ADLINK PCI-7258 User Manual

NuDAQ®

PCI-7258

PhotoMos Relay Cards

User’s Guide

Recycled Paper

©Copyright 2002 ADLINK Technology Inc.

All Rights Reserved.

Manual Rev: 1.04: October 18, 2002

Part NO: 50-11132-100

The information in this document is subject to change without prior notice in
order to improve reliability, design and function and does not represent a
commitment on the part of the manufacturer.

In no event will the manufacturer be liable for direct, indirect, special,
incidental, or consequential damages arising out of the use or inability to use
the product or documentation, even if advised of the possibility of such
damages.

This document contains proprietary information protected by copyright. All
rights are reserved. No part of this manual may be reproduced by any
mechanical, electronic, or other means in any form without prior written
permission of the manufacturer.

Trademarks

NuDAQ is registered trademarks of ADLINK Technology Inc. Other product
names mentioned herein are used for identification purposes only and may
be trademarks and/or registered trademarks of their respective companies.

Getting service from ADLINK

• Customer Satisfaction is the most important priority for ADLINK Tech Inc. If
you need any help or service, please contact us.

ADLINK Technology Inc.

Web Site http://www.adlinktech.com

Sales & Service [e-mail]

NuDAQ + USBDAQ [e-mail]

Technical

Support

TEL [phone] FAX [phone]

Address 9F, No. 166, Jian Yi Road, Chungho City, Taipei, 235 Taiwan.

• Please email or FAX us of your detailed information for a prompt,
satisfactory and constant service.

Company/Organization

Contact Person

E-mail Address

Address

Country

TEL

Web Site

Product Model

Environment to Use

Detail Description

Automation [e-mail]

NuIPC [e-mail]

NuPRO / EBC [e-mail]

Detailed Company Information

FAX

Questions

OS:
Computer Brand:
M/B: CPU:
Chipset: BIOS:
Video Card:
Network Interface Card:
Other:

Suggestions to ADLINK

Table of Contents

Tables and Figures.........................................................iii

How to Use This Guide ..................................................iv

Introduction .....................................................................1

1.1 Features ............................................................................... 2

1.2 Applications.......................................................................... 2

1.3 Specifications ....................................................................... 2

1.4 Software Support .................................................................4

1.4.1 Programming Library.........................................................4

1.4.2 PCIS-LVIEW: LabVIEW® Driver .......................................4

1.4.3 PCIS-VEE: VEE Driver......................................................5

1.4.4 PCIS-OCX: ActiveX Controls.............................................5

1.4.5 PCIS-DDE: DDE Server and InTouchTM............................5

1.4.6 PCIS-ISG: ISaGRAFTM driver ............................................5

1.4.7 PCIS-ICL: InControlTM Driver.............................................6

1.4.8 PCIS-OPC: OPC Server....................................................6

Getting Started.................................................................7

2.1 What you have .....................................................................7

2.2 Unpacking ............................................................................ 8

2.3 PCB Layout.......................................................................... 9

2.4 Board ID ............................................................................. 11

2.6 Connector Pin Assignments............................................... 12

2.7 Termination Board Connection .......................................... 13

Registers ........................................................................15

3.1 I/O Address Map ................................................................15

3.2 Relay Output Control Register ........................................... 16

3.3 Relay Output Read Back Register..................................... 17

3.4 Isolated Digital Input Register ............................................ 18

3.5 Clear IRQ register ..............................................................18

3.6 Handling PCI Controller Registers ..................................... 19

Table of Contents • i

Operation Theory...........................................................20

4.1 PhotoMos Relay Output..................................................... 20

4.2 Isolated Digital Input ..........................................................22

4.3 Interrupt Architecture .........................................................22

C/C++ DOS Libraries .....................................................23

5.1 Programming Guide........................................................... 23

5.1.1 Naming Convention.........................................................23

5.1.2 Data Types ......................................................................24

5.2 _7258 Initial........................................................................ 25

5.3 _7258_DO.......................................................................... 26

5.4 _7258_DO_Read_Back ..................................................... 26

5.5 _7258_DI............................................................................ 27

5.6 _7258_INT_Control............................................................ 27

