ADJ Flat Par CWWW9 Operation Manual

Flat Par CWWW9 Introduction

Unpacking: Thank you for purchasing the Flat Par CWWW9 by Amer-

ican DJ®. Every Flat Par CWWW9 has been thoroughly tested and has
been shipped in perfect operating condition. Carefully check the ship­ping carton for damage that may have occurred during shipping. If the

carton appears to be damaged, carefully inspect your xture for any

damage and be sure all accessories necessary to operate the unit has
arrived intact. In the case damage has been found or parts are miss­ing, please contact our toll free customer support number for further
instructions. Do not return this unit to your dealer without rst contact­ing customer support.

Introduction: The American DJ® Flat Par CWWW9 is part of a con-

tinuing pursuit to create high quality intelligent lighting. The Flat Par
CWWW9 is a DMX intelligent, high powered LED par fixture. This x­ture can be used in a stand alone mode or connected in a Master/Slave

conguration. This wash has six operating modes: Sound Active mode,

Auto mode, CW & WW dimmer modes, Fade mode, White Preset Mode
(Color Temperature mode) and DMX control mode.

Customer Support: American DJ provides a customer support line,

to provide set up help and to answer any question should you encoun­ter problems during your set up or initial operation. You may also visit
us on the web at www.American DJ.com for any comments or sugges-

tions. Service Hours are Monday through Friday 8:00 a.m. to 4:30 p.m.
Pacic Standard Time.
Voice: [phone]
Fax: [phone]
E-mail: [e-mail]

Rev. 11/11

User Instructions

Warning! To prevent or reduce the risk of electrical shock or re, do

not expose this unit to rain or moisture.

Caution! There are no user serviceable parts inside this unit. Do not

attempt any repairs yourself, doing so will void your manufactures war­ranty. In the unlikely event your unit may require service please contact
American DJ.

PLEASE recycle the shipping carton when ever possible.

©American DJ® - www.Americandj.com - Flat Par CWWW9 User Manual Page 2

Flat Par CWWW9 General Instructions

Flat Par CWWW9 Safety Precautions

To optimize the performance of this product, please read these
operating instructions carefully to familiarize yourself with the basic
operations of this unit. These instructions contain important safety
information regarding the use and maintenance of this unit. Please
keep this manual with the unit, for future reference.

Flat Par CWWW9 Features

• Cool White & Warm White

• Six Operating Modes

• Electronic Dimming 0-100%

• Built in Microphone

• DMX-512 protocol

• 3-Pin DMX Connection

• 3 DMX Modes: 3 Channel Mode, 4 Channel Mode, and 5 Channel

Mode

• ADJ LED RC2 compatiable (Not Included)

• Power Cord Daisy Chain (See page 9)

Flat Par CWWW9 Warranty Registration

The Flat Par CWWW9 carries a 3 year limited warranty. Please fill out
the enclosed warranty card to validate your purchase. All returned
service items whether under warranty or not, must be freight pre-paid

and accompany a return authorization (R.A.) number. The R.A. number

must be clearly written on the outside of the return package. A brief

description of the problem as well as the R.A. number must also be

written down on a piece of paper included in the shipping carton. If
the unit is under warranty, you must provide a copy of your proof of

purchase invoice. You may obtain a R.A. number by contacting our

customer support team on our customer support number. All pack-

ages returned to the service department not displaying a R.A. number

on the outside of the package will be returned to the shipper.

• To reduce the risk of electrical shock or re, do not expose this unit

rain or moisture

• Do not spill water or other liquids into or on to your unit.

• Do not attempt to operate this unit if the power cord has been
frayed or broken. Do not attempt to remove or break o the ground

prong from the electrical cord. This prong is used to reduce the risk

of electrical shock and re in case of an internal short.

• Disconnect from main power before making any type of connection.

• Do not remove the cover under any conditions. There are no user

serviceable parts inside.

• Never operate this unit when it’s cover is removed.

• Never plug this unit in to a dimmer pack

• Always be sure to mount this unit in an area that will allow proper
ventilation. Allow about 6” (15cm) between this device and a wall.

• Do not attempt to operate this unit, if it becomes damaged.

• This unit is intended for indoor use only, use of this product out`

doors voids all warranties.

