180 seconds.
Note! When you have finished the configuration of these settings for each cat-
egory, please press the “Apply” button in order to make these settings
effective on the Serial Device Server.
27 EKI-1500-CE Series User Manual
3.4 Administrator Settings
3.4.1 Locate the Serial Device Server
When several serial device servers are connected to the network, identification of a
specific serial device is possible through the Locate function.
To locate the serial device server:
1. From the device list frame, locate the desired device and right-click on it to dis-
play the settings menu.
2. Select Locate from the menu.
Figure 3.12 Locate the Serial Device Server
The unit’s Status LED will turn solid amber and the buzzer will sound until you click
Stop Locate.
EKI-1500-CE Series User Manual 28
3.4.2 Securing the Serial Device Server
3.4.2.1 Lock the Serial Device Server
The configuration utility provides the “Lock Device” function to make it more secure.
To lock the serial device server:
1. Right-click a desired device to display the settings menu.
2. Select Lock Device.
Figure 3.13 Lock the Serial Device Server
3. Enter a password. Retype the password entry to confirm the profile password.
Figure 3.14 Enter a Password
29 EKI-1500-CE Series User Manual
4. Right-click a desired device to display the settings menu. Select Reset Device
to restart the serial device server and store your setting password into the memory.
Figure 3.15 Reset Device
3.4.2.2 Unlock the Serial Device Server
To unlock the serial device server:
1. Right-click a desired device to display the settings menu.
2. Select Unlock Device.
3. Enter the password as entered in the Lock Device procedure.
Figure 3.16 Unlock the Serial Device Server
If you forgot the password, you must restore the setting of the serial device server to
the factory defaults, which will be introduced in the next section.
EKI-1500-CE Series User Manual 30
3.4.3 Restore to Factory Default Settings
The configuration utility provides the function to restore the serial device server to
factory default settings.
Figure 3.17 Restore to Factory Default Settings
The confirm message will display after clicking Restore to Factory Default Settings. If you really want to restore the serial device sever to factory default settings,
please click Yes button to continue.
Power off the serial device server within ten seconds. After reconnecting the power,
all settings will be reset to the factory default. If the power supply remains connected
for more than ten seconds, the serial device server will not be changed.
31 EKI-1500-CE Series User Manual
3.4.4 Resetting the Device
The Reset Device is available to allow you to reset the serial device server. The
function disconnects both the ethernet and serial connections.
The function also allows the serial device server to save new configuration settings to
flash memory. Once a new setting is changed, you can use the Save function to
accept the changes. You will need to reset the device to save the settings to flash
memory .
To reset the device:
1. Right-click a desired device to display the settings menu.
2. Select Reset Device.
Figure 3.18 Reset Device
The device resets. Once the process is complete, the serial device server displays
under the Serial Device Server listing once again.
EKI-1500-CE Series User Manual 32
3.4.5 Add to Favorite
The Add to Favorite function allows to easily map available devices to Favorite’s. By
bookmarking specific devices, you can create quickly accessible shortcuts for existing critical devices from the vast pool of locally or remotely networked EKI-1500-CE
Series devices.
3.4.6 Auto Mapping
See “Auto Mapping” on page 44 for further details.
3.4.7 Manual Mapping
See “Manual Mapping” on page 46 for further details.
Figure 3.19 Add to Favorite
33 EKI-1500-CE Series User Manual
3.4.8 Update Firmware
Advantech continually upgrades its firmware to keep up with the ever-expanding
world of computing. You can use the update firmware function in the utility to carry
out the upgrade procedure. Please access Advantech’s website: http://www.advantech.com to download the latest version of the firmware. Before updating the firmware, make sure that your host’s Network domain is as same as the serial device
server or the host can establish the TCP connection to the serial device server.
To update firmware:
1. Right-click a desired device to display the settings menu.
2. Select Update Firmware.
Figure 3.20 Update Firmware
3. Select the firmware file you want to update.
Wait for a few seconds for the firmware to finish updating. After the update has completed, click on the OK button. The serial device server will restart automatically.
Note! Be sure that the host PC Ethernet network domain is as same as the
EKI-1500-CE Series serial device server or the host PC can establish
the TCP connection with the serial device server while doing the updating firmware process.
EKI-1500-CE Series User Manual 34
Chapter 4
4Selecting An
Operating Mode
4.1 Overview
P
W
R
2
P
F
a
i
l
D
C
1
2
4
8
V
P
W
R1
V
2
V
2
+
V
1
V
1
+
1
A@
2
4
V
1
2
4
LA
N
D
ef
a
ult
T
x
R
x
T
x
Rx
Tx
Rx
T
x
Rx
Rx
P1
P
2
S
t
a
tus
S
e
r
i
a
l
P
o
r
t
s
E
K
I
1
5
2
8
C
I
EKI 1524
Ethernet
Ethe
r
Device A
SCADASCADA
S
S
C
C
A
A
A
D
D
A
A
S
C
C
A
A
D
D
A
SSS
C
C
C
A
A
A
D
D
S
S
C
C
A
A
D
D
SCADA
COM11 (Device F)
COM12 (Device G)
COM13 (Device H)
COM14 (Device I )
Port 1
Port 4
Port 2
Port 3
Device H
Device I
Device G
Device F
1
1
Device
GDevicF
e
I
H
c
RS232/422/485
The EKI-1500-CE Series is designed to network-enable any RS-232/422/485 serial
device, an provides industry-grade hardware and easy-to-use software to make connecting serial devices to an Ethernet network a surprisingly simple process.
These units immediately upgrade your existing serial devices for integration into the
Internet world. The EKI-1500-CE Series features many powerful functions, such as
high speed data transfer, access-control, auto-detection of all EKI-1500-CE Series
products, and more.
After the simple installation steps to attach your network and serial device to the
appropriate connectors on the serial device servers and driver installation, you will be
able to communicate with the serial devices via its own application software and wit
the EKI-1500-CE Series device server. COM port redirector, USDG TCP server
mode, TCP client mode, UDP server mode, UDP client mode, RFC2217 mode are all
different methods of making a serial connection across using one or more serial
device servers.
4.2 COM Port Redirector (Virtual COM Port)
Advantech EKI Device Configuration Utilityis a serial COM port redirector that creates virtual COM ports and provides access to serial device connected to Advantech
serial device server. You can configure the serial device server and enable the V irtual
COM port using one integrated utility. Advantech EKI Device Configuration Utilityallows you to configure Microsoft applications to communicate with network enabled
serial device servers as easily as if they were physically installed in or directly connected on the PC.
