American DJ
FS-1000
®
User Instructions
™
R O
P
HALOGEN LAMP WARNING!
This fixture is fitted with halogen lamps
which are highly susceptible to damage if
improperly handled. Never touch lamp with
bare fingers as the oil from your hands will
shorten lamp life. Also, never move fixture
until lamp has had ample time to cool.
Remember, lamps are not covered under
warranty conditions.
O L L O WS PO T
F
Caution! Always disconnect from main
power before replacing lamps or servicing unit.
Remember to always replace with same lamps
and fuses.
CAUTION! WARNING! The top of unit gets extremely hot, watch where you rest your hands,
or objects that can melt or burn.
Model:
SPECIFICATIONS:
FS-1000™
Lamp: ZB-HX600 120V 575W
Power: 110V/60Hz
Fuse : 5 A GMA
Ventilation: Fan Cooling
Working Position: Any
Weight: 17 lbs.
23 lbs. w/ tripod stand
Size: 7 1/2” x 7 1/2” x 22”
Beam Spread:
From 30 ft. : 5 1/2 ft.
From 60 ft. : 10 3/4 ft
Thank you for purchasing this
American DJ® product. For your
convenience this lighting effect has
been lamped and is ready to be used,
there is no assembly required. Please
read the following instructions before
installing or using your new unit.
Operating Instructions:
Unit is ready to be hung or set on a Tripod. The
FS1000™ features a bright HX-600 575 watt lamp,
dual focusing knobs for precise, full focusing, iris
control knob at top of unit can also blackout, dimmer knob at back of un it, handle, gel frame, and
a hanging bracket. Optional LTS-5 tripod stand
comes w system. Color gels not included. The
ADJ FS-6C, color changer adapter, which fits on
the front of the FS-1000™, gives the user convenient access to 4 color gels or to mix colors
between the four(FS-6C sold separately).
Notice: When unit is brand new
smoke will emit from the inside of unit. This is
the paint on the inside burning off. There is no
problem with the unit, this is normal.
To replace lamp; unscrew screws on the back
of the unit, pull out module, replace bulb and reassemble. Do not forget to unplug unit before replacing bulb!
Fuse is located underneath mains input
For service, contact your American DJ™ dealer.
American DJ ®
LOS ANGELES, CA. 90058
