ADLINK PCI-7300A User Manual

NuIPC



/ NuDAQ

cPCI-7300A & PCI -7300A

80MB Ultra-High Speed 32-CH

Digital I/O Boards

User’s Guide

Recycle Paper

Copyright 2002 ADLINK Technology Inc.
All Rights Reserved.

Manual Rev 2.22: July 16, 2002

Part No.: 50-11106-100

The information in this document is subject to change without prior notice in
order to improve reliability, design and function and does not represent a
commitment on the part of the manufacturer.

In no event will the manufacturer be liable for direct, indirect, special,
incidental, or consequential damages arising out of the use or inability to
use the product or documentation, even if advised of the possibility of such
damages.

This document contains proprietary information protected by copyright. All
rights are reserved. No part of this manual may be reproduced by any
mechanical, electronic, or other means in any form without prior written
permission of the manufacturer.

Trademarks

NuDAQ, NuIPC, DAQBench are registered trademarks of ADLINK
Technology Inc.,

Other product names mentioned herein are used for identification purposes
only and may be trademarks and/or registered trademarks of their
respective companies.

Getting service from ADLINK

• Customer Satisfaction is the most important priority for ADLINK Tech Inc. If
you need any help or service, please contact us.

ADLINK Technology Inc.

Web Site http://www.adlinktech.com

Sales &
Service

NuDAQ + USBDAQ [e-mail]

Technical

Support

TEL [phone] FAX [phone]

Address 9F, No. 166, Jian Yi Road, Chungho City, Taipei, 235 Taiwan.

Automation [e-mail]

NuIPC [e-mail]

NuPRO / EBC [e-mail]

• Please email or FAX us of your detailed information for a prompt,

satisfactory and constant serv ice.

Detailed Company Information

Com pany/Organization

Contact Person
E -mail Address
Address
Country
TEL FAX
Web Site

Product Model

OS:
Computer Brand:
M/B: CPU:

Environment to Use

Detail Description
Suggestions to ADLINK

Chipset: BIOS:
Video Card:
Network Interface Card:
Other:

[e-mail]

Questions

Table of Contents

Introduction...............................................................................1

1.1 APPLICATIONS...............................................................................................2

1.2 FEATURES .....................................................................................................2

1.3 SPECIFICATIONS ........................................................................................... 3

1.4 SOFTWARE SUPPORTING..............................................................................5

1.4.1 Programming Library .................................................................5

1.4.2 PCIS-LVIEW: LabVIEW® Driver..............................................5

1.4.3 PCIS-VEE: HP-VEE Driver......................................................6

1.4.4 DAQBenchTM: ActiveX Controls..............................................6

Installation.................................................................................7

2.1 WHAT YOU HAVE..........................................................................................7

2.2 UNPACKING...................................................................................................8

2.3 DEVICE INSTALLATION FOR WINDOWS SYSTEMS .........................................8

2.4 PCI-7300A'S LAYOUT..................................................................................9

2.5 HARDWARE INSTALLATION OUTLINE...........................................................11

2.6 CONNECTOR PIN ASSIGNMENT...................................................................12

2.7

WIRING AND TERMINATION ........................................................................14

2.8

DAUGHTER BOARD SUPPORTING ..............................................................15

2.8.1 Connect with DIN-100S..........................................................15

2.8.2 Connect with DIN-502S..........................................................15

Registers..................................................................................16

3.1 I/O PORT BASE ADDRESS ..........................................................................17

3.2 DI_CSR: DI CONTROL & STATUS REGISTER ...........................................18

3.3 DO_CSR: DO CONTROL & STATUS REGISTER .......................................19

3.4 AUXILIARY DIGITAL I/O REGISTER ..............................................................21

3.5 INT_CSR: INTERRUPT CONTROL AND STATUS REGISTER .......................21

3.6 DI_FIFO: DI FIFO DIRECT ACCESS PORT ................................................22

3.7 DO_FIFO: DO EXTERNAL DATA FIFO DIRECT ACCESS PORT ..................23

3.8 FIFO_CR: FIFO ALMOST EMPTY /FULL REGISTER.....................................24

3.9 POL_CNTRL: CONTROL SIGNAL POLARITY CONTROL REGISTER ..........24

3.10

PLX PCI -9080 DMA CONTROL REGISTERS...........................................25

Operation Theory ....................................................................26

