Chapter 1 Introduction
DUAL NX56/64 V.35 OPTION MODULE OVERVIEW
The Dual Nx56/6 4 V.35 option module is one of the option modules available for use with the following ADTRAN equipment:
• TSU 100e
• TSU 600e
• TSU 610
• TSU 120e
• TDU 120e
• ESU 120e
The Dual Nx56/64 V.35 option module installs in the op-
tion slot of the TSU/TDU/ESU family of products and
provides two additional synchronous V.35 interface
ports. When used in these products, this interface port allows two additional DTEs to have access to the T1 service.
DUAL NX56/64 V.35 PLUG-ON BOARD OVERVIEW
The operations of the Dual Nx56/64 V.35 option module
described in this manual are also applicable for the Dual
Nx56/64 V.35 plug-on board. Operation of both is identical except for the physical installation.
61200142L1-1 Dual Nx56/64 Option Module User Manual 1-1
Chapter 1. Introduction
Dual Nx56/64 V.35 Option Module and Plug-on Board Description
The Dual Nx56/64 V.35 option module operates in the
option slot of the TSU/TDU/ESU products, while the
plug-on board operates as a plug-on to any option module. Both are under the control of the TSU/TDU/ESU
product. The option module and the plug-on board are
configured from the front panel or by an external PC program. The internal menus for their configuration are part
of the option module and plug-on board and are automatically installed when either is plugged into a TSU/TDU /
ESU product.
Features of the Dual Nx56/64 V.35 Option Module
• Operates using one to twenty-four DS0s (32 in E1).
• Includes an elastic store for absorption of rate variations
• Outputs a 50 percent duty-cycle output clock at all
rates
• Menu operation for easy configuration
• Executes and responds to V.54 looping codes
• Generates and checks a 511 test pattern
• Performs an extensive self-test
• Supports multiport dial backup operation
• Provides inband channel ne tw ork management c om munication
Interfaces
• CCITT V.35 electrical (differential)
• 26-Pin Subminiature D (Amp PN 786200-1) to V.35
Winchester
Two cables are included with this product. See Appendix B for a detailed
description of these cables.
1-2 Dual Nx56/64 Option Module User Manual 61200142L1-1
• Loopbacks
Port (toward the network)
DTE (toward the DTE)
• Both loopbacks can be invoked locally or remotely
(V.54)
Dual Nx56/64 V.35 Option Module Specifications
DTE Interface
CCITT V.35 Synchronous
Rates
56 kbps to 1.536 Mbps (T1) and 2048 Mbps (E 1) in 56K or
64K steps
Clock Options
Normal, Inverted
Tests
• Local Loopback (Bilateral) - Menu activated
• Remote Loopback (V.54) - Menu activated
•Self-test
Chapter 1. Introduction
Test Pattern
511 with errored seconds display and error inject capability
Data Inversion
Menu selectable
1s Density Protection
Force 1s to network after one second of consecutive zer os
from DTE.
Choices: On or Off
CTS, DCD, DSR Options
Choices: Normal or Forced On
Connector
26-Pin Subminiature D
61200142L1-1 Dual Nx56/64 Option Module User Manual 1-3
Chapter 1. Introduction
Inband Communication Channel
Enabled or Disabled
Physical Description
The Dual Nx56/64 V.35 option modu le plug s in to the o ption slot in the rear of the TSU/TDU/ESU family of products (see Figure 1-1).
The rear panel of the option module includes a plastic
plug over a cutout for a second V.35 connector. This allows a Dual Nx56/64 V.35 plug-on board (or any other
plug-on board) to be added to the Dual Nx56/64 option
module, creating a multiport module. The
X.2
phy of the TSU/TDU/ESU product family. The X represents the slot number into which the op tion module is
plugged.
For the TSU 1X0 there is only one option slot. Therefore
the port designations are
Plug-On V.35 option module is present, ports
The numbers appear in the front panel LCD menu displays.
