ADLINK PCI-7396 User Manual

User’s Guide

NuDAQ

PCI-7348/7396

48/96-CH Digital I/O Cards

DIN-96DI, DIN-96DO

©Copyright 2002 ADLINK Technology Inc.
All Rights Reserved.
Manual Rev. 1.22 June 7, 2002
Pato No : 50-11107-200

The information in this document is subject to change without prior notice in
order to improve reliability, design and function and does not represent a
commitment on the part of the manufacturer.

In no event will the manufacturer be liable for direct, indirect, special,
incidental, or consequential damages arising out of the use or inability to use
the product or documentation, even if advised of the possibility of such
damages.

This document contains proprietary information protected by copyright. All
rights are reserved. No part of this manual may be reproduced by any
mechanical, electronic, or other means in any form without prior written
permission of the manufacturer.

Trademarks

NuDAQ, DAQBench are registered trademarks of ADLINK Technology
Inc.

Other product names mentioned herein are used for identification purposes
only and may be trademarks and/or registered trademarks of their respective
companies.

Getting service from ADLINK

Sales & Service

[e-mail]

TEL +886

-2-

82265877

FAX +886

-2-

82265717

Address

9F, No. 166, Jian Yi Road, Chungho City, Taipei, 235 Taiwan,

Company/Organization

Contact Person

E-mail Address

Address

Country

TEL

FAX

Product Model

OS: Computer

Customer Satisfaction is always the most important thing for ADLINK
Tech Inc. If you need any help or service, please contact us and get it.

ADLINK Technology Inc.

Web Site

Technical
Support

Please inform or FAX us of your detailed information for a prompt,
satisfactory and constant service.

Web Site
Questions

http://www.adlinktech.com

NuDAQ [e-mail]
automation [e-mail]
NuIPC [e-mail]
NuPRO/EBC [e-mail]

Detailed Company Information

Environment to Use

M/B: CPU:
Chipset: BIOS:
Video Card:
Network Interface Card:
Other:

Challenge Description
Suggestions to

ADLINK

Table of Contents

Chapter 1 Introduction......................................................1

1.1 Features.................................................................................1

1.1.1 Digital I/O Ports...............................................................................1

1.1.2 Timer / Counter and Interrupt System..........................................2

1.1.3 Miscellaneous.................................................................................2

1.2 Applications............................................................................2

1.3 Specifications.........................................................................3

1.4 Software Supporting...............................................................4

1.4.1 Programming Library .....................................................................4

1.4.2 PCIS-LVIEW: LabVIEW® Driver....................................................5

1.4.3 PCIS-VEE: HP-VEE Driver............................................................5

1.4.4 DAQBenchTM: ActiveX Controls....................................................5

1.4.5 PCIS-DDE: DDE Server and InTouchTM......................................5

1.4.6 PCIS-ISG: ISaGRAFTM driver........................................................5

1.4.7 PCIS-ICL: InControlTM Driver.........................................................6

1.4.8 PCIS-OPC: OPC Server.................................................................6

Chapter 2 Installation........................................................7

2.1 What You Have......................................................................7

2.2 Unpacking...............................................................................8

2.3 PCI-7396 Layout....................................................................9

2.4 Hardware Installation Outline................................................10

2.5 Connectors’ Pin Assignment of PCI-7348.............................11

2.6 Connectors’ Pin Assignment of PCI-7396.............................12

2.7 Jumpers’ Description............................................................13

2.7.1 Power-on-state..............................................................................13

2.8 Termination Boards Supporting.............................................14

2.8.1 Connect with DIN-100S................................................................14

2.8.2 Connect with DIN-96DI.................................................................14

2.8.3 Connect with DIN-96DO...............................................................14

Chapter 3 Registers Format...........................................15

3.1 PCI PnP Registers...............................................................15

3.2 I/O Address Map...................................................................17

3.3 Digital Data Registers ..........................................................18

3.4 Control Register...................................................................19

Table of Contents • i

3.5 External Trigger Enable Register..........................................19

3.6 External Trigger Disable Register.........................................20

3.7 Change of State (COS) Control Register..............................20

3.8 Interrupt Source Control (ISC) Register................................21

3.9 Clear Interrupt Register........................................................22

3.10 Timer/Counter Register.........................................................22

3.11 High Level Programming.......................................................22

Chapter 4 Operation Theorem........................................23

4.1 Digital I/O Ports....................................................................23

4.1.1 Introduction....................................................................................23

4.1.2 External Trigger............................................................................23

4.2 8254 Timer/Counter Operation.............................................25

4.2.1 Introduction....................................................................................25

4.2.2 Cascaded 32 bits Timer...............................................................25

4.2.3 Event Counter and Edge Control................................................25

4.3 Interrupt Circuit.....................................................................26

4.3.1 System Architecture.....................................................................26

4.3.2 IRQ Level Setting..........................................................................26

4.3.3 Dual Interrupt System...................................................................27

4.3.4 Interrupt Source Control (ISC).....................................................28

4.3.5 Change of State (COS) Interrupt.................................................29

4.4 12V and 5V Power Supply ....................................................30

Chapter 5 C/C++ Libraries..............................................31

5.1 Libraries Installation.............................................................31

5.2 Programming Guide..............................................................32

5.2.1 Naming Convention.....................................................................32

5.2.2 Data Types....................................................................................32

5.3 _7396_Initial........................................................................33

5.4 _7396_DI.............................................................................34

5.5 _7396_DO ...........................................................................36

5.6 _7396_Config_Port..............................................................37

5.7 _7396_Software_Reset.......................................................39

5.8 _7396_INT_Source_Control.................................................40

5.9 _7396_COSIRQ_Control......................................................41

5.10 _7396_CLR_IRQ ..............................................................42

5.11 _7396_Set_Event_Edge ...................................................43

5.12 _7396_Cascaded_Timer...................................................44

5.13 _7396_Timer_Start ...........................................................45

ii • Table of Contents

5.14 _7396_Timer_Read ..........................................................46

Appendix 1 DIN-96DI....................................................47

A1.1 Introductions .....................................................................47

A1.2 Features ...........................................................................47

A1.3 Specifications ...................................................................47

A1.4 Layout of DIN-96DI...........................................................49

A1.5 DI Circuits and Wiring .......................................................50

Appendix 2 DIN-96DO...................................................51

A2.1 Introductions .....................................................................51

A2.2 Features ...........................................................................51

A2.3 Specifications ...................................................................51

A2.4 Layout of DIN-96DO..........................................................53

A2.5 Circuits and Wiring............................................................54

Warranty Policy...............................................................56

Table of Contents • iii

How to Use This Guide

This manual is designed to help you use the PCI-7396. It describes how to
modify and control various functions on the PCI-7396 card to meet your
requirements. It is divided into three chapters:

u Chapter 1, "Introduction," gives an overview of the product features.

applications, and specifications.

u Chapter 2, "Installation," describes how to install the PCI-7396. The

layout of PCI-7396 is shown. The jumper settings, the connectors’ pin
assignment, and the other notes for installation are described.

u Chapter 3, "Registers’ Format," describes the details of registers’

format and structure of the PCI-7396, this information is very important
for the programmers who want to control the hardware by low-level
programming language.

u Chapter 4, "Operation Theorem" describes more details about the

versatile functions, including DIO, timer / counter, and interrupt systems.

u Chapter 5, "C/C++ Software Libraries" specifies the software libraries

of C/C++ language under DOS environment that make you operate the
functions of this card easily.

How to Use This Guide • iv

1

Introduction

The PCI-7396 is a 48/96-bit parallel digital input/output (DIO) card designed
for industrial applications. The plug and play feature of PCI-Bus architecture
make it easy for users to install their systems quickly.

The PCI-7396 emulates two/four 8255 Programmable Peripheral Interface
(PPI) chips. Each PPI offers 3 8-bit DIO ports which can be accessed
simultaneously. The total 6/12 ports can be programmed as input or output
independently.

