ADT Safewatch Pro 3000EN Installation Manual

Download

Safewatch Pro

Safewatch Pro ® 3000EN

Safewatch Pro Safewatch Pro

Entrepreneur 3000EN

Entrepreneur 3000ENEntrepreneur 3000EN

Security Manager 3000EN

Security Manager 3000ENSecurity Manager 3000EN

3000EN

3000EN3000EN

Security Systems

Security SystemsSecurity Systems

Installation and Set-Up Guide

ARMED

READY

Meets ADT Security Services Triple Standards Requirements:

LISTED

Standards for Security and Fire

AWAY

STAY

OFF

BYPASS

TEST

CHIME

CODE

INSTANT

READY

ARMED

READY

STAY

AWAY

OFF

BYPASS

TEST

CHIME

CODE

INSTANT

READY

Standard for False Alarm Reduction

7 167-0495:110

California State Fire Marshal Approval

K5305V8 11/10 Rev. A - SIA Model SASW3000EN

RECOMMENDATIONS FOR PROPER PROTECTION

The Following Recommendations for the Location of Fire and Burglary Detection

Devices Help Provide Proper Coverage for the Protected Premises.

Recommendations For Smoke And Heat Detectors

With regard to the number and placement of smoke/heat detectors, we subscribe to the recommendations contained in the National Fire Protection Association's (NFPA) Standard #72 noted below.

Early warning fire detection is best achieved by the installation of fire detection equipment in all rooms and areas of the

household as follows: For minimum protection a smoke detector should be installed outside of each separate sleeping area, and on

each additional floor of a multi-floor family living unit, including basements. The installation of smoke detectors in kitchens, attics

(finished or unfinished), or in garages is not normally recommended.

For additional protection the NFPA recommends that you install heat or smoke detectors in the living room, dining room,

bedroom(s), kitchen, hallway(s), attic, furnace room, utility and storage rooms, basements and attached garages.

In addition, we recommend the following:

• Install a smoke detector inside every bedroom where a smoker sleeps.

• Install a smoke detector inside every bedroom where someone sleeps with the door partly or completely closed. Smoke could

be blocked by the closed door. Also, an alarm in the hallway outside may not wake up the sleeper if the door is closed.

DINING

LIVING ROOM

BEDROOM

LVNG RM

BASEMENT

KITCHEN

BEDROOM

TO BR

BEDROOM

KTCHN

BEDROOM

CLOSED

DOOR

KITCHEN

TV ROOM

LIVING ROOM

BEDROOM

Smoke Detectors for Minimum Protection

Smoke Detectors for Additional Protection

Heat-Activated Detectors

GARAGE

DINING

BDRM

floor_plan-001-V1

• Install a smoke detector inside bedrooms where

electrical appliances (such as portable heaters, air

conditioners or humidifiers) are used.

• Install a smoke detector at both ends of a hallway if

the hallway is more than 40 feet (12 meters) long.

• Install smoke detectors in any room where an alarm

control is located, or in any room where alarm

control connections to an AC source or phone lines

are made. If detectors are not so located, a fire

within the room could prevent the control from

reporting a fire or an intrusion.

THIS CONTROL COMPLIES WITH NFPA REQUIREMENTS FOR TEMPORAL PULSE SOUNDING OF FIRE NOTIFICATION APPLIANCES.

Recommendations For Proper Intrusion Protection

For proper intrusion coverage, sensors should be located at every possible point of entry to a home or commercial premises. This

would include any skylights that may be present, and the upper windows in a multi-level building.

In addition, we recommend that radio backup be used in a security system so that alarm signals can still be sent to the alarm

monitoring station in the event that the telephone lines are out of order (alarm signals are normally sent over the phone lines, if

connected to an alarm monitoring station).

Table Of Contents

•••••••••••••••••••••••••••••••••••••

Features and Installation Highlights ...................................................................................................................1-1

Capabilities .............................................................................................................................................................................................. 1-1

Functions................................................................................................................................................................................................. 1-1

Compatible Devices................................................................................................................................................................................. 1-2

Important Installation Highlights (Installer Please Read) .......................................................................................................................... 1-2

Mounting and Wiring the Control ........................................................................................................................2-1

Cabinet and Lock..................................................................................................................................................................................... 2-1

Mounting the PC Board Alone (no RF Receiver)...................................................................................................................................... 2-1

Mounting Board with RF Receiver............................................................................................................................................................ 2-2

Wiring to Touchpads................................................................................................................................................................................ 2-3

Sounder (Bell) Connections ..................................................................................................................................................................... 2-4

Wiring the AC Transformer...................................................................................................................................................................... 2-5

Backup Battery ........................................................................................................................................................................................ 2-6

Earth Ground ........................................................................................................................................................................................... 2-6

Hardwire Zones ....................................................................................................................................................................................... 2-8

Smoke Detectors..................................................................................................................................................................................... 2-8

4219/4229 Expansion Zones ................................................................................................................................................................. 2-10

Installing the RF Receiver...................................................................................................................................................................... 2-11

Installing a 5800TM Module................................................................................................................................................................... 2-12

Installing the Transmitters...................................................................................................................................................................... 2-12

Installing a Keyswitch ............................................................................................................................................................................ 2-13

Connecting Relay Modules .................................................................................................................................................................... 2-14

Powerline Carrier Devices...................................................................................................................................................................... 2-15

On-Board Triggers ................................................................................................................................................................................. 2-16

Phone Line/Phone Module Connections ................................................................................................................................................ 2-17

Audio Alarm Verification Connections (AAV, “Listen-In”)........................................................................................................................ 2-19

Long Range Radio (Communication Device) Connections..................................................................................................................... 2-22

Programming Overview ........................................................................................................................................3-1

About Programming................................................................................................................................................................................. 3-1

Zones and Partitions................................................................................................................................................................................ 3-1

Touchpads............................................................................................................................................................................................... 3-2

Wireless Receiver, Transmitters, and Wireless Keys (keyfobs) ............................................................................................................... 3-2

Pager Programming................................................................................................................................................................................. 3-2

Function Keys.......................................................................................................................................................................................... 3-3

Output Devices........................................................................................................................................................................................ 3-3

Zone Type Definitions.............................................................................................................................................................................. 3-3

Mechanics of Programming ..................................................................................................................................................................... 3-5

Data Field Programming.......................................................................................................................................4-1

About Data Field Programming................................................................................................................................................................ 4-1

Programming Data Fields ........................................................................................................................................................................ 4-1

System Setup Fields (∗20 – ∗29) ............................................................................................................................................................. 4-1

Zone Sounds & Timing (∗31–∗39)............................................................................................................................................................ 4-2

Dialer Programming (∗40 – ∗50) .............................................................................................................................................................. 4-3

System Status Report Codes (∗59–∗68) .................................................................................................................................................. 4-5

Restore Report Codes (∗70–∗76)............................................................................................................................................................. 4-7

Miscellaneous System Fields................................................................................................................................................................... 4-7

Pager Programming Fields .................................................................................................................................................................... 4-11

Miscellaneous System Fields................................................................................................................................................................. 4-12

Configurable Zone Type Programming Fields........................................................................................................................................ 4-13

iCenter (AUI) Enable.............................................................................................................................................................................. 4-13

Touchpad Programming Fields .............................................................................................................................................................. 4-16

Zone Programming................................................................................................................................................5-1

About Zone Programming........................................................................................................................................................................ 5-1

∗56 Zone Programming Procedure .......................................................................................................................................................... 5-1

Completing Zone Programming ............................................................................................................................................................... 5-5

∗58 Expert Programming Mode Procedures............................................................................................................................................. 5-5

Wireless Key Programming Templates.................................................................................................................................................... 5-7

Output Device Programming................................................................................................................................6-1

About Output Device Programming ......................................................................................................................................................... 6-1

*79 Menu Mode: Output Device Mapping................................................................................................................................................. 6-1

*80 Menu Mode: Defining Output Functions............................................................................................................................................. 6-3

Zone Lists...............................................................................................................................................................7-1

About Zone Lists...................................................................................................................................................................................... 7-1

Zone List Programming ........................................................................................................................................................................... 7-1

iii

Table Of Contents (continued)

Function Key Programming .................................................................................................................................8-1

About Function Key Programming ........................................................................................................................................................... 8-1

Programming Function Keys.................................................................................................................................................................... 8-1

Alpha Descriptor Programming ...........................................................................................................................9-1

About Descriptor Programming................................................................................................................................................................ 9-1

Programming Zone Descriptors (Menu Mode ∗82)................................................................................................................................... 9-1

Adding Custom Words (will not be annunciated by 4286 Phone Module)................................................................................................. 9-3

Creating Schedules .............................................................................................................................................10-1

About Schedules.................................................................................................................................................................................... 10-1

∗∗∗∗29 IP/GSM Menu Mode ......................................................................................................................................11-1

∗29 Communication Device Menu Mode (Pass-Through Programming)................................................................................................ 11-1

∗29 IP/GSM Program Mode Procedure.................................................................................................................................................. 11-1

AVS System Enable and Quick Program Commands......................................................................................12-1

AVS Command Procedure..................................................................................................................................................................... 12-1

Quick Program Command Results......................................................................................................................................................... 12-1

System Communication......................................................................................................................................13-1

Report Code Format (Ademco Contact ID)............................................................................................................................................ 13-1

Uploading/Downloading via the Internet ................................................................................................................................................. 13-3

System Operation................................................................................................................................................14-1

Security Codes ...................................................................................................................................................................................... 14-1

Touchpad Functions .............................................................................................................................................................................. 14-3

Setting the Real-Time Clock .................................................................................................................................................................. 14-4

Various System Trouble Displays .......................................................................................................................................................... 14-5

Testing the System..............................................................................................................................................15-1

About Test Procedures .......................................................................................................................................................................... 15-1

System Test .......................................................................................................................................................................................... 15-1

Go/No Go Test Mode............................................................................................................................................................................. 15-2

Dialer Communication Test and Periodic Test Reports.......................................................................................................................... 15-3

Specifications & Accessories ............................................................................................................................16-1

SECURITY CONTROL .......................................................................................................................................................................... 16-1

COMPATIBLE DEVICES....................................................................................................................................................................... 16-1

5800 Series Transmitter Input Loop Identification .................................................................................................................................. 16-2

Regulatory Agency Statements .........................................................................................................................17-1

Limitations and Warranty ...................................................................................................................................18-5

SECTION 1

Features and Installation Highlights

•••••••••••••••••••••••••••••••••••••••

This ADT system is a SIA-compliant control (in accordance with ANSI/SIA standard CP-01-2000 control unit standard-features for false alarm reduction).

This system is a 2-partition control with the following major features:

Capabilities

• 2 partitions; can protect two independent areas, as if each area had its own separate control.

• Common zone option allows either partition to arm, while leaving a common area (ex. lobby or

foyer) disarmed for access into the other partition.

• 48 protection zones plus 16 keyfob zones (zones 49-64) for a total of 64 zones:

-- 8 basic hardwired zones (zones 1-8)

-- Up to 40 additional wired zones (zones 9-48) using up to 5 4219/4229 modules.

-- Up to 40 wireless transmitter zones (5800 series; zones 9-48)

-- Supports up to 4 configurable zone types

• Up to 48 Security Codes, each with separate authority levels and partition access

• Up to 3 programmable panic key functions; reported separately by partition, distinguished by

subscriber ID number

• Communication Format: Ademco Contact ID

• Downloading via phone line using an IBM compatible computer, Compass downloading software,

and a compatible HAYES or CIA modem specified by Honeywell.

• Downloading via Internet/Intranet when used with an appropriate communications device (ex.

7845i-ent, 7845GSMADT) and Compass downloading software. This allows site maintenance independent of central station monitoring, and modification to sites globally via the Internet.

UL NOTE: Uploading/Downloading via the Internet has not been evaluated by UL

Functions

• Single-button arming feature: Can use up to 2 dedicated touchpad keys on Custom English Display

touchpads to arm the system AWAY, STAY, or NIGHT-STAY

• Scheduling, which can control devices and/or auto-arm/disarm the system

• Up to 4 touchpad macros, which can be activated by wired touchpads

• Paging feature allows certain system conditions to be reported to up to 4 pager phone numbers; can

use a dedicated key on touchpads to send a signal to a pager

• Built-in Telephone Line Monitoring option can monitor the telephone line voltage and can cause a

local display, or a display and trouble/alarm sound.

• Event Logging records up to 100 selected events in a history log (control and readout from the log is

done via Ademco Compass Downloader software or installer/master code at Touchpad).

• Zone descriptors for all zones (useful only when using Custom English display touchpads and/or the

4286 Phone Module).

• Optional bell supervision detects external sounder wiring short

off); causes a trouble condition, touchpad display, and sends a report to the central monitoring station, if enabled.

• Optional RF jam detection for wireless systems detects a condition that may impede proper RF

reception (i.e., jamming or other RF interference); causes touchpad display, and sends a report to the central monitoring station (if trouble reporting is enabled).

(when in alarm) or open (when bell is

1-1

3000EN Series: Installation and Setup Guide

Compatible Devices

• Supports up to 8 Addressable Touchpads: English Display Touchpad (6150ADT), Custom English

Display Touchpad (6160ADT), and Custom English Display Voice Touchpad (6160VADT)

• Supports up to four iCenter (AUI) or 6270ADT touch screen devices in addition to up to 8

touchpads (described above).

• Supports up to five (5) 4219, 4229 addressable zone expander modules for up to 40 expansion zones

• Up to 16 output relays and/or Powerline Carrier Devices (X-10 type) plus two on-board triggers

-- Use any combination of 4204, 4229 and or Powerline Carrier Devices.

-- Up to 48 output functions

• Ademco 4286 Phone Module (Part. 1 only); provides access to the system via on premises or off-

premises phones for arming, disarming, etc., plus control of relay outputs and Powerline Carrier devices.

• Audio Alarm Verification (using AAV module, such as ADEMCO UVS); can be used in conjunction

with an output trigger to permit voice dialog between an operator at the central station and a person at the premises. Alternatively, the AVS-ADT system can be used to provide AAV via phone line or AlarmNet IP/GSM (using a GSMV-ADT module).

• Alarm output provides a 12VDC, 2 AMP output that can drive the compatible sounders; steady

output for burglary/panic, or temporal pulse output (3 pulses – pause – 3 pulses – pause – 3 pulses. . .) for fire. Uses current limiting circuitry for protection.

• Auxiliary Power Output: 12VDC, 600 mA maximum (uses circuit protection).

• Backup Battery: Rechargeable (sealed lead-acid type) 12VDC, 4AH minimum.

• Long Range Radio (Communication Device): Primary telephone number messages can be reported

via ECP connection to various communication devices (check compatibility and availability of specific models)

• AC Power Supply: Plug-in 120VAC transformer, ADEMCO 1321 (1321CN in Canada) or, if using

Powerline Carrier devices, ADEMCO 1361X10 Transformer Module

NOTE: All devices and accessories used in a Canadian installation must be Listed for use in Canada.

Important Installation Highlights (Installer Please Read)

• This system uses addressable touchpads and Zone Expander Modules (see table of addresses in

Programming Overview section).

• Touchpads must be set for addresses 16-23 (first touchpad is address 16, which is different from

previous controls) and programmed in data fields *190-*196.

• Zone Expander Modules must be set for specific addresses (07-11), based on the zone numbers used

(see table of addresses in 4219/4229 Expansion Zones section).

• 4204 Relay Modules must be set for specific addresses (12-15; see Connecting Relay Modules

section).

• This control will not power-up unless AC power is connected (will not power-up on battery alone).

However, once the system is powered up, it will operate on battery power in the event of AC loss.

• Relays have two programming menu modes: Use *79 Menu mode to map module addresses and

device (output) numbers. Use *80 Menu mode to define the output functions (see Output Device Programming section).

• This system supports programmable function keys. Use *57 Menu mode to define the function keys

(see Function Key Programming section).

• This system provides various paging features. Refer to the Programming Overview section for a

summary on pager programming.

1-2

SECTION 2

Mounting and Wiring the Control

•••••••••••••••••••••••••••••••••••••••

This section describes the procedures for mounting and wiring this control and its peripheral devices. In the following subsections, procedures are listed in the left column, while notes and pertinent explanations are provided in the right column.

Cabinet and Lock

1. Mount the control cabinet to a sturdy wall in a clean, dry area, which is not readily accessible to the general public, using fasteners or anchors (not supplied) with the four cabinet mounting holes.

2. Remove cabinet door, then remove the lock knockout from the door. Insert the key into the lock.

3. Position the lock in the hole, making certain that the latch will make contact with the latch bracket when the door is closed. When correctly positioned, push the lock until it is held securely by its snap tabs.

Notes

• The cabinet can be closed and secured without a lock by using 2 screws in the cover's edge.

PUSH

ON LOCK

CHECK

POSITION

LOCKED

PUSH

SNAP

TAB

UNTIL IT IS SEATED SECURELY

SNAP

TAB

STEP 2STEP 1

cab_lock_snap-001-V0

UNLOCKED

CABINET DOOR

BOTTOM

Figure 1. Installing the Cabinet Lock

Mounting the PC Board Alone (no RF Receiver)

1. Hang two short mounting clips (provided) on the raised cabinet tabs (see Detail B in Fig. 2).

2. a. Insert the top of the circuit board into the slots at the top of the cabinet. Make sure that the board rests on the correct row (see Detail A).

b. Swing the base of the board into the mounting clips and secure the board to the cabinet with

the accompanying screws (see Detail B).

Notes

• Before installing the cabinet's contents, remove the metal cabinet knockouts required for wiring

entry. Do not remove the knockouts after the circuit board has been installed.

CIRCUIT

BOARD

DETAIL A

SIDE VIEW

OF BOARD

SUPPORTING

SLOTS

CABINET

CIRCUIT

BOARD

DETAIL B

SIDE VIEW

OF MOUNTING

CLIPS

CABINET

Figure 2. Mounting the PC Board

ADT3000-013-V0

2-1

3000EN Series: Installation Instructions

Mounting Board with RF Receiver

1. a. Remove the receiver board from its case, then insert the top of the board into the slots at the top

of the cabinet, as shown in Detail A in Figure 3. Make sure that the board rests on the correct row of tabs.

b. Swing the base of the board into the mounting clips and secure it to the cabinet with the

accompanying screws.

c. Insert the top of the control's board into the slot in the clips and position two clips at the lower

edge of the board.

d. Swing this board into place and secure it with two additional screws.

2. Insert grounding lugs (supplied with the receiver) through the top of the cabinet into the left-

hand terminals of the antenna blocks (at the upper edge of the receiver board) and secure them to the cabinet top with the screws provided, as shown in Detail B.

3. Insert the receiver's antennas through the top of the cabinet, into the blocks' right-hand

terminals, and tighten the screws.

Notes

• Do not mount the cabinet on or near metal objects. This will decrease RF range and/or block RF

transmissions from wireless transmitters.

• Do not locate the cabinet in an area of high RF interference (revealed by frequent or prolonged

lighting of the LED in the receiver after it is operational (random flicker is OK)

CABINET

RECEIVER CIRCUIT BOARD

CONTROL

CIRCUIT

BOARD

INSTALLATION WITH RECEIVER CIRCUIT BOARD

WHITE

MOUNTING

CLIP

NOTE A COMBINATION OF THESE MOUNTING CLIPS HAS BEEN INCLUDED IN YOUR INSTALLATION KIT. USE THE APPROPRIATE CLIPS FOR MOUNTING.

IF NO RF RECEIVER IS USED, MOUNT THE PC BOARD USING EITHER THE WHITE OR BLACK CLIPS, WHICHEVER ARE INCLUDED IN THE CONTROL PANEL'S HARDWARE KIT.

BLACK

MOUNTING

CLIP

RED

MOUNTING

CLIP

Figure 3. Mounting the PC Board and RF Receiver

BOARD SUPPORTING SLOTS

MOUNTING CLIP

CABINET

CIRCUIT

BOARD

DETAIL A

SIDE VIEW

OF BOARD -

SUPPORTING SLOTS

ANTENNA

(2)

SCREW

(2)

GROUNDING

LUG

(2)

ANTENNA

MOUNT

(2 PLACES)

DETAIL B

ANTENNA AND GROUNDING

LUG INSTALLATION

pc_mount-001-V1

2-2

Mounting and Wiring the Control

Wiring to Touchpads

1. Connect touchpads to the control’s touchpad terminals as shown on the Summary of Connections

diagram.

Determine wire size using the Wire Run Chart on the next page.

2. Set Touchpad Addresses (first touchpad is address 16). Refer to the address setting instructions

included with the touchpads and set each touchpad device address according to the Touchpad Addresses chart below.

3. Program the touchpad addresses, partition assignments and sound options in data fields *190-*196.

NOTE: Each touchpad must be assigned a unique address, starting at address 16. Touchpads

programmed with the same address will give unpredictable results.

Supplementary Power (optional)

1. Connect as shown. Be sure to connect the negative (–) terminal on the power supply unit to

terminal 4 (AUX –) on the control.

SUPPLEMENTARY

POWER SUPPLY

–

CONTROL TERMINAL STRIP

AUX. DATA

AUX.

–

456 7

DATA

OUT

IMPORTANT:

MAKE THESE CONNECTIONS DIRECTLY TO SCREW TERMINALS AS SHOWN.

TO TOUCHPAD RED WIRE

TO TOUCHPAD BLK WIRE

TO TOUCHPAD YEL WIRE

TO TOUCHPAD GRN WIRE

TO TOUCHPAD BLK WIRE

TO TOUCHPAD RED WIRE

TO TOUCHPAD GRN WIRE

TO TOUCHPAD YEL WIRE

pwr_supply-001-V0

Figure 4. Using a Supplementary Power Supply

Notes

• Typical English Display: 6150ADT

• Typical Custom English Display: 6160ADT

• Typical Voice Touchpad: 6160VADT

• AUI: iCenter (see note below) or 6270ADT Touch Screen

• The system supports up to 8 addressable touchpads, which can be assigned to partitions in any

combination (see program fields *190-*196).

• For single 4-wire runs, determine the current drawn by all units, then refer to the Wiring Run

chart to determine the maximum length that can be safely used for each wire size.

• Use supplementary power if the control’s aux. power load for all devices exceeds 600mA.

Suggested power supply: AD12612

Touchpad Addresses AUI Device Addresses

Touchpad Address Touchpad Address AUI Device Address

no. 1 16** no. 5 20 device 1 1 no. 2 17 no. 6 21 device 2 2 no. 3 18 no. 7 22 device 3 5 no. 4 19 no. 8 23 device 4 6

** The first Touchpad is address 16, which is always enabled and set for partition 1 with all sounds on.

AUI NOTE: Use of up to four AUI devices is independent from standard touchpads and does not affect the number of standard touchpads the system can support. AUI touchpads must be set for addresses according to the AUI Device Addresses chart above, depending on which units are enabled in field *189.

2-3

3000EN Series: Installation Instructions

Use a UL Listed, battery-backed supply for UL installations. The battery supplies power to these touchpads in

case of AC power loss. The battery-backed power supply should have enough power to supply the touchpads with the UL required minimum standby power time.

Touchpads powered from supplies that do not have a backup battery will not function if AC power is lost.

Make sure to power at least one touchpad in each partition from the control’s auxiliary power output.

Wire Run Chart For Devices* Drawing Aux Power From The Control (12V+ & 12V–)

Wire

TOTAL CURRENT DRAWN BY ALL DEVICES CONNECTED TO A SINGLE WIRE RUN

Size 50 mA or less 100 mA 300 mA 500 mA 600 mA

#22 900 ft (274m) 450 ft (137m) 150 ft (46m) 90 ft (27m) 75 ft (23m) #20 1400 ft (427m) 700 ft (213m) 240 ft (73m) 140 ft (43m) 120 ft (37m) #18 1500 ft (457m) 1100 ft (335m) 350 ft (107m) 220 ft (67m) 170 ft (52m) #16 1500 ft (457m) 1500 ft (457m) 550 ft (168m) 350 ft (107m) 270 ft (82m)

* Includes Touchpads, RF Receivers, Zone Expander/Relay Units, 4286 Phone Module and communication device. Maximum wire

lengths for any device that is homerun to the control can also be determined from the Wiring Run Chart, based on the current draw of that device alone

. The length of all wire runs for both partitions combined must not exceed 1500 feet (457m) when unshielded quad conductor cable is used (750 feet if shielded cable is used). This restriction is due to the capacitive effect on the data lines when quad cable is used.

Sounder (Bell) Connections

1. Make sounder connections to alarm output terminals 3 (+) and 4 (–).

For supervised output, continue with steps 2 and 3.

2. Cut the red Bell Supervision Jumper located above terminal 5 on the control board.

3. Connect a 2k ohm resistor across the terminals of the last sounder.

TERMINALS ON

CONTROL BOARD

EXTERNAL ALARM

SOUNDER

ALARM

OUTPUT

TERMINALS

CUT RED JUMPER ON CONTROL BOARD TO ENABLE BELL (SOUNDER) SUPERVISION.

IF BELL SUPERVISION IS ENABLED IN FIELD 91 (AND RED JUMPER ON CONTROL BOARD IS CUT) CONNECT A 2000 OHM RESISTOR ACROSS THE EXTERNAL SOUNDER AS SHOWN BY THE DOTTED LINE.

DO NOT CONNECT THE RESISTOR AT THE ALARM OUTPUT TERMINALS THEMSELVES!

OBSERVE POLARITY

2000 OHM EOL RESISTOR

50-sounder-001-V0

Figure 5. Sounder Wiring (Supervised)

Notes

This control complies with NFPA requirements for temporal pulse sounding of fire notification appliances. Temporal pulse sounding for a fire alarm consists of: 3 pulses – pause – 3 pulses – pause – 3 pulses–etc..

• The 12VDC sounder output activates when an alarm occurs.

• Total current drawn from this output cannot exceed 2 amps (going beyond 2 amps will overload the

power supply, or may cause the electronic circuit protecting the sounder output to trip).

• You must install a battery, since the battery supplies this current.

• Use only UL Listed sounding devices for UL installations.

• Bell supervision is required for fire alarm installations.

• The total current drawn from the alarm output and the auxiliary power output, combined, cannot exceed 600mA.

In addition, the sounding device must be a UL Listed audible signal appliance rated to operate in a 10.2-13.8 VDC voltage range, and must be mounted indoors.

2-4

Mounting and Wiring the Control

Wiring the AC Transformer

1321 Transformer

Connect the 1321 Transformer to terminals 1 and 2 on the control board. See Wire Run Chart below for wire size to use. Use 1321CN in Canada.

1361X10 Transformer (required if using Powerline Carrier devices)

1. Splice one end of a 3-conductor cable to the wire ends of the SA4120XM-1 Cable.

2. Connect the SA4120XM-1 cable plug to the 8-pin connector on the control (see the Summary of Connections diagram for location of the 8-pin connector).

3. Connect the other end of the 3-conductor cable to the 1361X10 Transformer, as shown.

Canada: See Powerline Carrier Device section for connections to the PSC04 X-10 Interface and trigger pins. Notes

• Use caution when wiring the transformer to the control to guard against blowing the transformer

fuse (the fuse is non-replaceable).

• Wiring to the AC transformer must not exceed 250 feet using 16 gauge wire. The voltage level between terminals 1 and 2 of the control must not fall below 16.5VAC or else an “AC LOSS” message will be displayed.

• Do not plug the transformer into the AC outlet while making any wiring connections to the control. As a safety precaution, always power down the control when making such connections.

Wire Run Chart

Distance from control Wire Size

Up to 50 feet # 20 50–100 feet # 18 100-250 feet # 16

8-PIN TRIGGER CONNECTOR

1 345678

KEY

1361X10 TRANSFORMER

AC AC

CONTROL

BOARD

TERMS.

SYNC

COM DATA

(RED)

OUTPUT 17

(GREEN)

(YELLOW)

(ORANGE)

GND (-)

+12 AUX.

OUTPUT 18

(BLUE)

(PURPLE)

COM

DATA

Figure 4. 1361X10 Transformer Connections

(BLACK)

SYNC

SA412OXM-1 CABLE

00-trigcon-001-V2

2-5

3000EN Series: Installation Instructions

Backup Battery

1. Place the 12-volt backup battery in the cabinet.

2. After all connections to the control are completed, connect the red and black flying leads on the control board to the battery. Do not attach these leads to the battery terminals until all connections are completed.

Battery Saver Feature: The battery will disconnect from the system after its voltage decreases

below 9VDC. This assists the control panel in recharging the battery when AC is restored.

Notes

IMPORTANT: The panel will not power up initially on battery power only. You must plug the transformer in first, and then connect the battery.

For UL installations and Residential fire installations, refer to the chart below for the correct battery size

required to meet the mandatory standby time.

CALIFORNIA STATE FIRE MARSHALL (CSFM) AND UL RESIDENTIAL FIRE

The California State Fire Marshal and UL have regulations which require that all residential fire alarm control panels must be provided with a backup battery which has sufficient capacity to operate the panel and its attached peripheral devices for 24 hours in the intended standby condition, followed by at least 4 minutes in the intended fire alarm signaling condition. This control panel can meet these requirements without using a supplementary power supply, provided that the panel’s auxiliary power and bell output currents are limited as indicated below.

OUTPUT LIMITATIONS TO MEET CSFM 24 HOUR BATTERY BACKUP REQUIREMENTS

OUTPUT CURRENT LIMITATIONS BATTERY INFORMATION

Output Current Total Maximum Auxiliary Current Battery Capacity

600mA maximum total of

auxiliary power plus bell

output currents

‡ NOTE: Use two batteries, connected in parallel. Use Ademco Battery Harness Kit SA5140-1. (Both batteries fit inside the cabinet.)

Earth Ground

Metal Cold Water Pipe:

Use a non-corrosive metal strap (copper is recommended) firmly secured to the pipe to which the ground lead is electrically connected and secured.

