Advanced SC1997/00 User Manual
4222_100_4211_1_FrontCover_A5_fc.pdf 1 6/18/15 12:09 PM
Lumea
SC1997
6
10
9
2a 3
5
4
5
14
15
4
2b
8
7
12
11
1
13
English 5
繁體中文 19
Czech 32
Polski 47
Romna 63
Slovenščina 79
Welcome
Welcome to the beauty world of Lumea! You are only a few weeks away
from silky-smooth skin.
Philips Lumea uses Intense Pulsed Light (IPL) technology, known as one of
the most effective methods to continuously prevent hair regrowth. In close
cooperation with licensed dermatologists we adapted this light-based
technology, originally used in professional beauty salons, for easy and
effective use in the safety of your home. Philips Lumea is gentle and offers
convenient and effective treatment at a light intensity that you find
comfortable. Unwanted hairs are finally a thing of the past. Enjoy the feeling
of being hair-free and look and feel amazing every day.
To fully benefit from the support that Philips offers, register your product at
www.philips.com/welcome. For further information, please go to
www.philips.com/lumea to find our experts' advice, tutorial videos and
FAQs and make the most of your Lumea.
Device overview
1 Light exit window with integrated UV filter
2 Attachments
a Body attachment
b Precision attachment
3 Reflector inside the attachment
4 Integrated safety system
5 Skin tone sensor
6 Electronic contacts
7 Flash button
8 Opening for electronic contacts
9 On/off button
10 Intensity lights (1-5)
11 'Ready to flash' light
12 Air vents
13 Device socket
14 Adapter
15 Small plug
English
5
Who should not use Lumea? Contraindications
-
Never use the device if you have skin type V and VI (You rarely to never
sunburn, very dark tanning). In this case you run a high risk of developing
skin reactions, such as hyperpigmentation and hypopigmentation, strong
redness or burns.
-
Never use the device if you are pregnant or breast feeding as the device
was not tested on pregnant or breast feeding women.
-
Never use the device if you suffer from any of the diseases listed below:
English
6
English
-
If you have a skin disease such as active skin cancer, you have a
history of skin cancer or any other localized cancer in the areas to be
treated.
-
If you have pre-cancerous lesions or multiple atypical moles in the
areas to be treated.
-
If you have a history of collagen disorder, including a history of keloid
scar formation or a history of poor wound healing.
-
If you have a history of vascular disorder, such as the presence of
varicose veins or vascular ectasia in the areas to be treated.
-
If your skin is sensitive to light and easily develops a rash or an allergic
reaction.
-
If you have infections, eczema, burns, inflammation of hair follicles,
open lacerations, abrasions, herpes simplex, wounds or lesions and
haematomas in the areas to be treated.
-
If you have had surgery in the areas to be treatedin the last three
weeks.
-
If you have epilepsy with flashlight sensitivity.
-
If you have diabetes, lupus erythematodes, porphyria or congestive
heart disease.
-
If you have any bleeding disorder.
-
If you have a history of immunosuppressive disease (including HIV
infection or AIDS)
-
Never use the device if you take any of the medications listed below:
-
If your skin is currently being treated with or has recently been treated
in the past week with Alpha-Hydroxy Acids (AHAs), Beta-Hydroxy
Acids (BHAs), topical isotretinoin and azelaic acid.
-
If you have taken any form of isotretinoin Accutane or Roaccutane in
the last six months. This treatment can make skin more susceptible to
tears, wounds and irritations.
-
If you are on painkillers which reduce the skin's sensitivity to heat.
-
If you are taking photosensitising agents or medications, check the
package insert of your medicine and never use the device if it is stated
that it can cause photo-allergic reactions, photo-toxic reactions or if
you have to avoid sun when taking this medicine.
-
If you take anticoagulation medications, including heavy use of
aspirin, in a manner which does not allow for a minimum 1-week
washout period prior to each treatment.
-
If you take immunosuppressive medications.
-
Never use the device on the following areas:
-
Around the eyes and near the eyebrows.
-
On nipples, areolas, labia minora, vagina, anus and the inside of the
nostrils and ears.
-
Men must not use it on the scrotum and face.
-
Over or near anything artificial like silicone implants, pacemakers,
subcutaneous injection ports (insulin dispenser) or piercings.
-
On moles, freckles, large veins, darker pigmented areas, scars, skin
anomalies without consulting your doctor. This can result in a burn
and a change in skincolor, which makes it potentially harder to
identify skin-related diseases.
Important
Danger
Warning
English
-
On warts, tattoos or permanent make-up. This can result in a burn and
a change in skin color.
-
On areas, where you use long-lasting deodorants. This can result in
skin reactions.
-
Never use the device on sunburned, recently tanned or fake-tanned skin.
Note: This list is not exhaustive. If you are not sure whether you can use
the device, we advise you to consult a doctor.