The Advantech redirector can create up to 255 virtual COM ports. Application to the
host can open a virtual COM port to access the serial device servers at the same
time. The redirector will handle each active virtual COM port as a separate TCP connection to Advantech serial device servers.
evic
e
evi
Figure 4.1 Virtual COM Mode
EKI-1500-CE Series User Manual 36
The EKI-1500-CE Series provides Multi-access function through an Ethernet connection path, allowing a maximum of five connections to open one serial port simultaneously. In this mode all connections must use the same serial setting. If one serial
setting within this configuration is configured differently, the data communication will
not function correctly.
Figure 4.2 Configuring Virtual COM Mode
The Host Idle Timeout setting monitors the connection between the host and the
device. If the Host Idle Timeout setting time is reached, the device server will release
the resources allocated to the port mapping. This prevents a stalled host from affecting the connective device.
The Multi-access function has two modes. One is Normal mode and the other is
Round-Robin mode.
4.2.1 Normal mode
By disabling the Response Timeout parameter, the EKI-1500-CE Series will operate
in normal mode. When multiple hosts simultaneously open the serial port, only the
first connected host obtain management control, the remaining connections only
have data communication function. Each serial port supports up to five simultaneous
connections, so multiple hosts can transmit/receive data to/from the same serial port
simultaneously. Every host can transmit data to the same serial port, and the EKI1500-CE Series will also transmit data to every hosts. When the multiple hosts transmit data to the same serial port at the same time, the received data from Ethernet
and the outputs of serial port are mixed. Wh en the EKI-1 500-CE Series receives dat a
from serial port, the data will also be transmitted to the connected hosts simultaneously.
4.2.2 Round-Robin mode
By enabling the Response Timeout parameter, the EKI-1500-CE Series Series
operates in “Round-Robin mode”. Each serial port supports up to five simultaneous
connections allowing hosts to simultaneously transmit/receive data to/from the same
serial port. Every host can simultaneously transmit data to the same serial port, EKI1500-CE Series processes the data in the order arrived. The EKI-1500-CE Series
processes the first host’s request and replies. The serial device server determines
the end of the serial acknowledgement through a response timeout. When EKI-1500CE Series serial device server does not receive a response from the serial port after
a response timeout query, the device replies with an acknowledgement and then processes the next host request. With an increased number of hosts, response time may
be lengthy, increasing the period of the Response Timeout.
Frame Break is an important parameter for Round Robin mode. The parameter is a
smart method of reducing ineffective waiting periods and streamlining the transmission process.
37 EKI-1500-CE Series User Manual
If the Frame Break function is disabled, EKI-1500-CE Series devices will wait for a
“Response Timeout” period, whether or not the device has transmitted data. During
this period, the host commands are queued and processed in the order received.
If Frame Break is enabled, the serial port idle is longer than the Frame Break period.
The EKI-1500-CE Series assumes the communication is completed and continues
with the next query. This is an efficient way to reduce waiting time and improve performance.
4.3 USDG Data Mode
The EKI-1500-CE Series can funciton as either a Data TCP server or a Data TCP client. Both operations support TCP and UDP protocol. The EKI-1500-CE Series allows
you to treat your serial devices as if they were networking devices. You can issue
commands or transmit data from serial devices, connected to a EKI-1500-CE Series
device, to any devices that are connected to the Internet.
4.3.1 USDG TCP Client Mode
In TCP Client mode, the TCP connection is established from the EKI-1500-CE Series
device server . This operation mo de support s a maximum of 16 simultan eous connections for each serial port on EKI-1500-CE Series to one host or several hosts. You
can configure the IP address and TCP port number of the network hosts connected
to the EKI-1500-CE Series device server using the Advantech Serial Device Server
Configuration Utility. After configuring the devices, when the EKI-1500-CE Series
device server receives the data from the serial port, and the device server connects
to the hosts which are configured.
Ethernet 1
Ethernet 2
V
2
V
2
D
+
P
C
-
F
1
a
2
i
-
l
4
8
V
P
V1
W
R
-
2
V
1
+
1
A
@
2
4
V
PW
R
1
P
1
P
2
S
ta
tus
De
fa
u
l
t
1
LA
N
2
R
x
T
x
R
x
T
x
R
x
T
x
Rx
T
x
4
S
er
ial P
o
r
ts
E
K
I
15
2
4
S232/422/485
R
Figure 4.3 USDG TCP Client Mode
In USDG Data TCP Client mode, you may need to enable the peer numbers you
would like to receive. You can set a maximum sixteen network devices to which you
may connect. You need to fill out the IP Address and Port (including local port and
peer port) of each network device to which you want to connect.
EKI-1500-CE Series User Manual 38
In the Peer for Receiving Data menu, entering “0” as the value for the Local Port will
P
W
R
2
P
-
F
ai
l
D
C
1
2
4
8
V
PW
R
1
V
2
V
2
+
V1
V
1
+
1
A
@
2
4
V
1
2
4
L
A
N
D
e
fa
u
lt
T
x
R
x
T
x
R
x
T
x
R
x
Tx
R
x
P
1
P
2
S
ta
tus
S
er
ial P
o
r
ts
E
K
I
1
52
4
Ethernet 1
RS232/422/485
Ethernet 2
assign a random TCP Port for an EKI-1500-CE Series device.
Figure 4.4 Peers for Receiving Data
4.3.2 USDG Data TCP Server mode
In TCP server mode, the TCP connection is initiated from the host to the EKI-1500CE Series device server . This operation mode support s a maximum of five simultaneous connections for each serial port on an EKI-1500-CE Series device server from a
single or multiple hosts. However a multi-host connection simultaneously transmits
the data from a single serial port.
Figure 4.5 USDG TCP Server Mode
Figure 4.6 USDG Data Mode
39 EKI-1500-CE Series User Manual
4.3.3 USDG UDP Server/Client mode
The USDG UDP mode is primarily used for the broadcasting of messages over a network. In UDP server mode, data is transmitted from the Host connected to the EKI1500-CE Series USDG UDP Port (Default Port 5300). In the default UDP client
mode, EKI-1500-CE Series device servers simultaneously transmits UDP messages
to a maximum of 16 peers.
USDG Data mode supports Data Idle Timeout, Data Listen Port, and Command Listen Port parameters.
