Chapter 1 Introduction

OVERVIEW
The Nx56/64 (EIA-530) option module is one of the op­tion modules available for use with the ADTRAN TSU 100, 120, 600, and 610. The Nx56/64 (EIA-530) option module installs in the option slot of the TSU 100 and pro­vides an additional synchronous EIA-530 interface port. When used in the TSU, this interface port allows an addi­tional DTE to have access to the T1 service.
Functional Description
The Nx56/64 (EIA-530) interface operates in the option slot of the TSUs, or as a plug-on to any option module and is under the control of the TSU. The Nx56/64 (EIA-530) option module is configured from the front panel or by an external PC program. The internal menus for its configu­ration are part of the Nx card and are automatically in­stalled when the option module is plugged into the TSU.
61200054L2-1 Nx56/64 (EIA-530) Option Module User Manual 1-1
Chapter 1. Introduction
Features
Interfaces
Operates using 1 to 24 DS0s
Includes an elastic store for absorption of rate varia­tions
Capable of including an Nx56/64 (EIA-530) plug-on interface port, resulting in a dual port module
Outputs a 50% duty-cycle output clock at all rates
Menu operation for easy configu ration
Executes and responds to V.54 looping codes
Generates and checks a 511 test pattern
Performs an extensive self-test
EIA-530 electrical (differential)
Connector : DB-25 (EIA-530)
Loopbacks:
- Port (toward the network)
- DTE (toward the DTE)
Both loopbacks can be invoked locally or remotely (V.54)
Option Module Specifications
DTE Interface
EIA-530
Rates
56 kbps - 1.536 Mbps in 56K or 64K steps
Clock Options
Internal, Internal-Inverted, External
1-2 Nx56/64 (EIA-530) Option Module User Manual 61200054L2-1
Chapter 1. Introduction
Tests
Local Loopback (Bilateral): Menu activated Remote Loopback (V.54) Menu activated: Self-test
Test Pattern
511 with errored seconds display
Data Inversion
Menu selectable
1s Density Protection
Force 1s to network after one second of consecutive zer os from DTE. On/Off
CTS, DCD, DSR Options
Normal or Forced On
Connector
DB-25 (EIA-530)
61200054L2-1 Nx56/64 (EIA-530) Option Module User Manual 1-3
Chapter 1. Introduction
Physical Description
The Nx56/64 (EIA-530) is an o ption m odule wh ich plu gs into the option slot in the rear of the TSU product family. See Figure 1-1.
3
2
EIA 530
PORT X.1
1 - Cutout for second connector 2 - Screw receptacles for "plug-on" board 3 - Port X.2 header pins
PORT X.2/X.3
1
2
Figure 1-1. Nx56/64 (EIA-530) Option Module
The rear panel of the option module includes a plastic plug over a cutout for a second EIA-530 connector. This allows the addition of another plug-on module. The port
X.1
and
X.2
indication is linked to the port numbering philosophy of the TSU 100 product family. The X repre­sents the slot number, into which the option module is plugged. For the TSU 100, there is only one option slot. Therefore, the port designation would be
1.1
. If a plug-on
(EIA-530) is present, then the part designation would be
1.2
port numbers would be port
. In a TSU 600 with six option slots, these port
1.1
to port
6.1
. The numbers ap-
pear in the front panel LCD menu displays.
1-4 Nx56/64 (EIA-530) Option Module User Manual 61200054L2-1

Chapter 2 Installation

UNPACK & INSPECT
Carefully inspect the Nx56/64 (EIA 530) option module for any shipping damage. If damage is suspected, file a claim immediately with the carrier and then contact ADTRAN customer service. If possible, keep the original shipping container for use in shipping the module back for repair or for verification of damage during shipment.
ADTRAN Shipments Include
The Nx56/64 (EIA-530) option module
The user manual (to be inserted into the main TSU manual
Customer Provides
DTE cable
61200054L2-1 Nx56/64 (EIA-530) Option Module User Manual 2-1
Chapter 2. Installation
INSTALLING THE OPTION MODULE
Power to the TSU 100 should be Off when installing any option module .