-
Keep the device and the adapter dry.
-
If the device is broken, do not touch any inner part to avoid electric
shock.
-
Never insert any objects into the device.
-
This device is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, unless they have been
given supervision or instruction concerning use of the device by a person
responsible for their safety.
-
Children should be supervised to ensure that they do not play with the
device.
-
The device is not intended for children under the age of 15 years.
Teenagers aged between 15 and 18 years can use the device with the
consent and/or assistance of their parents or the persons who have
parental authority over them.Adults of 18 years and older can use the
device freely.
-
Always check the device before you use it. Do not use the device or
adapter if it is damaged. Always replace a damaged part with one of the
original type.
-
The adapter contains a transformer. Do not cut off the adapter to replace
it with another plug, as this causes a hazardous situation.
-
Do not use the device if the UV filter of the light exit window is broken.
-
Do not use the precision attachment if its filter is broken.
7
8
English
Caution
-
This device is not washable. Never immerse the device in water and do
not rinse it under the tap.
-
For hygienic reasons, the device should only be used by one person.
-
Use the device only at settings suitable for your skin type. Use at higher
settings than those recommended can increase the risk of skin reactions
and side effects.
-
Only use the device for its intended purpose as shown in the user
manual.
-
Never use compressed air, scouring pads, abrasive cleaning agents or
aggressive liquids such as petrol or acetone to clean the device.
-
Always return the device to a service centre authorised by Philips for
examination or repair. Repair by unqualified people could cause an
extremelyhazardous situation for the user.
Electromagnetic fields (EMF)
This Philips device complies with all applicable standards and regulations
regarding exposure to electromagnetic fields.
How IPL works
With IPL technology, gentle pulses of light are applied to the skin and
absorbed by the hairroot. The darker the hair, the better the pulses of light
are absorbed.
The pulses of light stimulate the hair follicle to go into a resting phase. As a
consequence, the hair sheds naturally and hair regrowth is prevented,
leaving your skin continuously silky-smooth.
The cycle of hair growth consists of different phases. IPL technology is only
effective when the hair is in its growing phase.Not all hairs are in the
growing phase at the same time. This is why we recommend an 8-week
treatment schedule followed by touch-ups to make sure all hairs are
effectively treated in the growing phase.
Note: Treatment with Lumea is not effective if you have light blond, blond
as light hairs do not absorb enough light. Below you can see the hair colors
for which Lumea is suitable and effective.
Suitable body hair colors
What to expect
Immediately after the 1st treatment
Afterthe first treatment, it can take 1 to 2 weeks for the hairs to fall out. In the
first weeks following the initial treatments, you still see some hairs
growing.These are likely to be hairs that were not in their growing phase
during the first treatments.
After 2-3 treatments
After 2-3 treatments, you should see a noticeable reduction in hair growth.
However, to effectively treat all hairs, it is important to keep on treating
according to the recommended treatment schedule.
After 4-5 treatments
After 4-5 treatments, you should see a significant reduction of hair growth in
the areas that you treated with Lumea. A reduction of hair density should be
visible as well. Keep on treating with frequent touch-ups (every 4-8
weeks)to maintain the result.
English
9
Tanning advice
Tanning with natural or artificial sunlight
Intentionally exposing your skin to natural or artificial sunlight with the aim
of developing a tan influences the sensitivity and color of your skin.
Therefore the following is important
-
After each treatment, wait at least 48 hours before tanning. Even after 48
hours, make sure that the treated skin does not show any redness from
the treatment anymore.
-
In case of exposing your skin to the sun (without tanning intentionally) in
the 48 hours after treatment, use a sunblock SPF 50+ on the treated
areas. After this period, you can use a sunblock SPF 30+ for two weeks.
-
After tanning, wait at least 2 weeks before you use Lumea. Perform a skin
test to determine the appropriate light intensity setting.
-
Do not use Lumea on sunburned body areas.
Note: Occasional and indirect sun exposure does not qualify as tanning.
10
English
Tanning with creams
If you have used an artificial tanning lotion, wait until the artificial tan has
disappeared completely before you use the device.
Before you use your Lumea
Pretreating your skin
Before you use Lumea, you should pretreat your skinby removing hairs on
the surface of your skin. This allows the light to beabsorbed by the hair
parts below the skin surface to ensure effective treatment. You can either
shave, short-trim, epilate or wax. Do not use depilatory creams, as
chemicals may cause skin reactions.
If you chose to wax, please wait 24 hours before using Lumea to let your
skin rest.We recommend that you take a shower before the treatment to
ensure that all possible residue of wax has been removed from your skin.
1 Pretreat the areas you intend to treat with Lumea.
2 Clean your skin and make sure it is hair-free, entirely dry and free from
oily substances.
Note: Once the hairs stop growing back, which usually happens after
4-5 treatments, you no longer have to pretreat your skin before you use
the device.