4.3.3.1 Data Idle Timeout
The default is 60 seconds. If you want to keep connection continually, you can diasble the Data Idle T imeout. Dat a idle Time is the time period for which the device waits
for data. If the EKI-1500-CE Series does not receive data during established idle
time, the EKI-1500-CE Series will disconnect temporarily. When the data comes in, it
will reconnect automatically. Users do not need to reconnect.
4.3.3.2 Data Listen Port
The TCP/UDP port number represents the source port number, and the number is
used to identify the channel for remote initiating connections. The port range is 1024-
65533. If an unknown caller wants to connect to the system and request services,
they must define the TCP/UDP port to carry a long-term conversation.
Each node on a TCP/IP network has an IP address, and each IP address can allow
connection on one or more TCP port. The well-known TCP ports are those that have
been defined; for example, port 23 is used for Telnet connections. There are also
custom sockets that users and developers define for their specific needs. The default
TCP/UDP port of the EKI-1500-CE Series Port1 is 5300, Port2 is 5301, etc. Users
can adjust them according to preference or application. Each port has its own data
listen port to accept the connection requests of other network device. The data listen
port cannot be set to the same value. You can transmit/receive data to/from devices
via the data listen port.
4.3.3.3 Command Listen Port
Each port has its own command listen port to accept connection requests from other
network devices, so the command listen port cannot be set to the same value. The
Command Listen Port is different from the Data Listen port. <Default Port is 5400>
EKI-1500-CE Series User Manual 40
4.4 USDG Control Mode
In controlling mode, the EKI-1500-CE Series device server presents a modem interface to the attached serial device: it accepts AT-style modem commands to connect /
disconnect to other networking device.
If you want a serial device running application program to connect/disconnect to different devices on request, this function is available through the USDG Control mode.
Figure 4.7 USDG Control Mode
4.4.1 Hangup Character
The default character is “+”. After you have connected to another serial device an via
EKI-1500-CE Series device, you may need to disconnect, using the command “+++”.
To do this, press “+” three times and wait for the Guard timeout <default value is
1000ms>; the device will disconnect. You can set “Guard Time” to define the idle
time.
4.4.2 Guard Time
The default value is 1000 ms.
Example: <Guard Time>+++<Guard Time>
Command Function
ATD <IP address><TCP port><CR> Forms a TCP connection to the specified host.
ATA <CR> Answering an incoming call
+++<CR> Returns the user to the command prompt when
<LF><CR> OK <LF><CR> Commands are executed correctly
<LF><CR> CONNECT <LF><CR> Connect to other device
<LF><CR> RING ddd.ddd.ddd
<LF>< CR>
<LF><CR> DISCONNECT
<LF><CR>
<LF><CR> ERROR <LF><CR> Incorrect commands
<LF><CR> FAIL <LF><CR> If you issue an ATDT command and can not connect
Ex: ATDT 192.0.55.22:5201
In above example, the EKI-1500-CE Seri es de vic e
server forms a raw TCP connection to the networking
device (192.0.55.22). The TCP port is 5201.
entered from the serial port during a remote host connection.
Detect the connection request from other device,
which IP address is ddd.ddd.ddd.ddd.
Disconnect from other device
to the device, it will response “FAIL”.
41 EKI-1500-CE Series User Manual
4.5 RFC2217 Mode
RFC2217 mode is similar to virtual COM mode in that a driver is used to establish a
transparent connection between a host computer and a serial device by mapping the
serial port on EKI-1500-CE Series devices to a local COM port on a host computer.
RFC2217 defines general COM port control options based on the Telnet protocol.
Third party drivers supporting RFC2217 are widely available on the Internet and can
be used to implement virtual COM mapping to the serial port of your device.
Figure 4.8 RFC2217 Mode
EKI-1500-CE Series User Manual 42
Chapter 5
5Setting up Virtual COM
Port
5.1 Setting COM Port Redirector
Advantech COM port mapping software is a serial COM port redirector that creates
virtual COM ports and provides access to serial devices connected to an Advantech
serial device servers. Your serial device applications can communicate with serial
devices connected to the Advantech serial device servers without software ch anges.
Since the virtual COM ports work like standard Windows COM ports, your application
software sees no difference between a local serial device and one connected to an
Advantech serial device server.
The COM redirector utility and the virtual COM port management utility are integrated
into one utility with same GUI. The Advantech Serial Device Server Configuration
Utility can create all Virtual COM ports using the Auto Mapping function or by using
the manual mapping function.
5.2 Virtual COM Port Mapping
5.2.1 Auto Mapping
1. On your desktop, navigate to Start > All Programs > EKI Device Configura-
tion Utility and click Advantech EKI Device Configuration Utility to open the
utility.
2. Under Serial Device Servers, locate your server and click the icon to exp and
the listing.
3. Select the target device and right-click on it to open up the options menu win-
dow.
4. Locate Auto Mapping and select it.
Figure 5.1 Selecting Auto Mapping
The Batch Automatic Mapping Virtual COM Port window displays.
EKI-1500-CE Series User Manual 44
5. Locate From System Port and click the drop-down menu to select the target
System Port
Device PortSelected Options
COM port.
6. From the network address list, select the address options to map.
The selected address displays the Device Port and (EKI-1500-CE Series device
server physical serial port) and the system port which will be the VCOM port for
the PC.
Figure 5.2 Selecting Auto Mapping
7. From the network address list, select the address options to map.
8. Click Map Selected Ports to set the configuration.
Figure 5.3 Mapping Selected Ports
Once the mapping function is initialized, a successful mapping process results in the
virtual mapping of the designated physical serial port and VCOM PC port. See the
following figure.
Figure 5.4 Viewing VCOM Mapping Results
45 EKI-1500-CE Series User Manual
5.2.2 Manual Mapping
VCOM PC Port
EKI Physical
Serial Port
1. On your desktop, navigate to Start > All Programs > EKI Device Configura-
tion Utility and click Advantech EKI Device Configuration Utility to open the
utility.
2. Under Serial Device Servers, locate your server and click the icon to expand
the listing.
3. Select the target device and right-click on it to open up the options menu win-
dow.
4. Locate Manual Mapping and select it.
Figure 5.5 Selecting Manual Mapping
The Manual Mapping Virtual COM Port window displays.
5. In the Device > Serial Port drop-down menu, select the target port to map.
This is the physical serial port on the EKI-1500-CE Series device.
6. In the Host > COM Port drop-down menu, select the target COM port to map.
This is the virtual port on the target PC.
Figure 5.6 Viewing Manual VCOM Mapping Results
EKI-1500-CE Series User Manual 46
7. Click Map it to continue the process. The mapping process may require a short
time. Once this step is completed, the Manual Mapping Virtual COM Port window displays again to map the VCOM port on the target PC.