5.9 _7258_CLR_IRQ ...............................................................28

5.10 _7258_GET_IRQ_Status ................................................... 28

Warranty Policy .............................................................29

ii • Table of Contents

Tables and Figures

Tables

Table 1. Board ID Setting Conditions ................................................. 11

Table 2. Registers Address Map ........................................................ 15

Table 3. Data Types and Range......................................................... 24

Figures

Figure 1: PCI-7258 PCB Layout ............................................................ 9

Figure 2: Board ID Dipswitch ............................................................... 11

Figure 3: Pin Assignment of PCI-7258 CN1......................................... 12

Figure 4: PhotoMos relay schematic.................................................... 20

Figure 5: PhotoMos relay wiring diagram ............................................ 21

Figure 6: Protection circuit for an Inductive load .................................. 21

Figure 7: Photo-Coupler ...................................................................... 22

Tables and Figures • iii

How to Use This Guide

This manual is intended to assist users to configure the PCI-7258 PhotoMos
Relay Card. It is divided into 5 chapters.

Chapter 1, “Introduction”

applications, and specifications.

Chapter 2, “Getting Started”

The Board ID switch and connectors’ pin assignments are
also described.

Chapter3, “Registers”

PCI-7258. The information is important for programmers who
want to control the hardware with low level programming
languages.

Chapter 4, “Operation Theory”

7258. The PhotoMos relay and isolated digital input are
introduced. Some programming concepts are also described.

Chapter 5, “C/C++ libraries”

software libraries of the PCI-7258. This chapter also
outlines basic requirements for programming your own
software application.

, gives an overview of the product features,

, describes how to install the PCI-7258.

, describes the registers that are available to the

, describes how to operate the PCI-

, describes the software utility and the

iv • How to Use This Guide

1

Introduction

The PCI-7258 PhotoMos relay card is a basic Digital I/O card for PCI bus
computers used in industrial applications.

This PCI-7258 provides 32 PhotoMos relay actuators and 2 opto-isolated
digital inputs. All relays are of Form A type and is very suited for constant
ON/OFF control devices.

Other useful feature includes the Board ID. It is convenient for board
identification when two or more PCI-7258 cards are in a system. All I/O
signals are routed via a 68-pin SCSI connector.

Introduction • 1

1.1 Features

The PCI-7258 PhotoMos relay actuator and D/I Card provides the following
advanced features:

• 32-bit PCI-Bus, Plug and Play

• 32 PhotoMos relay actuator outputs

• 2 opto-isolated digital inputs

• On-board relay driving circuits

• Digital input channel 0 & 1 interrupt

• Board ID

1.2 Applications

• Industrial ON/OFF control

• Energy management

• Laboratory automation

• Industrial automation

• Switch contact status sensing, limit switch monitoring,

• Integrate with A/D and D/A cards to implement a data acquisition & control

system

1.3 Specifications

Digital input

♦

• Input channels: 2

• Photo-coupler: PC-3H4

• Input current:

3 10 mA rated

3 50 mA max. for isolated input

2 • Introduction

• Input Voltage:

3 Up-to 24 V

3 Logic Low: 0~2V

3 Logic High 5~24V

• Input impedance: 2.4 KΩ / 0.5W

• Isolated voltage: 2,500 V

Relay Output

♦

• Output channels: 32

• Relay type: 32 SPST (Form A)

• Load voltage (peak AC): 350V

• Continuous load current (peak AC): 0.12A

• Peak load current: 0.3A

• I/O isolation voltage: 1,500 V AC

• Output turn on resistance (typical): 17Ω

• Output off state leakage current (Maximum): 1μA

• Turn on time (typical): 0.23 ms

• Turn off time (typical): 0.04 ms

or 24V

DC

AC

channel-to-system

rms

General Specifications

♦

• Bus: 32-bit PCI bus

• Dimension: 174 mm x 106 mm, standard PCI half size

• Operating temperature: 0 ~ 60 °C

• Storage temperature: -20 °C ~ 80 °C

• Humidity: 5 to 95% non-condensing

Power Consumption

♦

• +5V @ 380 mA (All relays energized)

Introduction • 3

1.4 Software Support

ADLINK provides versatile software drivers and packages for users’ different
approach to building a system. ADLINK not only provides programming
libraries such as DLL for most Windows based systems, but also provide

drivers for other software packages such as LabVIEW®, VEETM, InTouchTM,
InControl

All software options are included in the ADLINK CD. Non-free software
drivers are protected with licensing codes. Without the software code, you
can install and run the demo version for two hours for trial/demonstration
purposes. Please contact ADLINK dealers to purchase the formal license.