4.1 I/O CONFIGURATION ...................................................................................26

4.2 BLOCK DIAGRAM.........................................................................................27

Table of Contents • i

4.3 DIGITAL I/O DATA FLOW .............................................................................28

4.4 INPUT FIFO AND OUTPUT FIFO................................................................29

4.5 BUS-MASTERING DMA...............................................................................30

4.6 SCATTER/GATHER DMA .............................................................................31

4.7 CLOCKING MODE ........................................................................................32

4.8 STARTING MODE.........................................................................................33

4.9 ACTIVE TERMINATOR ..................................................................................34

4.10

DIGITAL INPUT OPERATION MODE .............................................................34

4.10.1 Digital Input DMA in Internal Clock Mode............................34

4.10.2 Digital Input DMA in External Clock Mode ...........................36

4.10.3 Digital Input DMA in Handshaking Mode.............................38

4.10.4 Continuous Digital Input..........................................................40

4.11

DIGITAL OUTPUT OPERATION MODE .........................................................41

4.11.1 Digital Output DMA in Internal Clock Mode.........................41

4.11.2 Digital Output DMA in Handshaking Mode..........................42

4.11.3 Digital Output DMA in Burst Handshaking Mode...............44

4.11.4 Pattern Generator....................................................................45

4.12

AUXILIARY DIO..........................................................................................46

C/C++ Libraries.......................................................................47

5.1 LIBRARIES INSTALLATION ............................................................................47

5.2 PROGRAMMING GUIDE................................................................................48

5.2.1 Naming Convention.................................................................48

5.2.2 Data Types ................................................................................48

5.3 _7300_INITIAL............................................................................................49

5.4 _7300_CLOSE ...........................................................................................50

5.5 _7300_CONFIGURE...................................................................................50

5.6 _7300_DI_MODE ......................................................................................52

5.7 _7300_DO_MODE ....................................................................................53

5.8 _7300_AUX_DI........................................................................................54

5.9 _7300_AUX_DI_CHANNEL ......................................................................54

5.10

_7300_AUX_DO.....................................................................................55

5.11

_7300_AUX_DO_CHANNEL....................................................................55

5.12

_7300_ALLOC_DMA_MEM......................................................................56

5.13

_7300_FREE_DMA_M EM........................................................................57

5.14

_7300_DI_DMA_START..........................................................................57

5.15

_7300_DI_DMA_STATUS........................................................................60

5.16

_7300_DI_DMA_ABORT.........................................................................60

5.17

_7300_GETOVERRUNSTATUS..................................................................61

5.18

_7300_DO_DMA_START........................................................................61

ii • Table of Contents

5.19

_7300_DO_DMA_STATUS......................................................................63

5.20

_7300_DO_DMA_ABORT.......................................................................63

5.21

_7300_DO_PG_START...........................................................................64

5.22

_7300_DO_PG_STOP ............................................................................65

5.23

_7300_DI_TIMER .....................................................................................65

5.24

_7300_DO_TIMER ...................................................................................66

5.25

_7300_INT_TIMER ....................................................................................66

5.26

_7300_GET_SAMPLE ...............................................................................67

5.27

_7300_SET_SAMPLE................................................................................68

5.28

_7300_GETUNDERRUN STATUS ...............................................................68

Appendix A 8254 Programmable Interval Timer................70

A.1 THE INTEL (NEC) 8254.............................................................................70

A.2 THE CONTROL BYTE ...................................................................................70

A.3 MODE DEFINITION .......................................................................................72

Warranty Policy.......................................................................74

Table of Contents • iii

How to Use This Guide

This manual is designed to help you use the cPCI -7300 and PCI-7300A Rev.B.
The manual describes how to modify various settings on the PCI -7300A card
to meet your requirements. It is divided into five chapters:

• Chapter 1, "Introduction", gives an overview of the product features,
applications, and specifications.

