User's Manual
4110DL/4110XM
N5100V5 9/96
Previous Menu
–2–
TABLE OF CONTENTS
SYSTEM OVERVIEW....................................................................................................................................... 4
Keypads................................................................................................................................................... 4
Zones....................................................................................................................................................... 4
Alarms...................................................................................................................................................... 5
Fire Protection............................................................................................................................................ 5
Burglary Protection ..................................................................................................................................... 5
Memory of Alarm......................................................................................................................................... 5
Pager Notification ....................................................................................................................................... 5
ABOUT THE KEYPADS .................................................................................................................................... 6
Keypad Types ........................................................................................................................................... 6
Keypad Styles ........................................................................................................................................... 6
SUMMARY OF SYSTEM STATUS DISPLAYS ........................................................................................................ 7
SUMMARY OF KEYPAD FUNCTIONS .................................................................................................................. 8
SECURITY CODES......................................................................................................................................... 10
Duress Code............................................................................................................................................. 10
Quick Arming ............................................................................................................................................ 10
Assigning/Changing/Deleting User Codes (Using the 8
CODE Key) .................................................................... 11
ENTRY/EXIT DELAYS..................................................................................................................................... 12
CHECKING FOR OPEN ZONES (Using the ✴
READY Key) ................................................................................... 13
BYPASSING PROTECTION ZONES................................................................................................................... 14
Using The 6 BYPASS Key.......................................................................................................................... 14
Quick Bypass........................................................................................................................................... 15
ARMING PERIMETER ONLY, WITH ENTRY DELAY ON (Using The 3 STAY Key) ....................................................... 16
ARMING PERIMETER ONLY, WITH ENTRY DELAY OFF (Using The 7
INSTANT Key ) ................................................ 17
ARMING ALL PROTECTION, WITH ENTRY DELAY ON (Using The 2
AWAY Key)....................................................... 18
ARMING ALL PROTECTION, WITH ENTRY DELAY OFF (Using The 4
MAXIMUM Key) ................................................ 19
DISARMING THE SYSTEM AND SILENCING ALARMS (Using the 1
OFF Key)........................................................... 20
–3–
(continued) TABLE OF CONTENTS
USING THE KEYSWITCH................................................................................................................................. 21
CHIME MODE (Using the 9
CHIME Key) ............................................................................................................ 22
PANIC KEYS................................................................................................................................................. 22
TESTING THE SYSTEM (Using the 5
TEST Key) ................................................................................................. 24
TROUBLE CONDITIONS.................................................................................................................................. 26
"Check" and "Battery" Displays..................................................................................................................... 26
Power Failure ............................................................................................................................................ 27
Other Displays .......................................................................................................................................... 28
FIRE ALARM SYSTEM, IF INSTALLED................................................................................................................ 29
In Case of Fire Alarm................................................................................................................................... 29
Silencing Fire Alarms .................................................................................................................................. 30
NATIONAL FIRE PROTECTION ASSOCIATION RECOMMENDATIONS ON SMOKE DETECTORS................................... 31
EMERGENCY EVACUATION ............................................................................................................................ 32
QUICK GUIDE TO ALARM SYSTEM FUNCTIONS.................................................................................................. 33
SUMMARY OF AUDIBLE/VISUAL NOTIFICATION ................................................................................................ 34
PROTECTION ZONES LIST.............................................................................................................................. 35
OWNER'S INSURANCE PREMIUM CREDIT REQUEST........................................................................................... 37
CANADIAN DEPARTMENT OF COMMUNICATIONS (DOC) STATEMENT.................................................................... 39
FEDERAL COMMUNICATIONS COMMISSION (FCC) STATEMENTS ......................................................................... 40
IN THE EVENT OF TELEPHONE OPERATIONAL PROBLEMS ................................................................................. 41
THE LIMITATIONS OF THIS ALARM SYSTEM ...................................................................................................... 42
SERVICING INFORMATION ............................................................................................................................. 43
WARRANTY ..................................................................................................................................... Back Cover
This manual is a step-by-step guide that will aquaint you with the system's features and benefits. It defines the
components and their functions, describes their operation, and instructs you with normal and emergency procedures.
