Adj Royal 3D II User Manual

ROYAL 3D II

Royal 3D II General Introduction

Unpacking: Thank you for purchasing the Royal 3D II by ADJ Prod-

ucts, LLC. Every Royal 3D II has been thoroughly tested and has been
shipped in perfect operating condition. Carefully check the shipping
carton for damage that may have occurred during shipping. If the

carton appears to be damaged, carefully inspect your xture for any

damage and be sure all equipment necessary to operate the unit has
arrived intact. In the event damage has been found or parts are miss­ing, please contact our toll free customer support number for further
instructions. Please do not return this unit to your dealer without con-

tacting customer support rst.

Introduction: The Royal 3D II is an incredible five channel DMX intel-

ligent, green and violet blue laser fixture. The blue laser combined with

the green laser create amazing aerial effects on a ceiling or wall. The
Royal 3D II can operate as a stand alone fixture, or in a Master/Slave
configuration. The Royal 3D II has two operating modes; sound active
or controlled via DMX. This fixture is suitable for theaters, studios,
retail stores, and other similar locations. For best results use fog or

special effects smoke to enhance the beams projections.

Customer Support: ADJ Products, LLC provides a toll free cus-

tomer support line, to provide set up help and to answer any question
should you encounter problems during your set up or initial operation.
You may also visit us on the web at www.adj.com for any comments
or suggestions. For service related issue please contact ADJ Products,
LLC. Service Hours are Monday through Friday 8:00 a.m. to 4:30 p.m.

Pacic Standard Time.

Voice: [phone]

Fax: [phone]

E-mail: [e-mail]

3/13

User Instructions

Warning! To prevent or reduce the risk of electrical shock or re, do

not expose this unit to rain or moisture.

Caution! There are no user serviceable parts inside this unit. Do not

attempt any repairs yourself, doing so will void your manufactures war­ranty. In the unlikely event your unit may require service please contact
ADJ customer support.

PLEASE recycle the shipping carton whenever possible.

ADJ Products, LLC - www.adj.com - Royal 3D II Instruction Manual Page 2

Royal 3D II General Instructions

!

!

Please carefully read and understand the instructions in this manual
thoroughly before attempting to operate this unit. These instructions
contain important safety information regarding the use and mainte­nance of this unit. Please keep this manual with the unit, for future
reference.

CAUTION IMPORTANT! When installing this projector, make sure
that it is mounted in a manner that prevents the audience from
looking directly into the beam, and the beam from striking the
audience.

Royal 3D II Features

• 30mW Green Laser & 350mW Violet Blue Laser

• 5 Channel DMX Control

• 2 Operating Modes - Sound Active & DMX Control

• Digital Display for Address and Function Setting

• UC3 Controller (Not Included)

• Run as Stand Alone unit or in a Master-Slave Conguration

• Power Cord Daisy Chain up to 14 units max. See page 16

Royal 3D II Warranty Registration

The Royal 3D II carries a 90 day limited warranty. Please fill out the
enclosed warranty card to validate your purchase. All returned ser­vice items whether under warranty or not, must be freight pre-paid
and accompany a return authorization (R.A.) number. If the unit is
under warranty you must provide a copy of your proof of purchase
invoice. Please contact ADJ customer support for a R.A. number.

Royal 3D II Installation

The unit should be mounted using a mounting clamp (not provided),

afxing it to the mounting bracket that is provided with the unit.
Always ensure that the unit is rmly xed to avoid vibration and slip-

ping while operating. Always ensure that the structure to which you

are attaching the unit is secure and is able to support a weight of 10
times the unit’s weight. Also, always use a safety cable that can hold
12 times the weight of the unit when installing the xture.

The equipment must be installed by a professional, and it must be

installed in a place where it is out of the reach of people’s grasp.

