ADTRAN Express 3110, Express 3010 User Manual

Express 3010/3110

128 kbps ISDN Modem

Document Number 61200239L1-20A

Part Numbers:
1200239L1 (U-Interface)
1200240L1 (S/T Interface)

Jul y 199 9

Trademarks:

Expert ISDN is a trademark of ADTRAN, Inc. (patent number 5,715,241)
Express 3010 and Express 3110 are trademarks of ADTRAN, Inc.
Macintosh is a registered trademark of Apple Computer, Incorporated.
Windows is a registered trademark and Windows NT is a trademark of
Microsoft Corporation.
HyperTerminal is a registered trademark of Hilgraeve, Inc.
Hayes is a registered trademark of Hays Microcomputer Products, Inc.
5ESS is a registered trademark of LUCENT.
DMS-100 is a trade ma rk of Northern Telecom.
The Express 3010 and 3110 incorporate Synchronous Data Compression
based on either IBM or hi/fn proprie tary in tellec tual property depending on
the time of manufacture. The following trademarks and copyrights are appli­cable:

Stacker LZS Compression
Copyright (c) 1989 Carnegie Mellon University.
All rights reserved.

Redistribution and use in source and binary forms are permitted provided
that the above copyright notice and this paragraph are duplicated in all such
forms and that any documentation, advertising materials, and other materi­als related to such distribution and use acknowledge that the software was
developed by Carnegie Mellon University. The name of the University may
not be used to endorse or promote products derived from this software with­out specific prior written permission. This software is provided "as is" and
without any expres s or implied w arranties, including, without limit ation , the
implied warranties of merchantability and fitness for a particular purpose.

hi/fn Electronics
5993 Avenida Encinas
Carlsbad, CA

901 Explorer Boulevard

P. O. Box 140000

Huntsville, AL 35814- 4000

[phone]
1999 ADTRAN, Inc.
All Rights Reserved

Printed in U.S.A.

FCC regulations require that the following information be pro­vided in this manual:

1. This equipment complies with Part 68 of the FCC rules.
On the bottom of the equipment housing is a label that
shows the FCC registration number and Ringer Equiva­lence Number (REN) for this equipment. If requested, pro­vide this information to the telephone company.

2. If this equipment causes harm to the telephone network,
the telephone company may temporarily discontinue ser­vice. If possible, advance notification is given; otherwise,
notification is given as soon as possible. The telephone
company will advise the customer of the right to file a
complaint with the FCC.

3. The telephone company may make changes in its facilities,
equipment, operations, or procedures that could affect the
proper operation of this equipment; advance notification
and the opportunity to maintain uninterrupted service is
given.

4. If experiencing difficulty with this equipment, please con­tact ADTRAN for repair and warranty information. The
telephone company may require this equipment to be dis­connected from the network until the problem is corrected
or it is certain the equipment is not malfunctioning.

5. This unit contains no user serviceable parts.

6. An FCC compliant telephone cord with a modular plug is
provided with this equipment. In addition, an FCC com­pliant cable appropriate for the dial backup option ordered
is provided with this equipment. This equipment is
designed to be connected to the telephone network or pre­mises wiring using an FCC compatible modular jack,
which is Part 68 compliant.

7. The following information may be required when apply­ing to the local telephone company for leased line facilities.

Service
Type

ISDN 021S5 6.0F RJ-49C

Digital Facility
Interface Code

Service Order
Code

Network
Jacks

iii

FEDERAL COMMUNICATIONS COMMISSION RADIO FRE-

QUENCY INTERFERENCE STATEMENT:

This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commer­cial environment. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference to radio
or TV reception. The user is encouraged to try to correct the interfer­ence by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for
help.

Change or modifications to this unit not expressly ap­proved by ADTRAN will void the user’s authority to
operate the equipment.

iv

ADTRAN YEAR 2000 (Y2K)

READINESS DISCLOSURE

ADTRAN has established a Year 2000 program to ensure that our
products and operations will correctly function in the new millen­nium. ADTRAN warrants that all products meet Year 2000 specifica­tions regardless of model or revision. Information about ADTRAN’s
Year 2000 compliance program is available at the following:

Web Site www.a dtran.com
Product Matrix www.adtran.com/Y2Kfax.html
Faxback Document Line [phone]

Y2K plans and product certifications
are listed in the matrix

Y2K Project Line [phone]
E-mail year [e-mail]

v

CANADIAN EMISSIONS REQUIREMENTS

This digital apparatus does not exceed the Class A limits for radio
noise emissions from digital apparatus as set out in the interference­causing equipment standard entitled "Digital Apparatus," ICES-003 of
the Department of Communications.

Cet appareil nuerique respecte les limites de bruits radioelectriques
applicables aux appareils numeriques de Class A prescrites dans la
norme sur le materiel brouilleur: "Appareils Numeriques," NMB-003
edictee par le ministre des Communications.

CANADIAN EQUIPMENT LIMITATIONS

Notice: The Canadian Industry and Science Canada label identifies
certified equipment. This certification means that the equi pment
meets certain telecommunications network protective, operational,
and safety requirements. The Department does not guarantee the
equipment will operate to the user’s satisfaction.

Before installing this equipment, ensure that it is permissible to be
connected to the facilities of the local telecommunications company.
The equipment must also be installed using an acceptable method of
connection. In some cases, the company’s inside wiring associated
with a single-line individual service may be extended by means of a
certified connector assembly (telephone extension cor d). Compliance
with the above conditions may not prevent degradation of service in
some situations.

Repairs to certified equipment should be made by an authorized Ca­nadian maintenance facility designated by the supplier. Any repairs
or alterations made by the user to this equipment, or equipment mal­functions, may give the telecommunications company cause to re­quest the user to disconnect the equipment.

Users should ensure for their own pr otection that the electrical ground
connections of the power utility , telephone lines, and internal metallic
water pipe system, if present, are connected together . This pr ecaution
may be particularly important in rural areas.

Users should not attempt to make such connections
themselves, but should contact the appropriate electric
inspection authority, or an electrician, as appropriate.

vi

Load Number

The
percentage of the total load to be connected to a telephone loop which
is used by the device, to prevent overloading. The termination on a
loop may consist of any combination of devices subject only to the re­quirement that the total of the Load Numbers of all devices does not
exceed 100.

(LN) assigned to each terminal device denotes the

vii

IMPORTANT SAFETY INSTRUCTIONS

When using your telephone equipment, basic safety precautions
should always be followed to reduce the risk of fire, electric shock and
injury to persons. The precautions are listed below.

1. Do not use this product near water (for example, near a
bath tub, wash bowl, kitchen sink or laundry tub, in a wet
basement or near a swimming pool).

2. Avoid using a telephone (other than a cordless type) dur­ing an electrical storm. There may be a remote risk of elec­tric shock from lightning.

3. Do not use the telephone to report a gas leak in the vicinity
of the leak.

4. Use only the power cord, power supply, and/or batteries
indicated in the manual. Do not dispose of batteries in a
fire. They may explode. Check local codes for any special
disposal instructions.

5. Use a suitably approved and certified power supply that
has a minimum output rating of 12 VDC, 800 mA, with a
maximum output power r ating of 240 VA (W) (1 200240L1).
Use a “Listed” Class 2 power supply.

SAVE THESE INSTRUCTIONS.

viii

AFFIDAVIT REQUIREMENTS FOR CONNECTION TO DIGITAL

SERVICES

• An affidavit is required to be given to the telephone company
whenever digital terminal equipment without encoded analog
content and billing protection is used to transmit digital signals
containing encoded analog content which are intended for even­tual conversion into voiceband analog signals and transmitted on
the network.

• The affidavit shall affirm that either no encoded analog content
or billing information is being transmitted or that the output of
the device meets Part 68 encoded analog content or billing pro­tection specifications.

• End user/customer will be responsible to file an affidavit with
the local exchange carrier when connecting unprotected CPE to a

1.544 Mbps or subrate digital service.

• Until such time as subrate digital terminal equipment is regis­tered for voice applications, the affidavit requirement for subrate
services is waived.

ix

AFFIDAVIT FOR CONNECTION OF CUSTOMER PREMISES EQUIPMENT

TO 1.544 MBPS AND/OR SUBRATE DIGITAL SERVICES

For the work to be performed in the certified territory of
_________________________
(telco name)
State of ___________________
County of ___ _______________

I, _______________________________ (name),

_________________________________ (business address),

_________________________________ (telephone number)
being duly sworn, state:

I have responsibility for the operation and maintenance of the termi­nal equipment to be connected to 1.544 Mbps and/or
_________subrate digital services. The terminal equipment to be con­nected complies with Part 68 of the FCC rules except for the encoded
analog content and billing protection specifications. With respect to
encoded analog content and billing protection:

( ) I attest that all operations associated with the establishment, main­tenance, and adjustment of the digital CPE with respect to encoded
analog content and billing protection information continuously com­plies with Part 68 of the FCC Rules and Regulations.

( ) The digital CPE does not transmit digital signals containing encod­ed analog content or billing information which is intended to be de­coded within the telecommunications network.

( ) The encoded analog content and billing protection is factory set and
is not under the control of the customer.

I attest that the operator(s)/maintainer(s) of the digital CPE responsi­ble for establishment, maintenance, and adjustment of the encoded
analog content and billing information has (have) been trained to per­form these functions by successfully having completed one of the fol­lowing (check appropriate blocks):

x

( ) A. A training course provided by the manufacturer/grantee of the
equipment used to encode analog signals; or

( ) B. A training course provided by the customer or authorized repre­sentative, using training materials and instructions provided by the
manufacturer/grantee of the equipment used to encode analog sig­nals; or

( ) C. An independent training course (e.g., trade school or technical
institution) recognized by the manufacturer/grantee of the equip­ment used to encode analog signals; or

( ) D. In lieu of the preceding training requirements, the operator(s)/
maintainer(s) is (are) under the control of a supervisor trained in ac­cordance with __________________ (circle one) above.

I agree to provide _______________ _______(telco’s name) with proper
documentation to demonstrate compliance with the information as
provided in the preceding paragraph, if so requested.

______________________________Signature

______________________________Title

______________________________Date

Transcribed and sworn to before me on:

Month________, Date________, Year________.

______________________________
Notary Public

My commission expires:

______________________________

xi

WARRANTY:

ADTRAN and supplied under Buyer’s order shall be free from de­fects in materials and workmanship and will conform to applica­ble specifications and drawings. ADTRAN’s liability herein,
whether based upon breach of warranty or co ntract or negligence
in manufacture, shall be limited to replacement or repair at ADT­RAN’s election of all such defective or nonconforming items, pro­vided that this warranty shall apply only where Buyer has given
ADTRAN written notice of such defects or nonconformity within
five (5) years* after delivery by ADTRAN of such items to Buyer.
ADTRAN shall have the right prior to return to inspect at Buyer’s
plant any items claimed to be defective or nonconforming.

*Note: The following items carry warranty period as shown.

1. Items not of ADTRAN manufacture will carry the remain-

ing warranty and related terms and conditions of the origi­nal manufact urer.

2. Encapsulated U-Repeater and Encapsulated DDS Repeater

- 2 years.

The foregoing constitutes the sole and exclusive remedy of the
Buyer and exclusive liability of ADTRAN AND IS IN LIEU OF
ANY AND ALL OTHER WARRANTIES EXPRESSED OR IM­PLIED OR STATUTORY AS TO MERCHANTABILITY, FITNESS
FOR PURPOSE SOLD, DESCRIPTION, QUALITY, PRODUC­TIVENESS OR ANY OTHER MATTER. Without limiting the fore­going, in no event shal l ADTRAN be liable for the loss of use or
profit or other collateral, special or consequential damages.

ADTRAN warrants that items manufactured by

RETURNS:

RAN prior to return of any items, including those for repair. Buy­er’s right to repair or replacement are governed by this Warranty.
Issuance of credit for returned items shall be made at ADTRAN’s
discretion upon Buyer’s request. All returns for credit accepted by
ADTRAN are subject to a restocking fee.

SHIPPING:

cility back to ADTRAN shall be paid by the Buyer. The cost for re­turn shipping of the equipment by surface carrier shall be paid by
ADTRAN. ADTRAN will utilize other means of express shipment
at the request of the Buyer. The cost of shipping shall be paid by
the Buyer if express shipment is requested. In-warranty equip-

xii

Return authorization must be obtained from ADT-

The cost of shipping the equipment from Buyer’s fa-

ment returned for repair that is found not defective will carry a
nominal charge to cover handling cost.

OUT OF WARRANTY:

cluding return shipment are subject to a charge as quoted by
ADTRAN. The cost of the repair will be invoiced and the return of
the item will be made using the most economical shipment means
available. ADTRAN will use other means of express shipment at
the request of the Buyer. In this case, the cost of shipping shall be
paid by the Buyer.

ALTERATION TO EQUIPMENT PURCHASED:

or alteration to purchased equipment by Buyer, other than that
specifically authorized by this Agreement or by ADTRAN, shall
VOID AND NULLIFY, in its entirety, all warranty conditions as
set forth in Warranty paragraph.

ENGINEERING CHANGES:

make progress and design changes in standard product items or­dered without prior approval or notification to Buyer and without
incurring any obligations or liability to make the same changes in
items previously manufactured.