AC Power Outlet Ground:

Available from 3-prong, 120VAC power outlets only. To test the integrity of the ground terminal, use a 3-wire circuit tester with neon lamp indicators, such as the UL Listed Ideal Model 61-035, or equivalent, available at most electrical supply stores.

Notes

• This product has been designed and laboratory-tested to ensure its resistance to damage from

generally expected levels of lightning and electrical discharge, and does not normally require an earth ground.

• If an earth ground is desired for additional protection in areas of severe electrical activity, terminal

25 on the control board, or the cabinet, may be used as the ground connection point. The examples of good earth grounds listed at the left are available at most installations.

24-HOUR BATTERY BACKUP REQUIREMENTS

AND UL RESIDENTIAL FIRE INSTALLATIONS

To Use (Amp/Hrs)

45mA 160mA 200mA 425mA 500mA

4AH 7AH 8AH

14AH

17.2AH

Recommended Battery

(Yuasa Model No.)

NP4-12 (or ADEMCO 467)

NP7-12 NP4-12 (two) ‡ NP7-12 (two) ‡ NPG18-12

2-6

AUXILIARY DEVICE CURRENT DRAW WORKSHEET

DEVICE CURRENT # UNITS TOTAL

CURRENT

6150ADT Touchpad 40mA

(70mA alarm) 6160VADT Voice Touchpad 6270ADT Touch Screen

60mA

(190mA alarm)

180mA/220mA

††

(280mA alarm)

8132ADT iCenter

150mA/350mA

††

(200mA/400mA†† alarm)

5881/5882 RF Receiver 60mA

5883 Transceiver 80mA

4219 Zone Expander 30mA

4204 Relay Unit

15/180mA

‡

4229 Zone Expander/Relay Unit

30/100mA

‡

4286 Phone Module 300mA

Mounting and Wiring the Control

* If using hardwire devices such

as PIRs, refer to the specifications for that particular unit's current draw.

†

In UL installations, maximum current draw from the Auxiliary Output and the Alarm Output combined must not exceed 600 mA (500 mA max from Auxiliary Output).

‡

Figures are for relays OFF/relays ON.

††

backlighting off/backlighting on

†

(Current available from Aux. terminals = 600 mA max.)

TOTAL =

2-7

3000EN Series: Installation Instructions

Hardwire Zones

Normally Open Zones/ Normally Open EOLR Zones

1. Connect open circuit devices in parallel across the loop; for EOLR zones, connect the EOLR across the loop wires at the last device.

2. Enable normally open/EOLR zones using Zone Programming mode, “Hardwire Type” prompt.

Normally Closed Zones/Normally Closed EOLR Zones

1. Connect closed circuit devices in series in the high (+) side of the loop; for EOLR zones, connect the EOLR in series following the last device.

2. Enable normally closed/EOLR zones using Zone Programming mode, “Hardwire Type” prompt.

Notes

• EOLR: If the EOLR is not at the end of the loop, the zone will not be properly supervised, and the

system may not respond to an open circuit on the zone.

• Zone 1 is intended for EOLR only.

For UL commercial burglar alarm installations, use EOLR zones.

Smoke Detectors

2-Wire Smoke Detectors

1. Connect up to sixteen 2-wire smoke detectors across zone 1 terminals 8 (+) and 9 (-) as shown in the Summary of Connections diagram at the back this manual. Observe proper polarity when connecting the detectors.

2. Connect an EOL resistor across the loop wires at the last detector.

4-Wire Smoke Detectors

Connect up to 16 (depending on detector current draw) 4-wire smoke detectors to any zone 2-8 as

shown on the next page. This control does not automatically reset power to 4-wire smoke detector zones, so you must use a relay (e.g., 4204, 4229), or on-board trigger** to reset power (also required for fire verification). Do this by programming the designated relay/trigger as zone type 54 (fire zone reset); see On-Board Trigger section for other information.

** Maximum current for trigger 17 output for 4-wire smoke detectors is 100mA.

Notes

•••• Fire Verification (zone type 16): The control panel will “verify” a fire alarm by resetting the

smoke detectors after the first alarm trigger (removes power 7 seconds for zone 1; 3 seconds for trigger output), and then waiting up to 90 seconds for a second alarm trigger. If the smoke detector or thermostat does not trigger again, the control will disregard the first trigger, and no alarm signal will occur. This feature eliminates false alarms due to electrical or physical transients.

SIA Installations: If using fire verification on zones other than zone 1, UL Fire Alarm Listed relay

accessories must be used to reset power as described in 4-Wire Smoke Detectors paragraph above.

• The zone 1 alarm current supports only one smoke detector in the alarmed state.

• Do not use 4-wire smoke detectors on zone 1.

• Detector Reset Display: During smoke detector reset, “FAULT XX” is displayed (about 6 seconds)

and should disappear if the detector is clear.

2-8

Mounting and Wiring the Control

AUX PWR

OUTPUT

TERMINALS

CONTACT OPENS

MOMENTARILY UPON

FIRE ALARM RESET

TO ZONE TERM. ( )

PROGRAM

RELAY

AS ZONE

TYPE 54

(FIRE ZONE

RESET)

RELAY

N.C.

4-WIRE SMOKE

OR COMBUSTION

HEAT

DETECTOR

BLK

2000

OHMS

EOLR

VIOLET

N.O.

RED

EOL POWER SUPERVISION RELAY MODULE A77-716B. USE N.O. CONTACT, WHICH CLOSES WHEN POWER IS APPLIED.

4_wiresmk-007-V0

Figure 7a. 4-Wire Smoke Detector Using Relay for Power Reset

( )

DETECTOR

4-WIRE SMOKE

OR COMBUSTION

DETECTOR

HEAT

BLK

2000

OHMS

EOLR

N.O.

VIOLET

RED

EOL POWER SUPERVISION RELAY MODULE A77-716B. USE N.O. CONTACT, WHICH CLOSES WHEN POWER IS APPLIED.

4_wiresmk-008-V0

AUX PWR

TO OUTPUT 17

PROGRAM OUTPUT 17

FOR "OUT NORM

LOW" = YES IN 79 MENU

MODE AND AS ZONE

TYPE 54 IN

80 MENU MODE

TO ZONE TERM. ( )

Figure 7b. 4-Wire Smoke Detector Using Output 17 for Power Reset

2-9

3000EN Series: Installation Instructions

4219/4229 Expansion Zones

1. Connect each module to the control’s touchpad terminals.

2. Assign each module a unique device address (07-11) using its DIP switches. Device addresses are based on the zone numbers being used, as shown below.

Expander Module Addresses

For Zones… Set Module to Device Address… (see DIP chart)

09-16 07 17-24 08 25-32 09 33-40 10 41-48 11

3. Connect sensors to the module’s loops.

4. If using relays with the 4229, connect the desired field wiring to the unit's relay contact terminals.

Notes

• The system supports up to 40 expansion zones (NO or NC) using up to five (5) 4219 and/or 4229

Zone Expander Modules.

• Use 1000 ohm end-of-line resistors at the end of loops connected to the 4219/4229 modules. (End-of

line resistors used on the control are 2000 ohms.)

•

Expansion zones have normal response time (300–500 msec), except zone connected to each module’s loop “A,” which can be set for fast response (10–15 msec).

4219/4229 DIP Switch Address Settings

SW ADDRESS

7 8 9 10 11 2 off ON off ON off 3 off ON ON off off 4 off ON ON ON ON 5 ON off off off off

RELAY

CONNECTOR

VIO

YEL

BRN

BLK

GRY

GND

NONCC

RLY

RELAYS OFF

ORG

NONCC

RLY

Figure 8. Wiring Connections, 4219 & 4229 (4229 shown)

WHT

NO C NC

REED

(TAMPER)

SWITCH

ZONES

RELAY

TAMPER JUMPER POSITION

4229 IN CABINET (NOT TAMPER)

4229 REMOTE (TAMPER PROTECTED)

DIP SWITCH

FOR SETTING ADDRESS AND ZONE "A" RESPONSE

4 6

EITHER OR BOTH CAN BE USED

4-PIN CONSOLE PLUG

TB1

4229

TB2

GRN

BLK

4 3

RED

YEL

TERMINATE EACH PROGRAMMED ZONE WITH 1000 OHM (1K) END-OF-LINE RESISTOR (EACH ZONE'S MAX. LOOP RESISTANCE 300 OHMS + EOL)

DATA OUT (>) TO CONTROL

(–) GROUND

(+) 12VDC

DATA IN (<) FROM CONTROL

TERMINALS ON

CONTROL PANEL

(TERM 6)

(TERM 4)

(TERM 5)

(TERM 7)

4229-002-V0

2-10

Mounting and Wiring the Control

Installing the RF Receiver

Use any 5800 Series Wireless Receivers, such as:

RF Receiver No. of Zones

5881L/5882L up to 8 5881M/5882M up to 16 5881H/5882H up to 40 plus 16 button zones 5883, 6150RFADT

Zone Nos.: transmitters = 9-48; buttons = 49-64

1. Set Device Address to “00” as described in its instructions (set all switches to the right, “off” position).

2. Mount the receiver, noting that the RF receiver can detect signals from transmitters within a nominal range of 200 feet.

3. Connect the receiver's wire harness to the control's touchpad terminals. Plug the connector at the other end of the harness into the receiver. Refer to the installation instructions provided with the receiver for further procedures regarding antenna mounting, etc.

Notes

• The receiver is supervised and a trouble report is sent (“CHECK 100” displayed) if communication

between the panel and receiver is interrupted, or if no valid RF signals from at least one supervised transmitter are received within 12 hours.

If the receiver is mounted remotely:

• Place the RF receiver in a high, centrally located area for best reception.

• Do not locate the receiver or transmitters on or near metal objects. This will decrease range and/or

block transmissions.

• Do not locate the RF receiver in an area of high RF interference (indicated by frequent or prolonged

lighting of the LED in the receiver; random flicker is OK).

• Do not locate RF receiver closer than 10 feet from any touchpads to avoid interference from the

microprocessors in those units.

NOTE

CIRCUIT BOARD IS MOUNTED IN CONTROL'S CABINET. GROUNDING LUGS (2) PROVIDED IN LEFT-HAND TERMINALS OF ANTENNA BLOCKS AND SECURED TO CABINET. (SEE RECEIVER'S AND CONTROL'S INSTRUCTIONS)

MUST

BE INSERTED

ANTENNAS

(INSERT IN

RIGHT-HAND

TERMINALS)

INSERT IN

RIGHT- HAND

TERMINALS

MOUNTING

HOLES

YELLOW

MODEL NO. IS INDICATED ON CIRCUIT BOARD

5882

LOCATION

INTERFERENCE

INDICATOR

LED

CIRCUIT BOARD

TO RELEASE CIRCUIT BOARD,

REMOVE SCREWS AND

BEND BACK TABS

DIP SWITCH

SOCKET

RED BLACK GREEN

PLUG

Figure 9. 5881/5882 RF Receiver (cover removed)

TO CONTROL'S REMOTE KEYPAD CONNECTION POINTS.

WIRING OPENING

KNOCKOUT AREA FOR SURFACE WIRING

5881-003-V0

2-11

3000EN Series: Installation Instructions

Installing a 5800TM Module

1. Mount the 5800TM next to the RF receiver (between one and two feet from the receiver’s antennas) using its accompanying mounting bracket. Do not install within the control cabinet.

2. Connect the 5800TM to the control panel’s touchpad connection terminals as shown on the Summary of Connections diagram and set to address 28.

3. For additional information, refer to the 5800TM’s instructions.

Notes

• Use this module only if you are using one or more wireless bi-directional touchpads or keyfobs with

a wireless Receiver; 5800TM is not necessary if using a Transceiver (e.g., 5883).

• The 5800TM must be set to address 28 (cut red-W1 jumper).

• The 5800TM can be used in partition 1 only.

• For additional information regarding the 5800TM, refer to the 5800TM’s instructions.

Installing the Transmitters

1. To be sure reception of the transmitter's signal at the proposed mounting location is adequate, perform a Go/No Go Test, described in the Testing the System section.

2. Install transmitters in accordance with the instructions provided with each.

3. Set 5827, 5827BD, 5804BD wireless touchpads to the programmed House ID (field *24), using its DIP switches (5827) or follow the instructions provided with the device.

ULC Note for Canadian Units: In accordance with ULC standards, the RF supervision period for this control is three hours for Fire zones (Zone Types 9 and 16) and 12 hours for all other zone types.

Notes

• Refer to the table of compatible devices at the back of this manual.

• Supervised transmitters† send check-in signals to the receiver at 70-90 minute intervals. If at least

one check-in message is not received from each transmitter within a 12-hour period, the “missing” transmitter number(s) and “CHECK XX” is displayed.

† Hand-held transmitters (e.g., 5802, 5802CP, 5804, 5804BD, 5827, 5827BD) do not send check-in signals.

The following transmitters are not intended for use in UL installations: 5802, 5802MN, 5802MN2, 5804BD,

5804BDV, 5804E, 5804WATCH, 5814, 5816TEMP, 5819, 5819WHS & BRS, and 5850.

The 5827BD and 5800TM can be used in UL Listed Residential Burglar installations.

Transmitter Battery Life

• Batteries in the wireless transmitters may last from 4 to 7 years, depending on the environment, usage, and the specific wireless device being used. Factors such as humidity, extreme temperatures, as well as large temperature variations may all reduce the actual battery life in a given installation. The wireless system can identify a true low-battery situation, thus allowing the dealer or user of the system time to arrange a change of battery and maintain protection for that given point within the system.

• Some transmitters (e.g., 5802 and 5802CP) contain long-life but non-replaceable batteries, and no battery installation is required. At the end of their life, the complete unit must be replaced (and a new serial number enrolled by the control).

• Button-type transmitters (such as 5801, 5802, and 5802CP) should be periodically tested for battery life.

• The 5802MN and 5804 Button Transmitters have replaceable batteries.

Do not install batteries in wireless transmitters until you are ready to enroll during system programming. After enrolling, batteries need not be removed.

2-12

Mounting and Wiring the Control

Installing a Keyswitch

1. Connect the 4146 keyswitch's normally open momentary switch to a zone’s (2-8) terminals. Remove the 2000 ohm EOL resistor if connected across the selected zone.

2. Using a standard touchpad cable as shown: Connect the yellow and white keyswitch wires to trigger connector pin 3 (+12V).

Connect the Red and Green LED wires to the appropriate output 17/output 18 trigger connector pins.

3. Connect a 2000 ohm EOL resistor across the momentary switch.

4. You can wire an optional closed-circuit tamper switch (model 112) in series with the zone. If the switchplate is then removed from the wall, the tamper will open, disabling keyswitch operation until the system is next disarmed from the touchpad.

If the tamper is opened when the system is armed, an alarm will occur.

A UL Listed keyswitch is required for fire installations and UL commercial and residential burglar alarm

installations.

If a keyswitch is used on:

• an installation that transmits opening and closing signals, the keyswitch zone must be programmed to send

opening and closing signals.

• a UL commercial burglar alarm installation, the keyswitch’s tamper switch must be connected in to the alarm

system. This tamper switch zone must also be programmed for Zone Type 05 – Trouble by Day / Alarm by Night.

• a fire alarm installation, the keyswitch must be located next to an alphanumeric display touchpad.

The Ademco 4146 keyswitch is UL Listed.

Notes

• Use 4146 keyswitch or any N.O. keyswitch.

• Use only one keyswitch per partition.

• When using a keyswitch, the zone it is connected to is no longer available for use as a protective zone.

• Use *56 Menu mode to program the keyswitch zone and assign it zone type 77.

• Use *80 Menu mode to program the LED functions: program outputs 17 and 18 for system

operation zone type 78 (red LED) and 79 (green LED) as appropriate (see Output Device Programming section).

8-PIN TRIGGER CONNECTOR

1345678

KEY

(YEL)

(RED)

(GRN)

+12 AUX.

OUT 17

ON CONTROL BOARD

OUT 18

TYPICAL ZONE

4-WIRE CABLE

YELLOW

WHITE

BLACK

RED

BROWN

BLUE

4146 KEYSWITCH

(ARMED)

RED

(READY)

GREEN

(use appropriate value)

820

ohms

SWITCH (N. C.)

SWITCH (N. O.)

TAMPER

LOCK

EOLR

820

ohms

BROWN

BLUE

Figure 10. Keyswitch Wiring Connections

00-trigcon-004-V2

2-13

3000EN Series: Installation Instructions

Connecting Relay Modules

1. Mount either remotely or in the control panel. Use 4204 or 4229 modules.

2. Connect to control’s touchpad terminals using the connector harness supplied with the module. Use standard 4-conductor twisted cable for long wiring runs.

3. Set each module’s device address according to the following table (and see DIP Switch chart).

Relay Module Addresses

4204 Address 4229 Address

no. 1 12 no. 1 (zn 09-16) 07

no. 2 13 no. 2 (zn 17-24) 08

no. 3 14 no. 3 (zn 25-32) 09

no. 4 15 no. 4 (zn 33-40) 10

no. 5 (zn 41-48) 11

4. Connect the desired field wiring to the unit's relay contact terminals.

For UL installation requirements, refer to the Installation Instructions for the 4204.

Notes

• Supervision: 4204 and 4229 modules are supervised against removal. The module’s device address

is displayed as follows if a module is disconnected from the control’s terminals, or if the module cover is removed and the tamper jumper is installed:

Alpha: CHECK xx Wire Expansion FAULT xx Wire Expansion ALARM xx Wire Expansion

Fixed-Glass: lxx (or 91 if field *199 set for 2-digit display) where “xx is the module’s address.

• If communication/tamper failure occurs on a device with zones wired to it, all zones on the device

will be displayed in their respective partitions.

4204 DIP Switch Address Settings

ADDRESS 12 13 14 15 7 8 9 10 11 2 3 4 5

off

(4229 Module is shown in the 4219/4229 Expansion Zones paragraph earlier in this section)

off ON off off

ON off off off

off off off off

4204

DIP SWITCH

FOR SETTING DEVICE ADDRESS AND ENABLING/DISABLING TAMPER

COVER TAMPER (REED) SWITCH

4-PIN TOUCHPAD PLUG

13 14 15 16

Figure 11. 4204 Connections to Control

2 3 4 5

(SHOWN "OFF")

EITHER OR BOTH CAN BE USED

TB1

DATA IN

YEL

FROM CONTROL

BLK

(–) GROUND

GRN

DATA OUT TO CONTROL

RED

(+) 12V

ADDRESS

off off off ON

RELAY

TYPICAL

RELAY

ON ON ON off

121110

87654321

NO C

TB2

4204_conn-1-V0

off ON ON off

ON off ON off

off off ON off

2-14

Mounting and Wiring the Control

Powerline Carrier Devices

1. Install the powerline carrier devices according to the instructions included with each.

2. Use Programming Mode to enter the device house ID in data field*27, and enter the unit code using *79 Output Device menu Mode. See connections diagram in the AC Wiring paragraph for connecting the 1361X10 transformer.

Canada: Use the PSC04 Powerline Interface as shown:

8-PIN TRIGGER CONNECTOR

1345678

KEY

X10 PSC04

POWERLINE INTERFACE

(RED)

OUT 17

(GREEN)

(YELLOW)

(ORANGE)

GND (-)

+12 AUX.

OUT 18

(BLUE)

(PURPLE)

COM

DATA

(BLACK)

SYNC

SA4120XM-1 CABLE

SYNC

COM

DATA

BLK GRN

RED YEL

1 2 3 4

MODULAR PHONE CORD (not supplied)

1 - BLACK 2 - RED 3 - GREEN 4 - YELLOW

00-trigcon-015-V0

Notes

• When using Powerline Carrier devices, you must use a 1361X10 Transformer instead of the 1321

Transformer.

• The 1361X10 Transformer provides AC power to the control panel, and also supplies signals from

the control panel through the premises AC wiring to the Powerline Carrier devices (which are plugged into AC outlets). You can then make devices that are plugged into Powerline Carrier devices perform various functions in response to commands you enter at the security system touchpads.

Powerline Carrier devices are not UL Listed for fire or burglary functions and are intended for home

automation.

2-15

3000EN Series: Installation Instructions

On-Board Triggers

Connect field wiring to the desired trigger pin on the 8-pin trigger connector centrally located above the terminal strip.

• If using 1361X10 transformer and powerline carrier devices, use the SA4120XM-1 cable (part of 4120TR Trigger Cable). See Wiring the AC Transformer section for transformer-to-trigger connections.

• If only using the on-board triggers, you can use a 4-wire cable (N4632-4, supplied with the control) as shown below.

If on-board triggers are used, the wiring between the control unit and the UL Listed device must be run in

conduit, be no more than 3 feet apart and have no intervening barriers or walls.

Notes

• The trigger outputs are normally high, and go low upon programmed condition.

• The outputs can be programmed for inverted operation (normally low, go high) using *79 Menu

mode.

• Program these triggers using *80/*81 Menu modes as you would for any other relay output.

• When using these outputs, note:

pin 1 = output number 17 (trigger 1): 15 ohms to ground when closed (output low), open when off (output high, normal default);

can be used to reset smoke detector power (must set “output normal low = yes” in *79 Menu mode, and set for zone type 54, fire zone reset, in *80 Menu mode); or can support 12V relay

module† that draws less than 100mA pin 5 = output number 18 (trigger 2): 100 ohms to ground when closed (output low); open when off (output high, normal default);

or can support 12V relay module that draws less than 20mA

† e.g., Altronix AX-RBS

8-PIN TRIGGER CONNECTOR

1345678

KEY

8-PIN TRIGGER CONNECTOR

1345678

KEY

2-16

(RED)

(ORANGE)

+12 AUX.

OUTPUT 17

(GREEN)

(YELLOW)

GND (-)

OUTPUT 18

(BLUE)

(PURPLE)

COM

DATA

(BLACK)

SYNC

SA412OXM-1 CABLE

ADT3000-006-V0

(RED)

(YELLOW)

+12 AUX.

OUTPUT 17

(BLACK)

(GREEN)

GND (-)

OUTPUT 18

4-WIRE CABLE

00-trigcon-005-V2

Figure 12. On-Board Trigger Connector with Figure 13. On-Board Trigger Connector with SA4120XM-1 Cable for Use With 1361X10 Transformer 4-Wire Cable for Trigger Use Only

Mounting and Wiring the Control

Phone Line/Phone Module Connections

1. Connect incoming phone line and handset wiring to the main terminal block (via an RJ31X jack)

as shown in the Summary of Connections diagram at the back of this manual. Wire colors represent the colors of the cable to the RJ31X jack.

If using a phone module, continue with the following steps.

2. Make 12V (+) and (–) and data in and data out connections from the phone module to the control,

using the connector cable supplied with the phone module, then insert the keyed connector at the other end of the connector cable into the header on the phone module.

3. Connect Phone Module terminals as shown. Use an RJ31X jack with a direct-connect cord and

make all connections exactly as shown.

4. Caller ID Units: If a Caller ID unit is being used, connect the unit directly to the “Handset”

terminals (21 & 22) on the control, as shown.

Notes

• Use 4286 Phone Modules. Compatibility: 4286 Phone Modules must have software version WA4286-

15.1 or higher (refer to the label on the square 4286 microprocessor chip).

• Only one phone module can be used and it can only be connected to partition 1.

• The phone lines must be in service for the phone module to function, even when accessing the system

from an on-premises phone.

• If you are also using an Audio Alarm Verification (AAV) unit, refer to Audio Alarm Verification

(AAV) section for special wiring connections.

NOTE: To reduce the risk of fire, use only 26AWG or larger telecommunications line cord for phone line connection.

The 4286 module is UL Listed only for use on residential fire and UL residential burglar alarm installations.

Phone Module Problems

If no touch tones are produced following access to the security system from on-premises (this problem may arise in rare cases), it may be necessary to reverse the wires connected to terminals 3 and 4 on the phone module and the wires connected to terminals (21) & (22) on the control. The wiring diagram shows the wiring connections that will provide proper operation in most cases. Connection to the incoming telco line via a RJ31X jack and direct-connect cord, as shown, is essential, even if the system is not connected to a central station. The 4286 will not function if this is not done and an error signal (fast busy signal) will occur when trying to access the system via the phone. The house phone lines (gray and brown wires) must be wired to the phone module terminals; not to the control terminals. Otherwise, an error signal (fast busy signal) will occur when trying to access the system from an onpremises phone.

2-17

3000EN Series: Installation Instructions

TERMINALS

ON CONTROL

CALLER ID

UNIT

IMPORTANT NOTE FOR EXISTING INSTALLATIONS:

EXISTING WIRES CONNECTED TO THE "HANDSET" TERMINALS ON CONTROL MUST BE MOVED FROM THERE TO TERMINALS 3 AND 4 ON THE 4285/4286.

HANDSET

{

21 22 23 24 25

(TIP)

INCOMING

TELCO LINE

GREEN (TIP)

(RING)

{

RED (RING)

GROUND

DIRECT

CONNECT

CORD

PLUG

TO EARTH GROUND (COLD WATER PIPE, ETC.)

INCOMING TELCO LINE

TIP

RING

TIP

RJ31X

RING

JACK

CA38A

CANADA

PREMISES ANSWERING MACHINE AND PHONES

ANSWERING

MACHINE

V IP MODULE

LOUDER

4285/4286

123456 7

GREY (R)

BROWN (T)

VOLUME

(4286

ONLY)

UNUSED

CONNECTOR WITH FLYING

LEADS

KEYED HEADER

YELLOW: TO DATA OUT (term. 7) NO CONNECTION RED: TO AUX (+) (term. 5) BLACK: TO AUX. GROUND (–) (term.4) GREEN: TO DATA IN (term. 6)

Figure 14. 4286 Phone Module Wiring Connections

TO CONTROL PANEL TERMINALS USED FOR KEYPAD CONNECTIONS

NOTE: IF THE TELEPHONE HAS BUILT-IN CALLER ID,

THE CALLER ID FUNCTION MAY NOT WORK

4285/4286

TERMINAL ASSIGNMENTS

1 - TIP 2 - RING 3 - TIP 4 - RING 5 - NO CONNECTION 6 7 -

PHONE INPUT

}

PHONE OUTPUT

}

AUDIO OUT

}

4286 ONLY

4286_cntrl-001-V0

2-18

Audio Alarm Verification Connections (AAV, “Listen-In”)

Using the UVS System with UVCM Module

Refer to the connection diagrams below. One diagram shows connections when a 4286 Phone Module is used, the other shows connections when the 4286 is not used.

NOTE:

REFER TO UVCM MODULE INSTRUCTIONS FOR CONNECTIONS TO AUDIO SPEAKERS AND MICROPHONE.

Connections use one of the on-board triggers.

UL installations using the AAV feature must use the ADEMCO UVCM module (part of the ADEMCO UVS

system).

Suggested AAV Module: ADEMCO UVS

Notes

• Set field *91 for AAV and program the appropriate output (output 17 or 18) using *80 Menu mode:

select zone type “60” and output action 1 (close for 2 seconds).

• For voice session monitoring, connect a zone to module terminals 6 & 7, and program the zone as

zone type 81 (*56 Menu mode). E.g., Using output 18 for the trigger, program an output function in *80 Menu mode as: ZT = 60, P = 0, Action = 1, Device = 18

SWITCH

BANK 1

1 = OFF 2 = OFF 3 = OFF 4 = OFF 5 = OFF 6 = OFF 7 = OFF 8 = ON

SWITCH BANK 2

1 = ON 2 = ON 3 = OFF 4 = ON 5 = ON 6 = ON 7 = ON 8 = ON

AUDIO LEVEL

ADJUSTMENT

UVCM MODULE

ON ON

AUXILIARY

TRIM POT

SWITCH BANK 2

FALLING VOICE TRIG

SWITCH BANK 1

12345678 1 2345678

GND

+12VDC IN

CONTROL

29 30 31 32 33 34

1234567891011

GND

+12VDC

TERMINALS

OUTPUT 18

TRIGGER CONNECTOR

ZONE

Mounting and Wiring the Control

EOL

RING

TIP

RED (R)

GREEN (T)

GREY (R)

BROWN (T)

OPTIONAL MONITORING ZONE CONNECTION (USE ZONE TYPE 81)

PREMISES

HANDSET

EARTH

GROUND

RJ31X

INCOMING

PHONE LINE

Figure 15. Connection of AAV Unit When Not Using a 4286 Phone Module

2-19

aav_uvcm-003-V0

3000EN Series: Installation Instructions

AUXILIARY

AUDIO LEVEL

ADJUSTMENT

TRIM POT

UVCM MODULE

NOTE:

REFER TO UVCM MODULE INSTRUCTIONS FOR CONNECTIONS TO AUDIO SPEAKERS AND MICROPHONE.

SWITCH

BANK 1

1 = OFF 2 = OFF 3 = OFF 4 = OFF 5 = OFF 6 = OFF 7 = OFF 8 = ON

SWITCH BANK 2

1 = ON 2 = ON 3 = OFF 4 = ON 5 = ON 6 = ON 7 = ON 8 = ON

ON ON

SWITCH BANK 2

FALLING VOICE TRIG

SWITCH BANK 1

12345678 1 2345678

Figure 16. Connection of AAV Unit When Using a 4286 Phone Module

RING

TIP

GND

+12VDC IN

CONTROL

29 30 31 32 33 34

1234567891011

GND

TRIGGER

CONNECTOR

ZONE

TERMINALS

+12VDC

OUTPUT 18

EOL

OPTIONAL MONITORING ZONE CONNECTION (USE ZONE TYPE 81)

RING

23 24

TIP

RED (R)

GREEN (T)

GREY (R)

BROWN (T)

PREMISES

HANDSET

4286

EARTH

GROUND

RJ31X

INCOMING

PHONE LINE

aav_uvcm-004-V1

2-20

Mounting and Wiring the Control

Using the AVS System with AVS-ADT Module and AVST-ADT Remote Stations

The AVS system provides audio alarm verification via the phone line or via AlarmNet if the

GSMV-ADT module is used as the communication device.