• During long periods of non-use, disconnect the unit’s main power.

• Always mount this unit in safe and stable matter.

• Power-supply cords should be routed so that they are not likely to

be walked on or pinched by items placed upon or against them,

paying particular attention to the point they exit from the unit.

• Cleaning -The fixture should be cleaned only as recommended by
t he manufacturer. See page 16 for cleaning details.

• Heat -The appliance should be situated away from heat sources

such as radiators, heat registers, stoves, or other appliances (inclu­ d ing amplifiers) that produce heat.

• The fixture should be serviced by qualified service personnel when:

A. The power-supply cord or the plug has been damaged.

B. Objects have fallen, or liquid has been spilled into the appliance.
C. The appliance has been exposed to rain or water.
D. The appliance does not appear to operate normally or exhibits a

marked change in performance.

©American DJ® - www.Americandj.com - Flat Par CWWW9 User Manual Page 4©American DJ® - www.Americandj.com - Flat Par CWWW9 User Manual Page 3

Flat Par CWWW9 Set Up

REMOTE

CONTROL

INPUT

POWER

INPUT OUTPUT

SOUND

REMOTE

CONTROL

INPUT

POWER

INPUT OUTPUT

SOUND

REMOTE

CONTROL

INPUT

POWER

INPUT OUTPUT

DMX512

DMX+,DMX-,COMMON

1

2

3

Termination reduces signal errors and
avoids signal transmission problems
and interference. It is always advisable
to connect a DMX terminal, (Resistance
120 Ohm 1/4 W) between PIN 2 (DMX-)
and PIN 3 (DMX +) of the last fixture.

POWER

SOUND

REMOTE

CONTROL

INPUT

POWER

INPUT OUTPUT

Flat Par CWWW9 Set Up

Power Supply: The American DJ Flat Par CWWW9 contains a auto­matic voltage switch, which will auto sense the voltage when it is
plugged into the power source. With this switch there is no need to
worry about the correct power voltage, this unit can be plugged in
anywhere.

DMX-512: DMX is short for Digital Multiplex. This is a universal pro-

tocol used as a form of communication between intelligent fixtures

and controllers. A DMX controller sends DMX data instructions from

the controller to the fixture. DMX data is sent as serial data that trav­els from fixture to fixture via the DATA “IN” and DATA “OUT” XLR ter­minals located on all DMX fixtures (most controllers only have a DATA
“OUT” terminal).

DMX Linking: DMX is a language allowing all makes and models of

dierent manufactures to be linked together and operate from a single
controller, as long as all xtures and the controller are DMX compli-

ant. To ensure proper DMX data transmission, when using several

DMX fixtures try to use the shortest cable path possible. The order
in which fixtures are connected in a DMX line does not influence the
DMX addressing. For example; a fixture assigned a DMX address of 1

may be placed anywhere in a DMX line, at the beginning, at the end,

or anywhere in the middle. When a fixture is assigned a DMX address
of 1, the DMX controller knows to send DATA assigned to address 1

to that unit, no matter where it is located in the DMX chain.

Data Cable (DMX Cable) Requirements (For DMX Operation):

The Flat Par CWWW9 can be controlled via DMX-512 protocol. The Flat
Par CWWW9 has 3 DMX channel modes, please see pages 7-8 for the
dierent modes. The DMX address is set on the back panel of the Flat

Par CWWW9. Your unit and your DMX controller

require a standard 3-pin XLR connector for data
input and data output (Figure 1). We recommend

Accu-Cable DMX cables. If you are making your

own cables, be sure to use standard 110-120 Ohm

shielded cable (This cable may be purchased at
almost all pro lighting stores). Your cables should

be made with a male and female XLR connector

on either end of the cable. Also remember that
DMX cable must be daisy chained and cannot be split.

©American DJ® - www.Americandj.com - Flat Par CWWW9 User Manual Page 5

Figure 1

Notice: Be sure to follow gures two and three when making your own

cables. Do not use the ground lug on the XLR connector. Do not con­nect the cable’s shield conductor to the ground lug or allow the shield
conductor to come in contact with the XLR’s outer casing. Grounding

the shield could cause a short circuit and erratic behavior.