DATA RIGHTS:

the products or any data furnished hereunder are not granted ex­cept by specific written permission by an authorized representa­tive of ADTRAN. Buyer shall have no right to copy or reproduce
in whole or part any data furnished hereunder without the prior
written consen t of ADTRAN.

The cost of out-of-warranty repairs in-

Modification

ADTRAN reserves the right to

Rights to any intellectual property residing in

PATENT AND COPYRIGHT INDEMNITY:

that the equipment and documentation furnished under this
Agreement shall be free and clear of infringement of any patent or
copyright covering the structure or composition of such articles or
documentation. In the event of a clai m, suit or acti on aga inst Buy ­er alleging such infringement, ADTRAN shall save Buyer and its
affiliates, agents or customers harmless from liability as finally de­termined by a court of competent jurisdiction, for such infringe­ment, provided that Buyer gives ADTRAN notice promptly of
such claim, suit or action, and shall have given ADTRAN full and
exclusive control of the defense thereof, and that ADTRAN shall
have sole right to settle or compromise such claim, suit or action.

ADTRAN warrants

xiii

In the event of a claim, suit o r action against AD TRAN alle ging in ­fringement by the use of any such equipment or documentation,
furnished under this Agreement, in combination with other arti­cles or in carrying out any process covered by a patent owned or
controlled by any other person, in which independent use of the
equipment under this Agreement would not be an infringement.
Buyer shall save ADTRAN harmless from liability, as finally de­termined by a court of competent jurisdiction, for such infringe­ment, provided that ADTRAN shall have given Buyer full and
exclusive control of the defense thereof, and that Buyer shall have
the sole right to settle claim, suit or action.

Except as herein provided in this indemnity paragraph, neither
Buyer nor ADTRAN makes any warranty to the other with re­spect to any claim, suit or action of any third party by way of in­fringement and neither party shall be responsible to the other for
any loss, cost or damages consequential or otherwise, that may be
suffered by the other as a result of any such claim, suit or action.

Telephone Company Contacts for ISDN Service in U.S.A.:

Ameritech ISDN Repair 1-800-TEAMDATA
Bell Atlantic South 1-800-570-ISDN
Bell South 1-800-247-2020
Cincinnati Bell 1-513-241-6900
Bell Atlantic North 1-800-GET-ISDN

1-800-430-ISDN (New England
Area)

Support: 1-888-676-4736
Pac Bell 1-800-4PB-ISDN
Rochester Tel [phone] (Repair)

1-716-777-2000 (Order)
Southwestern Bell 1-800-792-4736
US West 1-800-223-7508 (Repair)

1-800-244-1111 (Order)

xiv

Table of Contents

Chapter 1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

Express 3x10 Series Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

Requirements for Computer Connection . . . . . . . . . . . . . . . . . . . . . . 1-2

For a PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

For a Macintosh . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

General Requirements (PC and Macintosh) . . . . . . . . . . . . . . 1-2

Basic Rate ISDN Line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

What ADTRAN Provides . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

Dialing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4

Recommended Operating Protocols . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4

Chapter 2 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

Installing the Express 3010/3110 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

Verify Switch Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2

Windows Installation Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3

Hardware Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3

Windows 95/98 Users . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3

Windows NT 4.0 Users . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3

Windows NT 3.51 Users . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4

Macintosh Installation Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4

Hardware Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4

Basic Telephone Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5

Supplementary Voice Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5

Call Waiting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5

Conference Calling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5

Phone Number Allocation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6

Auto-Detect SPIDs/Switch Type (Expert ISDN) (Express 3010 Only) 2-6

VT 100 Terminal Emulation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7

VT 100 Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8

VT 100 Terminal Status Buffer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9

Chapter 3 Application Configuration. . . . . . . . . . . . . . . . . . . . . . . 3-1

Configuring the Express . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

Network Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

Area Code (Express 3010 only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

ISDN Phone Number (Local Directory Number) . . . . . . . . . . . . . 3-2

61200239L1-20 Express 3010/3110 User Manual xv

Table of Contents

Auto-Detect SPIDs/Switch (Express 3010 only) . . . . . . . . . . . . . .3-2

Switch Protocol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-2

Call Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-2

Service Profile ID (SPID) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-3

Auto Answer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-4

Disabled . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-4

Enabled . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4

Dump all calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-4

Call Screening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-4

Call Routing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-5

All Calls to DTE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-5

Speech calls to POTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-5

Speech/Audio calls to POTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-5

Dial Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-6

AT Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-6

V.25 bis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-6

VT 100 Terminal Dialing Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6

Hang up line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-6

Dial number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-6

Redial last number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-7

Answer call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-7

Dial stored number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-7

Store/Review number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-7

Options for both Leased and Switched ISDN Service . . . . . . . . . . . 3-8

DTE Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-8

Bit Rate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-8

Transmit Clock for Synchronous Data . . . . . . . . . . . . . . . . . . . . . . .3-8

DTR Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-9

Flow Control for Asynchronous Data . . . . . . . . . . . . . . . . . . . . . .3-10

Setting Protocol Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10

Setting PPP Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-11

Clear Channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-11

Point-to-Point Protocol (PPP) Async-to-Sync . . . . . . . . . . . . . . . .3-11

BONDING Mode 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-12

V.120 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-12

V.110 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-12

FALLBACK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-12

Multilink Point-to-Point Protocol . . . . . . . . . . . . . . . . . . . . . . . . . .3-13

PPP and STAC Compression . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-13

Configuring the Express Using profiles (Quick Setup) . . . . . . . . . 3-14

xvi Express 3010/3110 User Manual 61200239L1-20

Table of Contents

Default (factory) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-15

Dial 56K sync . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-16

Dial 64K sync . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-16

Dial 112K sync . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-17

Dial 128K sync . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-17

Leased 128k (Express 3010 only) . . . . . . . . . . . . . . . . . . . . . . . . 3-18

Ldm 128 Master (Express 3010 only) . . . . . . . . . . . . . . . . . . . . . 3-18

Dial V120 asyn . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-19

Dial Bond asyn . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-19

Internet 64K . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-20

Internet 128K . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-20

Remote 64K . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-21

Remote 128K . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-21

Leased V120 (Express 3010 only) . . . . . . . . . . . . . . . . . . . . . . . . 3-22

Configuring the Express for V.25 bis In-band Dialing . . . . . . . . . . 3-23

SYNC V.25 Dialing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-23

SYNC V.25 HDLC Dialing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-24

SYNC V.25 BISYNC Dialing . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-24

The Status Buffer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-25

Test Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-25

Test Remote . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-25

Loopback Protocol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-26

Lpbk Proto Timeout = 1 min . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-26

Loopback Disable = V54 Accepted . . . . . . . . . . . . . . . . . . . . . . 3-26

Near-End Block Errors/Far-End Block Errors (NEBE/FEBE)

(Express 3010) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-26

Chapter 4 Upgrading Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1

Using HyperTerminal to Upgrade Software . . . . . . . . . . . . . . . . . 4-1

Chapter 5 Installing an Analog Modem. . . . . . . . . . . . . . . . . . . . . 5-1

Internal Analog Modem Application . . . . . . . . . . . . . . . . . . . . . . . . . 5-1

Connecting an Internal Analog Modem . . . . . . . . . . . . . . . . . . . . . 5-2

Chapter 6 Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1

Troubleshooting Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1

Power/Line LED is Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1

Power/Line LED Flashes and 1 and 2 LEDs are Off . . . . . . . . . . 6-1

Power/Line LED, 1, and 2 LEDs Flash Green . . . . . . . . . . . . . . . . 6-2

Dial-Up Connection Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2

61200239L1-20 Express 3010/3110 User Manual xvii

Table of Contents

Auto-detect Switch/SPIDs Remains at Link Down . . . . . . . . . . . .6-3

Express Not Detected . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-3

Difficulty with 230.4 kbps Operation . . . . . . . . . . . . . . . . . . . . . . . .6-4

Dial-Up Networking Difficulty . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-4

Appendix A AT Commands and S-Registers . . . . . . . . . . . . . . . . A-1

Appendix B LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-1

Appendix C Status Buffer Messages . . . . . . . . . . . . . . . . . . . . . . . C-1

Appendix D Loop Status Messages . . . . . . . . . . . . . . . . . . . . . . . . D-1

Appendix E Connector Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . .E-1

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Index-1

xviii Express 3010/3110 User Manual 61200239L1-20

List of Figures and Tables

Figure 1-1. Express Package Contents. . . . . . . . . . . . . . . . . . . . . . . . 1-3

Figure 2-1. Standard ISDN Internet/Remote Access Application 2-1

Figure 2-2. Dip Switches on Rear Panel . . . . . . . . . . . . . . . . . . . . . . 2-2

Figure 2-3. Telephone Connection Port. . . . . . . . . . . . . . . . . . . . . . . 2-6

Figure 2-4. VT 100 Terminal Configuration Menu . . . . . . . . . . . . . 2-8

Figure 2-5. VT 100 Terminal Status Buffer Menu . . . . . . . . . . . . . . 2-9

Figure 3-1. Express Loopback Points. . . . . . . . . . . . . . . . . . . . . . . . 3-26

Figure 5-1. Internal Analog Modem Application . . . . . . . . . . . . . . 5-1

Figure B-1. Front Panel LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-1

Figure E-1. EIA-232 Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-1

Figure E-2. Express 3010 Ground Pinouts. . . . . . . . . . . . . . . . . . . . . E-2

Table 1-1 Recommended Operating Modes . . . . . . . . . . . . . . . . . 1-5

61200239L1-20 Express 3010/3110 User Manual xix

List of Figures and Tables

xx Express 3010/3110 User Manual 61200239L1-20

Chapter 1

The Express 3x10 series™ modems are versatile ISDN modems that
convert a synchronous or asynchronous DTE port to a Basic Rate
ISDN circuit at speeds up to 128 kbps. The Express 3010 presents a
U-interface to the ISDN network. The Express 3110 presents an S/ T in­terface to the ISDN network.

Key features offered by both the Express 3010 and Express 3110 are
listed below.

Overview

EXPRESS 3X10 SERIES FEATURES

• Two ports for phone or analog service

• Synchronous DTE rates to 128 kbps

• Asynchronous data rates up to 230.4 kbps

• Custom calling features and Caller ID support

• Automatic SPID and Switch Detection using ADTRAN Expert

ISDN (covered under patent number 5,715,241), or Auto SPID

download where available for the Express 3010

•LZS

• Remote configuration

•Windows

• Multilink PPP, Bonding Mode 1

®

technology from hi/fn™ for compression up to 230.4 kbps

®

Plug and Play compatibility

61200239L1-20 Express 3010/3110 User Manual 1-1

Chapter 1. Overview

REQUIREMENTS FOR COMPUTER CONNECTION

For a PC

• Personal computer 386 or higher

• Windows 95/98 or Windows NT 3.51 or higher

For a Macintosh

• Power Mac or 68020 Processor

• Macintosh high-speed modem cable

General Requirements (PC and Macintosh)

• 16550 UART high speed serial port (16650 UAR T required for
data speed of 230.4 kbps)

• EIA-232 serial cable with a DB25 connector for the Express and
the other end matching the COM port on the computer (do not
use a null modem cable)

• One Basic Rate ISDN line (two ISDN phone numbers, sometimes
referred to as local directory numbers)

Single ISDN phone number and point-to-point lines are not
recommended for use with the Express.

Basic Rate ISDN Line

When ordering your ISDN line from the telephone company, request

EZ-ISDN 1

(Capability Package U) to ensure that it is set up properly.
EZ-ISDN 1 is recommended by the industry for most home office/
small business applications. If EZ-ISDN is not available from your ser­vice provider, order
ordering ISDN, see the ADTRAN document

User Guide

part number 60000.015-8, or contact the telephone compa-

ny for alternative line configurations. The

Guide

is available on the ADTRAN home page at

ran.com

1-2 Express 3010/3110 User Manual 61200239L1-20

or by calling ADTRAN.

Generic Da ta S

. For more information regarding

Ordering ISDN Service

Ordering ISDN S e rvice User

http://www.adt-

Chapter 1. Overview

What ADTRAN Provides

The ADTRAN Express is packaged with the following contents (see
Figure 1-1).

• Express unit

• AC power supply

• RJ-45 to RJ-11 telephone cable

CD-ROM

Figure 1-1. Express Package Contents

61200239L1-20 Express 3010/3110 User Manual 1-3

Chapter 1. Overview

DIALING

Dialing from the Express is accomplished in the following ways:

• Using a VT 100 terminal connected to the rear panel EIA-232

port. (See

Express
Dialing

• Over the DTE interface using the AT command set. (See

Commands and S-Registers

• V.25 bis in-band (used in applications such as LAN/WAN

bridging). (See
on page 3-23.)

• When DTR is raised. Routers can be configured when band width

on their dedicated line is exceeded. In high-traffic times, this
allows the Express to dial out over the ISDN for an e xtra 128 kbps
of bandwidth-on-demand.

VT 100 Terminal Emulation

on page 3-1, and
on page 3-23.)

Configuring the Express for V.25 bis In-band Dialing

Configuring the Express for V.25 bis In-band

on page A-1.)

on page 2-7,

Configuring the

AT

RECOMMENDED OPERATING PROTOCOLS

The Express supports a wide range of operating modes. Many combi­nations of circuit type, protocol, and data rate may be selected. The
combinations shown in Table 1-1 on page 1-5 are recommended.