Refer to the instructions included with the AVS-ADT system for installation procedures. The

following is a summary.

Mounting the AVS-ADT Base Unit

As shipped, the AVS-ADT Base unit board comes premounted on its mounting bracket, which is designed to mount inside the control cabinet. Refer to the diagram at right. a. Position the mounting plate/PC board assembly in

SECURE WITH TWO (2) SELF-TAP SCREWS (SUPPLIED)

the bottom of the control’s cabinet.

b. Slide the mounting plate to the right so that the

plate’s left-hand tang slides under the cabinet’s tiewrap loop.

c. Secure the assembly to the cabinet using the two

self-tapping screws provided.

SYSTEM

BATTERY

TANG

BENEATH

MOUNTING

PLATE

4 3 2

4 23 1

SLIDE ASSEMBLY TO RIGHT UNTIL

TANG SLIPS UNDER CABINET LOOP

CABINET TIE-WRAP LOOP

AVS-003-V0

BATTERY NOTE: When using a 7AH battery, mount the battery vertically on the bottom left-hand side of the cabinet, with the terminals facing down and right (negative terminal closest to the PC board bracket).

Wiring the AVS-ADT to the Control

The AVS-ADT Base unit board has several terminal blocks for making connections to remote stations, telephone lines, and to the control panel. The AVS-ADT base unit connects to the control’s ECP terminals, with all other ECP devices connecting to the AVS-ADT base unit ECP terminals. See the diagram on the next page for specific wiring connections.

DIP Switch: Set the AVS DIP switch to the address 11.

IMPORTANT: The AVS-ADT should be the only ECP device connected to the control’s ECP

terminals. Connect all other ECP devices (touchpads, expander modules, etc.) to the ECP terminals on the AVS board.

Connecting an Optional GSMV Module

a. If using a GSMV module for 2-way voice operation, install the module according to its instructions.

NOTE: The module must be mounted within three feet of the control.

b. Connect the audio cable from the GSMV module to the Audio connector on the AVS board. The

audio cable is supplied with the GSMV module.

c. Complete all other GSMV wiring following the instructions included with that module.

The following summarizes the programming steps for AVS operation (refer to the Programming Guide for details of the AVS Quick Command options): a. Install the AVS module according to its instructions. b. Use one of the control’s AVS Quick Program commands as follows :

• installer code + [#] + 03: enable AVS operation without panel sounds on the AVST

• installer code + [#] + 04: enable AVS operation and enable panel sounds on the AVST speaker c. Use data field ∗55 Dynamic Signaling Priority to select the desired reporting paths.

2-21

3000EN Series: Installation Instructions

PREMISES

PHONES

TIP

RING

RJ31X

12 3

DIRECT CONNECT CORD

TIP

RING

INCOMING

TELCO

TOUCHPAD

AVST-ADT STATION

LED

VOLUME / ID

BUTTON

TOUCHPAD

MIC

TB 1

4 5 6

8 9 10 11

GSMV-ADT

(OPTIONAL)

BASE UNIT

DEVICE ADDRESS

SET FOR

ADDRESS 11

23 541

SPEAKERS

YEL

GRN

BLK

RED

FOREXTERNAL ANTENNA 50 OHM, MMCX ONLY

MODE 1

RSSI

AAV

WEB

MODE 2

CONTROL PANEL

(EARTH GND

BRN

GRY

GRN

(TIP)

INCOMING

PHONE LINE

(RING)

(TIP)

RED

(RING)

DATA AUDIO

ECP TERMINALS

DATAINDATA

GND AUX

BLK

GRN

RED

TRIGGER HEADER

123456

OUT

IMPORTANT:

DO NOT CONNECT ANY OTHER

YEL

ECP DEVICES TO PANEL. USE BASE UNIT ECP TERMINALS FOR OTHER ECP DEVIES.

HANDSET

SUPPLIED HARNESS

GND

+VDC

AUDIO CABLE

GSM

GPPS

AVS-ADT BASE UNIT

LED

HANDSET

INCOMING

PHONE LINE

RED BLK GRN YELRED BLK GRN YELRED BLK GRN YEL

PHONE

RING

TIP

RING

GRY

BRN

TO ALL OTHER ECP DEVICES

BATTERY

(200 FT. MAX)

PROGRAM MODE

CALLBACK MODE

PANEL TRIGGER

MODE

NORMAL MODE

DIP SW

2341

NOT USED

23 541

AUDIO CONNECTOR

AAV

DEVICE ADDRESS (ADDRESS 11 SHOWN)

PANEL ECP

2-22

AVS-ADT-001-V0

Long Range Radio (Communication Device) Connections

Connect the data in/data out terminals and voltage input terminals of the Long Range Radio to

the control's touchpad connection points.

Set the radio’s address to “03” following the instructions provided with the radio.

Notes

• Use compatible Communication Devices (e.g., 7845GSMADT).

SECTION 3

Programming Overview

•••••••••••••••••••••••••••••••••••••••

About Programming

• You can program the system at any time, even at the installer's premises prior to installation.

• Programming can also be performed remotely from the installer’s office/home, using an IBM

personal computer, a modem, and Compass downloading software.

• The Real-Time Clock must be set before completing the installation.

The following is a list of the various Programming modes used to program this system:

Programming Mode… Used to … Data Field Programming Program basic data fields used for setting the various system options.

Most of the data fields in this system are programmed for specific ADT values. However, some fields must be programmed for each particular installation to establish its specific alarm and reporting features.

∗56 Zone Programming

∗57 Function Key

Programming ∗58 Zone Programming (Expert Mode)

∗79 Output Device Mapping

∗80 Output Definitions

∗81 Zone List Programming

∗82 Alpha Programming ∗29 IP/GSM Programming

Scheduling Mode Create up to 32 schedules to automate various system functions.

Zones and Partitions

The system supports up to 64 zones plus three emergency zones (numbered 95, 96, and 99). Each

protection zone needs to be programmed with various attributes using *56 Zone Programming mode or *58 Expert Programming mode. Refer to those sections for detailed procedures.

The system can control two independent areas of protection (known as partitions) for use by

independent users, if desired, by simply assigning zones to one or the other partition during zone programming. The system, by default, automatically distributes users between the two partitions. The master user can change the user number distributions.

Zones can also be assigned to a common partition, which is an area shared by users of both partitions

(such as a lobby in a building). This allows either partition to arm, while leaving the common partition disarmed for access into the other partition. The common partition functions as follows:

• The common zone sounds and reports alarms only when both partitions are armed. If only one partition is armed, the system ignores faults on the common zone.

• Either partition may arm its system if the common zone is faulted, but once armed, the other partition will not be able to arm unless the common zone is first bypassed or the fault is corrected.

• Faults on the common zone are displayed on common zone touchpads, and will also appear on another partition’s touchpad when that partition is armed.

• Either partition can clear and restore the common zone after an alarm.

Assign zone characteristics, report codes, alpha descriptors, and serial numbers for 5800 RF transmitters. Program each of the four alphabet function keys to perform one of several system operations.

Assign zone attributes similar to ∗56 mode, but provides a faster programming procedure and is intended for those more experienced in programming controls of this type. Assign device addresses used by 4229 or 4204 Relay modules and map specific relays and device outputs, and assign unit codes for Powerline Carrier devices Define up to 48 output definitions which can control the output relays mapped using *79 Output Device Mapping mode. Create Zone Lists for relay/powerline carrier zones, chime, night-stay, cross zone and pager zones. Create alpha descriptors for easy zone identification. For programming IP/GSM options.

3-1

3000EN Series: Installation Instructions

Touchpads

Touchpads are identified by predefined addresses as follows:

Address Touchpad Program Field

16 touchpad 1 • always enabled for partition 1, all sounds enabled. NOTE: First touchpad 17 touchpad 2 • data field *190 is address 16. 18 touchpad 3 • data field *191 19 touchpad 4 • data field *192 20 touchpad 5 • data field *193 21 touchpad 6 • data field *194 22 touchpad 7 • data field *195 23 touchpad 8 • data field *196

To enable touchpads:

1. Set desired address at touchpad (refer to touchpad’s instructions for setting the address).

2. Use data field program mode to enable touchpad addresses, assign a partition, enable sound

options in fields *190-*196 as shown in the table above.

3. If desired, use data field *198 to turn on the display of the partition number.

4. Set the following touchpad-related data fields as required by the installation:

*21 Quick Arm Enable, *23 Forced Bypass, *84 Auto STAY Arm, *176 Lack of Usage Option

5. If using AUI, enable each unit in field *189 and set the AUI devices to the following addresses:

AUI 1 = address 1; AUI 2 = address 2; AUI 3 = address 5; AUI 4 = address 6

Wireless Receiver, Transmitters, and Wireless Keys (keyfobs)

Receiver: Set the receiver’s address to “00” using its DIP switches, then set the following options:

*22 RF Jam Option† *24 RF House ID Code (if using wireless touchpads) for each partition

*67 Transmitter Low Battery Report Code†

*75 Transmitter Low battery restore report code† *173 RF Reporting Options

Transmitters: Use *56 or *58 Zone Programming Menu modes to program zone information and enroll transmitters.

Wireless Keys: Use Wireless Key Programming Templates section of the *58 Expert Programming mode in Section 5 Zone Programming (page 5-6) to program zone information and enroll each

button of the wireless keys used. Once a wireless key is enrolled, it must be assigned to a user before it becomes active. See Adding/Deleting Security Codes in Section 12 System Operation (page 12-2) for the procedure.

Pager Programming

The system can send various reports to up to four pagers. To program pager reporting:

1. Enter the appropriate information in the following data fields

*160, *163, *166, *169 Pager Phone Numbers (for pagers 1-4 respectively) *161, *164, *167, *170 Pager Prefix Characters (for pagers 1-4 respectively) *162, *165, *168, *171 Pager Reporting Options by Partition (for pagers 1-4 respectively)

2. Enable Pager Delay, if desired, in field *172 (delays alarm reporting for ALL pagers)

3. Make sure appropriate user open/close pager reports are enabled using the user attribute command

(master code + [8] + user no. + [#] [5] + [1]). Users that perform actions in partition 1 will, if

enabled, attempt to report to all pagers enabled for open/close reporting in partition 1. Users that perform actions in partition 2 will, if enabled, attempt to report to all pagers enabled for open/close reporting in partition 2.

4. If using latchkey pager report, define the latchkey report schedule using Scheduling mode (master

code + [#] [6] [4], select event type “03”). System must be armed for the Latchkey report to be sent.

5. If using a function key to manually send a message to a pager, see Function Keys paragraph.

6. If reporting zone alarms and troubles to a pager, use *81 Zone List menu mode to assign the zones

associated with each pager (zone lists 9-12).

† These fields must be enabled for Residential

Fire, UL Residential Burglar Alarm, and UL Commercial Burglar Alarm installations.

3-2

Function Keys

To assign functions to the function keys, use *57 Function Key menu mode. To assign emergency key functions (function key option “00”), first program the respective emergency

zone number (95 for “A” key, 96 for “C” key, 99 for “B” key) with the desired zone type using *56 Zone Programming mode, then use *57 Function Key menu mode to assign the desired key.

If using a function key to activate a relay action (*57 Menu mode key function 07), use *79 Menu

mode to map the output, and use *80 Menu mode to define the output’s action; select system operation type “66.”

If using a function key for a user macro, use *57 menu mode to activate the desired key, then define

the actual macro functions using the user code + [#] + [6] [6] command.

Output Devices

To program a device for manual activation (user code + [#] [7] / [#] [8] + 2-digit device number) or for

scheduled automatic activation, simply map the device using *79 Menu mode.

To program a device to automatically activate upon a system event (or function key), use *79 Menu

mode to map the device, then use *80 Menu mode to define the automated device action.

If the device action is based on more than one zone, use *81 Zone List menu mode to assign the zones.

Zone Type Definitions

You must assign a zone type to each zone, which defines the way in which the system responds to faults in that zone. Zone types are defined below.

Zone Type Description

Type 00 Zone Not Used Type 01 Entry/Exit Burglary #1

Type 02 Entry/Exit Burglary #2

Type 03 Perimeter Burglary

Type 04 Interior Follower

Type 05 Trouble by Day/ Alarm by Night

Program a zone with this zone type if the zone is not used.

• Assign to zones that are used for primary entry and exit.

• Provides entry delay when zone is faulted if control is armed in the Away, Stay,

or Night-Stay modes.

• No entry delay is provided when the panel is armed in the Instant mode.

• Entry delay #1 is programmable for each partition.

• Exit delay begins whenever the control is armed, regardless of the arming mode

selected, and is independently programmable.

• Assign to zones that are used for entry and exit and require more time than the

primary entry/exit point.

• Provides a secondary entry delay, in same manner as entry delay #1.

• Entry delay #2 is programmable for each partition.

• Exit delay is same as described for Type 01.

• Assign to all sensors or contacts on exterior doors and windows.

• Provides an instant alarm if the zone is faulted when the panel is armed in the

Away, Stay, Night-Stay, or Instant modes.

• Assign to a zone covering an area such as a foyer, lobby, or hallway through

which one must pass upon entry (to and from the touchpad).

• Provides a delayed alarm (using the programmed entry 1 time) if the entry/exit

zone is faulted first. Otherwise this zone type gives an instant alarm.

• Active when the panel is armed in the Away mode.

• Bypassed automatically when the panel is armed in the Stay or Instant modes;

if armed in Night-Stay mode, zones assigned to zone list 05 (night-stay zone list)

are not bypassed when system armed in Night-Stay mode.

• Assign to a zone that contains a foil-protected door or window (such as in a store),

or to a zone covering a sensitive area such as a stock room, drug supply room, etc.

• Can also be used on a sensor or contact in an area where immediate notification

of an entry is desired.

• Provides an instant alarm if faulted when armed in the Away, Stay, Night-Stay,

or Instant (night) modes.

• During the disarmed state (day), the system will provide a latched trouble

sounding from the touchpad (and a central station report, if desired).

3-3

3000EN Series: Installation Instructions

Type 06 24-hour Silent Alarm

Type 07 24-hour Audible Alarm

Type 08 24-hour Auxiliary Alarm

Type 09 Supervised Fire

Type 10 Interior w/Delay

Type 12 Monitor Zone

Type 14 24 Hour Carbon Monoxide Monitor

Type 16 Fire w/Verification

Type 20 Arm-Stay (BR only)

Type 21 Arm-Away (BR only)

Type 22 Disarm (BR only)

Type 23 * No Alarm Response

Type 24 Silent Burglary

• Usually assigned to a zone containing an emergency button.

• Sends a report to the central station but provides no touchpad display or

sounding.

• Assign to a zone that has an emergency button.

• Sends a report to the central station, and provides an alarm sound at the

touchpad, and an audible external alarm.

• Assign to a zone containing an emergency button, or to a zone containing

monitoring devices such as water or temperature sensors.

• Sends a report to the central station and provides an alarm sound at the

touchpad. (No bell output is provided.)

• Provides a fire alarm on short circuit and a trouble condition on open circuit. A

fire alarm produces a pulsing bell output.

• This zone type is always active and cannot be bypassed.

• Provides entry delay (using the programmed entry time), if tripped when the

panel is armed in the Away mode.

• Entry Delay 1 begins whenever sensors in this zone are violated, regardless of

whether or not an entry/exit delay zone was tripped first.

• Bypassed when the panel is armed in the Stay or Instant modes; if armed in

Night-Stay mode, zones assigned to zone list 05 (night-stay zone list) are not bypassed when system armed in Night-Stay mode.

• Works as a dynamic monitor of a zone fault/trouble (not alarm). In the case of a

short/open, the message, "*ALARM*-24 Hr. Non-Burg. -#XXX " (where XXX is the zone number) will be sent to the Central Station. The system touchpad will display a “check” message indicating the appropriate zone (but touchpad beeping does not occur). Upon restoral of the zone, the message, "*RESTORE*-24 Hr. Non-Burg. -#XXX " will be sent to the Central Station.

• The “check” message will automatically disappear from the touchpad dynamically,

when the zone restores; a user code + off sequence is not needed to reset the zone.

• Faults of this zone type are independent of the system, and can exist at the time

of arming without interference.

• Since this is a “trouble” zone type, do not use this zone type with relays set to

activate upon “alarm.”

• Assigned to any zone with a carbon monoxide detector.

• A carbon monoxide alarm produces touchpad and detector sounding (does not

affect bell output).

• Always active and cannot be bypassed.

• Provides a fire alarm when zone is shorted, but only after alarm verified.

• System verifies alarm by resetting smoke detectors after short is detected

(removes power 7 seconds for zone 1; 3 seconds for trigger output). A subsequent short circuit within 90 seconds triggers fire alarm.

• Provides a trouble response when zone is open.

• Arms the system in Stay mode when the zone is activated.

• Pushbutton units send the user number to the central station when arming or

disarming.

• User number for button must be assigned.

• Arms the system in Away mode when the zone is activated.

• Pushbutton units send the user number to the central station when arming or

disarming.

• User number for button must be assigned.

• Disarms the system when the zone is activated.

• User number for button must be assigned.

• Can be used on a zone when an output relay action is desired, but with no

accompanying alarm (e.g., lobby door access).

• Usually assigned to all sensors or contacts on exterior doors and windows where

bells and/or sirens are NOT desired.

• Provides an instant alarm, with NO audible indication at any touchpad or

external sounder, if the zone is faulted when the system is armed in the Away, Stay, or Instant, modes.

• A report is sent to the central station.

3-4

Type 25 * 24-Hour Non-Alarm Monitor

• For use with sensors designed to provide a trouble display (but no trouble

sounding) when an oil tank is low, or other similar application for critical condition monitoring where a non-alarm response is required.

• When this zone type is faulted and remains faulted for the programmed time

duration (field *53), a special event message is sent to the central monitoring station. The same holds true for restoration.

Type 77 Keyswitch

Type 81 AAV Monitor Zone

• Assign to zone wired to a keyswitch.

• Do not use devices assigned as input type “BR” with this zone type.

• Assign to zone connected to AAV module.

• Monitors 2-way voice sessions as follows:

- When the zone is faulted, all alarm sounding and dialer reporting stops, except for fire alarms, which immediately terminate the voice session and cause a fire report to be sent.

- When the zone is restored (session ended), sounding resumes (if bell timeout has not expired) and reports that were stopped are sent.

Types 90-93 Configurable

Allows for various custom responses. Options include response to entry/exit delays,

response to opens/shorts, types of alarm/trouble sounding, dial delay, and unique Contact ID report codes. Types 92 and 93 can only be programmed via downloader.

UL installations: Zone Types 90 – 93 may not be used as fire or burglar alarm zones

on fire or UL burglar alarm installations.

* The system can still be armed when these zone types are in a faulted condition. NOTE: All of the zone types described are available for the wireless portion of the system, if used.

Mechanics of Programming

To program the system from a touchpad:

• You must use a 2-line Custom English display touchpad.

• Both partitions must be disarmed.

POWER UP NOTE (firmware version display): After powering up, AC, dI (disabled) or “Busy Standby vx.x Dl will be displayed after about 4 seconds (where vx.x = firmware version). This reverts to a “Ready” message in approximately 1 minute, which allows PIRS, etc. to stabilize. You can bypass the delay by pressing [#] + [0].

Data Field Programming Procedures

Task Procedure

Entering Program Mode

Go to a Data Field

Entering Data

Review a Data Field

Deleting an Entry

Interactive Mode Programming (∗∗∗∗56, *57, ∗∗∗∗58, ∗∗∗∗79, ∗∗∗∗80, ∗∗∗∗81, ∗∗∗∗82, ∗∗∗∗29)

Entering Interactive Mode

A) Press both [∗] and [#] at the same time within 50 seconds after power is applied to the control, OR B) After power-up, enter [Installer code (6321)] + 800 (long beep indicates one of the partitions is armed and system cannot enter program mode).

(method “B” is disabled if you exit the program mode using ∗98) Press [∗] + [Field Number] (for example, ∗21).

A display of “EE” or “Entry Error” means you have entered a nonexistent field. Simply re-enter [∗] plus a valid field number. When the desired field number appears, simply enter the digits required. The

touchpad beeps three times after the last digit is entered and automatically displays the next data field in sequence. If entering less than the maximum digits available (e.g., phone number field), enter

the desired digits, then press [∗] and the next data field number to be programmed to end the entry. Press [#] + [Field Number]. That field’s data is displayed, but no changes can be made.

Press [∗] + [Field No.] + [∗] (applies only to phone number, account number, and pager character fields).

Press [∗] + [Interactive Mode No.] (for example, ∗56) while in Program Mode. The Custom English display touchpad will display the first of a series of prompts requesting entries. After making the appropriate entry, press the [∗] key to accept the entry and continue to the next prompt.

3-5

3000EN Series: Installation Instructions

AVS QUICK PROGRAMMING COMMANDS (for AAV sessions using the AVS-ADT system)

For controls with the firmware revision level 7.0 or higher, these commands automatically configure the control for AVS operation.

• installer code + [#] + [0] + 3: enable AVS operation

• installer code + [#] + [0] + 4: enable AVS operation and enable panels sounds on the AVST-ADT speaker

• installer code + [#] + [0] + 5: remove all programming options set by [#] + [0] + 3 quick command

• installer code + [#] + [0] + 6: remove all programming options set by [#] + [0] + 4 quick command

Refer to the AVS SYSTEM ENABLE section for details on the specific options that are set with each command, depending on the control used. To select the AAV session communication path (phone line/communication device), see field ∗55 Dynamic Signaling Priority. To enable AAV operation, use ∗91 Options field (option 4).

Loading Factory Defaults/Initializing for Download

To Load Default Entries Press ∗97 while in Program Mode. This resets all data fields to the ADT

default values shown on the Program Form. Use ∗97 only if you wish to return to the original factory-programmed defaults.

To Initialize Download ID Press ∗96 while in Program Mode. This initializes the system for

downloading and resets all the subscriber account numbers and CSID.

IMPORTANT: Do not press ✱97 to load defaults if any programming has been done previously—data already programmed into the system will be changed!

Exiting the Programming Mode

Prevent installer code reentry Press ∗98. Exits Programming Mode and prevents re-entry by:

Installer Code + [8] + [0] + [0]. To enter the programming mode if ∗ 98 was used to exit, you must first power the system down. Then power up again, and press [∗] and [#] at the same time, within 50 seconds of powering up.

Allow installer code reentry Press ∗99. Exits Programming Mode and allows re-entry by:

Installer Code + [ 8] + [0] + [0] or by: Pressing [∗] and [#] at the same time, within 50 seconds of power-up.

Table of Device Addresses

n/a

107 108 109 110 111

112 113 114 115

n/a n/a n/a n/a n/a n/a n/a n/a

†

Enabled By…

††

automatic if AUI enable field *189 enabled for AUI 1

automatic if communication device enabled in menu mode ∗29

*56 zone programming: input device type, entry 2, then:

automatic if zone no. 9-16 entered as AW type or relay assigned automatic if zone no. 17-24 entered as AW type or relay assigned automatic if zone no. 25-32 entered as AW type or relay assigned automatic if zone no. 33-40 entered as AW type or relay assigned automatic if zone no. 41-48 entered as AW type or relay assigned

*79 output device programming: device address prompt:

entered at device address prompt entered at device address prompt entered at device address prompt entered at device address prompt

data field programming as listed below:

always enabled for partition 1, all sounds enabled. data field *190 data field *191 data field *192 data field *193 data field *194 data field *195

†† Addressable devices are identified by “1” plus the

device address when reporting. Enter report code for zone 91 to enable device reporting (default = enabled). See field *199 for addressable device (ECP) 3-digit/2digit identification touchpad display options.

data field *196

This Device Uses

Reports as

Address

RF Receiver 00 100 *56 zone programming: input device type entry AUI 1 01

AUI 2 02 n/a automatic if AUI enable field *189 enabled for AUI 2 AUI 3 05 n/a automatic if AUI enable field *189 enabled for AUI 3 AUI 4 06 n/a automatic if AUI enable field *189 enabled for AUI 4 Communication Device (LRR) 03 103 4286 Voice Module 04 104 automatic if phone module access code field *28 enabled Zone Expanders (4219/4229):

module 1 (for zones 09 - 16) module 2 (for zones 17 - 24) module 3 (for zones 25 - 32) module 4 (for zones 33 - 40) module 5 (for zones 41 - 48)

Relay Modules (4204):

module 1 module 2 module 3 module 4

Touchpads:

touchpad 1 touchpad 2 touchpad 3 touchpad 4 touchpad 5 touchpad 6 touchpad 7 touchpad 8

07 08 09 10 11

12 13 14 15

16 17 18 19 20 21 22

23 HSPIM Module 25 n/a automatic 5800TM Module 28 n/a automatic

3-6

SECTION 4

Data Field Programming

•••••••••••••••••••••••••••••••••••••••

About Data Field Programming

The following pages list this control’s data fields in numerical order. Field numbers are listed in the left column followed by a “Title and Data Entries” column, which lists the valid entries for each field. Experienced installers can simply follow this column when programming the data fields. The “Explanation” column provides explanatory information and special notes where applicable.

Programming Data Fields

Data field programming involves making the appropriate entries for each of the data fields. Start Data Field programming by entering the installer code + 8 + 0 + 0.

System Setup Fields (∗∗∗∗20 – ∗∗∗∗29)

FIELD TITLE and DATA ENTRIES EXPLANATION

*20

*21

*22

*23

*24

*26

Use the blank programming form to record the data for this installation.

Installer Code

Enter 4 digits, 0000-9999

The Installer Code is used to enter programming mode and to assign the 4-digit Master Security Code (see "Master Code" in the System Operation section for procedure). For security purposes, the factory default installer code should be changed.

Quick Arm Enable

0 = do not allow quick arm 1 = allow quick arm

If enabled, a user code is not needed to arm the system. Instead, users can press the [#] followed by an arming key to arm the system. However, a user code is always needed to disarm the system.

RF Jam Option

0 = no RF jam detection 1 = send RF jam report

Quick (Forced) Bypass

0 = no quick (forced) bypass 1 = allow quick bypass (code + [6] + [#])

RF House ID Code

00 = disable all wireless touchpad usage 01–31 = House ID for partition 1, 2 and common

Chime By Zone/KP Sound Enables

Entry 1

0 = no Entry 1 touchpad trouble sounds AND

1 = Chime by Zone enabled (select zones

2 = Communication Device (LRR) Trouble

4 = System Low Battery sounding enabled 7 = select all entry 1 options

Entry 2

0 = no Entry 2 touchpad trouble sounds 1 = RF Supervision sounding enabled 2 = RF Low Battery sounding enabled 4 = RF Jam sounding enabled 7 = select all entry 2 options

no chime by zone (touchpad chimes on fault of any entry/exit or perimeter zone when chime mode is on)

to chime on zone list 3, using *81 Menu mode)

sounding enabled (for communication devices such as GSMV-ADT)

If enabled, a report is sent if the system detects an RF jamming signal. UL installations must be 1 if wireless devices are used.

All zones bypassed by this function will be displayed after the bypass is initiated. UL installations must be 0 (no forced bypass)

The House ID identifies receivers and wireless touchpads. If a 5827 or 5827BD Wireless Touchpad or 5804BD Transmitter is being used, a House ID code must be entered, and the touchpad should be set to the same House ID. You can assign RF house ID for each partition.

If enabled, you can define the specific zones intended to chime when faulted while the system is in Chime mode. Use zone list 3 to assign these zones (see ∗81 Zone List Programming section for details).

Keypad trouble sounding can be enabled/disabled for the

conditions listed for each entry below. For each entry, enter the sum of the desired options. Example Entry 1: for Chime by Zone and System Low Battery sounding, enter 5. To enable all options, enter 7.

4-1

3000EN Series: Installation Instructions

FIELD TITLE and DATA ENTRIES EXPLANATION

*27

Powerline Carrier Device (X-10) House ID

0 = A 6 = G # + 11 = L 1 = B 7 = H # + 12 = M 2 = C 8 = I # + 13 = N

Powerline Carrier devices require a House ID, identified in this field. Program Powerline Carrier devices in interactive modes ∗79, *80 and *81. Not intended for fire or UL installations.

3 = D 9 = J # + 14 = O 4 = E # + 10 = K # + 15 = P

*28

5 = F

Access Code for Phone Module

1-9 = first digit of access code ∗ or # = second digit of access code (enter # +11 for “∗”, or # +12 for “#”)

*29

Enable IP/GSM – Communication Device Menu Mode (pass-through programming)

Zone Sounds & Timing (

FIELD TITLE and DATA ENTRIES EXPLANATION

*31

*32

*33

*34

Single Alarm Sounding Per Zone

(per armed period) 0 = no limit on alarm sounding per

zone

1 = limit alarm sounding to once per

arming period for a given zone

Fire Alarm Sounder Timeout

0 = yes; fire sounder timeout after time

programmed in field ∗33

1 = no fire sounder timeout; continue

sounding until manually turned off

Alarm Sounder Timeout

0 = No timeout 3 = 12 min 1 = 4 min 4 = 16 min 2 = 8 min

Exit Delay

45 - 96 = 45 - 96 seconds 97 = 120 seconds

NOTE: Entries less than 45 will result in a

45-second delay.

∗∗∗∗

31–

∗∗∗∗

39)

You need to assign a 2-digit access code for the 4286 Phone Module, if used. Example: If desired access code is 7∗ , 7 is the first entry, and [#] + 11 (for ∗) is the second entry.

NOTE: A “0” in either digit disables the phone module. Must be “00” for UL Commercial Burglar Alarm installations.