Placement of the Option Module
Figure 2-1 shows the proper placement of the option module. To install the option module, perform the fol­lowing steps:
1. Remove the cover plate from the TSU 100 rear panel.
2. Slide the option module into the rear panel of the TSU 100 until it is positioned firmly against the front of the unit.
3. Fasten the thumbscrews at both edges of the option module.
Cover Plate
TSU 100
Option Module
Figure 2-1. Installing the Option Module
2-2 Nx56/64 (EIA-530) Option Module User Manual 61200054L2-1
Power Connection
Each option module derives power from the base TSU 100 unit. Power to the TSU 100 is supplied by a captive eight­foot power cord.
Attaching the Plug-on Board
Figure 2-2 shows the proper attachment of a plug-on board to the option module. Perform the following steps to install the plug-on board:
1. Hold the plug-on board above the option module.
2. Using a downward and right to left motion , slip the DTE connector plug into the opening in the option module back panel.
3. Move the plug-on board downward then secure the connection of the header pins at the front of the boards.
4. Install the two 4-40 screws at both edges of the option module.
Chapter 2. Installation
EIA 530
PORT X.1
PORT X.2/X.3
Figure 2-2. Attaching the Plug-on Board
The connection of the header pins between the option module and the plug-on board must be visually verified . An improper connection can damage the equipment.
61200054L2-1 Nx56/64 (EIA-530) Option Module User Manual 2-3
Chapter 2. Installation
WIRING
(ETC-A) External TX Clock (from DTE)
(DSR) Data Set Ready Return
(RTS-B) Request to Send Return (LL) Local Loopback (from DTE)*
(RC-A) Recieve Clock (to DTE)
(RD-B) Recieve Data Return
(TC-A) Transmit Clock (to DTE)
(TC-B) Transmit Data Return
The Nx56/64 (EIA-530) option module has a DB-25 Win­chester-style connection, as show n in Figure 2-3.
(TM) Test Mode (to DTE)
(DTR-B) DTE Ready Return
(RL) Remote Loopback*
(DTR-A) DTE Ready
13
25 24 23 22 21 20 19 18 17 16 15 14
Clear to Send Return (CTS-B)
12
Transmit Clock Return (TC-B)
11
External TX Clock Return (ETC-B)
10
Data Carrier Detect Return (DCD-B)
9
Recieve Clock Return (RC-B)
8
Data Carrier Detect (to DTE) (DCD-A)
7
Signal Ground (SG)
6
Data Set Ready (to DTE) (DSR-A)
5
Clear to Send (to DTE) (CTS-A)
4
Request to Send (from DTE) (RTS-A)
3
Recieve Data (to DTE) (RD-A)
2
Transmit Data (from DTE) (TD-A)
1
Protective Ground, Cable Shield (PG)
* Ignored by Nx56/64
Figure 2-3. DB-25 Pin Connection
2-4 Nx56/64 (EIA-530) Option Module User Manual 61200054L2-1
POWER-UP AND INITIALIZATION
The Nx56/64 (EIA-530) option module executes a self-test during the power-up sequence, as described in the TSU 100 User Manual. No initialization input is required. Upon power-up, any previously configured setting for the Nx56/64 (EIA-530) option module is automatically re­stored.
When the self-test is complete and the configuration is successfully restored, the LED labeled OK in the module group on the front panel turns ON. For more information, see Front Panel Operation in Chapter 3, Operation, of the TSU 100 User Manual. If any alarms are detected during operation, the red LED labeled group on the front pane l turns ON.
ALARM
Chapter 2. Installation
in the module
61200054L2-1 Nx56/64 (EIA-530) Option Module User Manual 2-5
Chapter 2. Installation
2-6 Nx56/64 (EIA-530) Option Module User Manual 61200054L2-1

Chapter 3 Operation

OVERVIEW
The Nx56/64 (EIA 530) option module is controlled as part of the TSU 100 using the same methods as described in the TSU 100 Us er Manual.
Front Panel Indicators/Buttons
See the description of the TSU 100 front panel indicators and buttons in the TSU 100 User Manual.
Menu Structure
The Nx56/64 menus appear as a subset of, and operate the same as, menus for the TSU 100. The menus are ac­cessed by selecting items.
Figure 3-1 on page 3-2 shows the TSU 100 main menu. The Port menu items are in bold, italic type.
