ADJ LED Pixel 10C User Instructions

LED Pixel 10C Introduction
Unpacking: Thank you for purchasing the LED Pixel 10C by ADJ
Products, LLC. Every LED Pixel 10C has been thoroughly tested and has been shipped in perfect operating condition. Carefully check the shipping carton for damage that may have occurred during shipping.
If the carton appears to be damaged, carefully inspect your xture for
Introduction: The ADJ LED Pixel 4C 10-Channel Driver/Controller for
the LED Pixel Tube 360 (not included). This xture can be used in a stand alone mode or connected in a Master/Slave conguration. This
controller has five operating modes: Sound Active mode, Auto mode, RGB Dimmer mode, Static Color mode and DMX control mode.
Customer Support: ADJ Products, LLC provides a customer sup-
port line, to provide set up help and to answer any question should you encounter problems during your set up or initial operation. You may also visit us on the web at www.adj.com for any comments or sugges­tions. Service Hours are Monday through Friday 8:00 a.m. to 4:30 p.m.
Pacic Standard Time.
Voice: (323) 582-3322 Fax: (323) 582-3108 E-mail: support@adj.com
1/13
User Instructions
Warning! To prevent or reduce the risk of electrical shock or re, do
not expose this unit to rain or moisture.
Caution! There are no user serviceable parts inside this unit. Do not
attempt any repairs yourself, doing so will void your manufactures war­ranty. In the unlikely event your unit may require service please contact ADJ Products, LLC.
PLEASE recycle the shipping carton when ever possible.
ADJ Products, LLC - www.adj.com - LED Pixel 10C User Manual Page 2
LED Pixel 10C General Instructions
LED Pixel 10C Safety Precautions
To optimize the performance of this product, please read these operating instructions carefully to familiarize yourself with the basic operations of this unit. These instructions contain important safety information regarding the use and maintenance of this unit. Please keep this manual with the unit, for future reference.
LED Pixel 10C Features
• Mulit-Colors
• Five Operating Modes
• Electronic Dimming 0-100%
• Built in Microphone
• DMX-512 protocol
• 3-Pin DMX Connection
• 4 DMX Modes: 5 Channel Mode, 7 Channel Mode, 32 Channel
Mode, and 480 Channel Mode.
• ADJ LED RC compatiable (Not Included)
• Power Cord Daisy Chain (See page 23)
LED Pixel 10C Warranty Registration
The LED Pixel 10C carries a 1 year limited warranty. The reason this product carries a 1 year limited warranty is because it is a controller. Please fill out the enclosed warranty card to validate your purchase. All returned service items whether under warranty or not, must be freight pre-paid and accompany a return authorization (R.A.) number. The R.A. number must be clearly written on the outside of the return package. A brief description of the problem as well as the R.A. number must also be written down on a piece of paper included in the ship­ping carton. If the unit is under warranty, you must provide a copy of your proof of purchase invoice. You may obtain a R.A. number by con­tacting our customer support team on our customer support number. All packages returned to the service department not displaying a R.A. number on the outside of the package will be returned to the shipper.
• To reduce the risk of electrical shock or re, do not expose this unit
rain or moisture
• Do not spill water or other liquids into or on to your unit.
• Do not attempt to operate this unit if the power cord has been
frayed or broken. Do not attempt to remove or break off the ground prong from the electrical cord. This prong is used to reduce the risk
of electrical shock and re in case of an internal short.
• Disconnect from main power before making any type of connection.
• Do not remove the cover under any conditions. There are no user
serviceable parts inside.
• Never operate this unit when it’s cover is removed.
• Never plug this unit in to a dimmer pack
• Always be sure to mount this unit in an area that will allow proper
ventilation. Allow about 6” (15cm) between this device and a wall.
• Do not attempt to operate this unit, if it becomes damaged.
• This unit is intended for indoor use only, use of this product out`
doors voids all warranties.
• During long periods of non-use, disconnect the unit’s main power.
• Always mount this unit in safe and stable matter.
• Power-supply cords should be routed so that they are not likely to
be walked on or pinched by items placed upon or against them, paying particular attention to the point they exit from the unit.
• Cleaning -The fixture should be cleaned only as recommended by
t he manufacturer. See page 23 for cleaning details.
• Heat -The appliance should be situated away from heat sources
such as radiators, heat registers, stoves, or other appliances (inclu­ d ing amplifiers) that produce heat.
• The fixture should be serviced by qualified service personnel when:
A. The power-supply cord or the plug has been damaged.
B. Objects have fallen, or liquid has been spilled into the appliance.
C. The appliance has been exposed to rain or water. D. The appliance does not appear to operate normally or exhibits a marked change in performance.
ADJ Products, LLC - www.adj.com - LED Pixel 10C User Manual Page 4ADJ Products, LLC - www.adj.com - LED Pixel 10C User Manual Page 3
LED Pixel 10C Set Up
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
SOUND
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
SOUND
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
DMX512
DMX+,DMX-,COMMON
1
2
3
Termination reduces signal errors and avoids signal transmission problems and interference. It is always advisable to connect a DMX terminal, (Resistance 120 Ohm 1/4 W) between PIN 2 (DMX-) and PIN 3 (DMX +) of the last fixture.