• Chapter 2, "Installation", describes how to install the PCI -7300A. The
layout of PCI-7300A is shown, and the installation procedures, pin
assignment of connectors, and timer pacer generation are specified.

• Chapter 3, "Register Structure & Format", describes the low-level
register structure and format of the PCI -7300A.

• Chapter 4, "Operation Theory", describes how to use the operations of
digital input and output on the PCI -7300A.

• Chapter 5, "C/C++ & DLL Library", describes the high level C and DLL
library functions. It will help you to programming in DOS, Win 3.11,
Win-95 and Win-NT environments.

• Appendix A, "8254 Programmable Interval Timer", describes the
detailed structure and register format of 8254-timer/counter chip.

How to Use This Guide • iv

1

Introduction

The cPCI/PCI -7300A is cPCI/PCI form factor ultra-high speed digital I/O card,
it consists of 32 digital input or output channel. High performance designs and
the state-of-the-art technology make this card to be ideal for high speed digital
input and output applications.

The cPCI/PCI -7300A performs high-speed data transfers using bus mastering
DMA and scatter/gather via 32-bit PCI bus architecture. The maxim um data
transfer rates can be up to 80MB per second. It is very suitable for interface
between high speed peripherals and your computer system.

The cPCI/PCI-7300A is configured as two ports, PORTA and PORTB, each
port controls 16 digital I/O lines. The I/O can configure as either input or output,
and 8-bit or 16-bit. According to outside device environment, users can
configure cPCI/PCI -7300A to meet all high speed digital I/O data transfer.

There are 4 different digital I/O operation modes are supported:

1. Internal Clock: the digital input and output operations are paced by
internal clock and transferred by bus mastering DMA.

2. External Clock: the digital input operation is paced by external strobe
signal ( DIREQ ) and transferred by bus mastering DMA.

3. Handshaking: through REQ signal and ACK signal, the digital I/O
data can have simple handshaking data transfer.

4. Pattern Generation: You can output a digital pattern repeatedly at a
predetermined rate. The transfer rate is controlled by internal timer.

Introduction • 1

1.1 Applications

• Interface to high-speed peripherals

• High-speed data transfers from other computers

• Automated test equipment (ATE)

• Electronic and logic testing

• Interface to external high-speed A/D and D/A converter

• Digital pattern generator

• Waveform and pulse generation

• Parallel digital communication

1.2 Features

The PCI-7300A Ultra-High Speed DIO card provides the following advanced
features:

• 32 digital input/output channels

• Extra 4-bit TTL digital input and output channels

• Transfer up to 80M Bytes per second

• SCSI active terminator for high speed and long distance data transfer

• 32-bit PCI bus

• Plug and Play

• Scatter/gatter DMA

• On-board internal clock generator

• Internal timer/external clock controls input sampling rate

• Internal timer control digital output rate

• ACK and REQ for handshaking

• TRIG signal controls start of data acquisition/pattern generation

• On-board 64KB FIFO

• 100-pin SCSI style connector

2 • Introduction

1.3 Specifications

♦ Digital I/O (DIO)

• Numbers of Channel: 32 TTL compatible inputs and/or outputs

• Device: IDT 74FCT373

• I/O Configurations:

16 DI & 16 DO
32 DI
32 DO

♦ Input Voltage:

• Low: Min. 0V; Max. 0.8V

• High: Min. +2.0V

♦ Input Load:

• Terminator OFF:

Low: +0.5V @ ±20 mA
High: +2.7V @ ±1 mA max.

• Terminator ON:
Termination resistor: 110 Ohms
Termination voltage: 2.9V

Low: +0.5V @ ±22.4mA
High: +2.7V @ ± 1mA max.

