ADJ H2O LED IR Users Manual

H20 IR

©2015 ADJ Products, LLC all rights reserved. Information,

specications, diagrams, images, and instructions herein are
subject to change without notice. ADJ Products, LLC logo and
identifying product names and numbers herein are trademarks
of ADJ Products, LLC. Copyright protection claimed includes all
forms and matters of copyrightable materials and information
now allowed by statutory or judicial law or hereinafter granted.
Product names used in this document may be trademarks or
registered trademarks of their respective companies and are
hereby acknowledged. All non-ADJ Products, LLC brands and
product names are trademarks or registered trademarks of their

respective companies.

ADJ Products, LLC and all aliated companies hereby dis­claim any and all liabilities for property, equipment, building,
and electrical damages, injuries to any persons, and direct or
indirect economic loss associated with the use or reliance of
any information contained within this document, and/or as a
result of the improper, unsafe, unsucient and negligent as­sembly, installation, rigging, and operation of this product.

6/15

User Instructions

Europe Energy Saving Notice
Energy Saving Matters (EuP 2009/125/EC)
Saving electric energy is a key to help protecting the enviroment.
Please turn o all electrical products when they are not in use. To
avoid power consumption in idle mode, disconnect all electrical
equipment from power when not in use. Thank you!

H2O IR Introduction

H2O IR General Instructions

Introduction:

Thank you for purchasing the H2O IR by ADJ Products, LLC. The H2O
IR is an improvement of the very popular H2O LED. This new unit has
better optics and brighter LED output producing vibrant colors. It can
also be used with the ADJ UC IR (sold separately). This unit is suitable
for theaters, studios, retail stores, and other similar locations.

Unpacking: Every H2O IR has been thoroughly tested and has been
shipped in perfect operating condition. Carefully check the shipping
carton for damage that may have occurred during shipping. If the
carton appears to be damaged, carefully inspect your units for any
damage and be sure all accessories necessary to operate the system
have arrived intact. In the event damage has been found or parts are
missing, please contact our toll free customer support number for fur­ther instructions. Please do not return the system to your dealer with­out rst contacting customer support.

Customer Support:

ADJ Products, LLC provides a toll free customer support line, to pro­vide set up help and to answer any question should you encounter
problems during your set up or initial operation. You may also visit us
on the web at www.adj.com for any comments or suggestions. Ser­vice Hours are Monday through Friday 8:00 a.m. to 4:30 p.m. Pacic
Standard Time.
Voice: [phone]
Fax: [phone]
E-mail: [e-mail]
To purchase parts online visit http://parts.americandj.com

Warning! To prevent or reduce the risk of electrical shock or re, do
not expose this unit to rain or moisture.

Caution! There are no user serviceable parts inside this unit. Do not
attempt any repairs yourself, doing so will void your manufactures
warranty. In the unlikely event your unit may require service please
contact ADJ.

Please recycle the shipping cartoon when ever possible.

To optimize the performance of this product, please read these
operating instructions carefully to familiarize yourself with the basic
operations of this unit. These instructions contain important safety
information regarding the use and maintenance of this unit. Please
keep this manual with the unit, for future reference.

H2O IR Features

• Includes Built-In Hanging Yoke

• 5 Colors Plus White

• Color Mixing

• 34 Degree Lens & Optional 43 Degree Lens

• ADJ UC IR Compatible (Sold Separately)

H2O IR Warranty Registration

The H2O IR carries a two year (730 days) limited warranty. Please
fill out the enclosed warranty card to validate your purchase. All
returned service items whether under warranty or not, must be freight
pre-paid and accompany a return authorization (R.A.) number. The
R.A. number must be clearly written on the outside of the return
package. A brief description of the problem as well as the R.A. num­ber must also be written down on a piece of paper and included in
the shipping container. If the unit is under warranty, you must pro­vide a copy of your proof of purchase invoice. You may obtain a R.A.
number by contacting customer support at [phone].

H2O IR Installation

The unit should be mounted using a mounting clamp (not provided),
axing it to the mounting bracket that is provided with the unit.
Always ensure that the unit is rmly xed to avoid vibration and slip­ping while operating. Always ensure that the structure to which you
are attaching the unit is secure and is able to support a weight of 10
times the unit’s weight. Also always use a safety cable that can hold
12 times the weight of the unit when installing the xture.
The equipment must be installed by a professional, and it must be
installed in a place where it is out of the reach of people’s grasp.

ADJ Products, LLC - www.adj.com - H2O IR Instruction Manual Page 2

ADJ Products, LLC - www.adj.com - H2O IR Instruction Manual Page 3