POWER
SOUND
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
LED Pixel 10C Set Up
Power Supply: Before plugging your unit in, be sure the source
voltage in your area matches the required voltage for your ADJ LED Pixel 10C. Because line voltage may vary from venue to venue, you should be sure your unit voltage matches the wall outlet voltage before
attempting to operate you xture.
DMX-512: DMX is short for Digital Multiplex. This is a universal pro-
tocol used as a form of communication between intelligent fixtures and controllers. A DMX controller sends DMX data instructions from the controller to the fixture. DMX data is sent as serial data that trav­els from fixture to fixture via the DATA “IN” and DATA “OUT” XLR ter­minals located on all DMX fixtures (most controllers only have a DATA
“OUT” terminal).
DMX Linking: DMX is a language allowing all makes and models of different manufactures to be linked together and operate from a single controller, as long as all xtures and the controller are DMX compli­ant. To ensure proper DMX data transmission, when using several DMX fixtures try to use the shortest cable path possible. The order in which fixtures are connected in a DMX line does not influence the DMX addressing. For example; a fixture assigned a DMX address of 1 may be placed anywhere in a DMX line, at the beginning, at the end, or anywhere in the middle. When a fixture is assigned a DMX address of 1, the DMX controller knows to send DATA assigned to address 1 to that unit, no matter where it is located in the DMX chain.
Data Cable (DMX Cable) Requirements (For DMX Operation):
The LED Pixel 10C can be controlled via DMX-512 protocol. The LED
Pixel 10C has 4 DMX channel modes, please see page 7 for the different
DMX modes. The DMX address is set on the back panel of the LED Pixel 10C. Your unit and your DMX controller require a standard 3-pin XLR con­nector for data input and data output (Figure 1). We recommend Accu-Cable DMX cables. If you are making your own cables, be sure to use standard
110-120 Ohm shielded cable (This cable may be
purchased at almost all pro lighting stores). Your cables should be made with a male and female XLR connector on either end of the cable. Also remember that DMX cable must be daisy chained and cannot be split.
ADJ Products, LLC - www.adj.com - LED Pixel 10C User Manual Page 5
Figure 1
Notice: Be sure to follow gures two and three when making your own
cables. Do not use the ground lug on the XLR connector. Do not con-
nect the cable’s shield conductor to the ground lug or allow the shield conductor to come in contact with the XLR’s outer casing. Grounding
the shield could cause a short circuit and erratic behavior.
COMMON
1
DMX512 IN
3
3-PIN XLR
2
Figure 2
XLR Pin Conguration
1 Ground
3 Hot
Pin 1 = Ground
Pin 2 = Data Compliment (negative)
Pin 3 = Data True (positive)
When longer runs of cable are
Figure 4
Pin 1
Pin 2
Pin 3
Do Not Use
Do Not Use
XLR Male Socket
1 Ground
DMX512 OUT
3-PIN XLR
2 Cold
3 Hot
1
3
2
DMX +
DMX -
XLR Female Socket
2 Cold
Figure 3
Special Note: Line Termination.
used, you may need to use a terminator on the last unit to avoid erratic behavior. A terminator is a 110-120 ohm 1/4 watt resistor which is con­nected between pins 2 and 3 of a male XLR connector (DATA + and DATA -). This unit is inserted in the female XLR connector of the last unit in your daisy chain to terminate the line. Using a cable terminator (ADJ part number Z-DMX/T) will decrease the possibilities of erratic behavior.
5-Pin XLR DMX Connectors.
512 data cables for DATA transmission in place of 3-pin. 5-pin DMX xtures may be implemented in a 3-pin DMX line. When inserting stan­dard 5-pin data cables in to a 3-pin line a cable adaptor must be used, these adaptors are readily available at most electric stores. The chart below details a proper cable conversion.
Conductor 5-Pin XLR Male (In)3-Pin XLR Female (Out)
Ground/Shield
Data Compliment (- signal)
Data True (+ signal)
Not Used
Not Used
ADJ Products, LLC - www.adj.com - LED Pixel 10C User Manual Page 6
Termination reduces signal errors and
1
avoids signal transmission problems
3
and interference. It is always advisable
2
to connect a DMX terminal, (Resistance 120 Ohm 1/4 W) between PIN 2 (DMX-) and PIN 3 (DMX +) of the last fixture.
Some manufactures use 5-pin DMX-
3-Pin XLR to 5-Pin XLR Conversion
Pin 1
Pin 2
Pin 3
LED Pixel 10C Operating Instructions
LED Pixel 10C Operating Instructions
Operating Modes:
The LED Pixel 10C has five operating modes:
DMX control mode - This function will allow you to control each individual fixtures traits with a standard DMX 512 controller.
• RGB Dimmer Mode - Choose one of the three colors to remain
static or adjust the intensity of each color to make your own color.
• Sound-Active mode - The unit will react to sound. There are 24 sound active programs.
• Auto Mode - There are 2 different Auto Modes to choose from.
• Static Color Mode - Choose 1 of 7 colors to remain static.