PORT X.1
and
indication is linked to the port numbering philoso-
1.1, 1.2
and, if a Dual Nx56/64
1.3
and
1.4
.
3
2
PORT X.1
DUAL
NX 56/64
PORT X.2
PORT X.3
1
2
1 - Cutout for second V.35 connector
2 - Screw receptacles for plug-on board
3 - Plug-on board header
Figure 1-1. Dual Nx56/64 V.35 Option Module
1-4 Dual Nx56/64 Option Module User Manual 61200142L1-1
Chapter 2 Installation
UNPACK & INSPECT
Carefully inspect the option module or plug-on board for
any shipping damage. If damage is suspected, file a claim
immediately with the carrier and then contact ADTRAN
Customer and Product Service (CAPS). If possible, keep
the original shipping container for use in shipping the option module or plug-on board back for repair or for verification of damage during shipment. See product support
information on the back page of this manual for information on how to contact ADTRAN.
ADTRAN Shipments Include
• The Dual Nx56/6 4 Module or Dual N x56/64 Plug-o n
Board.
•The Dual Nx56/64 Option Module User Manual (to be
inserted into the main TSU/TDU/ESU User Manual).
• Two interface cables (ADTRAN PN 3125I020) (Included only with system part number 4200142L1#HS
or 4200159L1).
• Four 4-40 screws are provided with plug-on board
(part number 1200159L1).
61200142L1-1 Dual Nx56/64 Option Module User Manual 2-1
Chapter 2. Installation
INSTALLING THE OPTION MODULE
Placement of the Option Module
Figure 2-1 shows the proper placement of the option
module. Perform the following steps to install the option
module:
1. Remove the cover plate from the TSU/TDU/ESU
unit rear panel.
2. Slide the option module into the rear panel of the
TSU/TDU/ESU unit until it is positioned firmly
against the front of the unit.
3. Fasten the thumbscrews at both edges of the option
module.
Cover Plate
TSU/TDU/ESU
UNIT
Option Module
Figure 2-1. Installing the Option Module
2-2 Dual Nx56/64 Option Module User Manual 61200142L1-1
Power Connection
Each option module derives power from the base TSU/
TDU/ESU unit. Power to the base unit is supplied by a
captive eight-foot power cord.
Attaching the Plug-On Board
Figure 2-2 shows the proper attachment of a plug-on
board to the option module. Perform the following steps
to install the plug-on board:
1. Hold the plug-on board above the option module.
2. Using a downward and right-to-left motion, slip the
plug-on board connector into opening in the option
module back panel.
3. Moving the plug-on board downward, secure the
connection of the header pins at the front of the
boards.
4. Install two 4-40 screws at both front edges of the
option module.
5. Install two 4-40 screws o n each of the standoffs on
the rear of the plug-on module.
Chapter 2. Installation
PORT X.3
PORT X.4
PORT X.1
NX 56/64
PORT X.1
PORT X.2
PORT X.3
Figure 2-2. Attaching the Plug-On Board
61200142L1-1 Dual Nx56/64 Option Module User Manual 2-3
Chapter 2. Installation
Wiring
The connection of the header pins between the option module and the
plug-on board must be visually verified. An improper connection can
cause severe damage to the equipment.
The Dual Nx56/64 option module has two 26-pin subminiature D connectors. Each co nn ector is pinn ed out a s
shown in Table 2-1.
Table 2-1. Subminiature D Connection
PIN DESCRIPTION
1
4
5
6
7
8
9
10
11
12
13
19
22
23
24
25
26
Protective ground (PG)
Request to send (RTS) from DTE
Clear to send (CTS) to DTE
Data set ready (DSR) to DTE
Signal ground (SG)
Received line signal detector (DCD) to DTE
Transmitted data (TD-A) to DTE
Transmitted data (TD-B) to DTE
Received data (RD-A) to DTE
Received data (RD-B) to DTE
External TX clock (ETC-A) from DTE
Test mode (TM) to DTE
TX clock (TC-A) to DTE
TX clock (TC-B) to DTE
RX clock (RC-A) to DTE
RX clock (RC-B) to DTE
External TX clock (ETC-B) from DTE
2-4 Dual Nx56/64 Option Module User Manual 61200142L1-1
Power-Up Testing and Initialization
The option module executes a self-test during the powerup sequence, as described in the TSU/TDU/ESU manual
of the base unit. No initialization input is required. Upon
power-up, any previously configured setting for the option module is automatically restored unless the software
has changed revision.