Royal 3D II Safety Precautions

LASER RADIATION AVOID
DIRECT EYE EXPOSURE

Maximum output <5 mW
Wavelength: 532nm, 450nm
Class IIIa laser product

This device complies with 21 CFR chapter I,
Subchapter J, CFR 1040.10 and 1040.1 1

Safety Issues: This unit may “pop” the fuse if the maximum allotted
load of 7 amps is reached.

• To reduce the risk of electrical shock or re, do not expose this unit

rain or moisture.

• Do not spill water or other liquids into or on to your unit.

• Do not attempt to remove or break off the ground prong from the

electrical cord. This prong is used to reduce the risk of electrical

shock and re in case of an internal short. Do not attempt to oper-

ate this unit if the power cord has been frayed or broken.

• Disconnect from main power before making any type of connection.

• Do not remove the cover under any conditions. There are no user

serviceable parts inside.

• Always be sure to mount this unit in an area that will allow proper
ventilation. Allow about 6” (15cm) between this device and a wall.

• Do not attempt to operate this unit, if it becomes damaged.

• This unit is intended for indoor use only, use of this product out-

doors voids all warranties.

• During long periods of non-use, disconnect the unit’s main power.

• Always mount this unit in safe and stable matter.

• Power cords should be routed so they are not likely to be walked

on, pinched by items placed upon or against them.

• Cleaning -The fixture should be cleaned only as recommended by
the manufacturer. See page 18 for cleaning details.

• Heat -The appliance should be situated away from heat sources

such as radiators, heat registers, stoves, or other appliances
(including amplifiers) that produce heat.

• The fixture should be serviced by qualified service personnel when:

A. The power-supply cord or the plug has been damaged.
B. Objects have fallen, or liquid has been spilled into the unit.

C. The unit has been exposed to rain or water.
D. The unit does not appear to operate normally or exhibits a

marked change in performance.

ADJ Products, LLC - www.adj.com - Royal 3D II Instruction Manual Page 4ADJ Products, LLC - www.adj.com - Royal 3D II Instruction Manual Page 3

Royal 3D II Laser Warnings and Safety

NON-INTERLOCKED HOUSING WARNING

The Royal 3D II contains high power laser devices internally. Do not

open the laser housing, due to the potential exposure to unsafe levels

of laser radiation. The laser power levels, if the unit is opened, can

cause instant blindness, skin burns and res.

Royal 3D II Laser Warnings and Safety

After setting up, and before public use, test laser to ensure proper
function. Do not use if any defect is detected. Do not use if laser
emits only one or two laser beams rather than dozens/hundreds, as
this could indicate damage to the diffraction grating optic, and could
allow emission of higher laser levels above Class 3R.

STOP AND READ ALL LASER SAFETY DATA

OPERATION INSTRUCTIONS AND LASER SAFETY

The light source emitted from this product can potentially cause eye
injury if not set up and used properly. The light source emitted from a
laser is very different from any other light sources with which you may
be aware of. Laser light is thousands of times more concentrated
than any light from any other kind of light source. This concentration
of light can cause instant eye injuries, primarily by burning the retina
(the back of your eyeball contatining cells that are sensitive to light).
Even if you cannot feel “heat” from a laser beam, it can still poten­tially injure or blind you or your audience. Even very small amounts
of laser beam light are potentially hazardous even at long distances.
Laser eye injuries can be sustained faster than you can blink.

Do not think that because this laser splits the laser beam into hun­dreds of beams and that the laser beam is scanned out in high

speed, that an individual laser beam is safe for eye exposure. This

laser uses dozens of milliwatts of laser power (Class 3B levels inter­nally) before it splits into multiple beams (Class 3R levels). Many of
the individual beams are potentially hazardous to the eyes.

Do not that because the laser light is moving, it is safe. This is not

true. Nor, do the laser beams always move. Since eye injuries can

occur instantly, it is critical to prevent even the smallest possibility of

any direct eye exposure. In the laser safety regulation, it is not legal
to aim Class 3R lasers in areas which people can get exposed. This
is true even if it is aimed below people’s faces, such as on a dance
oor.