Once the mapping function is initialized, a successful mapping process results
in the virtual mapping of the designated physical serial port and VCOM PC port.
See the following figure.
Figure 5.7 Viewing Manual VCOM Mapping Results
To allow for an automatic connection after a reboot or a power up, click the Auto
Reconnect option to enable this function.
5.2.3 Configuration Wizard
1. On your desktop, navigate to Start > All Programs > EKI Device Configura-
tion Utility and click Advantech EKI Device Configuration Utility to open the
utility.
2. Under Serial Device Servers, locate your server and click the icon to expand
the listing.
3. From the tool bar, select Configuration Wizard.
Figure 5.8 Selecting the Configuration Wizard
The Wizard screen displays and lists available devices.
4. Select the target device and click Next to continue.
The Wizard Device Settings window displays.
5. Under Serial Port Settings, click the Type drop-down menu and select the port
type.
Review the settings under the Ethernet fields and verify them.
6. Click Next to continue or Previous to return to the previous screen.
The selected settings are displayed in the following Wizard window.
7. Locate the radio button correlating to the target port to modify and click on it to
select it.
Verify the Device Port (EKI-1500-CE Series device physical serial port) and
System Port (virtual COM port for PC) settings before continuing.
8. Click Finish to complete the process. A Wizard complete! screen displays indi-
cating the completion of a successful procedure.
47 EKI-1500-CE Series User Manual
5.2.4 Confirming Virtual COM Settings
1. On your desktop, navigate to Start > All Programs > EKI Device Configura-
tion Utility and click Advantech EKI Device Configuration Utility to open the
utility.
2. Locate Serial Ports menu in the menu pane and click on the Expand icon next
to Virtual COM Ports to view a list of the mapped ports.
3. Select a VCOM port to view its settings.
Figure 5.9 Serial Port Listing on EKI-1500-CE Series Device
For the next step, you will need to open the device manager on your system.
Using the Device Manager, you can both view and change the COM port settings.
Note! The following instructions were developed in a Windows 7 environment;
the Windows XP equivalent is displayed in parentheses (). Instructions
may vary according to the operating system used.
4. On your desktop, click on the Start button and then on Control Panel. A win-
dow displays showing all the available control panels.
5. Click on Hardware and Sound (Hardware). A list of all available hardware con-
figuration options displays.
6. Under Devices and Printers, click on the Device Manage r link. A new window
displays showing a list of all the available devices on your computer.
7. Locate Ports (COM & LPT) and click on the expand icon. A list of all available
serial and parallel port devices display.
EKI-1500-CE Series User Manual 48
The newly mapped VCOM port should be listed under the same mapped settings used in the previous steps.
Figure 5.10 System Port VCOM Mapping Configuration
The newly mapped VCOM port is listed under the same mapped settings used
in the previous steps. The settings correspond to the VCOM port configuration
on the EKI-1500-CE Series device, see the following figure.
Figure 5.11 Verifying VCOM Mapping Configuration
If the settings do not correspond, the VCOM mapping is not correct. See “Virtual
COM Port Mapping” on page 44 to re-map the VCOM ports.
49 EKI-1500-CE Series User Manual
5.2.5 Removing VCOM Ports
1. On your desktop, navigate to Start > All Programs > EKI Device Configura-
tion Utility and click Advantech EKI Device Configuration Utility to open the
utility.
2. Under Serial Ports, click the expand icon on Virtual COM Ports to view the con-
figured port list.
3. Locate the port to remove and right-click on it to open the options menu.
4. Scroll down to Remove This Port and click on it to initiate the procedure.
Figure 5.12 Remove VCOM Port
A Remove Port confirmation window displays.
5. Click OK to continue with the removal process or Cancel to return to the previ-
ous menu.
Once the procedure is completed, a prompt displays the successful removal of
the port from the VCOM mapping list.
EKI-1500-CE Series User Manual 50
5.2.6 Exporting and Importing VCOM Mapping
Importing and exporting Virtual COM Port Mapping is useful when the factory has
already used a number of serial device servers in VCOM mode. You can easily
upgrade to a new utility, and don’t need to re-map the Virtual COM Ports. For example, when you would like to upgrade from Utility 1.71 to Utility 3.0, you can export
your own mapped Virtual COM Ports in Utility 1.71 and save them as a *.cpm file.
After upgrading to Utility 3.0, import your *.cpm file and restore your own V irtual COM
Ports.
Note! This Virtual COM Port Mapping tool can only recover Virtual COM Ports
that have been mapped previously. For newly installed serial device
servers, please follow the virtual COM Port mapping steps.
1. On your desktop, navigate to Start > All Programs > EKI Device Configura-
tion Utility and click Advantech EKI Device Configuration Utility to open the
utility.
2. Locate Serial Ports menu in the menu pane and click on the Expand icon next
to Virtual COM Ports to view a list of the mapped ports.
3. Select a VCOM port.
4. Click Import V irtual COM Port Mapping or Export Virtual COM Port Mapping
in the File menu.
5.3 Running a Diagnostic Test
The loopback test allows you to determine if the EKI-1500-CE Series device server is
configured correctly to identify any failed nodes in the network. The test allows you to
send a signal from the server and return (looped back) it back to the server.
1. Connect the loopack connector to a COM port on the EKI-1500-CE Series
device server.
2. On your desktop, navigate to Start > All Programs > EKI Device Configura-
tion Utility and click Advantech EKI Device Configuration Utility to open the
utility.
3. Under Serial Ports, click the expand icon on Virtual COM Ports to view the con-
figured port list.
4. Open the ICOMToolsPlus utility to open the EKI-1500-CE Series device server
settings.
5. Set the COM port configuration to match the Port Configuration.
6. Click the Start menu.
A successful loopback test incrementally displays the Bytes/sec values on both displayed menus.
51 EKI-1500-CE Series User Manual
Chapter 6
6Web Interface
6.1 Overview
EKI-1500-CE Series serial device server can be configured through a web interface.
By using a standard web browser, the same procedure as with the Windows configuration utility can be used. In the browser’s address field, enter the IP Address of your
EKI-1500-CE Series serial device server. The default IP setting is 10.0.0.1, but you
should use the IP which you have previously assigned for this device. Once the IP is
entered, you will be presented with the following windows.
Note! Before using the web-based configuration, make sure your host PC
Ethernet network IP domain is as same as the serial device server, or it
can establish the TCP connection with the serial device server.