COMMON

1

DMX512 IN

3

3-PIN XLR

2

Figure 2

XLR Pin Conguration

1 Ground

3 Hot

Pin 1 = Ground

Pin 2 = Data Compliment (negative)

Pin 3 = Data True (positive)

When longer runs of cable are

Figure 4

Pin 1

Pin 2

Pin 3

Do Not Use

Do Not Use

XLR Male Socket

1 Ground

DMX512 OUT

3-PIN XLR

2 Cold

3 Hot

1

3

2

DMX +

DMX -

XLR Female Socket

2 Cold

Figure 3

Special Note: Line Termination.

used, you may need to use a terminator on the last unit to avoid erratic

behavior. A terminator is a 110-120 ohm 1/4 watt resistor which is con­nected between pins 2 and 3 of a male XLR connector (DATA + and
DATA -). This unit is inserted in the female XLR connector of the last

unit in your daisy chain to terminate the line. Using a cable terminator
(ADJ part number Z-DMX/T) will decrease the possibilities of erratic
behavior.

5-Pin XLR DMX Connectors.

512 data cables for DATA transmission in place of 3-pin. 5-pin DMX
xtures may be implemented in a 3-pin DMX line. When inserting stan­dard 5-pin data cables in to a 3-pin line a cable adaptor must be used,

these adaptors are readily available at most electric stores. The chart
below details a proper cable conversion.

Conductor 5-Pin XLR Male (In)3-Pin XLR Female (Out)

Ground/Shield

Data Compliment (- signal)

Data True (+ signal)

Not Used

Not Used

©American DJ® - www.Americandj.com - Flat Par CWWW9 User Manual Page 6

Termination reduces signal errors and

1

avoids signal transmission problems

3

and interference. It is always advisable

2

to connect a DMX terminal, (Resistance
120 Ohm 1/4 W) between PIN 2 (DMX-)
and PIN 3 (DMX +) of the last fixture.

Some manufactures use 5-pin DMX-

3-Pin XLR to 5-Pin XLR Conversion

Pin 1

Pin 2

Pin 3

Flat Par CWWW9 Operating Instructions

Flat Par CWWW9 Operating Instructions

LED Display On/Off:

To set the LED display to turn off after 10 seconds, press the MODE but­ton until “dS-X” is displayed, press the UP or DOWN button to display
“dS-2”. Now the display will disappear after 10s. Press any button to
turn the display on again. Be advised though that the display will turn off
automatically after 10 seconds.

To set the display press the MODE button until “dS-X” is displayed. Use
the UP or DOWN buttons to select either:
“dS-1” = LED display on at all times.
“dS-2” = LED display shuts off after 10 seconds.

Operating Modes:

The Flat Par CWWW9 has six operating modes:

• DMX control mode - This function will allow you to control each
individual fixtures traits with a standard DMX 512 controller such as

as the American DJ® Show Designer™.

• Cool White & Warm White Dimmer Mode - Adjust the intensity of

each color to make your own desired color. You can also use strob-

ing in this mode.

• White Preset Mode - Choose 1 of 19 White Preset Colors. You can

also use strobing in this mode.

• Fade Mode - In this mode the colors will fade in and out of each other.

You can also use strobing in this mode.

• Sound-Active mode - The unit will react to sound, chasing through the
built in programs.

• Auto Mode - In this mode the unit will cycle through different modes.

DMX Mode:

Operating through a DMX controller gives the user the freedom to create
their own programs tailored to their own individual needs. This function

also allows you to use your fixtures as spot lights. The Flat Par CWWW9
has 3 DMX modes: 3 Channel mode, 4 Channel mode, and a 5 Channel
mode. See pages 13-14 for each modes’ DMX traits.

1. This function will allow you to control each individual fixture’s traits
with a standard DMX 512 controller.

2. To run your fixture in DMX mode press the MODE button until
“XXXX” is displayed. “XXXX” represents the current displayed DMX

Mode and address.

3. Press the SET UP Button to scroll through the 3 DMX Channel

modes. When you have found your desired DMX mode, use the UP

©American DJ® - www.Americandj.com - Flat Par CWWW9 User Manual Page 7

or DOWN buttons to select your desired DMX address. The DMX

Channel Modes are listed below.