Use this Menu mode to program IP/GSM communication device options. See ∗29 Menu Mode section later in this document. Program the radio for device address 3.

Select whether alarm sounding (on the bell output) should be limited to once per arming period or be unlimited.

SIA NOTE: If “0” selected, “alarm sounding per zone” will be the same as the “number of reports in armed period” set in field *93 (1 if one report, 2 if 2 reports, unlimited for zones in zone list 7).

This control complies with NFPA requirements for temporal pulse sounding of fire notification appliances. Temporal pulse sounding for a fire alarm consists of the following: 3 pulses – pause – 3 pulses – pause – 3 pulses. UL fire alarm installations: must be 1.

This field determines whether the external sounder will shut off after time allotted, or continue until manually turned off. UL installations: For residential fire alarm installation, must be set for a minimum of 4 min (option 1); for UL Commercial Burglary installations, must be minimum of 16 min (option 4).

The system waits the time entered before arming entry/exit zones. If the entry/exit door is left open after this time expires, an alarm will occur. Common zones use same delay as partition 1. UL installations: For UL Commercial Burglar Alarm and UL Residential Burglar Alarm installations with line security, total exit time must not exceed 60 seconds.

*35

Entry Delay 1

30 - 96 = 30 - 96 seconds 97 = 120 seconds 98 = 180 seconds 99 = 240 seconds

NOTE: Entries less than 30 will result in a

30-second delay.

SIA Installations: minimum exit delay is 45 seconds

Upon entering, the system must be disarmed before the time entered expires, otherwise it sounds an alarm. Common zones use same delay as partition 1. UL installations: For UL Residential Burglary Alarm installations, must be set for a maximum of 30 seconds; entry delay plus dial delay should not exceed 1 min. For UL Commercial Burglar Alarm, total entry delay may not exceed 45 seconds. SIA Installations: minimum entry delay is 30 seconds

4-2

*36

*38

Entry Delay 2

See *35 above for entries.

Confirmation Of Arming Ding

0 = no ding 1 = confirmation ding after arming

system

2 = confirmation ding after arming from

RF button or RF touchpad only (except 5827, 5827BD)

*39

Dialer Programming (

FIELD TITLE and DATA ENTRIES EXPLANATION

*40

Power-Up In Previous State

Feature always enabled; field removed in this control.

∗∗∗∗

40 –

PABX Access Code or Call Waiting Disable

∗∗∗∗

50)

Enter up to 6 digits if PABX is needed to access an outside line or enter call waiting disable code (*70) if call waiting is being used on the phone line.

Do not fill unused spaces.

0–9, # + 11 for ‘∗’, # + 12 for ‘#’, # + 13

for a pause (2 seconds)

See *35 above for explanation.

Confirmation of arming is 1/2 second external sounder “ding.” If “1” selected, ding occurs when closing report is sent if open/close reporting is enabled, or at the end of Exit Delay. If “2” selected, ding occurs upon reception of the wireless arming command. UL installations: must be “1” for UL Commercial Burglar Alarm installations.

When the system powers up armed, an alarm will occur 1 minute after arming if a zone is faulted. Note that if the previous state was armed Away or Stay, the system ignores sensor changes for 1 minute, which allows time for sensors such as PIRs to stabilize.

To clear entries from field, press ∗40∗. If fewer than 6 digits need to be entered, exit by pressing [∗], which advances to the next field.

SIA Installations - Call Waiting: If the subscriber’s phone service has “call waiting” (and is not using PABX), enter “*70” (“# + 11”) plus “# + 13” (pause) as the PABX entry and set call waiting disable option in field *91 to disable “call waiting” during control panel calls. If the subscriber does not have “call waiting” and is not using PABX, make no entry in this field.

NOTE: The call waiting disable feature cannot be used on a PABX line.

IMPORTANT: Using Call Waiting Disable on a non-call waiting line will prevent successful communication to the

*41

Primary Phone No.

Enter up to 20 digits. Do not fill unused

spaces.

0–9, # + 11 for ‘∗’, # + 12 for ‘#’, # + 13 for a pause (2 seconds)

*42

Secondary Phone No.

Enter up to 20 digits. Do not fill unused

spaces.

0–9, # + 11 for ‘✱’, # + 12 for ‘#’, # + 13

*43

for a pause (2 seconds)

Partition 1 Subscriber ID No.

Enter digits 0–9; # + 11 for B, # + 12 for

C, # + 13 for D, # + 14 for E, # + 15 for

*45

*47

Partition 2 Subscriber ID No.

Enter digits 0–9; # + 11 for B, # + 12 for

C, # + 13 for D, # + 14 for E, # + 15 for F.

Phone System Select

If Central Station Receiver is not on

central station. If you enter fewer than 20 digits, exit by pressing [∗]. To clear

entries from field, press ∗41∗. Backup reporting (in which 8 calls are made to the secondary phone number if no kissoff is received after 8 attempts to the primary number) is automatic only if there is a secondary phone number (field ∗42).

If you enter fewer than 20 digits, exit by pressing [∗]. To clear entries from field, press ∗42∗. See backup reporting note for field ∗41.

Enter 4 or 10 digits, depending on report format selection in field *48. To clear entries from field, press ∗43∗. Automatically puts same entries into field *45.

Enter 4 or 10 digits, depending on report format selection in field *48. To clear entries from field, press ∗45∗.

Select the type of telephone service.

WATS line: 0 = Pulse Dial; 1 = Tone Dial

If Central Station Receiver is on WATS line: 2 = Pulse Dial; 3 = Tone Dial

4-3

3000EN Series: Installation Instructions

*48

Report Format - Field Deleted

NOTE: The reporting format for the Safewatch Pro 3000EN is factory-set as 4-digit Contact ID format for both primary and secondary phone numbers and cannot be changed. Previous versions of this control panel used field *48 (now

*49

Split/Dual Reporting

0 = standard/backup reporting only

(all reports only to primary unless

unsuccessful, then will attempt secondary)

1 - 5 = see table to right

*50

Burglary Dialer Delay

Entry 1: Dela y Tim er

1 = 15 seconds

2 = 30 seconds

3 = 45 seconds

Entry 2: Delay Disable

0 = use delay set in entry 1

1 = dial delay disabled for zones listed

in zone list 6 (use zone list 6 to enter those zones that require dial delay to be disabled; these zones ignore the setting in entry 1)

*53

Misc. Fault Delay Time

0 = 15 secs 6 = 2-1/2 min #+12 = 8 min

1 = 30 secs 7 = 3 min #+13 = 10 min

2 = 45 secs 8 = 4 min #+14 = 12 min

3 = 60 secs 9 = 5 min #+15 = 15 min

4 = 90 secs #+10 = 6 min

5 = 2 min #+11 = 7 min

deleted) to select the reporting format.

To Primary No. To Secondary No.

1 = alarms, restore, cancel others 2 = all except open/close, test open/close, test 3 = alarms, restore, cancel all 4 = all except open/close, test all 5 = all all

Provides delay of “BURGLARY ALARM” report to the central station, which allows time for the subscriber to avoid a false alarm transmission. This delay does not apply to zone type 24 alarms (silent burglary) or to 24-hour zone types 6, 7, and 8 (silent panic, audible alarm, auxiliary alarm), which are always sent as soon as they occur. Entry 1: Delay timer sets the delay time. Entry 2: Delay Disable lets you selectively disable the delay by zone using zone list 6.

UL Installations: Dial delay plus entry delay must not exceed one minute; use zone list 6 to disable dial delay from appropriate zones, if necessary.

SIA Installations: delay must be minimum of 15 seconds

Used with zones assigned to zone type 25 and/or zones assigned to a configurable zone type with fault delay on. This field lets you select a zone response time of 15 seconds to 15 min. It can be assigned to zones with sensors designed to provide a trouble indication when an oil tank is low, or other similar application for critical condition monitoring where a non-alarm response is desired. UL Installations: May only be used on non-burglar alarm and non-fire alarm zones when used on a fire and/or UL burglar

FIELD TITLE and DATA ENTRIES EXPLANATION

*54

Dynamic Signaling Delay

0 = disabled (both signals sent)

1–15 = entry times a 15-second delay.

e.g., 1 = 15 seconds, 2 = 30 seconds,

etc.

alarm installation.

Intended for reporting via a communication device on the ECP bus (Long Range Radio). This field lets you select the time the panel should wait for acknowledgment from the first reporting destination (see ∗55) before it attempts to send a message to the second destination. Delays can be selected from 0 to 225 seconds, in 15-second increments. This delay is per message. If ”0” is entered in this field, the control panel will send redundant reports to both Primary Dialer and the communication device.

UL Installations:

For UL Burglar Alarm installations with Line Security, Dynamic Signaling Delay must be “0”. The reports will be sent to both the dialer and the communication device.

4-4

*55

*56

*57

*58

Dynamic Signaling Priority

0 = Primary dialer first / AAV via phone

line

1 = Communication Device (LRR) first /

AAV via communication device path (see AAV Path Select paragraph at right)

UL Installations: For UL Commercial Burglary installations that use a DACT and LRR, the DACT must be programmed for priority (option “0”).

Zone Programming Menu Mode

Function Key Menu Mode

Expert Zone Programming Menu

Mode

System Status Report Codes (

Zone report codes are programmed using interactive ✱56 or ✱58 Zone Programming modes, while system status (non-alarm) codes and restore codes are entered in the following data fields. UL installations: Program fields *59 - *76 as required by the applicable UL Standards shown in each field’s description.

Contact ID® Reporting: Enter any digit (other than “0”) in the first box to enable the zone to report. Entries in the second boxes are ignored.

∗∗∗∗

This field selects the primary communication path for reporting (dialer or communication device) of primary phone number events (see ∗49 Split/Dual Reporting) and selects the communication path used for AAV sessions (phone line or communication device path). Use ∗29 IP/GSM menu mode to enable the communication device being used.

For Dynamic Signaling Priority:

reporting destination for messages as follows:

Primary Dialer First selected (0):

• If acknowledged before delay expires (see ∗54), then

message will not be sent via LRR.

• If not acknowledged before delay expires, message is sent to

both the Primary Phone No. and via LRR.

Communication Device (Long Range Radio) First selected (1):

• If acknowledged before delay expires, then message will not

be sent to the primary dialer.

• If not acknowledged before delay expires, message is sent to

both the Primary Phone No. and via LRR.

For AAV Path Select:

• If using the UVS system or AVS system with non-ECP

connection, option 0 must always be used.

• If using the AVS system with ECP connection, either option

(0 or 1) may be used, but note the following:

IMPORTANT: If option “1” is selected, a 2-way voice (AAV)

device compatible with the communication device path must be used (ex. GSMV-ADT communicator). When selected, AAV sessions always occur via the GSMV-ADT communicator, even if reporting reverts to phone line backup due to GSMVADT communicator path reporting failure.

Use this menu mode to program zone information. See Zone Programming section for procedures.

Use this menu mode to program touchpad function keys. See Function Key section for procedures.

This menu mode can be used to quickly program zone information, but is recommended only for those already familiar with *56 menu mode. See Zone Programming section for procedures.

∗∗∗∗

59–

68)

Select the initial

4-5

3000EN Series: Installation Instructions

FIELD TITLE and DATA ENTRIES EXPLANATION

*59

Exit Error Alarm Report Code

SIA NOTE: exit error report is always

enabled

The Contact ID message will contain the zone number and error code 374 (“ALARM–EXIT ERROR”).

After arming the system, entry/exit and interior zones remaining open after exit delay expires cause an alarm sound at the touchpad and external sounder (touchpad also displays “EXIT ALARM”), and entry delay begins. Disarming before the end of the entry delay stops the alarm sounding and no message is sent to the central station. The touchpad will display “CA” (English displays) or “ALARM CANCELED” (Custom displays).

If the system is not disarmed before entry delay expires, an “EXIT ALARM” message and a zone alarm message is sent to the central station. The touchpad will display “EA” (English display ) or “EXIT ALARM” (Custom English display), and alarm sounding continues until the system is disarmed (or timeout occurs).

If a fault occurs in an exit or interior zone within 2 minutes following the end of the exit delay, a “RECENT CLOSING” message is sent to the central station. See field *69 Recent

*60

*61

*62

*63

*64

Trouble Report Code

0 = no report

1st digit non-zero = send report

Bypass Report Code

0 = no report

1st digit non-zero = send report

AC Loss Report Code

0 = no report

1st digit non-zero = send report

Low Bat Report Code

0 = no report

1st digit non-zero = send report

Test Report Code

0 = no report

1st digit non-zero = send report

Periodic Test Report Scheduling Commands:

installer code + [#] + [0] + 0 = report every

installer code + [#] + [0] + 1 = report once

installer code + [#] + [0] + 2 = report every

24 hrs

per week

28 days

Closing Report.

This will be sent if a zone has a trouble condition. UL: Required for UL commercial burglar alarm installations and required for residential fire alarm installations.

This will be sent when a zone is manually bypassed. UL: Required for UL commercial burglar alarm installations.

Timing of report is random with up to a 4-hour delay. If AC restores before the report is sent, there is no “AC LOSS” report. UL: Required for UL commercial burglar alarm installations and required for residential fire alarm installations.

Sent when a low-battery condition exists in the system’s battery. UL: Required for UL commercial burglar alarm installations and required for residential fire alarm installations.

Sent periodically to test that the communicator and phone lines are operational.

UL: Required for UL commercial burglar alarm installations and required for residential fire alarm installations.

Use Scheduling mode (event 11) or the key commands listed below to set the frequency of periodic test reports. Each command sets schedule 32 to the stated repeat option; first test report sent 12 hours after command.

NOTE: Make sure the Real-Time Clock is set to the proper time before entering the test report schedule command to

*65

*66

*67

*68

Open Report Code

0 = no report

1st digit non-zero = send report

Arm Away/Stay Report Code

0 = no report

1st digit non-zero = send report

RF Trans. Low Batt. Report Code

0 = no report

1st digit non-zero = send report

Cancel Report Code

0 = no report

1st digit non-zero = send report

ensure that test reports are sent when expected.

This is sent upon disarming of the system in the selected partitions. UL: Required for UL commercial burglar alarm installations.

This option allows for independent programming of Away and Stay reports for each partition, including the common lobby. NOTE: “OPEN” reports are not sent if the associated closing report is not enabled.

Sent when a wireless transmitter low-battery condition exists. UL installations: must be enabled if wireless devices are used; Required for UL commercial burglar alarm installations.

This is sent upon disarming of the system after an alarm condition was reported. SIA NOTE: Report enabled.

4-6

*69

Recent Closing Report Code

SIA NOTE: Recent closing report is

always enabled.

The Contact ID message will contain the zone number and error code 459 (“RECENT CLOSING”).

Similar to the Exit Error condition described in field *59, but occurs if any burglary zone is faulted within two minutes after the initial exit delay expires. Disarming the system within the two minutes stops the alarm sound and displays " ALARM CANCELED " or "CA" and the faulted zone number. No message is sent to the Central Monitoring Station. If the system is not disarmed within two minutes, the alarm sound continues and a “recent closing” and a “zone alarm” message are sent to the Central Monitoring Station (after dial

∗∗∗∗

Restore Report Codes (

FIELD TITLE and DATA ENTRIES EXPLANATION

*70

*71

*72

*73

*74

*75

Alarm Restore Report Code

0 = no report

non-zero = send report

Trouble Restore Report Code

0 = no report

1st digit non-zero = send report

Bypass Restore Report Code

0 = no report

1st digit non-zero = send report

AC Restore Report Code

0 = no report

1st digit non-zero = send report

Low Bat Restore Report Code

0 = no report

1st digit non-zero = send report

RF Xmtr Low Batt. Restore Code

0 = no report

1st digit non-zero = send report

70–

∗∗∗∗

76)

delay expires).

Sent when an alarm zone is restored to non-faulted condition. UL: Required for UL commercial burglar alarm installations and required for residential fire alarm installations.

This is sent when a trouble in a zone is restored and code + OFF performed. UL: Required for residential fire alarm installations.

This is sent when a zone that has been bypassed is unbypassed. UL: Required for UL commercial burglar alarm installations.

Sent after AC power has been restored after an AC power outage. UL: Required for UL commercial burglar alarm installations and required for residential fire alarm installations.

Sent after a system low-battery condition is restored to normal. UL: Required for UL commercial burglar alarm installations and required for residential fire alarm installations.

Sent when a transmitter’s low battery condition is restored (i.e., new battery installed). UL installations: must be enabled if wireless devices are used; Required for UL commercial burglar alarm installations and

*76

Test Restore Report Code

0 = no report

1st digit non-zero = send report

required for residential fire alarm installations.

This is sent when the Test mode is exited or upon timeout (4hrs). UL: Required for UL commercial burglar alarm installations and required for residential fire alarm installations.

Miscellaneous System Fields

FIELD TITLE and DATA ENTRIES EXPLANATION

*77

Daylight Saving Time

Start/End Month

0 = Disabled 4 = April

1 = Jan # + 10 = Oct

2 = Feb # + 11 = Nov

*78

3 = Mar # + 12 = Dec

Daylight Saving Time

Start/End Weekend

0 = disabled 4 = fourth

1 = first 5 = last

2 = second 6 = next to last

*79

3 = third 7 = third to last

Output Device Mapping Menu

Mode

Enter the start and end month for daylight savings time, if applicable to the region.

Enter the start and end weekend for daylight savings time, if applicable to the region.

Use this menu mode to enter output devices/powerline carrier devices into the system. See Output Device Programming section for procedures.

4-7

3000EN Series: Installation Instructions

FIELD TITLE and DATA ENTRIES EXPLANATION

*80

*81

*82

*84

Output Programming Menu Mode

Zone List Menu Mode

Alpha Descriptor Programming

Menu Mode

Auto-Stay Arm

0 = no

1 = partition 1 only

2 = partition 2 only

3 = both partitions

Use this menu mode to define output functions for use with output devices/powerline carrier devices. See Output Programming section for procedures.

Use the menu mode to define zone lists. See Zone List Programming section.

Use this menu mode to assign alpha descriptors to zones and/or create partition descriptors.

If enabled, the system will automatically change AWAY mode to STAY mode if the entry/exit door is not opened and closed within the exit delay time after a user arms in AWAY mode from a wired touchpad (non-RF device). An Opening report followed by an Armed Stay report is sent to the Central Station. If the door is opened and closed within the exit delay period, the system remains in AWAY mode. Any RF device that arms the system AWAY overrides this

*85

Cross Zone Timer

0 = 15 secs 6 = 2.5 min #+12 = 8 min

1 = 30 secs 7 = 3 min #+13 = 10 min

2 = 45 secs 8 = 4 min #+14 = 12 min

3 = 60 secs 9 = 5 min #+15 = 15 min

4 = 90 secs #+10 = 6 min

5 = 2 min #+11 = 7 min

*86

Cancel Verify Touchpad Display

0 = no

1 = yes

feature and the system remains armed in the AWAY mode.

Sets the maximum amount of time in which two cross zones must be tripped in an armed system to send an Alarm message to the Central Station. If only one cross zone is tripped during this time, a trouble message (CID code 380) for that zone is sent to the Central Station. Assign cross zone pairs in zone list 4. NOTE: Cross zoning takes effect only after Exit Delay expires. This option not for use in UL installations.

When enabled (1 = yes), this feature causes the message “ALARM CANCELED” to be displayed on the LCD touchpad under the following conditions:

• After the kissoff of the cancel message to the Central Station,

indicating a successful transmission.

• If an alarm is canceled before the Central Station received the

Alarm message. For example, if an alarm is incorrectly triggered and the user presses code + OFF before the dial delay time for the alarm has expired, the message will never go out to the CS. When the Cancel report is not enabled and the system is

•

a. before dialer delay expires (alarm report not sent) message

b. after dialer delay expires “Alarm Canceled” is not

*89

*90

Event Log Full Report Code

0 = no report

1st digit non-zero = send report

Event Log Enables

0 = no event logging

1 = log Alarm/Alarm Restore

2 = log Trouble/Trouble Restore

4 = log Bypass/Bypass Restore

8 = log Open/Close

x = log combination of events (add

value of entries)

If an Event Logging selection is made in field ∗90, a message can be sent to the central station receiver when the log is 80% full. If the log becomes full, new messages overwrite the oldest messages in the log.

This system can record various events in a history log (up to 100 events). The downloader operator can then upload the log and view or print out all or selected categories of the log. The downloader operator can also clear the log. Event log can also be viewed at an alpha touchpad. The display/printout at the central station will show the date, time, event, and description of the occurrences. Data Entry Example: To select Alarm/Alarm Restore” and “Open/Close”, enter 9 (1+ 8); to select all events, enter #15.

disarmed:

“Alarm Canceled” is displayed.

displayed

4-8

*91

Option Selection / Call Waiting

Disable & ADT Pulse Enable

Entry 1: Options

0 = none

1 = Bell Supervision Processing†

4 = using Audio Alarm Verification

(AAV) unit

8 = Enable Exit delay restart/reset ††

1. UL installations using the AAV feature must use the ADEMCO UVCM module (part of ADEMCO UVS system).

2. Bell supervision is required for fire alarm installations.

3. Exit delay restart/reset must be disabled.

FOR SIA INSTALLATIONS: Exit delay should be enabled.

Multiple choice example: for both AAV and Exit delay restart, enter # + 12 (4 +

8); for all (1 + 4 + 8), enter # + 13.

Entry 2: Call Waiting Disable / ADT

Pulse Enable

0 = Call Waiting not used / Pulse

disabled

1 = Call Waiting disable digits (*70)

entered in field *40 2 = Pulse enabled 3 = Call Waiting disable and Pulse

enabled

*92

Phone Line Monitor Enable Entry 1–Timeout:

0 = disabled 1-15 = 1 minute to 15 minutes

respectively

(2 = 2 min, 3 = 3 min, etc.;

# = 10 = 10 min, # + 11 min = 11, # + 12 = 12 min, # + 13 = 13 min, # + 14 = 14 min, # + 15 = 15 min)

Entry 2–Display/Sound:

0 = touchpad display only when phone

line is faulted.

1 = touchpad display plus touchpad

trouble sound when line is faulted. Each partition turns off its own trouble sound. No automatic timeout.

2 = Same as “1” plus programmed

output device STARTS. If either partition is armed, external sounder activates. External sounder will be turned off by normal bell timeout, or by security code plus OFF from either partition (it does not have to be the one that was armed).

Entry 1: Options

Select the desired options by adding the values of each desired option.

† If bell supervision is selected, you must also cut the red PCB jumper.

††“Exit Delay Restart/reset” option allows use of the [∗] key to restart the exit delay at any time when the system is armed STAY or INSTANT. This feature also enables automatic exit delay reset, which, when the system is armed in AWAY mode, restarts exit delay if the entry/exit door is re-opened and closed before the original exit delay time expires. This automatic exit delay reset occurs only once during an armed away period.

IMPORTANT: AAV should not be used when Paging or Alarm Reports are sent to a secondary number unless the monitoring zone option is used (which pauses calls). Otherwise, the call to the secondary number by the communicator after the alarm report will prevent the AAV from taking control of the telephone line, and the AAV “Listen in” session cannot take place.

Entry 2: Call Waiting Disable / ADT Pulse Interactive Solutions Enable

Call Waiting Disable: If call waiting is used, the call

waiting cancel digits must be entered in field *40 PABX Code or Call Waiting Disable, and the call waiting disable option must be enabled (“1”) in entry 2. When selected, the system dials the entry in field *40 only on alternate dial attempts; this allows proper dialing in the event call waiting service is later canceled by the user.

ADT Pulse Enable: Enables ADT Pulse Interactive Solutions, if used.

Entry 1: Sets the length of time a phone line fault must remain after detected before the second digit option is activated.

Entry 2: Selects the desired phone line fault response. Option 2 may be used even if a relay unit or Powerline carrier device is not connected to the control. Programmed Output Device must either be programmed to be STOPPED in field ∗80 or STOPPED by entry of [security code] + [#] + 8 + device number. Partition in ∗80 should be set to “0,” for STOP.

L Field *92 must be enabled for fire alarm installations, UL

commercial burglar alarm installations and UL residential burglar alarm installations.

If the control unit is used on a UL commercial burglar alarm system which requires 2 methods of remote communication, then the control unit’s DACT and the other method of signal transmission must monitor each other against communication failure and line fault. The fault must be received and annunciated within 200 seconds of its occurrence.

4-9

3000EN Series: Installation Instructions

*93

No. of Reports In Armed Period per Zone (Swinger Suppression)

Entry 1: No. of Report Pairs

1 = 1 report pair per zone per armed

period

2 = 2 report pairs per zone per armed

period

Entry 2 (SIA Installations): Unlimited

Reports Enable

0 = restrict reports to the setting in

entry 1

1 = unlimited reports for zones listed in

*94

zone list 7

Download Phone Number

Enter up to 20 digits as follows: 0–9, # +11 for “∗”, # + 12 for “#”, # + 13 for a pause.

*95

Ring Count For Downloading

0–15 = number of rings before control

picks up phone line .

† NOTE: If “15” is entered to bypass an answering machine, and a 4286 Phone Module is included in the system, you should note the following: When calling in from an offpremises phone, the user should make the initial call, allow 1 or 2 rings only, then hang up. The user should then call again. The phone module will now seize the line, and 2 long tones sound, followed by the usual voice prompt for the access code. If this procedure is not followed, phone module operation

*96

*97

*98

*99

will not be possible.

Command to Initialize CSID and Subscriber Account Number

Command to Reset System to Factory Default Values

Command to Exit Program Mode (with installer code lockout)

Command to Exit Program Mode

This option can be used to limit the number of alarm/alarm restore message pairs per zone sent to the central station in an armed period. Swinger suppression applies to burglary zones only.

Use entry 1 to limit reports to one or two report pairs as desired, or use entry 2 for zones that require unlimited reporting; these zones ignore the setting in entry 1. If selected, enter appropriate zones in zone list 7.

SIA installations: Entry 1 must be set for option 1 or 2.

Enter the phone number of the downloading computer. Do not fill unused spaces. End field by entering ∗. To clear entries from field, press ∗94∗.

Field *

L Downloading may be performed only if a technician is at the site.

Refer to the chart below and program this field accordingly.

phone answer down- module machine loading Set field ∗∗∗∗95 to…

yes no no 1-14 (not 0) yes yes no greater than rings set on

answer machine (e.g., if ans. machine is 4 rings, set this field to 5). This allows access to the phone module if the

answer machine is turned off. yes no yes 1-14 (not 0) yes yes yes 15 (bypasses answer

machine)† no no no 0 no yes no 0 no no yes 1-14 no yes yes 15

This is a command function, not a data field. Use this command, if necessary, to reset all subscriber account numbers and the internal CSID to the factory default values.

This is a command function, not a data field. Pressing ∗97 resets all data fields to the factory default values (shown on the Program Form). IMPORTANT: Do not press ∗97 to load defaults if any programming has been done previously—data already programmed into the system will be changed!

Exits Programming Mode and prevents re-entry by: Installer Code + [8] + [0] + [0]. To enter the programming

mode if ∗ 98 was used to exit, you must first power the system down. Then power up again, and press [∗] and [#] at the same time, within 50 seconds of powering up.

Exits Programming Mode and allows re-entry by: Installer Code + [ 8] + [0] + [0] or by: Pressing [∗] and [#] at the same time, within 50 seconds of power-up.

4-10

Pager Programming Fields

FIELD TITLE and DATA ENTRIES EXPLANATION

*160

*161

FIELD TITLE and DATA ENTRIES EXPLANATION

*162

Pager 1 Phone No.

Enter up to 20 digits

Pager 1 Characters

Enter up to 16 characters

Pager 1 Report Options

0 = No reports sent 1 = Open/close for all users enabled to

page† 4 = All alarms and troubles 5 = All alarms, troubles, and open/close

for all users enabled to page 12 = Alarms and troubles for zones

entered in zone list 9 13 = Alarms and troubles for zones

listed in zone list 9 and open/close

*163

*164

*165

for all users enabled to page

Pager 2 Phone No.

Enter up to 20 digits

Pager 2 Characters

Enter up to 16 characters

Pager 2 Report Options

see pager 1 reports, field *162 for entries, except use zone list 10.

If you enter fewer than 20 digits, exit by pressing [∗] and next field number. To clear entries from this field, press ∗160∗.

Up to 16 optional characters may be sent as a prefix to the 7digit system status code sent to Pager #1 (if used). Phone number in field *160 must have been entered. If fewer than 16 characters, exit by pressing [∗] and next field number. To clear entries, press ∗161∗. For example, these optional 16 characters may be composed of the following:

• PIN number (to identify a specific pager to the paging

company)

• Subscriber account number

• ∗ (enter # + 11 to send ∗)

• # (enter # + 12 to send #)

• Pause (enter # + 13 to allow a 2-second pause)*

• Any special character(s) the end user may decide to

transmit * Some paging systems require pause(s) before the prefix. Pager Format: XXX-YYYY where: XXX = 3-digit event code: 911 = Alarm 811 = Trouble 101 = Opening (disarm) 102 = Closing (arm AWAY) YYYY = 4-digit user or zone number (depending on type of

The first digit indicates partition (0 = system, 1 = part 1, 2 = part 2, 3 = common), followed by the 3-digit user or zone number. Example 1. Pager displays: 911– 1004 This indicates that the system is reporting an alarm (911) caused by a fault in zone 4 (0004) in partition 1. Example 2. Pager displays: 102– 2005 This indicates that the system is reporting a closing–system arming (102) by User 5 (0005) in partition 2.

Enter the types of reports to be sent to Pager 1 for each partition.

† Reports to pager only when arming (close)/disarming (open) from a touchpad using a security code; autoarming/disarming, arming with assigned button, and keyswitch arming do not send pager messages.