DMX Mode:
Operating through a DMX controller gives the user the freedom to cre­ate their own programs tailored to their own individual needs. This func­tion also allows you to use your fixtures as spot lights. The LED Pixel
10C has 4 DMX modes: 5 Channel mode, 7 Channel mode, 32 Channel mode, and a 480 Channel mode. See pages 14-21 for each modes’ DMX
traits.
1. This function will allow you to control each individual fixture’s traits with a standard DMX 512 controller.
2. To run your fixture in DMX mode press the MODE button until
“A.XXX” is displayed. “XXX” represents the current displayed ad-
dress. Use the UP or DOWN buttons to select your desired DMX
address, then press the SETUP button to select your DMX Channel mode.
3. Use the UP or DOWN buttons to scroll through the DMX Channel
modes. The Channel modes are listed below:
To run the 5 Channel Mode, press the MODE button until “Ch.05”
is displayed. This is the 5 Channel DMX Mode.
To run the 7 Channel Mode, press the MODE button until “Ch.07” is displayed. This is the 7 Channel DMX Mode. To run the 32 Channel Mode, press the MODE button until
“Ch.32” is displayed. This is the 32 Channel DMX Mode.
To run the 480 Channel Mode, press the MODE button until
“Ch.48” is displayed. This is the 480 Channel DMX Mode.
4. Please see pages 14-21 for DMX values and traits.
5. After you have chosen your desired DMX Channel mode plug in
the fixture via the XLR connections to any standard DMX controller.
ADJ Products, LLC - www.adj.com - LED Pixel 10C User Manual Page 7
RGB Dimmer Mode:
1. Plug the fixture in and press the MODE button until “d-XX” is dis-
played. “XX” represents the current LED Pixel Tube being controlled. If “d-FU” is displayed then all of the tubes are being controlled. If “d-01” is displayed, you are controlling the tube connected to port 1. If “d-02” is displayed, you are controlling the tube connected to port
2. If “d-03” is displayed, your controlling the tube connected to port
3. If “d-04” is displayed, you are controlling the tube connected to port 4. After deciding what tube to control press the SET UP button.
2. When “r.XXX” is displayed you are in Red dimming mode. Press the
UP and DOWN buttons to adjust intensity. After you have finished
adjusting the intensity, or if you would like to skip to the next color, press the SET UP button.
3. When “G.XXX” is displayed you are in Green dimming mode. Press
the UP and DOWN buttons to adjust intensity.
4. When “b.XXX” is displayed you are in Blue dimming mode. Press the
UP and DOWN buttons to adjust intensity.
5. After you have adjusted the RGB colors to make your desired color you can then activate strobing by pressing the SET UP button to enter the Flash (strobe) mode.
6. “FS.XX” will be displayed, this is Flash mode. The Flash can be adjusted between “FS.00” (flash off) to “FS.15” (fastest flash).
Sound Active Mode:
In this mode the LED Pixel 10C will react to sound. There are 24 sound active programs to choose from. The sound sensitivity can also be adjusted.
1. Plug the fixture in and press the MODE button until “SoXX” is dis-
played. “XX” represents the sound active mode (1-24) currently dis-
played. Use the UP or DOWN buttons to scroll through the 24 sound
active programs.
2. When you have found your desired sound active program press the SET UP button to adjust the sound sensitivity. When you press SET
UP, “SJ-X” will be displayed. Use the UP or DOWN buttons to adjust
the sensitivity. “SJ-1” is the least sensitive, “SJ-8” is the most sensi­ tive.
Auto Run Mode: There are 2 different Auto Modes to choose from;
Color running
Fade, Color Change, and both modes running together.
speed is adjustable in all 2 modes.
ADJ Products, LLC - www.adj.com - LED Pixel 10C User Manual Page 8
The
LED Pixel 10C Operating Instructions
LED Pixel 10C Operating Instructions
1. Plug the fixture in and press the MODE button until either “AFXX”,
or “AJXX” is displayed. Press the SET UP button to switch between the different modes.
• AJXX = Color Change mode, there are 24 Color Change modes to choose from. Use the UP or DOWN buttons to scroll through the
different Auto Change modes.
• AFXX = Color Fade mode, there are 24 Color Fade modes to choose from. Use the UP or DOWN buttons to scroll through the different
Auto Fade modes.
2. After you have chosen your desired Auto Mode press the SET UP button until “SP.XX” is displayed. When this is displayed you can
adjust the running speed of your Auto Mode. Use the UP or DOWN
button to adjust the speed between “SP.01” (slowest) and “SP.16”
(fastest). Once you have set your desired running speed, press the
SET UP button to return to your desired Auto Mode.
Static Color Mode:
1. Plug the fixture in and press the MODE button until “S-XX” is dis-
played. “XX” represents the current LED Pixel Tube being controlled. If “S-FU” is displayed then all of the tubes are being controlled. If “S-01” is displayed, you are controlling the tube connected to port 1. If “S-02” is displayed, you are controlling the tube connected to port
2. If “S-03” is displayed, your controlling the tube connected to port
3. If “S-04” is displayed, you are controlling the tube connected to port 4. After deciding what tube to control press the SET UP button.