Table 1-1 shows that a given data rate may be achieved by more than
one protocol/rate adaption selection. The table is organized so that
selections with the least transport delay are closer to the top of the ta­ble for any given circuit type. Therefore, choose a protocol and rate
closer to the top of the protocol rate list for a given circuit type.

1-4 Express 3010/3110 User Manual 61200239L1-20

Chapter 1. Overview

Table 1-1.

Call Type Protocol Sync/

DIAL-64K BONDING Sync 56000 64000

DIAL-56K BONDING Sync 56000

DIAL-64K*2 BONDING Sync 128000

DIAL-56K*2 BONDING Sync 112000

LEASED 64K Clear Chan Sync 48000 56000 64000
LEASED

128K

Clear Chan Sync 48000 56000 64000
PPP Sync 2400 4800 9600 19200 38400 56000 64000
V.110 Sync 2400 4800 9600 19200 38400
V.120 Sync 9600 19200 38400 48000
PPP async-

sync
BONDING Async 2400 4800 9600 19200 38400 57600
V.110 Async 1200 2400 4800 9600 19200 38400
V.120 Async 1200 2400 4800 9600 19200 38400 57600 115200f230400

Clear Chan Sync 48000 56000
PPP Sync 2400 4800 9600 19200 38400 56000
V.110 Sync 2400 4800 9600 19200
V.120 Sync 9600 19200 38400 48000
PPP async-

sync
BONDING Async 2400 4800 9600 19200 38400 57600
V.110 Async 1200 2400 4800 9600 19200
V.120 Async 1200 2400 4800 9600 19200 38400 57600 115200f230400

MPPP Sync 128000
MPPP Async 115200
BONDING Async 115200

MPPP Sync 112000
MPPP Async 115200
BONDING Async 115200

Clear Chan Sync 128000

Rates Supported (bps)

Async

Async 1200 2400 4800 9600 19200 38400 57600 115200f230400

Async 1200 2400 4800 9600 19200 38400 57600 115200f230400

Recommended Operating Modes

f

f

f

f

1.All asynchronous rates support flow control

2.All dial-up modes support front panel, DTR, AT command, and
V.25 bis dialing methods.

3.Rates marked with f require flow control.

4.Given a choice between two protocols, pick the protocol closer to the
top of the list for the circuit type.

61200239L1-20 Express 3010/3110 User Manual 1-5

Chapter 1. Overview

1-6 Express 3010/3110 User Manual 61200239L1-20

Chapter 2

Installation

INSTALLING THE EXPRESS 3010/3110

This section describes how to connect the Express 3010/31 10 to a com­puter. Figure 2-1 depicts the final hardware configuration (see also

Windows Installation Instructions
Instructions

on page 2-4).

on page 2-3 and

Macintosh Installation

Figure 2-1. Standard ISDN Internet/Remote Access Application

61200239L1-20 Express 3010/3110 User Manual 2-1

Chapter 2. Installation

Verify Switch Settings

Dip switches 1 and 2 located on the rear panel of the Express 3010/
3110 allow you to physically configure certain settings. Figure 2-2
shows the location of the dip switches on the rear panel of the unit.

The factory default position for all switches is down (On) during ini­tial installation.

SW 1:

Off (Up) = 230.4 kbps

On (Down) = Autobaud (speeds up to 115.2 kbps)

If switch 1 is set to the Off position, the unit is set to operate at a DTE
rate of 230.4 kbps. A special COM port using a 16650 UART is re­quired while in this mode. If switch 1 is set to the On position, the unit
will automatically adapt to the DTE rate (up to 115.2 kbps).

SW 2:

Off (Up) = Factory Default

On (Down) = Normal (previous settings saved)

If switch 2 is set to the Off posit ion (up), the unit continue s to use the fac­tory default setti ngs until swi tch 2 is set to the On position (d own). Also,
area code, phone numbers, SPIDS, and stored numbers are cleared.

If both switches are up, the unit is offline in Command Mode.

12VDC

EIA232

PWR

OFF

12

21

ON

ISDN

OFF

12

ON

Figure 2-2. Dip Switches on Rear Panel

2-2 Express 3010/3110 User Manual 61200239L1-20

Chapter 2. Installation

WINDOWS INSTALLATION INSTRUCTIONS
Hardware Installation

1. With the computer’s power off, connect the
the Express to an available COM port on the computer.

2. Plug the Express’s AC power cord into the port labeled
Plug the other end into a 120 V electrical outlet. The Express is
now powered on.

3. Plug the RJ-45 connector (large end) of the RJ-45 to RJ-11 tele­phone cable into the jack labeled

4. Plug the RJ-11 connector (small end) of the RJ-45 to RJ-11 tele­phone cable into the ISDN telephone wall jack.

5. Power on the computer.

Windows 95/98 Users

1. Windows 95/98 automatically detects and installs the necessary
driver for the Express. Follow the on screen instructions.

Windows NT 4.0 Users

1. Double click on the

Panel

icon.

2. Double click on the

3. If there is no other modem installed on the compute r, the

New Modem

installed on the computer, click the

Install New Modem

4. Click the
ically detect the Express.

5. To complete the installation, follow the on screen instructions.

Next

My Computer

Modems

window appears. If another modem is already

window.

button and Windows NT will attempt to automat-

ISDN

icon, then on the

icon.

Add

EIA232

on the rear of the Express.

button to display the

serial port on

PWR

.

Control

Install

61200239L1-20 Express 3010/3110 User Manual 2-3

Chapter 2. Installation

Windows NT 3.51 Users

1. Locate the

c:\winnt35\system32\ras

documentation for instructions on installing the Remote Access
Service.

2. To recover your files in case of a user mistake, create a backup of
the modem.inf file.

3. Using Notepad, open the

4. Copy the contents of the
board.

5. Open the modem.inf file.

6. Paste the contents of the clipboard (

modem.inf

7. Save the new altered

8. Restart the system.

modem.inf

file.

file. This file is normally located in the

directory. See the Windows NT

adtran.inf

adtran.inf

modem.inf

file (on the Express CD).

file into the Windows clip-

adtran.inf

and close the file.

) to the end of the

MACINTOSH INSTALLATION INSTRUCTIONS
Hardware Installation

1. With the Macintosh’s power off, connect the
on the Express to an available communications port on the
Macintosh.

Be sure to use a Macintosh high-speed modem cable. Macintosh
high-speed modem cables are available at any electronics store that
carries Macintosh equipment.

2. Plug the Express’s AC power cord into the port labeled
Plug the other end into a 120 V electrical outlet. The Express is
now powered on.

3. Plug the RJ-45 connector (large end) of the RJ-45-to-RJ-11 tele­phone cable into the jack labeled

4. Plug the RJ-11 connector (small end) of the RJ-45 to the RJ-11 tele­phone cable into the ISDN telephone wall jack.

5. Power on the Macintosh.

2-4 Express 3010/3110 User Manual 61200239L1-20

ISDN

EIA232

on the rear of the Express.

serial port

PWR

.

Chapter 2. Installation

BASIC T ELEPHONE SERVICE

In addition to the computer connectio n, two analog devices such as a tele­phone, Fax, modem, answering machine, or caller ID box can be connect­ed using the t wo P OTS inte rfa ces on t he rear p anel ( RJ- 11 jack s label ed

2

and

with an illustration of a telephone abo ve the jack).

Supplementary Voice Services

Supplementary services such as call forwarding, caller ID, call return,
call holding, three- or six-way conference calling, call transfer, call re­jection, and call waiting are fully supported by the Express 3010/3110
on a touch-tone telephone. These services are available only if includ­ed in the ISDN line configuration and are implemented using the stan­dard commands provided by the telephone company.

Call Waiting

Call Waiting permit s one voice c all to be placed o n hold while answerin g
another voice call. Use the flash-hook t o place the active call on hold and
answer an incoming call. Hanging up terminates both c alls. The call wai t­ing tone can be disabled and enabled on a per-call basis. To disable call
waiting (using a touch-tone p hone), pr ess
hang up. (The Expre ss de fault s to cal l wai ti ng.)

*70

. To enable call waiting,

1

Conference Calling

Conference Calling (also known as three-way calling) permits a con­versation between three parties, each at different locations.

After establishing a voice call, flash-hook to put the first party on hold
and receive a second dial tone. Dial the second party. Flash-hook
again to conference the two calls.

When connecting to a National ISDN 1 switch, call conferencing, message
waiting, and call transferring are a ssigned a unique featur e i dentifier
num b e r. T h is number may n o t be the same i n all ar eas. S-regis t ers 90
through 93 contain the featu re ident ifier numbers for confere nce and
transfer. If these featu res do not work, contact your ISDN provider.

61200239L1-20 Express 3010/3110 User Manual 2-5

Chapter 2. Installation

Phone Number Allocation

The Express allocates ISDN phone number 1 to POTS port 1. Connect
the primary telephone to POTS port 1 (see Figure 2-3).

21ISDN

Figure 2-3. Telephone Connection Port

ISDN phone number 2 is shared by the EIA-232 port and POTS port 2;
therefore only one port can be used at a time.

ISDN data calls and external modem applications must be placed to
ISDN phone number 2.

Auto-Detect SPIDs/Switch Type (Expert ISDN)
(Express 3010 Only)

Auto-detection of SPIDs and Switch Type greatly reduces the likeli­hood of time-consuming problems occurring during installation of
the Express. It evaluates common SPID formats based on the area
code and phone numbers and reports success after placing a test call.

The switch type and SPID numbers can be detected automatically
through the Express interface by using the following steps:

1. Type

2. Type

AT!V

to activate the VT 100 screen.

Ctrl+C

to activate the Configuration menu.

3. Enter the area code and ISDN phone numbers given by the ISDN
service provider.

4. Enter “Enabled” under the Auto-Detect SPIDS/switch selection.

2-6 Express 3010/3110 User Manual 61200239L1-20

Chapter 2. Installation

After installation is complete, the Express 3010/3110 resets the ISDN
line for a clean start. Therefore, the PWR/LINE LED may not be on
solid (indicating link up) for a few more seconds. In the few cases
where the procedure does not succeed, a window will pop up,
prompting you to enter the SPIDs.

VT 100 TERMINAL EMULATION

The Express 3010/3110 can be configured using any communications
package supporting VT 100 terminal emulation. Instructions for VT
100 configuration are given in
Chapter 3,

Application Configuration

menu tree and their hot keys (the keys you press to go to a particular
menu) are as follows:

Menu: Hot Keys:

CONFIG (Ctrl + C)
DIAL (Ctrl + D)
STATUS (Ctrl + V)
TEST (Ctrl + T)

VT 100 Configuration

on page 2-8 and in

. The main branches of the VT 100

Ensure that the communications package is configured to pass these
Control Sequences through to the Express.

To exit a menu, you can press

Ctrl + X

. The

Ctrl + X

command also

places the unit back on-line if a call is connected.

Some features in the Express 3010/3110 do not immediately take ef­fect upon selection. This prevents unintentional reconfiguration of the
Express 3010/3110 during an active call. Items such as

Call Type

61200239L1-20 Express 3010/3110 User Manual 2-7

take effect

only

at the beginning of a new call.

Protocol

and

Chapter 2. Installation

VT 100 Configuration

After connecting a VT 100 terminal, press

AT!V

followed by

Enter.

The Configuration screen is the first screen displayed (see Figure 2-4).

Figure 2-4. VT 100 Terminal Configuration Menu

Press the number corresponding to the item you want to configure.
The possible settings display. Press the number of the setting you de­sire. See Chapter 3,

Application Configuration

, for details on configura-

tion.

2-8 Express 3010/3110 User Manual 61200239L1-20

Chapter 2. Installation

VT 100 Terminal Status Buffer

The status buffer can be displayed at any time after entering the menu
structure. Pressing
menu. The last 20 status messages generated during the operation of
the unit are displayed with relevant status items. See Figure 2-5 on
page 2-9. Status messages provide informatio n about call progress,
ISDN link status and error conditions. The most recent status message
appears as Status 1, with the remaining status messages appearing in
descending order. The status buffer messages and their descriptions
are listed in the appendix

Ctrl + C

Press

Ctrl + V

displays the Express 3010/3110 Status

Status Buffer Messages

on page C-1

to return to the Configuration menu.

.

Figure 2-5. VT 100 Terminal Status Buffer Menu

61200239L1-20 Express 3010/3110 User Manual 2-9

Chapter 2. Installation

2-10 Express 3010/3110 User Manual 61200239L1-20

Chapter 3

There are two methods for configuring the Express 3100: (1) by VT 100
terminal or (2) by AT commands. Before configuring the Express for
any application, the Express should be properly connected as de­scribed in the Chapter 2.

Technical notes, documents, and scripts can be found on the
ADTRAN web home page at
tation explains how to use ADTRAN products in specific applications
on PC and Macintosh platforms.

Application Configuration

http://www.adtran.com

. This documen-

CONFIGURING THE EXPRESS

It is important to note that some features in the Express do not
immediately take effect upon selection. This prevents unintentional
reconfiguration of the Express during an active call. Items such as
Protocol and Call Type take effect only at the beginning of a new
call.

Network Options

To place ISDN modem calls, the unit must be configured for
form the following steps to configure for Dial Line operation:

1. Go to the Configuration screen.

2. Press the number corresponding to

Enter

to view the

Leased Line

3. Press the number corresponding to

Dial Line

select

Network Options

.

.