If you enter fewer than 20 digits, exit by pressing [∗] and next field number. To clear entries from this field, press ∗163∗.

See field ∗161 for explanation of entries. If fewer than 16 characters, exit by pressing [∗] and next field number. To clear entries from this field, press ∗164∗.

Enter the types of reports to be sent to Pager 2 for each partition.

event).

4-11

3000EN Series: Installation Instructions

*166

*167

*168

*169

*170

*171

*172

Pager 3 Phone No.

Enter up to 20 digits

Pager 3 Characters

Enter up to 16 characters

Pager 3 Report Options

see pager 1 reports, field *162 for entries, except use zone list 11.

Pager 4 Phone No.

Enter up to 20 digits

Pager 4 Characters

Enter up to 16 characters

Pager 4 Report Options

see pager 1 reports, field *162 for entries, except use zone list 12.

Pager Delay Option for Alarms

0 = none 2 = 2 minutes 1 = 1 minute 3 = 3 minutes

Miscellaneous System Fields

*173

*175

*176

*177

*180

*181

RF Reporting Options

0 = disable all options 1 = RF Tamper reports during disarm 2 = RF button types send low battery

reports

8 = RF low battery reports delayed 28

days

Up And About Time

0 = none; 1-15 = 1 to 15 hours respectively

Lack Of Usage Option

0 = disable feature 1-15 = 1-15 weeks

Device Duration 1, 2

0 = 15 secs 6 = 2.5 min #+12 = 8 min 1 = 30 secs 7 = 3 min #+13 = 10 min 2 = 45 secs 8 = 4 min #+14 = 12 min 3 = 60 secs 9 = 5 min #+15 = 15 min 4 = 90 secs #+10 = 6 min 5 = 2 min #+11 = 7 min

Single Zone Bypass

0 = disable; 1 = enable

50/60 Hz AC Operation

0 = 60 Hz; 1 = 50 Hz

If you enter fewer than 20 digits, exit by pressing [∗] and next field number. To clear entries from this field, press ∗166∗.

See field ∗161 for explanation of entries. If fewer than 16 characters, exit by pressing [∗] and next field number. To clear entries from this field, press ∗167∗.

Enter the types of reports to be sent to Pager 3 for each partition.

If you enter fewer than 20 digits, exit by pressing [∗] and next field number. To clear entries from this field, press ∗169∗.

See field ∗161 for explanation of entries. If fewer than 16 characters, exit by pressing [∗] and next field number. To clear entries from this field, press ∗170∗.

Enter the types of reports to be sent to Pager 4 for each partition.

This field determines the delay of alarm reports to the pager. This gives the Central Station enough time to verify the alarm report that it received, before the dialer attempts to dial the pager. NOTE: This delay is for ALL pagers in the system.

E.g., .Entering “10” (8 + 2) enables button-type transmitters to send low battery reports, and delay all low battery reports for 28 days. UL Installations: RF tamper reports (“1”) and RF button low battery reports (“2”) must both be enabled by entering “3” in this field.

This option is part of an Up and About schedule (event 12) that requires programming (see Scheduling section for details). The value in this field is the time within which activity must occur within the overall scheduled up and about time window. If no zones are faulted or no key is pressed within the selected time period during a scheduled Up and About time window, a report is sent to the central station. This can serve as a safety feature for elderly, infirm, or disabled persons.

If the control is not armed within the selected time period, a report is sent to the central station.

These entries set the duration for output action options 5 (duration 1) and 6 (duration 2) programmed in ∗80 Output Function Programming.

If enabled, users can bypass only one zone when arming the system.

Select the type of AC power applied to the control. This option is used for Real-Time Clock synchronization.

4-12

Configurable Zone Type Programming Fields

The system allows you to define up to four custom zone types (zone types 90-93), based on the options described below, which can be assigned to zones that require customized responses. All of these zone types can be programmed via the downloader. Configurable zone types 90 and 91 can also be programmed from a touchpad using data fields *182-*185 described below.

IMPORTANT: Be careful when selecting combinations of options for configurable zone types. Contradictory options can cause unpredictable results.

UL installations: Do not configure zones as a fire alarm or UL burglar alarm zone.

*182

Configurable Zone Type 90

0-15 = values for each of 10 entries (0-9, #+10 = 10, #+11 = 11, #+12 = 12, #+13 = 13, #+14 = 14, #+15 = 15)

Enter the appropriate value for each entry, 1-10, based on the charts on the next page. add the values of the selected options in each of the entry’s columns shown in the respective chart (one option per column). For example, to program entry 2 for “alarm response to short,” “auto restore on,” but not a “vent zone,” enter 5 (“1” for alarm

*183

Zone Type 90 Report Codes

90 ALARM ID: XXX TROUBLE ID: XXX

Use existing Contact ID® codes, if appropriate, or define unique codes in CID code range 750-789.

NOTE: zone alarm report code (prompt in ∗56 Zone Programming) and trouble report code (∗60) and relevant restore codes (∗70, ∗71) must be enabled in order for the configurable zone type codes to be reported.

*184 *185

Configurable Zone Type 91

Zone Type 91 Report Codes

91 ALARM ID: XXX TROUBLE ID: XXX

short + “4” for auto restore yes + “0” for vent zone no).

Enter the desired 3-digit Contact ID report codes for alarms and troubles occurring on zones assigned to this zone type. Press [∗] to accept and continue.

Important Notice on Report Codes: To avoid confusion at the central station, it is recommended that existing Contact ID® codes be used with configurable zone types whenever possible. See list in System Communication section and/or check with the central station for a complete list of Contact ID® report codes. If none of the codes are suitable, choose a code in the reserved range of 750-789 (reserved for configurable zone type report codes) and make sure to define the code with your central station.

See field *182 for explanation of entries.

See field *183 for explanation of entries.

iCenter (AUI) Enable

FIELD TITLE and DATA ENTRIES EXPLANATION

*189

Touchscreen Device (AUI) Enable

See Partition Entries table at right for entries.

Touchscreen Compatibility Note: To ensure proper touchscreen device operation, use AUI devices with the following rev levels: Touchscreen style touchpads use version 1.0.9 or higher; iCenter use version 1.1.175 or higher.

Note for Remote Services Device Address: Using a touchscreen device address for Remote Services provides enhanced remote services features, but an actual AUI device is not used. If no AUI addresses are available (all four AUIs are being used), choose an available standard touchpad address and use the appropriate touchpad address field ∗190 - ∗196 to select the Remote Services operating partition (some remote access features will be unavailable).

† Remote Services Devices: If using the

Remote Services feature of the communication device, select an option 5-7, depending on the partition the Remote Services device is associated with (these options automatically disable auto-stay arming when the system is armed from the respective Remote Services device). Refer to the communication device’s installation instructions for details on enabling the Remote Services feature.

The system supports up to four touchscreen style touchpads (e.g., iCenter and 6270ADT).

To enable a touchscreen, enter the option corresponding to each touchscreen’s home partition:

Partition Entries:

for Touchscreen device usage

0 = disable 5 = partition 1 1 = partition 1 6 = partition 2 2 = partition 2 7 = partition 3 (common;) 3 = partition 3 (common)

NOTES:

• Use of touchscreens does not affect the number of standard

• Touchscreen device addresses must be set as follows:

Device Address AUI 1 1 AUI 2 2 AUI 3 5 AUI 4 6

touchpads supported.

To calculate the value for each entry,

for Remote Services device usage arm feature disabled)

†

(auto-stay

4-13

3000EN Series: Installation Instructions

Configurable Zone Type Options

Auto Restore

Vent Zone

Bypass when Disarmed Bypass when Armed Dial Delay

Fault Delay

Faults Display Power Reset/Verification

Use Entry Delay 1/2 Use Exit Delay Interior Type

Alarm Sounds Bell Timeout

Fire Zone

Trouble Sounds

Chime Enable

Faults on zones set for this option are cleared and restore messages sent upon restoral of faults. Zones set for this option are ignored if faulted when arming the system, but will be protected if the zone is later restored (e.g., an open window can be ignored when arming, but if the window is later closed, it will be protected; opening the window again causes an alarm.) Zones set for this option can be bypassed only while the system is disarmed. Zones set for this option can be bypassed while system is armed. Alarms on zones set for this option participate in dial delay central station reporting, if system dial delay enabled in field *50. Faults on zones set for this option are delayed by the time set in field *53. Do not use this option if using entry/exit delay for this zone type. Selects how faults on zones set for this zone type are displayed. Selects whether the system resets power (when user enters code + OFF), and whether the system performs alarm verification (see description for zone type 16 in Section 3 Programming Overview) when a fault occurs on these zones. Selects whether to use the system’s entry delay times. Selects whether to use the system’s exit delay time. Zones set for this option are treated same as standard zone type 4 (bypasses when armed STAY, faults displayed). Selects the type of alarms sound for zones set for this zone type. Alarm sounds on zones set for this option remain for the duration set in fields *32 and *33. Zones set for this option respond in the same manner as if programmed for zone type 9. Do not set fire zones to respond as a “fault” in entries 1-6. Selects the type of trouble sounds for zones set for this zone type (periodic beeps = once every 30 seconds; trouble beeps = rapid beeping). Zones set for this option cause a chime when Chime mode is on.

4-14

Configurable Zone Type Charts

ENTRY 1 ENTRY 2

Response when system disarmed and zone is:

Intact EOL

RF zone normal

0 = normal 1 = alarm 2 = trouble 3 = fault

Open

RF zone N/A

0 = normal 4 = alarm 8 = trouble 12 = fault

Shorted

RF zn off-normal

0 = normal 1 = alarm 2 = trouble 3 = fault

Auto

Restore

0 = no 4 = yes

Vent Zone

0 = no 8 = yes

see note 5

Entry 1 = EOL + Open Entry 2 = Short + auto restore + vent zone

ENTRY 3 ENTRY 4

Response when armed STAY and zone is:

Intact EOL

RF zone normal

0 = normal 1 = alarm 2 = trouble 3 = fault

Open

RF zone N/A

0 = normal 4 = alarm 8 = trouble 12 = fault

Shorted

RF zn off-normal

0 = normal 1 = alarm 2 = trouble 3 = fault

Byp. when

disarmed

0 = no 4 = yes

Byp. when

armed

0 = no 8 = yes

see note 5

Entry 3 = EOL + Open Entry 4 = Short + byp. disarmed + byp. armed

ENTRY 5 ENTRY 6

Response when armed AWAY and zone is:

Intact EOL

RF zone normal

0 = normal 1 = alarm 2 = trouble 3 = fault

Open

RF zone N/A

0 = normal 4 = alarm 8 = trouble 12 = fault

Shorted

RF zn off-normal

0 = normal 1 = alarm 2 = trouble 3 = fault

Dial Delay

(see field *50)

0 = no 4 = use delay

Fault Delay

(see field *53)

0 = no 8 = use delay

see note 1

see note 5

Entry 5 = EOL + Open Entry 6 = Short + dial delay + fault delay

ENTRY 7 ENTRY 8

Display Faults Power Reset/

Verification

0 = show alarms

when armed & disarmed

1 = don’t show

alarms when armed

alarms, trbles, faults when disarmed)

0 = no 4 = power reset

(with code + OFF)

12 = verification (see zone

(show

after fault

type 16)

Use Entry

Delay 1/2

0 = no 1 = delay 1 2 = delay 2

Use Exit

Delay

0 = no 4 = use exit

delay

Respond as

Interior Type

0 = no 8 = yes

see note 2

3 = never show

any alarms,

trbles, faults Entry 7 = fault display + power reset/verification

Entry 8 = entry delay 1/entry delay 2 + exit delay +

interior zone type

ENTRY 9 ENTRY 10

Alarm Sounds Use Bell

Timeout

0 = none 1 = steady

touchpad 2 = steady bell

and

0 = no 4 = yes

see fields *32, *33

Respond as

Fire Zone

0 = no 8 = yes

see zone type 09; see note 4

Trouble Sounds

0 = none 1 = periodic

beep

2 = trouble

beeps

Chime when Chime

Mode On

0 = no 4 = yes

touchpad 3 = pulsing bell

and

touchpad Entry 9 = alarm sounds + bell timeout + fire zone Entry 10 = trouble sounds + chime

EOL

OPEN SHORTEDINTACT

ADT3000-018-V0

Zone Conditions Represented

in Entries 1-6

Configurable Zone Type Notes

1. Do not use the “fault delay” option with a configurable zone type if it is set for an entry or exit delay, otherwise unpredictable results may occur.

2. To create an interior type zone, select “respond as interior zone type” (entry 8, interior type = yes), and set zone response to “fault” in entries 3-4 to ensure fault displays; do not set as “normal,” “alarm,” or “trouble.”

3. Do not set fire zones to respond as a “fault” (entries 1-6), otherwise faults will not display unless the [∗] key is pressed.

4. 4219/4229 modules must use EOLRs or unpredictable results may occur.

5. RF ZONE NOTE: The “open” options in entries 1, 3, and 5 are not applicable for RF zones. Use the “intact EOL” option for normal RF zone conditions and “shorted” for off-normal RF zone conditions.

4-15

3000EN Series: Installation Instructions

Touchpad Programming Fields

NOTE: Each touchpad must be assigned a unique address. Touchpads programmed with the same address will give unpredictable results.

FIELD TITLE and DATA ENTRIES EXPLANATION

*190

*191 *192 *193 *194 *195 *196 *197

*198

*199

Touchpad 2 Device Address 17

Entry 1 – Partition Assignment:

0 = touchpad disabled

Standard Touchpads 1 = partition 1 2 = partition 2

3 = partition 3 (common)

Touchpad 2

Entry 1: Enter the partition in which the touchpad is located. Entry 2: Enter the desired sound option for this touchpad.

NOTE: Address 16 is reserved for touchpad 1, which is automatically set to partition 1 with all sounds enabled.

Remote Services Devices (see note in *189) 5 = partition 1 (auto-stay arm disabled) 6 = partition 2 (auto-stay arm disabled) 7 = partition 3 (auto-stay arm disabled)

Entry 2 – Sound Option:

0 = no suppression 1 = suppress arm/disarm and E/E/ beeps 2 = suppress chime beeps only 3 = suppress arm/disarm, E/E/ beeps

and chime beeps

Touchpad 3 Device Address 18

Touchpad 4 Device Address 19

Touchpad 5 Device Address 20

Touchpad 6 Device Address 21

Touchpad 7 Device Address 22

Touchpad 8 Device Address 23

Exit Time Display Interval

0 = no display 1-5 = seconds between display updates

TOUCH SCREEN DEVICE NOTE: If using more than one touch screen device with the system, leave field *197 set to the default value “0.” Touch Screen style touchpads automatically display remaining exit time in one-second increments.

Touchpad 3 See *190 for entries and description.

Touchpad 4 See *190 for entries and description.

Touchpad 5 See *190 for entries and description.

Touchpad 6 See *190 for entries and description.

Touchpad 7 See *190 for entries and description.

Touchpad 8 See *190 for entries and description.

If enabled, touchpads display the exit time remaining after arming the system, with display updates at the interval selected (i.e. if the exit delay is 30 seconds and “2” is selected in this field, the touchpad display refreshes every 2 seconds, displaying 30, 28, 26, 24, etc.). An interval greater than “1” may be necessary for some older touchpads to allow users time to enter key presses between display updates.

FIXED-WORD TOUCHPAD NOTE: If using 2-digit display touchpads (e.g. 6150RFADT), do not use exit times greater than the 96-second delay option. Using a longer delay time may cause end-user confusion because 2-digit display touchpads cannot display times greater than “99.” If longer exit time is required by the installation, it is recommended that the Exit Time Display option be disabled (“0”).

Display Partition Number

0 = no 1 = yes

ECP Fail Display

0 = 3-digit display (“1” + device address) 1 = 2-digit fixed-display as “91”

If selected, the partition number is displayed in the upper-left corner of the display. This is useful when using the GOTO partition function.

Select “0” if using Custom English touchpads and/or 3-digit English Display touchpads. ECP faults will display “1” plus the device address (00-15) of device causing the fault (e.g., faults on device 07 display as “107”). Select “1” if using 2-digit English Display touchpads (e.g., certain 6128 series touchpads). If selected, ECP faults for all devices will display as “91” on 2-digit displays, and “191” on 3-digit or Custom English touchpads.

4-16

SECTION 5

Zone Programming

(

∗∗∗∗

56 and

••••••••••••••••••••••••••••••••••••••••••••••••••

About Zone Programming

∗56 Zone Programming is used to program zones, zone types, report codes, enroll 5800 RF Wireless Transmitter serial numbers, and identify the type of loop input device(s). This mode can also be used to enter alpha descriptors for programmed zones; however, we recommend entering descriptors in menu mode ∗82 (Alpha Descriptor Programming after all zone programming has been completed). For a faster method of zone programming, you can use the ∗58 Expert Programming Mode instead of ∗56 Zone programming. The ∗58 Expert Programming Mode is designed for those who have had previous experience in programming control panels of this type.

NOTE: Alpha display prompts are shown in a double-line box.

∗∗∗∗56 Zone Programming Procedure

Zone Programming involves:

1. Entering the zone number to be programmed;

2. Making appropriate entries at the prompts;

3. Confirming the serial number of wireless transmitter zones.

Start Zone Programming mode by pressing ∗56 while in Data Programming mode. The following prompts are displayed:

PROMPT

SET TO CONFIRM? 0 = NO 1 = YES

Enter Zn Num.

(00 = Quit) 10

VALID ENTRIES EXPLANATION

Set to Confirm

0 = no 1 = yes

Zone Number

01-08 = wired zones 09-48 = expander/wireless

49-64 = RF button zones† 91 = addressable device

92 = duress report enable 95, 96, 99 = emergency

00 to quit [∗] to continue

zones

reporting enable

zones

If 1 (Yes) is entered, you will be prompted to confirm each transmitter after entering the serial and loop numbers (at the “XMIT TO CONFIRM” prompt later in this procedure). We

recommend that you confirm the programming of every transmitter.

Enter the zone number that you wish to program. Zone 10 has been entered as an example in the display at left. Zone 91 is used to enable/disable addressable device reporting. Zone 92 is used for duress reporting. 95, 96, 99 are emergency (panic) key zones.

† Each button on a wireless key must be assigned to a unique zone number. That zone number can then be programmed for the desired zone response type. Use the Wireless Key Programming Templates (following the *58 Expert Mode later in this section) to easily assign buttons to predefined functions.

∗∗∗∗

58 Menu Modes)

5-1

3000EN Series: Installation Instructions

PROMPT

Zn ZT P RC In: L 10 00 1 10 RF: 1

VALID ENTRIES EXPLANATION

Summary Screen

[∗] to continue

Zn ZT P RC In: AD 10 00 1 10 AW: 07

Zn ZT P RC HW: RT 10 00 1 10 EL 1

10 Zone Type Perimeter 03

10 Partition 1

10 Report Code 1st 01 2nd 00 10

Zone Type (ZT)

(see table at right; types 92/93 only programmable via downloader)

Partition No. (P)

1-3 = partition (3 = common) [∗] to continue

Report Code (RC)

First Digit: 01† = enable CID report

00 = disable CID report Second Digit: entries ignored

02 HARDWIRE TYPE EOL 0

[∗] to continue

Hardwire Type

0 = EOL 1 = NC 2 = NO

02 Response Time 1

[∗] to continue

Response Time (RT)

0 = 10mSec 1 = 350mSec 2 = 700mSec 3 = 1.2 seconds [∗] to continue

A summary display appears. “IN: L” appears for wireless zones and indicates input type and loop. “IN: AD” appears for hardwire expansion zones (AW) and indicates the module’s address (AD), which is based on the zone number. “HW: RT” appears for hardwire zones and indicates configuration (EOL, NO, NC ) and response time selection.

Each zone must be assigned to a zone type, which defines the way in which the system responds to faults in that zone. Enter the Zone Type code from the list below: Note: If 00 is entered, Delete Zone ? will be displayed.

00 = Not used 07 = 24-Hr Audible 20 = Arm–STAY* 01 = Entry/exit #1 08 = 24-Hr Aux 21 = Arm–AWAY* 02 = Entry/exit #2 09 = Fire 22 = Disarm* 03 = Perimeter 10 = Interior w/Delay 04 = Interior Follower 12 = Monitor Zone 24 = Silent Burglary 05 = Trouble Day/Alarm Night 14 = Carbon Monoxide 25 = 24-Hr Non-Alarm 06 = 24-Hr Silent 16 = Fire w/Verify 77 = Keyswitch 81 = AAV Monitor Zone *5800 button-type transmitters only 90-93 = Configurable

23 = No Alarm Resp

Enter the Partition number for this zone. Partition 1 is shown entered.

Entering any non-zero entry as the first digit enables the Contact ID report code for this zone. Refer to the System Communication section for information about report codes and formats.

† typical entry

This prompt appears only for zone numbers 02-08.

Zone 1 is automatically set for EOL operation.

This prompt appears only for hard-wired zones 01-08 (zone 02 is used as an example in display).

5-2

PROMPT

10 INPUT TYPE RF TRANS 3

10 INPUT S/N: L A022-4064 1

10 INPUT S/N L A022-4064 ?

10 INPUT S/N L A022-4064 1

XMIT TO CONFIRM PRESS ✱ TO SKIP

VALID ENTRIES EXPLANATION

Input Device type (In)

2 = AW (Aux wired zone) 3 = RF (supervised RF

transmitter,

4 = UR (unsupervised RF

transmitter)

5 = Button type RF

transmitter (unsupervised).

[∗] to continue

Serial number Entry and Loop Number Entry

see explanation [∗] to continue

Loop Number Change

[∗] to continue

Enroll Summary

[∗] to continue

Confirmation Option

[∗] to continue

All of the RF transmitters have one or more unique factoryassigned input (loop) ID codes. Each of the inputs requires its own programming zone (e.g., a 5804's four inputs require four programming zones). RF Transmitters can be enrolled as one of the following types:

Type Description “RF” Sends periodic check-in signals, as well

(Supervised RF) as fault, restore, and low-battery signals.

The transmitter must stay within

“UR” Sends all the signals that the “RF” type

(Unsupervised RF) does, but the control does not supervise

“BR”

(Unsupervised Sends only fault signals. It will not send a

Button RF) low-battery signal until it is activated.

NOTES:

• For the built-in hardwired zones, the Input Device type is

automatically displayed as HW and cannot be edited.

• To change the input type of a previously programmed

wireless device (type RF, UR, BR) to a wired zone (type AW), you must first delete transmitter’s serial number (see To Delete A Serial Number prompt on next page)

Used only when enrolling wireless transmitters.

a. Transmit two open/close sequences. If using a button-type

transmitter, press and release the button twice, but wait about 4 seconds before pressing the button the second time.

b. Manually enter the 7-digit serial number printed on the

label of the transmitter. Then press the [✱] key – the cursor will move to the “L” position. You can edit the loop number, if necessary. When the loop number is acceptable, press [✱].

c. Press key [C] to copy the serial number previously enrolled

(used when programming a transmitter with several input loops).

NOTE: If the [C] key is used to copy the previously enrolled serial number, the cursor will move to the Loop column (L) with the previous serial number displayed, and display a highlighted question mark for the loop number.

Enter the loop number and press [✱]. The system will now check for a duplicate serial/loop number combination.

If the serial/loop number combination is not a duplicate in the system, a display showing the serial number and loop number entry will appear.

This prompt will only appear if you answered “Yes” at the first prompt in this section.

The system will enter a confirmation mode so that the operation of the actual programmed input can be confirmed. Activate the loop input or button that corresponds to this zone.

receiver's range.

the check-in signals. The transmitter may therefore be carried off-premises.

The transmitter may be carried offpremises.

5-3

3000EN Series: Installation Instructions

Entd A022-4063 1 Rcvd A022-4064 1

If Serial or Loop Numbers do not match after activating the transmitter

[∗] to continue

10 INPUT S/N: L A000-0000 0

Zn ZT RC In: L 10 03 10 RF: 1s

PROGRAM ALPHA? 0 = NO 1 = YES 0

ENTER ZN NUM. (00 = QUIT) 11

To Delete a Serial No.

enter 0 in loop number field # = undo deletion [∗] to continue

Summary Screen

[∗] to continue

Alpha Descriptors

0 = no 1 = yes [∗] to continue

Next Zone Number

00 = quit [∗] to continue

If the serial number transmitted does not match the serial number entered, a display similar to the one shown appears. If the loop number does not match, it will also be displayed. If so, activate the loop input or button on the transmitter once again. If a match is not obtained (i.e., summary display does not appear), press the [#] key twice and then enter (or transmit) the correct serial number.

To delete an existing serial number, enter 0 in the loop number field. The serial number will change to 0's. If 0 was entered in error, simply re-enter the loop number or press [#], and the serial number will return to the display.

If the serial number transmitted matches the serial number entered, the touchpad will beep 3 times and a summary display will appear, showing that zone's programming. Note that an “s” indicates that a transmitter’s serial number has been enrolled.

Press [✱] to accept the zone information and continue.

If you want to program descriptors for zones now, enter 1 (Yes) and refer to the Alpha Descriptor Programming section for available descriptors.

If 0 (No) was entered above, the system will return you to the ENTER ZN NUM. prompt for the next zone. When all zones have been programmed, enter 00 to quit.

5-4

Completing Zone Programming

When you have finished programming all zones, test each zone using the system’s TEST mode. Do not use the Transmitter ID Sniffer Mode for checking wireless transmitting devices, as it

will only check for transmission of one zone on a particular transmitter, NOT the zones assigned to each additional loop.

NOTE: Following the successful enrollment of each wireless device, note the device serial number in the appropriate column on the ENROLLED TRANSMITTERS worksheet in the Programming Form; then enter the other information (zone number, zone type, loop number, etc.) relevant to that device.

∗∗∗∗58 Expert Programming Mode Procedures

This method is designed for use by installers with previous experience in programming ADT control panels. This mode is also used to program wireless keys using pre-defined templates.

Start Expert Programming mode by pressing ∗58 while in Data Programming mode. The following prompts are displayed:

PROMPT

SET TO CONFIRM? 0 = NO 1 = YES 0

Zn ZT P RC HW: RT 01 09 1 10 EL 1

Zn 10 – – – : –

Zn ZT P RC IN: L 10 00 1 10 RF 1

ZT P RC IN: L

VALID ENTRIES EXPLANATION

Confirm?

0 = no 1 = yes [∗] to continue

This display appears upon entry into this mode. The default is 0 (No).

If 1 (Yes) is entered, you will be prompted to confirm each transmitter after entering the serial and loop numbers (at the “XMIT TO CONFIRM” prompt later).

Summary Screen

01-64 = zone number 00 = quit [∗] to continue

[D] to go to prompts for wireless key programming templates

A summary screen will appear, showing zone 1’s currently programmed (or default) values.

Enter the zone number being programmed, then press [∗], which displays a summary screen for that zone. See next prompt (in this example, zone 10 is being entered).

If programming a wireless key, press the [D] key then skip to the Wireless Key Programming Template section following this section. When [D] is pressed, you can choose from a series of preset templates for easy programming of wireless key zones.

To quit this mode, press “00” at this Summary Screen prompt.

Zone Programming

ZT = see Zone Type chart

shown in *56 Menu Mode “Zone Type” prompt

P = partition 1, 2, 3

(common)

RC = 1 (send CID report)

0 (no report) IN = input type L = loop number

[∗] to continue

A summary screen with the selected zone’s current programming appears.

Begin programming zone information as follows:

• Enter Zone Type (ZT), Partition (P), Report Code (RC), and

Input Device Type (IN)* sequentially, but not the Loop No. (L).

• Use the [A] (Advance) and [B] (Back) keys on the touchpad

to move the cursor within the screen.

• Use the [C] key to copy the previous zone’s attributes.

Press [✱] to save the programming and continue to the serial number/loop number prompt. If needed, you can press the [#] key to back up without saving. * If HW (hardwired) or AW (Auxiliary) is entered for Input Device Type, the next screen will be similar to the prompt shown, except that HW or AW will be displayed under “IN”. If RF, BR, or UR is entered, a prompt for Serial and Loop number will be displayed, as follows.

5-5

3000EN Series: Installation Instructions

PROMPT

10 INPUT S/N: L AXXX-XXX –

VALID ENTRIES EXPLANATION

Serial number

S/N = serial number L = loop number

[∗] to continue

10 INPUT S/N: L A000-0000 0

10 XMIT TO CONFIRM PRESS ✱ TO SKIP

To Delete a Serial Number

[∗] to continue

Confirm

[∗] to continue

Entd A022-4063 Rcvd A022-4064

If Serial or Loop Numbers do not match after activating the transmitter

[∗] to continue

Zn ZT P RC In L 10 03 1 10 RF: 1s

Note that an “s” indicates that a transmitter’s serial number has been enrolled.

Summary Screen

[∗] to continue 01-64 = zone number 00 = quit

Manually enter the serial number (found on the transmitter label), by typing digits in the “X” locations, using the [A] (advance) or [B] (back) keys as required. You can also perform two open and close sequences; for button-type transmitters that means pressing and releasing the button twice.

NOTE: If you want to copy the previous zone’s serial number, press the [C] key.

Press [✱] to advance to the loop number, then enter loop number.

Press [✱] to accept the existing serial and loop number and continue to the “Confirm” prompt below. If necessary, press [#] to back up and re-enter or edit the serial number.

To delete an existing serial number, enter 0 in the loop number field. The serial number will change to all 0's as shown. If 0 was entered in error, simply re-enter the loop number, and the serial number will return to the display.

The prompt to confirm appears. This prompt will only appear if the first prompt after entering ✱58 was answered “Yes.” To confirm, activate the loop input or button that corresponds to this zone. The system checks for duplicate. If a duplicate exists, a long error beep will sound. Press [#] to back up and re-enter the serial and/or loop number.