When the self-testing is completed and the configuration
is successfully restored, the LED labeled OK in the module group on the front panel turns
tion, see Front Panel Operation in the Operation chapter of
the appropriate TSU/TDU/ESU user manual. If any
alarms are detected during operation, the red LED la-
ALARM
beled
turns
On.
in the module group on the front panel
Chapter 2. Installation
On. For more informa-
61200142L1-1 Dual Nx56/64 Option Module User Manual 2-5
Chapter 2. Installation
2-6 Dual Nx56/64 Option Module User Manual 61200142L1-1
Chapter 3 Operation
OVERVIEW
The Dual Nx56/64 V.35 option module is controlled as
part of the TSU/TDU/ESU using the same methods as
described in the appropriate TSU/TDU/ESU user manual.
Front Panel Indicators/Buttons
Refer to the description of the TSU/TDU/ESU front panel indicators and buttons in the appropriate user manual.
Menu Structure
The Dual Nx56/64 V.35 opti on mo du l e me nu s appear as
a subset of, and operate the same as, menus for the TSU/
TDU/ESUs. The menus for the Dual Nx56/64 option
module are accessed by selecting the following from the
Port menu:
<SLOT>.<PORT> NX56/64
.
Slot
SLOT is the slot number in which the option module is installed.
• In the TSU unit with one option card slot (for example, TSU 100), this number will always be 1.
• In the TSU unit with six option card slots (for example, TSU 600), this number will be 1 through 6.
61200142L1-1 Dual Nx56/64 Option Module User Manual 3-1
Chapter 3. Operation
Port
• PORT is the port ID of the V.35 interface to be co nfigured. Each slot may have up to four independent
ports.
ID
•The
P
for each port on the Dual Nx56/64 op-
ORT
tion module and the Dual Nx56/64 plug-on board is
printed next to each connector on the faceplate.
The main menu for the TSU 100 is used as an example.
Figure 3-1 shows the TSU 100 main menu with the PORT
menu items printed in bold italics. The main menu for the
other TSU/TDU/ESU units operates in a similar way.
See Appendi x A in the TSU 100 User Manual for a complete
menu tree diagram.
1) STATUS 1) NI PERF RPTS
2) NI ERRORS
1) NETWORK (NI 3) ACTIVE ALARMS
2) UNIT 4) VIEW HISTORY
3) MAP XCHNG
5) PORT STATUS
2) CONFIG 4) MAP IN USE A (B) 6) REMOTE PORT
5) DS0 MAP A 7) CLEAR PORT ALARM
6) DS0 MAP B 8) ENET STATUS
7) PORT CONFIG
1) TIME/DATE
TSU 100 2) FACTORY RESTORE
MAIN MENU 3) UTIL 3) SET PASSCODE
4) UNIT ID
5) SOFTWARE REV
1) NETWORK TESTS 6) PORT UTILITY
4)TEST
2) RUN SELF TEST
3) PORT TEST
7) ENET ADDRESS
8) SERIAL NUMBER
4) CANCEL TEST
Figure 3-1. TSU 100 Main Menu Tree
3-2 Dual Nx56/64 Option Module User Manual 61200142L1-1
Dual Nx56/64 V.35 Menus Are All Submenus
The Dual Nx56/64 V.35 option module menus are accessed from and operated the same as menus for the TSU 100.
Menu items in the main menu in Figure 3- 1 on page 3-2
printed in bold italics are submenu choices for Dual
Nx56/64 V.35 option modules (see Figure 3-2). Each of
these submenu items is discussed in the following paragraphs. All are accessed by the same method.