Do not operate the laser without rst reading and understanding

all safety and technical data in this manual.

Always set up and install all laser effects so that all laser light is at

least 3 meters (9.8 feet) above the oor on which people can stand.

ADJ Products, LLC - www.adj.com - Royal 3D II Instruction Manual Page 5

Do not point lasers at people or animals. Never look into the laser

aperture or laser beams.

Do not point lasers in areas in which people can potentially get

exposed, such as uncontrolled balconies, etc.

Do not point lasers at highly reective surfaces, such as windows,
mirrors and shiny metal. Even laser reections can be hazardous.

Never point a laser at aircraft, this is a federal offense.

Never point un-terminated laser beams into the sky.

Do not expose the output optic (aperture) to cleaning chemicals.

Do not use laser if the laser appears to be emitting only one or two

beams.

Do not use the laser if the housing is damaged, the housing is open,
or if the optics appear damaged in any way.

Never open the laser housing. The high laser power levels inside of

the protective housing can start res, burn skin and will cause instant

eye injury.

Never leave this device running unattended.

The operation of a class 3R laser show is only allowed if the show
is controlled by a skilled and well- trained operator, familiar with the
data included in this manual.

The legal requirements for using laser entertainment products vary
from country to country. The user is responsible for the legal require­ments at the location/country of use.

Always use proper lighting safety cables when hanging lights and
effects overhead.

ADJ Products, LLC - www.adj.com - Royal 3D II Instruction Manual Page 6

Royal 3D II Laser Warning Labels

Specification stickers

LASER RA DIATIO N
IS EMITT ED FROM
THIS APER TURE

AVOID E XPOSU RE

A.D.J Supply Europe B.V
Junostraat 2,6468 EW Kerkrade,
Netherlands

Manufactured:

55mm

27mm

A.D.J Supply Europe B.V
Junostraat 2,6468 EW Kerkrade,
Netherlands

Manufactured:

Before use, you need to check

if it is allowed to use this item

in your country!

Specification stickers

LASER RA DIATIO N
IS EMITT ED FROM
THIS APER TURE

AVOID E XPOSU RE

40mm

40mm

Before use, you need to check

if it is allowed to use this item

in your country!

17mm

Royal 3D II Set Up

Power Supply: The ADJ Royal 3D II contains a automatic voltage

switch, which will auto sense the voltage when it is plugged into the
power source. With this switch there is no need to worry about the cor­rect power voltage, this unit can be plugged in anywhere.

DMX-512: DMX is short for Digital Multiplex. This is a universal pro-

tocol used by most lighting and controller manufactures as a form of
communication between intelligent fixtures and controllers. A DMX

controller sends DMX data instructions from the controller to the fix­ture. DMX data is sent as serial data that travels from fixture to fixture
via the DATA “IN” and DATA “OUT” XLR terminals located on all DMX
fixtures (most controllers only have a DATA “OUT” terminal).

DMX Linking: DMX is a language allowing all makes and models of
different manufactures to be linked together and operate from a sin­gle controller, as long as all xtures and the controller are DMX com­pliant. To ensure proper DMX data transmission, when using several

DMX fixtures try to use the shortest cable path possible. The order
in which fixtures are connected in a DMX line does not influence the
DMX addressing. For example; a fixture assigned a DMX address of 1
may be placed anywhere in a DMX line, at the beginning, at the end,
or anywhere in the middle. Therefore, the first fixture controlled by the
controller could be the last fixture in the chain. When a fixture is as­signed a DMX address of 1, the DMX controller knows to send DATA
assigned to address 1 to that unit, no matter where it is located in the
DMX chain.

Data Cable (DMX Cable) Requirements (For DMX and Master/Slave
Operation): The Royal 3D II can be controlled via DMX-512 protocol.