Note! It is recommended that you use Microsoft Internet Explorer 7.0 or
higher.
6.2 Accessing the Web Page
6.2.1 Accessing the Web Page via Configuration Utility
To access the web page via configuration utility:
1. Select Ethernet under the desired device.
2. Click Launch Browser.
Figure 6.1 Accessing the Web Page via Configuration Utility
53 EKI-1500-CE Series User Manual
6.2.2 Accessing the Web Page via Web Browser
Once the device is installed and connected, power on the device. The following information guides you through the logging in process.
1. Launch your web browser on the PC.
2. In the browser’s address bar, type the device’s default IP address (Eth1:
10.0.0.1, Eth2: 10.0.0.2).
The main menu is shown.
6.3 System
You can change the Device Name and Device Description on this page. You can also
enable or disable the Telnet and SNMP functions. Moreover, you can set the Time
zone related settings.
To access this page, click System.
Figure 6.2 System
The following table describes the items in the previous figure.
Item Description
Firmware version Displays the current firmware version of the device.
Revision number Displays the revision number of the device.
Device Name Enter the device name: up to 31 alphanumeric characters.
Device Description Enter the device description.
VCOM Ignore Device ID Click Enabled or Disabled to enable or disable VCOM ignore
device ID.
Telnet Click Enabled or Disabled to set remote access through the Tel-
net Service function.
SNMP Click Enabled or Disabled to define the SNMP daemon.
Local Time Click Modify to set local date and time of the system.
EKI-1500-CE Series User Manual 54
Item Description
Time Server Enter the address of the SNTP server. This is a text string of up to
64 characters containing the encoded unicast IP address or hostname of a SNTP server. Unicast SNTP requests will be sent to this
address. If this address is a DNS hostname, then that hostname
should be resolved into an IP address each time a SNTP request
is sent to it.
Save Click Save to save the values and update the screen.
6.4 Ethernet Configuration
Choose either Eth 1 or Eth 2 in the Ethernet Configuration page.Enter the corresponding values for your network environment. Remember press Save after fill in all
values.
To access this page, click Ethernet Configuration.
Figure 6.3 Ethernet Configuration
The following table describes the items in the previous figure.
Item Description
Mode Click the drop-down menu to select the IP Address Setting mode:
Static or DHCP.
MAC Address Enter the MAC address to which packets are statically forwarded.
IP Address Enter a value to specify the IP address of the interface. The default
is 192.168.1.1.
Subnet Mask Enter a value to specify the IP subnet mask for the interface. The
default is 255.255.255.0.
Default Gateway Enter a value to specify the default gateway for the interface. The
default is 192.168.1.254.
DNS Click the radio button to select the DNS mode: Automatic or S pe-
cific.
55 EKI-1500-CE Series User Manual
Item Description
Current Status
IP 1 Displays the current IP address 1 of the device.
IP 2 Displays the current IP address 2 of the device.
Save Click Save to save the values and update the screen.
Note! All new configurations will take effect after rebooting. To reboot the
device, click Tools > Reboot.
6.5 Port Configuration
The serial port configuration menu has Basic, Operation Mode, and Advanced Settings.
6.5.1 Basic
The Basic menu allows for the configuration of the serial interface type, baud rate,
parity, data / stop bits, and flow control for port configuration.
To access this page, click Port Configuration > Basic.
Figure 6.4 Port Configuration > Basic
The following table describes the items in the previous figure.
Item Description
Type Click the drop-down menu to select a serial interface: RS-232,
RS-422 or RS-485.
Baud Rate Enter a value to specify the baud rate. The value should conform
to the current transmission speeds of connected devi ces when setting the baud rate.
Parity Click the drop-down menu to select the parity: None, Odd, Even,
Mark or Space.
Data Bits Click the drop-down menu to select the data bits: 5, 6, 7, or 8.
Stop Bits Click the drop-down menu to select the stop bits: 1, 1.5 or 2.
EKI-1500-CE Series User Manual 56
Item Description
Flow Control Click the drop-down menu to select the flow control mode: None,
Save Click Save to save the values and update the screen.
6.5.2 Operation
The Operation menu allows for the configuration of the mode type and related attributes for port configuration.
To access this page, click Port Configuration > Operation.
XOn/XOff, RTS/CTS or DTR/DSR
Figure 6.5 Port Configuration > Operation
The following table describes the items in the previous figure.
Item Description
Mode Click the drop-down menu to select the port configuration mode:
Virtual COM Mode, USDG Data Mode, USDG Control Mode or
RFC2217 Mode.
Host Idle Timeout(s) Enter a value to define the host idle timeout period.
Response Timeout(s) Enter a value to define the response timeout period.
Frame Break(ms) Enter a value to specify the frame break time.
Pack conditions (Pack sent immediately when reach 1024 Bytes)
By size Click the option to sent pack immediately by size.
By interval Click the op tio n to sent pack immediate ly by interval.
57 EKI-1500-CE Series User Manual
Item Description
By end-character Click the option to sent pack immediately by end-character.
Port Data Buffering
Media Click the drop-down menu to select port data buffering type: None
When Data Full Click the drop-down menu to select process mode when data full:
Save Click Save to save the values and update the screen.
6.5.3 Advanced
The Advanced menu allows for the configuration of the time delay, buffer data size
and FIFO size for port configuration.
To access this page, click Port Configuration > Advanced.
or RAM.
Stop.
Figure 6.6 Port Configuration > Operation
The following table describes the items in the previous figure.
Item Description
Ignore Purge Click the option to purge the serial port when the serial port opens
first time.
Disable Character Timeout Detection
Disable Multiple Connection
Enable BufferData Size Click the option to enter the value to queue data to become a
USDG Advanced Options (Flow Control will overwrite these options)
RTS Control Click the drop-down menu to select the status of RTS: ON, OFF,
DTR Control Click the drop-down menu to select the status of DTR: ON, OFF,
Save Click Save to save the values and update the screen.
Click the option to disable the serial port character timeout detection.
Click the option to disable the multi-access function. Then only one
TCP connection is allowed on this serial port.
packet.
Toggle By Connect or Toggle By Data.
Toggle By Connect or Toggle By Data.
EKI-1500-CE Series User Manual 58
6.6 Monitor
The EKI-1500-CE Series device server allows monitoring of the serial ports’ status.
The serial port’s operation mode and status is available for displa y. The IP address of
the host PC which is communicating with serial port is also displayed.
The Monitor function provides a method to monitor the serial device server’s status
(operation mode, baud rate, data bits, stop bits, parity and RTS/XON/DTR).