Skin test
When you use Lumea for the first time or after recent tanning, perform a skin
test on each area to be treated. The skin test is necessary to check your
skin's reaction to the treatment and to determine the correct light intensity
setting for each bodyarea.
1 Choose an area close to the area you intend to treat.
2 Turn on the device. Make sure you select setting 1.
3 Put the device against your skin and press the flash button to release a
flash.
4 Slide the device over the skin to the next area to be treated.
5 Increase the setting by one level, apply a flash and slide the device to the
next area. Repeat this for all levels within the recommended range for
your skin type.
6 After the skin test, wait 24 hours and check your skin for any reaction. If
your skin shows reactions, choose the highest setting that did not result
in any skin reaction for subsequent use.
Using your Philips Lumea
Skin tone sensor
For extra safety the integrated skin tone sensor measures the skin tone at
the beginning of each session and occasionally during the session. If it
detects a skin tone that is too dark for treatment with Lumea, the device
automatically disables to prevent you from developing skin reactions. This
means that it does not emit pulses when you press the flash button.
Attachments
Placing and removing
To place the attachment, simply snap it onto the light exit window.
To remove the attachment, pull it off the light exit window.
English
11
Body attachment
You can use the body attachment to treat unwanted hair on several body
areas below the neckline. You can use it for example forfast treatment of
larger areas like legs.
Precision attachment
The precision attachment includes an additional integrated light filter for
extra safetyand you can therefore use it to treat unwanted facial hair on the
upper lip, chin and sideburns. You can also use the precision attachment to
easily treat hard to reach areas such as toes, bikini area or armpits.
However, do not treat your eyebrows with Lumea.
Selecting the right light intensity
Lumea provides 5 different light intensities. Depending on your skin type
and light intensity level you find comfortable, you can select the right light
intensity setting.
1 Consult the table below to select the right setting.
12
English
Skin type
2 To adjust the light intensity setting,press the on/off button one or more
times until you have reached the required setting. The corresponding
intensity light lights up white.
Note: Thedevice automatically disables when your skin tone is too
dark, to prevent you from developing skin reactions. The integrated skin
tone sensor does not tell you which light intensity setting to use, as
Philips Lumea gives you the freedom to select the light intensity that
you find most convenient.
3 Lumea should never be painful. If you experience discomfort, reduce the
light intensity setting.
4 After recent tanning, perform a skin test to determine the right light
intensity setting.
Skin tone Light intensity setting
I White; You always sunburn,
never tan.
II Beige; You easily sunburn, tan
minimally.
III Light brown; You sunburn easily,
tan slowlyto light brown.
IV Mid brown; You rarely sunburn,
tan easily.
V Dark brown; You rarely sunburn,
tan very easily.
VI Brownish black or darker; You
rarelyor never sunburn, very
dark tanning.
Note:Your skin may react differently on different days/occasions for a
number of reasons.
Handling the device
1 Before use, clean the attachments and the light exit window.
2 Put the small plug in the device and put the adapter in the wall socket.
3 Switch on the device and select the right light intensity for your skin tone.
4/5
4/5
4/5
3/4
You cannot use the device
You cannot use the device
90º
English
4 Place the device at a 90° angle on the skin so that the attachment and
the integrated safety system are in contact with your skin
The integrated safety system prevents unintentional flashingwithout skin
contact.
5 Press the devicefirmly onto your skin to ensureproper skin contact. The
device then automatically performs a skin tone analysis and the ‘ready to
flash light’ lights up white to indicate that you can proceed with the
treatment.
Note: When the ‘ready to flash’ light lights up orange, your skin is not
suitable for treatment. In this case, the device automatically disables.
You can try to use the device on other areas with a lighter skin tone.
TIP: If you use Lumea on your bikini area and want to leave some hair in
place, make sure that the skin tone sensor is not placed on the
remaining hair during the treatment, as this can cause the device to
block
6 Press the flash button to release a flash.You should feel a warm
sensation because of the flash.
Note: The light produced by the device is harmless to your eyes. It is not
necessary to wear goggles during use. Use the device in a well-lit
roomso that the light is less glaring to your eyes.
7 Place the device on the next area to be treated. After each flash, it takes
up to 3.5 seconds until the device is ready to flash again. You can release
a flash when the 'ready to flash' light lights up again.
13
8 To make sure that you have treated all areas, release the flashes close to
each other. Effective light only comes out of the light exit window,
therefore there should be some overlap.However, make sure you flash
the same area only once. Flashing the same area twice doesn't improve
the effectiveness of the treatment, but increases the risk of skin reactions.
9 When you have finished the treatment, press and hold the on/off button
for 2 seconds to switch off the device.
Two treatment modes: Stamp & Flash and Slide & Flash
YourPhilips Lumea has two treatment modes for more convenient use on
different body areas:
-
The Stamp & Flash mode is ideal to treat small orcurvy areas like knees
and underarms. Simply press and releasethe flash button to release a
single flash.