The PCI-7396 supports external trigger to latch the digital input data. The
function of “Change of State” (COS) interrupt is provided. It means when
anyone of these digital inputs changes its state, an interrupt will be generated
for user to handle this external event.

1.1 Features

The PCI-7396 Digital I/O boards provide the following advanced features:

1.1.1 Digital I/O Ports

u 48/96 TTL compatible digital I/O lines
u SCSI-type 100-pin connector (AMP-787082-9)
u 48mA High current driving capability per channel
u Output status read-back
u Support external trigger to latch digital input data (PCI-7348 only)

Introduction • 1

1.1.2 Timer / Counter and Interrupt System

u A programmable 32-bit timer to generate timer interrupt
u A programmable 16-bit event counter to generate event interrupt
u 48/96-bit change of state (COS) interrupt
u Dual interrupt system

1.1.3 Miscellaneous

u Provide 12V and 5V power supply on SCSI-type 100-pin

connectors(only for PCI-7348)

u On board resettable fuses to protect power supply from external

damage. (only for PCI-7348)

1.2 Applications

u Programmable mixed digital input & output
u Industrial monitoring and controlling
u LED indicator driving
u Parallel data transfer
u TTL,DTL, and CMOS logic sensing

2 • Introduction

1.3 Specifications

I/O channels 48-bit for PCI-7348

96-bit for PCI-7396

Input Signal Logic High Voltage

Logic Low Voltage
Logic High Current
Logic Low Current

Output Signal Logic High Voltage

Logic Low Voltage
Logic High Current
Logic Low Current

Operating Temperature 0° ~ 60° C
Storage Temperature -20° ~ 80° C

Humidity 5% ~ 95% non-condensing
I/O Connectors 100-pin SCSI connector
Bus PCI bus, rev 2.1
IRQ Level Set by PCI BIOS
I/O port address Set by PCI BIOS
Power Consumption
(without external devices)
Transfer Rate 1M bytes/sec (Typical)
Size Half-size PCB : 158 mm x 107 mm

PCI-7348 : 350mA (TYP)
PCI-7396 : 450mA (TYP)

: 2.0 V to 5.25V
: 0.0 V to 0.80V
: 0.1 uA
: -8 mA
: Typical 3.3 V
: Minimum 2.4 V
: Maximum 0.5V
: -15.0 mA
: 48.0 mA

Introduction • 3

1.4 Software Supporting

ADLink provides versatile software drivers and packages for users’ different
approach to built-up a system. We not only provide programming library
such as DLL for many Windows systems, but also provide drivers for many
software package such as LabVIEW®, HP VEETM, DASYLabTM, InTouchTM,
InControlTM, ISaGRAFTM, and so on.

All the software options are included in the ADLink CD. The non-free
software drivers are protected with serial licensed code. Without the
software serial number, you can still install them and run the demo version
for two hours for demonstration purpose. Please contact with your dealer to
purchase the formal license serial code.

1.4.1 Programming Library

For customers who are writing their own programs, we provide function
libraries for many different operating systems, including:

u DOS Library: Borland C/C++ and Microsoft C++, the functions

descriptions are included in this user’s guide.

u Windows 95 DLL: For VB, VC++, Delphi, BC5, the functions

descriptions are included in this user’s guide.

u PCIS-DASK: Include device drivers and DLL for Windows 98,

Windows NT and Windows 2000. DLL is binary compatible across

Windows 98, Windows NT and Windows 2000. That means all
applications developed with PCIS-DASK are compatible across
Windows 98, Windows NT and Windows 2000. The developing
environment can be VB, VC++, Delphi, BC5, or any Windows
programming language that allows calls to a DLL. The user’s guide and
function reference manual of PCIS-DASK are in the CD. Please refer
the PDF manual files under (\\Manual_PDF\Software\PCIS-DASK)

u PCIS-DASK/X: Include device drivers and shared library for Linux. The

developing environment can be Gnu C/C++ or any programming
language that allows linking to a shared library. The user's guide and
function reference manual of PCIS-DASK/X are in the CD.
(\\Manual_PDF\Software\PCIS-DASK-X.)

The above software drivers are shipped with the board. Please refer to the
“Software Installation Guide” to install these drivers.

4 • Introduction

1.4.2 PCIS-LVIEW: LabVIEW® Driver

PCIS-LVIEW contains the VIs, which are used to interface with NI’s
LabVIEW® software package. The PCIS-LVIEW supports Windows
95/98/NT/2000. The LabVIEW® drivers are free shipped with the board.
You can install and use them without license. For detail information about
PCIS-LVIEW, please refer to the user’s guide in the CD.

(\\Manual_PDF\Software\PCIS-LVIEW)

1.4.3 PCIS-VEE: HP-VEE Driver

The PCIS-VEE includes the user objects, which are used to interface with
HP VEE software package. PCIS-VEE supports Windows 95/98/NT. The
HP-VEE drivers are free shipped with the board. You can install and use
them without license. For detail information about PCIS-VEE, please refer
to the user’s guide in the CD.

(\\Manual_PDF\Software\PCIS-VEE)

1.4.4 DAQBenchTM: ActiveX Controls

We suggest the customers who are familiar with ActiveX controls and
VB/VC++ programming use the DAQBenchTM ActiveX Control components
library for developing applications. The DAQBenchTM is designed under
Windows NT/98. For more detailed information about DAQBench, please
refer to the user’s guide in the CD.

(\\Manual_PDF\Software\DAQBench\DAQBench Manual.PDF)

1.4.5 PCIS-DDE: DDE Server and InTouchTM

DDE stands for Dynamic Data Exchange specifications. The PCIS-DDE
includes the PCI cards’ DDE server. The PCIS-DDE server is included in
the ADLINK CD. It needs license. The DDE server can be used
conjunction with any DDE client under Windows NT.

1.4.6 PCIS-ISG: ISaGRAFTM driver

The ISaGRAF WorkBench is an IEC1131-3 SoftPLC control program
development environment. The PCIS-ISG includes ADLink products’ target
drivers for ISaGRAF under Windows NT environment. The PCIS-ISG is
included in the ADLINK CD. It needs license.

Introduction • 5

1.4.7 PCIS-ICL: InControlTM Driver

PCIS-ICL is the InControl driver which support the Windows NT. The PCIS­ICL is included in the ADLINK CD. It needs license.

1.4.8 PCIS-OPC: OPC Server

PCIS-OPC is an OPC Server, which can link with the OPC clients. There are
many software packages on the market can provide the OPC clients now.
The PCIS-OPC supports the Windows NT. It needs license.

6 • Introduction

2

Installation

This chapter describes how to install the PCI-7396. The contents in the
package and unpacking information that you should be careful are described.

Please follow the steps to install the PCI-7348/7396.

u Check what you have (section 2.1)
u Unpacking (section 2.2)
u Check the PCB (section 2.3)
u Install the hardware (section 2.4)
u Please refer to the “Software Installation Guide” to install the software

drivers.

2.1 What You Have

In addition to this User's Manual, the package includes the following items:

u PCI-7396 96-bits Parallel Digital I/O Card
u ADLINK CD
u Software Installation Guide

If any of thes e items is missing or damag ed, contact the dealer from whom
you purchased the product. Save the shipping materials and carton in case
you want to ship or store the product in the future.

Installation • 7

2.2 Unpacking

Your PCI-7396 card contains sensitive electronic components that can be
easily damaged by static electricity.

The card should be done on a grounded anti-static mat. The operator
should be wearing an anti-static wristband, grounded at the same point as
the anti-static mat.

Inspect the card module carton for obvious damage. Shipping and handling
may cause damage to your module. Be sure there are no shipping and
handing damages on the module before processing.

After opening the card module carton, exact the system module and place it
only on a grounded anti-static surface component side up.

Note: DO NOT APPLY POWER TO THE CARD IF IT HAS BEEN

DAMAGED.

You are now ready to install your PCI-7396.