Keep this manual in a convenient place so that you can refer to it as necessary.
–4–
SYSTEM OVERVIEW
General
Congratulations on your ownership of an Ademco Security System.
You've made a wise decision in choosing it, for it represents the latest in
security protection technology today, including microcomputer technology to
monitor all system status. Ademco is the world's largest manufacturer of
security systems and millions of premises are protected by Ademco
systems.
Basically, this system offers you three forms of protection: burglary, fire
and emergency. Your system may consist of at least one keypad which
provides full control of system operation, various sensors such as motion
detectors and door and window sensing devices, plus a selected number
of strategically placed smoke or combustion detectors designed to provide
early warning in case of fire. Your system may also have been pro-
grammed to automatically transmit alarm or status messages over the
phone lines to a central alarm monitoring station.
Keypads
All system functions are controlled by your keypad(s). The keypads
feature a telephone style (digital) keypad and a Liquid Crystal Display
(LCD) which shows the nature and location of all occurrences. Their built-in
sounder will sound during alarm and trouble conditions.
For additional information, see the following section:
ABOUT THE
KEYPADS.
Zones
Your system's sensing devices have been assigned to various zones. For
example, the sensing device on your Entry/Exit door may have been
assigned to zone 01, sensing devices on windows in the master bedroom
to zone 02, and so on. These zone numbers will appear on the display
when an alarm or trouble condition occurs.
–5–
(continued) SYSTEM OVERVIEW
Alarms
When an alarm occurs, both the keypad and external sounders will sound,
and a message at the keypad will identify the zone(s) causing the alarm. In
addition, if your system is connected to a central monitoring station, an
alarm message will be sent. To stop the alarm sounding, you simply disarm
the system.
Fire Protection
The fire protection portion of your security system (if used) is always on
and will sound an alarm if a fire condition is detected. Refer to the
FIRE
ALARM SYSTEM
section for important information concerning fire pro-
tection, smoke detectors and planning emergency exit routes from your
premises.
Burglary Protection
The burglary protection portion of your system must be turned on or
"armed" before it will sense burglary alarm conditions and sound an alarm.
Your system can be armed in one of four modes: STAY, AWAY, INSTANT
and MAXIMUM. Refer to the
ARMING THE SYSTEM
sections for
instructions in using these modes of operation.
Your system also provides a CHIME mode for alerting you to the opening
and closing of doors and windows while the system is disarmed.
Memory Of Alarm
When an alarm or trouble condition occurs, the keypad displays the
number(s) of the zone(s) that caused the problem, and displays the type
of alarm or trouble (ex. FIRE, ALARM, CHECK). The display remains until it
is cleared by entering the OFF sequence (security code + OFF key) twice.
Pager Notification
If you have chosen to be notified of alarms or other system conditions by
pager, the following codes will be sent to your pager by the control:
1811=Trouble 1911=Alarm
1001=Open 1002=Close
–6–
ABOUT THE KEYPADS
Keypad Types
All commands and procedures described herein are illustrated for Fixed-
Word Display Keypads. However, an Alpha Display Keypad (with a 2-
line LCD display for more detailed protection point identification and system
status, but with similar commands and procedures) is available and might
have been used instead.
Keypad Styles
Unless noted oth-
erwise, all proce-
dures in this man-
ual apply equally to
all keypad types
and styles.
Fixed-Word keypads are available in two styles, A and B, either of which
may have been used in your system. Although different in appearance,
both styles are functionally similar. The keypads on style B keypads are
located behind a flip-down door which can be removed, if desired. Words
displayed on all Fixed-Word keypads are the same, except that their
location in the display window differs slightly with each style.
Note:
Some Style B keypads are equipped with a READY indicator in
place of the POWER indicator on Style A keypads. The READY indicator
is lit when the system is ready for arming (no protection zones open).