Network Options

choices:

Dial Line

Dial Line

Dial Line

and press

and press

and

Enter

. Per-

to

Area Code (Express 3010 only)

Enter the area code when using the AutoSPID/switch option.

61200239L1-20 Express 3010/3110 User Manual 3-1

Chapter 3. Application Configuration

ISDN Phone Number (Local Directory Number)

This option allows the entry of 0, 1, or 2 LDNs. The LDN is used when
placing or receiving calls. The LDN is the local phone number as­signed to the line.

LDN 1 = 5 5 5 1 2 1 2

LDN 2 = 5 5 5 1 2 1 2

Auto-Detect S PIDs/ Switch (Express 3010 onl y)

This can be set to
switch type for your ISDN switch are automatically detected. If set to

Disabled

, no automatic detection takes place.

Active

Disabled

or

. If set to

Active,

the SPID and

Switch Protocol

Find out what kind of ISDN switch your local CO is using by asking
your telephone administrator or your telephone company representa­tive. The Express can be configured for a Northern Telecom DMS-100,
LUCENT 5ESS
ISDN-1 standard (usually an LUCENT 5ESS, NTI DMS-100™, or Sie­mens EWSD), or an NEC Switch.

Press the number corresponding to
to display the

National ISDN1, NEC

Press the number corresponding to the de sired option and pre ss
again.

®

CO switch, a switch conforming to the National

Switch Protocol

(Express 3110), and

Switch Protocol

options:

LUCENT 5ESS, DMS-100

EuroISDN

and press

(Express 3110).

Enter

,

Enter

Call Type

The Call type can be configured four different ways, depending on
the type of service used. Press the number corresponding to

Speech, Audio, Data

and

Enter

to display the Call Type options:

Data 64k

. Press the number corresponding to the desired op-

and press

56k,

tion, and then press

Enter

.

Call Type

3-2 Express 3010/3110 User Manual 61200239L1-20

Chapter 3. Application Configuration

Service Profile ID (SPID)

The SPID is a sequence of digits used to identify ISDN terminal equip­ment to the ISDN switch. The SPID is assigned by the local phone
company when the ISDN line is installed and it usually looks similar
to the phone number. Obtain SPIDs from your telephone administra­tor or local telephone representative.

The number of SPIDs required (0, 1, or 2) depends on how your ISDN
line is configured. For instance, a point-to-point line has no SPID.
Multipoint lines may have one or two SPIDs. The Express uses the
presence of SPID 1 to determine if the line is multipoint. If the line has
only one SPID, then it must be entered in SPID 1. Outside of North
America, the SPID format may not be used.

Example:

SPID 1 = 2 5 6
SPID 2 = 2 5 6 5 5 5 4 3 2 1 0 1 0 1

PREFIX SUFFIX

National ISDN-1 switches require the addition of a two-digit
terminal identifier (TID) at the end of the SPID.

5 5 5 1 2 3 4 0 1 0 1

Disconnect the network interface from the unit before initially
entering or altering the SPIDs and LDNs.

Press the number corresponding to SPID 1 and press
field for entering or changing SPID1. Type the SPID and press

Press the number corresponding to SPID 2 and press
field for entering or changing SPID2. Type the SPID and press

Enter

to display the

Enter

to display the

Enter

Enter

.

.

The switch type and SPID numbers can be detected automatically
through the Express interface by doing the following:

(1) Type AT!V to activate the VT 100 screen; (2) Type Ctrl+C to
activate the Configuration menu; (3) Enter the area code and ISDN
phone numbers given by the ISDN service provider; (4) Enter
Enabled under the Auto-Detect SPIDS/switch selection.

61200239L1-20 Express 3010/3110 User Manual 3-3

Chapter 3. Application Configuration

Auto Answer

Press the number corresponding to
view the

Calls

press

Disabled

When
AT answer command (ATA) must be issued to the Express before it
accepts the incoming call. The ringing call can be dumped using the

Hang up line

Enabled

When
call on the primary phone number (SPID1, LDN1). If that call is a
BONDING call, then another incoming call is accepted on the second­ary phone number (SPID2, LDN2).

Dump all calls

When
coming calls, keeping the line clear for outgoing calls.

Auto Answer

. Press the number corresponding to the desired options; then

Enter

.

Disabled

Enabled

Dump all calls

is selected, the Express will not answer the call. An

command.

is selected, the Express will accept an incoming data

options:

is selected, the Express will not accept any in-

Auto Answer

Disabled, Enabled,

and press

and

Enter

to

Dump All

Call Screening

Call Screening
swer Any

stored in the

wer if SN0 .. 9

Call Screening

When
through SN9, an incoming call is not answered if the Call ID received
from the switch does not match a stored number. Depending on the
switch type, the Call ID may be presented in either a seven- or ten-dig­it format. The Express displays the Call ID for all dumped calls in the
Status buffer.

3-4 Express 3010/3110 User Manual 61200239L1-20

allows the Express to answer all incoming calls (

) (default) or only calls originating from phone numbers

DIAL

menu as stored number s SN0 through S N9 (

).

is set to answer any numbers stored in SN0

1) An-

2) An-

Chapter 3. Application Configuration

Because different switches handle calls and Call ID differently, use the
following procedure to determine if your switch uses a seven- or ten­digit Call ID format or phone number.

1. Press the number corresponding to

Enter

2. Select

to view the

Ansr if SN0 . . 9

Call Screening

.

Call Screening

options.

and press

3. Store your seven-digit num b er in SN 0.

4. Place a call to the Express with the stored number to see if it

answers.

5. If the Express does not answer the call, look at the Call ID mes-

sage in the Status buffer. More than likely, the Call ID number is
a ten-digit number.

6. Re-store the number in SN0 as it is displayed in the Call ID mes-

sage, and test

Call Screening

again.

Call Routing

These options specify how the Express is to route incoming voice calls.
Press the number corresponding to
view the

POTS

Call Routing

Speech/Audio calls to POTS

, and

options:

Call Routing

and press

All Calls to DTE, Speech calls to

.

All Calls to DTE

This option routes all calls to the EIA-232 port, regardless of call type.

Enter

to

Speech calls to POTS

This option rou tes call s with a Spe ec h Cal l Ty pe to t he POT S p ort s. Cal ls
with Data 56k, Data 64k, and Audio are routed to the EIA-232 port.

Speech/Audio calls to POTS

This option routes cal ls wi th Speech and Audi o Call Types to the POTS
ports. Calls with Data 56k and Data 64k are routed to the EIA-232 por t.

61200239L1-20 Express 3010/3110 User Manual 3-5

Chapter 3. Application Configuration

Dial Options

Press the number corresponding to
view the

Dial Options: AT Commands

ber corresponding to the desired option; then press

Dial Options

V.25 bis

and

and press

. Press the num-

Enter

option will not take effect until exiting the VT 100 interface (

Enter

. The selected

Ctrl+X

AT Commands

Configuring the Express for
over the DTE interface using asynchronous AT commands.

mands

can be used to set up the Express as well as establish and end

AT commands

enables in-band dialing

AT com-

a call.

V.25 bis

Configuring the Express for

V.25 bis

enables in-band dialing over the
DTE interface using asynchronous or synchronous V.25 bis com­mands.

See the section

V.25 bis

can be used to establish and end a call.

Configuring the Express for V.25 bis In-band Dialing

page 3-23 for more information.

VT 100 TERMINAL DIALING OPTIONS

to

).

on

After starting the terminal emulation package, type

ter

. Enter the Express Dial menu by pressing

Ctl + D

AT!V

.

and press

En-

Hang up line

Terminates current call.

Dial number

Enter

Allows a number to be entered and dialed. Pressing

after enter­ing a number causes the Express to dial the number and save the di­aled number in storage location 9 for redialing purposes.

3-6 Express 3010/3110 User Manual 61200239L1-20

Chapter 3. Application Configuration

Redial last number

Allows redial of the last number called or attempted. This number
was saved in storage location 9 from the last attempted phone call.

Answer call

Allows selective answer of incoming calls when the Auto Answer is
configured for disable. Auto Answer is described in the section

Answer

on page 3-4

.

Auto

Dial stored number

Allows the dialing of one of ten stored phone numbers.

Store/Review number

Permits entry and review of stored numbers.

61200239L1-20 Express 3010/3110 User Manual 3-7

Chapter 3. Application Configuration

OPTIONS FOR BOTH LEASED AND
SWITCHED ISDN SERVICE

This section describes the options that apply to both leased digital ser­vice and dial operation. To access these options, first go to the Config­uraton menu.

DTE Options

Press the number corresponding to
display the
desired option.

DTE

options:

Asynchronous and Synchronous

DTE Options

and press

Enter

to

. Select the

Bit Rate

Press the number corresponding to

Bit Rate

the

Bit Rate

The
38400, 48000, 56000, 64000, 112000, and 128000 bps. The Express will
autobaud to the asynchronous DTE rate.

options.

can be set synchronously for 2400, 4800, 9600, 19200,

Bit Rate

and press

Enter

to display

Transmit Clock for Synchronous Data

Press the number corresponding to
display the
sired option.

Selecting the
DTE interface transm it timi ng sourc e. Tran smit d ata is ti med f rom th e
transmit clock provided by the Express on the DTE connector.
clock is the normal mode of operation for the Express.

Transmit Clock

Normal

option causes the Express to be the synchronous

Transmit Clock

options:

Normal

and

and press

External

. Select the de-

Enter

Normal

to

With the
mit timing source. The external clock is provided to the Express by the
external transmit clock sig nal at the DT E. This si gnal is ec hoed by th e Ex­press to the trans m it cl oc k sig nal o n the DT E p or t.

3-8 Express 3010/3110 User Manual 61200239L1-20

External

option selected, the Express slaves to an external trans-

Chapter 3. Application Configuration

This option is provided for situations where equipment connected to
the Express DTE connector cannot slave to the Express-provided
clock. The Express uses the U-interface as the frequency standard
when it must provide a synchronous receive or transmit clock. When
using the Express in a Tail Circuit application, it may be necessary to
add delay to accommodate clock jitter. Entering a number from

TxRxDelay

under

will yield the size of the delay buffer, which is ap-

0-255

proximately 8x the number selected in bytes.

DTR Options

Press the number corresponding to
display the

Selecting
data terminal ready (DTR) pin.

DTR

options.

Ignore DTR

causes the Express to disregard the state of the

Cmd when Off

DTR Options

forces the unit into the

and press

Enter

to

AT command processor mode when DTR is not asserted. To return
on-line, DTR must be asserted, followed by the AT0 command.

when Off

asserted.

forces the unit to end the current call when DTR is no longer

Off>On dial #0

allows one call attempt to be automatically

Idle

established when the DTR signal goes from inactive to active. While
DTR is active, dialing is also possible through the built-in menu sys­tem. When DTR goes inactive, any outgoing or incoming call present
is disconnected.

Off>On dial #0

uses the phone number in stored
number register 0 to establish the call. To store a nu mber for automat­ic dialing, see the section

aling

on page 3-23. Selecting

Configuring the Express for V.25 bis In-band Di-

Dial #0 if On

allows calls to be
automatically established when the DTR signal is in the active state.
The unit attempts to establish a call using SN0 until the call is estab­lished or DTR goes inactive. Selecting

Answer if On

only allows the

unit to answer an incoming call if the DTR signal is asserted.

61200239L1-20 Express 3010/3110 User Manual 3-9

Chapter 3. Application Configuration

Flow Control for Asynchronous Data

Press the number corresponding to
display the

Selecting
the DTE interface only when RTS is asserted.
uses XON/XOFF to control data transferred between the DTE and the
Express. Selecting

Flow Control

Hardware Flow Control

No Flow Ctrl

options.

Flow Control

allows RX data to be presented to

disables flow control.

and press

Software Flow

Enter

control

to

SETTING PROTOCOL OPTIONS

The Express communicates with many different types of telecommu­nication equipment including other Express units, ISDN terminal
adapters, BONDING mode 1-compatible inverse multiplexers, and
PPP-compatible bridges/routers.

Communicating between such diverse types of equipment requires
the use of various rate adaptation protocols to support various bit
rates and DTE settings. The Express supports the following rate adap­tation protocols:

1. Clear Channel (no rate adaption protocol)

2. Point-to point protocol (PPP) asynchronous to synchronous con­version

3. BONDING mode 1 (Bandwidth on Demand Interoperability
Group)

4. CCITT V.120

5. CCITT V.110

6. FALLBACK

7. PPP async-sync

The desired protocol may be selected with AT commands at the DTE
port or from the Express built-in menu system. (With the built-in
menu system, view these protocol choices by press the number corre­sponding to
follows.

3-10 Express 3010/3110 User Manual 61200239L1-20

Protocol

and pressing

Enter

.) A descript i on of protocols

Chapter 3. Application Configuration

See the section
information on recommended modes of operation.

Recommended Operating Protocols

on page 1-3 for more

Setting PPP Mode

PPP Mode contains the available options for the PPP async-sync pro­tocol:

1. Multilink PPP

2. PPP

3. PPP with compression

Clear Channel

Clear channel

regard to data format or pro tocol. This provides a rate a daptation at or
near the ISDN circuit rate. The primary usage for
dial line mode is for 56 kbps an d 64 kbps synchronous. It is useful
when the DTE performs its own internal synchronous protocol/rate
adaptation or the Express is calling a 4-wire Switched 56 DSU. In the
leased line mode,
56 kbps, 64 kbps, 112 kbps, and 128 kbps.

provides the entire bearer channel to the DTE without

Clear Channel

Clear Channel

can provide synchronous bit rates of

in the

Point-to-Point Protocol (PPP) Async-to-Sync

PPP provides a standard method for transporting multi-protocol dat­agrams over point-to-point links. The ADTRAN PPP async-sync pro­tocol allows the Express and a PC or Macintosh
software, to communicate with a PPP-compatible bridge or router.
The PPP async-sync protocol complies with Internet Engineering Task
Force (IETF) RFC 1662.