8 • Installation

2.3 PCI-7396 Layout

Figure 2.1 PCI-7396 Layout

Installation • 9

2.4 Hardware Installation Outline

Hardware configuration

The PCI cards (or CompactPCI cards) are equipped with plug and play PCI
controller, it can request base addresses and interrupt according to PCI
standard. The system BIOS will install the system resource based on the
PCI cards’ configuration registers and system parameters (which are set by
system BIOS). Interrupt assignment and memory usage (I/O port locations)
of the PCI cards can be assigned by system BIOS only. These system
resource assignments are done on a board-by-board basis. It is not
suggested to assign the system resource by any other methods.

PCI slot selection

The PCI card can be inserted to any PCI slot without any configuration for
system resource.

Installation Procedures

1 Turn off your computer
2 Turn off all accessories (printer, modem, monitor, etc.) connected to

your computer.
3 Remove the cover from your computer.
4 Setup jumpers on the PCI or CompactPCI card.
5 Select a 32-bit PCI slot. PCI slot are short than ISA or EISA slots, and

are usually white or ivory.
6 Before handling the PCI cards, discharge any static buildup on your

body by touching the metal case of the computer. Hold the edge and

do not touch the components.
7 Position the board into the PCI slot you selected.
8 Secure the card in place at the rear panel of the system.

10 • Installation

(51)

2.5 Connectors’ Pin Assignment of PCI-7348

The I/O pin assignment of PCI-7348 is shown in the Figure 2.2.

(1) P1A0 (26) P2A0 (51) EVENT (76) GND

(1)
(2)
(3)

(48)
(49)
(50)

(52)
(53)

(98)
(99)
(100)

The DIO pin names are specified as PnXb, where

n : means the PPI number of the PCI-7348, n=1~2
X : means the port name of the PPI, X= ‘A’ , ‘B’ or ‘C’
b: means the bit number of the port, b=0~7

For example, P1C4 means bit 4 of port C on PPI1.

EXTTRG : External trigger signal to latch digital input data
EVENT : External event source for counter 0

V5V : +5V power supply output
+12V : +12v power supply output
GND : Ground

(2) P1A1 (27) P2A1 (52) GND (77) GND
(3) P1A2 (28) P2A2 (53) GND (78) GND
(4) P1A3 (29) P2A3 (54) GND (79) GND
(5) P1A4 (30) P2A4 (55) GND (80) GND
(6) P1A5 (31) P2A5 (56) GND (81) GND
(7) P1A6 (32) P2A6 (57) GND (82) GND
(8) P1A7 (33) P2A7 (58) GND (83) GND
(9) P1B0 (34) P2B0 (59) GND (84) GND
(10) P1B1 (35) P2B1 (60) GND (85) GND
(11) P1B2 (36) P2B2 (61) GND (86) GND
(12) P1B3 (37) P2B3 (62) GND (87) GND
(13) P1B4 (38) P2B4 (63) GND (88) GND
(14) P1B5 (39) P2B5 (64) GND (89) GND
(15) P1B6 (40) P2B6 (65) GND (90) GND
(16) P1B7 (41) P2B7 (66) GND (91) GND
(17) P1C0 (42) P2C0 (67) GND (92) GND
(18) P1C1 (43) P2C1 (68) GND (93) GND
(19) P1C2 (44) P2C2 (69) GND (94) GND
(20) P1C3 (45) P2C3 (70) GND (95) GND
(21) P1C4 (46) P2C4 (71) GND (96) GND
(22) P1C5 (47) P2C5 (72) GND (97) GND
(23) P1C6 (48) P2C6 (73) GND (98) GND
(24) P1C7 (49) P2C7 (74) GND (99) EXTTRG
(25) V5V (50) +12V (75) V5V (100) +12V

Note : The power supply pins are protected by resettable fuses. Refer

to section 4.4 for details of the power supply.

Installation • 11

2.6 Connectors’ Pin Assignment of PCI-7396

(48)
(49)
(50)

(1)
(2)
(3)

(51)
(52)
(53)

(2) P1A1 (27) P2A1 (52) P3A1 (77) P4A1
(3) P1A2 (28) P2A2 (53) P3A2 (78) P4A2
(4) P1A3 (29) P2A3 (54) P3A3 (79) P4A3
(5) P1A4 (30) P2A4 (55) P3A4 (80) P4A4
(6) P1A5 (31) P2A5 (56) P3A5 (81) P4A5
(7) P1A6 (32) P2A6 (57) P3A6 (82) P4A6
(8) P1A7 (33) P2A7 (58) P3A7 (83) P4A7
(9) P1B0 (34) P2B0 (59) P3B0 (84) P4B0
(10) P1B1 (35) P2B1 (60) P3B1 (85) P4B1
(11) P1B2 (36) P2B2 (61) P3B2 (86) P4B2
(12) P1B3 (37) P2B3 (62) P3B3 (87) P4B3
(13) P1B4 (38) P2B4 (63) P3B4 (88) P4B4
(14) P1B5 (39) P2B5 (64) P3B5 (89) P4B5
(15) P1B6 (40) P2B6 (65) P3B6 (90) P4B6
(16) P1B7 (41) P2B7 (66) P3B7 (91) P4B7
(17) P1C0 (42) P2C0 (67) P3C0 (92) P4C0
(18) P1C1 (43) P2C1 (68) P3C1 (93) P4C1

(1) P1A0 (26) P2A0 (51) P3A0/EVENT (76) P4A0

(98)
(99)
(100)

(19) P1C2 (44) P2C2 (69) P3C2 (94) P4C2
(20) P1C3 (45) P2C3 (70) P3C3 (95) P4C3
(21) P1C4 (46) P2C4 (71) P3C4 (96) P4C4
(22) P1C5 (47) P2C5 (72) P3C5 (97) P4C5
(23) P1C6 (48) P2C6 (73) P3C6 (98) P4C6
(24) P1C7 (49) P2C7 (74) P3C7 (99) P4C7/EXTTRG
(25) GND (50) GND (75) GND (100) GND

Figure 2.3 Connectors Pin Assignment of PCI-7396

The DIO pin names are specified as PnXb, where
n : means the PPI number of the PCI-7396, n=1~4
X : means the port name of the PPI, X= ‘A’ , ‘B’ or ‘C’
b: means the bit number of the port, b=0~7
For example, P1C4 means bit 4 of port C on PPI1.

EXTTRG : External trigger signal to latch digital input data
EVENT : External event source for counter 0

GND : Ground

12 • Installation

JA1

2.7 Jumpers’ Description

The PCI-7396 is a ‘plug and play’ add-on card using PCI bus. It is un­necessary for user to setup its base address and IRQ level to fit the
hardware of your computer system. However, to fit users’ versatile operation,
there are still a few jumpers to set the power-on-states of all I/O ports.

2.7.1 Power-on-state

For all I/O ports of the PCI-7396, the power-on-states could be pulled high,
pulled low, or floating. It is depended on the jumper settings. Table 2.1 lists
the reference numbers of jumpers and their corresponding port names.

Jumper Port Name Jumper Port Name

JA1 P1A JA3 P3A
JB1 P1B JB3 P3B
JC1 P1C JC3 P3C
JA2 P2A JA4 P4A
JB2 P2B JB4 P4B
JC2 P2C JC4 P4C

Table 2.1 Jumpers and port names list

All the jumpers are identical physically. The power-on-state of each port can
be set independently. To pull all signals low is the default settings. The
following diagram use JA1 as an example to show the possible settings.

Port A of PPI1 is pulled low.(default setting)

JA1

Port A of PPI1 is pulled high.

When the jumper cap is removed, the power-on-state is floating.

Installation • 13

2.8 Termination Boards Supporting

PCI-7396 can be connected with several different daughter boards,
including DIN-100S, DIN-96DI, and DIN-96DO. The functionality and
connections are specified as follows.

2.8.1 Connect with DIN-100S

DIN-100S is a direct connector for the add-on card that is equipped with
SCSI-100 connector. It is suitable for the simple applications that do not
need isolated connection in front of the digital inputs or outputs of PCI-7396.