1.4.1 Programming Library

For customers who are writing their own programs, we provide function
libraries for many different operating systems, including:

The above software drivers are shipped with the board. Please refer to the
“Software Installation Guide” for installation procedures.

TM

, ISaGRAFTM, and so on.

• DOS Library: Borland C/C++ and Microsoft C++. Functional

descriptions are included in this user’s guide

• PCIS-DASK: Include device drivers and DLL for Windows 98,

Windows NT and Windows 2000. DLL is binary compatible across
Windows 98, Windows NT and Windows 2000. That means all
applications developed with PCIS-DASK are compatible across
Windows 98, Windows NT and Windows 2000. The developing
environment can be VB, VC++, Delphi, BC5, or any Windows
programming language that allows calls to a DLL. The user’s guide
and function reference manual of PCIS-DASK are in the CD. Please
refer the PDF manual files under \\Manual_PDF\Software\PCIS­DASK

1.4.2 PCIS-LVIEW: LabVIEW® Driver

PCIS-LVIEW contains the VIs, which is used to interface with NI’s LabVIEW®
software package. The PCIS-LVIEW supports Windows 95/98/NT/2000. The
LabVIEW
them without a license. For more information about PCIS-LVIEW, please
refer to the user’s guide in the CD. (\\Manual_PDF\Software\PCIS-LVIEW).

4 • Introduction

®

drivers is shipped free with the board. You can install and use

1.4.3 PCIS-VEE: VEE Driver

The PCIS-VEE includes user objects, which are used to interface with the
VEE software package. PCIS-VEE supports Windows 95/98/NT. The VEE
drivers are shipped free with the board. You can install and use them without
a license. For more information about PCIS-VEE, please refer to the user’s
guide in the CD. (\\Manual_PDF\Software\PCIS-VEE).

1.4.4 PCIS-OCX: ActiveX Controls

We suggest users who are familiar with ActiveX controls and VB/VC++
programming use the PCIS-OCX ActiveX control components library to
develop their applications. PCIS-OCX is designed for Windows 98/NT/2000.
For more information about PCIS-OCX, please refer to the user's guide in the
CD. (\Manual_PDF\Software\PCIS-OCX\PCIS-OCX.PDF).

The above software drivers are shipped with the board. Please refer to the
“Software Installation Guide” for installation procedures.

ADLINK also supply an ActiveX control software called DAQBench.
DAQBench is a collection of ActiveX controls for measurement and
automation applications. With DAQBench, you can develop custom user
interfaces to display and analyze data you acquired or received from other
sources, or integrate with popular applications or data sources. For more
information about DAQBench, please refer to the user's guide in the CD.
(\Manual_PDF\Software\DAQBench\DAQBenchManual.PDF). There is a
free 4-hour evaluation version of DAQBench available in the CD. DAQBench
is not free. Please contact ADLINK dealers or ADLINK to purchase the
software license.

1.4.5 PCIS-DDE: DDE Server and InTouchTM

DDE stands for Dynamic Data Exchange. The PCIS-DDE includes the PCI
cards’ DDE server. The PCIS-DDE server is free and is included in the
ADLINK CD. The DDE server can be used in conjunction with any DDE client
under Windows 98/NT/2000.

1.4.6 PCIS-ISG: ISaGRAFTM driver

The ISaGRAF Workbench is an IEC1131-3 SoftPLC control development
environment. The PCIS-ISG includes ADLINK product drivers for ISaGRAF
under Windows NT environment. The PCIS-ISG is included in the ADLINK
CD. It is not free. Please contact ADLINK dealers or ADLINK to purchase
the license.