The Royal 3D II is a 5 channel DMX unit. The DMX address is set elec­tronically using the controls on the rear panel of
the unit. Your unit and your DMX controller require

a approved DMX-512 110 Ohm Data cable for data
input and data output (Figure 1). We recommend

20m m

Accu-Cable DMX cables. If you are making your

own cables, be sure to use standard 110-120 Ohm

shielded cable (This cable may be purchased at
almost all professional sound and lighting stores).
Your cables should be made with a male and

Figure 1

female XLR connector on either end of the cable. Also remember that

ADJ Products, LLC - www.adj.com - Royal 3D II Instruction Manual Page 8ADJ Products, LLC - www.adj.com - Royal 3D II Instruction Manual Page 7

Royal 3D II Set Up Royal 3D II Set Up

DMX cable must be daisy chained and cannot be split.

Notice: Be sure to follow gures two and three when making your own

cables. Do not use the ground lug on the XLR connector. Do not con-

nect the cable’s shield conductor to the ground lug or allow the shield
conductor to come in contact with the XLR’s outer casing. Grounding

the shield could cause a short circuit and erratic behavior.

COMMON

1 Ground

3 Hot

1

DMX512 IN

3

3-PIN XLR

2

XLR Pin Conguration

Pin 1 = Ground

Pin 2 = Data Compliment (negative)

Pin 3 = Data True (positive)

Figure 2

XLR Male Socket

1 Ground

Figure 3

DMX512 OUT

3-PIN XLR

2 Cold

3 Hot

1

3

2

2 Cold

DMX +

DMX -

XLR Female Socket

5-Pin XLR DMX Connectors.

Some manufactures use 5-pin DMX-

512 data cables for DATA transmission in place of 3-pin. 5-pin DMX
xtures may be implemented in a 3-pin DMX line. When inserting stan­dard 5-pin data cables in to a 3-pin line a cable adaptor must be used,

these adaptors are readily available at most electric stores. The chart
below details a proper cable conversion.

3-Pin XLR to 5-Pin XLR Conversion

Conductor 5-Pin XLR Male (In)3-Pin XLR Female (Out)

Ground/Shield

Data Compliment (- signal)

Data True (+ signal)

Not Used

Not Used

Pin 1

Pin 2

Pin 3

Pin 1

Pin 2

Pin 3

Pin 4 - Do Not Use

Pin 5 - Do Not Use

Special Note: Line Termination.

When longer runs of cable are

used, you may need to use a terminator on the last unit to avoid erratic
behavior. A terminator is a 110-120 ohm 1/4 watt resistor which is con­nected between pins 2 and 3 of a male XLR connector (DATA + and
DATA -). This unit is inserted in the female XLR connector of the last
unit in your daisy chain to terminate the line. Using a cable terminator
(ADJ part number Z-DMX/T) will decrease the possibilities of erratic
behavior.

Termination reduces signal errors and

1

avoids signal transmission problems

3

and interference. It is always advisable

2

to connect a DMX terminal, (Resistance
120 Ohm 1/4 W) between PIN 2 (DMX-)
and PIN 3 (DMX +) of the last fixture.

ADJ Products, LLC - www.adj.com - Royal 3D II Instruction Manual Page 9 ADJ Products, LLC - www.adj.com - Royal 3D II Instruction Manual Page 10

Figure 4

Royal 3D II System Menu Royal 3D II System Menu

System Menu: When conrming your setting press ENTER
and then hold MENU for at least 2-3 seconds, or you can
wait 1 minute for automatic setup. To exit without making
any adjustments press the MENU button.

ADDR - DMX Address Setting via control board.

1. Press the MENU button until “ADDR” is displayed, press ENTER.

2. “X” will now be displayed, “X” represents the displayed address.

Press the UP or DOWN buttons to nd your desired address.

3. Press ENTER to conrm, then connect your DMX controller.

NOTE: If after you connect your DMX controller the unit does not fall

into DMX mode, press and hold the MENU button for at least 3 sec­onds.