• To run the 3 Channel Mode, press the MODE button until “1XXX”

is displayed. This is the 3 Channel DMX Mode.

• To run the 4 Channel Mode, press the MODE button until “2XXX”
is displayed. This is the 4 Channel DMX Mode.

• To run the 5 Channel Mode, press the MODE button until “3XXX”
is displayed. This is the 5 Channel DMX Mode.

4. After you have chosen your desired DMX Channel mode plug in

the fixture via the XLR connections to any standard DMX controller.

5. Please see pages 13-14 for DMX values and traits.

Cool White & Warm White Dimmer Mode:

1. Plug the fixture in and press the MODE button until:

2. When “4.XXX” is displayed you are in Cool White dimming mode.
Press the UP and DOWN buttons to adjust intensity.

3. When “5.XXX” is displayed you are in Warm White dimming mode.
Press the UP and DOWN buttons to adjust intensity.

4. After you have adjusted the RGB colors to make your desired color

you can then activate strobing by pressing the SET UP button to
enter the Flash (strobe) mode.

5. “7-XX” will be displayed, this is Flash mode. The Flash can be
adjusted between “7-00” (flash off) to “7-20” (fastest flash).

White Preset Mode (Preset Color Temperature):

In this mode you are able to choose one of 19 preset white colors (preset

color temperatures).

1. Plug the fixture in and press the MODE button until “6-XX” is dis-
played. “XX” represents the current color number that is displayed.
There are 19 color temperatures to choose from.

2. Use the UP and DOWN buttons to find your desired preset color.
See the chart on page 10 for the list of color temperatures.

3. After you have found your desired color temperature you can then

activate strobing by pressing the SET UP button to enter the Flash
(strobe) mode.

4. “7-XX” will be displayed, this is Flash mode. The Flash can be
adjusted between “7-00” (flash off) to “7-20” (fastest flash).

Fade Mode:

1. Plug the fixture in and press the MODE button until “8-XX” is dis-

©American DJ® - www.Americandj.com - Flat Par CWWW9 User Manual Page 8

Flat Par CWWW9 Operating Instructions

Flat Par CWWW9 Master-Slave Configuration

played. “XX” represents the displayed fade speed number.

2. Use the UP and DOWN buttons to adjust the fade speed. “8-01” is
the slowest speed, and “8-16” is the fastest. After you have selected

your desired color you can activate strobing by pressing the SET UP
button to enter the Flash (strobe) mode.

3. “7-XX” will be displayed, this is Flash mode. The Flash can be
adjusted between “7-00” (flash off) to “7-20” (fastest flash).

Sound Active Mode:

In this mode the Flat Par CWWW9 will react to sound, and chase through
the different colors.

1. Plug the fixture in and press the MODE button until “9-SO” is dis-

played.

2. The fixture will now change via sound.

Auto Mode:

1. Plug the fixture in and press the MODE button until “AUTO” is dis-

played. Auto mode is now active.

Infrared Receiver:

This function is used to activate and deactivate the infrared receiver.

When this function is activated you can control the fixture using the
ADJ LED RC (Remote Control). Please see page 11 for ADJ LED RC

controls and functions.

1. Plug the fixture in and press the MODE button until “Ir-X” is dis-
played. “X” represents either “1” (On) or “2” (Off).

2. Press the UP or DOWN buttons to either activate the remote func­ tion (1) or deactivate it (2).

Flat Par CWWW9 Power Cord Daisy Chain

With this feature you can connect the xtures to one another

using the IEC input and output sockets. The quantity that can be

connected is 20 xtures maximum. After 20 xtures you will need
to use a new power outlet. They must be the same xtures. DO
NOT mix xtures.

Master-Slave Configuration:

This function will allows you to link units together to run in a Master-Slave
mode. In Master-Slave operation one unit will act as the controlling unit
and the others will react to the controlling units built-in programs. Any
unit can act as a Master or as a Slave however, only one unit can be pro-

grammed to act as the “Master.”

Master-Slave Connections and Settings:

1. Daisy chain your units via the XLR connector on the rear of the unit.
Use standard XLR data cables to link your units together. Remember
that the Male XLR connector is the input and the Female XLR con-
nector is the ouput. The first unit in the chain (master) will use the
female XLR connector only. The last unit in the chain will use the
male XLR connector only.