1.1 N
56/64
X
under the Port menu
A complete TSU 100 menu tree diagram is found in the TSU 100 User Manual.
61200054L2-1 Nx56/64 (EIA-530) Option Module User Manual 3-1
Chapter 3. Operation
TSU 100 5) DS0 MAP A 1) TIME/DATE MAIN MENU 6) DS0 MAP B 2) FACTORY RESTORE
1) NI PERF REPORTS
1)STATUS 2) NI ERRORS
3) ACTIVE ALARMS
1) NETWORK (NI) 4) VIEW HISTORY
2) CONFIG 2) UNIT
3) MAP XCHNG
4) MAP IN USE A (B)
7) PORT CONFIG
3) UTIL
1) NETWORK TESTS 7) ENET ADDRESS
4) TEST
2) RUN SELF-TEST
3) PORT TEST
4) CANCEL TEST
5) PORT STATUS
3) SET PASSCODE
4) UNIT ID
5) PORT UTIL
6) SOFTWARE REV
8) SERIAL NUMBER
Figure 3-1. TSU 100 Main Menu Tree
Nx56/64 Menus Are All Submenus
The Nx56/64 menus are accessed from and operated the same as menus for the TSU 100. As shown in the bold, italicized menu items in Figure 3-1, the Nx56/64 items are submenu choices of the four main menus. Each of the Nx56/64 submenu items is discussed in the following paragraphs. All are accessed by using the same method.
OPERATION OF NX56/64 SUBMENUS
With the cursor on one of the four Main menu choices, press
Enter or the number key. The first two submenu
items with the cursor on the first item will display. Use
S
the
CROLL DOWN
item; then press menu choices.
3-2 Nx56/64 (EIA-530) Option Module User Manual 61200054L2-1
key to place the cursor on the desired
Enter. This displays the first two sub-
2)PORT Status, Submenu of 1)Status
The Status menu branch allows you to view the status of the TSU 100 operation. It displays the status of the moni­tored signal line on the Nx56/64 (EIA-530) option module and the data rate for which the Nx card is configured.
Operation
To display Figure 3-2 on the TSU 100, place the cursor on main menu item steps:
1)STATUS
Chapter 3. Operation
and perform the following
1. Press
Enter or the number 1 key. This displays the
first two Status submenu items with the cursor on
1)NI PERF RPTS
2. Use the
5) PORT STATUS
Scroll Down key to place the cursor on
.
and press
Enter. This displays the
first available port.
56/64
3. Use the
Enter.
Scroll keys to id ent i fy
1.1 N
X
Figure 3-2. Port Status Submenu
and press
61200054L2-1 Nx56/64 (EIA-530) Option Module User Manual 3-3
Chapter 3. Operation
The base Nx interface shows the status screens listed in this manual. For other option modules, refer to the ap­propriate user manual.
Nx56/64 Status
Select 0.1 NX56/64
1) DTE DATA/CK
2) DTE STATUS
3) PORT RATE
DTE Data/CK
Shows the status (active or not active) of the following lines:
TXD Transmit data to the DTE RXD Receive data from the DTE ETC External transmit clock from DTE LCK Lock status of the phase-locked loop
DTE Status
Shows the status (active or not active) of the following lines:
RTS Request-to-send from DTE CTS Clear-to-send to DTE DCD Data carrier detect to DTE DSR Data set ready to DTE
Port Rate
Displays the data rate to which the Nx port is set.
Exit the displays as described in the TSU 100 User Manual.
3-4 Nx56/64 (EIA-530) Option Module User Manual 61200054L2-1
7)PORT CONFIG, Submenu of 2)CONFIG
7)PORT CONFIG
Operation
The of the Nx56/64 (EIA-530) option module.
To display Figure 3-3 on the TSU 1 00, place the cursor on menu item
2)CONFIG
submenu is used for configuration
and perform the following steps:
Chapter 3. Operation
1. Press
Enter or the number 2 key. This displays the
first two Configuration submenu items. The cursor will be on
2. Use the
7)PORT CONFIG
3. Use the scroll keys to identify
1)NETWORK (NI)
Scroll Down key to place the cursor on
and press
.