SLND - This will let you set unit as a slave in a master/

slave conguration.

1. Press the MENU button until “SLND” is displayed, press ENTER.

Either “SL 1” or “SL 2” will be displayed.

2. Press the UP or DOWN buttons until your desired setting is dis­played, press ENTER to conm.

NOTE: In a Master/Slave conguration you can make one xture the
Master and then set the next xture to “SL 2”, the xtures will now

have contrast movement to each other.

SOUN - In this mode you can run in sound active mode.

1. Press the MENU button until “SOUN” is displayed, press ENTER.

2. Either “ON” or “OFF” will now be displayed. Press the UP or DOWN
buttons to select one or the other.

3. When you have made your selection, press the ENTER, and then
press and hold the MENU button for at least 3 seconds to conrm.

ADJ Products, LLC - www.adj.com - Royal 3D II Instruction Manual Page 12ADJ Products, LLC - www.adj.com - Royal 3D II Instruction Manual Page 11

Royal 3D II System Menu Royal 3D II System Menu

SENS - Sound sensitivity control.

1. Press the MENU button until “SENS” is displayed, press ENTER.

2. The display will show a number between 0-100. Press the UP or
DOWN buttons to adjust the sound sensitivity. 0 being the least sen­sitive and 100 the most sensitive.

3. Press the ENTER to conrm.

DNST - This mode can be used as a precaution mode, that

in case the DMX signal is lost, the operating mode chosen

in the setup is the running mode the xture will go into when

the DMX signal is lost. You can also set this as the operat­ing mode you would like the unit to return to when power is
applied.

1. Press the MENU button until “DNST” is displayed, press
ENTER.

2. Either “MAST”, “BLND”, or “LAST” will be displayed. Choose
an operating mode you would like the unit to start up in when
power is applied or the DMX signal is lost.

• MAST (Master Slave) - If the DMX signal is lost or power is

applied, the unit will automatically go into Master Slave mode.

2. Either “ON” or “OFF” will now be displayed. Press the UP or DOWN
buttons to select “ON” to keep the LED display on at all times, or
“OFF” to allow the LED display to turn off after 2 minutes. Press any
button to turn on the LED display again.

3. Press ENTER, and then press and hold the MENU button for at least
three seconds to conrm.

DISP - This function will “ip” the LED display 180º.

1. Press the MENU button until “DISP” is displayed, press ENTER.

2. Either “dISP” or “dSIP” will now be displayed. Press the UP or

DOWN buttons to select one or the other.

3. Press ENTER, and then press and hold the MENU button for at least
three seconds to conrm.

TEST - This function will run a self test program.

1. Press the MENU button until “TEST” is displayed, press ENTER.

2. The unit will now run a self test. Press the MENU button to exit.

FHRS - With this function you can display the running

time of the unit.

1. Press the MENU button until “FHRS” is displayed, press ENTER.

• BLND (Blackout) - If the DMX signal is lost or power is applied,

the unit will automatically go into stand by mode.

• LAST (Last State) - If the DMX signal is lost the xture will stay

in the last DMX set up. If power is applied and this mode is set,
the unit will automatically go into the last DMX set up.

3. Press ENTER to conrm your desired set up.

LED - With this function the LED display will turn off after

2 minutes.

1. Press the MENU button until “LED” is displayed, press ENTER.

2. The running time of the xture will now be displayed. Press MENU
to exit.

VER - This will display the software version.

1. Press the MENU button until “VER” is displayed. Press the ENTER

button and the software vesion will be displayed.

2. Press the MENU button to leave this function.

RSET - Use this function to reset the unit.