Introduction • 5

1.4.7 PCIS-ICL: InControlTM Driver

PCIS-ICL is the InControl driver, which supports Windows NT. The PCIS-ICL
is included in the ADLINK CD. It is not free and requires a license. Please
contact ADLINK dealers or ADLINK to purchase the license.

1.4.8 PCIS-OPC: OPC Server

PCIS-OPC is an OPC server, which can be used to link with other OPC
clients. There are many software packages on the market that can provide
the OPC clients. The PCIS-OPC supports Windows 98, NT, and 2000. It is
not free. Please contact ADLINK dealers or ADLINK to purchase the license.

6 • Introduction

2

Getting Started

This chapter describes how to install and setup the PCI-7258. The contents
in the package and unpacking information that you should be aware of are
outlined first.

2.1 What you have

In addition to the User’s Manual, the package should include the following
items:

• PCI-7258 PhotoMos relay cards

• ADLINK Software CD

• Software Installation Guide

If any of these items are missing or damaged, contact ADLINK or the dealer
from whom you purchased the product. Save the shipping materials and
carton in case you want to ship or store the product in the future.

Getting Started • 7

2.2 Unpacking

The card contains electro-static sensitive components that can be easily be
damaged by static electricity.

Therefore, the card should be handled on a grounded anti-static mat. The
operator should be wearing an anti-static wristband, grounded at the same
point as the anti-static mat.

Inspect the card module carton for obvious damages. Shipping and handling
may cause damage to your module. Be sure there are no shipping and
handling damages on the modules carton before continuing.

After opening the card module carton, extract the system module and place it
only on a grounded anti-static surface with component side up.

Again, inspect the module for damages. Press down on all the socketed IC's
to make sure that they are properly seated. Do this only with the module
place on a firm flat surface.

Note: DO NOT ATTEMPT TO INSTALL A DAMAGED BOARD IN THE

COMPUTER.

You are now ready to install your card.

8 • Getting Started

2.3 PCB Layout

The location of the connectors and switches on the PCI-7258 are shown in
figure 1 below. Descriptions are outline in the proceeding sections.

Figure 1: PCI-7258 PCB Layout

Getting Started • 9

2.4 External LED

LED16

LED10

LED1

A

JP1

K

A

K

JP2

LED32

LED26

LED17

Figure 2: PCI-7258 External LED connector

The PCI-7258 card is designed with 32 LEDs, each indicating the operation
status of the 32 relays. In addition, there are also 32 external LED connectors
available for users’ to use as so pleases. Utilizing the external LEDs
connecting to JP1 or JP2, users can have a visual status of each relay
displayed on a chassis, panel or on any apparatus. Only LED’s with a
forward voltage (V

) lower than 2V will operate. Each external LED connector

f

has a current limiting resistor (330Ω) connected to the +5V supply, therefore
external current limiting circuitry for external LED’s are not necessary.

The direction of the external LED’s connection is shown in Figure 2. Before
connecting a LED to a connector, make sure the LED’s orientation is correct.

10 • Getting Started

2.5 Board ID

When two or more data acquisition cards are installed in a system, it can be
tedious trying to identify a specific card. For easier identification, the PCI­7258 implemented a Board ID function. By setting the Dipswitch located at
S1, users can assign an ID address to a specific card and access the card
through software programming. For more details about the Board ID in
programming, please refer to chapter 5. Table 1 below shows all dipswitch
setting conditions.

ON

1

234

Figure 3: Board ID Dipswitch

Board ID

0 (default) 1 1 1 1

1 0 1 1 1

2 1 0 1 1

3 0 0 1 1

4 1 1 0 1

5 0 1 0 1

6 1 0 0 1

7 0 0 0 1

8 1 1 1 0

9 0 1 1 0

10 1 0 1 0

11 0 0 1 0

12 1 1 0 0

13 0 1 0 0

14 1 0 0 0

15 0 0 0 0

1 2 3 4

Switch No.

Table 1. Board ID Setting Conditions

Note: 1=on, 0=off

Getting Started • 11

2.6 Connector Pin Assignments

The PCI-7258 card is equipped with a 68-pin SCSI connector (CN1). Figure
3 defines the pin assignment for the connector.