While the system is disarmed, this indicator will go on and off as protection
zones are opened and closed.
STYLE A FIXED-WORD KEYPADS STYLE B FIXED-WORD KEYPADS
00
ALARM
CHECK
FIRE
AWAY
STAY
INSTANT
BYPASS
NOT READY
NO AC
CHIME
BAT
PANIC
1
2
3
4
5
6
7
8
9
*
0
#
OFF AWAY STAY
MAX TEST BYPASS
INSTANT CODE CHIME
READY
ARMED
POWER
1 2 3
A
4 5 6
B
7 8 9
C
*
0
#
D
OFF
AWAY
STAY
MAX
TEST
BYPASS
INSTANT
CODE
CHIME
READY
PANIC
ARMED
READY
00
ALARM
CHECK
FIRE
AWAY
STAY
INSTANT
BYPASS
NOT READY
NO AC
CHIME
BAT
D
DIAGRAM
A
B
C
SHOWN WITH DOOR REMOVED
–7–
SUMMARY OF SYSTEM STATUS DISPLAYS
AWAY All burglary zones, interior & perimeter,
are armed.
STAY Perimeter burglary zones, such as windows
and doors are armed.
INSTANT Perimeter burglary zones armed and
entry delay is turned off.
BYPASS One or more burglary protection zones
have been bypassed.
NOT READY Appears when burglary portion of the system
is not ready for arming (due to one or more
open protection zones).
READY The burglary portion of the system
is ready to be armed.
NO AC Appears when AC power has been cut off.
System is operating on backup battery power.
AC Appears when AC power is present.
CHIME Appears when the CHIME feature is ON.
BAT Low system battery
(if no zone number is shown), or
Low battery condition in a wireless sensor
(if zone number is
also
shown).
00
ALARM
CHECK
FIRE
AWAY
STAY
INSTANT
BYPASS
NO AC
CHIME
BAT
NOT READY
00
00
STYLE A
00
ALARM
FIRE
AWA Y
BYPASS
STAY
CHECK INSTANT
NO AC
NOT READY
CHIME BAT
00
STAY
FIRE
ALARM
AWAY
STYLE B
FIXED-WORD KEYPAD DISPLAYS
ALARM Appears when an intrusion has been detected and the system is armed (also appears
during a fire alarm). Accompanied by the ID # of the protection zone in alarm.
CHECK Appears when a malfunction is discovered in the system at any time or if a fault is
detected in a FIRE zone at any time or in a DAY(Trouble)/NIGHT(Alarm) burglary zone
during a disarmed period. Accompanied by a display of zone number in trouble.
FIRE Appears when a fire alarm is present. Accompanied by a display of the zone in alarm.
–8–
SUMMARY OF KEYPAD FUNCTIONS
1. DISPLAY WINDOW: Displays protection zone
ID and system status messages.
2. 1 OFF KEY: Disarms burglary portion of the
system, silences alarms and audible trouble
indicators, and clears visual display after
problem's correction.
3. 2 AWAY KEY: Arms the entire burglary sys-
tem, perimeter and interior.
4. 3 STAY KEY: Arms perimeter portion of bur-
glary system only. Interior protection is not
armed, which allows movement within
premises without causing alarm.
5. 4 MAXIMUM KEY: Arms in manner similar to
AWAY mode, but without the entry delay
feature, thus providing maximum protection.
An alarm will occur immediately upon opening
any protection point, including the entry/exit
door.
6. 5 TEST KEY: Tests the system and alarm
sounder if disarmed. Refer to
TESTING THE
SYSTEM
section for test procedures.
7. 6 BYPASS KEY: Removes individual pro-
tection zones from being monitored by the
system.
8. 7 INSTANT KEY: Arms in manner similar to
STAY mode, but without the entry delay
feature. Entering via the entry/exit door will
cause an instant alarm.
9. 8 CODE KEY: Used to assign additional user
codes for other users of the system.