♦ Output Voltage:

• Low: Min. 0V; Max. 0.5V

• High: Min. +2.7V

♦ Driving Capacity:

• Low: Max. +0.5V at 48mA (Sink)

• High: Min. 2.4V at -8 mA (Source)

♦ Hysteresis: 500mV
♦ Transfer Characteristic

Introduction • 3

• Mode: Bus Mastering DMA with Scatter/Gather

• Data Transfers: 8/16/32-bit input or output (programmable)

♦ DMA Transfer count:

• 2M double words (8M bytes) for non-chaining mode DMA

• No limitation for chaining mode (scatter/gather) DMA

♦ Max. Transfer rate:

• DO: 80M Bytes/sec: 32-bit output @ 20 MHz

• DI: 80M Bytes/sec: 32-bit input @ 20 MHz

♦ Programmable Counter:

• Device: 82C54-10

• Digital Input Pacer: 20MHz, 10MHz, or clock output of Timer #0

• Digital Output Pacer: 20MHz, 10MHz, or clock output of Timer #1

• General Purpose Timer: Output of Timer #2

• General Specifications

♦ Connector: one 100-pin male SCSI-II style cable connector
♦ Operating Temperature: 0° C ~ 60°C
♦ Storage Temperature: -20° C ~ 80°C
♦ Humidity: 5 ~ 95%, non-condensing
♦ Dimension: Compact size only 179mm(L) X 102mm(H)
♦ Power Consumption:

• +5 V @ 830 mA max. with on-board terminator off

or

• +5 V @ 1.0A max. with on-board terminator on

4 • Introduction

1.4 Software Supporting

ADLINK provides versatile software drivers and packages for users’ different
approach to built -up a system. We not only provide programming library such
as DLL for many Windows systems, but also provide drivers for software

packages such as LabVIEW®, HP VEETM, DASYLabTM, InTouchTM,
InControlTM, ISaGRAFTM, and so on.

All the software options are included in the ADLINK CD. The non-free software
drivers are protected with serial licensed code. Without the software serial
number, you can still install them and run the demo version for two hours for
demonstration purpose. Please contact with your dealer to purchase the
formal license serial code.

1.4.1 Programming Library

For customers who are writing their own programs, we provide function
libraries for many different operating systems, including:

♦ DOS Library: Borland C/C++ and Microsoft C++, the functions

descriptions are included in this user’s guide.

♦ Windows 95 DLL: For VB, VC++, Delphi, BC5, the functions descriptions

are included in this user’s guide.

♦ PCIS-DASK: Include device drivers and DLL for Windows 98, Windows

NT and Windows 2000. DLL is binary compatible across Windows 98,
Windows NT and Windows 2000. That means all applications developed
with PCIS-DASK are compatible across Windows 98, Windows NT and
Windows 2000. The developing environment can be VB, VC++, Delphi,
BC5, or any Windows programming language that allows calls to a DLL.
The user’s guide and function reference manual of PCIS-DASK are in the
CD. Please refer the PDF manual files under
\\Manual_PDF\Software\PCIS-DASK

The above software drivers are shipped with the board. Please refer to the
“Software Installation Guide” to install these drivers.

1.4.2 PCIS-LVIEW: LabVIEW® Driver

PCIS-LVIEW contains the VIs, which are used to interface with NI’s LabVIEW®
software package. The PCIS-LVIEW supports Windows 95/98/NT/2000. The
LabVIEW® drivers are free shipped with the board. You can install and use
them without license. For detail information about PCIS-LVIEW, please refer
to the user’s guide in the CD.

(\\Manual_PDF\Software\PCIS-LVIEW)

Introduction • 5

1.4.3 PCIS-VEE: HP -VEE Driver

The PCIS-VEE includes the user objects, which are used to interface with HP
VEE software package. PCIS-VEE supports Windows 95/98/NT. The HP-VEE
drivers are free shipped with the board. You can install and use them without
license. For detail information about PCIS-VEE, please refer to the us er’s
guide in the CD.

(\\Manual_PDF\Software\PCIS-VEE)

1.4.4 DAQBenchTM: ActiveX Controls

We suggest the customers who are familiar with ActiveX controls and
VB/VC++ programming use the DAQBenchTM ActiveX Control components
library for developing applications. The DAQBenchTM is designed under
Windows NT/98. For more detailed information about DAQBench, please refer
to the user’s guide in the CD.