2. On the “Master” unit, set your desired operating mode. For the
“Slave” unit, press the MODE button until “SLAV” is displayed

3. Now connect the “Slave” unit to the “Master” unit using the XLR con-

nections.

Flat Par CWWW9 Color Preset Chart

MODE Color Temperature DMX Values

etihW mraW etihWlooC

19 7400K 255 2

18 7200K 255 11

17 7000K 255 20

16 6800K 255 30

15 6600K 255 42

14 6400K 255 56

13 6200K 255 72

12 6000K 255 91

11 5800K 255 113

10 5600K 255 138

9 5400K 255 170

8 5100K 255 231

7 5000K 255 255

6 4800K 204 255

5 4600K 161 255

4 4300K 106 255

3 4000K 61 255

2 3800K 35 255

1 3400K 0 255

©American DJ® - www.Americandj.com - Flat Par CWWW9 User Manual Page 10©American DJ® - www.Americandj.com - Flat Par CWWW9 User Manual Page 9

Flat Par CWWW9 ADJ LED RC2 Operation

Flat Par CWWW9 ADJ LED RC2 Operation

The ADJ LED RC2 infrared remote (sold seperately) has many dif-
ferent functions and gives you complete control of your Flat Par
CWWW9. To control the your desired fixture you must aim the con-

troller at the front of the fixture and be no more the 30 feet away. To
use the ADJ LED RC2 you must first activate the fixtures infrared re-

ceiver, to activate the receiver please see the instructions on page 9.

BLACKOUT - Pressing this button will blackout the fixture.

PROGRAM SELECTION - This button has 3 functions; Auto Run,

Display On/Off, and White presets. Each press of this button will
change to the next function. Note: To know what function you are

in, it is helpful to have a good view of the LED display.

• When the unit is in Auto Run you can adjust the speed of the Auto
Run. Press the speed button (this will put the unit into Fade Mode)
and use the “+” or “-” buttons to adjust the speed, the press the
Program Selection button to return to Auto Run. The Auto Run will
now run at the speed you set. When this mode is active, “AUTO” will

be seen on the LED display.

• When the unit is in Display On/Off mode, press the “+” or “-” but­tons to switch the operating mode of the display. See LED Display

On/Off on page 8.

• When the unit is in White Presets mode, press the “+” or “-” buttons
to scroll through the different presets. When this mode is active, “6-

XX” will appear in the LED display.

FLASH - This button will activate the strobe effect. You can control

the flash rate by pressing the “+” and “-” buttons. Press this button
again to exit strobe mode.

SPEED - Pressing this button will activate Fade Mode. Press this

button and use the “+” & “-” buttons to adjust the speed of the Fade

Mode.

DMX MODE - This button will let you select which DMX mode you

want to use. Some fixtures will come with different DMX channel

modes. This button will switch between the different modes. Please

see pages 14-15 for DMX modes, values, and traits.

SL/SA (Slave or Sound Active) - This button lets you toggle be­tween Slave mode and Sound Active mode.

• When the display reads “Slav”, it means that the unit is designated
as a slave in a Master-Slave configuration. See page 10 for Master-

Slave configuration.

• When the display reads “9-SO”, the unit is in Sound Active mode.

SET ADDRESS - Press this button to set the DMX address. Press
this button first, then press the numbers to set the address.

Example: Set DMX Address 1 Press “S-0-0-1”
Set DMX Address 245 Press “S-2-4-5”

R G B - These buttons are not functional with this unit.

W - When the “W” button is pressed Cool White will be activated.

After pressing either of these buttons press the “+” or “-” to adjust the

brightness.

A - When the “A” button is pressed Warm White will be activated.
After pressing either of these buttons press the “+” or “-” to adjust the

brightness.

“+” and “-” - Use these buttons to adjust the flash rate, speed of the
Fade Mode, and program selection.

DMX Control:

Operating through an DMX controller gives the user the freedom to
create their own programs tailored to their own individual needs.
Follow the directions below to set your DMX Mode and address.

1. Before connecting to an DMX controller, your fixture has different

DMX channel modes, please select your desired mode by press-

ing the DMX Mode button, then using the “+” or “-” buttons to

scroll through the DMX Channel Modes. Set the mode before you

address the fixture. See the next page for the DMX modes.