1. Tap the MENU button until “RSET” is displayed, press ENTER.

2. The xture will now reset.

ADJ Products, LLC - www.adj.com - Royal 3D II Instruction Manual Page 14ADJ Products, LLC - www.adj.com - Royal 3D II Instruction Manual Page 13

Royal 3D II Operation

Royal 3D II Master-Slave Configuration

CAUTION IMPORTANT! When installing this projector, make sure
that it is mounted in a manner that prevents the audience from
looking directly into the beam, and the beam from striking the

audience.

Operating Modes: The Royal 3D II has two different operating
modes.

Universal DMX Control: This function allows you to use a Elation®

universal DMX-512 controller to control the individual lasers, rotation,
and macros. A DMX controller allows you to create unique programs
tailored to your individual needs.

1. The Royal 3D II is a five channel DMX fixture. See page 17 for

detailed description of the DMX values and traits.

2. To control your fixture in DMX mode, follow the set-up procedures
on pages 8-10 as well as the set-up specifications that are includ-

ed with your DMX controller.

3. Use the controller’s faders to control the various DMX fixture traits.

4. This will allow you to create your own programs.

5. Follow the instruction on page 12 to set the DMX address.

6. For longer cable runs (more than a 100 feet) use a terminator on
the last fixture.

7. For help operating in DMX mode consult the manual included
with your DMX controller.

Sound Active Mode (Stand Alone or Master-Slave): This mode

allows either single unit or several units linked together, to run to the
beat of the music.

1. Press the MENU button until “SOUN” is displayed, and press
ENTER.

2. Press the UP or DOWN buttons so that “ON” is displayed, and

press ENTER to conrm and then hold MENU for at least 2-3 sec-

onds.

3. To adjust the sound sensitivity press the MENU button until

“SENS” is displayed and press ENTER. Use the UP or DOWN
buttons to adjust sensitivity.

4. The optional UC3 Controller (not included) may be used to con-

trol different functions including blackout. See page 16 for UC3

controls and functions.

Master-Slave Conguration: This function will allow you to link

up to 16 units together and operate without a controller. The units will
be sound activated. In Master-Slave operation one unit will act as the
controlling unit and the others will react to the controlling units pro­grams. Any unit can act as a Master or as a Slave.

1. Using approved DMX data cables, daisy chain your units togeth-

er via the XLR connector on the rear of the units. Remember the
Male XLR connector is the input and the Female XLR connector

is the output. The rst unit in the chain (master) will use the female

XLR connector only - The last unit in the chain will use the male
XLR connector only. For longer cable runs we suggest a termina-

tor at the last fixture.

2. Set your Master unit to sound active mode.

3. On the slave units press the MENU button until “SLND” is dis-
played, and press ENTER. Choose either “SL 1” or “SL 2” and
press ENTER. See page 12 for more info.

4. The slave units will now follow the Master unit.

Royal 3D II Power Cord Daisy Chain

With this feature you can connect the xtures to one another
using the IEC input and output sockets. The quantity that can be
connected is 14 xtures maximum. After 14 xtures you will need
to use a new power outlet. They must be the same xtures. DO
NOT mix xtures.

Royal 3D II UC3 Control

Stand By Blackout the fixture

Function 1. Strobe Red

2. Strobe Green

3. Strobe in Green/Red

Mode Sound (LED OFF) Speed(LED ON)

Chase Speed

1-3

ADJ Products, LLC - www.adj.com - Royal 3D II Instruction Manual Page 15 ADJ Products, LLC - www.adj.com - Royal 3D II Instruction Manual Page 16