(\\Manual_PDF\Software\DAQBench\DAQBench Manual.PDF)

6 • Introduction

2

Installation

This chapter describes how to install the cPCI/PCI -7300A. At first, the contents
in the package and unpacking information that you should be careful are
described. Because the PCI -7300A is following the PCI design philosophy, it
is no more jumpers and DIP switches setting for configuration. The Interrupt
and I/O port address are the variables associated with automatic configuration,
the resource allocation is managed by the system BIOS. Upon system
power-on, the internal configuration registers on the board interact with the
BIOS.

2.1 What You Have

In addition to this User's Manual, the package includes the following items:

• cPCI/PCI-7300A 80MB Ultra-High Speed 32-CH Digital I/O Card

• ADLINK All-in-one CD

• Software Installation Guide

If any of these items is missing or damaged, contact the dealer fro m whom you
purchased the product. Save the shipping materials and carton in case you
want to ship or store the product in the future.

Installation • 7

2.2 Unpacking

Your cPCI/PCI -7300A card contains sensitive electronic components that can
be easily damaged by static electricity.

The card should be placed on a grounded anti-static mat. The operator should
be wearing an anti-static wristband, grounded at the same point as the
anti-static mat.

Inspect the card module carton for obvious damage. Shipping and handling
may caus e damage to your module. Be sure there are no shipping and
handling damages on the module before processing.

After opening the card module carton, extract the system module and place it
only on a grounded anti-static surface component side up.

Again inspect the module for damage. Press down on all the socketed IC's to
make sure that they are properly seated. Do this only with the module place on
a firm flat surface.

Note: DO NOT APPLY POWER TO THE CARD IF IT HAS BEEN

DAMAGED.

You are now ready to install your cPCI/PCI -7300A.

2.3 Device Installation for Windows Systems

Once Windows 95/98/2000 has started, the Plug and Play function of Windows
system will find the new NuDAQ/NuIPC cards. If this is the first time to install
NuDAQ/NuIPC cards in your Windows system, you will be informed to input
the device information source. Please refer to the “Software Installation
Guide” for the steps of installing the device.

8 • Installation

2.4 PCI-7300A's Layout

Figure 2.1 PCI-7300A Layout Diagram

Installation • 9

10 • Installation

Figure 2.2 cPCI-7300A Layout Diagram

2.5 Hardware Installation Outline

PCI configuration

The PCI cards (or CompactPCI cards) are equipped with plug and play PCI
controller, it can request base addresses and interrupt according to PCI
standard. The system BIOS will install the system resource based on the PCI
cards’ configuration registers and system parameters (which are set by system
BIOS). Interrupt assignment and memory usage (I/O port locations) of the PCI
cards can be assigned by system BIOS only. These system resource
assignments are done on a board-by-board basis. It is not suggested to assign
the system resource by any other methods.

PCI slot selection

Please note that the PCI slot must provide bus-mastering capability to operate
this board well.

Installation Procedures

1. Turn off your computer.

2. Turn off all accessories (printer, modem, monitor, etc.) connected to
your computer.

3. Remove the cover from your computer.

4. Select a 32-bit PCI slot. PCI slots are short than ISA or EISA slots, and
are usually white or ivory.

5. Before handling the PCI cards, discharge any static buildup on your
body by touching the metal case of the computer. Hold the edge and
do not touch the components.

6. Position the board into the PCI slot you selected.

7. Secure the card in place at the rear panel of the system.

Installation • 11

2.6 Connector Pin Assignment

The PCI -7300A comes equipped with one 100-pin SCSI type connector (CN1)
located on the rear mounting plate. The pin assignment of CN1 is illustrated in
the figure 2.2.