2. After pressing the SET UP button “CLXX” will be displayed.
3. There are 7 colors to choose from. Use the UP and DOWN buttons to scroll through the 7 colors. After you have found your desired
color you can activate strobing by pressing the SET UP button to enter the Flash (strobe) mode.
3. “FS.XX” will be displayed, this is Flash mode. The Flash can be adjusted between “FS.00” (flash off) to “FS.15” (fastest flash).
“don” = LED display on at all times. “doFF” = LED display shuts off after 10 seconds.
LED Display Inversion:
Follow these instructions to flip the display 180° so that the display can be read upside down.
1. Plug the fixture in and press the MODE button until “dXXX” is dis-
played.
2. Press the SET UP button until “Stnd” is displayed.
3. Press the UP or DOWN buttons to “flip” the display 180°.
Default Running Mode:
This is a default running mode. When this mode is activated all modes will return to their default settings.
1. Plug the fixture in and press the MODE button until “dXXX” is dis-
played.
2. Press the SET UP button until “dEFA” is displayed.
3. Press the UP and DOWN buttons simultaneously. Press the MODE
button to exit.
Infrared Receiver:
This function is used to activate and deactivate the infrared receiver. When this function is activated you can control the fixture using the ADJ LED RC (Remote Control). Please see the next page for ADJ LED RC controls and functions.
1. Plug the fixture in and press the MODE button until “dXXX” is dis-
played.
2. Press the SET UP button until “IrXX” is displayed. “XX” represents either “on” or “oF”.
3. Press the UP or DOWN buttons to either activate the remote func­ tion (On) or deactivate it (Off).
LED Display On/Off:
To set the LED display to turn off after 10 seconds, press the MODE but­ton until “dXXX” is displayed. “XXX” represents either “on” or “oFF”.
Press the UP or DONW buttons so that “doff” is displayed. Now the
display will disappear after 10s. Press any button to turn the display on again. Be advised though that the display will turn off automatically after 10 seconds.
ADJ Products, LLC - www.adj.com - LED Pixel 10C User Manual Page 10ADJ Products, LLC - www.adj.com - LED Pixel 10C User Manual Page 9
LED Pixel 10C Operating Instructions
LED Pixel 10C ADJ LED RC Operation
Master-Slave Operation:
This function will allows you to link units together to run in a Master-Slave configuration. In a Master-Slave configuration one unit will act as the controlling unit and the others will react and copy the controlling units operation. Any unit can act as a Master or as a Slave however, only one unit can be programmed to act as the “Master.”
Master-Slave Connections and Settings:
1. Daisy chain your units via the XLR connector on the rear of the unit. Use standard XLR data cables to link your units together. Remember that the Male XLR connector is the input and the Female XLR con­ nector is the ouput. The first unit in the chain (master) will use the female XLR connector only. The last unit in the chain will use the male XLR connector only.
2. Connect the rst “Slave” unit to the “Master.” Set the “Slave” to any
DMX Channel mode.
3. Set the “Master” unit to your desired mode of operation. The “Slave” unit will now follow the “Master”.
The ADJ LED RC infrared remote (sold seperately) has many differnet functions and gives you complete control of your LED Pixel 10C. To control the your desired fixture you must aim the controller at the front of the fixture and be no more the 30 feet away. To use the ADJ LED RC you must first activate the fixtures infrared receiver, to acti­vate the receiver please see the instructions on page 10.
BLACKOUT - Pressing this button will blackout the fixture.
AUTO RUN - Press this button to switch between the Color Change
mode and Color Fade mode. Use the “+” and “-” buttons to scroll through the 24 programs of each mode. You can control the speed of the modes by pressing the SPEED button first and then pressing the
“+” and “-” buttons.
PROGRAM SELECTION - This button activates static color mode and lets you select which tube to control. See Static Color mode for information on selecting the LED Pixel Tube. Use the “+” and “-” but-
tons to scroll through the 7 static colors and to scroll through the LED
Pixel tubes. Press the Flash button to activate strobing and use the “+” and “-” buttons to adjust the strobe speed.
SOUND ACTIVE - This button activates sound active mode. Use the “+” and “-” buttons to scroll through the 24 sound active modes. Press this button again to switch to sound sensitivity adjustment and use the “+” and “-” buttons to adjust the sound sensitivity.
ADJ Products, LLC - www.adj.com - LED Pixel 10C User Manual Page 11
FLASH - This button will activate the strobe effect. You can control the flash rate by pressing the “+” and “-” buttons. Press this button again to exit strobe mode.
SPEED - Press this button to activate and use the “+” & “-” buttons to adjust the speed of color fade and color change mode, color fade mode, color change mode, and the sound sensitivity level.
DMX MODE - This button will let you select which DMX mode you want to use. Use the “+” and “-” buttons to scroll through the DMX channel modes. Some fixtures will come with different DMX channel modes. This button will switch between the different modes. Please see pages 14-21 for DMX modes, values, and traits.