1) STATUS 2) PORT STATUS 3) PORT RATE
2) CONFIG 7) PORT CONFIG 4) DATA
DUAL 5) CTS
NX56/64 MENU 6) DCD
Chapter 3. Operation
1) DTE DATA CLOCK
2) DTE STATUS
1) INTERFACE
2) RATE
3) TX CKL CNTRL
7) DSR
8) “0” INHIB
9) INBAND
A) TX CLK SOURCE
3) UTIL 7) PORT UTILITY SW REV
1) LOOPBACK
4) TEST 3) PORT TEST 2) 511 PATT
3) DISP 511 RSLT
Figure 3-2. Dual Nx56/64 V.35 Menu Tree
61200142L1-1 Dual Nx56/64 Option Module User Manual 3-3
Chapter 3. Operation
Operation
PORT Status
Operation
With the cursor on one of the four main menu choices,
Enter or the number key. This displays the first two
press
submenu items with the cursor on the first item. Use the
down arrow key to place the cursor on the desired item;
then press
E
. This displays the first two submenu
NTER
choices.
S
The
menu branch allows you to view the status of
TATUS
the TSU 100 operation. It displays the status of the monitored signal line on the Dual Nx56/64 V.35 option board
and the data rate for which the option module is configured.
To display Figure 3-3 on the TSU 100, place the cursor on
main menu item
1)STATUS
, and do the following:
1. Press
Enter or the number 1 key. This displays the
first two Status submenu items with the cursor on
1)NI PERF RPTS
.
2. Use the down arrow to place the cursor on
5) PORT STATUS
, and press
Enter. This displays the
first available port.
3. Use the up and down arrow keys to identify
N
56/64 V.35,
X
and press
Enter.
1.1
Figure 3-3. Port Status Submenu
3-4 Dual Nx56/64 Option Module User Manual 61200142L1-1
Chapter 3. Operation
The Dual Nx interface offers the status screens listed in
this manual. For other option modules, refer to the appropriate user manual.
Dual NX56/64 Status
Select 1.1 NX56/64
DTE DATA/ C K
DTE STATUS
PORT RATE
DTE DATA/CK
Shows the status (active or not active) of th e following
lines:
TXD Transmit data from the DTE
RXD Receive data to the DTE
ETC External transmit clock from DTE
LCK Lock status of the phase locked loop
DTE Status
Shows the status (active or not active) of th e following
lines:
RTS Request to send from DTE
CTS Clear to send to DTE
DCD Data carrier detect to DTE
DSR Data set ready to DTE
Port Rate
Displays the data rate to which the NX port is set.
Exit the displays as described in the TSU 100 User Manual .
61200142L1-1 Dual Nx56/64 Option Module User Manual 3-5
Chapter 3. Operation
PORT CONFIG
Operation
7)PORT CONFIG
The
submenu is used for configuration
of the Dual Nx56/64 V.35 option module.
To display Figure 3-4 on the TSU 100, place the cursor on
main menu item
2)CONFIG
, and do the following:
1. Press
Enter or the number 2 key. This displays the
first two Configuration submenu items with the cur-
1)NETWORK (NI)
sor on
.
2. Use the down arrow key to place the cursor on
7)PORT CONFIG,
3. Use the up and down arrow keys to identify
D
UAL NX
56/64 V.35
and press
Enter.
1.1
option module. Only the bottom
line of the display changes.
Figure 3-4. Port Configuration Submenu
To select
P
ORT CONFIGURATION
, press Enter. This displays
the first of eight submenu items. They are:
Interface
This selects the active interface for the Nx port. The Nx
ports, which are installed as option modules, ha ve only
one type of interface.