Legend:

Pins Signal Name Signal Type

1…50 GND GND

51..66 PB15…PB0 DATA I/O

67 DOACK CONTROL

68 DOREQ CONTROL

69 DOTRIG CONTROL

70…73 AUXDO3…0 DATA O

85..100 PA15…PA0 DATA I/O

82 DIACK CONTROL

83 DIREQ CONTROL

84 DITRIG CONTROL

78…81 AUXDI3…0 DATA I

74…77 TERMPWR POWER

Signal

Direction

I

O

I

O

I

I

Description

Ground – these lines are the ground
reference for all other signals
PortB bidirectional data liness-PB15
is the MSB, and PB0 is the LSB.
Digital output Acknowledge lines –
In handshaking mode, DOACK
carries handshaking status
information from the peripheral.
Request line – In handshaking
mode, DOREQ carries handshaking
control information to peripheral.
DO TRIG- can be used to control
the start of data output in all DO
modes and to control the stop of
pattern generation in pattern
generation mode.
AUX DO 3…0 – can be used as
extra output data or can be used as
extra control signals.
PortA bidirectional data liness-PA15
is the MSB, and PA0 is the LSB.
Digital output Acknowledge lines –
In handshaking mode, DIACK
carries handshaking status
information to the peripheral.
Request line – In handshaking
mode, DIREQ carries handshaking
control information from peripheral.
In external clock mode, DIREQ
carries the external clock input.
DI TRIG – can be used to control
the start of data acquisition in all DI
modes.
AUX DI 3…0 – can be used as extra
input data or can be used as extra
control signals.
TERMPWR -- 4.7V active
terminator power output

12 • Installation

GND

100

PA0

DI_ACK

DO_ACK

PB15

50

99

PA1
PA2
PA3
PA4
PA5
PA6
PA7
PA8

PA9
PA10
PA11
PA12
PA13
PA14
PA15

DI_TRG
DI_REQ

AUXI0
AUXI1
AUXI2

AUXI3
TERMPWR
TERMPWR
TERMPWR
TERMPWR

AUXO0
AUXO1
AUXO2

AUXO3
DO_TRG
DO_REQ

PB0
PB1
PB2
PB3
PB4
PB5
PB6
PB7
PB8
PB9

PB10

PB11

PB12
PB13

PB14

98
97
96
95
94
93
92
91
90
89
88
87
86
85
84
83
82
81
80
79
78
77
76
75
74
73
72
71
70
69
68
67
66
65
64
63
62
61
60
59
58
57
56
55
54
53
52
51

GND

49

GND

48

GND

47

GND

46

GND

45

GND

44

GND

43

GND

42

GND

41

GND

40

GND

39

GND

38

GND

37

GND

36

GND

35

GND

34

GND

33

GND

32

GND

31

GND

30

GND

29

GND

28

GND

27

GND

26

GND

25

GND

24

GND

23

GND

22

GND

21

GND

20

GND

19

GND

18

GND

17

GND

16

GND

15

GND

14

GND

13

GND

12

GND

11

GND

10

GND

9

GND

8

GND

7

GND

6

GND

5

GND

4

GND

3

GND

2

GND

1

Figure 2.2 CN1 Pin Assignment

Installation • 13

2.7 Wiring and Termination

Transmission line effects and environment noise, particularly on clock and
control lines, can lead to incorrect data transfers if you do not take care when
running signal wires to and from the devices.

Take the following precautions to ensure a uniform transformation line and
minimize noise pickup:

1. Use twisted-pair wires to connect digital I/O signals to the device. Twist each
digital I/O signal with a GND line. In PCI-7300A, 50 signals are used as
GND.

2. Place a shield around the wires connecting digital I/O signal to device.

3. Route signals to the devices carefully. Keep cabling away from noise
sources, such as video monitor.

For cPCI/PCI -7300A, it is important to terminate your cable properly to reduce
or eliminate signal reflections in the cable. The PCI-7300A support active
terminator on board, you can enable or disable the terminator by software
selection. This is a good way to include termination on the signal transmission.

Additional recommendations apply for all signal connection to your
cPCI/PCI-7300A are listed as follows:

1. Separate cPCI/PCI-7300A device signal lines from high-current or
high-voltage line. These lines are capable of inducing currents in or voltages
on the cPCI/PCI -7300A if they run in parallel paths at a close distance. To
reduce the magnetic coupling between lines, separate them by a
reasonable distance if they run in parallel, or run the lines at right angles to
each other.

2. Do not run signal lines through conducts that also contain power lines.

3. Protect signal lines from magnetic fields.

14 • Installation

2.8 Daughter Board Supporting

The cPCI/PCI -7300A can be connected with two daughter boards: DIN-100S
or DIN-502S. The functionality and connections are specified as follows.