The asynchronous control character map (ACCM) option is scanned
during the negotiation. When the ACCM option is seen in a configure
ACK link control packet, it is adopted by the Express. In addition,
when the ACCM option is not seen in the configure-request packet
from the network, the Express will spoof or add it to the packet.

61200239L1-20 Express 3010/3110 User Manual 3-11

®

running PPP

Chapter 3. Application Configuration

BONDING Mode 1

BONDING mode 1

The
at bit rates in excess of 64 kbps to a maximum of 128 kbps. The proto­col allows use of both synchronous and asynchronous bit rates. When
the Express uses the
separate ISDN phone calls to seize control of both ISDN bearer chan­nels. The protocol corrects any delays existing between the two bearer
channels and presents a single high-speed data channel to the DTE.
For successful high-speed operation, both the near- and far-end DCE
need to be configured to use the

BONDING mode 1

to allow transmission delays due to satellite hops, international calls,
etc. The timers may be adjusted if necessary by entering into the

BONDING mode 1

protocol allows the Express to communicate

BONDING mode 1

BONDING mode 1

protocol negotiation phase has numerous timers

submenu.

protocol, it must make two

protocol. The

V.120

V.120

The
provides DTE service between the Express and other V.120 compliant
devices at DTE rates less than the 64 kbps ISDN Bearer channel rate.
V.120 supports synchronous and asynchronous DTE rates. See the
section
page 1-4 for available V.120 rates.

protocol is a CCITT- compliant rate adaption method which

Recommended Operating Protocols

on page 1-3 and Table 1-1 on

V.110

V.110

The
provides DTE service between the Express and other V.110 compliant
devices. V.110 supports synchronous and asynchronous DTE rates.
See the section
ter 1) and Table 1-1 on page 1-4 for available V.110 rates.

protocol is a CCITT- compliant rate adaption method which

Recommended Operating Protocols

on page 1-3 (in Chap-

FALLBACK

FALLBACK

The
capability to automatically establish calls with other ISDN terminal
adapters, Switched 56 DSUs, PPP-compatible bridges/routers, as well

3-12 Express 3010/3110 User Manual 61200239L1-20

asynchronous rate-adaption protocol provides the

Chapter 3. Application Configuration

as other ISUs using a single configuration. This allows for integrating
services without changing the configuration on the Express.

The Express must be optioned as follows for FALLBACK operation:

• Any asynchronous bit rate up to 115.2 kbps which is supported

by the DTE.

• Flow control must be enabled and supported by the DTE.

FALLBACK supports the following protocols based on the call type:
BONDING mode 1, V.120, and PPP async-sync. When answering
calls, the Express uses the inco ming call type to determine which rate
adaption protocols to support.

When originating calls to unknown units, the ISU begins protocol se­lection based on the local call type. Data 64k is u sed for FALLBACK
selected from the
BONDING, V.120, and PP P async-sync are attempted. If connection
is not made at 64k, the Express attempts another call at 56k call type.
If connection is made at 56k, V.120, and PPP async-sync are attempted.

Profiles

menu. Upon connection at 64k call type,

Multilink Point-to-Point Protocol

This protocol allows the Express to dial a second number, establishing
a second point-to-point link. Once the second PPP is established, mul­tilink PPP is performed over both B-channels. The phone number for
the second call should be placed in stored number 1 (SN1). If no num­ber is stored in SN1, the same phone number dialed to establish the
first link is used for the second link.

PPP and STAC Compression

When set up to do compression, the Express will negotiate the com­pression control protocol (CCP) with the network PPP peer. If STAC
compression is successfully negotiated with the peer, data packets
from the DTE are compressed before being sent out the network. Like­wise, compressed packets from the network ar e decompressed before
being transmitted out the DTE.

61200239L1-20 Express 3010/3110 User Manual 3-13

Chapter 3. Application Configuration

CONFIGURING THE EXPRESS USING PRO­FILES (QUICK SETUP)

To configure the DTE Options quickly and easily, use the
menu to automatically set up the most common DTE configurations.
Press the number corresponding to

Profiles

the

Default Dial V120 asyn
Dial 56k Sync Dial Bond asyn
Dial 64k Sync Internet 64k
Dial 112k Sync Internet 128k
Dial 128k Sync Remote 64k
Leased 128k (Express 3010 only) Remote 128k
Ldm 128 Master (Express 3010

only)

For fine-tuning a particular application and DTE settings, see the sec-

Options for both Leased and Switched ISDN Service

tion
section provides detailed step-by-step processes for configuring the
DTE Options.

Most Internet service providers supporting ISDN also support PPP
protocol. If connecting to an Internet service provider using one B­channel, select
rangements have been made with the Internet service provider to use
two B-channels, select
col.

options:

Internet 64K,

Internet 128K

Profiles

which sets the protocol to PPP. If ar-

and press

Leased V.120 (Express
3010 only)

, which uses multilink PPP proto-

Profiles

Enter

to display

on page 3-8

.

This

Loading a factory profile has no effect on any SPID(s), ISDN Phone
Number(s), or Switch Type settings already configured. The settings
that are altered when applying a profile are shown on the following
pages.

3-14 Express 3010/3110 User Manual 61200239L1-20

Chapter 3. Application Configuration

Default (factory)

This option restores the Express to the following factory default setup:

Service type ISDN dial line
Automatic answering Enabled
ISDN call type Data 64k
Call screening Answer Any
Data protocol Clear Channel
DTE mode Synchronous
DTR option Ignore DTR
DTE flow control None

The Express can be reset to the factory default settings by setting
switch 2 to the off (up) position. See the section

Verify Switch Settings

on page 3-1 for more information.

Factory default erases all stored phone numbers, SPIDs, and LDNs.

61200239L1-20 Express 3010/3110 User Manual 3-15

Chapter 3. Application Configuration

Dial 56K sync

When the Express is configured for

Dial 56K sync

ing parameters are automatically preset:

Service type ISDN dial line
Automatic answering Enabled
ISDN call type 56 kbps data
Data protocol Clear channel
DTE mode Synchronous
DTE connector bit rate 56 kbps
DTE flow control None
Transmit data clock Normal

Dial 64K sync

When the Express is configured for

Dial 64K sync

ing parameters are automatically preset:

Service type ISDN dial line
Automatic answering Enabled
ISDN call type 64 kbps data
Data protocol Clear channel
DTE mode Synchronous
DTE connector bit rate 64 kbps
DTE flow control None
Transmit data clock Normal

service, the follow-

service, the follow-

3-16 Express 3010/3110 User Manual 61200239L1-20

Dial 112K sync

Chapter 3. Application Configuration

When the Express is configured for

Dial 112K sync

ing parameters are automatically preset:

Service type ISDN dial line
Automatic answering Enabled
ISDN call type 56 kbps data
Data protocol BONDING mode 1
DTE mode Synchronous
DTE connector bit rate 112 kbps
DTE flow control None
Transmit data clock Normal

Dial 128K sync

When the Express is configured for

Dial 128K sync

lowing parameters are automatically preset:

Service type ISDN dial line
Automatic answering Enabled
ISDN call type 64 kbps data
Data protocol BONDING mode 1
DTE mode Synchronous
DTE connector bit rate 128 kbps
DTE flow control None
Transmit data clock Normal

service, the follow-

service, the fol-

61200239L1-20 Express 3010/3110 User Manual 3-17

Chapter 3. Application Configuration

Leased 128k (Express 3010 only)

When the Express is configured for

Leased 128k

parameters are automatically preset:

Service type ISDN leased line
Automatic answering Enabled
ISDN call type Data 64k
Data Protocol Clear Channel
DTE mode Synchronous
DTR option Ignore DTR
DTE flow control No Flow Ctrl

Ldm 128 Master (Express 3010 only)

When the Express is configured for

Leased 128 Master

lowing parameters are automatically preset:

Service type ISDN leased line
Automatic answering Enabled
ISDN call type Data 64k
Data protocol V.120
DTE mode Asynchronous
DTR option Ignore DTR
DTE flow control Hardware

service, the following

service, the fol-

3-18 Express 3010/3110 User Manual 61200239L1-20

Dial V120 asyn

Chapter 3. Application Configuration

When the Express is configured for

Dial V120 asyn

lowing parameters are automatically preset:

Service type ISDN dial line
Automatic answering Enabled
ISDN call type 64 kbps data
Data Protocol V.120
DTE mode Asynchronous
DTE connector bit rate Hardware
DTR option Ignore DTR
DTE flow control Hardware

Dial Bond asyn

When the Express is configured for

Dial Bond asyn

lowing parameters are automatically preset:

Service type ISDN dial line
Automatic answering Enabled
ISDN call type Data 64k
Data protocol Bonding Mode 1
DTE mode Asynchronous
DTR option Ignore DTR
DTE flow control Hardware

service, the fol-

service, the fol-

61200239L1-20 Express 3010/3110 User Manual 3-19

Chapter 3. Application Configuration

Internet 64K

When the Express is configured for

Internet 64K

ing parameters are automatically preset:

Service type ISDN dial line
Automatic answering Enabled
ISDN call type 64 kbps data
Data protocol PPP asyn-sync
PPP Mode PPP
DTE mode Asynchronous
DTR option Ignore DTR
DTE flow control Hardware

Internet 128K

When the Express is configured for

Internet 128K

ing parameters are automatically preset:

Service type ISDN dial line
Automatic answering Enabled
ISDN call type 64 kbps data
Data protocol PPP asyn-sync
PPP Mode Multilink PPP
DTE mode Asynchronous
DTR Options Ignore DTR
DTE flow control Hardware

service, the follow-

service, the follow-

3-20 Express 3010/3110 User Manual 61200239L1-20

Remote 64K

Chapter 3. Application Configuration

When the Express is configured for

Remote 64K

ing parameters are automatically preset:

Service type ISDN dial line
Automatic answering Enabled
ISDN call type 64 kbps data
Data protocol V.120
DTE mode Asynchronous
DTR Options Ignore DTR
DTE flow control Hardware
Transmit data clock Normal

Remote 128K

When the Express is configured for

Remote 128K

ing parameters are automatically preset:

Service type ISDN dial line
Automatic answering Enabled
ISDN call type 64 kbps data
Data protocol Bonding Mode 1
DTE mode Asynchronous
DTR Options Ignore DTR
DTE flow control Hardware

service, the follow-

service, the follow-

61200239L1-20 Express 3010/3110 User Manual 3-21

Chapter 3. Application Configuration

Leased V120 (Express 3010 only)

When the Express is configured for

Remote 128K

ing parameters are automatically preset:

Service type ISDN leased line
Automatic answering Enabled
ISDN call type 64 kbps data
Data protocol V.120
DTE mode Asynchronous
DTR Options Ignore DTR
DTE flow control Hardware

service, the follow-

3-22 Express 3010/3110 User Manual 61200239L1-20

Chapter 3. Application Configuration

CONFIGURING THE EXPRESS FOR V.25 BIS
IN-BAND DIALING

V.25 bis dialing is used primarily by DTE with synchronous interfaces.
The Express supports the following V.25 bis commands to control au­tomatic calling and answering:

CRN Call request (number in command)
CRS Call request (using stored number)
PRN Program stored number
RLN List stored number
CIC Connect incoming call
DIC Disconnect incoming call

When using stored numbers V.25 bis accesses stored numbers 1
through 9. See the section VT 100 Terminal Dialing Options on
page 3-6.

SYNC V.25 Dialing

V.25 bis specifies that the characters should be ASCII, 7 bits, with even
parity, and one stop bit. However, for versatility the Express allows
the data bits, parity, and stop bits to be changed as defined under
format.

Data

This setting allows for V.25 bis messages in asynchronous (start/stop)
data format.

In synchronous mode, the Exp ress is an IS DN ve r si on of a syn c hronous
modem. For configu rat ion o r troubleshooting, t he un it requires
connection to an async VT 100 terminal and the dial option must be set
to AT Commands. After the unit i s completely configu r ed, set the dial
option to V.25 bis and exit the VT 100 terminal interface. The unit is
now ready to respond to V.25 bis dialing commands. If it is necessary to
reenter the VT 100 interface for re -configuration, tr ouble shooting or to
view the status buffer , perform the foll owing steps: (1) power the unit off,
(2) set dip switch 2 to off (up) for factory default AT commands, (3)
powe r t h e u nit back on, (4 ) set d i p s w i tch 2 t o o n ( d own), a n d (5) type

to activate the terminal interface.

AT!V

61200239L1-20 Express 3010/3110 User Manual 3-23

Chapter 3. Application Configuration

SYNC V.25 HDLC Dialing

Although V.25 bis allows asynchronous data format, asynchronous
DTE is more likely to support the AT command set than V.25 bis.

This sett ing provi des V.25 bi s messages in bit-sy nchronous format (fo r
example, HDLC, SDLC, X.25). The bit-synchronous format is the most
commonly used by V.25 bis.