NO1 1 35 NO18

COM1 2 36 COM18

NO2 3 37 NO19

COM2 4 38 COM19

NO3 5 39 NO20

COM3 6 40 COM20

NO4 7 41 NO21

COM4 8 42 COM21

NO5 9 43 NO22

COM5 10 44 COM22

NO6 11 45 NO23

COM6 12 46 COM23

NO7 13 47 NO24

COM7 14 48 COM24

NO8 15 49 NO25

COM8 16 50 COM25

NO9 17 51 NO26

COM9 18 52 COM26

NO10 19 53 NO27

COM10 20 54 COM27

NO11 21 55 NO28

COM11 22 56 COM28

NO12 23 57 NO29

COM12 24 58 COM29

NO13 25 59 NO30

COM13 26 60 COM30

NO14 27 61 NO31

COM14 28 62 COM31

NO15 29 63 NO32

COM15 30 64 COM32

NO16 31 65 DIO

COM16 32 66 DI1

NO17 33 67 DIGND0

COM17 34 68 DIGND1

Figure 4: Pin Assignment of PCI-7258 CN1

Legend:

NO x:

Relay normal open pin x, x = 1~32

COM x:

DI x:

DIGND x:

Relay common pin x, x = 1~32

Digital input pin x, x = 0~1

Digital input ground pin x, x = 0~1

12 • Getting Started

2.7 Termination Board Connection

The available termination board for the 68-pin SCSI connector is the DIN­68S/1S. The DIN-68S/1S is a general-purpose 68-pin screw terminal with a
DIN socket. It is also equipped with a 68-pin SCSI cable that allows for easy
installation of the PCI-7258.

Getting Started • 13

3

Registers

Detailed descriptions of the registers are specified in this chapter. This
information is useful for programmers who wish to handle the card with low­level programming. However, we suggest users to have an understanding of
the PCI interface before starting any low-level programming.

3.1 I/O Address Map

The PCI-7258 registers are all 16-bits long. Users can access these
registers by 16-bit I/O instructions only. The controls for the relays and
status of the isolated inputs are by means of accessing these registers. The
following table shows the registers mapping addresses; the addresses are
offset relative to the base address.

Offset Write Read

0x00h Relay Output CH. 1~16

0x02h Relay Output CH. 17~32

0x04h --- Isolated Input CH. 0, 1

0x08h Clear IRQ ---

Table 2. Registers Address Map

Relay Output Read back

CH.1~16

Relay Output Read back

CH.17~32

Registers • 15

3.2 Relay Output Control Register

There are 32 PhotoMos relays on the PCI-7258; each bit of the register
corresponds to a relay channel. Writing “1” to the register will cause the relay
to close and “0” will cause it to open.

Address: BASE + 0x00

Attribute: Write

7 6 5 4 3 2 1 0

RLY8 RLY7 RLY6 RLY5 RLY4 RLY3 RLY2 RLY1

15 14 13 12 11 10 9 8

RLY16 RLY15 RLY14 RLY13 RLY12 RLY11 RLY10 RLY9

Address: BASE + 0x02

Attribute: Write

7 6 5 4 3 2 1 0

RLY24 RLY23 RLY22 RLY21 RLY20 RLY19 RLY18 RLY17

15 14 13 12 11 10 9 8

RLY32 RLY31 RLY30 RLY29 RLY28 RLY27 RLY26 RLY25

RLYx:

relay output channel x, x=1~32

16 • Registers

3.3 Relay Output Read Back Register

The status of the PhotoMos relay can be read back from the readback
register. If the relay is in the close position, the corresponding bit value is ‘1’.
If the relay is open, then the bit value is ‘0’.