Choice: V.35
3-6 Dual Nx56/64 Option Module User Manual 61200142L1-1
Chapter 3. Operation
Rate 56/64
This sets the base rate of the interface. The actual data
rate depends on the number of DS0s assigned to the Nx
port. The DTE data rate versus the number of DS0s
appear in the DTE Data Rate Chart appendix of the TSU
100 User Manual.
Choices: 56K or 64K
Transmit Clock (TX CLK)
Controls the clock used by the TSU 100 to accept the
transmit (TX) data from the DTE. This is usually s et to
N
. If the interface cable is long and causes a
ORMAL
phase-shift in the data, the clock can be selected as
I
NVERTED
. This switches the phase of the clock, which
should compensate for a long cable.
Choices: Normal; Inverted
Data
Used to control the inverting of the DTE data. This
inversion can be useful when operating with a high level
data link (HDLC) protocol. Often used as a means to
ensure 1s density.
Choices: Normal or Inverted
Clear to Send (CTS)
Used to control characteristics of CTS.
Choices: Normal or Force On (see Table 3-1 on page 3-8).
Data Carrier Detect (DCD)
Indicates to the DTE when a valid signal is being
received at the Network Interface.
Choices: Normal or Force On (see Table 3-1 on page 3-8).
Data Set Ready (DSR)
This signal indicates to the DTE when the DCE is turned
On and ready for operation.
Choices: Normal or Force On (see Table 3-1 on page 3-8).
Table 3-1 on page 3-8 shows conditions which cause the
port control signal to be deactivated
61200142L1-1 Dual Nx56/64 Option Module User Manual 3-7
Chapter 3. Operation
Table 3-1. Normal Mode Operation
SIGNAL RTS V-54
CTS Follows off off off off off off
DCD — — — off off off off
DSR — off off off off off —
— = Do not care
Force On = On under all conditions
LOOPBACK
511 TESTONSELF
TEST
ACTIVE
NETWORK
TEST
ACTIVE
NO DS0
MAPPED
NETWORK
0 INHIB
If the Nx interface detects an uninterrupted string of 0s
being transmitted toward the network, and if 0s are
transmitted for more than one second, then the TSU 100
forces 1s towards the network.
Choices: On; Off
INBAND
Inband Configuration Channel - Used to enable/disable
an 8 kbps remote configuration channel (see Figure 3-5
on page 3-9). When this option is set to ON, the first DS0
mapped to the Nx interface operates in 56K mode and
the DTE clock rate is reduced by 8 kbps. The TSU/HSU
uses this 8 kbps channel to send and receive configuration data across a T1 span. As shown in Figure 3-5, this
allows the PC connected to the chain-in port on TSU 600
A to monitor/configure both TSU 600 A and B. This feature is useful when FDL connectivity is not available
across the T1 span.
ALARM
The 8 kbps channel is only taken out of the first DS0. If
two 64K DS0s are mapped, the DTE rate would be 120
kbps instead of 128 kbps.
3-8 Dual Nx56/64 Option Module User Manual 61200142L1-1
Chapter 3. Operation
TSU 600 A
CHAIN IN
NX
This menu option can also be set to
O
N-DEMAND
will activate the Inband Channel only when commands
are sent from T-Watch Pro to the remote unit (TSU 60 0 B
in Figure 3-5). If no T-Watch Pro activity is detected for
10 minutes, the Inband Channel is deactivated.
TX CLK SOURCE
Controls the clock used by the DTE. Normally this is set
INTERNAL
to
the clock selection is set to
. If the DTE provides a clock with TX data,
EXTERNAL
. The Nx56/64
will depend on an externally supplied clock to accept the
TX data.
Choices: INTERNAL or EXTERNAL
T-WATCH
TSU 600 B
NETWORK
DSX 1
NX DSX 1
which
ROUTER PBX
ROUTER PBX
Figure 3-5. Inband Remote Configuration
Although a router can accommodate this 8K rate reduction, some DTE
devices may not (i.e., video). Determination should be made if the
connected DTE can handle this reduced clock source. A second option
would be to operate in 56K/DS0.
61200142L1-1 Dual Nx56/64 Option Module User Manual 3-9
Chapter 3. Operation
Factory Restore
Operation
Port Utility
Operation
This selection is used to restore the factory default settings for all pass-through option module parameters.