Royal 3D II DMX Traits

Royal 3D II Fuse Replacement

Channel Value Function
1 BLUE LASER

0 - 7 OFF

8 - 15 ON
16 - 239 STROBING SLOW - FAST
240 - 247 SOUND ACTIVE
248 - 255 ON

2 GREEN LASER
0 - 7 OFF

8 - 15 ON
16 - 239 STROBING SLOW - FAST
240 - 247 SOUND ACTIVE
248 - 255 ON
3 LASER ROTATION 1
0 - 127 0° - 360°
128 - 189 COUNTER - CLOCKWISE FAST - SLOW
190 - 193 NO ROTATION
194 - 255 CLOCKWISE SLOW - FAST
4 LASER ROTATION 2
0 - 127 0° - 360°
128 - 189 COUNTER - CLOCKWISE FAST - SLOW
190 - 193 NO ROTATION
194 - 255 CLOCKWISE SLOW - FAST
5 MACROS
0 - 7 NO FUNCTION
8 - 23 MACRO 1
24 - 39 MACRO 2
40 - 55 MACRO 3
56 - 71 MACRO 4
72 - 87 MACRO 5
88 - 103 MACRO 6
104 - 119 MACRO 7
120 - 135 MACRO 8
136 - 151 MACRO 9
152 - 167 MACRO 10
168 - 183 MACRO 11
184 - 199 MACRO 12
200 - 215 MACRO 13
216 - 231 MACRO 14
232 - 247 MACRO 15
248 - 255 SOUND ACTIVE

Locate and remove the unit’s power cord. Once the cord has been

removed located the fuse holder located inside the power socket.
Insert a flat-head screw driver into the power socket and gently pry
out the fuse holder. Remove the bad fuse and replace with a new one.
The fuse holder has a built-in socket for a spare fuse be sure not to
confuse the spare fuse with active fuse.

Royal 3D II Cleaning

Fixture Cleaning: Due to fog residue, smoke, and dust cleaning

the internal and external lenses should be carried out periodically to

optimize light output.

1. Use normal glass cleaner and a soft cloth to wipe down the out-

side casing.

2. Clean the external optics with glass cleaner and a soft cloth every

20 days.

3. Always be sure to dry all parts completely before plugging the
unit back in.

Cleaning frequency depends on the environment in which the fixture

operates (I.e. smoke, fog residue, dust, dew). In heavy use we recom­mend cleaning on a monthly basis. Periodic cleaning will ensure lon­gevity, and crisp beam output.

Royal 3D II Trouble Shooting

Trouble Shooting: Listed below are a few common problems that
you may encounter, with solutions.

No laser output from the unit;

1. Be sure you have turned “ON” the unit.

2. Be sure the external fuse has not blown. The fuse is located on
the rear panel of the unit.

3. Be sure the fuse holder is completely and properly seated.

4. Be sure the unit is not in blackout mode.

Unit does not respond to sound;

1. Low frequencies (bass) should cause the unit to react to sound.

Tapping on the microphone, quiet or high pitched sounds may
not activate the unit.

ADJ Products, LLC - www.adj.com - Royal 3D II Instruction Manual Page 17

ADJ Products, LLC - www.adj.com - Royal 3D II Instruction Manual Page 18

Royal 3D II Warranty

MANUFACTURER’S LIMITED WARRANTY

A. ADJ Products, LLC hereby warrants, to the original purchaser, ADJ Products, LLC products
to be free of manufacturing defects in material and workmanship for a prescribed period from
the date of purchase (see specific warranty period on reverse). This warranty shall be valid only if the
product is purchased within the United States of America, including possessions and
territories. It is the owner’s responsibility to establish the date and place of purchase by acceptable
evidence, at the time service is sought.

B. For warranty service you must obtain a Return Authorization number (RA#)

before sending back the product–please contact ADJ Products, LLC Service Department
at 800-322-6337. Send the product only to the ADJ Products, LLC factory. All

shipping charges must be pre-paid. If the requested repairs or service (including
parts replacement) are within the terms of this warranty, ADJ Products, LLC will pay return
shipping charges only to a designated point within the United States. If the entire instrument is
sent, it must be shipped in it’s original package. No accessories should be shipped with the product. If
any accessories are shipped with the product, ADJ Products, LLC shall have no liability whatsoever for
loss of or damage to any such accessories, nor for the safe return thereof.