Enter.
1.1 N
56/64
X
. Only the
bottom line of the display changes.
Figure 3-3. Port Configuration Submenu
To select
P
ORT CONFIGURATION
, press Enter. This displays
the first of eight submenu items. They are:
1)INTERFACE
This selects the active interface for the Base Nx port. The Nx ports, which are installed as option modules, have only one type of interface. Choice: EIA-530
61200054L2-1 Nx56/64 (EIA-530) Option Module User Manual 3-5
Chapter 3. Operation
2)RATE 56/64
This sets the base rate of the interface. The actual data rate depends on the number of DS0s assigned to the Nx port. The DTE Data Rate versus the number of DS0s appear in the DTE Data Rate Chart shown in the TSU 100 User Manual. Choices: Internal, Int-Inv, or External
3)TX CLK
Controls the clock used by the TSU 100 to accept the transmit (TX) data from the DTE. Normally this is set to
I
NTERNAL
shift in the data, the clock can be selected as
. If the interface cable is long, causing a phase
I
NT/INV
(Internal/Inverted). This switches the phase of the clock which should compensate for a long cable.
If the DTE provides a clock with TX data, the clock selec­tion is set to
E
XTERNAL
. The TSU 100 depends on an externally supplied clock to accept the TX data. Choices: Internal, Int-Inv, or External
4)DATA
Used to control the inverting of the DTE da ta. This inver­sion can be useful when operating with a High Level Data Link (HLDC) protocol. Often used as a means to ensure 1s density. Choices: Normal or Invert
5)CTS
Used to control characteristics of CTS. Choices: Normal or Force On (see Table 3-1 on page 3-7).
6)DCD
Data Carrier Detect - Indicates to the DTE when a valid signal is being received at the Network Interface. Choices: Normal or Force On (see Table 3-1 on page 3-7).
7)DSR (Data Set Ready)
This signal indicates to the DTE when the DCE is turned On and ready for operation. Choices: Normal or Force On (see Table 3-1 on page 3-7).
3-6 Nx56/64 (EIA-530) Option Module User Manual 61200054L2-1
Chapter 3. Operation
8)0 INHIB
The Nx interface detects an uninterrupted string of 0s
0
being transmitted toward the network. If ted for more than one second, the TSU 100 forces
are transmit-
S
1
S
towards the network. Choices: On or Off
Table 3-1 shows the conditions which cause the port con ­trol signal to be deactivated.
Table 3-1. Normal Mode Operation
SIGNAL RTS V.54
LOOPBACK
CTS Follows Off Off Off Off Off Off DCD - - - Off - Off Off DSR - Off Off Off Off Off -
- = Do not care Force On = On under all conditions
511 TEST ONSELF-TEST
ACTIVE
NETWORK
TEST ACTI VE
NO DS0
MAPPED
3)FACTORY RESTORE, Submenu of 3)UTIL
This selection is used to restore the factory default set­tings for all pass through option module parameters.
Operation
To return the unit to the opening main menu with all the factory default settings restored, do the following:
1. Follow the standard operating procedure to access
3)UTIL
the
2. With the cursor on
menu items.
3)FACT RESTORE
, press
NETWORK
ALARM
Enter.
61200054L2-1 Nx56/64 (EIA-530) Option Module User Manual 3-7
Chapter 3. Operation
5)PORT UTILITY, Submenu of 3)UTIL
5)PORT UTILITY
The cess the display of the current software information fo r each port installed in the unit. This information is re­quired when requesting assistance from ADTRAN Tech­nical Support or when updates are needed.
Operation
To display Figure 3-4 on the TSU 100, do the following:
1. Follow the standard operating procedure to access
3)UTIL
the
2. With the cursor on This displays the first available port.
menu items.
5
submenu is primarily used to ac-
5)PORT UTILITY
, press
Enter.
Figure 3-4. Port Utility Submenu
3-8 Nx56/64 (EIA-530) Option Module User Manual 61200054L2-1
Chapter 3. Operation
To display the port name and the software version in­stalled, as shown in Figure 3-5, do the following:
1. Use the
Scroll keys to move through the available
ports, or enter the port number with the number key.
2. When the desired port name is displayed, press
Enter.