ADJ Products, LLC - www.adj.com - LED Pixel 10C User Manual Page 12
LED Pixel 10C ADJ LED RC Operation
SL (Slave) - This button lets you designate the unit as a slave in a
master-slave configuration.
SET ADDRESS - Press this button to set the DMX address. Press this button first, then press the numbers to set the address.
Example: Set DMX Address 1 Press “S-0-0-1” Set DMX Address 245 Press “S-2-4-5”
R G B - Press either one of these buttons and the press the “+” or “-” to adjust the brightness or use the number buttons to input a 3 num­ber intensity degree. Press the Flash button to activate strobing and use the “+” and “-” buttons to adjust the strobe speed.
“+” and “-” - Use these buttons to adjust the flash rate speed, program speed, fade speed, output intensity, and sound sensitiv­ity. These buttons are also used to scroll through the DMX channel modes, static colors, sound active modes, and auto run programs.
DMX Control:
Operating through an DMX controller gives the user the freedom to create their own programs tailored to their own individual needs. Follow the directions below to set your DMX Mode and address.
1. Before connecting to an DMX controller, your fixture has different DMX channel modes, please select your desired mode by press­ ing the DMX Mode button, then using the “+” or “-” buttons to scroll through the DMX Channel Modes. Set the mode before you address the fixture. See the bottom of this page for the DMX modes.
LED Pixel 10C 5 Channel - DMX Values & Functions
Channel Value Function
1 RED
0 - 255 0% - 100% 2 GREEN 0 - 255 0% - 100%
3 BLUE
0 - 255 0% - 100%
4 MASTER DIMMER
0 - 255 0% - 100% 5 SOUND ACTIVITY/STROBING 0 NO FUNCTION 1 - 5 SOUND ACTIVE 6 - 10 NO FUNCTION 11 - 255 STROBING SLOW - FAST
2. After you have selected your mode, set the DMX address for the fixture by pressing the “S” button. When the “S” button is pressed
the LED’s will flash 2-3 times and all the red LED’s will light. Use
the number buttons to press in your desired address. See “SET ADDRESS” located above for examples. Note: When setting the DMX address, each time a number is pressed
a LED color will glow, when you have set the DMX address correctly
all LED’s will flash 2-3 times.
3. Now you may connect the fixture via the XLR connections to any
standard DMX controller. Please see pages 14-21 to for a detailed descriptions of the DMX modes, values, and traits.
ADJ Products, LLC - www.adj.com - LED Pixel 10C User Manual Page 13 ADJ Products, LLC - www.adj.com - LED Pixel 10C User Manual Page 14
LED Pixel 10C 7 Channel - DMX Values & Functions
LED Pixel 10C 7 Channel - DMX Values & Functions
Channel Value Function
1 MASTER DIMMER
0 - 255 0% - 100% 2 STROBING/PROGRAM SPEED/ SOUND SENSITIVITY 0 - 27 STROBING OFF 28 - 255 STROBING SLOW - FAST 0 - 255 PROGRAM SPEED SLOW - FAST 0 - 31 SOUND SENSITIVITY OFF 32 - 255 SOUND SENSITIVE LEAST - MOST 3 DIMMING/STATIC COLOR SELECT/ COLOR CHANGE SELECT/ COLOR FADE SELECT 0 - 51 DIMMER MODE 52 - 102 COLOR MACRO MODE 103 - 153 COLOR CHANGE MODE 154 - 204 COLOR FADE MODE 205 - 255 SOUND ACTIVE MODE 4 COLOR MACROS & MODES
COLOR MACROS 0 - 31 BLACKOUT
32 - 63 RED
64 - 95 GREEN 96 - 127 BLUE 128 - 159 YELLOW
160 - 191 PURPLE
192 - 223 CYAN
224 - 255 WHITE
COLOR CHANGE MODE 0 - 10 COLOR CHANGE 1 11 - 20 COLOR CHANGE 2 21 - 31 COLOR CHANGE 3 32 - 42 COLOR CHANGE 4 43 - 52 COLOR CHANGE 5
ADJ Products, LLC - www.adj.com - LED Pixel 10C User Manual Page 15 ADJ Products, LLC - www.adj.com - LED Pixel 10C User Manual Page 16
Channel Value Function
4 COLOR CHANGE MODE CONT.
53 - 63 COLOR CHANGE 6 64 - 74 COLOR CHANGE 7 75 - 84 COLOR CHANGE 8 85 - 95 COLOR CHANGE 9 96 - 106 COLOR CHANGE 10 107 - 117 COLOR CHANGE 11 118 - 127 COLOR CHANGE 12 128 - 138 COLOR CHANGE 13 139 - 148 COLOR CHANGE 14 149 - 159 COLOR CHANGE 15 160 - 170 COLOR CHANGE 16 171 - 180 COLOR CHANGE 17 181 - 191 COLOR CHANGE 18 192 - 202 COLOR CHANGE 19 203 - 212 COLOR CHANGE 20 213 - 223 COLOR CHANGE 21 224 - 234 COLOR CHANGE 22 235 - 244 COLOR CHANGE 23 245 - 255 COLOR CHANGE 24
COLOR FADE MODE 0 - 10 COLOR FADE 1 11 - 20 COLOR FADE 2 21 - 31 COLOR FADE 3 32 - 42 COLOR FADE 4 43 - 52 COLOR FADE 5 53 - 63 COLOR FADE 6 64 - 74 COLOR FADE 7 75 - 84 COLOR FADE 8 85 - 95 COLOR FADE 9 96 - 106 COLOR FADE 10 107 - 117 COLOR FADE 11 118 - 127 COLOR FADE 12