2.8.2 Connect with DIN-96DI

DIN-96DI digital input termination board features high-voltage opto-isolation
on all inputs to prevent floating potential and ground loop problems from
damaging your PC system. It is composed of one TB-96 base board, one
TB-96DI daughter board, and one DIN socket for easy maintenance, wiring,
and installation. It provides 96 channels that are accessed through a SCSI­100 connector.(see Appendix A1)

2.8.3 Connect with DIN-96DO

DIN-96DO digital output termination board features high-voltage opto­isolation on all outputs to prevent floating potential and ground loop
problems from damaging your PC system. It is composed of one TB-96
base board, one TB-96DO daughter board, and one DIN socket for easy
maintenance, wiring, and installation. It provides 96 channels that are
accessed through a SCSI-100 connector. (see Appendix A2).

14 • Installation

3

Registers Format

The detailed descriptions of the registers format are specified in this chapter.
This information is quite useful for the programmers who wish to handle the
card by low-level programming. However, we suggest user have to
understand more about the PCI interface then start any low-level
programming. In addition, the contents of this chapter can help users
understand how to use software driver to manipulate this card.

3.1 PCI PnP Registers

This PCI card functions as a 32-bit PCI target device to any master on the
PCI bus. There are three types of registers: PCI Configuration Registers
(PCR), Local Configuration Registers (LCR) and PCI-6308 registers.

The PCR, which is compliant to the PCI-bus specifications, is initialized and
controlled by the plug & play (PnP) PCI BIOS. User‘s can study the PCI
BIOS specification to understand the operation of the PCR. Please contact
with PCISIG to acquire the specifications of the PCI interface.

The PCI bus controller PCI-9050 is provided by PLX technology Inc.
(www.plxtech.com). For more detailed information of LCR, please visit PLX
technology’s web site to download relative information. It is not necessary
for users to understand the details of the LCR if you use the software library.
The PCI PnP BIOS assigns the base address of the LCR. The assigned
address is located at offset 14h of PCR.

The PCI-6308 registers are shown in the next section. The base address,
which is also assigned by the PCI PnP BIOS, is located at offset 18h of
PCR. Therefore, users can read the 18h of PCR to know the base address
by using the BIOS function call.

Registers Format • 15

Please do not try to modify the base address and interrupt which assigned
by the PCI PnP BIOS, it may cause resource confliction in your system.

16 • Registers Format

3.2 I/O Address Map

Most of the PCI-7396 registers are 32 bits. The users can access these
registers by 32 bits I/O instructions. The following table shows the registers
map, including descriptions and their offset addresses relative to the base
address.

Offset Write Read
0x00 P1ABC P1ABC

0x04 P1Control No used
0x08 P1EXTTRG Enable No used
0x0C P1EXTTRG Disable No used
0x10 P2ABC P2ABC
0x14 P2Control No used
0x18 P2EXTTRG Enable No used
0x1C P2EXTTRG Disable No used
0x20 P3ABC P3ABC
0x24 P3Control No used
0x28 P3EXTTRG Enable No used
0x2C P3EXTTRG Disable No used
0x30 P4ABC P4ABC
0x34 P4Control No used
0x38 P4EXTTRG Enable No used
0x3C P4EXTTRG Disable No used
0x40 Timer/Counter #0 Timer/Counter #0
0x44 Timer/Counter #1 Timer/Counter #1
0x48 Timer/Counter #2 Timer/Counter #2
0x4C Timer/Counter Mode Control Timer/Counter Mode Status
0x50 ISC: Interrupt Source Control No used
0x54 Clear Interrupt No used
0x60 P1 COS Control No used
0x64 P2 COS Control No used
0x68 P3 COS Control No used
0x6C P4 COS Control No used

Table 3.1 Register Map

Registers Format • 17

The PCI-7396 has 2/4 PPIs on board. Each PPI contains 5 registers,
including Digital Data Register, Control Register, External Trigger Enable
Register, External Trigger Disable Register, and COS Interrupt Control
Register.

In the following sections, the 5 registers of PPI1 will be introduced
respectively. The registers of the other 3 PPIs are of the same configuration
which will not be repeated in this manual.

3.3 Digital Data Registers

The 24-bit I/O data of the PCI-7396 is accessed from/to this register by
software. The digital data can also be read back through this register.

Address: BASE + 00h
Attribute: read and write
Data Format:

Bit 7 6 5 4 3 2 1 0
BASE+

00h
BASE+

01h
BASE+
02h
BASE+
03h

P1A7 P1A6 P1A5 P1A4 P1A3 P1A2 P1A1 P1A

0

P1B7 P1B6 P1B5 P1B4 P1B3 P1B2 P1B1 P1B

0

P1C7 P1C6 P1C5 P1C4 P1C3 P1C2 P1C1 P1C

0

X X X X X X X X

P1X7~P1X0: Digital I/O data X:A~C.

18 • Registers Format

3.4 Control Register

Each PPI’s control register is used to set its three ports to be as input or
output one independently.

Address: BASE + 04h
Attribute: write only
Data Format:

Bit 7 6 5 4 3 2 1 0
BASE+ 04h x x x x x P1C P1B P1A

BASE+ 05h x x x x x x x x
BASE+ 06h x x x x x x x x
BASE+ 07h x x x x x x x x

P1n : n: port number
Set to be ‘0’ for input port , ‘1’ for output port

3.5 External Trigger Enable Register

Users can write anything to this register to enable the external trigger to latch
the input data of port A,B and C simultaneously. Note that when this register
is enabled, the settings of the previous control register are disabled.

Address: BASE + 08h
Attribute: write only
Data Format:

Bit 7 6 5 4 3 2 1 0
BASE+08h x x x x x x x x

BASE+09h x x x x x x x x
BASE+0Ah x x x x x x x x

BASE+0Bh x x x x x x x x

Registers Format • 19

3.6 External Trigger Disable Register

Users can write anything to this register to disable the function of external
trigger.

Address: BASE + 0Ch
Attribute: write only
Data Format:

Bit 7 6 5 4 3 2 1 0
BASE+0Ch x x x x x x x x

BASE+0Dh x x x x x x x x

BASE+0Eh x x x x x x x x

BASE+0Fh x x x x x x x x

3.7 Change of State (COS) Control Register

This register is used to configure the COS interrupt.
Address: BASE + 60h

Attribute: write only
Data Format:

Bit 7 6 5 4 3 2 1 0
BASE+60h x x x x x P1C P1B P1A

BASE+61h x x x x x x x x
BASE+62h x x x x x x x x

BASE+64h x x x x x x x x
P1n : n: port number
Set to be ‘0’ to disable COS , ‘1’ to enable COS

20 • Registers Format

3.8 Interrupt Source Control (ISC) Register

The PCI-7396 has a dual interrupt system, two interrupt sources can be
generated and be distinguished by software setting. This register is used to
select the interrupt sources.

Address: BASE + 50h
Attribute: write only
Data Format:

Bit 7 6 5 4 3 2 1 0

BASE+50h x x x x C2_1 C2_0 C1_1 C1_

0
BASE+51h x x x x x x x x
BASE+52h x x x x x x x x
BASE+54h x x x x x x x x

C1_0,C1_1 : Select source INT 1
C2_0,C2_1 : Select source INT 2

INT1 C1_1 C1_0 IRQ Sources IRQ Trigger Condition
Mode 1 0 0 COS P1&P2 (48bits) Change of State for PCI-

7396 P1 & P2
Mode 2 0 1 P1C0 OR ~P1C3 (see Table 4.2)
Mode 3 1 0 ~P1C0 falling edge of P1C0
Mode 4 1 1 Event Counter Counter count down to 0
INT2 C2_1 C2_0 IRQ Sources IRQ Trigger Condition

Mode 1 0 0 COS P3&P4(48bits) Change of State for PCI-

7396 P3 & P4
Mode 2 0 1 P2C0 OR ~P2C3 (see Table 4.2)
Mode 3 1 0 ~P2C0 falling edge of P2C0
Mode 4 1 1 32-bit Timer Timer count down to 0

Registers Format • 21

3.9 Clear Interrupt Register

Users can write anything to this register to clear the interrupt request of the
PCI-7396.