3. Press
Cancel to exit or to select another port.
Figure 3-5. Port Name and Software Version Display
2)RUN SELF-TEST, Submenu of 4)Test
This menu item is used to execute both the internal test of the TSU 100 and of the Nx56/64 (EIA-530) option mod­ule. This is the same test executed during power-up. The results of the self-test are shown on the TSU 100 display. For additional information on self-test, see Chapter 3, Op- eration in the TSU 100 User Manual.
To activate a self-test, do the following:
1. Follow the standard operating procedure to access
4)TEST
the
2. With the cursor on
menu items.
2)RUN SELF-TEST
, press
Enter.
The TSU 100 display will show the test outcome.
61200054L2-1 Nx56/64 (EIA-530) Option Module User Manual 3-9
Chapter 3. Operation
3)PORT TEST, Submenu of 4)Test
This menu item is used to activate testing of specific data ports. It also controls the activation of loopbacks and the initiation of data test patterns. Test results are shown on the TSU 100 disp lay.
The execution of port tests disrupts normal data flow in the port being tested.
Operation
To display Figure 3-6 on the TSU 100, place the cursor on
3)PORT TEST
displays the available ports.
, and press
Enter or the number 3 key. This
Figure 3-6. Port Test Submenu
1.1 Nx56/64
The Nx interface offers the following test functions:
1)LOOPBK: Initiates a loopback.
PRT/LCL: The Nx port activates both a local loop­back (back toward the DTE) and a port loopback when either is invoked. See Chapter 1, Introduction, of the TSU 100 User Manual, for more information.
Remote: The remote loopback causes a V.54 code to be sent to the far end. The Nx at the far end activates a PRT/LCL loopback on detection of the V.54 code.
Off: The loop is deactivated.
3-10 Nx56/64 (EIA-530) Option Module User Manual 61200054L2-1
Chapter 3. Operation
The TSU 100 checks the remote loopback activation by detecting a proper response from the remote end. While waiting for the response, the display shows Looping. If successful, the display changes to Looped Up. If unsuccessful, the display shows Failed.
2)511 PATT: Activates the generation of the 511 test pat­tern.
On: The pattern check circuitry is enabled and a test started. The test is ended by selecting Off.
Off: The pattern generation and check is disabled.
3)DIS 511 RESLT: Displays the results of the 511 test indicated in item 2, above. The results are in the form of the number of errored seconds. The error count can be cleared by pressing
Clear (shift + 9).
61200054L2-1 Nx56/64 (EIA-530) Option Module User Manual 3-11
Chapter 3. Operation
3-12 Nx56/64 (EIA-530) Option Module User Manual 61200054L2-1

Appendix A System Messages

ALARM MESSAGES
Network Interface (NI)
Red Alarm
NI unable to align frame with incoming signal
Yellow Alarm
Remote alarm indication (RAI) being received from the far end
Blue Alarm
Unframed all 1s (AIS) being received at NI
Loss of Signal
No signal detected at NI
Nx56/64 Card
Clock Slip
Difference in frequency of the data clock at the network and DTE
PLL Alarm
Unable to lock phase lock on the clock provided by the network interface
Zeros Alarm
All 0s data being sent to the network interface
61200054L2-1 Nx56/64 (EIA-530) Option Module User Manual A-1
Appendix A. System Messages
FIFO Alarm
Error in propagation of data through the FIFOS
No EXT Clock
No external transmit clock at DTE (when applicable)
STATUS MESSAGES
Network Interface (NI)
Payload On
Payload loopback activated
Line On
Line loopback activated
Loopback Off
All loopbacks deactivated
Factory Restore
Factory setting restored
Power On
Unit powered on
Self-test
Internal self-test performed
A-2 Nx56/64 (EIA-530) Option Module User Manual 61200054L2-1
Nx56/64 Card
Appendix A. System Messages
Loop-Up
Data is looped back at both the network interface and the DTE interface of the card