LED Pixel 10C 7 Channel - DMX Values & Functions
LED Pixel 10C 7 Channel - DMX Values & Functions
Channel Value Function
4 COLOR FADE MODE CONT.
128 - 138 COLOR FADE 13 139 - 148 COLOR FADE 14 149 - 159 COLOR FADE 15 160 - 170 COLOR FADE 16 171 - 180 COLOR FADE 17 181 - 191 COLOR FADE 18 192 - 202 COLOR FADE 19 203 - 212 COLOR FADE 20 213 - 223 COLOR FADE 21 224 - 234 COLOR FADE 22 235 - 244 COLOR FADE 23 245 - 255 COLOR FADE 24
SOUND ACTIVE MODE 0 - 10 SOUND ACTIVE 1 11 - 20 SOUND ACTIVE 2 21 - 31 SOUND ACTIVE 3 32 - 42 SOUND ACTIVE 4 43 - 52 SOUND ACTIVE 5 53 - 63 SOUND ACTIVE 6 64 - 74 SOUND ACTIVE 7 75 - 84 SOUND ACTIVE 8 85 - 95 SOUND ACTIVE 9 96 - 106 SOUND ACTIVE 10 107 - 117 SOUND ACTIVE 11 118 - 127 SOUND ACTIVE 12 128 - 138 SOUND ACTIVE 13 139 - 148 SOUND ACTIVE 14 149 - 159 SOUND ACTIVE 15 160 - 170 SOUND ACTIVE 16 171 - 180 SOUND ACTIVE 17 181 - 191 SOUND ACTIVE 18 192 - 202 SOUND ACTIVE 19
Channel Value Function
4 SOUND ACTIVE MODE CONT.
203 - 212 SOUND ACTIVE 20 213 - 223 SOUND ACTIVE 21 224 - 234 SOUND ACTIVE 22 235 - 244 SOUND ACTIVE 23 245 - 255 SOUND ACTIVE 24
5 RED
0 - 255 0% - 100% 6 GREEN 0 - 255 0% - 100% 7 BLUE 0 - 255 0% - 100%
When Channel 3 is between the values of 0-51, Channels 5-7 are used, and Channel 2 will control strobing.
When Channel 3 is between the values of 52-102, Channel 4 is in Color Macros Mode, and Channel 2 will control strobing.
When Channel 3 is between the values of 103-153, Channel 4 is in Color Change Mode, and Channel 2 will control the color change speed.
When Channel 3 is between the values of 154-204, Channel 4 is in Color Fade Mode, and Channel 2 will control the color fade speed.
When Channel 3 is between the values of 205-255, Channel 4 is in Sound Active Mode, and Channel 2 will control the sound sensi­tivity.
ADJ Products, LLC - www.adj.com - LED Pixel 10C User Manual Page 17 ADJ Products, LLC - www.adj.com - LED Pixel 10C User Manual Page 18
LED Pixel 10C 32 Channel - DMX Values & Functions
LED Pixel 10C 32 Channel - DMX Values & Functions
Channel Value Function
1 MASTER DIMMER
0 - 255 0% - 100% 2 STROBING 0 - 27 STROBING OFF 28 - 255 STROBING SLOW - FAST
3 RED (TUBE 1)
0 - 255 0% - 100% 4 GREEN (TUBE 1) 0 - 255 0% - 100%
5 BLUE (TUBE 1)
0 - 255 0% - 100%
6 RED (TUBE 2)
0 - 255 0% - 100% 7 GREEN (TUBE 2) 0 - 255 0% - 100%
8 BLUE (TUBE 2)
0 - 255 0% - 100%
9 RED (TUBE 3)
0 - 255 0% - 100% 10 GREEN (TUBE 3) 0 - 255 0% - 100%
11 BLUE (TUBE 3)
0 - 255 0% - 100%
12 RED (TUBE 4)
0 - 255 0% - 100% 13 GREEN (TUBE 4) 0 - 255 0% - 100%
14 BLUE (TUBE 4)
0 - 255 0% - 100%
15 RED (TUBE 5)
0 - 255 0% - 100% 16 GREEN (TUBE 5) 0 - 255 0% - 100%
Channel Value Function
17 BLUE (TUBE 5)
0 - 255 0% - 100%
18 RED (TUBE 6)
0 - 255 0% - 100% 19 GREEN (TUBE 6) 0 - 255 0% - 100%
20 BLUE (TUBE 6)
0 - 255 0% - 100% 21 RED (TUBE 7) 0 - 255 0% - 100% 22 GREEN (TUBE 7) 0 - 255 0% - 100% 23 BLUE (TUBE 7) 0 - 255 0% - 100%
24 RED (TUBE 8)
0 - 255 0% - 100% 25 GREEN (TUBE 8) 0 - 255 0% - 100%
26 BLUE (TUBE 8)
0 - 255 0% - 100% 27 RED (TUBE 9) 0 - 255 0% - 100% 28 GREEN (TUBE 9) 0 - 255 0% - 100%
29 BLUE (TUBE 9)
0 - 255 0% - 100%
30 RED (TUBE 10)
0 - 255 0% - 100% 31 GREEN (TUBE 10) 0 - 255 0% - 100%
32 BLUE (TUBE 10)
0 - 255 0% - 100%
ADJ Products, LLC - www.adj.com - LED Pixel 10C User Manual Page 19 ADJ Products, LLC - www.adj.com - LED Pixel 10C User Manual Page 20
LED Pixel 10C 480 Channel - DMX Values & Functions
LED Pixel 10C Installation
Channel Value Function
1 RED (TUBE 1 PIXEL 1)
0 - 255 0% - 100% 2 GREEN (TUBE 1 PIXEL 1) 0 - 255 0% - 100%