This option specifies that the characters should be 7-bit ASCII, with
the 8th bit ignored (it may be either 0 or 1).

The first byte of each packet contains all one bits (A = FF HEX), and
the second byte of each packet (the C byte) is either 13 HEX or 03 HEX
if not the final packet.

Select V.25 HDLC flags if your terminal equipment requires idle
state flags.

SYNC V.25 BISYNC Dialing

This setting allows for V.25 bis messages in byte-synchronous format
(BISYNC). V.25 bis specifies that the characters should be ASCII, 7
bits, and odd parity. This setting allows synchronous DTE which does
not use HDLC to support serial in-band dialing.

3-24 Express 3010/3110 User Manual 61200239L1-20

THE STATUS BUFFER

Chapter 3. Application Configuration

The status buffer is discussed in the section
on page 3-4.

Configure the Express 3010

TEST OPTIONS

Ctrl+T

Press
vides the following test options:

1. Test Remote

2. Loopback Protocol

3. Lpbk Proto Timeout=1 min

4. Loopback Disable = V54 Accepted

5. NEBE/FEBE

Press the number corresponding to the desired option and press
to select an option.

Test Remote

This test causes the Express to issue a V.54 inband loopback command
to a far-end unit and BERT test the link using a built-in pattern gener­ator/checker. This allows a circuit to be tested without any extra test
equipment. To use this feature, both units must be configured for
Clear Channel operation and the f ar-end unit must be able to respond
to V.54 loopback commands. See the section
page 3-10 to configure the unit for Clear Channel operation. The built­in 2047 pattern generator/checker displays the number of bytes trans­mitted on the top line and the number of errored bytes received on the
lower line of the front panel display. Pressing
Pressing

to display the Express Test menu screen. The Express pro-

Setting Protocol Options

0

clears the counts.

Cancel

ends the test.

Enter

on

61200239L1-20 Express 3010/3110 User Manual 3-25

Chapter 3. Application Configuration

Loopback Protocol

This option allows data to be looped back toward the network after
passing through a selected protocol such as BONDING. See Figure 3­1 for loopback points.

NETWORK

NET

IFCE

Network

RATE

ADAPTION

Protocol

DTE

DTE

IFCE

DTE

Figure 3-1. Express Loopback Points

Lpbk Proto Timeout = 1 min

This option sets the length of time for the loopback protocol test.

Loopback Disable = V54 Accepted

The Express responds to V.54 loopback commands.

Near-End Block Errors/Far-End Block Errors (NEBE/FEBE)
(Express 3010)

Use this test to determine the quality of the network connection by
viewing the number of near-end block errors (NEBE) and far-end
block errors (FEBE) occurring on the ISDN U-interface. A large count
indicates problems with network equipment.

3-26 Express 3010/3110 User Manual 61200239L1-20

Chapter 4

As features are added to the Express, software upgrades may be nec­essary. The Express has flash memory allowing the software to be up­graded from a file provided by ADTRAN. The current version of the
software can be found on the Status menu in the VT 100 Terminal Em­ulation menu s.

The software can be upgraded using HyperTerminal or any terminal
emulation package supporting the XMODEM or XMODEM 1K proto­cols. Please proceed to the appropriate section for further instruction.

If a terminal emulation package other than HyperTerminal is selected,
please see the instructions supplied with the package to set up an
XMODEM or XMODEM 1K connection.

Upgrading Software

Using HyperTerminal to Upgrade Software

1. Download the necessary upgrade files from the ADTRAN web

site (www.adtran.com).

2. From the

ries

3. Wh en the

connection name, select an icon, and click OK.

4. In the

Express is connected in the

5. The

Bits per second

6. You are now connected. Next type

the firmware update. The AT command will not be visible since
echo is off by default. To enable echo, type

7. Click on the

8. Click

Express.

Start

button, choose

HyperTerminal

, then

Connection Description

Connect To

COM port Properties

Browse

window, select the COM port to which the

field to

Transfer

to locate the directory and file to download to the

menu; then click

Programs

.

Connect using

window appears next. Change the

57600

and click OK.

; then choose

window appears, type in a

field and click OK.

AT!FLASHLOAD

ATE1

Send File…

Accesso-

to initiate

.

.

61200239L1-20 Express 3010/3110 User Manual 4-1

Chapter 4. Upgrading Software

9. Change the

Protocol

1K Xmodem

to

and click

Send

.

10. Once the download is complete, exit HyperTerminal, saving the
session if desired.

The software upgrade is now complete. If the PWR/LINE, B1 and B2
LEDs are flashing, the software upgrade failed. See

Troubleshooting

on

page 6-1 if the software upgrade failed.

4-2 Express 3010/3110 User Manual 61200239L1-20

Chapter 5

Installing an Analog Modem

INTERNAL ANALOG MODEM APPLICATION

In order to connect an internal analog modem to the Express the fol­lowing items are necessary:

• Internal analog modem

• RJ-11 to RJ-11 telephone cable

Figure 5-1 shows how to connect an internal modem to the Express.

Figure 5-1. Internal Analog Modem Application

61200239L1-20 Express 3010/3110 User Manual 5-1

Chapter 5. Installing an Analog Modem

When using an internal analog modem and the Express, two COM
ports are assigned on the PC. Both COM ports are configured inde­pendently. See the manufacturer's documentation for internal analog
modem configuration.

Connecting an Internal Analog Modem

To connect an internal analog modem to the Express, use the follow­ing procedure:

1. Ensure the Express is connected to the PC.

2. Connect one end of the RJ-11 to RJ-11 telephone cable to the tele­phone jack labeled 2 on the Express. Positioned above the jack is
an illustration of a telephone above a modem.

3. Connect the other end of the RJ-11 to RJ-11 telephone cable to the

Dial Line

See the documentation for the internal analog modem to determine
which jack on the internal analog modem is the Dial Line or Line
jack.

Line jack

or

on the internal analog modem.

5-2 Express 3010/3110 User Manual 61200239L1-20

Chapter 6

Troubleshooting

TROUBLESHOOTING GUIDELINES

This section provides troubleshooting techniques to resolve problems
that may be encountered while operating the Express. If problems
persist contact ADTRAN technical support for assistance (see the in­side back cover of this manual).

Power/Line LED is Off

This indicates a problem with the power to the unit. Verify the power
cord is connected to the Express and is plugged into a working 120
volt AC electrical outlet.

P ower/Line LED Flashes and 1 and 2 LEDs are
Off

This indicates a problem with the physical connection of the ISDN line
from the local telephone company to the Express.

1. Verify the large end of the RJ-45 to RJ-11 telephone cable

(included with the Express) is connected to the ISDN connector
on the rear panel of the Express.

2. Verify the small end of the RJ-45 to RJ-11 telephone cable is con-

nected to the ISDN telephone wall jack installed with Basic Rate
ISDN.

3. Contact the local telephone service provider.

61200239L1-20 Express 3010/3110 User Manual 6-1

Chapter 6. Troubleshooting

Power/Line LED, 1, and 2 LEDs Flash Green

This indicates a configuration problem. Verify the following informa­tion is correct:

•Switch Type

• Service Profile Identifiers (SPIDs)

• ISDN Phone Numbers

This information can be viewed by using the Express Configuration
program or the Configuration Screen in the VT 100 menu system. The
Link Status should indicate
correct and the unit is properly connected. If the link status is good
and calls still cannot be placed, review the section

Problems

(below).

Link Up

if all configuration information is

Dial-Up Connection

Auto-Detect can be enabled at the
in the Configuration screen of the VT 100 menus to automatically de­tect the SPIDs and the Switch Type.

Look for the following with the COM port setup:

• IRQ conflicts

• Wrong DTE speed

Power/Line LED, 1, and 2 LEDs flash green sequentially. After a
software upgrade, if the Power/Line, 1 and 2 LEDs flash green in
sequence, a problem occurred. Restart the download using the
instructions in Chapter 4. If the download fails a second time, contact
ADTRAN technical support.

Auto-Detect SPIDs/Switch

option

Dial-Up Connection Problems

Many connection problems can be diagnosed by viewing the status
buffer message returned from the ISDN network and the Express.
These messages are accessed by choosing the

Diagnostics

the

tab of the ADTRAN Express Configuration window.

Status Buffer

button in

6-2 Express 3010/3110 User Manual 61200239L1-20

Chapter 6. Troubleshooting

The Status buffer can also be accessed using the key sequence
in the VT 100 menu system. Issue the AT command
minal emulation package such as HyperTerminal to invoke the VT 10 0
menu system.

Ensure the following to verify the correct protocol is selected:

• PPP or V.120 generally for Internet applications

• V.120 or Multilink PPP for work-at-home

AT!V

Ctrl+V

from a ter-

Auto-detect Switch/SPIDs Remains at Link
Down

The Link Down condition persisti ng for longer than fiv e minu tes indi­cates a problem with the ISDN line provided from the telephone compa­ny. The ISDN physical layer device has not been able to sync hronize to
the network. Ensure that the RJ-45 to RJ-11 telephone cable is correctly in­stalled between the Express and the ISDN wall jack and that the Express
is powered on. If the wall jack does not have ISDN installed on the two
middle pins (tip, ring), the Express will never synchronize t o the tele­phone switching equipment. Call the local telephone company and hav e
them check the ISDN line for correct operation.

Express Not Detected

If the Express Configuration program cannot detect the Express, veri­fy the following:

1. The Express is powered on.

2. No other applications are running that could be using the COM

port to which the Express is attached. A Windows application
does not have to be active to tie up a COM port. Be sure to check
the Windows 95/98 Taskbar for any suspended applications
(such as HyperTerminal) that may be using the COM port. If any
are minimized, these must be closed before starting the Express
Configuration program.

3. If you are operating at 230.4 kbps, Switch 1 to Off (up). Also, con-

firm that the computer has a 16650 UAR T.

61200239L1-20 Express 3010/3110 User Manual 6-3

Chapter 6. Troubleshooting

Difficulty with 230.4 kbps Operation

If the Express does not work when the DTE rate is set to 230.4 kbps in­side Windows, verify the following:

1. Verify that switch 1 on the back of the Express is set to Off (up).

2. Verify that a high speed serial card with a 16650 UART is being
used and the software drivers to support the extended baud rate
tables are installed.

Dial-Up Networking Difficulty

If Windows 95/98 Dial-Up Networking cannot talk to the Express,
check the modem configuration for the Express. Ensure the bit rate for
the DTE is set correctly. If the PC is not equipped with a 16650 UART,
then the fastest DTE operation speed is 115.2 kbps. Ensure the speed
is not higher than the PC and modem can support.

6-4 Express 3010/3110 User Manual 61200239L1-20

Appendix A

While a call is not established, the DTE port accepts AT co mmands.
During this time, the CD signal is inactive. When a call is established,
the port is used for data. This data mode is indicated by the CD signal
active. The Express can be configured and controlled with AT com­mands from a serial port similarly to analog modems.

To exit data mode and enter command mode, the serial port must
transmit a proper escape sequence to the Express. A specified time de­lay must occur between the last data character and the first escape se­quence character. This is the guard time delay, and it can be changed
by writing a value to the S12 register. The default value for the guard
time is one second. For a valid escape sequence to occur, the DTE
must transmit the escape code character three times in succession with
delay between each character being less than the guard time. The de­fault escape sequence is

Once command mode is entered, AT commands can be transmitted to
the Express to configure most of the options, dial remote Expresss, or
initiate tests to check the Express and the network connections. All
command lines must begin with the AT character set in either capital
or lower case letters. To return an active call to the on-line state type

ATO

.

AT Commands and S-Registers

+++

.

Commands may be separated with spaces for readability. The maxi­mum length for a command lin e is 40 characters. Each comm and line
is executed by the Express upon receipt of a terminating character.
The default terminating character is a carriage return (ASCII 013), but
it can be changed by writing a different value to r egister S3. Before the
terminating character is transmitted, the command line can be edited
by using the backspace character (ASCII 008) to erase errors so the
proper commands can be entered.

61200239L1-20 Express 3010/3110 User Manual A-1

Appendix A. AT Commands and S-Registers

Using an AT Command

Type AT followed by the letter of the command and numeric value of
the setting desired and then press
turns the software version of the unit:

ATI1

Enter

. The following command re-

Using S-Registers

The configuration of the Express can be changed or reviewed with S­registers. See the section
of each S-register and its corresponding range of values.

S-Register List

on page A-9 for a description

Reading an S-Register

ATS

Type
lowed by a question mark and press

followed by the number of the S-register to be read fol-

Enter

.

ATS0?

Reading an S-Register String

The Express uses S-register strings to store strings of digits for stored

,

ATSS

phone numbers, SPIDs, etc. Type
string S-register to be read, followed by a question mark, and press

.

ter

ATSS80?

followed by the number of the

En-

Changing an S-Register

,

ATS

Type
lowed by an equal sign, followed by the numeric value to be assigned
to the register, and press

A-2 Express 3010/3110 User Manual 61200239L1-20

followed by the nu mber of the S-register to be changed, fol-

Enter

.

ATS0=2

Appendix A. AT Commands and S-Registers

Changing a String S-Register

,

ATSS

Type
followed by an equal sign, followed by the numeric value to be as­signed to the register, and press

Dialing a Call using the AT Command Processor

followed by the number of the S-register to be changed,

Enter

.