To return the unit to the opening main menu with all the
factory default settings restored, do the following:
1. Follow the standard operating procedure to access
3)UTIL
the
2. With the cursor on
menu items.
2)FACT RESTORE
, press
Enter.
The Port Utility submenu is used primarily to a ccess the
display of the current software information for each port
installed in the unit. This information is required when
requesting assistance from ADTRAN Technical Support
or when updates are needed.
To display Figure 3-6, do the following:
1. Follow the standard operating procedure to access
3)UTIL
the
2. With the cursor on
menu items.
6)PORT UTILITY
, press
Enter.
This displays the first available port.
Figure 3-6. Port Utility Submenu
3-10 Dual Nx56/64 Option Module User Manual 61200142L1-1
Run Self-Test
Chapter 3. Operation
To display the port name and the software version installed as shown in Figure 3-7, do the following:
1. Use the arrow keys to move through the available
ports, or enter the port number with the number key.
2. When the desired port name is displayed, press
Enter.
3. Press
Cancel to exit or to select another port.
Figure 3-7. Port Name and Software Version Display
This menu item is used to execute both the internal test of
the TSU/TDU/ESU and of the Dual Nx56/64. This is the
same test executed during power-up. The results of the
self-test are shown on the TSU 100 display. For additional
information on Self-Test, see the Operation chapter of the
appropriate TSU/TDU/ESU user manual.
To activate a self-test, do the following:
1. Follow the standard operating procedure to access
4)TEST
the
2. With the cursor on
menu items.
2)RUN SELFTEST
, press
Enter.
The TSU/TDU/ESU display changes and shows the
test outcome.
61200142L1-1 Dual Nx56/64 Option Module User Manual 3-11
Chapter 3. Operation
Port Test
Port Test e xecution disrupts norm al data flow in the port being tested.
Operation
This menu item is used to activate testing of specific data
ports. It also controls the activation of loopbacks and the
initiation of data test patterns. Test results are shown on
the TSU/TDU/ESU display.
To display Figure 3-8 on the TSU 100, place the cursor on
3)PORT TEST
displays the available ports.
, and press
Enter or the number 3 key. This
3
Figure 3-8. Port Test Submenu
1.1 Dual Nx56/64
The Nx interface offers the following test functions:
LOOPBK
Initiates a loopback.
PRT/LCI
The Nx port activates both a local loopback (Back toward
the DTE) and a port loopback when either is invoked
3-12 Dual Nx56/64 Option Module User Manual 61200142L1-1
Chapter 3. Operation
REMOTE
The remote loopback causes a V.54 code to be sent to the
far end. The Nx at the far end activates a PORT/LCL
loopback on detection of the V.54 code.
REM V.54 CONT
This loopback causes continuous V.54 code to be sent to
the far end. The Nx at the far end activates a
PORT/LCL
loopback upon detection of the V.54 code.
OFF
The loop is deactivated.
The TSU/TDU/ESU checks the remote loopback act ivation by det ecting a
proper response from the remote end. While waiting for the response, the
display shows Looping. If successful, the display changes to Looped
Up. If unsuccessful, the display shows Failed.
511 PATT
Activates the generation of the 511 test pattern.
ON
The pattern check circuitry is enabled and test started.
The test is ended by selecting
O
.
FF
OFF
The pattern generation and check is disabled
DIS 511 RESLT
Displays the results of the 511 test indicated above. The
results are in the f orm o f the n umber of e rrored seconds.
The error count can be cleared by pressing the
(
Shift + 9). A bit error may be inserted into the data
stream by pressing the
61200142L1-1 Dual Nx56/64 Option Module User Manual 3-13
2 key.