3 BLUE (TUBE 1 PIXEL 1)
0 - 255 0% - 100%
4 RED (TUBE 1 PIXEL 2)
0 - 255 0% - 100% 5 GREEN (TUBE 1 PIXEL 2) 0 - 255 0% - 100%
6 BLUE (TUBE 1 PIXEL 2)
0 - 255 0% - 100% 7 RED (TUBE 1 PIXEL 3) 0 - 255 0% - 100% 8 GREEN (TUBE 1 PIXEL 3) 0 - 255 0% - 100%
*Channels 9-472 Continues the same RGB Tube Pixel pattern*
473 GREEN (TUBE 10 PIXEL 14) 0 - 255 0% - 100% 474 BLUE (TUBE 10 PIXEL 14) 0 - 255 0% - 100% 475 RED (TUBE 10 PIXEL 15) 0 - 255 0% - 100% 476 GREEN (TUBE 10 PIXEL 15) 0 - 255 0% - 100% 477 BLUE (TUBE 10 PIXEL 15) 0 - 255 0% - 100% 478 RED (TUBE 10 PIXEL 16) 0 - 255 0% - 100% 479 GREEN (TUBE 10 PIXEL 16) 0 - 255 0% - 100%
480 BLUE (TUBE 10 PIXEL 16)
0 - 255 0% - 100%
ADJ Products, LLC - www.adj.com - LED Pixel 10C User Manual Page 21 ADJ Products, LLC - www.adj.com - LED Pixel 10C User Manual Page 22
The LED Pixel 10C is fully operational in three different mounting positions, hanging upside-down from a ceiling, hanging sideways on
trussing, or set on a at level surface. The unit should be mounted using a mounting clamp (not provided), afxing it to the mounting
bracket that is provided with the unit. Always ensure that the unit is
rmly xed to avoid vibration and slipping while operating. Always
ensure that the structure to which you are attaching the unit is secure
and is able to support a weight of 10 times the unit’s weight. Also,
always use a safety cable that can hold 12 times the weight of the
unit when installing the xture.
The equipment must be installed by a professional, and it must be
installed in a place where it is out of the reach of people’s grasp.
LED Pixel 10C Connection & Linking
LED Pixel 10C Power Cord Daisy Chain
With this feature you can connect the controllers to one another using the IEC input and output sockets. The quantity that can be connected is 3 controllers maximum. After 3 controllers you will need to use a new power outlet. They must be the same control­lers. DO NOT mix controllers.
LED Pixel 10C Fuse Replacement
Disconnect the unit from its power source. Remove the power cord
from the unit. Once the cord has been removed, you will find that the
fuse holder is located inside the power socket. Insert a flat-head screw driver into the power socket and gently pry out the fuse holder. Remove the bad fuse and replace with a new one. The fuse holder also has a holder for a spare fuse.
LED Pixel 10C Cleaning
Due to fog residue, smoke, and dust cleaning the internal and exter­nal optical lenses must be carried out periodically to optimize light output.
1. Use normal glass cleaner and a soft cloth to wipe down the outside casing.
2. Clean the external optics with glass cleaner and a soft cloth every 20 days.
3. Always be sure to dry all parts completely before plugging the unit back in. Cleaning frequency depends on the environment in which the fixture operates (i.e. smoke, fog residue, dust, dew).
LED Pixel 10C Trouble Shooting
Listed below are a few common problems the user may encounter, with solutions.
LED Pixel 10C Warranty
MANUFACTURER’S LIMITED WARRANTY
A. ADJ Products, LLC hereby warrants, to the original purchaser, ADJ Products, LLC products to be free of manufacturing defects in material and workmanship for a prescribed period from the date of purchase (see specific warranty period on reverse). This warranty shall be valid only if the product is purchased within the United States of America, including possessions and territories. It is the owner ’s responsibility to establish the date and place of purchase by acceptable evidence, at the time service is sought.