Address: BASE + 0x00

Attribute: Read

7 6 5 4 3 2 1 0

RBK8 RBK7 RBK6 RBK5 RBK4 RBK3 RBK2 RBK1

15 14 13 12 11 10 9 8

RBK16 RBK15 RBK14 RBK13 RBK12 RBK11 RBK10 RBK9

Address: BASE + 0x02

Attribute: Read

7 6 5 4 3 2 1 0

RBK24 RBK23 RBK22 RBK21 RBK20 RBK19 RBK18 RBK17

15 14 13 12 11 10 9 8

RBK32 RBK31 RBK30 RBK29 RBK28 RBK27 RBK26 RBK25

RBKx:

Read back data of relay x, x=1~32

Registers • 17

3.4 Isolated Digital Input Register

There are 2 isolated input channels on PCI-7258 card. The status of the 2
channels can be read from the isolated input register. Each bit corresponds
to each channel. A “1” means the input logic is high and “0” means the input
logic is low.

Address: BASE + 0x04

Attribute: Read

7 6 5 4 3 2 1 0

--- --- --- --- --- --- DI1 DI0

15 14 13 12 11 10 9 8

--- --- --- --- --- --- --- ---

DIx:

isolated digital input channel x, x=0, 1

3.5 Clear IRQ register

The PCI-7258 has two interrupt sources for the digital input channels 0 and 1.
Writing anything to this register will clear the interrupt request.

Address: BASE + 0x08

Attribute: Write

7 6 5 4 3 2 1 0

--- --- --- --- --- --- --- ---

15 14 13 12 11 10 9 8

--- --- --- --- --- --- --- ---

18 • Registers

3.6 Handling PCI Controller Registers

The PCI bus controller adopted in PCI-7258 is the PCI-9030, which is
provided by PLX technology Inc. When users attempt to handle low-level
programming, some registers in the PCI-9030 should be noticed. The
interrupt control register (INTCSR; 0x4Ch) of the PCI-9030 takes charge of
all interrupt information from the local bus to PCI bus. When users want to
develop their own interrupt function driver, both interrupt registers in the PCI­9030 and in PCI-7258 have to work together. For more information about the
interrupt control register in the PCI-9030, refer to the PCI-9030 data book.

With the PCI-7258 software function library, ADLINK has provided simple
and easy-to-use functions to handle the procedures of interrupts. Using these
functions, users are not required to know about the interrupt register in the
PCI controller. Hence, we recommend users use these functions instead of
developing your own interrupt functions. For more information about the PCI­7258 function library, refer to Chapter 5.

Registers • 19

4

Operation Theory

4.1 PhotoMos Relay Output

The PhotoMos relay has LED inputs and MOSFET outputs that provide input­output isolation. When a signal current flows into the LED input pin, the
emitted light from the LED is detected by the photoelectric element (solar
cell), which is mounted opposite to the LED. The photoelectric element then
converts the received light to a voltage, which charges the MOSFET gate on
the output side. When the voltage reaches a preset voltage value, the
MOSFET begins to conduct and turns on the load. The simplified circuit of
PhotoMos relay is shown in figure 4 below.

Figure 5: PhotoMos relay schematic

20 • Operation Theory

The PhotoMos relay incorporates the advantages of both a semiconductor
and an electro-mechanical relay. The PhotoMos relay utilizes the MOSFET
as a switch instead of the mechanical contact. Thus the contact resistance
remains stable through the life of the relay. Furthermore, dithering problems
is eliminated.

The PCI-7258 is equipped with 32 PhotoMos relays, which are all form A
type. The load voltage can either be AC or DC. The basic wiring diagram is
shown in figure 5 below.

Figure 6: PhotoMos relay wiring diagram

If an inductive load is connected, the spike voltage may exceed the relay’s
maximum rating. To protect the components, user should add a diode in the
circuit. A typical protection circuit is shown below.

Figure 7: Protection circuit for an Inductive load

Operation Theory • 21

4.2 Isolated Digital Input

The PCI-7258 contains 2 opto-isolated digital input channels. The circuit
diagram of the isolated input channel is shown below.

Figure 8: Photo-Coupler

The digital input is routed through a photo-coupler (PC3H4), so that the
connections are not polarity sensitive whether using positive or negative
voltages. The PCI-7258 digital input has an inline 2.4kΩ resistor and the
input voltage can ranges from 0 to 24V.