2. After you have selected your mode, set the DMX address for the

fixture by pressing the “S” (Set Addr) button. When the “S” button
is pressed the LED’s will flash 2-3 times. Use the number buttons to

press in your desired address. See “SET ADDRESS” on this page

for examples.

Note: When seeting the DMX address each time a number is pressed
a LED color will glow, when you have set the DMX address correctly

all LED’s will flash 2-3 times.

©American DJ® - www.Americandj.com - Flat Par CWWW9 User Manual Page 11

©American DJ® - www.Americandj.com - Flat Par CWWW9 User Manual Page 12

Flat Par CWWW9 ADJ LED RC2 Operation

Flat Par CWWW9 3 Channel - DMX Values & Functions

3. Now you may connect the fixture via the XLR connections to any

standard DMX controller. Please see pages 14-15 to for a detailed
descriptions of the DMX modes, values, and traits.

• If the Cool White LED’s glow you are in DMX Mode 1: 3 DMX

Channel.

• If the Warm White LED’s glow you are in DMX Mode 2: 4 DMX

Channels.

• If all of the LED’s glow you are in DMX Mode 3: 5 DMX

Channels.

Channel Value Function

1 COOL WHITE

1 - 255 0% - 100%
2 WARM WHITE
1 - 255 0% - 100%
3 WHITE PRESETS
1 - 13 3400K
14 - 27 3800K
28 - 41 4000K
42 - 55 4300K
56 - 69 4600K
70 - 83 4800K
84 - 97 5000K
98 - 111 5100K
112 - 125 5400K
126 - 139 5600K
140 - 153 5800K
154 - 167 6000K
168 - 181 6200K
182 - 195 6400K
196 - 209 6600K
210 - 223 6800K
224 - 236 7000K
237 - 248 7200K
249 - 255 7400K

©American DJ® - www.Americandj.com - Flat Par CWWW9 User Manual Page 13 ©American DJ® - www.Americandj.com - Flat Par CWWW9 User Manual Page 14

Flat Par CWWW9 4 Channel - DMX Values & Functions

Flat Par CWWW9 Fuse Replacement

Channel Value Function

1 COOL WHITE

1 - 255 0% - 100%
2 WARM WHITE
1 - 255 0% - 100%
3 WHITE PRESETS
1 - 255 Please see 3 Channel Mode
4 STROBING
0 OFF
1 - 255 STROBING SLOW - FAST

Flat Par CWWW9 5 Channel - DMX Values & Functions

Channel Value Function

1 COOL WHITE

1 - 255 0% - 100%
2 WARM WHITE
1 - 255 0% - 100%
3 WHITE PRESETS
1 - 255 Please see 3 Channel Mode
4 STROBING
0 OFF
1 - 255 STROBING SLOW - FAST
5 MASTER DIMMER
1 - 255 0% - 100%

Disconnect the unit from its power source. Remove the power cord
from the unit. Once the cord has been removed, you will find that the

fuse holder is located inside the power socket. Insert a flat-head screw

driver into the power socket and gently pry out the fuse holder. Remove

the bad fuse and replace with a new one. The fuse holder also has a
holder for a spare fuse.

Flat Par CWWW9 Cleaning

Due to fog residue, smoke, and dust cleaning the internal and exter­nal optical lenses must be carried out periodically to optimize light
output.

1. Use normal glass cleaner and a soft cloth to wipe down the

outside casing.

2. Clean the external optics with glass cleaner and a soft cloth
every 20 days.

3. Always be sure to dry all parts completely before plugging

the unit back in.

Cleaning frequency depends on the environment in which the fixture

operates (i.e. smoke, fog residue, dust, dew).

©American DJ® - www.Americandj.com - Flat Par CWWW9 User Manual Page 15

©American DJ® - www.Americandj.com - Flat Par CWWW9 User Manual Page 16

Flat Par CWWW9 Installation

The Flat Par CWWW9 is fully operational in three dierent mounting

positions, hanging upside-down from a ceiling, hanging sideways on

trussing, or set on a at level surface. The unit should be mounted
using a mounting clamp (not provided), axing it to the mounting

bracket that is provided with the unit. Always ensure that the unit is

rmly xed to avoid vibration and slipping while operating. Always

ensure that the structure to which you are attaching the unit is secure

and is able to support a weight of 10 times the unit’s weight. Also,
always use a safety cable that can hold 12 times the weight of the
unit when installing the xture.