Address: BASE + 54h
Attribute: write only
Data Format:

Bit 7 6 5 4 3 2 1 0
BASE+54h x x x x x x x x

BASE+55h x x x x x x x x
BASE+56h x x x x x x x x
BASE+57h x x x x x x x x

3.10 Timer/Counter Register

The 8254 chip occupies 4 I/O addresses in the PCI-7396. Please refer to
NEC's or Intel's data sheet for the full description of the 8254 operation.

Address : BASE + 40h ~ BASE + 4Ch
Attribute : read / write
Data Format :

Base + 40h Bit 7~Bit 0: Counter 0 Register
Base + 44h Bit 7~Bit 0: Counter 1 Register
Base + 48h Bit 7~Bit 0: Counter 2 Register
Base + 4Ch Bit 7~Bit 0: Control Register

3.11 High Level Programming

To operate the PCI-7396 quickly, you can bypass the detailed register
structures and use the high-level application programming interface (API)
directly. The DOS library for Borland C/C++ is included in the ADLINK CD.
Please refer to chapter 5 for more detailed information.

22 • Registers Format

INPUT

4

Operation Theorem

The operation theorem of the functions on PCI-7396 card is described in
this chapter. The operation theorem can help you to understand how to
manipulate or to program the PCI-7396.

4.1 Digital I/O Ports

4.1.1 Introduction

The PCI-7396 has 2/4 PPIs on board. Each 24-bit PPI is divided into three
8-bit I/O ports: A, B, and C. All of these 6/12 ports can be programmed as
input or output independent.

4.1.2 External Trigger

The pin-99 EXTTRG support user to receive an external trigger to latch
input data. User can use function _7396_Set_Event_Edge to set EXTTRG
pin to be active high or active low.

EXTTR

Read Data

Figure 4.1 External Trigger Function Block

Edge

DATA to PC

Operation Theorem • 23

Read Data (Read date from registers

atch input data to

EXTTRG

Latch Data (L

Figure 4.2 Read Data use External Trigger

24 • Operation Theorem

8254 Chip

4.2 8254 Timer/Counter Operation

4.2.1 Introduction

One 8254 programmable timer/counter chip is installed in the PCI-7396.
There are three counters in one 8254 chip and 6 possible operation modes
for each counter. The block diagram of the timer /counter system is shown in
Figure 4.3.

EVENT
(PIN 51)

Event Edge
Control

Gate='H'

Counter #0

Event IRQ

2 MHz Clock

Gate='H'

Gate='H'

Timer #1

Timer #2

Timer IRQ

Figure 4.3 Timer / counter system of PCI-7396.

Timer #1 and timer #2 of the 8254 chip are cascaded as a 32-bits
programmable timer. In the software library, timer #1 and #2 are always set
as mode 2 (rate generator). Counter #0 is used as an event counter, that is,
there is an interrupt on the terminal count of 8254 mode 0.

4.2.2 Cascaded 32 bits Timer

The base frequency of input clock for the cascaded timer is 2MHz. The
output is send to be the timer interrupt. To set the maximum and minimum
frequency of the timer, please refer to the function _7348_Cascaded_Timer
or _7396_Cascaded_Timer.

4.2.3 Event Counter and Edge Control

The counter #0 of 8254 is used to be an event counter. The input is pin-51
of CN1. The trigger edge of counter clock is programmable. The gate
control fixs high (enable). The output is send to be the event interrupt. That
means If counter #0 is set as 8254 mode 0, the event IRQ asserts as the
counter counts down to zero.

Operation Theorem • 25

4.3 Interrupt Circuit

4.3.1 System Architecture

The PCI-7396‘s interrupt system is powerful and flexible, which is suitable
for many applications. It is a Dual Interrupt System. The dual interrupt
means the hardware can generate two interrupt request signals in the same
time and the software can service these two request signals by ISR. Note
that the dual interrupt do not mean the card occupy two IRQ levels.

The two interrupt request signals (INT1 and INT2) comes from digital inputs
or the timer/counter outputs. Two multiplexers (MUX) are used to select the
IRQ sources. Fig 4.4 shows the interrupt system.

4.3.2 IRQ Level Setting

There is only one IRQ level needed in the PCI-7396, although it is a dual
interrupt system. This card uses INT #A interrupt request signal on PCI bus.
The mother board circuits will transfer INT #A to one of the AT bus IRQ
levels. The IRQ level is set by the PCI plug and play BIOS and saved in the
PCI controller. It is not necessary for users to set the IRQ level. Users can
get the IRQ level by software library.

26 • Operation Theorem

P1C0/~P1C3

COS P1 & P2

Event IRQ

Timer IRQ

~P1C0

4.3.3 Dual Interrupt System

The PCI controller can receive two hardware IRQ requests. However, only
one IRQ will be sent to PCI bus, the two IRQ requests must be
distinguished by user’s interrupt service routine (ISR).

The two IRQ requests are named as INT1 and INT2. INT1 comes from COS
P1 & P2, P1C0, P1C3, or the event counter interrupt. INT2 comes from
COS P3 & P4, P2C0, P2C3, or the timer interrupt. The sources of INT1 and
INT2 is selectable by using the Interrupt Source Control (ISC) Register.

INT1
MUX

INT2
MUX

P2C0/~P2C

COS P3 & P4

INT #A

PCI
Controller

Clear IRQ

Figure 4.4 Dual Interrupt System of PCI-7396

INT2

IRQ
Flip­Flops

Operation Theorem • 27

4.3.4 Interrupt Source Control (ISC)

There are four bits to control the IRQ sources of INT1 and INT2. Table 4.1
shows the selection of the IRQ sources and the interrupt trigger condition.

If the application needs one IRQ only, you can disable one of the IRQ
sources by software. You can also disable both the two interrupts If you do
not need any IRQ source. However, the PCI BIOS still assign a IRQ level to
the PCI card and occupy the PC resource if you only disable the IRQ
sources without change the initial condition of the PCI controller.

INT1 C1 C2 IRQ Sources IRQ Trigger Condition
Disable 4 X INT1 disable --

Mode 1 0 X COS P1&P2 (48bits) Change of State for PCI-7396
Mode 2 1 X P1C0 OR ~P1C3 (see following)
Mode 3 2 X ~P1C0 falling edge of P1C0
Mode 4 3 X Event Counter Counter count down to 0
INT2 C1 C2 IRQ Sources IRQ Trigger Condition

Disable X 4 INT2 disable -­Mode 1 X 0 COS P3&P4 (48bits) Change of State for PCI-7396
Mode 2 X 1 P2C0 OR ~P2C3 (see following)
Mode 3 X 2 ~P2C0 falling edge of P2C0
Mode 4 X 3 Timer Output Timer count down to 0

Table 4.1 ISC register format

Default settings

When the IRQ sources is set as “P1C0 OR ~P1C3” or “P2C0 OR ~P2C3”,
the IRQ trigger conditions are summarized in Table 4.2,

P1C0 P1C3 IRQ Trigger Condition
High X P1C0=‘H’ disable all IRQ
X Low P1C3=‘L’ disable all IRQ
Low 1->0 P1C3 falling edge trigger when P1C0=L
0->1 High P1C0 rising edge trigger when P1C3=H
P2C0 P2C3 IRQ Trigger Condition
High X P2C0=‘H’ disable all IRQ
X Low P2C3=‘L’ disable all IRQ
Low 1->0 P2C3 falling edge trigger when P2C0=L
0->1 High P2C0 rising edge trigger when P2C3=H

Table 4.2 IRQ Trigger conditions

28 • Operation Theorem

P1A0

By using the four signals: P1C0, P2C0, P1C3, and P2C3, user can utilize
their combination to generate a proper IRQ for versatile applications.

4.3.5 Change of State (COS) Interrupt

What is COS?

The COS (Change of State) means when the input state (logic level) is
changed from low to high, or from high to low. The COS detection circuit will
detect the edge of level change. In the PCI-7396 card, the COS detection
circuit is applied to all the input channels. When any channel changes its
logic level, the COS detection circuit generates an interrupt request to PCI
controller.