-
The Slide & Flash mode offers convenient use on larger areas like legs.
Keep the flash button pressed while you slide the device over your
skinto release several flashes in a row.
14
English
Recommended treatment schedule
Initial phase
For the first 4 to 5 treatments, we advise you to use Philips Lumea once
every two weeks to ensure that all hairs are treated.
Touch-up phase
After the initial treatment phase (4-5 treatments), we recommend touch-ups
every 4 to 8 weeks,when you see hairs growing back. This is to maintain
results and enjoy smooth skin for months.The time between treatments
may vary based on your individual hair regrowth and also across different
body areas.
Recommended attachment & treatment time per area
2
1
8 min.
1 min.
1 min.
1
4 min.
1 2
1 14 min.
1
English
15
After use
Common skin reactions
Your skin may show slight redness and/or may prickle, tingle or feel warm.
This reaction is absolutely harmless and disappears quickly.
Dry skin and itching may occur due to shaving or a combination of shaving
and light treatment. You can cool the area with an ice pack or a wet face
cloth. If dryness persists, you can apply a non-scented moisturizer on the
treated area 24 hours after the treatment.
16
English
Aftercare
After use, you can safely apply lotions, creams, deodorant, moisturizer or
cosmetics to the treated areas. If you experience skin irritation or skin
redness after treatment, wait until it disappears before applying any product
to your skin. If you experience skin irritation after applying a product to your
skin, wash it off with water.
Cleaning & storage
1 After use, switch off the device, unplug it and let it cool down.
2 Remove the attachment.
3 Moisten the soft cloth supplied with the device with a few drops of water
4 Let all parts air dry thoroughly.
5 Store the device in a dust-free and dry place at a temperature between 0
and use it to clean the following parts:
-
the light exit window
-
the outside surface of the attachments
-
the reflector inside the attachments
-
the reddish filter glass inside theprecision attachment.
°C and 60 °C.
Guarantee and support
If you need information or support, please visit www.philips.com/support or read the separate
worldwide guarantee leaflet.
Recycling
-
This symbol means that this product shall not be disposed of with normal
household waste (2012/19/EU).
-
Follow your country's rules for the separate collection of electrical and
electronic products. Correct disposal helps prevent negative
consequences for the environment and human health.
Technical specifications
Rated voltage 100V-240V
Rated frequency 50Hz-60Hz
Rated input 36W
Protection against electric shock Class II
Protections rating IP 30 (EN 60529)
Operating conditions Temperature:+15 ºC to 35°C
Relative humidity: 30% to 95%
Spectrum of body attachment >530nm
Spectrum ofprecision attachment >600nm
Troubleshooting
This chapter summarizes the most common problems you could encounter
with the device. If you are unable to solve the problem with the information
below, visit www.philips.com/support for a list of frequently asked questions
or contact the Consumer Care Center in your country.
Problem Possible cause Solution
English
17
The device/adapter
becomes warm during use
When I place the device on
the skin it does not release
a flash. The ' ready to flash
light blinks orange and
then lights up orange
continuously.
The 'ready to flash light'
doesn't light up when I
place the attachment on
my skin, but the cooling fan
works.
The 'ready to flash light'
lights up white but the
device does not produce a
flash when I press the flash
button.
I cannot increase or
decrease the light intensity
settings/All intensity lights
are blinking alternately
strange smell.
This is normal. No action required.
You skin tone in the area to
be treated is too dark.
The overheat protection has
been activated.
The device needs to be reset. To reset the device, switch it off and
The device needs to be reset. To reset the device, switch it off and
The attachment or the filter
glass is dirty.
You have not removed the
hairs on the area to be
treated properly. These hairs
may get burned and can
cause the smell.
Treat other body areas with lighter skin
tones with Lumea.
When the overheat protection has been
activated, the fan still works. Do not
switch off the device, but let it cool down
for approx.15 minutes before you
continue to use it.
switch it on again.
switch it on again.
Clean the attachment carefully.The device produces a
Pretreat your skin before you use Lumea.
18
English
Problem Possible cause Solution
The skin feels more
sensitive than usual during
treatment/ I experience an
unacceptable pain
sensation when I use the
device.
The skin reaction after
treatment last longer than
usual.
The results of the
treatment are not
satisfactory.
The light intensity setting you
use is too high.
You did not remove the hairs
on the areas to be treated.
The UV filter of the light exit
window is broken.
You treated an area for which
the device is not intended.
You have used a light
intensity setting which is too
high for you.
You have used a light
intensity setting which is too
low for you.
You did not flash an area
adjacent to an area you
treated before.
The device is not effective on
your body hair color.
Check if you have selected the right light
intensity setting. If necessary, select a
lower setting.
Pretreat your skin before you use Lumea.