2.8.1 Connect with DIN-100S

The DIN-100S is a direct connection for the add-on card that is equipped with
SCSI-100 connector. User can connect this daughter board by a 100-pin SCSI
type cable (ACL-102100) to the cPCI/PCI-7300A. It is suitable for the
applications of 32-bit digit al input or 32-bit digital output.

2.8.2 Connect with DIN-502S

The DIN-502S with the cable ACL-10252 separates the 100-pin SCSI
connector into two 50-pin SCSI connectors. One 50 pin connector is for pin 1 ~
25 and pin 51~75 of CN1 while the other one is for pin 26 ~ 50 and pin 76~100
of CN1. That means the DIN -502S and the ACL-10252 make users easy to
connect the 16-bit digital inputs and 16-bit digital outputs by using two 50-pin
daughter boards respectively. The independent wiring of 16-bit DI and 16-bit
DO let users convenient to setup and maintain his systems.

Installation • 15

3

Registers

In this chapter, the registers’ format of the cPCI/PCI-7300A is described.
Please note that the registers’ map of the PCI-7300A Rev.B is different from
the PCI -7300A Rev.A

This in formation is quite useful for the programmers who wish to handle the
card by low-level programming. In addition, users can realize how to use
software driver to manipulate this card after understanding the registers'
structure of the cPCI/PCI -7300A

The cPCI/PCI-7300A functions as a 32-bit PCI master device on the PCI bus.
There are three types of registers on the cPCI/PCI -7300A: PCI Configuration
Registers (PCR), Local Configuration Registers (LCR) and cPCI/PCI -7300A’s
registers.

The PCR, which compliant to the PCI-bus specifications, is initialized and
controlled by the plug & play (PnP) PCI BIOS. User‘s can study the PCI BIOS
specification to understand the operation of the PCR. Please contact with
PCISIG to acquire the specifications of the PCI interface.

The LCR is specified by the PCI bus controller PLX PCI-9080, which is
provided by PLX technology Inc. (www.plxtech.com) . It is not necessary for
users to understand the details of the LCR if you use the software library. The
base address of the LCR is assigned by the PCI PnP BIOS. The assigned
address is located at offset 14h of PCR.

16 • Registers

3.1 I/O Port Base Address

The registers of the cPCI/PCI-7300A are shown in Table 3.1. The base
address of these registers is als o assigned by the PCI P&P BIOS. The
assigned base address is stored at offset 18h of the PCR. Therefore, users
can read the PCR to know the base address by using BIOS function call. Note
that the cPCI/PCI-7300A registers are all 32 bits. Users should access these
registers by 32 bits I/O instructions.

The PCI-7300A occupies 8 consecutive 32-bit I/O addresses in the I/O
address space. Table 3.1 shows the I/O Map of the PCI -7300A rev.B.

Address Read Write

Base + 0 DI_CSR DI_CSR
Base + 4 DO_CSR DO_CSR
Base + 8 AUX_DIO AUX_DIO

Base + C INT_CSR INT_CSR
Base + 10 DI_FIFO DI_FIFO
Base + 14 DO_FIFO DO_FIFO
Base + 18 - FIFO_CR

Base + 1C POL_CTRL POL_CTRL

Base + 20 8254_COUNT0 8254_COUNT0
Base + 24 8254_COUNT1 8254_COUNT1
Base + 28 8254_COUNT2 8254_COUNT2

Base + 2C

Legend:

DI_CSR: Digital input control & status register
DO_SCR: Digital output control & status register
AUX_DIO: Auxiliary digital I/O port
INT_CSR: Interrupt control and status register
DI_FIFO: DI FIFO direct access port
DO_FIFO: DO FIFO direct access port
FIFO_CR: FIFO almost empty/full programming register
POL_CTRL: Polarity control register for the control signals

Caution:

1. I/O port is 32-bit width

2. 8-bit or 16-bit I/O access is not allowed.

8254_CONTROL 8254_CONTROL

Registers • 17