COS Detection

The following timing is an example of COS operation. All the DI signals’ level
change will be detected and then take an ‘OR’ operation to generate the
INT1 or INT2 IRQ request.

If INT1 or INT2 IRQ request generates, the signal will be latched. User
should apply the function “_7396_CLR_IRQ” or “_7348_CLR_IRQ” to reset
its state, after the corresponding ISR is finished,

P2A0
COS

CO

INT1

Clear_IRQ Clear_IRQ Clear_IRQ

Operation Theorem • 29

4.4 12V and 5V Power Supply

The SCSI-100 connector CN1 provides +12V and +5V power supply (only
for PCI-7348) for external devices. To avoid the short circuit or the overload
of the power supply, the resettable fuses are added on all the power
supply signals.

The maximum current for 5V power supply is 0.5 A. If the load current is
larger than this limitation, the resistance of the resettable fuse will increase
for the reason of the rising temperature. The rising resistance will further
cause the power supply to reduce the load current. After the condition of
overload or short circuit is removed, the fuse will return to its normal
condition. It is unnecessary to replace the fuse.

The maximum current of 12V power supply is 0.5A, too. The action of the
fuse is the same as that of +5V power supply.

30 • Operation Theorem

5

C/C++ Libraries

This chapter describes the software library for operating this card. Only the
functions in DOS library and Windows 95 DLL are described. Please refer to
the PCIS-DASK function reference manual, which included in ADLINK CD,
for the descriptions of the Windows 98/NT/2000 DLL functions.

The function prototypes and some useful constants are defined in the
header files LIB directory (DOS) and INCLUDE directory (Windows 95). For
Windows 95 DLL, the developing environment can be Visual Basic 4.0 or
above, Visual C/C++ 4.0 or above, Borland C++ 5.0 or above, Borland
Delphi 2.x (32-bit) or above, or any Windows programming language that
allows calls to a DLL. It provides the C/C++, VB, and Delphi include files.

5.1 Libraries Installation

Please refer to the “Software Installation Guide” for the detail information
about how to install the software libraries for DOS, or Windows 95 DLL, or
PCIS-DASK for Windows 98/NT/2000.

The device drivers and DLL functions of Windows 98/NT/2000 are included
in the PCIS-DASK. Please refer the PCIS-DASK user’s guide and function
reference, which included in the ADLINK CD, for detailed programming
information.

C/C++ Libraries • 31

5.2 Programming Guide

precision

precision

3.402823E38 to

precision

1.797683134862315E308 to

5.2.1 Naming Convention

The functions of the NuDAQ PCI cards or NuIPC CompactPCI cards’
software driver are using full-names to represent the functions' real meaning.
The naming convention rules are:

In DOS Environment :
_{hardware_model}_{action_name}. e.g. _7396_Initial().

In order to recognize the difference between DOS library and Windows 95
library, a capital "W" is put on the head of each function name of the
Windows 95 DLL driver. e.g. W_7396_Initial().

5.2.2 Data Types

We defined some data type in Pci_7396.h (DOS) and Acl_pci.h (Windows

95). These data types are used by NuDAQ Cards’ library. We suggest you to
use these data types in your application programs. The following table
shows the data type names and their range.

Type Name

U8 8-bit ASCII character 0 to 255

I16 16-bit signed integer -32768 to 32767

U16 16-bit unsigned integer 0 to 65535

I32 32-bit signed integer -2147483648 to 2147483647

U32

F32

F64

Boolean Boolean logic value TRUE, FALSE

32 • C/C++ Libraries

Description Range

32-bit single­floating-point

32-bit single­floating-point

64-bit double­floating-point

0 to 4294967295

-

3.402823E38

-

1.797683134862315E309

5.3 _7396_Initial

@ Description

This function is used to initialize the PCI-7396. Every PCI-7396 has to be
initialized by this function before calling other functions.

@ Syntax

C/C++ (DOS)

U16 _7396_Initial (U16 *existCards, PCI_INFO *pciInfo)

C/C++ (Windows 95)

U16 W_7396_Initial (U16 *existCards, PCI_INFO *pciInfo)

Visual Basic (Windows 95)

W_7396_Initial (existCards As Integer, pciInfo As PCI_INFO) As
Integer

@ Argument

existCards: The numbers of installed PCI-7396 cards. The

pciinfo: It is a structure to memorize the PCI bus plug and

@ Return Code

ERR_NoError
ERR_PCIBiosNotExist

returned value shows how many PCI-7396 cards are
installed in your system.

play initialization information which is decided
by P&P BIOS. The PCI_INFO structure is defined in
ACL_PCI.H. The base I/O address and the interrupt
channel number is stored in this variable.

C/C++ Libraries • 33

5.4 _7396_DI

@ Description

This function is used to read the 24-bit digital inputs data from the input port of
the PCI-7396.The written data and read in data is 24 bits data. Each data is
mapped to a signal as the table below.

D7 D6 D5 D4 D3 D2 D1 D0
PA7 PA6 PA5 PA4 PA3 PA2 PA1 PA0
D15 D14 D13 D12 D11 D10 D9 D8
PB7 PB6 PB5 PB4 PB3 PB2 PB1 PB0
D23 D22 D21 D20 D19 D18 D17 D16
PC7 PC6 PC5 PC4 PC3 PC2 PC1 PC0

@ Syntax

C/C++ (DOS)

U16 _7396_DI (U16 cardNo, U16 channelPort, U32 *diData)

C/C++ (Windows 95)

U16 W_7396_DI (U16 cardNo, U16 channelPort, U32 *diData)

Visual Basic (Windows 95)

W_7396_DI (ByVal cardNo As Integer, ByVal channelPort As Integer,
diData As Integer) As Integer

@ Argument

cardNo: The card number of PCI7396 card initialized.
channelPort: port of each channel
P1_A : CH1’s Port A
P1_B : CH1’s Port B
P1_C : CH1’s Port C
P1_ABC: CH1’s Port A ,Port B ,Port C
P2_A : CH2’s Port A
P2_B : CH2’s Port B
P2_C : CH2’s Port C
P2_ABC: CH2’s Port A ,Port B ,Port C

(The following items are for PCI-7396 only.)
P3_A : CH3’s Port A
P3_B : CH3’s Port B
P3_C : CH3’s Port C
P3_ABC: CH3’s Port A ,Port B ,Port C
P4_A : CH4’s Port A
P4_B : CH4’s Port B
P4_C : CH4’s Port C
P4_ABC: CH4’s Port A ,Port B ,Port C
diData: returned 24-bit value from digital port.

34 • C/C++ Libraries

@ Return Code

ERR_NoError

C/C++ Libraries • 35

5.5 _7396_DO

@ Description

This function is used to write data to digital output ports. There are 6 ports
(P1A, P1B, P1C, P2A, P2B, P2C) could be configured as digital outputs on
the PCI-7348. And there are totally 12 digital output ports (P1A, P1B, P1C,
P2A, P2B, P2C, P3A, P3B, P3C, P4A, P4B, P4C) could be configured as
digital outputs on the PCI-7396.

@ Syntax

C/C++ (DOS)

U16 _7396_DO (U16 cardNo, U16 channelPort, U32 doData)

C/C++ (Windows 95)

U16 W_7396_DO (U16 cardNo, U16 channelPort, U32 doData)

Visual Basic (Windows 95)

W_7396_DO (ByVal cardNo As Integer, ByVal channelPort As Integer,
ByVal doData As Integer) As Integer

@ Argument

cardNo : The card number of PCI7396 card initialized.
channelPort: The same as the arguments in the previous section.
doData : value will be written to digital output port

@ Return Code

ERR_NoError

36 • C/C++ Libraries

5.6 _7396_Config_Port

@ Description

This function is used to configure the Input or Ouput of each Port. Each I/O
Port of PCI-7396 is either input or output, so it has to configure as input or
output before I/O operations are applied.

