Figure 3-2 Port Status Display ........................................................................... 1 3
Figure 3-3 Diagram of Loopbacks ..................................................................... 17
Figure B-1 DSX-1 Plug-On Board Menu Tree ................................................... 21
Tables
Table 2-A Pinout Connectors for Eight-Position Modular Jack Interface ........ 7
Table 3-A Port Configuration Parameters .......................................................... 15
vi DSX-1 Plug-On Board User Manual 61200.114L1-1
ii
DSX-1 PLUG-ON BOARD OVERVIEW
The DSX-1 plug-on board is one of the plug-on options
available for use with the ADTRAN TSU 100/600. The
DSX-1 plug-on board provides a single DSX-1 interface
that can be used to provide access to a PBX, router, or
other equipment that uses a DSX-1 interface. When
used with a PBX, this interface permits the combination
of voice and data in a single T1 stream. The allocation
of the amount of bandwidth for the DSX-1 plug-on
board is selectable.
Chapter 1. Introduction
Chapter 1
Introduction
When plugged onto any option card other than the drop
and insert (D&I) or DSX-1 option modules, the DSX-1
plug-on board operates exactly like the DSX-1 passthru
option module. The DSX-1 plug-on board can also be
installed on option modules in slots 1 through 5 of the
TSU 600 and used as a data port for applications not
requiring robbed-bit signaling. When plugged onto a
drop & insert option module, the DSX-1 plug-on board
can be used as a PBX port for the drop & insert T1. In
this configuration, robbed bit-signaling can be enabled
or disabled from a front-panel menu option.
FUNCTIONAL DESCRIPTION
The DSX-1 plug-on board operates as a plug-on with any
TSU option module. The DSX-1 plug-on board is
configured from the front panel of the TSU 100/600 or
by an external personal computer (PC) program. The
61200.114L1-1 DSX-1 Plug-On Board User Manual 1
Chapter 1. Introduction
FEATURES
internal menus for its configuration are a part of the
passthru and are automatically installed when the DSX-1
plug-on board is present in the unit.
The DSX-1 plug-on board has the following features:
• Operates using 1 to 24 DS0s
• Executes an extensive self test
• Can be used as a PBX port for the drop and insert
option module
• Displays menu options for easy configuration
• Functions as a data port in slots 1 through 5 of the
TSU 600
When used as a DSX-1 passthru:
• Operates as a drop and pass-on or as a standard passon module
• Provides timing for the TSU 100/600 as an option
INTERFACES
The DSX-1 plug-on board interface has the following
features:
• DSX-1 per ANSI T1.102
• RJ-48C interface connector
• Alternate mark inversion (AMI) or binary 8 zero
substitution (B8ZS) coding
• Extended superframe (ESF) or superframe (SF) (D4)
formatting (independent of T1 facility interface)
• Line length up to 655 feet
• Line loopback (front panel/remote/inband)
2 DSX-1 Plug-On Board User Manual 61200.114L1-1
DSX-1 PLUG-ON BOARD SPECIFICATIONS
The DSX-1 plug-on board conforms to the following
specifications:
DSX-1 Interface Per ANSI T1.102
Line rate 1.544 Mbps
Capacity 1 to 24 DS0s (can be user
configured, contiguous or noncontiguous)
Line Codes AMI
Bipolar return to zero (B8ZS)
Framing Options ESF per ANSI T1.403 and AT&T
Publication TR 54016;
D4 per AT&T Publication 62411
Line Length -3 dB dsx up to 655 feet in 110 feet
steps
Chapter 1. Introduction
Clock Source Supports network, secondary,
and CSU timing modes
Tests Power-on circuit self test
Line loopback
Port loopback (internal toward
Mux)
Connectors RJ-45C
61200.114L1-1 DSX-1 Plug-On Board User Manual 3
Chapter 1. Introduction
PHYSICAL DESCRIPTION
The DSX-1 plug-on board (see Figure 1-1) is a plug-on
board that plugs onto the TSU 100/600 option modules.
DSX-1
2x32 Plug-On
Connector
Mounting Screw
Holes
Figure 1-1
DSX-1 Plug-On Board