4.3 Interrupt Architecture

PCI-7258 has a powerful dual interrupt routing scheme and the interrupt
sources are on the digital input channels 0 and 1. Using these interrupts will
make handling complicated digital information much easier and relief your
computer from the heavy burden of dealing with digital input data. Note that
dual interrupts does not mean the card occupies two IRQ levels. The
interrupt will occur only when digital input level changes from 0 to 1. In other
words, the interrupt condition occurs on the
channel. Be sure to clear the interrupt request after handling the ISR or the
next interrupt request will not be received normally. For more information
about the interrupt operation, refer to section 5.6.

22 • Operation Theory

rising edge,

triggered on the DI

5

C/C++ DOS Libraries

This chapter describes the software libraries for operating this card. The
function prototypes and useful constants are defined in the header files
located in the LIB and INCLUDE directory.

5.1 Programming Guide

5.1.1 Naming Convention

The functions of the NuDAQ PCI or NuIPC CompactPCI card software
drivers uses full-names to represent the functions' real meaning. The naming
convention rules are:

_7258_Initial()

_{hardware_model}_{action_name}.

All functions in the PCI-7258 drivers are with 7258 as {hardware_model}.

e.g.

.

C/C++ Libraries • 23

5.1.2 Data Types

We have defined some data types in the ACL_PCI.h header file. These data
types are used by the NuDAQ Cards’ library. We suggest you use these data
types in your application programs. The following table shows the data type
names and their range.

Type Name Description Range

U8 8-bit ASCII character 0 to 255

I16 16-bit signed integer -32768 to 32767

U16 16-bit unsigned integer 0 to 65535

I32 32-bit signed integer -2147483648 to 2147483647

U32

F32

F64

Boolean Boolean logic value TRUE, FALSE

32-bit single-precision

floating-point

32-bit single-precision

floating-point

64-bit double-precision

floating-point

Table 3. Data Types and Range

-3.402823E38 to 3.402823E38

-1.797683134862315E308 to

1.797683134862315E309

0 to 4294967295

24 • C/C++ Libraries

5.2 _7258 Initial

@ Description

The PCI-7258 cards are initialized according to the card number. Because
the PCI-7258 is designed with the PCI bus architecture and meets the plug
and play specifications, the IRQ and base_address (pass-through address)
are assigned by system BIOS directly. Every PCI-7258 card has to be
initialized by this function before using any other functions.

@ Syntax

U16 _7258_Initial (U16 *existCards, PCI_INFO *pciInfo)

@ Argument

existCards: The number of installed PCI-7258 cards. The returned value

shows how many PCI-7258 cards are installed in the system.

pciInfo: This structure stores the PCI bus plug and play initialization

information which is determined by PnP BIOS. The PCI_INFO
structure is defined in the ACL_PCI.H header file. The base I/O
addresses and the interrupt channel number are stored in the
pciinfo, which is used for reference.

@ Return Code

ERR_NoError, ERR_PCIBiosNotExist, ERR_BoardNoInit,
ERR_InvalidBoardNumber

C/C++ Libraries • 25

5.3 _7258_DO

@ Description

@ Syntax

U16 _7258_DO (U16 boardID, U16 Group, U16 doData)

@ Argument

boardID: Board ID for the specific board.

Group: group 0 represents DO channel 1~16, group 1 represents DO

channel 17~32.

doData: value which will be written to digital output port.

@ Return Code

ERR_NoError, ERR_BoardNoInit, ERR_InvalidDOChannel

5.4 _7258_DO_Read_Back

@ Description

This function is used to read data back from the digital output port controlled
by the 7258_DO function. You can read back all relay status (close or open)
by using this function.

@ Syntax

U16 _7258_DO_Read_Back (U16 boardID, U16 Group, U16

*doReadBackData)

@ Argument

boardID : Board ID for the specific board.

Group: group 0 represents DO channel 1~16, group 1 represents DO

channel 17~32.

diReadBackData : Value read back from digital output port. ‘0’ represents

the PhotoMos relay is under open condition and ‘1’
represents the PhotoMos relay is under close condition.