If the serial/loop number combination transmitted does not match the serial and loop number entered, a display similar to the one below will appear. If the loop number does not match, it will also be displayed. If so, activate the transmitter’s loop input or button one or more times. If a match is still not obtained (i.e., summary display does not appear), press the [#] key twice and enter the correct loop input or, if correct, press [#] again and then enter the correct serial number.

If the serial number transmitted matches the serial number entered, the touchpad will beep 3 times and a summary display will appear, showing the programmed information for that zone.

Press [✱] to begin programming the next zone. See first “Summary Screen” prompt paragraph on previous page.

To quit this mode, press “00” at this prompt.

5-6

Wireless Key Programming Templates

This procedure programs the wireless keys, but a key is not active for arming/disarming until it is assigned to a user number (see Section 12 System Operation, assigning attributes

command page 12-2).

If the D key was previously pressed (from *58 Menu mode) to program 5804 and/or 5804BD wireless keys, the following screens appear.

PROMPT

TEMPLATE ? 1–6 1

L 01 02 03 04 T 23 22 21 23

PARTITION 1

ENTER START ZONE

00 = QUIT 36

INPUT S/N L AXXX-XXXX –

VALID ENTRIES EXPLANATION

Template Number

1–3 = 5804 templates 4–6 = 5804BD templates [∗] to continue or [#] to return

Template Display

[∗] to continue

Partition

1 = partition 1 2 = partition 2

[∗] to continue

Start Zone Number

[∗] to continue

Serial Number

[∗] to continue

1. Enter Template number 1–6 (from next page).

See the defaults provided for each template in the chart

that follows these procedures.

2. Select from templates. Press [✱] to display template (1

shown selected). NOTE: If necessary, press [#] to back up and re-enter template number.

3. If you want to return to the *58 Menu mode Summary Screen, press [#].

4. When [✱] is pressed, the selected template will be displayed.

Top line of display represents loop numbers, bottom line

represents zone type assigned for each loop.

5. Press [✱] to accept template.

6. Enter the partition in which the key is to be active.

7. Press [∗] to continue.

8. The system will search for the highest available consecutive 4-zone group (the four zones in the case of the 5804 and 5804BD), and display the lowest zone number of the group.

If you want to start at a different zone, enter the zone

desired, and press [✱]. If that zone number is displayed, the system has the required number of consecutive zones available, beginning with the zone you entered. If not, the system will again display a suggested zone that can be used.

If the required number of consecutive zones is not available at all, the system will display “00”.

To quit this mode and return to *58 Menu mode, enter 00 at this prompt.

9. Press [✱] to accept.

10. Manually enter the serial number printed on the label for the wireless key or press and release the button to transmit its serial number.

11. Press [✱] to accept the serial number. The system will check for duplicate.

12. If necessary, press the [#] key to back up without saving, and re-enter the serial number.

Use the [A] key to move forward within the screen, and the [B] key to move backward.

5-7

3000EN Series: Installation Instructions

XMIT TO CONFIRM PRESS ✱ TO SKIP

Confirm

[∗] to continue

13. If “Yes” was entered at the SET TO CONFIRM? prompt

previously (see first prompt following entry into the ∗58 Expert Programming Mode), the display on the left will appear. Confirm serial and loop numbers by activating the wireless key.

IMPORTANT:

When confirmed, the key is not active for arming/disarming until it is assigned to a user number (using the assigning attributes command, attribute “4”). See System Operation

Entd A022-4063 Rcvd A022-4064

Not Confirmed

[∗] to continue

section for procedure.

If the serial number transmitted does not match the serial number entered, a display similar to the one shown will appear. If the loop number does not match, it will also be displayed. If so, activate the button on the wireless key once again. If a match is not obtained (i.e., summary display does not appear), press the [#] key and then enter the correct serial number.

If the serial number transmitted matches the serial number entered, the touchpad will beep 3 times and will return you to step 8 (Zone Number prompt) to enter the starting zone for the next wireless key. Or you can return to *58 Menu mode by pressing 00 at the Zone Number prompt.

NOTE: Following the successful enrollment of each wireless device, remove ONE of the serial number labels from the device and affix it in the appropriate column on the ENROLLED TRANSMITTERS worksheet of the Programming Form; then enter the other information (zone number, zone type, loop number, etc.) relevant to that device.

Wireless Key Predefined Default Templates

YOU MUST PROGRAM

THIS BUTTON

LOOP 4

LOOP 3

OFF

LOOP 2

LOOP 1

Note:

These transmitters

RED/YELLOW

are not intended for use in UL installations.

ENROLL AS "BR"

5804 Wireless Key Transmitter

For 5804

5804-001-V1

5804BD 2-Way Wireless Key Transmitter

TEMPLATE 1 Loop Function Zone Type TEMPLATE 4 Loop Function Zone Type 1 No Response 23 1 No Response 23 2 Disarm 22 2 No Response 23 3 Arm Away 21 3 Arm Away 21 4 No Response 23 4 Disarm 22 TEMPLATE 2 Loop Function Zone Type TEMPLATE 5 Loop Function Zone Type 1 No Response 23 1 No Response 23 2 Disarm 22 2 Arm Stay 20 3 Arm Away 21 3 Arm Away 21 4 Arm Stay 20 4 Disarm 22 TEMPLATE 3 Loop Function Zone Type TEMPLATE 6 Loop Function Zone Type (same as temp. 2) 1 No Response 23 (same as temp. 5) 1 No Response 23 2 Disarm 22 2 Arm Stay 20 3 Arm Away 21 3 Arm Away 21 4 Arm Stay 20 4 Disarm 22

GREEN/YELLOW

LED

LOOP 3

ENROLL AS "BR"

For 5804BD

LED

LOOP 2

LOOP 4 (YOU MUST PROGRAM THIS BUTTON)

•

•••

•

LOOP 1

5804BD-007-V0

NOTE: Templates 3 and 6, which are identical to templates 2 and 5 respectively, are shown for future reference.

5-8

SECTION 6

Output Device Programming

(*79/*80 Menu Mode)

•••••••••••••••••••••••••••••••••••••••

About Output Device Programming

Output Devices: The system supports up to 16 relays and/or Powerline Carrier devices (X-10

devices) plus 2 built-in trigger outputs in any combination. These 18 “outputs” are assigned to system-wide output numbers (01-18). Use *79 Menu Mode to

Output Functions: The system also provides up to 48 installer-defined output functions, which can

Relays and output devices are not recommended for life safety applications.

NOTE: When navigating the *79 and *80 menus: The [✱] key is used to accept an entry and advance to the next prompt. The [#] key is used to revert back to the last question to check or change an entry. Press [✱] to go forward again.

Output Device programming involves:

1. Use *79 Menu Mode to assign module and output numbers and map them to device addresses. NOTE: You must map output devices using *79 Menu Mode before you can use *80 menu Mode).

2. Use *80 Menu Mode to create up to 48 output definitions, which control the output devices.

*79 Menu Mode: Output Device Mapping

Use this menu to assign Relay Module device addresses and specific relay numbers, and Powerline Carrier unit numbers. The system is based on predefined module addresses for 4204 and 4229 modules. Refer to the table shown at the “Module Address” prompt on the next page and set the modules’ addresses (via module DIP switches) accordingly.

The following table shows how these outputs are identified.

Output Identification This output… is identified by…

Relays: the Relay Module’s device address and the relay position on that module (i.e. the

X-10 Device a house ID (entered in data field *27) and the unit number of the device. Built-in Outputs the output number assigned, 17 for Trigger 1 and/or 18 for Trigger 2.

assign output numbers and map them to device addresses.

be assigned to any of the 18 physical outputs. Therefore, the action of any one of the 18 outputs can be based on as many of these defined functions as desired. This lets a single relay or X-10 device perform many functions. Use *80 Menu Mode to define output functions.

physical relay number, 1-4, on that module).

6-1

3000EN Series: Installation Instructions

Start Output Device Mapping by pressing *79 while in Data Programming Mode. The following prompts are displayed:

∗∗∗∗79 Menu Mode

PROMPT

ENTER OUTPUT NO. 00 = QUIT xx

17 OUT NORM LOW 0 = NO 1 = YES 0

XX OUTPUT TYPE DELETE 0

“A”

XX UNIT No. yy

“B”

XX MODULE ADDR 07-15 yy

XX REL POSITION 1-4 zz

VALID ENTRIES EXPLANATION

Device Output Number

01-16, 17, 18 [∗] to continue

Output Normally Low

0 = no (standard default) 1 = yes [∗] to continue

Output Type

0 = delete 1 = relay on 4204/4229 module 2 = Powerline Carrier device [∗] to continue

Unit Number

01-16 = predefined address [∗] to continue

Module Address

07-15 = predefined address [∗] to continue

Relay Position

1-4 = relay position [∗] to continue

This is the logical (or reference) relay number as used in the system. Relays and X-10 devices are numbered 01-16; the onboard triggers are numbered 17 and 18 and can be programmed for inverted output.

This prompt appears only for Triggers 17 and 18. Selecting 0 (no) sets the output level normally high. Selecting 1 (yes) sets the output normally low. Output Trigger 17 can be used for resetting 4-wire smoke detectors by connecting it to the negative power terminal of the smoke detector, selecting 1 at this prompt, and setting as zone type 54, fire zone reset, in *80 Menu mode. After entry, display returns to Output Number prompt. Use *80 Menu mode to program the function of the trigger.

Select whether this is a relay or a Powerline Carrier (X-10) device. If relay is selected, skip to “B” prompt. If Powerline Carrier device is selected, go to “A” prompt.

If X-10 is selected, a prompt for the unit number appears. Enter the unit code (set at the device) and press [∗]. The system returns to the Output Number prompt.

If relay is selected, this prompt appears. Enter the predefined address for this module as listed below. Make sure the module’s DIP switches are set to the selected address.

Module Addresses

Address Module

07 1st 4229 (with zones 09-16)

08 2nd 4229 (with zones 17-24)

09 3rd 4229 (with zones 25-32)

10 4th 4229 (with zones 33-40)

11 5th 4229 (with zones 41-48)

12 1st 4204

13 2nd 4204

14 3rd 4204

15 4th 4204

This is the actual (or physical) relay number with respect to the Relay Module upon which it is located. For 4204 modules, relay numbers are 1-4. For 4229 modules, relay numbers are 1-2. The system returns to the Output Number prompt for programming the next device.

6-2

*80 Menu Mode: Defining Output Functions

Use this mode to program up to 48 output definitions that provide automated control of any of the 18 output devices, based on events occurring on individual zones or zones with certain zone types. Each output definition is identified by an output function number, and includes the following components:

Output Definition Components

Component Description

Output Function No. A reference number from 01-48, which defines an output’s characteristics.

Activated By Determines whether the initiating event occurs on a zone, a zone list, or a zone type.

Event Event that triggers the output action. Can be an event occurring on a specific zone

Partition If the output is activated by zone type, this defines the partition in which the

Output Action Defines the action of the relay/X-10 device when the defined event occurs. Can close for 2

Output No. Assigns this function to a specific output number (01-18). This is the output number

For example, if you want to pulse a strobe light upon fire alarms on zone 4 using a relay mapped to output number 2 (as programmed in *79 Menu Mode), program the following in *80 Menu Mode:

Prompt Entry

Output Funct. # = 01 (assuming this is the first output function)

Activated By: = 3 (zone number)

Enter Zn No. = 04 (requires 2-digit zone numbers)

Output Action = 3 (continuous pulse)

Output Number = 02 (device mapped in *79 Menu Mode)

Start Output Definition mode by pressing ✱ prompts are displayed:

∗∗∗∗80 Menu Mode

PROMPT

Output Funct. # (00 = Quit) 01

01 A E P Trig ?00 0 0 – ZL=00

number or a zone list, or a specific zone type.

programmed event is to cause the device action.

seconds, stay closed until reset, continuously pulse (1-second close-open-close-open, etc.), toggle the device state, or activate for a defined duration (set in data field *177).

that will perform this function upon the triggering event. Note that each defined function is associated with only one output number. This means that if more than one output device needs to perform this particular function, you need to define another output function number with the same attributes, but assign the appropriate output number. (i.e. output devices can be assigned more than one function number, but each function number can only be assigned a single output number.

80 while in Data Programming mode. The following

VALID ENTRIES EXPLANATION

Output Function No.

01-48

[∗] to continue

Summary Screen

[∗] to continue

Enter the Output function number 01–48 (or 00 to exit) to be defined.

This screen displays a summary of the current output programming (for this example, Zone List has been selectedthis is the default screen).

A = Output Action; E = Triggering event; P = Partition; Trig = Trigger type

NOTE: A question mark in the summary screen indicates that the device number shown has not been mapped. Use *79 Menu mode to map the device.

6-3

3000EN Series: Installation Instructions

01 Activated By: Zone List

Activated By

0 = delete 1 = zone list 2 = zone type 3 = zone number [∗] to continue

“A”

01 Zn List 1

“B”

01 Enter Zn type Perimeter 03

Zone List

01-08 = zone list [∗] to continue

Zone Type

see list at right

Select where the initiating event for this output definition is to occur as follows: 0 = delete (deletes the output function and any previous

programming;-see prompt below) 1 = zone list (go to “A” prompt) 2 = zone type (go to “B” prompt) 3 = zone number (go to “C” prompt) If you enter “0,” the following prompt appears:

Delete? Press 1 to delete this 0 = NO, 1 = YES output definition.

If zone list was selected, this screen appears. Otherwise skip to the next row.

Enter the desired zone list associated with this output number. NOTE: Do not use pager zone lists 09-12 in output definitions. Press [✱] to continue.

Enter the zone list event that will activate this output.

Enter Event 0 = restore; 1 = alarm; Alarm 1 2 = fault; 3= trouble

NOTE: For alarm, fault, and trouble, an event on ANY zone in the list activates the output, but ALL zones in the list must be restored before the output is restored. Press [✱] to continue and skip to the “Output Action” prompt.

If zone type was selected, this screen appears. Otherwise skip to the next row. Enter the desired zone type associated with this output number. See below for a list of available zone types.

CHOICES FOR ZONE TYPES:

00 = Not Used 05 = Trouble Day/Alarm Night 14 = Carbon Monoxide†† 01 = Ent/Exit #1 06 = 24 Hr Silent 16 = Fire w/verification 02 = Ent/Exit #2 07 = 24 Hr Audible 23 = No Alarm Response 03 = Perimeter 08 = 24 Hr Aux 24 = Silent Burglary 04 = Interior Follower 09 = Fire 25 = 24-Hr Non-Alarm 10 = Interior w/Delay 77 = Keyswitch Zone 12 = Monitor Zone 81 = AAV Monitor Zone 90-93 = Configurable

CHOICES FOR SYSTEM OPERATION:

20 = Arming–Stay 36 = **At Bell Timeout*** 58 = Duress 21 = Arming–Away 38 = Chime 60 = AAV 22 = Disarming 39 = Any Fire Alarm 61 = AVS/GSMV 31 = End of Exit Time 40 = Bypassing 62 = AVS/GSMV 32 = Start of Entry Time 41 = **AC Power Failure 66 = Function Key† 33 = Any Burglary Alarm 42 = **System Battery Low 67 = Bell Fail 43 = Comm. Failure 68 = Telco line cut 52 = Kissoff 78 = Keyswitch Red LED 54 = Fire Zone Reset 79 = Keyswitch Green LED

session begin § session end §

** Use 0 (Any) for Partition No. (P) entry. *** Or at Disarming, whichever occurs earlier. †

Use *57 Menu Mode to assign the function key (function “07”). †† when used with an output function, the carbon monoxide zone type activates upon CO alarms only. Does not activate for trouble condition

§ automatically set when appropriate AVS Quick Command performed

Note: In normal operation mode:

Code + # + 7 + NN Key Entry starts Device NN. Code + # + 8 + NN Key Entry stops Device NN.

Enter the partition in which this zone type will occur.

01 Partition 0 = any partition; 1 = partition 1; Any partition 0 2 = partition 2; 3 = common

Press [✱] to continue and skip to the “Output Action” prompt.

6-4

“C”

01 Enter Zn No. 12

01 Output Action Close for 2 sec 1

Enter Output No. R02 02

02 A E P TRIG R02 1 1 3 ZL=00

Zone Number

Output Action

0-6 = see list at right.

Output Number

01-18 = output number

Summary Screen

If zone number was selected, this screen appears. Enter the desired zone number associated with this output number. Press [✱] to continue. Enter the zone event that will activate this output.

01 Enter Event 0 = restore; 1 = alarm/fault/trouble

Restore 0

Press [✱] to continue to the “Output Action” prompt

Enter the desired device action as listed below. Press the [✱] key to continue. 0 = off 4 = Change Device State 1 = Close for 2 seconds 5 = Duration 1 (see data field *177) 2 = Stay Closed 6 = Duration 2 (see data field *177) 3 = Pulse one second ON, one second OFF)

Enter the device output number (programmed in *79 Menu Mode) you want associated with this output. Press [✱] to continue.

A summary screen appears showing the programmed settings.

Press [✱] to continue.

6-5

3000EN Series: Installation Instructions

6-6

SECTION 7

Zone Lists

(

∗∗∗∗

81 Menu Mode)

•••••••••••••••••••••••••••••••••••••••

About Zone Lists

Zone lists let you group individual zones for use with certain system actions. The following table shows the available zone lists and their purposes:

List No. Used for… Notes 1, 2 general purpose (GP) 3 chime-by-zone (see field *26 to enable option) 4 cross zones (see note at right) 5 night stay zones 6 dial delay disable or GP 7 unlimited reports or GP 8 general purpose 9 zones that activate Pager 1 10 zones that activate Pager 2 11 zones that activate Pager 3 12 zones that activate Pager 4

Zone List Programming

Zone List programming involves:

1. Selecting an appropriate zone list number;

2. Adding the desired zone numbers to be included in that list.

Start Zone List Program Mode by pressing ✱ prompts are displayed

*81 Menu Mode

PROMPT

Zone List No. (00 = Quit) 01

01 Enter Zn Num. (00 = Quit) 00

01 Del Zn List? 0 = No 1 = Yes 0

VALID ENTRIES EXPLANATION

Zone List Number

01-12 = zone list number [∗] to continue

Zone Number

01-64 = zone numbers

followed by [∗] to accept each zone

00 to continue

Deleting Zone Lists

0 = don’t delete list 1 = delete this zone list [∗] to continue

• Any list may include any or all of the system's zone

numbers.

• A zone list can be assigned to more than one output relay.

• Zone List 4: When creating zone list 4 for cross zoning,

include only zones assigned to zone types 3, 4, or 5. Do not include zones that have delays (entry/exit zones, interior w/delay) or 24-hour zones, as these zone types may produce unpredictable operation and may not function as intended. See field *85 for Cross Zone Timer option.

• Zone List 6: See field *50 for Dial Delay Disable option.

• Zone List 7: See field *93 for Unlimited Reports option.

while in Data Programming mode. The following

Enter the Zone List Number to program (or 00 to end these entries). Press [✱] to advance.

In the following displays, zone list 01 has been selected for programming.

Enter each zone number to add to the zone list, followed by pressing [✱] (example, 01✱, 02✱, 03✱). After all zones are entered, press 00 to continue.

IMPORTANT: Do not include fire zones in zone lists that are used to STOP device actions.

To delete the zone list, enter 1. All zones in the zone list will be deleted automatically and the system returns to the Zone List No. prompt.

To save the zone list, enter 0.

7-1

3000EN Series: Installation Instructions

01 Delete Zone? 0 = No 1 = Yes 0

Deleting a Zone

0 = don’t delete zones 1 = go to next prompt to

delete zones

01 Zn to Delete? (00 = Quit) 00

[∗] to continue

Delete the Zone

01-64 = zones to be deleted

from list followed by [∗] to accept each zone

00 to continue

To save the entire zone list, enter 0 and the system returns to the Zone List No. prompt.

To delete a zone or zones in a zone list enter 1 to continue.

Enter each zone to be deleted from the list, followed by [✱]. After all zones to be deleted are entered, enter 00 to return to the Zone List No. prompt so that another list can be programmed, if desired.

7-2

SECTION 8

Function Key Programming

(

∗∗∗∗

57 Menu Mode)

•••••••••••••••••••••••••••••••••••••••

About Function Key Programming

The system provides the ability to program each of the four touchpad function keys to perform one of 12 system operations. The end user can then activate the function by simply pressing and holding the programmed key for 2 seconds. Typical functions (listed below) include single-button arming, turning lights on/off, or single-button paging.

Programming Function Keys

Function key programming involves:

1. Assigning the function key number and partition;

2. Selecting the desired function for that key.

Start Function Key Programming mode by pressing ✱57 while in Data Programming mode. The following prompts are displayed:

PROMPT

Press Key to Pgm 0 = Quit 0

VALID ENTRIES EXPLANATION

Function Key

Press the desired function key, A-D.

[∗] to continue

Press the desired function key (A-D) you want to program. NOTE: A key programmed as a function key is no longer available to be used as an end-user macro key or panic key.

OFF

AWAY

STAY

321

Partition 1

Key "A" Func Zone 95 00

Partition Number

1 = partition 1 2 = partition 2 3 = common partition [∗] to continue

Define Key Function

00-12 = see list to right [∗] to continue Returns to key number prompt with the next function key letter displayed.

† System defaults to these function key settings.

†† if Night-Stay zones are listed in Zone List 5

INSTANT

READY

TEST

CODE

BYPASS

654

CHECK

987

keypad_keys-50-001-V0

Enter the partition in which the function key is active.

Enter the desired function for this key, 00 to 12, from the options listed. (00 selected for example display shown at left)

00† = For the Function key selected, functions are pre-defined:

If A selected = Zone 95 (emerg. key, same as [1] [∗] pair) If B selected = Zone 99 (emerg. key, same as [∗] [#] pair) If C selected = Zone 96 (emerg. key, same as [3] [#] pair) If D selected = Single-button paging

01 = Single-button paging

(sends a 999-9999 message to pager)

02 = Display time 03 = Arm AWAY

(reports as User 00 if closing reports are enabled)

04 = Arm STAY (reports as User 00 if closing reports are enabled) 05 = Arm NIGHT-STAY (reports as User 00 if closing reports enabled) 06 = Step Arming (arms STAY, then NIGHT-STAY 07 = Output Device control

operation type 66–function key in *80 Menu Mode)

08 = Communication Test 09 = Macro Key 1

(define macro by user code + [#] [6] [6] command)

(for device programmed as system

(sends Contact ID code 601)

††

, then AWAY)

10 = Macro Key 2 (define macro by user code + [#] [6] [6] command) 11 = Macro Key 3 (define macro by user code + [#] [6] [6] command) 12 = Macro Key 4 (define macro by user code + [#] [6] [6] command)

8-1

3000EN Series: Installation Instructions

8-2

SECTION 9

Alpha Descriptor Programming

(*82 Menu Mode)

•••••••••••••••••••••••••••••••••••••••

About Descriptor Programming

The system lets you assign zone descriptors for protection zones, touchpad panics, and RF receiver supervision faults. Each description can be composed of a combination of words (up to 3) selected from a vocabulary of 196 words stored in memory (see a following page). In addition, up to 10 installer-defined words can be added to those already in memory, plus 3 additional words can be assigned as partition descriptors. Thus, when an alarm or trouble occurs in a zone, an appropriate description for that zone's location can be displayed at the touchpad. Zone descriptors are recommended for systems using Custom English display touchpads, and are necessary if a 4286VIP Phone Module is used.

NOTE: You can enter zone descriptors when the zone is being defined in ✱56 Menu mode, but we recommend you do it using ✱82 Menu mode.

Programming Zone Descriptors (Menu Mode ∗∗∗∗82)

Descriptor programming involves:

1. Entering index numbers for up to three words from the vocabulary list for each descriptor;

2. Entering up to ten 10-digit custom words, if desired, which can then be used in descriptors.

When defining descriptors:

• Pressing the [6] key accepts the entered index number and moves the cursor to the next position

• Pressing the [8] key saves the entered descriptor and moves to the next descriptor.

Start Zone Descriptor Programming mode by pressing *82 while in Data Programming mode. The following prompts are displayed:

PROMPT

Program Alpha ? 0=No, 1=Yes 00

Custom Words ? 0=No, 1=Yes 00

✱

ZN 01

If using a 4286VIP Phone Module, select from those words in the Alpha Vocabulary List shown in boldface type. The phone module will not provide annunciation of the other words.

If a 4286 Phone Module is added to an existing system, the Alpha descriptors presently in the system should be reprogrammed, selecting from those words shown in boldface type in the Alpha Vocabular The phone module will not provide annunciation of any other words.

for a descriptor.

VALID ENTRIES EXPLANATION

Program Alpha

0 = no 1 = yes [∗] to continue

Custom Words

0 = no 1 = yes [∗] to continue

Summary Screen

[∗] to continue

The “Program Alpha ?” prompt will appear. Press 1 to continue.

The “Custom Words” prompt will appear. Press 0 to program standard alpha descriptors from the fixed vocabulary. The system will then automatically display the descriptor for zone 1. Press 1 to define custom words (described later in “Adding Custom Words” section).

Note that this is a “Summary mode,” and that no entries can be made. Entries can be made only when the display contains a flashing cursor, which signifies the “Entry mode.” Press [∗] to continue.

List.

9-1

3000EN Series: Installation Instructions

✱

ZN 01

✱

ZN 01 B ACK

✱

ZN 01 BACK

Flashing Cursor

[∗] to continue

First 3-Digit Index No.

see index for entries

[∗] to continue

Accept First Word

6 = save word and go to

next word in this descriptor

8 = save word and end

descriptor- go to next

✱ ZN 01 BACK

D OOR

✱ ZN 01 BACK

DOOR

zone

Second 3-Digit Index No.

see index for entries

[∗] to continue

Accept Second Word

6 = save word and go to last

word in this descriptor 8 = save word and end descriptor- go to next zone

✱ ZN 01 BACK

DOOR

Summary Screen

[∗] to continue

To delete or change the default descriptor for zone 1, press [∗] plus the same zone number (01). This will clear that descriptor and allow changes to be made at the flashing cursor.

NOTE: If you do not wish to change the existing descriptor for zone 1, enter [∗] plus the next zone number for which you wish to enter (or check) a descriptor. A summary display for that zone will appear. You must then press [∗] plus the same zone number again to gain access to the entry mode (flashing cursor) for that zone.

Press [#] plus the 3-digit number for the first word from the Alpha Vocabulary List. Example: The descriptor that we wish to enter for zone 1 is BACK DOOR. From the list, BACK =

013. Therefore, you would enter #013.

Note: If you accidentally enter the wrong word, simply press [#] plus the correct 3-digit number for the word you want.

Press [6] to accept the selected word and continue to the next word.

NOTE: If this is the only word you are using for the descriptor, press [8] instead of [6] to save that word in memory.

Enter the 3-digit number for the next word. In our example, the word is DOOR, whose number is “057.”

Enter # 0 5 7.

Press [6] to accept the selected word. NOTE: If these are the only words you are using for the

descriptor, press [8] instead of [6] to save them in memory. The two words in our example have now been entered. Note, however, that up to three words may be entered (provided the number of characters will fit on the screen).

Press [8] to save all words in memory.

The flashing cursor will disappear, indicating that the word(s) are stored in memory for that zone, as shown in the summary display at the left. To enter a descriptor for the next zone, press [

✱]

plus the desired zone number (e.g., ✱02). The summary display will appear. Now repeat the previous steps to enter the descriptor for the next zone. To exit the Alpha descriptor mode, press ✱ + 0 + 0 at the summary display.

9-2

Adding Custom Words (will not be annunciated by 4286 Phone Module)

You can add up to 10 installer-defined words to the built-in vocabulary, which can then be used when programming zone descriptors. Each of the 10 words can actually consist of a word string of one or more words, but no more than ten characters can be used for each word or word string.

When adding custom words, the touchpad keys perform the following functions:

[4] Moves cursor one space to the left.

[6] Moves cursor one space to the right.

[8] Saves the new word in the system's memory.

1. Select Custom Word mode (enter 1) when the prompt “CUSTOM WORD ?” is displayed.

2. Enter the number (01–10†) of the custom word or word string to be created, corresponding to index numbers 245 - 254 respectively (for example, if you are creating the first custom word or wordstring, enter 01, for the second, enter 02, etc.). A cursor will now appear at the beginning of the second line.

NOTE: Custom words 8, 9, and 10 are reminder words that can be programmed to display using

Scheduling mode.

† or 11, 12, 13 for partition 1, partition 2 and common partition descriptors respectively. See

Assigning Partition Descriptors paragraph below.

3. Refer to the Character List of letters, numbers, and symbols on a following page.

Press [#], followed by the two-digit entry for the first letter you would like to display

(e.g., # 6 5 for “A”).

The cursor will then move to the right, in position for the next character.

4. Repeat Step 3 to create the desired word(s). Note that the “4” key can be used to move the cursor

to the left, if necessary. Remember, no word or word-string can exceed 10 characters.

5. Press the [8] key to save the custom word(s) and return to the “CUSTOM WORD ?” display.

Repeat Steps 2–5 for other custom words to be entered. To change a custom word, just overwrite

it. If no more are to be entered now, press [0] to return to the Descriptor entry. The custom word(s) will be automatically added to the built-in vocabulary.

Assigning Partition Descriptors

You can assign a partition descriptor (up to 16 characters) for each partition plus the common lobby.

Use the same procedure as for adding custom words (described above), but use the following word numbers in step 2: 11 = partition 1 ___________________________________________ 12 = partition 2 ___________________________________________ 13 = common lobby ________________________________________

To delete a character, simply enter the SPACE character (#32).

Once a custom word is entered in any of these word locations (11-13), the system will display the appropriate partition’s word instead of the normal “DISARMED READY TO ARM” message.