ATSS80=5551212

To dial a call using the DTE terminal and AT commands, type

,

DT

ATDP

or

and the telephone number on one line; then press

ATD, AT-

Enter

ATD5551212

To end an active call with the AT command processor, press the break
in key sequence

Enter

to hang up the lin e.

+++

or the redefined key; then type

ATH

and press

Command Function

A Answer. Places the Express in answer mode.
AT!S Displays Status Buffer.
AT!S1 Displays Link Status
AT!V Configuration Menu
D Dial. Prece d es the telephone access number

[ATD5551212].
DS Dial a stored number [DS3].
H Hang up. Disconnects the current call.
I0 Identify unit. Commands the unit to display model

number .

.

I1 Identify software. Commands the unit to display

software version.
O On-line. Commands the unit to go back on line

61200239L1-20 Express 3010/3110 User Manual A-3

Appendix A. AT Commands and S-Registers

S S Register.
SS S String register.
_Z Reset. Resets the AT command processor.
&W Save. Save current configuration to EEPROM.
_U Resets ISDN interface.
!S Dumps status buffer contents to the DTE port.
+++ Break in. Break in A T command processor during an

active call. The break in key is defined in S2.
Carrier Detect (CD) Control Line Options
&C0

CD forced on.

&C1 CD normal.
&C2 CD off with local disconnect (LOCD)
&C3 CD off with link down.
Data Terminal Ready (DTR Control Line Options)
&D0 Ignore DTR
&D1 DTR off forces command.
&D2 Idle when off. DTR off forces idle (On allows auto

answer).

Generic Unit Configurations
&F0 Default
&F1 Configures unit for Dial 56k sync
&F2 Configures unit for Dial 64k sync
&F3 Configures unit for Dial 112k sync
&F4 Configures unit for Dial 128k sync

A-4 Express 3010/3110 User Manual 61200239L1-20

Appendix A. AT Commands and S-Registers

&F5 Configures unit for Leased 128k (not in S/T unit)
&F6 Configures unit for Ldm 128k Master (not in S/T

unit)
&F7 Configures unit for V120 async
&F8 Configures unit for Dial Bond async
&F9 Configures unit for Internet 64k
&F10 Configures unit for Internet 128k
&F11 Configures unit for Remote 64k
&F12 Configures unit for Remote 128k
&F13 Configures unit for Leased V120
Network Options
&L0 Dial network
&L1 Leased network (not in S/T unit)
&L2 Leased, backed up by dial network
Calling Number Identifiers
&N0 Number 1. Read far-end phone number 1 if service

subscribed from telephone company.
&N1 Number 2. Read far-end phone number 2 if service

subscribed from telephone company.
DTE Data Type Options
&Q0 DTE is async
&Q1 DTE is sync
Clear-To-Send (CTS) Control Line Options
&R0 Follows RTS
&R1 Forced CTS

61200239L1-20 Express 3010/3110 User Manual A-5

Appendix A. AT Commands and S-Registers

Data Set Ready (DSR) Control Line Options
&S0 DSR forced on
&S1 DSR if call up
&S2 DSR off if link down
&S3 DSR off if dial up
DTE Connector Data Synchronous Data Clocking Options
&X0 Internal transmit clock
&X1 External transmit clock
Accessing Stored numbers for Dialing Options*
&Z0 Stored number 0
&Z1 Stored number 1
&Z2 Stored number 2
&Z3 Stored number 3
&Z4 Stored number 4
&Z5 Stored number 5
&Z6 Stored number 6
&Z7 Stored number 7
&Z8 Stored number 8
&Z9 Stored number 9
Local Echo Options
E0 Echo off. Does not allow command characters

typed to be displayed on the screen.

E1 Echo on. Allows the command characters typed to

be displayed on the screen.

A-6 Express 3010/3110 User Manual 61200239L1-20

Appendix A. AT Commands and S-Registers

Unit Identification
I0 Identifies unit. Commands the unit to display model

number.
I1 Identifies software. Commands the unit to display

software version.
I2 Identifies lists.
AT Command Response Message Options
AT Command Response Message Types
V0 Numeric response messages
V1 Verbal response messages
AT Command Connect Message Options
X0 Simple connect message
X1-7 Connect messages with bit rate
Ready-To-Send (RTS) Control Line Options
_D0 1 mS delay
_D1 18 mS delay

MakeBusy
Options

_B0 Make DTE port not busy (same as S135=0)
_B1 Make DTE port busy (same as S135=1)
Service Profile Identification (SPID) Options
_I0 Access SPID1 for DTE #1
_I1 Access SPID2 for DTE #2

61200239L1-20 Express 3010/3110 User Manual A-7

Appendix A. AT Commands and S-Registers

Local Directory Number (LDN) Access Options
_N0 Access LDN1 for DTE #1
_N1 Access LDN2 for DTE #2
ISDN Switch Ty pe Options
_S0 5ESS
_S1 DMS-100
_S2 National ISDN-1
_S3 NEC
_S4 EuroISDN
ISDN U-interface Operational Mode Options
_X0 Express timing slaves to network (NT mode)
_X1 Express is U-interface timing master (LT mode)
_Z Resets unit.
Data Flow Control Options
\Q0 No flow control
\Q1 Software flow control (XON/XOFF)
\Q2 CTS only
\Q3 Hardware flow control (RTS/CTS) factory default
\Q4 Software from DCE only

A-8 Express 3010/3110 User Manual 61200239L1-20

Appendix A. AT Commands and S-Registers

S-REGISTER LIST

Defaults appear in bold type in the third column.

S0 AUTO ANSWER Determines how the Express answers an

incoming call.

0

= Disable (Express does not answer call).
1 = Enable (Express answers all calls).
2 = Dump all calls.

S2 ESCAPE

CHARACTER

S3 END OF LINE

CHARACTER

S4 LINE FEED

CHARACTER

S5 BACK SPACE

CHARACTER

S7 CONNECT

TIME

Determines which key or character (in ASCII
code) defines the escape command. The
standard escape character is a plus
(ASCII value of 43 decimal). To change the
character set, set S2 to the desired ASCII value.
Range = 0 to 127

Determines which key or character (in
ASCII code) ends a command line. The
standard end-of-line character is the carriage
return (ASCII value of 13 decimal).
Range = 0 to 127

Determines which key or character (in
ASCII code) advances the cursor to the next line
after ending a command line or after an
Express message. The standard character is the
line feed (ASCII value of 10 decimal).
Range = 0 to 127

Determines which key moves the cursor back
one space to erase a character. The standard
character is the backspace (ASCII value of 8
decimal).
Range = 0 to 127

Determines how long the Express waits for an
outgoing call to be answered.
15 = 15 seconds

30

= 30 seconds
60 = 1 minute
120 = 2 minutes
240 = 4 minutes

(+)

sign

61200239L1-20 Express 3010/3110 User Manual A-9

Appendix A. AT Commands and S-Registers

S12 ESCAPE TIME Determines the delay required immediately

before and after entering the escape command
for the Express to recognize and execute the
command.
Range = 0 to 127 (Default =

50

)

S13 AutoSpid

Download

0 = Enabled
1 = Disabled

S14 MISC BITS Miscellaneous bits (bit 8 is most significant bit).

Bit 2 = 1:Enables on screen echo of AT
commands.
Bit 2 = 0:Disables on screen echo of AT
commands.
Bit 3 = 0:Enables AT responses from the
Express.
Bit 3 = 1:Disables AT responses from the
Express.
Bit 4 = 1:Enables AT responses to be displayed
in text form.
Bit 4 = 0:Enables AT responses to be displayed
in numeric form.
Bit 7 = 1:Disable PPP ACCM spoofing.
Bit 7 = 0:Enable PPP ACCM spoofing.
Bit 8 = 1:Ring indicator uses cadence.
Bit 8 = 0:Ring indicator remains on.

S15 ASYNC

BONDING

Asynchronou s BO ND ING method.

0

= ADTRAN revision 0 (default)

1 = Multi-vendor option

S22 MSG BITS Miscellaneous message bits (bit 8 is most

significant bit).
Bit 5= Bit 6 = Bit 7 = 1 Allows connect
message with baud rate.
Bit 5= Bit 6 = Bit 7 = 0 Connect message
without baud rate.

S24 V120 LLC Enables/disables V120 lower layer

compatibility (LLC).

0

= Enabled

1 = Disabled

A-10 Express 3010/3110 User Manual 61200239L1-20

Appendix A. AT Commands and S-Registers

S25 DTR DETECT

TIME

Determines time, in hundredths of a second,
that must elapse before the Express recognizes
a change in DTR.
Range = 0 to 255 (Default = 5)

S26 VOICE DEFAULT Determines the speed at which an audio call is

received

0

= 56k speech/audio to DTE port

1 = 64k speech/audio to DTE port

S27 PPP MODE Value determines whether or not PPP will be a

single-link or multilink connection.

0

=Single-link operation (default)
1=Multilink operation
2=Use compression

S30 DTE CTS Controls the operation of the DTE connector

CTS line.

0

=Follows RTS
1=Force CTS

S31 DTE RTS Controls operation of the RTS line.

0

=1 ms delay
17=18 ms delay

S32 DTE DSR Controls the operation of the Data Set Ready

signal on the DTE connectors.

0

=Force DSR on always
1=DSR off OOS + Test
2=DSR off Link Down

S33 DTE CD Controls the operation of the Carrier Detect line

on the DTE connectors.

0

=Force CD on always
1=CD is active during a call (Normal
Operation)
2=Off with LOCD
3=Off link down

61200239L1-20 Express 3010/3110 User Manual A-11

Appendix A. AT Commands and S-Registers

S34 DTE DTR Determines how the Express responds to

changes in DTR. This is a bit-mapped register.

0

=Ignore DTR
1=Force AT command mode when DTR is off
2=Dump incoming call when DTR is off
4=Hang up incoming call when DTR is off
8=Hang up outgoing call when DTR is off
16=Answer incoming call when DTR is on
32=Dial SN0 when DTR is on
64=Dial SN0 when DTR transitions from off to
on

S46 V25 MODE Selects the type of V.25 bis dialing used.

0

=Asynchronous V.25
1=HDLC V.25
2=BISYNC V.25
3=HDLC with flags V.25

S50 LINE MODE Selects the operating mode of the Express.

0

=Dial service (switched service)
1=Leased service (nonswitched service)

S51 LINE CLOCK Selects the clock mode in leased mode.

0

=Slave (default)
1=Master (Leased line only, limited distance
MODEM application only)

S52 SWITCH TYPE Selects the network switch type for dial service.

0=AT&T 5ESS
1=Northern Telecom DMS-100

2

=National ISDN-1
3=NEC
4=EuroISDN (BT) (3110 only)

S53 CALL TYPE Call type (Dial service only).

0=Speech
1=Audio
2=56 Kbps data

3

=64 Kbps data

A-12 Express 3010/3110 User Manual 61200239L1-20

Appendix A. AT Commands and S-Registers

S54 PROTOCOL

TYPE

Rate adaption protocol type.
1=Clear Channel
2=Bonding
5=V.110
6=V.120

11

=Fallback

12=PPP

S55 DIAL MODE Selects dialing interface.

0=None

2

=AT commands

3=V.25 bis dialing

S56 ECHO TONE Enables an echo tone which suppresses the

echo cancellers in a voice circuit. Can be used
to trick the switch to allow sending data over a
line optioned for voice ISDN service.

0

=None
1=Answer
2=Originate
3=Both

S58 CALL

SCREENING

Allows the Express to screen incoming calls.

0

=Answer any call
1=Answer only calls from numbers matching
those stored in SN0 through SN9.

S59 CHANNEL RATE Sets the available network bandwidth when the

Express is in leased mode.

1

=64 kbps
2=128 kbps

SS60 SPID1 LOC SPID string location.
SS61 SPID2 LOC SPID string location.
SS62 LDN1 LOC ISDN phone number string location.
SS63 LDN2 LOC ISDN phone number string location
S65 AUTOSPID Sets the AutoSpid determination feature.

0

=Disable (default)
1=Enable

SS67 AREA CODE Area code location.

61200239L1-20 Express 3010/3110 User Manual A-13

Appendix A. AT Commands and S-Registers

S70 DTE MODE Selects asynchronous or synchronous mode on

the DTE connector.
0=Asynchronous

1

=Synchronous

S71 DTE RATE Selects the DTE connector bit rate.

3 = 1200
6 = 2400
8 = 4800
11 = 9600
15 = 19200
17= 38400
18 = 48000
19 = 56000

20

= 57600
21 = 64000
22 = 112000
23 = 115200
24 = 128000
25 = 230400

S72 DATA BITS Selects the number of asynchronous data bits.

0

= 8 bits

1 = 7 bits

S73 DTE PARITY Selects the number of asynchronous parity bits.

0

=None
1=Odd
2=Even

S74 DTE STOP Selects the number of asynchronous parity bits.

0

=None
1=Odd
2=Even

S75 DTE FLOW Selects asynchronous flow control.

0=None
1=XON/OFF from DTE controls DCE
2=XON/OFF from DCE controls DTE

3

=Hardware
12=Software

A-14 Express 3010/3110 User Manual 61200239L1-20

Appendix A. AT Commands and S-Registers

S76 DTE CLOCK Selects DTE connector transmit clock timing

source.

0

=Normal (Express supplies timing)

1=External (DTE supplies timing)

S77 REMOTE

NUMERIC

Numeric password string for remote
configuration.