@ Return Code

ERR_NoError, ERR_BoardNoInit, ERR_InvalidDOChannel

26 • C/C++ Libraries

5.5 _7258_DI

@ Description

This function is used to read data from the digital input port. There are 2 bits
in the Isolated Digital Input Register for digital inputs purposes. You can read
the input data by using this function.

@ Syntax

U16 _7258_DI (U16 boardID, U16 *diData)

@ Argument

boardID : Board ID for the specific board.

diData : return 16-bit value from digital input port. Only last 2 bit data are

valid.

@ Return Code

ERR_NoError, ERR_BoardNoInit

5.6 _7258_INT_Control

@ Description

This function is used to control the interrupt source of the PCI-7258. The
interrupt source can be the digital input of channel 0, 1 or both.

@ Syntax

U16 _7258_INT_Control (U16 boardID, U16 int1Flag, U16 int2Flag)

@ Argument

boardID: Board ID for the specific board.

Int1Flag: Digital input channel 0 interrupt control, “1” enable and “0”

disable.

Int2Flag: Digital input channel 1 interrupt control, “1” enable and “0”

disable.

@ Return Code

ERR_NoError, ERR_BoardNoInit

C/C++ Libraries • 27

5.9 _7258_CLR_IRQ

@ Description

This function is used to clear the interrupt request.

@ Syntax

U16 _7258_CLR_IRQ (U16 boardID)

@ Argument

boardID: Board ID for the specific board.

@ Return Code

ERR_NoError, ERR_BoardNoInit

5.10 _7258_GET_IRQ_Status

@ Description

This function is used to obtain the interrupt status.

@ Syntax

U16 _7258_GET_IRQ_Status (U16 boardID, U16 *int1Status, U16
*int2Status)

@ Argument

boardID: Board ID for the specific board.

Int1Status: interrupt source 0 status, “1” represents interrupt request assert

and “0” represents interrupt request de-assert.

Int2Status: interrupt source 1 status, “1” represents interrupt request assert

and “0” represents interrupt request de-assert.

@ Return Code

ERR_NoError, ERR_BoardNoInit

28 • C/C++ Libraries

Warranty Policy

Thank you for choosing ADLINK. To understand your rights and enjoy all the
after-sales services we offer, please read the following carefully.

1. Before using ADLINK’s products please read the user manual and
follow the instructions exactly. When sending in damaged products
for repair, please attach an RMA application form which can be
downloaded from: http://rma.adlinktech.com/policy/.

2. All ADLINK products come with a limited two-year warranty, one
year for products bought in China.

• The warranty period starts on the day the product is shipped from

ADLINK’s factory.

• Peripherals and third-party products not manufactured by

ADLINK will be covered by the original manufacturers' warranty.

• For products containing storage devices (hard drives, flash cards,

etc.), please back up your data before sending them for repair.
ADLINK is not responsible for any loss of data.

• Please ensure the use of properly licensed software with our

systems. ADLINK does not condone the use of pirated software
and will not service systems using such software. ADLINK will not
be held legally responsible for products shipped with unlicensed
software installed by the user.

• For general repairs, please do not include peripheral accessories.

If peripherals need to be included, be certain to specify which
items you sent on the RMA Request & Confirmation Form.
ADLINK is not responsible for items not listed on the RMA
Request & Confirmation Form.

3. Our repair service is not covered by ADLINK's guarantee in the
following situations:

• Damage caused by not following instructions in the User's

Manual.

• Damage caused by carelessness on the user's part during

product transportation.

• Damage caused by fire, earthquakes, floods, lightening, pollution,

other acts of God, and/or incorrect usage of voltage transformers.

• Damage caused by inappropriate storage environments such as

with high temperatures, high humidity, or volatile chemicals.

Warranty Policy • 29

• Damage caused by leakage of battery fluid during or after change

of batteries by customer/user.

• Damage from improper repair by unauthorized ADLINK

technicians.

• Products with altered and/or damaged serial numbers are not

entitled to our service.

• This warranty is not transferable or extendible.

• Other categories not protected under our warranty.

4. Customers are responsible for all fees necessary to transport
damaged products to ADLINK.

For further questions, please e-mail our FAE staff: [e-mail]

30 • Warranty Policy