9-3

Installation Instructions

ALPHA VOCABULARY LIST (For Entering Zone Descriptors)

000

– A –

• 001 AIR

• 002 ALARM

004 ALLEY 005 AMBUSH

• 006 AREA

• 007 APARTMENT

• 009 ATTIC

010 AUDIO

– B –

• 012 BABY

• 013 BACK

• 014 BAR

• 016 BASEMENT

• 017 BATHROOM

• 018 BED

• 019 BEDROOM

020 BELL

• 021 BLOWER

• 022 BOILER

023 BOTTOM 025 BREAK

• 026 BUILDING

028 CABINET

• 029 CALL 030 CAMERA 031 CAR 033 CASH 034 CCTV 035 CEILING 036 CELLAR

• 037 CENTRAL

038 CIRCUIT

• 040 CLOSED

• 046 COMPUTER

047 CONTACT

– D –

• 048 DAUGHTERS

049 DELAYED

• 050 DEN

051 DESK

• 052 DETECTOR

• 053 DINING

054 DISCRIMINATOR 055 DISPLAY

• 057 DOOR

• 059 DOWN

• 060 DOWNSTAIRS

Note: Bulleted (•) words in boldface type are those that are also available for use by the 4286 Phone Module. If using a phone

Italicized words followed by an asterisk indicate those words supported by the 6160VADT Voice Touchpads

32 (space) 33 ! 34 “ 35 # 36 $ 37 %

(Word Space)

– C –

061 DRAWER

• 062 DRIVEWAY

• 064 DUCT

∗∗∗∗

– E –

• 065 EAST

066 ELECTRIC

067 EMERGENCY

068 ENTRY

∗∗∗∗

• 069 EQUIPMENT

• 071 EXIT

∗∗∗∗

072 EXTERIOR

∗∗∗∗ ∗∗∗∗

– F –

• 073 FACTORY

075 FAMILY

• 076 FATHERS

∗∗∗∗

• 077 FENCE

∗∗∗∗

• 079 FIRE

• 080 FLOOR

∗∗∗∗

081 FLOW

∗∗∗∗

082 FOIL

• 083 FOYER

084 FREEZER

• 085 FRONT

∗∗∗∗

– G –

• 089 GARAGE

∗∗∗∗

• 090 GAS

091 GATE

• 092 GLASS

093 GUEST 094 GUN

– H –

• 095 HALL

∗∗∗∗

• 096 HEAT

098 HOLDUP

099 HOUSE

∗∗∗∗

100 INFRARED

• 101 INSIDE

∗∗∗∗

102 INTERIOR 103 INTRUSION

– J –

104 JEWELRY

∗∗∗∗

– K –

• 105 KITCHEN

∗∗∗∗

L –

• 106 LAUNDRY

∗∗∗∗

• 107 LEFT

108 LEVEL

∗∗∗∗

• 109 LIBRARY

∗∗∗∗

• 110 LIGHT

111 LINE

• 113 LIVING

• 114 LOADING

115 LOCK 116 LOOP 117 LOW

• 118 LOWER

– M –

∗∗∗∗

• 119 MACHINE

121 MAIDS

122 MAIN

• 123 MASTER

• 125 MEDICAL

126 MEDICINE 128 MONEY 129 MONITOR

• 130 MOTHERS

• 131 MOTION

132 MOTOR

– N –

• 134 NORTH

135 NURSERY

– O –

• 136 OFFICE

• 138 OPEN

139 OPENING

• 140 OUTSIDE

142 OVERHEAD

– P –

143 PAINTING

• 144 PANIC

145 PASSIVE

• 146 PATIO

147 PERIMETER

• 148 PHONE 150 POINT

151 POLICE 152 POOL

• 153 POWER

– R – 155 RADIO

• 156 REAR

157 RECREATION 159 REFRIGERATION

–

160 RF

• 161 RIGHT

∗∗∗∗

• 162 ROOM

163 ROOF

– S –

164 SAFE 165 SCREEN

∗∗∗∗

166 SENSOR

• 167 SERVICE

• 168 SHED

169 SHOCK

• 170 SHOP

171 SHORT

• 173 SIDE

174 SKYLIGHT

175 SLIDING

• 176 SMOKE

• 178 SONS

• 179 SOUTH

∗∗∗∗

180 SPRINKLER

• 182 STATION 184 STORE

• 185 STORAGE

186 STORY

190 SUPERVISED

191 SUPERVISION 192 SWIMMING 193 SWITCH

– T –

194 TAMPER 196 TELCO 197 TELEPHONE

• 199 TEMPERATURE

200 THERMOSTAT

• 201 TOOL

202 TRANSMITTER

– U –

• 205 UP

• 206 UPPER

• 207 UPSTAIRS

• 208 UTILITY

– V –

209 VALVE 210 VAULT 212 VOLTAGE

– W –

213 WALL 214 WAREHOUSE

• 216 WEST

• 217 WINDOW

• 219 WING

220 WIRELESS

– X –

222 XMITTER

– Y –

223 YARD

– Z –

∗∗∗∗

224 ZONE (No.)

• 225 ZONE

• 226 0

• 227 1

• 228 1ST

• 229 2

• 230 2ND

• 231 3

• 232 3RD

• 233 4

• 234 4TH

• 235 5

• 236 5TH

• 237 6

• 238 6TH

• 239 7

∗∗∗∗

• 240 7TH

• 241 8

• 242 8TH

∗∗∗∗

• 243 9

• 244 9TH

245 Custom Word #1

________________

246 Custom Word #2

________________

247 Custom Word #3

________________

248 Custom Word #4

________________

249 Custom Word #5

________________

250 Custom Word #6

∗∗∗∗

________________

251 Custom Word #7

________________

252 Custom Word #8

________________

253 Custom Word #9

________________

254 Custom Word #10

________________

NOTE: Custom words 8, 9, 10 are “reminder words” that can be programmed to display using Scheduling Mode.

module, and words other than these are selected for Alpha descriptors, the phone module will not provide annunciation of those words.

––––––––––––––– CHARACTER (ASCII) CHART

38 & 39 ' 40 ( 41 ) 42 * 43 +

44 , 45 – 46 . 47 / 48 0 49 1

50 2 51 3 52 4 53 5 54 6 55 7

56 8 57 9 58 : 59 ; 60 < 61 =

(For Adding Custom Words)––––––––––––––––––

62 > 63 ? 64 @ 65 A 66 B 67 C

68 D 69 E 70 F 71 G 72 H 73 I

74 J 75 K 76 L 77 M 78 N 79 O

80 P 81 Q 82 R 83 S 84 T 85 U

∗∗∗∗

86 V 87 W 88 X 89 Y 90 Z

9-4

SECTION 10

Creating Schedules

•••••••••••••••••••••••••••••••••••••••

About Schedules

The system provides up to 32 schedules, which can be used to control up to 12 types of system events at pre-defined times. Sixteen schedules are intended for use by the end-user, and sixteen are reserved for the installer. In addition, some events are reserved for the installer only (see “Enter Event” prompt).

NOTES:

• The master code can only access schedules 01-16 and events 00-07.

• System clock must be set before programming schedules.

• Programmed schedules do not take effect until the next scheduled “start” time. (e.g., if programming

a schedule time window for 8AM to 5PM, the schedule does not take effect until 8AM after the schedule has been programmed.)

Start Scheduling mode by entering installer code + [#] + [6] [4] while in normal operating mode.

PROMPT

ENTER SCHED NO. 00=QUIT 00

ENTER EVENT

NOTE: Events 07 and 10 cause the touchpad to beep every 30 seconds when messages are displayed. Stop the beeps by pressing any key.

DEVICE NUMBER XX

GROUP NUMBER X

PARTITION X

VALID ENTRIES EXPLANATION

Schedule Number

01-16 = end-user schedules 17-32 = installer-only

Schedule numbers 01-16 can be programmed and changed by the end user or installer. Schedules 17-32 can only be programmed or changed by the installer.

schedules [∗] to continue

Enter Event

00 = clear event 01 = Relay On/Off 02 = User Access 03 = Latch Key Report to Pager

04 = Forced Stay Arming† 05 = Forced Away Arming†

06 = Auto Disarm 07 = Display “Reminder”

10 = Display custom words 11 = Periodic Test Report 12 = Up and About

[∗] to continue

Enter the desired event number for event you want to occur at a specified time. Events 10-12 are reserved for the installer only.

Latch key report (option 03) is sent to all pagers in the user’s partition and is active only when the system is armed (message sent is 777-7777). User must be enabled for paging (see User Attributes in System Operation section).

† Forced bypass must be enabled in field *23. †† if selected, system displays custom words 8, 9, and 10 at

defined time. Can be used as installer’s reminder message to

††

the end user.

†††

††††

††† See key commands in Test Report Code data field *64 section to quickly set periodic test reporting intervals.

††††This selection defines the large time window within which the time window selected in data field *175 will be monitored.

Device Number

01-18 = device number

[∗] to continue

This prompt appears if event “01” (relay on/off) was selected, otherwise it is skipped. Enter the physical device number as programmed in ∗79 Menu Mode, then press [*] to continue to the “Start” prompt. Device numbers 17 and 18 designate built-in triggers 1 and 2 respectively.

Group Number

1-8 = group number

This prompt appears if event “02” (user access) was selected. Otherwise it is skipped. Press [*] to continue to the “Start” prompt.

[∗] to continue

Partition

0 = all partitions 1 = partition 1

This prompt appears if events “03-07,10,12” were selected. Otherwise it is skipped. Press [*] to continue to the “Start” prompt.

2 = partition 2 3 = common

[∗] to continue

10-1

3000EN Series: Installation Instructions

START SMTWTFS

HH MMAM 0010000

STOP SMTWTFS

HH MMAM 0010000

REPEAT OPTION

0-4 X

RANDOMIZE

0=NO 1=YES X

Start Time

01-12 = hour 00-59 = minute 0 = AM; 1 = PM Days = place “1” under days [∗] to continue

Stop Time

01-12 = hour 00-59 = minute 0 = AM; 1 = PM Days = place “1” under days

[∗] to continue

Repeat Option

0 = do not repeat 1 = repeat schedule weekly 2 = repeat schedule

biweekly (every other week)

3 = repeat schedule every

third week

4 = repeat schedule every

fourth week

[∗] to continue

Randomize

0 = no 1 = yes

[∗] to continue

Enter the event’s start time and days of the week to occur. To select days, position the cursor under the desired days using the [∗] key to move forward, then press “1” to select the day.

This prompt appears if event “01” (relay on/off), 02 (user access), or 03 (latch key report) was selected. Otherwise it is skipped. Enter the event’s stop time and days of the week to occur. To select days, position the cursor under the desired days using the [∗] key to move forward, then press “1” to select the day. This entry applies only to the following events: 1 (relay on/off) 2 (user access) 3 (latch key report) 12 (up and about)

Enter the desired repeat option for this schedule. e.g., To make a schedule that happens everyday you would select all days with a repeat count of 1. To make a schedule that runs for one week then stops, select everyday with a repeat count of 0.

This prompt appears if event “01” (relay on/off) or 11 (test report) was selected. Otherwise it is skipped. If selected, the scheduled start and stop times will vary within 60 minutes of the “hour” time. For example, if a schedule is set to start at 6:15pm, it will do so the first time 6:15pm arrives, but on subsequent days it will start anytime between 6:00 and 6:59 p.m.

NOTE: Do not use the random option if the start and stop times are within the same “hour” setting, otherwise unpredictable results may occur (e.g., the randomized stop time may occur before the start time).

10-2

SECTION 11

∗∗∗∗

29 IP/GSM Menu Mode

•••••••••••••••••••••••••••••••••••••••

∗∗∗∗29 Communication Device Menu Mode (Pass-Through Programming)

This mode is for programming an IP, GSM, or IP/GSM Communicator Module using a touchpad. Alternatively, these options can be programmed via the AlarmNet Direct website. After programming is complete, the module must be registered with AlarmNet before reporting via the communication device can occur. Refer to the device’s instructions for registration procedures.

NOTE: The module must be set to device address 3.

IMPORTANT: The use of an IP/GSM Communicator

Module requires an AlarmNet–I account. Please obtain the account information from the central station prior to programming this module.

Using a Custom English Touchpad as a 7720P Programming Tool

When programming with ∗29 menu mode, the touchpad mimics the functions of the 7720P Programming Tool. See figure to right and table below for 7720P key functions. Each key has two possible functions: a normal function and a SHIFT function.

Normal functions: The numeric values labeled

directly on the keys and the left-hand functions

ARMED

READY

SHIFT

FUNCTION

WHEN LIT

(A)

(B)

(C)

(D)

BS/ESC

N / Y

SHIFT

OFF

INSTANT

READY

SPACE

AWAY

STAY

BYPASS

TEST

CODE

CHIME

ENTER

shown in diagram on the ABC keys. To perform a normal key function, simply press the desired key.

SHIFT functions: Those functions shown in

diagram above the numerical keys and the right-hand

7720P Emulation Template for Custom English Touchpads

SW4000-012-V0

functions shown on the ABC keys. To perform a SHIFT key function, press SHIFT key (D key), then press the desired function key (shift function is indicated by the lit READY LED).

∗∗∗∗29 IP/GSM Program Mode Procedure

Press ∗29 while in Data Field Programming mode. The following prompts appear.

ENABLE IP/GSM? 0=No, 1=Yes

Enable IP/GSM?

0 = no, not using IP or GSM; 1 = yes using IP and/or

GSM module

[∗] to continue

1=PROG 2=DIAG 0=QUIT

Programming / Diagnostics Select

1= Prog (program the

IP/GSM options)

2 = Diag (enter diagnostic

mode)

0 = Quit; returns to data

field program mode

If using a communication device, enter 1 at this prompt and enter 1-Prog at the next prompt to program the device. Use the communication device’s Installation Guide for details of the device’s programming prompts and instructions for registration. [Default = 0 (no IP and/or GSM)]

Select whether you want to program the communication device or enter the device’s diagnostic mode.

Diagnostic Mode Note: Diagnostic mode option available only for communicators with firmware version 2.4.16 or higher.

11-1

Normal and SHIFT key Functions While in ∗∗∗∗29 Menu Mode

Key Normal Key Function SHIFT Key Function (A) = BS/ESC [BS]: Press to delete entry [ESC]: Press to quit Program Mode

(B) = ↓/↑ [↓]: Scroll down programming [↑]: Scroll up programming (C) = N/Y [N]: Press for "NO" answer [Y]: Press SHIFT-Y for "YES" answer (D) = SHIFT Press before pressing a SHIFT key function. Will light READY LED. LED goes out once a key is

1/A [1]: For entering the number 1 [A]: Used for entering C.S. ID number 2/B [2]: For entering the number 2 [B]: Used for entering C.S. ID number 3/C [3]: For entering the number 3 [C]: Used for entering C.S. ID number 4/D [4]: For entering the number 4 [D]: Used for entering C.S. ID number 5/E [5]: For entering the number 5 [E]: Used for entering C.S. ID number 6/F [6]: For entering the number 6 [F]: Used for entering C.S. ID number 7/S [7]: For entering the number 7 [S]: Press to display diagnostic status 8/T [8]: For entering the number 8 [T]: Press to send TEST messages 9/X [9]: For entering the number 9 [X]: Press to reset the IP/GSM [∗] / SPACE [∗]: Used to select programming options 0 [0]: For entering the number 0 [#] / ENTER [#] / ENTER: Press to accept entries No SHIFT function

† Active only when the "REVIEW ?" prompt is displayed

Also, can reset EEPROM defaults †

pressed. Press again for each SHIFT function desired.

[SPACE]: Not used

11-2

SECTION 12

AVS System Enable and

Quick Program Commands

•••••••••••••••••••••••••••••••••••••••

AVS Command Procedure

Applies to an AVS system using an ECP connection to the control.

1. Install the AVS module according to its instructions.

2. Use one of the control’s AVS Quick Program commands as follows (see Quick Program Command Results below for results of each command):

• installer code + [#] + [0] + 3: enable AVS operation without panel sounds on the AVST speaker

• installer code + [#] + [0] + 4: enable AVS operation and enable panel sounds on the AVST speaker

3. Use data field ∗55 Dynamic Signaling Priority to select the desired reporting paths (phone line and/or GSMV) and path for AAV communication.

4. To undo the Quick Command programming, use the following commands:

• installer code + [#] + [0] + 5: remove all programming options set by [#] +

• installer code + [#] + [0] + 6: remove all programming options set by [#] +

Quick Program Command Results

When either the #03 or #04 Quick Program command is used, the following are automatically programmed and no longer available for other control panel purposes.

Pre-Programmed #03 Command #04 Command

Output Function No. (∗80 mode)

Output Relay No. (∗79 mode)

Protection Zone (∗56/∗58 mode) Device Address address 11 (AVS module) Same as #03 command Data Field ∗91

46 (zone type 60, relay 15) 47 (zone type 61, relay 16) 48 (zone type 62, relay 16)

15 (addr 11, relay pos 2) 16 (addr 11, relay pos 1)

4229 zn 48 (zt 81, addr 11) Same as #03 command

AAV enabled AAV enabled

Same as #03 plus: 41 (zone type 14, relay 13) 42 (zone type 22, relay 13) 43 (zone type 39, relay 14) 44 (zone type 33, relay 14) 45 (zone type 36, relay 14) Same as #03 plus: 13 (addr 11, relay pos 4) 14 (addr 11, relay pos 3)

[0] + 3 quick command [0] + 4 quick command

12-1

3000EN Series: Installation Instructions

12-2

SECTION 13

System Communication

•••••••••••••••••••••••••••••••••••••••

Report Code Format (Ademco Contact ID)

Format Handshake Transmits Data Kissoff Transmit Time

The Ademco Contact ID Reporting Format comprises the following:

4- or 10-digit subscriber number.

1-digit event qualifier (“new” or “restore”).

3-digit event code.

2-digit Partition No.

3-digit zone number, user number, or system status number (see the following page).

Ademco Contact ID Reporting takes the following format:

Contact ID 1400–2300Hz DTMF (10 cps) 1400Hz Under 3 secs.

CCCC(CCCCCC) Q EEE GG ZZZ

where:

CCCC(CCCCCC) = Customer (subscriber) ID (4 or 10 digits depending on format

selected)

Q = Event qualifier, where: E = new event , and R = restore

EEE = Event code (3 hexadecimal digits) Note: For a complete list of event codes, refer to the central office receiver

manual.

GG = Partition Number (system messages show “00”)

ZZZ = Zone/contact ID number reporting the alarm, or user number for open/close reports.

System status messages (AC Loss, Walk Test, etc.) contain zeroes

in the ZZZ location.

13-1

3000EN Series: Installation Instructions

TABLE OF CONTACT ID EVENT CODES

Code Definition

110 Fire Alarm

121 Duress

122 Alarm, 24-hour Silent

123 Alarm, 24-hour Audible

131 Alarm, Perimeter

132 Alarm, Interior

134 Alarm, Entry/Exit

135 Alarm, Day/Night

143 Alarm, Expansion Module

145 ECP Module cover tamper

146 Silent Burglary

150 Alarm, 24-Hour Auxiliary/Monitor zone

162 Carbon Monoxide

163 Tank Level

301 AC Power

302 Low System Battery/Battery Test Fail

305

309 Battery Test Failure

321 Bell/Siren Trouble

333 Trouble, Expansion Mod. Supervision

341 Trouble, ECP Cover Tamper

344 RF Receiver Jam

351 Telco Line Fault

353 Long Range Radio Trouble

373 Fire Loop Trouble

374 Exit Error Alarm

380 Global Trouble, Trouble Day/Night

† Canadian panels log and report this code.

System Reset (Log only

Code Definition

381 RF Sensor Supervision

382 Supervision Auxiliary Wire Zone

383 RF Sensor Tamper

384 RF Sensor Low-battery

401 Disarmed, Armed AWAY

403 Schedule Arm/Disarm AWAY

406 Cancel by User

407 Remote Arm/Disarm (Downloading)

408 Quick Arm AWAY

409 Keyswitch Arm/Disarm AWAY

441 Disarmed/Armed STAY/INSTANT,

Quick-Arm STAY/INSTANT

442 Keyswitch Arm/Disarm STAY

455 Scheduled Arm Fail

459 Recent Closing

570 Bypass

†

)

601 Manually Triggered Dialer Test

602 Periodic Test

606 AAV to Follow

607 Walk Test Entered/Exited

623 Event Log 80% Full

625 Real-Time Clock was Changed (log only)

627 Program Mode Entry (log only)

628 Program Mode Exit (log only)

641 Up and About (senior watch)

642 Latchkey (log only)

654 Lack of Usage

750 789

Reserved for Configurable Zone Type report codes (check with central station when using these codes)

13-2

Section 22. System Communication

Uploading/Downloading via the Internet

This control, when used with a compatible Internet/Intranet Communication Device, supports upload/download programming capability via the Internet using the AlarmNet network or, depending on the communication module used, a Private local area network (Intranet). This allows site maintenance independent of central station monitoring, and modification to sites globally via the Internet or through a private LAN.

Refer to the instructions provided with the communication module for information regarding its installation, programming, and registration. The System Requirements table below lists two sets of system requirements, depending upon whether you intend to communicate over the Internet or whether you are communicating over a Private LAN (Intranet).

Compatible Communication Modules: The following modules support Internet uploading/downloading, but future modules may also provide Internet upload/download support;

System Requirements

Internet Communication

At the Installation Site:

• Appropriate Internet Communication Module

• 7720P Programmer

• Broadband Internet Access (for wired modules)

• Broadband (Cable/DSL) Modem (for wired modules)

• Broadband (Cable/DSL) Router (for wired modules if

• IP compatible Control Panel

At the Downloading Office:

• Broadband Internet Access

• Broadband (Cable/DSL) Modem

• Broadband (Cable/DSL) Router (optional, if connecting

• Computer running Compass Downloading Software

refer to the module’s instructions for compatibility. Compatible Modules: 7845i-ent, 7845GSMADT

connecting more than one device to the Internet)

more than one device to the Internet)

version that supports Internet upload/download for this control.

To set up the control panel, do the following:

1. Connect the module to the control panel’s ECP (touchpad) terminals.

2. Internet Users: For wired modules, connect the module to the Internet via a cable/DSL modem and router.

Intranet Users: Connect the module to the Intranet (LAN) via the appropriate Ethernet

connection.

3. Enable the module in the control panel (using •29 Menu mode) to enable alarm reporting and module supervision.

4. Using the module’s programming menus (via •29 Menu mode or 7720P programmer), program the communication device module for address 3 and program the module’s other options as required.

5. Register the module with AlarmNet. The module must be registered before downloading or alarm reporting can take place.

To perform upload/download functions:

1. Connect the computer to the Internet and start the Compass downloading software.

2. Open the control’s account, then select the Communications function and click the Connect button.

3. At the Connect screen, check that the control’s MAC address is entered and the TCP/IP checkbox is checked.

4. Click Connect. The Internet connection to the control is made automatically via AlarmNet.

5. Once connected, use the Compass downloading software as normal to perform upload/download functions.

Intranet (Private LAN) Communication, if applicable* At the Installation Site:

• Internet/Intranet Communication Module

• 7720P Programmer

• Ethernet Network Connection

• IP compatible Control Panel

At the Downloading Office:

• 7810iR-ent IP Receiver

• Internal Router

• Computer(s) running the following software:

- Compass Downloading Software version that supports IP upload/download for this control.

- Compass Connect Data Server Application

- Compass Connect Control Server Application

* see module’s instructions for applicability for LAN usage (ex. 7845i-ent supports LAN)

NOTE: Compass, the Compass Connect Data Server, and the Compass Connect Control Server applications may all be installed on the same computer if desired. If they are installed on one computer, the computer must have a fixed IP Address.

13-3

13-4

SECTION 14

System Operation

•••••••••••••••••••••••••••••••••••••••

Security Codes

The system supports up to 48 security codes, which can each be assigned one of 5 authority levels. The authority level determines the functions a particular user code can perform as follows:

Authority Levels (authority levels can be assigned to users 3-49 only; users 1 and 2 cannot be changed)

Level User No. Functions Installer 01 (default=6321) perform all security functions except can disarm only if used

to arm; can enter program mode; can change System Master code; cannot assign any other user codes

System Master

Partition Master (default)

0-User 03-49 perform security functions (arm, disarm, etc.) only; cannot add/delete users,

1-Arm Only

2-Guest 03-49 can disarm the system only if it was used to arm the system 3-Duress 03-49 performs security functions, but also silently sends a duress message to the

4-Partition Master

02 (default 1234) only one system master code per system; can perform all

security functions, can add/delete all users in either partition, can change system master code, view event log, set system clock, program touchpad

macro, program scheduled events, activate output devices (triggers/relays) P1 = 03 P2 = 33

03-49 arm system only

03-49 see Partition Master paragraph above; used to assign other user numbers

same as Master, except add/delete users limited to assigned partition only,

(these users can be assigned different authority levels, if desired; any user

can be assigned the partition master authority level)

view event log, set system clock or program scheduled events

central station; reports as duress code user number

as partition masters

14-1

3000EN Series: Installation Instructions

Adding/Deleting Security Codes and Changing User Attributes

The following lists the various command strings for adding user codes and attributes.

NOTE: Partition Master codes apply only to those user numbers assigned to the

partition master’s partition (default: users 03-32 = partition 1; users 33-49 = part. 2)

Changing the System Master code...

Using Installer code:

Using System Master code: current System Master code + [8] + 02 + new code + new code again

Add User Code:

(

Users 03/33 are preset

to partition masters,

but can be changed.)

Delete User Code:

The user code and all attributes* programmed for this user number,

Authority Level:

Factory Assignments: Authority Levels (see definitions on previous page): users 04-32/34-49 = 0 0 = standard user 3 = duress users 03/33 = 4 1 = arm only 4 = partition master 2 = guest

Access Group:

Factory Assignments: none You can assign users to a group, then set an access schedule that

User’s Partition:

Factory Assignments: This command assigns the partitions the user can access. If more tha Part. 1 = users 03-32 one, enter partition numbers sequentially, then press [#] to end. Part. 2 = users 33-49 E.g., master code + [8] + [user no.] + [#] [3] + [0] + [1] [2] + [#] gives

Partition Entries: 1 = partition 1 and common 2 = partition 2 and common 3 = common partition only

RF User Number:

Factory Assignments: none Use this command to assign a wireless button device (keyfob) to this

Zone number: enter the zone number assigned to a button on the

Pager On/Off: Factory Assignments: You can program a user so that a message is sent to a pager

users 01-04 = 0 (off) whenever this code is used to arm or disarm the system. users 05-49 = 1 (on) Paging On/Off: 1 = allow paging; 0 = no paging for this user

User 01 = installer User 03 = partition 1 master

The Touchpad beeps once to confirm that new user was added.

Installer code + [8] + 02 + new system master code

System/Partition Master code + [8] + user no. + new user’s code

User 02 = master User 33 = partition 2 master

System/Partition Master code + [8] + [user no.] + [#] [0]

including any associated RF keys, are erased from the system. (*except assigned partition)

System/Partition Master code + [8] + [user no.] + [#] [1]+ auth. level

System/Partition Master Code + [8] + [user no.] + [#] [2]+ group (1-8)

defines the times this group of users can operate the system. The system ignores these users outside the scheduled times.

System Master Code + [8] + [user no.] + [#] [3]+ 0 + partition(s) + [#]

the user access to partitions 1 and 2 and the common partition.

System/Partition Master Code + [8] + [user no.] + [#] [4]+ zone no.

user (keyfob must be enrolled in system first; see Wireless Key Programming Templates section, page 5-6).

keyfob that will be used for arming/disarming by this user.

System/Partition Master Code + [8] + [user no.] + [#] [5] + 0 or 1

14-2

Touchpad Functions

The following is a brief list of system commands. For detailed information concerning system functions, refer to the User's Manual. For AUI users, refer to the separate AUI User’s Guide

Voice Touchpads

The 6160VADT Voice Touchpads provide the following voice features:

• Message Center, which lets the user record and playback one message.

• Voice Status, which can announce system status by using the STATUS key.

• Voice Chime, which can alert users to the opening of doors and windows while the system is disarmed.

Refer to the User Guide for specific procedures for activating and using these features.

Touchpad Commands

Function Description

Silence Burglary Alarms Silence Fire or Carbon Monoxide Alarms

Quick Arm

Single-Button arming If programmed (*57 Function Key menu mode), lettered keys A-D can be used for arming,

Alarm Memory When the system is disarmed, any zones that were in an alarm condition during the armed

Arming Away Enter code + AWAY [2] or simply press appropriate lettered key on the touchpads (see

Arming Stay Enter code + STAY [3] or simply press appropriate key on the touchpads (see “Single-

Arming Night-Stay Enter code + STAY [3] + STAY [3] or simply press appropriate key on the touchpads (see

Arming Instant Enter code + INSTANT [7]. Disarming Enter code + OFF [1]. If entry delay or an alarm is active, you do not need to press OFF. Bypassing Zones Enter code + BYPASS [6] + zone number(s). Forced (Quick) Bypass To automatically bypass all faulted zones, use the “Quick Bypass” method. Enter code +

Chime Mode Enter code + CHIME [9]. To turn chime off, enter code + CHIME again. Activate Output Devices

Pressing any key will silence the touchpad sounder for 10 seconds. Disarming the system (security code + OFF) silences both touchpad and external sounders. Press the OFF [1] key to silence the touchpad sounder and, for fire alarms, the external sounder. The detector sounding stops when the contaminated air is cleared from the detector; see the detector’s instructions for further information. If enabled (field ∗21), you can press [#] in place of the system's security code, plus the desired arming key (Away, Stay, Instant)

using options 3-AWAY, 4-STAY, 5-NIGHT-STAY, or 6-Step-Arming If used, no security code is required to arm the system.

period will be displayed. To clear this display, simply repeat the disarm sequence (enter the security code and press the OFF key) again.