@ Syntax

C/C++ (DOS)

U16 _7396_Config_Port (U16 cardNo, int ctrlValue)

C/C++ (Windows 95)

U16 W_7396_Config_Port (U16 cardNo, int ctrlValue)

Visual Basic (Windows 95)

W_7396_Config_Port (ByVal cardNo As Integer, ByVal channelPort
As Integer, ByVal direction As Integer) As Integer

@ Argument

cardNo : The card number of PCI7396 card initialized.
ctrlValue :
P1ARD : CH1’s Port A input port
P1BRD : CH1’s Port B input port
P1CRD : CH1’s Port C input port
P1RD : CH1’s Port A,B,C input port
E_P1RD : CH1’s Port A,B,C input port use external clock to

P1AWR : CH1’s Port A output port
P1BWR : CH1’s Port B output port
P1CWR : CH1’s Port C output port
P1WR : CH1’s Port A,B,C output port
P2ARD : CH2’s Port A input port
P2BRD : CH2’s Port B input port
P2CRD : CH2’s Port C input port
P2RD : CH2’s Port A,B,C input port
E_P2RD : CH2’s Port A,B,C input port use external clock

P2AWR : CH2’s Port A output port
P2BWR : CH2’s Port B output port
P2CWR : CH2’s Port C output port
P2WR : CH2’s Port A,B,C output port

P3ARD : CH3’s Port A input port
P3BRD : CH3’s Port B input port
P3CRD : CH3’s Port C input port
P3RD : CH3’s Port A,B,C input port
E_P3RD : CH3’s Port A,B,C input port use external clock to

P3AWR : CH3’s Port A output port
P3BWR : CH3’s Port B output port

latch data

to latch data

latch data

C/C++ Libraries • 37

P3CWR : CH3’s Port C output port
P3WR : CH3’s Port A,B,C output port

P4ARD : CH4’s Port A input port
P4BRD : CH4’s Port B input port
P4CRD : CH4’s Port C input port
P4RD : CH4’s Port A,B,C input port
E_P4RD : CH4’s Port A,B,C input port use external clock to

P4AWR : CH4’s Port A output port
P4BWR : CH4’s Port B output port
P4CWR : CH4’s Port C output port
P4WR : CH4’s Port A,B,C output port

latch data

@ Return Code

ERR_NoError

38 • C/C++ Libraries

5.7 _7396_Software_Reset

@ Description

This function is used to reset the I/O port configuration. After resetting PCI­7396, all ports will be set as input ones. Note that this function will not re-start
the PCI bus and all the hardware settings will not be changed, neither.

@ Syntax

C/C++ (DOS)

U16 _7396_Software_Reset (U16 cardNo)

C/C++ (DOS, Windows 95)

U16 W_7396_Software_Reset (U16 cardNo)

Visual Basic (Windows 95)

W_7396_Software_Reset (ByVal cardNo As Integer) As Integer

@ Argument

cardNo : The card number of PCI7396 card initialized.

@ Return Code

ERR_NoError

C/C++ Libraries • 39

5.8 _7396_INT_Source_Control

@ Description

The PCI-7396 has dual interrupts system, two interrupt sources can be
generated and be checked by software. This function is used to select and
control PCI-7396’s interrupt sources by writing associated data to interrupt
control register.

@ Syntax

C/C++ (DOS)

void _7396_INT_Source_Control (U16 cardNo, U16 c1, U16 c2)

C/C++ (Windows 95)

void W_7396_INT_Source_Control (U16 cardNo, U16 c1, U16 c2)

Visual Basic (Windows 95)

W_7396_INT_Source_Control (ByVal cardNo As Integer, ByVal c1 As
Integer, ByVal c2 As Integer)

@ Argument

cardNo : The card number of PCI7396 card initialized.

c1 : INT1# interrupt source
c2 : INT2# interrupt source

For the C1,C2 settings, please refer to Table3.3.1

@ Return Code

ERR_NoError

40 • C/C++ Libraries

5.9 _7396_COSIRQ_Control

@ Description

This function is used to programe every channel port A,B,C‘s COS is enable or
disable.

@ Syntax

C/C++ (DOS)

void _7396_COSIRQ_Control (U16 cardNo, int ch_no, int A, Int B,
int C)

C/C++ (Windows 95)

void W_7396_COSIRQ_Control (U16 cardNo, int ch_no, int A, Int B,
int C)

Visual Basic (Windows 95)

W_7396_COSIRQ_Control (ByVal cardNo As Integer, ByVal ch_no As
Integer, ByVal A As Integer, ByVal B As Integer, ByVal C As
Integer)

@ Argument

cardNo: The card number of PCI7396 card initialized.
ch_no :channel number set 1 or 2 or 3 or 4
A: port A control (enable set 1,disable set 0)
B: port B control (enable set 1,disable set 0)
C: port C control (enable set 1,disable set 0)

@ Return Code

ERR_NoError

C/C++ Libraries • 41

5.10 _7396_CLR_IRQ

@ Description

This function is used to clear the interrupt request of PCI-7396.

@ Syntax

C/C++ (DOS)

void _7396_CLR_IRQ (U16 cardNo)

C/C++ (Windows 95)

void W_7396_CLR_IRQ (U16 cardNo)

Visual Basic(Windows 95)

W_7396_CLR_IRQ (ByVal cardNo As Integer)

@ Argument

cardNo : The card number of PCI7396 card initialized.

@ Return Code

None

42 • C/C++ Libraries

5.11 _7396_Set_Event_Edge

@ Description

This function is used to set the edge trigger of event signal (Pin51) and
external trigger signal (Pin99). The following table shows the possible settings.

Set_Event_Edge C0 0 1
External Trigger (Pin99) Active Low Active High

Event (Pin51)

Rising Edge
Count

@ Syntax

C/C++ (DOS)

U16 _7396_Set_Event_Edge (U16 cardNo, U16 *c0)

C/C++ (Windows 95)

U16 W_7396_Set_Event_Edge (U16 cardNo, U16 *c0)

Visual Basic (Windows 95)

W_7396_ Set_Event_Edge (ByVal cardNo As Integer, c0 As Integer)
As Integer

@ Argument

cardNo :The card number of PCI7396 card initialized.
c0: The event signal and external clock signal setting.

@ Return Code

ERR_NoError

Falling Edge
Count

C/C++ Libraries • 43

5.12 _7396_Cascaded_Timer

@ Description

The function is used to program the timer#1 & timer#2 of 8254, the 32bit timer,
to generate the timer interrupt .

@ Syntax

C/C++ (DOS)

U16 _7396_Cascaded_Timer (U16 *existCards, U16 c1, U16 c2)

C/C++ (Windows 95)

U16 W_7396_Cascaded_Timer (U16 *existCards, U16 c1, U16 c2)

Visual Basic (Windows 95)

W_7396_Initial (existCards As Integer, ByVal c1 As Integer,
ByVal c2 As Integer)

@ Argument

cardNo : The card number of PCI7396 card initialized.
c1 : frequency divider of timer #1
c2 : frequency divider of timer #2
About the settings of C1 & C2, please refer to section 3.2.2

@ Return Code

ERR_NoError
ERR_PCIBiosNotExist

44 • C/C++ Libraries

5.13 _7396_Timer_Start

@ Description

The function is used to program the timer#0 of 8254, 16bit timer, to generate
the event interrupt .

@ Syntax

C/C++ (DOS, Windows 95)

U16 _7396_Timer_Start (U16 *existCards, U16 timer_mode, U16 c0)

C/C++ (DOS, Windows 95)

U16 W_7396_Timer_Start (U16 *existCards, U16 timer_mode, U16 c0)

Visual Basic (Windows 95)

W_7396_Initial (existCards As Integer, ByVal timer_mode As
Integer, ByVal c0 As Integer)

@ Argument

cardNo: The card number of PCI7396 card initialized.
timer_mode: 8254 operating mode
c0: frequency divider of timer #0

@ Return Code

ERR_NoError
ERR_PCIBiosNotExist

C/C++ Libraries • 45

5.14 _7396_Timer_Read

@ Description

This function is used to read the counter value of the Counter#0.