Clear key
Chapter 3. Operation
3-14 Dual Nx56/64 Option Module User Manual 61200142L1-1
Appendix A System Messages
ALARM MESSAGES
Network Interface (NI)
Red Alarm
NI unable to align frame with incoming signal
Yellow Alarm
Remote alarm indication (RAI) being received from the
far end
Blue Alarm
Unframed all 1s (AIS) being received at NI
Loss of Signal
No signal detected at NI
61200142L1-1 Dual Nx56/64 Option Module User Manual A-1
Appendix A. System Messages
Dual Nx56/64 V.35 Option Module
Clock Slip
Difference in frequency of the data clock at the network
and DTE
PLL Alarm
Unable to lock phase lock on the clock provided by the
network interface
Zeros Alarm
All 0s data being sent to the network interface
No EXT Clock
No external transmit clock at DTE (when applicable)
STATUS MESSAGES
Network Interface (NI)
Payload On
Payload loopback activated
Line On
Line loopback activated
Loopback Off
All loopbacks deactivated
Factory Restore
Factory setting restored
Power On
Unit powered on
Self-Test
Internal self-test performed
A-2 Dual Nx56/64 Option Module User Manual 61200142L1-1
Dual Nx56/64 V.35 Option Module
Loop-Up
Data is looped back at both the network interface and the
DTE interface of the card
Remote Loop Up
Sending a V.54 pattern in an attempt to loop up a remote
device
511 Pattern On
Sending a 511 pattern towards the network interface
Loop Down
Data is no longer looped back at the network interface or
the DTE interface
511 Pattern Off
No longer sending a 511 pattern towards the network
interface
Appendix A. System Messages
61200142L1-1 Dual Nx56/64 Option Module User Manual A-3
Appendix A. System Messages
A-4 Dual Nx56/64 Option Module User Manual 61200142L1-1
Appendix B
26-Pin Subminiature D to
V.35 Winchester Cable
The interface cables (26-Pin Subminiature D to V.35 Winchester Cables) shipped with the Dual Nx56/64 Option
Module and the Dual Nx56/64 Plug-On Board are pinned
out as shown in Table B-1 on page B-2.
Subminiature D connector should be AMP PN 750850-3 or
equivalent.
V.35 Winchester cable should be Positronic PNV3400000.70
with GMCT34F0000YR-695 or equivalent.
Pins A thro ugh NN ar e V.35 c onne ctor pi ns; pins 101 th r ough
114 are CCITT pins.
61200142L1-1 Dual Nx56/64 Option Module User Manual B-1
Appendix B. 26-Pin Subminiature D to V.35 Winchester Cable
Table B-1. 26-Pin Subminiature D to V.35 Winchester Cable
SUBMINIATURE D PIN &
V.35 WINCHESTER PIN & SIGNAL (CCITT)
SIGNAL
Pin Signal Pin Signal
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
Frame Ground
NC
NC
RTS
CTS
DSR
SIGNAL GROUND
DCD
TD-A
TD-B
RD-A
RD-B
ETC-A
NC
NC
NC
RI
LL
TM
DTR
SIGNAL GROUND
TC-A
TC-B
RC-A
RC-B
ETC-B
A (101)
B (102)
C (105)
D (106)
E (107)
F (109)
H —
J —
K —
L —
M —
N —
P (103)
R (104)
S (103)
T (104)
U (113)
V (115)
W (113)
X (115)
Y (114)
Z —
AA (114)
BB —
CC —
DD —
Frame Ground
Signal Ground
ETC-A
ETC-B
EE —
FF —
HH —
JJ —
KK —
LL —
MM —
NN —
RTS
CTS
DSR
DCD
DTR
RI
TM
LL
—
—
TD-A
RD-A
TD-B
RD-B
RC-A
RC-B
TC-A
—
TC-B
—
—
—
—
—
—
—
—
—
—
TM
B-2 Dual Nx56/64 Option Module User Manual 61200142L1-1
Index
Numerics
0 INHIB, port config 3-8
1s Density Protection
26 Pin Subminiature D (Amp PN 786200-1) to
V.35 Winchester, interface
511 PATT
511 Pattern Off
511 Pattern On
3-13
A
alarm messages A-1
Attaching the Plug-On Board
B