Monitoring information is divided into three main message types: Setting/Statistic/
Connected IP.
6.6.1 Setting
The Monitor Setting page allows for easy viewing of the port’s statistics.
To access this page, click Monitor > Setting.
Figure 6.7 Monitor > Setting
The following table describes the items in the previous figure.
Item Description
Operation Mode Display the current operation mode of the selected port.
Baud Rate Display the current baud rate of the selected port.
Data Bits Display the current data bits of the selected port.
Stop Bits Display the current stop bits of the selected port.
Parity Display the current parity of the selected port.
RTS/CTS Display the current RTS/CTS status of the selected port.
XON/XOFF Display the current XON/OFF status of the selected port.
DTR/DSR Display the current DTR/DSR status of the selected port.
59 EKI-1500-CE Series User Manual
6.6.2 Statistic
The Monitor Statistic page allows for easy viewing of the port’s TX/RX data count.
To access this page, click Monitor > Statistic.
The following table describes the items in the previous figure.
Figure 6.8 Monitor > Statistic
Item Description
Tx Count Display the current Tx count of the selected port.
Rx Count Display the current Rx count of the selected port.
Total Tx Count Display th e current total Tx count of the selected port.
Total Rx Count Display the current total Rx count of the selected port.
RTS Display the current RTS status of the selected port.
CTS Display the current CTS status of the selected port.
DTR Display the current DTR status of the selected port.
DSR Display the current DSR status of the selected port.
DCD Display the current DCD status of the selected port.
EKI-1500-CE Series User Manual 60
6.6.3 Connected IP
The Monitor Connected IP page allows for easy viewing of all connected device’s IP
address.
To access this page, click Monitor > Connected IP.
Figure 6.9 Monitor > Connected IP
The following table describes the items in the previous figure.
Item Description
Connected IP Display s the IP design atio n for th e de vice.
IP Address Displays the current connected IP address of the selected port.
61 EKI-1500-CE Series User Manual
6.7 Auto Warning (Alarm)
You can set the e-mail server and SNMP Trap server in the Setting page, and set the
event type in the Event page.
6.7.1 Setting
The Alarm Setting menu includes three alarm setting menus for event notification:
Mail Sever, SNMP Trap Server, and the SNMP Agent Setting.
At the top of the list is the Mail Server setting which allows you to specify the mail
server to be used by the serial device server in order to deliver notifications to
selected Email accounts.
The SNMP Trap Server settings allows you to specify the management station of a
significant event by way of an unsolicited SNMP message.
The Simple Network Management Protocol (SNMP) is used by the serial device
server to collect detailed information about the serial device server.
To access this page, click Alarm > Setting.
Figure 6.10 Alarm > Setting
EKI-1500-CE Series User Manual 62
The following table describes the items in the previous figure.
Item Description
Mail Server
Mail Server Enter the SMTP mail server.
From Email address Enter the email address.
Email address 1 Enter the email address 1 to receive alarm emails.
Email address 2 Enter the email address 2 to receive alarm emails.
Email address 3 Enter the email address 3 to receive alarm emails.
Email address 4 Enter the email address 4 to receive alarm emails.
SNMP Trap Server
Trap Server Enter the SNMP Trap server address.
Trap Server Port Enter the SNMP Trap server port.
Trap Version Click the radio button to select the SNMP version credentials: v1 or
v2c.
Trap Community Enter the community string to be passed for the specified event.
SNMP Agent Setting
Read Community Enter the read-only, public, community string.
Write Community Enter the write-only, private, community string.
Contact Enter the individual designated the contact point for this event.
Location Enter the designated location/department of the setting.
Save Click Save to save the values and update the screen.
63 EKI-1500-CE Series User Manual
6.7.2 Event
The Alarm Event page allows the selection of triggers for system, DCD and DSR
events for the alarm function.
To access this page, click Alarm > Event.
Figure 6.11 Alarm > Event
The following table describes the items in the previous figure.
Item Description
System Event
Cold Start Click the option to select a warning type when the device server’s
power is cut off and reconnected.
Warm S tart Click the option to select a warning type when the device server is
reboot.
Authentication failure Click the option to select a warning type when an incorrect pass-
word is entered.
IP address changed Click the option to select a warning type when the IP address is
changed.
Password changed Click the option to select a warning type when the password is
changed.
EKI-1500-CE Series User Manual 64
Item Description
Ethernet1 link down Click the option to select a warning type when the Ethernet 1 port
Ethernet2 link down Click the option to select a warning type when the Ethernet 2 port
DCD changed
Port Click the option to select a warning type of the selected port when
DSR changed
Port Click the option to select a warning type of the selected port when
Save Click Save to save the values and update the screen.
6.8 Syslogd
The EKI-1500-CE Series device server provides the functionality to allow network
devices to send event messages to a logging server, also known as a Syslog server,
by way of the Syslogd function. The Syslog protocol is supported by a wide range of
devices and can be used to log different types of events.
is disconnected.
is disconnected.
a change in the DCD (Data Carrier Detect) signal indicates that the
modem connection status has changed.
a change in the DSR (Data Set Ready) signal indicates that the
data communication equipment is powered off.
6.8.1 Syslogd Setting
Users can enable the syslogd function to record historical events or me ssages locally
or on a remote syslog server.
To access this page, click Syslogd > Syslogd Setting.
The following table describes the items in the previous figure.
Item Description
Syslogd Click Enabled or Disabled to set the logging service status.
Save Click Save to save the values and update the screen.
Figure 6.12 Syslogd > Syslogd Setting
65 EKI-1500-CE Series User Manual
6.8.2 Syslogd Message
After enabling the syslogd function, users can check the history in the syslogd message page.
To access this page, click Syslogd > Syslogd Message.
Figure 6.13 Syslogd > Syslogd Message
EKI-1500-CE Series User Manual 66
6.9 Tools
The EKI-1500-CE Series device server provides tools for access to ping and reset
functions.
6.9.1 Ping
The Ping page can help users diagnose ethernet problems. Users can use the ping
page to ask the device to ping a specific target to check the Ethernet network status.
The Ping page allows you to configure the test log page.
To access this page, click Tools > Ping.
Figure 6.14 Tools > Ping
The following table describes the items in the previous figure.
Item Description
IP Enter the IP address or host name of the station to ping. The initial
value is blank. The IP Address or host name you enter is not
retained across a power cycle. Host names are composed of
series of labels concatenated with periods. Each label must be
between 1 and 63 characters long, maximum of 64 characters.