If the UV filter is broken, do not use the
device anymore. Contact the Consumer
Care Center in your country, your Philips
dealer or a Philips service center.
Never use the device on the following
areas: inner labia, anus, nipples, areolas,
lips,inside the nostrils and ears, around
the eyes and near the eyebrows. Men
must not use it on the face or on the
scrotum.
Select a lower intensity next
time.Seechapter 'Using your Philips
Lumea', section 'Selecting the right light
intensity'..
Select a higher setting next time.
You have to release the flashes close to
each other.
If you have light blond, blond, or red hair,
the treatment is not effective.
My body attachment does
not have an integrated
glass/filter/window.
You do not use the device as
often as recommended.
You respond more slowly to
IPL treatment.
This is normal. The body attachment does not contain a
To remove all hairs successfully, we
advice you to follow the recommended
treatment schedule. You can reduce the
time between treatments, but do not
treat more often than once every two
weeks.
Continue using the device for at least 6
months, as hair regrowth can still
decrease over the course of this period.
glass/filter/window.
歡迎
裝置概要
繁體中文
歡迎來到 Lumea 的美麗殿堂！再過幾週，您就能享有柔細光滑的肌膚。
飛利浦 Lumea 採用的脈衝光 (IPL) 技術，已知在防止毛髮重生方面具有長效而卓
越的效果。我們與皮膚科專家密切合作，引進了這個原先在專業美容沙龍中使用的
光學除毛技術，讓您在家中也能安全地運用這個簡單又有效的方法除毛。溫和實用
的飛利浦 Lumea 能以您覺得舒適的燈光強度，方便而有效地進行除毛療程。您可
以終於永遠擺脫這些惱人的多餘毛髮，享有光滑的肌膚，天天展現迷人風采。
為充分享受飛利浦為您提供的好處，請至下列位址註冊產品
：www.philips.com/welcome。如需進一步資訊，請造訪
www.philips.com/lumea，參閱專家建議、教學影片和常見問題集，發揮您
Lumea 的最大功效。
1 內建紫外線濾光片的出光口
2 配件
a 身體配件
b 精準配件
3 配件內的反射器
4 內建安全系統
5 膚色感應器
6 電子接點
7 閃光按鈕
8 電子接點開口
9 開關按鈕
10 強度指示燈 (1-5)
11 「閃光準備就緒」指示燈
12 通風口
13 裝置插孔
14 電源轉換器
15 小插頭
19
誰不適宜使用 Lumea？禁忌
-
皮膚類型為 V 和 VI 者 (極少或從未曬傷，膚色非常黝黑)，請勿使用本裝置，否
則很可能造成皮膚產生不良反應，例如色素沈澱及色素脫失、嚴重紅腫或灼熱
。
-
懷孕或哺乳者請勿使用本產品，因為裝置尚未針對懷孕或哺乳婦女進行測試。
-
如果罹患下列任何疾病，請勿使用本裝置：
-
患有皮膚病者，例如目前為皮膚癌患者、療程部位曾有皮膚癌或局部癌症病