Remote Loop Up
Sending a V.54 pattern in an attempt to loop-up a remote device
511 Pattern On
Sending a 511 pattern towards the network interface
Loop Down
Data is no longer looped back at the network interface or the DTE interface
511 Pattern Off
No longer sending a 511 pattern towards the network interface
61200054L2-1 Nx56/64 (EIA-530) Option Module User Manual A-3
Appendix A. System Messages
A-4 Nx56/64 (EIA-530) Option Module User Manual 61200054L2-1

Index

Numerics
1s Density Protection 1-3 511 Pattern Off 511 Pattern On
A-3
A-3
A
alarm messages A-1 attaching the plug-on board, how to
2-3
B
Blue Alarm A-1
C
Clock Options 1-2 Clock Slip Connector, DB-25 CTS, DCD, DSR Options Customer Provides
A-1
1-3
1-3
2-1
D
Data Inversion 1-3 DB-25 Winchester-style connection DB-25, connector DTE cable, provided by customer DTE Data/CK DTE Interface DTE Status
1-2
3-4
1-2
3-4
2-4
2-1
F
Factory Restore A-2 factory restore factory restore, operatio n Federal Communic ations commiss ion Radio Fre­quency Interfaerence Statement FIFO Alarm Front Panel Indicators/Buttons, See TSU 100 user manual
A-2
3-1
3-7
3-7
iv
I
installing the op t ion module, how to 2-2
L
limited product warranty v Line On Loop Down Loopback Off Loopbacks Loop-Up Loss of Signal
A-2
A-3
A-3
A-2
1-2
A-1
M
Menu Structure 3-1
N
Network Interface (NI), alarm messages A-1 Network Interface (NI), status messages No EXT Clock Nx interface, list an d descr iptio n of all tes t func ­tions
3-10 Nx56/64 (EIA 530, operation Nx56/64 (EIA-530), description Nx56/64 (EIA-530), features Nx56/64 (EIA-530), interfaces Nx56/64 (EIA-530), overview Nx56/64 (EIA-530), physical description Nx56/64 (EIA-530), power up and initial ization 2-5 Nx56/64 (EIA-530), wiring Nx56/64 Card Nx56/64 Card, system messages Nx56/64 Status Nx56/64, menu structure Nx56/64, submenus
A-2
A-3
3-4
3-1
1-2
1-2
1-1
2-4
3-1
3-2
A-2
1-1
1-4
A-1
P
Payload On A-2
61200054L2-1 Nx56/64 (EIA-530) Option Module User Manual Index-1
Index
3-4
3-10
A-2
A-1 3-5
3-8
3-5
3-10
3-8
2-3
2-5
PLL Alarm port config port config, operation Port Configuration submenu items Port Rate port test port test, operation port utility port utility, oper at ion power connec ti on Power On power-up and init ialization
R
Rates 1-2 Red Alarm Remote Loop Up run self-test
A-1
3-9
A-3
S
Self Test A-2 self-test, how to activate Shipments Include
3-9
2-1
A-2
1-2
3-3
Specifications, Nx56/64 Status menu
3-5
status menu, operation status messages
3-3
T
Test Pattern
511 w/ errored secon ds d isplay
Tests
1-3
1-3
U
Unpack & Inspect 2-1
W
Warranty and Custome r Service, Custome r Ser-
iv
vice
Y
Yellow Alarm A-1
Z
Zeros Alarm A-1
Index-2 Nx56/64 (EIA-530) Option Module User Manual 61200054L2-1
Product Support Information
Pre-Sales Inquiries and Applications Support
Please contact your local distributor, ADTRAN Applications Engineering, or ADTRAN Sales:
Applications Engineering (800) 615-1176 Sales (800) 827-0807
Post-Sale Support
Please contact your local distributor first. If your local distributor cannot help, please contact ADTRAN Technical Support and have the unit serial number avail­able.
Technical Support (888) 4ADTRAN
Repair and Return
If ADTRAN Technical Support determines that a repair is needed, Technical Sup­port will coordinate with the Customer and Product Service (CaPS) de partment to issue an RMA number. For information regarding equipment currently in house or possible fees associated with repair, contact CaPS directly at the following num­ber:
CaPS Department (256) 963-8722
Identify the RMA number clearly on the package (below address), and return to the following address:
ADTRAN, Inc. CaPS Depart ment 6767 Old Madison Pike Progress Center Building #6, Suite 690 Huntsville, AL 35807
RMA # _____________
Loading...