PASSWORD
The following are the string locations for stored numbers 0 - 9:
SS80 SN0 LOC Stored number 0 string
SS81 SN1 LOC Stored number 1 string. Used for second

number dialed in a multilink connection.
SS82 SN2 LOC Stored number 2 string
SS83 SN3 LOC Stored number 3 string
SS84 SN4 LOC Stored number 4 string
SS85 SN5 LOC Stored number 5 string
SS86 SN6 LOC Stored number 6 string
SS87 SN7 LOC Stored number 7 string
SS88 SN8 LOC Stored number 8 string
SS89 SN9 LOC Stored number 9 string
S90 CONFERENCE IDNI-1 feature identification number for

conferencing. See the ISDN service provider

for this ID.
S91 TRANSFER ID NI-1 feature identification number for

transferring. See the ISDN service provider for

this ID.
S92 MESSAGE

WAITING ID

NI-1 feature identification number for message

waiting indicator. See the ISDN service

provider for this ID.
S93 CALL TYPE

ROUTING

Determines how incoming call is routed when

connected to a point-to-point ISDN line.

0=Route all call types to DTE

61200239L1-20 Express 3010/3110 User Manual A-15

Appendix A. AT Commands and S-Registers

S-REGISTER STRING LIST

SS60 SPID1 LOC
SS61 SPID2 LOC
SS62 LDN1 LOC
SS63 LDN2 LOC
SS67 AREA CODE
SS77 REMOTE

NUMERIC

PASSWORD
SS80 SN0 LOC
SS81 SN1 LOC

SS82 SN2 LOC
SS83 SN3 LOC
SS84 SN4 LOC
SS85 SN5 LOC
SS86 SN6 LOC
SS87 SN7 LOC
SS88 SN8 LOC
SS89 SN9 LOC
SS130 CR0 LOC
SS131 CR1 LOC
SS132 CR2 LOC
SS133 CR3 LOC
SS134 CR4 LOC
SS135 CR5 LOC
SS136 CR6 LOC
SS137 CR7 LOC
SS138 CR8 LOC
SS139 CR9 LOC

SPID string loc ation.
SPID string loc ation.
ISDN phone number string location.
ISDN phone number string location
Area code location.
Numeric password string for remote configura-

tion.

Stored number 0 string
Stored number 1 string. Used fo r second number

dialed in a multilink connection.
Stored number 2 string
Stored number 3 string
Stored number 4 string
Stored number 5 string
Stored number 6 string
Stored number 7 string
Stored number 8 string
Stored number 9 string
Call Reject List Number 0
Call Reject List Number 1
Call Reject List Number 2
Call Reject List Number 3
Call Reject List Number 4
Call Reject List Number 5
Call Reject List Number 6
Call Reject List Number 7
Call Reject List Number 8
Call Reject List Number 9

A-16 Express 3010/3110 User Manual 61200239L1-20

Appendix B

LEDs

LEDS

The Express 3010 front panel contains five LEDs associated with the
DTE port and the ISDN interface as shown in Figure B-1 and described
below.

TD RD

Express 30 10

12

Figure B-1. Front Panel LEDs

LED Color Description

TD Green Transmit Data (TxD)
RD Green Received Data (RxD)
1 or 2 Slow Green

Flash
Fast Green Flash Attempting TEI registration.
Solid Green POTS 1 or 2 in use.
Off Ready. No data traffic.
Amber Flash B channel 1 or 2 passing data.
Solid Amber Remote test originate.

PWR/
LINE

Green (On
Solid)
Off
Flashing

Attempting SPID re gist ra t ion.

Link Established. Calls can be placed.
No Power.
Link is not established. Calls cannot be
placed.

PHONE

PWR

LINE

61200239L1-20 Express 3010/3110 User Manual B-1

Appendix B. LEDs

B-2 Express 3010/3110 User Manual 61200239L1-20

Appendix C

2047 BERT orig

Test remote originated 2047 BERT (bit error rate test) pattern.

2047 loopbk ansr

Test remote answered 2047 BERT pattern.

Answer

The Express answered a call on either the first or second channel. The
calling phone number is displayed if available.

ACCESS_INFO_DISCARDED

The network was unable to deliver access information to the far end.

Area Code Req'd

Area code required for Auto Spid determination.

AutoSpid Active

Status Buffer Messages

Unit is attempting automatic detection of switch type and SPID num­bers.

AutoSpid Disable

The user has stopped the automatic SPID detection process.

AutoSpid Failed

Automatic determination of switch type and SPID numbers failed.

61200239L1-20 Express 3010/3110 User Manual C-1

Appendix C. Status Buffer Messages

AutoSpid Passed

Automatic determination of switch type and SPID numbers succeed­ed.

AutoSwitch YYY

Switch type YYY detected during AutoSpid determination. (YYY can
be DMS, NI-1, or AT&T.)

Back to online

Express went back online.

Bad async BPS

The Bonding protocol determined that the selected asynchronous bit
rate is not supported.

Bad AT numeric

User issued an AT command with an argument that was out of range.

Bad call type

Express placed a call with an improper call type.

Bad DTE Baud

The DTE bit rate does not match a valid bit rate for the protocol select­ed.

BAD_INFO_ELEM

Call control error.

Bad phone number

Express 3010 attempted to call an invalid phone n umber.

C-2 Express 3010/3110 User Manual 61200239L1-20

Appendix C. Status Buffer Messages

BEAR_CAP_NOT_AVAIL

The bearer channel requested is not available.

BEARER_CAP_NOT_AUTH

Bearer capability requested is not authorized.

Bearer Mode?

Incoming call is not of a type the Express 3010 can accept.

Bearer Info Cap?

Incoming call information transfer capability is not known.

BONDING (+/-XXX)

The amount of bytes or corrected delay between the B2 a nd B1 Bearer
channels (XXX can range from -8000 to +8128).

BPS mismatch

Bonding negotiation found a bit rate mismatch.

Break to AT cmd

User issued a break-in request.

Break ignored

User issued an extra break-in request.

BUSY

The called number is busy.

B-X disconnected

B-channel disconnected. X can be 1 or 2 representing the appropriate
B-channel.

61200239L1-20 Express 3010/3110 User Manual C-3

Appendix C. Status Buffer Messages

CallID 1 in use

The Express 3010 tried to place a call using SPID 1 when SPID 1 was
already in use.

CallID 2 in use

The Express tried to place a call using SPID 2 when SPID 2 was already
in use.

Call lost

Held call could not be retrieved.

Call not ringing

User executed an answer command (ATA) but there was not a call
present.

CALL_REJECTED

The call has been rejected by the ISDN network.

Can't go online

Express 3010 cannot go back on line. Unknown AT command user is­sued an unknown AT command.

CHAN_DOES_NOT_EXIST

The user asked for a bearer channel that is not present.

CHAN_NOT_IMPLEMENTED

The network or far end does not support the bearer capability request­ed.

CHANNEL_UNACCEPT ABLE

The channel requested has not been subscribed.

C-4 Express 3010/3110 User Manual 61200239L1-20

Appendix C. Status Buffer Messages

CID>0 rcvd

Received an incoming call from a third party during n egotiations with
a far-end BONDING unit on the use of the second Bearer channel.

Connect Timeout

Call attempt does not connect in x amount of time.

DEST NOT IS DN

The number called is not ISDN (warning only).

DEST_OUT_OF_ORDER

The called number is out of order.

Dial

The Express 3010 placed a call on either the first or second channel.
The number called is displayed following the me ssage.

Disconnect

The call on either the first or second channel was disconnected from
the network. The far-end phone number is displayed if available. En­sure flow control setting match on both terminal adapters.

Disconnect Req

Far-end unit disconnected during BONDING negotiation.

DTR not up

Express 3010 tr ie d t o p l ac e a cal l i n a dialing mode th at r e quires DTR
to be in an active state, but it is not.

Dump call

The Express 3010 could not accept an incoming call because it was al­ready involved in a call.

61200239L1-20 Express 3010/3110 User Manual C-5

Appendix C. Status Buffer Messages

Dump

An incoming call on either the first or second channel was discarded
by the Express 3010. The calling number is displayed if available.

ED_MISMATCH

Call is connected to different end point device. Call ISP.

FACILITY_NOT_IMPLEMENT

The network does not support the requested supplementary service.

FACILITY_NOT_SUBSCRIBED

The channel type requested has not been subscribed.

FACILITY_REJECTED

A facility requested by the user cannot be provided by the network.

Factory Reset 0

Unit defaulted to factory configuration.

FlowCtl mismatch

Bonding negotiation determined a flow control mismatch.

FlowCtl required

Bonding negotiation determined that flow control needs to be op­tioned on.

Hangup

The call on either the first or second channel was disconnected by the
Express 3010. The far-end phone number is also displayed.

Hold

Voice call is on hold.

C-6 Express 3010/3110 User Manual 61200239L1-20

Appendix C. Status Buffer Messages

ID = XXXX

Calling party number.

INCOMING_CALL_BARRED

The network will not allow an incoming call.

INCOMPATIBLE_DEST

The called number cannot accept the type of call that has been placed.

INTERWORKING_UNSPEC

A non-ISDN network sent an unspecified message.

Inv Password

Remote configuration failed due to incorrect password.

INVALID_CALL_REF

Call control error.

INVALID_ELEM_CONTENTS

Call control error.

INVALID_MSG_UNSPEC

Invalid message: protocol error.

INVALID_NUMBER_FORMAT

The dialed number has an invalid format.

L1 not up

The network interface is not active.

61200239L1-20 Express 3010/3110 User Manual C-7

Appendix C. Status Buffer Messages

L2 not up

The data link layer interface is not active.

L3 not up

The call control interface is not active.

L2 #2 not up

The data link layer interface for a second call (BONDING) is not ac­tive.

L3 #2 not up

The call control layer interface for a second call (BONDING) is not ac­tive.

LDN TOO LONG

The local directory number entered has too many digits.

Login failed

Unable to connect to remote unit on remote configuration attempt.

MANDATORY_IE_LEN_ERR

Mandatory information element length error .

MANDATORY_IE_MISSING

Mandatory information element missing.

MULTILINK PPP UP

Unit connected with Multilink PPP.

Need 64K call

The BONDING protocol requires the Express 3010 to be configured
for 64K data call types.

C-8 Express 3010/3110 User Manual 61200239L1-20

Appendix C. Status Buffer Messages

NETWORK BUSY

The ISDN switch is busy and unable to process a call.

NETWORK_CONGESTION

The phone network is currently congested.

NETWORK_OUT_OF_ORDER

The phone network is out of order.

No calling ID

Calling party number not provided.

NO_CIRCUIT_AVAILABLE

The requested bearer channel is not available.

NONEXISTENT_MSG

Nonexistent/undefined message received from network.

NO_ROUTE
NO_ROUTE_DEST

The phone network was unable to find a route to the destination num­ber.

No Sreg number

Attempted to change an S-register but did not specify a specific S-reg­ister (example: ATS=1).

No Sreg value

Attempted to change an S-register but did not specify a value (exam­ple: ATS= ).

61200239L1-20 Express 3010/3110 User Manual C-9

Appendix C. Status Buffer Messages

No String Space

Stored number string space is full.

NO_USER_RESPONDING

The dialed number is not responding.

NORMAL_CLEARING

The network is disconnecting the current call.

NOT end2end ISDN

The path that the call was routed over is not ISDN from end-to-end
(warning only).

NUMBER_CHANGED

The number dialed has been changed.

OUTGOING_CALL_BARRED

The network will not allow the outgoing call to be placed.

Phone # Req'd

Phone number required for AutoSpid determination.

PPP COMPRESSION UP

Unit connected with compression.

PPP LINK LOOPBACK

Network link is looped backed.

PPP Timeout

PPP negotiation failed.

C-10 Express 3010/3110 User Manual 61200239L1-20

Appendix C. Status Buffer Messages

PROTOCOL_ERROR

Call control error.

PUMPIO: dpump-qu i t

Rate adaption stopped due to DTE error.

Rcv Cause XXX

Undefined cause message received.

REQ_CHANNEL_NOT_AVAIL

The channel type requested is currently not available.

Remote not ISU

Bonding negotiation determined the far-end unit is not another ISU
product.

RESOURCE_UNAVAIL

The requested resource is unavailable.

RESP_TO_STAT_ENQ

Response to status enquiry.

Restarting Rate

Unit restarts DTE rate.

Retrieve

Voice call is retrieved from a holding state.

Ring

An incoming call on either the first or second channel (third channel if
call waiting) entered the Ring state. The calling phone number is dis­played if available.

61200239L1-20 Express 3010/3110 User Manual C-11

Appendix C. Status Buffer Messages

S cmd not = or ?

Proper syntax not used.

SERVICE_NOT_AVAIL

The requested service is not available.

SOURCE NOT ISDN

The incoming calling party is not ISDN (warning only).

TANULL expired

Bonding timer TANULL expired. Received call from non-BONDING
equipment.

TEMPORARY_F AILURE

The network has temporarily failed; try the call again.

TIMER_EXPIRY

Call control error.

TXADD01 expired

Bonding timer TXADD01 expired.

TXDEQ expired

B-channel delay equalization during bonding failed.

TXFA1 expired

Bonding timer TXFA1 expired.

TXFA2 expired

Bonding timer TXFA2 expired.

C-12 Express 3010/3110 User Manual 61200239L1-20