“Single-Button Arming” above). If the “Auto-Stay Arm” feature is enabled (field *84) and the entry/exit door is not opened and closed within the programmed exit delay time, the system will automatically arm in STAY mode if armed from a wired touchpad (non-RF device). If the door is opened and closed within the exit delay period, the system arms in AWAY mode.

Button Arming” above). See “Arming Away” above for Auto-Stay arming feature.

“Single-Button Arming” above).

BYPASS + [#], then wait for all open zones to be displayed. Arm when display indicates “ZONE BYPASSED” and “READY TO ARM”.

If relay outputs (via a 4204, or 4229), or Powerline Carrier devices are used, two touchpad entries available to the user are included. If programmed, these entries can be used to manually activate or deactivate the device(s) for starting or stopping some action, such as turning lights on or off, etc. These touchpad entries are: [Security Code] + # + 7 + [2-digit Device #] activates (starts) that device. [Security Code] + # + 8 + [2-digit Device #] deactivates (stops) that device.

14-3

3000EN Series: Installation Instructions

Features for Each Arming Mode

Arming Mode

AWAY Yes Yes Yes Yes

STAY Yes Yes Yes No

INSTANT Yes No Yes No

NIGHT-STAY Yes Yes Yes Only those zones

Panic Keys

There are three Panic keys (A, B, and C) that, if programmed, can be used to manually initiate alarms and send a report to the central station.

Each key can be programmed for 24-hour Silent, 24-hour Audible, Fire, or Personal Emergency responses. See the table below for defaults.

The programmed Panic response is activated when the appropriate key is pressed for at least 2 seconds.

The Panic functions are identified by the system as follows:

Keys Displayed as Zone “Standard Dealer “ Defaults “Authorized Dealer” Defaults

[A] 95 Fire Emergency Fire Emergency

[B] 99 24-hour Audible 24-hour Audible

[C] 96

IMPORTANT: For a Silent panic function (if programmed) to be of practical value, you must program a report code for the zone and the system must be connected to a central station.

Setting the Real-Time Clock

IMPORTANT: The Real-Time Clock must be set before the end of the installation. NOTE: All partitions must be disarmed before time/date can be set.

Set the time and date by doing the following:

+[#] + [6] [3]

(Master Code)

2. Press [∗] when the time/date is displayed. A cursor appears under the first digit of the hour.

To move cursor ahead, press [

• Enter the 2-digit hour setting.

• Enter the 2-digit minute setting.

• Press [1] for PM or [2] for AM.

• Enter the last two digits of the current year.

• Enter the 2-digit month setting.

• Enter the 2-digit day setting.

3. To exit, press [∗] when cursor is at the last digit, or

wait 30 seconds.

SUMMARY OF ARMING MODES

Exit Delay Entry Delay Perimeter Armed Interior Armed

——

Alpha Display:

listed in Night-

Stay zone list

24-hour Auxiliary

DISARMED READY TO ARM

TIME/DATE SAT

∗

]. To go back, press [#].

04:04PM 10/17/00

Current time display

TIME/DATE SAT 04:04P2000/10/17

Time/date editing display

14-4

Various System Trouble Displays

Alpha Display Fixed Disp. Meaning

ALARM CANCELED CA

EXIT ALARM EA

CHECK CHECK

ALARM 1xx FAULT 1xx CHECK 1xx

SYSTEM LO BAT BAT LO BAT BAT

TELCO FAULT 94

Busy-Standby dl

Modem Comm CC

no display no display

Comm. Failure FC Open Circuit 0C Long Rng Trbl bF Bell Failure 70 RCVR Jam 90 KEYPAD LOW BAT 00 BAT Phone Okay Cd Dialer Off d0 Test in Progress dd Upload Completed dC Upload Failed dF

1xx 1xx 1xx (91)

Will appear if an exit or interior zone contained a fault during closing at the time the Exit Delay ended (e.g., exit door left open), but the system was disarmed during the Entry Delay time. The alarm sounder and touchpad sound continuously, but stop when the system is disarmed. No message will be transmitted to the central station. Will appear when the Exit Delay ends if an exit or interior zone contained a fault during closing. Alarm sounder and touchpad sound continuously until the system is disarmed (or timeout occurs). “Exit Alarm” message is sent to the central station. Also results if an alarm from an exit or interior zone occurs within 2 minutes after the end of an Exit Delay. Indicates that a problem exists with the displayed zone(s) and requires attention. Indicates that communication between control and a zone expander or wireless receiver is interrupted, where “xx” is the device address. Check the wiring and DIP switch settings on the units. If field *199 is set to “1,” all ECP module problems are displayed as “91.” If there are wireless sensors in the system, the Check condition may also be caused by some change in the environment that prevents the receiver from receiving signals from a particular sensor With no zone number indicates the system's main standby battery is weak. With a zone number and a once-per-minute beeping at the touchpad indicates that a low-battery condition exists in the wireless sensor displayed (zone “00” indicates a wireless touchpad). If the battery is not replaced within 30 days, a “CHECK” display may occur. Some wireless sensors use a non-replaceable long-life battery which requires replacement of the entire unit at the end of battery life (e.g., 5802, 5802CP). Telephone Line Failure, indicates that a monitored telephone line (if programmed in field *92) has been cut or disconnected. Depending on how the system was programmed, the touchpad may also produce a trouble sound, and the external sounder may be activated. Silence by entering installer code + OFF. If this remains displayed for more than 1 minute, the system is disabled. NOTE for CANADIAN PANELS: Power up time is 2 minutes, and CID code 305 System Reset is sent if the [#] + [0] command is not performed before the 2 minutes expires. The system is in communication with the central station for change of function or status verification. Power Failure: If there is no touchpad display at all and the LEDs are unlit, operating power (AC and battery) for the system has stopped and the system is inoperative. If the message “AC LOSS” (Custom English display) or “NO AC” (English display) is displayed, the touchpad is operating on battery power only. If the battery standby capacity is used up during a prolonged AC power outage, the control's power will shut down to minimize deep discharge of the battery. A communication failure has occurred. Touchpad is not receiving signals from the control and sees an open circuit. Backup LRR communication failure. Bell supervision failure. RF jam detected. Wireless touchpad low battery The dialer test has been successful (CID code 601). The dialer is disabled. Walk test mode is active the upload or download session was completed the upload or download session failed before completion

14-5

3000EN Series: Installation Instructions

14-6

SECTION 15

Testing the System

•••••••••••••••••••••••••••••••••••••••

About Test Procedures

After the installation is complete, you should perform the following tests: System Test: Checks that all zones have been installed properly and the system properly

responds to faults. Dialer Test: Checks that the phone connection to the central station is working properly. Go/No Go Test: Checks that transmissions can be received from transmitters. Should be

performed before permanently mounting transmitters. RF Sniffer Mode: Checks that RF transmitter serial numbers have been properly entered into the

system. Battery Tests: Automatic battery tests are performed by the system. See Automatic Battery Test

paragraph for details.

System Test

NOTE: Test mode can be entered from any touchpad. However, faulted zones appear only on those touchpads assigned to the partition to which the zone is assigned (i.e., partition 1 zones appear only on partition 1 touchpads, etc.). To see another partition’s faulted zones, view on a touchpad assigned to that partition or use the GOTO command (code +[∗] + partition number 0-3, where 0 is the touchpad’s home partition).

With the system in the disarmed state, check that all zones in the partition to be tested are intact (not faulted). Doors and windows with contacts should be closed, PIRs should be covered (use a cloth to mask them temporarily if necessary). If a “NOT READY” message is displayed, press [∗] to display the faulted zone(s). Restore faulted zone(s) if necessary, so that the “READY” message is displayed.

1. Enter Installer Code + 5 [TEST], then press “0” at the prompt to start Walk Test mode.

1=DIAL, 0=WALK (no special display on English Display Touchpads)

The following will be displayed on the initiating touchpad):

TEST IN PROGRESS (“dd” displayed on English Display Touchpads)

A Contact ID report will also be sent (code 607)

2. Upon entering the system test mode, the outside sounder should sound for 1 second. If the backup battery is discharged or missing, the sounder may not turn on and a “LOW

BATTERY” report will be transmitted with a “TEST” report.

The touchpad will beep about every 30 seconds as a reminder that the system is in the Test mode. NOTE: Wireless motion detectors (Passive Infrared units) will send signals out only if they have

been inactive for 3 minutes (conserves battery life).

3. Test all sensors using the procedure described in the User’s Guide “Testing the System” section.

4. After checking sensors, turn off the test mode by entering installer code + OFF.

NOTE: Test mode automatically ends after 4 hours. During the final 5 minutes (after 3 hours 55 minutes of Test mode), the touchpad emits a double-beep every 30 seconds to alert that the end of Test mode is nearing.

15-1

3000EN SERIES: INSTALLATION INSTRUCTIONS

Checking Transmitter Enrollment (Sniffer Mode)

Use this mode to verify that all transmitters have been properly programmed. Make sure both partitions are disarmed before trying to enter this mode, since this is a system-wide command.

1. From a touchpad in partition 1, Press [Installer code] + [#] + 3.

Note: If the communicator is in the process of sending a report to the central station, the system

will not go into the Sniffer mode. If so, wait a few minutes, and try again.

The touchpads in both partitions will display all zone numbers of wireless units (in both

partitions) programmed into the system. Fault each transmitter in turn, causing each one to send a signal. As the system receives a signal from each of the transmitters, the zone number of that transmitter disappears from the display.

2. After all transmitters have been checked, exit the sniffer mode by keying [Installer code] +

OFF.

IMPORTANT: Sniffer mode does not automatically expire. You must manually exit Sniffer mode (by entering [Installer code] + OFF) to return to normal operation.

Notes:

• All BR type units must physically be activated to clear the display.

• When one button of a transmitter (RF, UR, or BR) is activated, all zones assigned to other

buttons on that transmitter are cleared. This also applies to 5816 and 5817 transmitters, which have multiple loops (zones).

• Any transmitter that is not “enrolled” will not turn off its zone number.

Go/No Go Test Mode

The Go/No Go Test verifies adequate RF signal strength from the proposed transmitter location, and allow you to reorient or relocate transmitters if necessary, before mounting the transmitters permanently. This mode is similar to the Transmitter Test mode, except that the wireless receiver gain is reduced. This will enable you to make sure that the RF signal from each transmitter is received with sufficient signal amplitude when the system is in the normal operating mode.

1. Enter [Installer code] + [#] + 4 from the partition being tested. For multi-partition systems,

repeat this test for each partition.

2. After you have placed transmitters in their desired locations and the approximate length of wire to

be run to sensors is connected to the transmitter's screw terminals (if used), fault each transmitter. Do not conduct this test with your hand wrapped around the transmitter, as this will cause inaccurate results. a. The touchpad will beep three times to indicate signal reception and display the appropriate

zone number.

b. If the touchpad does not beep, you should reorient or move the transmitter to another location.

Usually a few inches in either direction is all that is required.

4. If each transmitter produces the proper touchpad response when it is faulted, you can then

permanently mount each of the transmitters according to the instructions provided with them.

5. Exit the Go/No Go Test mode by entering: [any user code (partition-specific)] + OFF.

15-2

Dialer Communication Test and Periodic Test Reports

1. Enter Installer Code + 5 [TEST], then press “1” at the prompt to start the Dialer Test (checks

phone line integrity only; does not confirm report transmissions).

1=DIAL, 0=WALK (no special display on English Display Touchpads)

The following will be displayed (accompanied by 2 beeps) if test is successful:

PHONE OKAY (“Cd” displayed on English Display Touchpads)

A Contact ID report will also be sent (code 601)

If the dialer test is unsuccessful, the following is displayed:

COMM FAILURE (“FC” displayed on English Display Touchpads)

2. Enter Installer code + OFF to clear the display and exit.

Automatic Periodic Test Report

The system can be set to automatically send test reports (enabled in field *64; Contact ID code 602) at specified intervals.

Frequency of the reports is set in Scheduling mode (event 11) or by the following key commands:

installer code + [#] + 0 + 0 = test report sent every 24 hours installer code + [#] + 0 + 1 = test report sent once per week installer code + [#] + 0 + 2 = test report sent every 28 days

Each mode sets schedule 32 to the selected repeat option; the first test report is sent 12 hours after command.

To ensure that test reports are sent at the times expected, set the Real-Time Clock to the proper time before entering the test report schedule command.

Automatic Standby Battery Tests

1. An automatic test is conducted every 3 minutes to ensure that a standby battery is present and

properly connected. If a battery is not present or is not properly connected, a “LOW BATTERY” message is displayed and, if so programmed, will be reported to the central station.

2. A battery capacity test is automatically conducted for 2 minutes every 4 hours, beginning 4 hours

after exiting the Programming mode or after powering up the system. In addition, entry into the Test mode will also cause a battery capacity test to be initiated. If the battery cannot sustain a load, a “Low Battery” message is displayed and, if so programmed, will be reported to the central station.

15-3

3000EN SERIES: INSTALLATION INSTRUCTIONS

15-4

SECTION 16

Specifications & Accessories

•••••••••••••••••••••••••••••••••••••••

SECURITY CONTROL

1. Physical: 12-1/2” W x 14-1/2” H x 3” D (318mm x 368mm x 76mm)

2. Electrical:

VOLTAGE INPUT: 16.5VAC from plug-in 25VA transformer, Ademco No. 1321 (in U.S.A.) RECHARGEABLE BACKUP BATTERY: 12VDC, 17AH (sealed lead acid type). Charging Voltage: 13.8VDC. ALARM SOUNDER: 12V, 2.0 Amp output can drive 12V BELLS or can drive one or two 702 (series connected)

self-contained 20-watt sirens. Do not connect two 702s in parallel.

AUXILIARY POWER OUTPUT: 12VDC, 600mA max.

Note: For UL installations, Alarm Sounder plus Auxiliary Power currents should not exceed 600mA total. FUSE: Battery (3A) No. 90–12 (PC board may have a PTC device instead of a fuse. The PTC serves as an

3. Communication:

FORMAT SUPPORTED:

LINE SEIZE: Double Pole FCC REGISTRATION No.: 5GBUSA-44003-AL-E RINGER EQUIVALENCE: 0.1B

4. Maximum Zone Resistance: Zones 1–8 = 300 ohms excluding EOLR standard zones

COMPATIBLE DEVICES

Touchpads: 6150ADT, 6160ADT, 6160VADT, iCenter (AUI), 6270ADT Wireless Receivers: 5881L/5882L: accepts up to 8 transmitters

5881M/5882M: accepts up to 16 transmitters 5881H/5882H: accepts up to system maximum transmitters 5883M (accepts up to 16 transmitters); 5883H (accepts up to system max. transmitters) 5800TM Transmitter Module (used with 5827BD Wireless 2-Way Touchpad) Zone Expansion: 4219 WIRED EXPANSION MODULE 4229 WIRED EXPANSION/RELAY MODULE

Relay Module: 4204 RELAY MODULE Phone Modules: 4286 PHONE MODULE Long Range Radio 7845GSMADT, 7845i-ent 2-Wire Smoke Detector:

Transformers: 1321: 16.5VAC, 25VA Plug-In Transformer (No. 1321CN in Canada)

1361X10: 16.5VAC, 40VA Powerline Carrier Device Interface AC Transformer

Sounders: AB12M 10” Motorized Bell & Box 744 Siren Driver 1011BE12M 10” Motorized Bell & Box 745X3 Voice Siren Driver 702 Outdoor Siren 705-820, 5-inch Round Speaker 719 2-Channel Siren 713 Speaker 713 High Power Speaker WAVE Speaker 746 Indoor Speaker WAVE2 Two-Tone Siren 747 Indoor Siren WAVE2PD Two-Tone Piezo Siren 747PD Two-Tone Piezo Dynamic Indoor Siren 5800WAVE Wireless Siren 747UL Indoor Siren 748 Dual Tone Siren 749 Speaker/Horn System Sensor PA400B (beige)/; PA400R (red) Indoor Piezo Sounder

automatically resetting fuse.)

Ademco Contact ID Reporting, 10 characters/sec., DTMF (TouchTone) Data Tones, 1400/2300Hz ACK,

1400Hz KISSOFF.

Detector Type Photoelectric w/heat sensor, direct wire 2300TB Photoelectric, direct wire 2400 Photoelectric w/heat sensor, direct wire 2400TH Photoelectric 2451 w/B401B base Photoelectric w/heat sensor 2451TH w/B401B base Ionization, direct wire 1400 Ionization 1451 w/B401B base Photoelectric duct detector 2451 w/DH400 base Ionization duct detector 1451D w/DH400 base H Low-profile, Photoelectric, w/135°F thermal 2100T Low-profile, Ionization type, direct wire 1100

System Sensor

Model No.

16-1

3000EN SERIES: INSTALLATION INSTRUCTIONS

5800 Series Transmitter Input Loop Identification

All of the transmitters illustrated below have one or more unique factory assigned input (loop) ID codes. Each of the input loops requires its own programming zone

LOOP

LOOP 4

YOU MUST

ENROLL

THIS

BUTTON

5800CO

ENROLL AS "RF"

OFF

5804/5804E

ENROLL AS "BR"

5816

ENROLL AS

5821

ENROLL AS

LOOP 3

LOOP 2

LOOP 1

LOOP 2 (REED)

LOOP 1 (TERMINALS)

"RF"

LOOPS

1 - 3

"RF"

LOOP

5800Micra

ENROLL AS "RF"

LOOP 2

LOOP 4 YOU MUST ENROLL

•

ENROLL AS

SET HOUSE ID

5816MN

ENROLL AS

ARMED

READY

5828/5828V

SET HOUSE ID

THIS BUTTON

LOOP 1

"BR"

LOOP 2 (REED)

LOOP 1 (TERMINALS)

"RF"

MIC

MESSAGE

LOOP

5804BD/5804BDV

ALTERNATE

POSITION FOR

LOOP 2

NOTE: For information on any transmitter not shown, refer to the instructions accompanying that transmitter for details regarding loop

numbers, etc.

UL NOTE: The following transmitters are not intended for use in UL installations:

5802, 5802MN, 5802MN2, 5804E, 5804BD, 5814, 5816TEMP, 5819, 5819WHS & BRS, and 5850.

(e.g., a 5804's four inputs require four programming zones).

5801

ENROLL AS

"UR OR"RF"

LOOP 1

5809

ENROLL AS

5819

"RF"

LOOP 3

LOOP 2 LOOP 1

"RF"

LOOP 1 (TERMINALS)

LOOP 1 (MOTION)

"RF"

LOOP 1

5800SS1

ENROLL AS "RF"

SERIAL #1

LOOP 3

SERIAL #1

LOOP 4

SERIAL #2

LOOP 3

SERIAL #2 - LOOP 1 = ON + 4 BUTTONS

5817

ENROLL AS

LOOP

5853

ENROLL AS

SERIAL #1

OFFON

LOOP 2

SERIAL #1

LOOP 1

SERIAL #2 LOOP 2

LOOP 4 = 3 + 4 BUTTONS

5805-6

ENROLL AS

"BR"

LOOP 1 (PRIMARY)

LOOP 2 (AUX. CENTER)

LOOP 3 (AUX. RIGHT)

"RF"

SERIAL #2 - LOOP 1 = ON + 4 BUTTONS

"RF"

SERIAL #1

SERIAL #2

5800WAVE

SET HOUSE ID

ENROLL AS"RF"

5806/5806W3

5808/5808LST/5808W3

ENROLL AS

LOOP 1

5818MNL

ENROLL AS

LOOP 3

AWAY

STAY

LOOP 4

LOOP 3

LOOP 4 = 3 + 4 BUTTONS

5878

ENROLL AS

"RF"

"BR"

LOOP 1

SERIAL #1 LOOP 2

SERIAL #1 LOOP 1

SERIAL #2 LOOP 2

"RF"

(TERMINALS)

LOOP 4

YOU MUST

ENROLL

THIS

BUTTON

LOOP 2

(REED)

LOOP 3

ENROLL AS

5890/5890PI

ENROLL AS

LOOP 1

5802 MN

ENROLL AS

"UR" OR "RF"

5814

ENROLL AS

LOOP 2

(REED)

LOOP 3

(TERMINALS)

5819S (WHS & BRS)

ENROLL AS

5894PI

ENROLL AS

"RF"

LOOP 1

LOOP 1 (INTERNAL SHOCK SENSOR

LOOP 1

5802 MN2

"UR" OR "RF"

LOOP 2 (REED)

ENROLL AS

5820/5820L

ENROLL AS

5815

5897-35

LOOP 2 (REED)

LOOP 1 (TERMINALS)

"RF"

LOOP 1

"RF"

LOOP 1

"RF"

5800-004-V0

16-2

SECTION 17

Regulatory Agency Statements

•••••••••••••••••••••••••••••••••••••••

FEDERAL COMMUNICATIONS COMMISSION (FCC) PART 15 STATEMENTS

The user shall not make any changes or modifications to the equipment unless authorized by the Installation Instructions or User's Manual. Unauthorized changes or modifications could void the user's authority to operate the equipment.

CLASS B DIGITAL DEVICE STATEMENT

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

INDUSTRY CANADA (IC) STATEMENTS

This device complies with RSS210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

TELEPHONE/MODEM INTERFACE

FCC Part 68

This equipment complies with Part 68 of the FCC rules. On the front cover of this equipment is a label that contains the FCC registration number and Ringer Equivalence Number (REN). You must provide this information to the telephone company when requested.

This equipment uses the following USOC jack: RJ31X

This equipment may not be used on telephone-company-provided coin service. Connection to party lines is subject to state tariffs. This equipment is hearing-aid compatible.

Industry Canada

NOTICE: The Industry Canada Label identifies certified equipment. This certification means that the equipment meets telecommunications network

protective, operational and safety requirements as prescribed in the appropriate Terminal Equipment Technical Requirements document(s). The Department does not guarantee the equipment will operate to the user’s satisfaction.

Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of the local telecommunications company. The equipment must also be installed using an acceptable method of connection. The customer should be aware that compliance with the above conditions may not prevent degradation of service in some situations.

Repairs to certified equipment should be coordinated by a representative designated by the supplier. Any repairs or alterations made by the user to this equipment, or equipment malfunctions, may give the telecommunications company to request the user to disconnect the equipment.

Users should ensure for their own protection that the electrical ground connections of the power utility, telephone lines and internal metallic water pipe system, if present, are connected together, This precaution may be particularly important in rural areas.

Caution: Users should not attempt to make such connections themselves but should contact appropriate electric inspection authority, or electrician, as appropriate.

Ringer Equivalence Number Notice:

The Ringer Equivalence Number (REN) assigned to each terminal device provides an indication of the maximum number of terminals allowed to be connected to a telephone interface. The termination on an interface may consist of any combination of devices subject only to the requirement that the sum of the Ringer Equivalence Numbers of all the devices does not exceed 5.

Industrie Canada

AVIS: l’étiquette d’Industrie Canada identifie le matériel homologué. Cette étiquette certifie que le matériel est conforme aux normes de protection,

d’exploitation et de sécurité des réseaux de télécommunications, comme le prescrivent les documents concernant les exigences techniques relatives au matériel terminal. Le Ministère n’assure toutefois pas que le matériel fonctionnera à la satisfaction de l’utilisateur.

Avant d’installer ce matériel, l’utilisateur doit s’assurer qu’il est permis de le raccorder aux installations de l’enterprise locale de télécommunication. Le matériel doit également être installé en suivant une méthode acceptée da raccordement. L’abonné ne doit pas oublier qu’il est possible que la conformité aux conditions énoncées ci-dessus n’empêche pas la dégradation du service dans certaines situations.

Les réparations de matériel nomologué doivent être coordonnées par un représentant désigné par le fournisseur. L’entreprise de télécommunications peut demander à l’utilisateur da débrancher un appareil à la suite de réparations ou de modifications effectuées par l’utilisateur ou à cause de mauvais fonctionnement.

Pour sa propre protection, l’utilisateur doit s’assurer que tous les fils de mise à la terre de la source d’energie électrique, de lignes téléphoniques et des canalisations d’eau métalliques, s’il y en a, sont raccordés ensemble. Cette précaution est particulièrement importante dans les régions rurales.

Avertissement : L’utilisateur ne doit pas tenter de faire ces raccordements lui-même; il doit avoir racours à un service d’inspection des installations électriques, ou à un électricien, selon le cas.

AVIS : L’indice d’équivalence de la sonnerie (IES) assigné à chaque dispositif terminal indique le nombre maximal de terminaux qui peuvent être raccordés à une interface. La terminaison d’une interface téléphonique peut consister en une combinaison de quelques dispositifs, à la seule condition que la somme d’indices d’équivalence de la sonnerie de tous les dispositifs n’excède pas 5.

17-1

3000EN SERIES: INSTALLATION INSTRUCTIONS

– NOTES –

17-2

– NOTES –

17-3

3000EN SERIES: INSTALLATION INSTRUCTIONS

– NOTES –

17-4

SECTION 18

Limitations and Warranty

•••••••••••••••••••••••••••••••••••••••

THE LIMITATIONS OF THIS ALARM SYSTEM

While this System is an advanced design security system, it does not offer guaranteed protection against burglary, fire or other emergency. Any alarm system, whether commercial or residential, is subject to compromise or failure to warn for a variety of reasons. For example:

• Intrusion detectors (e.g., passive infrared detectors), smoke detectors, and many other sensing devices will not work without power. Battery-operated devices will not work without batteries, with dead batteries, or if the batteries are not put in properly. Devices powered solely by AC will not work if their AC power supply is cut off for any reason, however briefly.

• Signals sent by wireless transmitters may be blocked or reflected by metal before they reach the alarm receiver. Even if the signal path has been recently checked during a weekly test, blockage can occur if a metal object is moved into the path.

• A user may not be able to reach a panic or emergency button quickly enough.

• While smoke detectors have played a key role in reducing residential fire deaths in the United States, they may not activate or provide early warning for a variety of reasons in as many as 35% of all fires, according to data published by the Federal Emergency Management Agency. Some of the reasons smoke detectors used in conjunction with this System may not work are as follows. Smoke detectors may have been improperly installed and positioned. Smoke detectors may not sense fires that start where smoke cannot reach the detectors, such as in chimneys, in walls, or roofs, or on the other side of closed doors. Smoke detectors also may not sense a fire on another level of a residence or building. A second floor detector, for example, may not sense a first floor or basement fire. Finally, smoke detectors have sensing limitations. No smoke detector can sense every kind of fire every time. In general, detectors may not always warn about fires caused by carelessness and safety hazards like smoking in bed, violent explosions, escaping gas, improper storage of flammable materials, overloaded electrical circuits, children playing with matches, or arson. Depending on the nature of the fire and/or location of the smoke detectors, the detector, even if it operates as anticipated, may not provide sufficient warning to allow all occupants to escape in time to prevent injury or death.

• Passive Infrared Motion Detectors can only detect intrusion within the designed ranges as diagrammed in their installation manual. Passive Infrared Detectors do not provide volumetric area protection. They do create multiple beams of protection, and intrusion can only be detected in unobstructed areas covered by those beams. They cannot detect motion or intrusion that takes place behind walls, ceilings, floors, closed doors, glass partitions, glass doors, or windows. Mechanical tampering, masking, painting or spraying of any material on the mirrors, windows or any part of the optical system can reduce their detection ability. Passive Infrared Detectors sense changes in temperature; however, as the ambient temperature of the protected area approaches the temperature range of 90° to 105°F (32° to 40°C), the detection performance can decrease.

• Alarm warning devices such as sirens, bells or horns may not alert people or wake up sleepers if they are located on the other side of closed or partly open doors. If warning devices are located on a different level of the residence from the bedrooms, then they are less likely to waken or alert people inside the bedrooms. Even persons who are awake may not hear the warning if the alarm is muffled by noise from a stereo, radio, air conditioner or other appliance, or by passing traffic. Finally, alarm warning devices, however loud, may not warn hearing-impaired people.

• Telephone lines needed to transmit alarm signals from a premises to a central monitoring station may be out of service or temporarily out of service. Telephone lines are also subject to compromise by sophisticated intruders.

• Even if the system responds to the emergency as intended, however, occupants may have insufficient time to protect themselves from the emergency situation. In the case of a monitored alarm system, authorities may not respond appropriately.

• This equipment, like other electrical devices, is subject to component failure. Even though this equipment is designed to last as long as 20 years, the electronic components could fail at any time.

WARNING

(Continued)

18-5

3000EN SERIES: INSTALLATION INSTRUCTIONS

WARNING

THE LIMITATIONS OF THIS ALARM SYSTEM

(Continued)

The most common cause of an alarm system not functioning when an intrusion or fire occurs is inadequate maintenance. This alarm system should be tested weekly to make sure all sensors and transmitters are working properly. The security touchpad (and remote touchpad) should be tested as well.

Wireless transmitters (used in some systems) are designed to provide long battery life under normal operating conditions. Longevity of batteries may be as much as 4 to 7 years, depending on the environment, usage, and the specific wireless device being used. External factors such as humidity, high or low temperatures, as well as large swings in temperature, may all reduce the actual battery life in a given installation. This wireless system, however, can identify a true low-battery situation, thus allowing time to arrange a change of battery to maintain protection for that given point within the system.

Installing an alarm system may make the owner eligible for a lower insurance rate, but an alarm system is not a substitute for insurance. Homeowners, property owners and renters should continue to act prudently in protecting themselves and continue to insure their lives and property.

We continue to develop new and improved protection devices. Users of alarm systems owe it to themselves and their loved ones to learn about these developments.

WARRANTY INFORMATION

For the latest warranty information, please go to:

www.honeywell.com/security/hsc/resources/wa

18-6

ADT Safewatch Pro 3000EN Installation Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