Size Enter the size of ping packet. The default value is 56. The value
ranges from 8 to 5120. The size entered is not retained across a
power cycle.
Count Enter the number of echo requests to send. The default value is 4.
The value ranges from 1 to 5. The count entered is not retained
across a power cycle.
Run ping Display the ping reply format.
67 EKI-1500-CE Series User Manual
6.9.2 Reboot
The configuration will take effect after clicking Save button. All configurations are
saved to flash memory after a system reboot. Press the Reboot button and the system will give a reset response. It will take a few seconds to reconnect with the new
values.
To access this page, click Tools > Reboot.
Click Yes to reboot the serial device server. Any configuration changes you have
made since the last time you saved will be lost.
6.10 Management
The EKI-1500-CE Series device server allows for easy installation and maintenance
and reliable maintenance access from anywhere. With the reliable management tools
available, you can streamline staffing and troubleshooting requirements to a centralized system.
Figure 6.15 Tools > Reboot
6.10.1 Log File
If users enable the system event or serial event to log in file, users can download the
log file from here.
To access this page, click Management > Log File.
The following table describes the items in the previous figure.
Item Description
System Log File Click the drop-down menu to select a spec ific action for the system
Export Click Export to download the log file.
Figure 6.16 Management > Log File
log file. Available options: Download System Log, Remove System
Log, Download and Remove System Log.
EKI-1500-CE Series User Manual 68
6.10.2 Change Password
The Change Password function allows you to easily update your current password
from a single menu.
To access this page, click Management > Change Password.
Figure 6.17 Management > Change Password
The following table describes the items in the previous figure.
Item Description
New password Enter the character set for the define password type.
New password again Retype the password entry to confirm the profile password.
Save Click Save to save the values and update the screen.
If you have set a password through the configuration utility or Telnet or serial console,
when you access the web configuration, you need to key in the password. It is not
necessary to enter the user name in the dialog.
If you want to disable the password protection, change th e password t o default option
None (leave the new password column blank). Be sure to press the Save button and
reboot the serial device server to make the change effective.
6.10.3 Secure access IP
To access this page, click Management > Secure access IP.
Figure 6.18 Management > Secure access IP
The following table describes the items in the previous figure.
Item Description
Access IP number Enter a value to define access IP number
Save Click Save to save the values and update the screen.
6.10.4 Export Device Settings
Export the server configuration settings to a .conf file.
To access this page, click Management > Export.
Click Export to export the serial device server settings.
69 EKI-1500-CE Series User Manual
6.10.5 Import Device Settings
Import the server configuration settings to a .conf file.
To access this page, click Management > Import.
Figure 6.19 Management > Import
The following table describes the items in the previous figure.
Item Description
Choose File Click Choose File to select the configuration file.
Submit Click Submit to backup the settings.
EKI-1500-CE Series User Manual 70
Chapter 7
7Telnet/Serial Console
Configuration
7.1 Overview
The purpose of the Console Configuration is to help you manage your device in console mode. One of the main functions of the console mode is to change th e web configuration login password. You can use terminal software like Hyper Terminal, Telix
and other related terminal software.
7.2 Telnet Console
7.2.1 Create a new connection
You can create a new Telnet connection and assign a connection name for the console configuration.
Figure 7.1 Creating a Telnet Connection
EKI-1500-CE Series User Manual 72
7.2.2 Input the IP address
Confirm that the Telnet console configuration works ok. Be sure that your host PC
Ethernet network IP domain is as same as the EKI-1500-CE Series device server,
and the Telnet TCP port number is “23”.
Figure 7.2 Creating a Telnet Connection
7.2.3 Connection Success
After connecting to the serial device server in HyperTerminal console, a welcome
greeting displays.
Figure 7.3 Telnet Connection Console
At the command prompt, you can type a “help” followed by the Enter button, or <Tab>
twice, to display the command list.
You can toggle between the different command menu options.
73 EKI-1500-CE Series User Manual
7.3 Command List
Command Function Description
system Show or config ur e th e sys tem in fo r ma tio n
port Show or configure the serial ports information
portadv Show or configure the serial ports advanced settings
mvcom Show or configure the serial ports in Virtual COM mode
mctrl Show or configure the serial ports in Control mode (USDG)
mdata Show or configure the serial ports in Data mode (USDG)
net Show or configure the Ethernet ports settings
password Set or change the password
alarm Show or configure the auto warning functions including mail alarm and
SNMP alarm
monitor Monitor the ser ia l ports status
mrfc2217 Show all port modes and mode information.
apply Write settings to the flash memory and reboot the system immediately
exit Terminate the shell session
help Display command list help information
reboot Write settings and reboot the system immediately.
7.3.1 system
Usage: system
Show current device status and informations.
Usage: system name [Maximum length 31 bytes]
Set current device name.
Usage: system desc [Maximum length 127 bytes]
Set current device description.
7.3.2 port
Usage: port [nn|all]
Show port status and informations.
Usage: port [nn] desc [Maximum length 127 bytes]
Set serial port description.
Usage: port [nn|all] type [232|422|485] flow []
Set serial port type and flow control.
– flow 0:None.
– flow 1:XOn/XOff.
– flow 2:RTS/CTS.
– flow 3:DTR/DSR.
Usage: port [nn|all] baud [50-921600] parity [] data [5-8] stop [1|1.5|2]
Set serial baud rate, parity and numbers of data bits, numbers of stop bits.
Acceptable baud: 50, 75, 110, 150, 300, 600, 1200, 1800, 2400, 4800, 7200,
9600, 14400, 19200, 38400, 57600, 115200, 230400, 460800, and 921600
– parity n: None Parity.
– parity e: Even Parity.
– parity o: Odd Parity.
– parity m: Mark Parity.
EKI-1500-CE Series User Manual 74
– parity s: Space Parity.
Usage: port [nn|all] mode [vcom|ctrl|data]
Set serial port as virtual COM port or control mode or data mode.
7.3.3 portadv
$ help portadv
Show port advanced setting.
Usage: portadv [nn|all] delayT []
Set delay time(ms).
Usage: portadv [nn|all] ignorepurge [TRUE|FALSE] dischato [TRUE|FALSE] dismulticon [TRUE|FALSE]
Enable or disable the feature of ignore purge,
Disable character timeout detection, and disable multiple connection.
Usage: portadv [nn|all] databuf []
Set databuffer threshold.