史者。
-
療程部位有癌症初期病變或數個非典型胎塊 (痣) 者。
-
具蟹足腫體質或傷口癒合能力不良等膠原蛋白異常病史者。
-
療程部位有靜脈曲張或血管擴張症等血管疾病病史者。
-
皮膚對光敏感而易引發紅疹或過敏反應者。
繁體中文
20
繁體中文
-
療程部位有感染、濕疹、灼傷、毛囊發炎、開放性撕裂傷、擦傷、單純皰疹
、創傷或病變和血腫者。
-
療程部位在三週內曾動過手術者。
-
易對閃光敏感而誘發癲癇者。
-
患有糖尿病、紅斑性狼瘡、紫質症或充血性心臟病者。
-
患有出血病症者。
-
曾有免疫抑制病史者 (包含感染 HIV 或愛滋病)。
-
如果服用下列任何藥物，請勿使用本裝置：
-
目前或過去一週內曾以 α-氫氧基酸 (AHA)、β-氫氧基酸 (BHA)、局部異維
甲酸和壬二酸治療皮膚者。
-
過去 6 個月內曾服用任何形式的 Accutane A 酸或 Roaccutane A 酸者。此
療程會使皮膚對裂傷、創傷及刺激性物質更加敏感。
-
服用止痛藥者，因為止痛藥會降低皮膚對熱度的感知。
-
服用光敏劑或藥物者，請參見藥盒內說明，若其中表示可能產生光過敏反應
、光毒性反應或服藥後應避免照射日光等說明，請勿使用本裝置。
-
服用抗凝血藥物者，包括大量服用阿斯匹靈，其用藥程度無法在療程前至少
1 星期停用以利藥物成分排出體外者。
-
接受免疫抑制藥物治療者。
-
請勿在下列部位使用本裝置：
-
眼睛周圍和眉毛附近。
-
乳頭、乳暈、小陰唇、陰道、肛門，以及鼻孔和耳朵內側。
-
男性使用者請勿將產品用於臉部或陰囊上。
-
矽膠植入物、心律調整器、皮下注射端口 (胰島素注射器) 或身體穿環等所有
人工物質之表面及周圍。
-
痣、雀斑、大血管、膚色較深區域、疤痕、皮膚異常部位，未經醫師同意請
勿使用。在這些部位使用可能導致灼傷與膚色異變，使得潛在的皮膚相關疾
病更難察覺。
-
疣、刺青或永久化妝部位；否則可能導致灼傷與膚色異變。
-
使用長效型體香劑的部位；否則可能導致皮膚不良反應。
-
請勿在曬傷、最近曾日曬或人工日曬的皮膚上使用本裝置。
注意：本清單並未徹底列出所有情況。如果不確定自己是否適合使用本裝置，
建議您向醫生諮詢。
重要事項
危險
-
本裝置及電源轉換器請保持乾燥。
-
如果裝置損壞，請勿碰觸任何內部零件，以免發生電擊風險。
-
請勿將任何物品放入裝置中。
警示
警告
繁體中文
-
除非有負責其安全的人員在旁監督或教導裝置的使用方法，否則本裝置不適合
供下列人士 (包括小孩) 使用：身體官能或心智能力退化者。
-
請看管孩童，避免他們將本裝置當成玩具。
-
本產品不適用於 15 歲以下的孩童。15 至 18 歲的青少年可在父母或監護人同意
及/或協助下使用本裝置。18 歲以上的成人則能自由使用本裝置。
-
每次使用裝置前請務必先檢查，裝置或電源轉換器如有損壞，請勿使用。零件
如有受損，請務必以原型號更換之。
-
電源轉換器內含一個變壓器。請勿切斷電源轉換器而以其他的插頭取代，否則
會造成危險。
-
如果出光口的紫外線濾光片破損，請勿使用本裝置。
-
如果濾光片破損，請勿使用精準配件。
-
本裝置不可水洗。請勿將本裝置浸入水中或置於水龍頭下沖洗。
-
基於衛生理由，請勿與其他人共用本裝置。
-
請務必使用適合個人膚質的裝置設定。如果使用的強度設定超出建議範圍，會
提高皮膚產生不良反應及副作用的風險。
-
請僅根據本使用手冊所述的用途使用本裝置。
-
絕對不可使用壓縮空氣、鋼絲絨、磨蝕性的清潔劑或侵蝕性的液體 (例如汽油或
丙酮) 清潔本裝置。
-
請將本產品送回飛利浦授權的服務中心檢查或維修，由不合格的人員所做的維
修可能導致使用上的危險。
21
電磁波 (EMF)
IPL 的原理
本飛利浦裝置符合所有電磁波暴露的相關適用標準和法規。
利用 IPL 技術，裝置會將溫和的脈衝光照射到皮膚上，其能量會由髮根吸收。毛
髮顏色越深，對脈衝光的吸收效果就越好。
脈衝光會刺激毛囊進入休止期，使毛髮自然脫落並抑制毛髮重生，進而常保肌膚柔
細光滑。
22
繁體中文
毛髮的生長週期是由不同階段所構成，而 IPL 技術只對處於生長期的毛髮有效果。
並不是所有的毛髮都會同時處於生長期，所以我們會建議您進行 8 週的療程，並
在之後接著做一些修護療程，確保能有效處理到所有處於生長期的毛髮。
注意：毛髮顏色為淡金色或金色的人士，使用 Lumea 除毛不會有效果，因為淡色
毛髮無法吸收足夠的脈衝光。以下列出的是適合以 Lumea 有效除毛的毛髮顏色。