C. This warranty is void if the serial number has been altered or removed; if the product is modified in any
manner which ADJ Products, LLC concludes, after inspection, affects the reliability of the product; if the
product has been repaired or serviced by anyone other than the ADJ Products, LLC factory unless prior
written authorization was issued to purchaser by ADJ Products, LLC; if the product is damaged because
not properly maintained as set forth in the instruction manual.

D. This is not a service contract, and this warranty does not include maintnance, cleaning or periodic check
up. During the period specified above, ADJ Products, LLC will replace defective parts at its expense
with new or refurbished parts, and will absorb all expenses for warranty service and repair labor by
reason of defects in material or workmanship. The sole responsibility of ADJ Products, LLC under this
warranty shall be limited to the repair of the product, or replacement thereof, including parts, at the sole
discretion of ADJ Products, LLC. All products covered by this warranty were manufactured after August
15, 2012, and bear indentifying marks to that effect.

E. ADJ Products, LLC reserves the right to make changes in design and/or improvements upon its products
without any obligation to include these changes in any products theretofore manufactured.

No warranty, whether expressed or implied, is given or made with respect to any accessory supplied with
products described above. Except to the extent prohibited by applicable law, all implied warranties made
by ADJ Products, LLC in connection with this product, including warranties of merchantability or fitness,
are limited in duration to the warranty period set forth above. And no warranties, whether expressed or
implied, including warranties of merchantability or fitness, shall apply to this product after said period
has expired. The consumer’s and/or Dealer’s sole remedy shall be such repair or replacement as is
expressly provided above; and under no circumstances shall ADJ Products, LLC be liable for any loss or
damage, direct or consequential, arising out of the use of, or inability to use, this product.

This warranty is the only written warranty applicable to ADJ Products, LLC Products and
supersedes all prior warranties and written descriptions of warranty terms and conditions heretofore
published.

Royal 3D II Specifications

Model: Royal 3D II

Voltage: 100~240V, 50~60Hz
Power Cord Daisy Chain: 14 Fixtures Max.
Power Consumption: 24W
Lasers: 30mW Green Diode

350mW Violet Blue Diode
Colors: Green & Violet Blue
Beam Angle: 90 Degrees
Dimensions: 8.25”(L) x 8”(W) x 7.5”(H)
207mm x 202mm x 187mm

Weight: 7 Lbs. / 3 kgs.
Fuse: 6.3 Amp
Duty Cycle: None
DMX: 5 DMX Channels

Sound Active: Ye s

Working Position: Any Safe, Secure Position
Warranty: 90 Days

Auto Sensing Voltage: This xture contains a automatic volt-

age switch, which will auto sense the voltage when it is plugged
into the power source.

Please Note: Specications and improvements in the design

of this unit and this manual are subject to change without any
prior written notice.

ADJ Products, LLC

6122 S. Eastern Ave. Los Angeles, CA 90040 USA

Tel: [phone] / Fax: [phone]

Web: www.adj.com / E-mail: [e-mail]

MANUFACTURER’S LIMITED WARRANTY PERIODS:

 •LightingProducts=1-year(365days)LimitedWarranty(Such as: Special Effect Lighting, Intelligent

Lighting, UV lighting, Strobes, Fog Machines, Bubble Machines, Mirror Balls, Par Cans, Trussing,
Lighting Stands etc. excluding LED and lamps)

 •LaserProducts=90-DayLimitedWarranty
 •L.E.D.Products=3-year(1095days)LimitedWarranty(excluding motors, PCB boards, and power

supplies, which have a 1-year (365 day Limited Warranty) and batteries which have a 180 day
limited warranty). Only the L.E.D.s carry a 3-year warranty

ADJ Products, LLC - www.adj.com - Royal 3D II Instruction Manual Page 19

A.D.J. Supply Europe B.V.

Junostraat 2

6468 EW Kerkrade

Netherlands

[e-mail] / www.adj.com

Tel: [phone] / Fax: [phone]