B. For warranty service you must obtain a Return Authorization number (RA#) before sending back the product–please contact ADJ Products, LLC Service Department at 800-322-6337. Send the pro­ duct only to the ADJ Products, LLC factory. All shipping charges must be pre-paid. If the requested repairs or service (including parts replacement) are within the terms of this warranty, ADJ Products, LLC will pay return shipping charges only to a designated point within the United States. If the entire instrument is sent, it must be shipped in it’s original package. No accessories should be shipped with the product. If any accessories are shipped with the product, ADJ Products, LLC shall have no liability whatsoever for loss of or damage to any such accessories, nor for the safe return thereof.
C. This warranty is void if the serial number has been altered or removed; if the product is modified in any manner which ADJ Products, LLC concludes, after inspection, affects the reliability of the product; if the product has been repaired or serviced by anyone other than the ADJ Products, LLC factory unless prior written authorization was issued to purchaser by ADJ Products, LLC; if the product is damaged because not properly maintained as set forth in the instruction manual.
D. This is not a service contract, and this warranty does not include maintenance, cleaning or periodic check up. During the period specified above, ADJ Products, LLC will replace defective parts at its expense with new or refurbished parts, and will absorb all expenses for warranty service and repair labor by reason of defects in material or workmanship. The sole responsibility of ADJ Products, LLC under this warranty shall be limited to the repair of the product, or replacement thereof, including parts, at the sole discretion of ADJ Products, LLC. All products covered by this warranty were manufactured after August 15, 2012, and bear indentifying marks to that effect.
E. ADJ Products, LLC reserves the right to make changes in design and/or improvements upon it’s products without any obligation to include these changes in any products theretofore manufactured.
No warranty, whether expressed or implied, is given or made with respect to any accessory supplied with products described above. Except to the extent prohibited by applicable law, all implied warranties made by ADJ Products, LLC in connection with this product, including warranties of merchantability or fitness, are limited in duration to the warranty period set forth above. And no warranties, whether expressed or implied, including warranties of merchantability or fitness, shall apply to this product after said period has expired. The consumer’s and/or Dealer’s sole remedy shall be such repair or replacement as is expressly provided above; and under no circumstances shall ADJ Products, LLC be liable for any loss or damage, direct or consequential, arising out of the use of, or inability to use, this product.
Unit not responding to DMX:
1. Check that the DMX cables are connected properly and are wired correctly (pin 3 is “hot”; on some other DMX devices
pin 2 may be ‘hot’). Also, check that all cables are connected
to the right connectors; it does matter which way the inputs and outputs are connected.
Unit does not respond to sound:
1. Quiet or high pitched sounds will not activate the unit.
2. Make sure that Sound Active mode is activated.
ADJ Products, LLC - www.adj.com - LED Pixel 10C User Manual Page 23
This warranty is the only written warranty applicable to ADJ Products, LLC Products and supersedes all prior warranties and written descriptions of warranty terms and conditions heretofore published. This warranty was revised after December 1, 2012.
MANUFACTURER’S LIMITED WARRANTY PERIODS:
•LightingProducts=1-year(365days)LimitedWarranty(Such as: Special Effect Lighting, Intelligent
Lighting, UV lighting, Strobes, Fog Machines, Bubble Machines, Mirror Balls, Par Cans, Trussing, Lighting Stands etc. excluding LED, Laser Products and lamps)
•LaserProducts=90-DayLimitedWarranty  •L.E.D.Products=3-year(1095days)LimitedWarranty(excluding motors, PCB boards, and power
supplies, which have a 1-year (365 day Limited Warranty) and batteries which have a 180 day limited warranty). Only the L.E.D.s carry a 3-year warranty
ADJ Products, LLC - www.adj.com - LED Pixel 10C User Manual Page 24
LED Pixel 10C Notes
LED Pixel 10C Notes
ADJ Products, LLC - www.adj.com - LED Pixel 10C User Manual Page 25
ADJ Products, LLC - www.adj.com - LED Pixel 10C User Manual Page 26
LED Pixel 10C Specifications
Model:
Voltage: 120v/60Hz or 240v/50Hz Working Position: Any safe working position Power Draw: 200W Power Cord Daisy Chain: 3 Controllers Max. Fuse: 4 Amp (120V)/ 2 Amp (240V) Weight: 6lbs./ 4.2Kgs.
Dimensions: 12.75” (L) x 11.25” (W) x 3.25” (H)
318 x 280 x 80mm DMX Channels: 4 DMX Modes: 5 Channel Mode,
7 Channel Mode, 32 Channel
Mode, and 480 Channel Mode Warranty: 1 Year (365 days)
Please Note: Specications and improvements in the design of
this unit and this manual are subject to change without any prior written notice.
LED Pixel 10C
ADJ Products, LLC - www.adj.com - LED Pixel 10C User Manual Page 27
ADJ Products, LLC
6122 S. Eastern Ave. Los Angeles, CA 90040 USA
Tel: 323-582-2650 / Fax: 323-725-6100
Web: www.adj.com / E-mail: info@adj.com
A.D.J. Supply Europe B.V.
Junostraat 2
6468 EW Kerkrade
Netherlands
service@adj.eu / www.adj.com
Tel: +31 45 546 85 00 / Fax: +31 45 546 85 99
Loading...