Blue Alarm, netw ork interface A-1
C
CCITT V.35 electrical, interface 1-2
CCITT V.35 Synchronous, DTE interface
Clear to Send (CTS), port config
Clock Options
Clock Slip
Connector
CTS, DCD, DSR Options
Customer Service
A-2
1-3
D
Data Carrier Detec t (D CD ), port config 3-7
Data Inversion
Data Set Ready (DSR), port config
Data, port config
DIS 511 RESLT
DTE DATA/CK
DTE Status
Dual NX56/64 Status
Dual Nx56/64 V.35 Menus
Dual Nx56/64 V.35, overv ie w
3-5
1-3
A-3
A-3
1-3
3-13
3-5
3-7
1-3
1-2
2-3
3-7
1-3
3-7
1-3
iv
3-5
3-3
1-1, 3-1
Dual Nx56/64 V.35, physical description
dual Nx56/64 V.35, specifications
Dual Nx56/64 V.35, system messages
1-4
1-3
A-2
F
factory restore 3-10
Factory Restore, status message
FCC Radio Frequency Interference Statement
Features, Dual Nx56/64 V.35 Option Module
Front Panel Indicators/Buttons, See TSU/TDU/
ESU user manual
3-1
A-2
1-2
iv
I
inband communication channel 1-4
inband configuration channel
Installing the Option Module, how to
interface, 26-pin Subminiature D
interface, CCITT V.35
interface, port config
items included in ship p i ng container
3-6
1-2
3-8
2-2
1-2
2-1
L
Line On, status message A-2
Local Loopback, test
Loop Down
Loopback Off, status message
Loopbacks, port and DTE
LOOPBK
Loop-Up
Loss of Signal, network interface
3-12
A-3
A-3
1-3
A-2
1-3
A-1
M
Menu Structure 3-1
N
network interface ala rm s A-1
No EXT Clock
A-2
61200142L1-1 Dual Nx/56/64 Option Module User Manual Index-1
Index
P
Payload On, status message A-2
pinouts
2-4
3-12
A-2
3-4
3-10
2-3
A-2
1-1
v
PLL Alarm
port status
port utility
Power Connection
Power On, status message
Power-Up Testing and Initialization
product ov e rview
product warranty
PRT/LC
R
RATE 56/64, port config 3-7
Red Alarm, netw ork in terface
REM V.54 CONT
REMOTE
Remote Loop Up
Remote Loopback, test
Run Self-Test
3-13
3-11
3-13
A-3
A-1
1-3
S
Self-Test
status message
A-2
Self-test
shipping container, items contained in
shipping damages, what to do if
Status Messages
1-3
A-2
2-1
2-1
T
Test Pattern 1-3
1-3
Tests
2-5
Transmit Clock, port config
TX CLK
TX CLK SOURCE
3-7
3-9
3-7
U
Unpack & Inspect 2-1
W
Warranty iv
2-4
Wiring
Y
Yellow Alarm, net work interface A-1
Z
Zeros Alarm A-2
Index-2 Dual Nx/56/64 Option Module User Manual 61200142L1-1
Product Support Information
Pre-Sales Inquiries and Applications Support
Please contact your local distributor, ADTRAN Applications Engineering, or
ADTRAN Sales:
Applications Engineering (800) 615-1176
Sales (800) 827-0807
Post-Sale Support
Please contact your local distributor first. If your local distributor cannot help,
please contact ADTRAN Technical Support and have the unit serial number available.
Technical Support (888) 4ADTRAN
Repair and Return
If ADTRAN Technical Support determines that a repair is needed, Technical Support will coordinate with the Customer and Product Service (CaPS) de partment to
issue an RMA number. For information regarding equipment currently in house
or possible fees associated with repair, contact CaPS directly at the following number:
CaPS Department (256) 963-8722
Identify the RMA number clearly on the package (below address), and return to
the following address:
ADTRAN, Inc.
CaPS Depart ment
6767 Old Madison Pike
Progress Center
Building #6, Suite 690
Huntsville, AL 35807
RMA # _____________
Loading...