10. 9 CHIME KEY: Turns CHIME mode on and
off. When on, the opening of windows or
doors while the system is disarmed will sound
3 beeps at the keypad(s).
11.
✴
READY KEY: Displays all open protection
zones.
12. # KEY: "Quick Arm" key permits ARMING of
the system without use of a security code (if
so programmed).
13. KEYS 0–9
†
: Used to enter your security code(s).
14. READY INDICATOR: (GREEN) Lit when the
system is ready to be armed (no faults present).
While the system is disarmed, this indicator will go
on and off as protection zones are closed and
opened.
Note:
On some keypads there is, instead, a
POWER INDICATOR (GREEN) which is
lit when AC power is present. If the
indicator is off, the system may still be
operating, but on its backup battery
power. See
Power Failure
in
TROUBLE
CONDITIONS
section.
†
Note: Keys 1 through 9 each perform their associated companion functions (OFF, AWAY, STAY,
etc.) when preceded by an entry of the security code (as described later).
–9–
15. ARMED INDICATOR: (RED) Lit when
the system has been armed (STAY,
AWAY, INSTANT or MAXIMUM).
16. INTERNAL SOUNDER: The built-in
keypad sounder mimics the alarm
sounder during alarms, and will also
"beep" during certain system functions.
(see
SUMMARY OF AUDIBLE/ VISUAL
NOTIFICATION
).
17. EMERGENCY KEYS:
Individual keys A, B, and C (key D not
used).
On some keypads, these keys are not
present, and the following key pairs may
be available, instead, for emergency
functions:
✴ &#, ✴ & 1 , # & 3
Some or all of these keys/pairs may be
programmed for panic functions by your
installer (see
PANIC KEYS
section).
IMPORTANT!: When entering codes and
commands, sequential key depressions must be
made within 2 seconds of one another. If 2 seconds
elapses without a key depression, the entry is
aborted and must be repeated from its beginning.
ARMED
READY
A
B
C
ALARM
FIRE
AWAY
BYPASS
STAY
CHECK INSTANT
NO AC
NOT READY
CHIME BAT
OFF AWAY STAY
MAX TEST BYPASS
INSTANT CODE CHIME
READY
123
45
6
*
98
7
#0
PANIC
1
5
3
15
4
14
2
8
11
9
13
12
10
7
6
17
16
STYLE B KEYPAD
–10–
SECURITY CODES
General
At the time of installation, your installer programmed a personal four-digit
Master code, known only to you and yours. This code is used to perform
most system functions, including arming and disarming of the system. As an
additional safety feature, temporary user codes can be assigned (see next
page) for use by those not having a need to know the Master code. Note
that the Master code remains in effect even when other user codes are
assigned.
Duress Code
Ask your installer if
"Duress" is active for
your system, and if so,
check here:
This feature is intended for use when you are forced to disarm or arm the
system under threat. When used, the system will act normally, but can
silently notify the central station of your situation, if that service has been
provided.
The Duress code is defined as user number 8.
Important: The Duress code is useful only when connected to a central
station.
Quick Arming
Ask your installer if
"Quick Arming" is active
for your system, and if
so, check here:
If your system supports "Quick Arming", the "#" key can be pressed in
place of the security code when arming the system. The security code is
always
required, however, when disarming the system. accept
–11–
(continued) SECURITY CODES
To Assign, Change,
or Delete
User Codes
4-DIGIT USER CODES
It is recommended that
obvious codes such as
1111 or 1234 not be
assigned.
1. Enter your Master code and press the CODE key.
2. Enter single-digit user number ('2', '3', '4', '5', '6' or '7') for which a code
is to be assigned, changed, or deleted.
3.
If
assigning or changing a user's code,
enter the desired 4-digit code
for use by that user number. The keypad will beep once.
If deleting a user's code,
perform steps 1 & 2 and stop. In a few
moments the keypad will beep once, indicating that the existing code
has been deleted.
To assign your Duress code, do the following:
Enter your [Master code] + [8] + [8] + [desired 4-digit code]. The
keypad will beep once.