Usage: portadv [nn|all] timeout [] rtl [] ttl [] fcl [] fch []
Set port timeout, and set portrtl, portttl, portfcl, portfch.
Usage: portadv [nn|all] fifosize [size|null]
Set port Writed size of FIFO, null for disable
Usage: portadv [nn|all] rts []
Set port RTS status.
– value 0: None Setting.
– value 1: Setting power on.
– value 2: Setting accept on.
– value 4: Setting transmission on.
Usage: portadv [nn|all] dtr []
Set port DTR status.
– value 0: None Setting.
– value 1: Setting power on.
– value 2: Setting accept on.
– value 4: Setting transmission on.
7.3.4 mvcom
Usage: mvcom
Show all port mode and mode informations.
Usage: mvcom [nn|all]
Set port [nn|all] as virtual COM port mode.
Usage: mvcom [nn|all] idleto []
Set host idle timeout(s).
Usage: mvcom [nn|all] respto [] framebk []
Set response timeout(ms) and frame break(ms).
Usage: mvcom [nn|all] bysize []
Usage: mvcom [nn|all] bytime []
Usage: mvcom [nn|all] bychar [NULL|]
Set datapackage as size (bytes) or time (ms) and character (HEX).
– value 0: None Setting.
75 EKI-1500-CE Series User Manual
7.3.5 mctrl
Usage: mctrl
Show port mode and mode informations.
Usage: mctrl [nn|all]
Set port [nn|all] as control mode.
Usage: mctrl [nn|all] idleto [] tcpp [] atp [] guardt [] hangchr []
Set data idle timeout(s) data listen port command listen port guard time(ms)
hangup character.
7.3.6 mdata
Usage: mdata
Show port mode and mode informations.
Usage: mdata [nn|all]
Set port [nn|all] as data mode.
Usage: mdata [nn|all] protocol [TCP|UDP]
Set transmit protocol as TCP or UDP.
Usage: mdata [nn|all] idleto [] lsport [] atport []
Set data idle timeout(s) listen port and AT command port.
Usage: mdata [nn|all] respto [] framebk []
Set response timeout(ms) and frame break(ms).
Usage: mdata [nn|all] bysize [] bytime [] bychar [NULL|] bychartimeout [ON|OFF]
Set datapackage as size (bytes) or time (ms) or character (HEX) and charactertimeout.
– value 0: None Setting.
Usage: mdata [nn|all] autopeerip [ON|OFF]
Set auto connect to peer ip as on or off.
Usage: mdata [nn|all] peernum [1-16] peer [d.d.d.d:d] ...
Set peer IP address and port for receive data.
7.3.7 net
Usage: net [1|2]
Usage: net [1|2] mode [static|dhcp|bootp|all]
Usage: net [1|2] ip [d.d.d.d] netmask [d.d.d.d] gw [d.d.d.d]
Usage: net [1|2] dns [auto|specific]
Usage: net [1|2] dns1 [d.d.d.d]
Usage: net [1|2] dns2 [d.d.d.d]
Usage: net [1|2] to [d]
Show device network status and informations.
Set network operating mode.
Set IP address and subnet mask and gateway.
Enable/Disable DNS.
Set network DNS1.
Set network DNS2.
Set network timeout.
EKI-1500-CE Series User Manual 76
7.3.8 password
Usage: password
Display two different Usage.
Usage: password new [1-31 characters]
Set new password.
Usage: password old [**...] new [1-31 characters]
Confirm the old password and set new password.
7.3.9 alarm
Usage: alarm
Show current alarm informations.
Usage: alarm mail server [null|address] from [null|address] to1 [null|address] to2
[null|address] to3 [null|address] to4 [null|address]
Set current mail server configuration.
Usage: alarm trap server [null|address] ver [1|2] community [null|name]
Set current trap server configuration.
Usage: alarm agent rcommunity [null|name] wcommunity [null|name] contact
[null|name] location [null|name]
Set current snmp agent configuration.
Usage: alarm event mail [cstart] [wstart] [auth] [ip] [passwd] [eth1] [eth2]
Set current mail event configuration.
Usage: alarm event trap [cstart] [wstart] [auth] [eth1] [eth2]
Set current trap event configuration.
Usage: alarm port [1|2|..] dcd [none|mail|trap|all] dsr [none|mail|trap|all]
Set current port alarm configuration.
7.3.10 monitor
Usage: monitor port [1|2|..] setting
Monitor COM port setting.
Usage: monitor port [1|2|..] statistic
Monitor COM port statistic data.
Usage: monitor port [1|2|..] ip
Monitor connected IP.
7.3.11 time
Usage: time
Show current time informations.
Usage: time [YYYYMMDDhhmmss]
Set current time configuration.
Usage: time ntp [timeserver]
Set current time server configuration.
77 EKI-1500-CE Series User Manual
7.3.12 service
Usage: service telnet [enable|disable]
Enable/Disable telnet function.
Usage: service snmp [enable|disable]
Enable/Disable SNMP function.
7.3.13 mrfc2217
Usage: mrfc2217
Show all port mode and mode informations.
Usage: mrfc2217 [nn|all]
Set port [nn|all] as RFC2217 mode.
Usage: mrfc2217 [nn|all] idleto [] lsport []
Set host idle timeout(s) and listen port.
7.3.14 apply
Usage: apply
Save the settings to flash and reboot right now.
7.3.15 exit
Usage: exit
Terminate shell session.
7.3.16 help
Usage: help [cmd]
Display help information of command cmd.
7.3.17 reboot
Usage: reboot
Write settings and reboot the system immediately.
EKI-1500-CE Series User Manual 78
Chapter 8
8TCP and UDP Port
Numbers
8.1 List of Known TCP and UDP Port Numbers
Port Protocol Service
5048 (TCP/UDP) Configuration Utility
5058 (TCP/UDP) Configuration Utility
5202 (TDP) VCOM/RVCOM
9999 (TDP) Firmware Download
22 (TDP) SSH
23 (TDP) Telnet
25 (TDP) SMTP (Mail Client)
53 (TCP/UDP) DNS
67 (UDP) BOOTP Server/DHCP
68 (UDP) BOOTP Client/DHCP
80 (TDP) Web Interface/HTTP
123 (TDP) NTP
161 (TDP) SNMP
162 (TCP/UDP) SNMP Trap
443 (TDP) HTTPS
502 (TDP) Modbus/TCP (Default)
514 (TDP) Syslog
546 (TCP/UDP) DHCPv6 Client
547 (TCP/UDP) DHCPv6 Server
EKI-1500-CE Series User Manual 80