適合的體毛顏色
預期效果
緊接著第 1 次療程結束後
完成第一次療程後，毛髮可能要 1 到 2 週的時間才會開始脫落。初次療程結束後
的頭幾週，仍舊會有些毛髮長出來，這很可能是因為這些毛髮在初次療程期間並
不是處於生長期。
2-3 次療程結束後
4-5 次療程結束後
做過 2-3 次療程後，您應該會發現毛髮生長量開始減少。不過，為了有效處理所
有毛髮，請務必根據建議的除毛療程繼續進行。
做過 4-5 次療程後，您應該會發現 Lumea 處理過部位的毛髮生長量會大幅減少，
同時亦可看到毛髮密度顯著降低。請持續定期進行修護療程 (每 4-8 週)，以保持
除毛效果。
曬膚建議
自然日曬或人造光源曬膚
刻意讓肌膚接觸陽光或人造光源，曬黑膚色，改變皮膚的敏感度和膚色。請注意以
下重要事項
-
每次療程結束後，請等候至少 48 小時後再行曬膚。即使已超過 48 小時，亦請
先確認療程部位皮膚沒有因治療而發生任何紅腫現象。
-
治療後 48 小時內若皮膚接觸陽光 (非刻意曬膚)，請在治療部位使用 SPF 50+
的防曬產品。過了這段時間，可使用 SPF 30+ 的防曬產品，使用兩週時間。
-
曬膚後，請等候至少 2 週再使用 Lumea。請進行皮膚測試，決定合適的燈光強
度。
-
請勿在曬傷的部位使用 Lumea。
注意：間歇性和間接曬太陽不算是曬膚。
使用助曬乳霜
如果使用仿曬劑，請等仿曬劑完全褪去後再使用裝置。
使用 Lumea 之前
皮膚事前處理
使用 Lumea 之前，請先除去皮膚表面的毛髮，做好皮膚事前處理。這麼做能讓皮
膚表面下方的毛髮部分吸收到光源，確保療程的效果。您可以採用刮毛、修剪、
美體刀或蜜蠟等方式除毛。請勿使用除毛膏，因為化學物質可能會引發皮膚不良反
應。
繁體中文
23
皮膚測試
如果選擇以蜜蠟除毛，請讓肌膚稍加休息，等 24 小時後再使用 Lumea。建議您
在進行療程前先淋浴，確保皮膚不會殘留任何蜜蠟。
1 請針對要用 Lumea 除毛的部位做好事先處理。
2 先清潔肌膚，並確認其表面沒有任何毛髮、已完全乾燥，而且沒有任何油性物
質。
注意：通常做完 4 到 5 次療程，毛髮不再重生之後，使用本裝置前就不必再事
先處理皮膚。
首次使用或在曬膚後使用 Lumea 之前，請針對每個療程部位進行皮膚測試。皮膚
測試是必要的步驟，目的是要檢查皮膚對療程的反應，並決定各個身體部位適合使
用的燈光強度設定。
1 選擇靠近欲進行療程的區域。
24
繁體中文
2 打開裝置電源，確認選擇設定 1。
3 將裝置抵著皮膚，然後按下閃光按鈕，發出一次閃光。
4 將裝置沿著皮膚滑動到下一個除毛部位。
5 將設定調高一級，發出一次閃光，然後再將裝置滑動到下一個部位。根據皮膚
類型的建議範圍，針對其中的所有強度等級重複此步驟。
6 做完皮膚測試後，請等待 24 小時再檢查皮膚是否有任何反應。如果皮膚產生
反應，請選擇不會引起皮膚反應的最高設定，在後續除毛療程使用。
使用飛利浦 Lumea
膚色感應器
為了增進安全，內建的膚色感應器會在每次療程開始時測量膚色，並在療程進行期
間偶爾測量膚色。如果偵測到膚色太黝黑而無法使用 Lumea 治療，裝置會自動停
用，以防發生皮膚反應。這表示按下閃光按鈕時，不會發射脈衝光。
配件
安裝與移除
若要安裝配件，只要將它卡進出光口即可。
若要拆下配件，只要將它從出光口拔出即可。
身體配件
您可以使用身體配件去除頸部以下多個部位的多餘體毛。比如說，您可以用它來
快速去除大範圍的毛髮，像是腿部。
精準配件
精準配件包括額外的內建濾光片，使用起來更加安全，因此可以用來處理上唇、
下巴和鬢角的多餘毛髮。也可使用精準配件輕易處理難以到達的部位，例如腳趾、
比基尼線或腋窩。
但是，請勿將 Lumea 使用於眉毛。
選擇合適的燈光強度
Lumea 共有 5 種不同的燈光強度。您可以根據自己的膚質以及您覺得舒服的燈光
強度等級，選擇合適的燈光強度設定。
1 請參閱下表，選擇合適的設定。
2 要調整燈光強度設定，按下開關按鈕一或多次，直到達到欲使用的設定為止。
3 Lumea 使用起來絕不會痛，如果感到不適，請降低燈光強度設定。
4 曬膚後，請進行皮膚測試，決定合適的燈光強度。
繁體中文
對應的強度指示燈會亮起白光。
注意：膚色太黝黑時，裝置會自動停用，防止發生皮膚反應。內建的膚色感應
器不會告知您應使用哪種燈光強度設定，因為飛利浦 Lumea 讓您自由選擇最
方便的燈光強度。
25
皮膚類型