The Master code can be changed by the main user of the system. To
change it, do the following:
Enter your [Master code] + [8] + [1] + [new Master code] + [new Master
code] again. The keypad will beep once.
Important:Temporary users should not be shown how to use any
system function they do not need to know (e.g., bypassing protection
zones).
–12–
ENTRY/EXIT DELAYS
General Information
Your system has preset time delays, known as exit delay and entry delay.
When you arm your system, exit delay gives you time to leave through
the entry/exit door without setting off an alarm. Entry delay gives you time
to disarm the system when you reenter through the entry/exit door. The
system must be disarmed, however, before the entry delay period ends, or
an alarm will occur. The keypad will beep slowly during the entry delay
period, reminding you to disarm the system.
You can also arm the system with no entry delay at all by using either
INSTANT or MAXIMUM arming modes. These modes can provide greater
security while you are sleeping or while you are away for extended
periods of time.
See your installer for your delay times and record them here:
Exit Delay:
seconds Entry Delay: seconds
–13–
CHECKING FOR OPEN ZONES
Using the
✴
READY Key
Before your system can be armed, all protected doors, windows and other
protection zones must be closed or bypassed (see
BYPASSING
PROTECTION
ZONES
section), otherwise the keypad will display a "Not
Ready" message, and if your keypad has a READY indicator light, it will
not be lit. The READY key can be used to display all faulted zones,
making it easier for you to secure any open zone.
To display faulted zones, simply press and release the READY key (do
not enter code first). Secure or bypass the zones displayed before arming
the system.
A "Ready" message will be displayed when all protection zones have
been either closed or bypassed and the keypad's READY indicator light (if
present) will be lit.
TYPICAL DISPLAYS
TYPICAL DISPLAYS INDICATING FAULTED PROTECTION ZONE TYPICAL DISPLAYS
WHEN NOT READY TO ARM (AFTER PRESSING READY KEY) INDICATING "READY TO ARM"
ALARM
AWAY
BYPASS
STAY
SUPV NO AC
PHONE TEST
NOT READY
CHIME BAT
FIRE
CHECK INSTANT TAMPER
ALARM
AWAY
BYPASS
STAY
SUPV NO AC
PHONE TEST
NOT READY
CHIME BAT
FIRE CHECK INSTANT TAMPER
03
ALARM
AWAY
BYPASS
STAY
SUPV NO AC
PHONE TEST
NOT READY
CHIME BAT
FIRE
CHECK INSTANT TAMPER
–14–
BYPASSING PROTECTION ZONES
Using the
6
BYPASS Key
LIMITATION
The system will not
allow fire zones to be
bypassed.
All bypasses are removed
when an OFF sequence
(security code plus OFF)
is performed.
This key is used when you want to arm your system with one or more
zones intentionally unprotected. The system must be disarmed first.
1. Enter your security code and press the BYPASS key.
2. Enter zone number(s) for the zone(s) to be bypassed (e.g., 06, 10,
13, etc.).
Single digit zone numbers must be preceded by a zero (e.g.
05, 06)
.
3. When finished, the keypad will display a "Bypass" message along
with each bypassed zone number, accompanied by a beep for each.
Wait for these zones to be displayed, to confirm their bypass.
4. Arm the system as usual.
Bypassed zones are unprotected and will not cause an alarm if
violated while your system is armed.
TO BYPASS ZONES:
• ENTER USER CODE.
• PRESS BYPASS KEY.
• ENTER ZONE Nos.
• WAIT FOR BYPASSED ZONES
TO BE DISPLAYED.
• ARM BURGLARY PROTECTION
AS USUAL.
TYPICAL MOMENTARY DISPLAYS
OF BYPASSED ZONE
ALARM
AWAY
BYPASS
STAY
SUPV NO AC
PHONE TEST
NOT READY
CHIME BAT
FIRE CHECK INSTANT TAMPER
03
FIXED-WORD
Loading...