@ Syntax

C/C++ (DOS)

U16 _7396_Timer_Read (U16 cardNo, U16 *c0)

C/C++ (Windows 95)

U16 W_7396_Timer_Read (U16 cardNo, U16 *c0)

Visual Basic (Windows 95)

W_7396_Timer_Read (ByVal cardNo As Integer, c0 As Integer) As
Integer

@ Argument

cardNo : The card number of PCI7396 card initialized.
c0: count value of counter#0

@ Return Code

ERR_NoError

46 • C/C++ Libraries

Appendix 1 DIN-96DI

A1.1 Introductions

DIN-96DI digital input termination board features high-voltage opto-isolation
on all inputs to prevent floating potential and ground loop problems from
damaging your PC system. It is composed of one TB-96 base board, one
TB-96DI daughter board, and one DIN socket for easy maintenance, wiring,
and installation. It provides 96 channels that are accessed through a SCSI­100 connector.

A1.2 Features

u 96 Opto-Isolated digital input channels
u For use with the PCI-7396
u AC or DC polarity-free digital input
u Screw terminals for easy field wiring

A1.3 Specifications

u Numbers of channel: 96
u Opto-isolator: PC3H4
u Input impedance: 4.7K Ohms
u Input voltage range: 0~24VDC
u Threshold voltage:

w 20VDC for 24V PS
w 8.8VDC for 12V PS
w 1.8VDC for 5V PS

u Isolation voltage: 2,500 Vdc channel-to-ground
u Connector: 100-Pin SCSI-type connector
u Dimensions: 112.7 mm x 225.0 mm
u Operating temp.: 0° ~ 60°C
u Storage temp.: -20° ~ 80°C
u Humidity: 5~95%, non-condensing

Appendix 1 DIN-96DI • 47

u Power consumption:

w 490mA(max.) for 24V PS
w 250mA(max.) for 12V PS
w 102mA(max.) for 5V PS

48 • Appendix 1 DIN-96DI

A1.4 Layout of DIN-96DI

CN1

PG P G G

52515049

.........

GP G P P

464748GG

.........

.........

X
3

X
2

TB-96DI

X
4

X
1

..................

94 95 96 G G

.........

G PGPP

TB96

.........

.........

P GPGG

12345 12345

Appendix 1 DIN-96DI • 49

Legend:

2.4K Ohm

JPxx

Vcc

CN1 : SCSI II 100 pin connector to connect PCI-7396 and DIN-96DI
X1~X4 : 50 pin Opto-22 connectors to connect TB96 and Tb96DI
n(1~96) : Input signal n
G : External ground
P : External power (5~24V)

A1.5 DI Circuits and Wiring

The outputs of the opto-isolated digital input circuits are open collector
transistors. PCI-7396 should provide pull-high resistors by correct jumper
setting. The connection between outside signal and PCI-7396 as well as the
jumper setting are shown below.

Power 24V

PCI-7396
DIn

Input

Figure A1.1: opto-isolated input circuit

PCI-7396
DIn

TTL Device

Figure A1.2: PCI-7396 jumper setting for DIN-96DI

50 • Appendix 1 DIN-96DI

Appendix 2 DIN-96DO

A2.1 Introductions

DIN-96DO digital output termination board features high-voltage opto­isolation on all outputs to prevent floating potential and ground loop
problems from damaging your PC system. It is composed of one TB-96
base board, one TB-96DO daughter board, and one DIN socket for easy
maintenance, wiring, and installation. It provides 96 channels that are
accessed through a SCSI-100 connector.

A2.2 Features

u 96 Opto-Isolated digital output channels
u For use with the PCI-7396
u On-board relay driver circuitry
u Screw terminals for easy field wiring

A2.3 Specifications

u Numbers of channel: 96
u Opto-isolator: PC3H7
u Output type: Darlingtoin transistors, open collector up to 35Vdc
u Sink current:

w 350mA max.@ 100% duty, one of transistors device ON
w 370mA @ duty 10% for all transistors devices ON
w 140mA @ duty 50% for all transistors devices ON
w 60mA @ duty 100% for all transistors devices ON

u Isolation voltage: 2500 Vrms
u Dimensions: 112.7 mm x 225.0 mm
u Operating temp.: 0° ~ 60°C
u Storage temp.: -20° ~ 80°C
u Humidity: 5~95%, non-condensing
u Power consumption:

Appendix 2 DIN-96DO • 51

w 4.294A(max.) for 24VPS
w 4.244A(max.) for 12VPS
w 4.215A(max.) for 12VPS
w 102mA(max.) from cable

52 • Appendix 2 DIN-96DO

A2.4 Layout of DIN-96DO

52515049

.........

PG P G G

.........

X
3

X
4

.........

94 95 96 G G

.........

G PGPP

CN1

TB-96DO

TB96

GP G P P

464748GG

.........

.........

X
2

X
1

.........

.........

P GPGG

12345 12345

Appendix 2 DIN-96DO • 53

Legend:

DD

V

GND

CN1 : SCSI II 100 pin connector to connect PCI-7396 and DIN-96DO
X1~X4 : 50 pin Opto-22 connectors to connect TB96 and Tb96DO
n(1~96) : Output signal n
G : External ground
P : External power (5~24V)

A2.5 Circuits and Wiring

The connection of isolated digital output is shown as the following diagram.
The DIN-96DO need external 5~24V DC power from the POWER pin to
provide the power source of the digital output circuit. The POWER pin is
used as “fly-wheel” diode, which can protect the driver if the loading is
inductance loading such as relay, motor or solenoid. If the loading is
resistance loading such as resistor or LED, the connection to fly-wheel diode
is not necessary.

Therefore, the first step for connecting the output with external device is to
distinguish the type of loading. For example, if the loading is LED or resistor,
you can use the following wiring diagram.

Power

Resistive

Loading

+

-

-

5~24V

Figure A2.1: opto-isolated output circuit for resistance loading

54 • Appendix 2 DIN-96DO

DD

V

Loading

If the loading is a inductance loading such as relay, you can use the following
wiring diagram. The POWER must connect to the external power to form a
fly-wheel current loop.

Power

Inductance

+

-

-

5~24V

GND

Figure A2.2: opto-isolated output circuit for inductance loading

Appendix 2 DIN-96DO • 55

Warranty Policy

Thank you for choosing ADLINK. To understand your rights and enjoy all
the after-sales services we offer, please read the following carefully.

1. Before using ADLINK’s products, please read the user manual
and follow the instructions exactly. When sending in damaged
products for repair, please attach an RMA application form.

2. All ADLINK products come with a two-year guarantee,free of
repair charge.

• The warranty period starts from the product’s shipment date

from ADLINK’s factory

• Peripherals and third-party products not manufactured by

ADLINK will be covered by the original manufacturers’
warranty

• End users requiring maintenance services should contact their

local dealers. Local warranty conditions will depend on the
local dealers3. Our repair service does not cover two-year

guarantee while damages are caused by the following:

a. Damage caused by not following instructions on user menus.
b. Damage caused by carelessness on the users’ part during

product transportation.

c. Damage caused by fire, earthquakes, floods, lightening, pollution

and incorrect usage of voltage transformers.

d. Damage caused by unsuitable storage environments with high

temperatures, high humidity or volatile chemicals.

e. Damage caused by leakage of battery fluid when changing

batteries.

f. Damages from improper repair by unauthorized technicians.
g. Products with altered and damaged serial numbers are not entitled

to our service.

h. Other categories not protected under our guarantees.4.

Customers are responsible for the fees regarding transportation
of damaged products to our company or to the sales office.

56 • Warranty Policy

5. To ensure the speed and quality of product repair, please
download an RMA application form from our company website

www.adlinktech.com. Damaged products with RMA forms

attached receive priority.

For further questions, please contact our FAE staff.
ADLINK: [e-mail]
Test & Measurement Product Segment: [e-mail]
Automation Product Segment: [e-mail]
Computer & Communication Product Segment: [e-mail] ;

[e-mail]

Warranty Policy • 57