I 白色；極易曬傷、無曬膚。 4/5
II 黃色；易曬傷、小幅曬膚。 4/5
III 淺褐色；易曬傷、膚色會慢慢曬至
IV 褐色；極少曬傷、曬膚狀況理想。 3/4
V 深褐色；極少曬傷、曬膚狀況相當
VI 深棕色或更深色；幾乎不會曬傷，
注意：您的皮膚可能會在不同日子/場合產生不同反應，原因不一。
膚色 燈光強度設定
淺褐色。
理想。
膚色非常黝黑。
處理裝置
1 使用前，請清潔配件和出光口。
2 將小插頭插入裝置中，再將電源轉換器接到牆壁的插座。
3 開啟裝置電源，並根據您的膚色選取正確的燈光強度。
4/5
您不能使用本裝置
您不能使用本裝置
90º
26
繁體中文
4 將裝置以 90° 放置於皮膚上，使配件與內建安全系統觸碰到皮膚
內建安全系統可避免在未接觸皮膚時意外發出閃光。
5 將裝置緊壓著皮膚，確保與皮膚適當地接觸。裝置接著會自動進行膚色分析，
且「閃光準備就緒」指示燈會亮白光，表示您可進行治療。
注意：如果「閃光準備就緒」指示燈亮橘光，表示您的皮膚不適合治療。此時
，裝置會自動停用。您可嘗試在膚色較淺的其他部位使用裝置。
提示：如果您將 Lumea 用於比基尼線，且希望保留部分毛髮，請確認治療期
間未將膚色感應器放在剩餘的毛髮上，以免裝置堵住
6 按下閃光按鈕，產品會發出一次閃光。您應該會感受到閃光產生的溫熱感。
注意：裝置產生的脈衝光對眼睛無害，因此使用時不需要戴護目鏡。請在照明
充足的房間中使用裝置，降低閃光對眼睛造成的眩光感。
7 將裝置放在下一個治療部位。每次閃光後，裝置大約要過 3.5 秒後才能再發出
閃光。只要「閃光準備就緒」指示燈亮燈，就可以再次發出閃光。
建議的療程時間表
8 為了確保能處理到所有部位，請盡量緊鄰著之前治療的部位發射閃光。有效燈
光只會從出光口發出，因此照射時應該略微重疊。然而請確定相同部位僅照射
閃光一次。對著同一區域照射兩次閃光並不能提高療程效果，反而會增加皮膚
產生不良反應的風險。
9 完成治療後，按住開關按鈕 2 秒鐘，以關閉裝置電源。
兩種療程模式：「按壓與閃光」跟「滑動與閃光」
飛利浦Lumea 有兩種療程模式，方便您在不同的身體部位上使用：
-
「按壓與閃光」模式適合使用於小範圍或彎曲的部位，例如膝蓋和腋下。只要
按下並放開閃光按鈕，即可發出一次閃光。
-
「滑動與閃光」模式則方便使用於例如腿部等大範圍區域。一邊按住閃光按鈕
一邊將裝置沿著皮膚滑動，即可連續發出多次閃光。
繁體中文
27
初期
對於頭 4 到 5 次療程，建議您每兩週使用一次飛利浦 Lumea，確保所有毛髮都能
處理到。
修護期
初期療程 (4-5 次療程) 結束後，如果看到毛髮再次長出，建議您每 4 到 8 週進行
一次修護。這樣可以有效維持除毛效果，享有數個月的光滑肌膚。療程的間隔時
間，要視您個人毛髮生長速度而定，身體各部位的情況也會有所不同。
2
1
8 min.
1 min.
1 min.
1
4 min.
1 2
1 14 min.
1
28
繁體中文
各部位的建議配件和療程時間
使用完畢
常見的皮膚反應
皮膚可能會有輕微紅腫和/或刺痛感或溫熱感。這些反應完全無害，很快就會消失
。
刮除毛髮再加上脈衝光療程，可能會讓皮膚變得乾燥發癢。您可以冰敷止癢，或加
強保溼。如果皮膚依然乾澀，可以在療程結束 24 小時後，於療程部位塗抹無香料
的保溼產品。
使用後保養
清潔與收納
繁體中文
使用後，您可以安心地在療程部位塗抹乳液、乳霜、體香劑、保溼產品或化妝品。
如果療程結束後皮膚有刺痛感或紅腫現象，請等這些狀況消失後，再在皮膚上塗抹
任何產品。如果塗抹產品後皮膚有刺痛感，請用清水沖洗掉。
1 使用完畢請關閉裝置電源、拔除插頭，並讓裝置冷卻。
2 取下配件。
3 將裝置隨附的清潔布以少許清水沾濕，然後用來清潔下列零件：
-
出光口
-
配件外部表面
-
配件內的反射器
-
精準配件內的紅色濾光鏡。
4 請徹底風乾所有零件。
5 請將裝置存放在溫度介於 0°C 至 60°C、無灰塵的乾燥處。
29
保固與支援
如需資訊或支援，請造訪：www.philips.com/support，或另行參閱全球保證書
。
回收
-
此符號表示本產品不得與一般家用廢棄物一併丟棄 (2012/19/EU)。
-
請按照您所在國家/地區的規定，分類與回收電子電器產品。正確處理廢棄物有
助避免對環境和人類健康的負面影響。
技術規格
額定電壓 100V-240V
額定頻率 50Hz-60Hz
額定輸入電壓 36W
Loading...