The equipment must be installed by a professional, and it must be

installed in a place where it is out of the reach of people’s grasp.

Flat Par CWWW9 Trouble Shooting

Listed below are a few common problems the user may encounter,
with solutions.

Unit not responding to DMX:

1. Check that the DMX cables are connected properly and are
wired correctly (pin 3 is “hot”; on some other DMX devices
pin 2 may be ‘hot’). Also, check that all cables are connected
to the right connectors; it does matter which way the inputs

and outputs are connected.

Unit does not respond to sound:

1. Quiet or high pitched sounds will not activate the unit.

2. Make sure that Sound Active mode is activated.

Flat Par CWWW9 Warranty

MANUFACTURER’S LIMITED WARRANTY

A. American DJ, Inc. hereby warrants, to the original purchaser, American DJ and American
Audio products to be free of manufacturing defects in material and workmanship for a prescribed

period from the date of purchase (see specic warranty period on reverse). This warranty shall be

valid only if the product is purchased within the United States of America, including possessions
and territories. It is the owner’s responsibility to establish the date and place of purchase by ac­ceptable evidence, at the time service is sought.

B. For warranty service you must obtain a Return Authorization number (RA#) before
sending back the product. Contact American DJ, Inc. Service Department at 800-322-6337. Send

the product only to the American DJ, Inc. factory. All shipping charges must be pre-paid. If the
requested repairs or service (including parts replacement) are within the terms of this warranty,
American DJ, Inc. will pay return shipping charges only to a designated point within the United

States. If the entire instrument is sent, it must be shipped in it’s original package. No accessories

should be shipped with the product. If any accessories are shipped with the product, American DJ,
Inc. shall have no liability whatsoever for loss of or damage to any such accessories, nor for the
safe return thereof.

C. This warranty is void if the serial number has been altered or removed; if the product is
modied in any manner which American DJ, Inc. concludes, after inspection, aects the reliability
of the product; if the product has been repaired or serviced by anyone other than the American DJ,
Inc. factory unless prior written authorization was issued to purchaser by American DJ, Inc.; if the

product is damaged because not properly maintained as set forth in the instruction manual.

D. This is not a service contract, and this warranty does not include maintenance, cleaning

or periodic check-up. During the period specied above, American DJ, Inc. will replace defective
parts at its expense with new or refurbished parts, and will absorb all expenses for warranty service

and repair labor by reason of defects in material or workmanship. The sole responsibility of Ameri­can DJ, Inc. under this warranty shall be limited to the repair of the product, or replacement thereof,
including parts, at the sole discretion of American DJ. All products covered by this warranty were

manufactured after January 1, 1990, and bear identifying marks to that eect.

E. American DJ, Inc. reserves the right to make changes in design and/or improvements
upon its products without any obligation to include these changes in any products theretofore man-

ufactured. No warranty, whether expressed or implied, is given or made with respect to any acces­sory supplied with products described above. Except to the extent prohibited by applicable law, all

implied warranties made by American DJ, Inc. in connection with this product, including warranties

of merchantability or tness, are limited in duration to the warranty period set forth above. And no
warranties, whether expressed or implied, including warranties of merchantability or tness, shall
apply to this product after said period has expired. The consumer’s and/or Dealer’s sole remedy
shall be such repair or replacement as is expressly provided above; and under no circumstances

shall American DJ, Inc. be liable for any loss or damage, direct or consequential, arising out of the
use of, or inability to use, this product.

This warranty is the only written warranty applicable to American DJ and American Audio
Products and supersedes all prior warranties and written descriptions of warranty terms and
conditions heretofore published.

MANUFACTURER’S LIMITED WARRANTY PERIODS:

• All American Audio Products = 1-year (365 day) Limited Warranty (except V-Plus Series Ampli­ers)

• All American Audio V-Plus Series Ampliers = 3-year (1095 day) Limited Warranty

• American DJ Lighting and American DJ Branded Products = 1-year (365 day) Limited Warranty
(Such as: Special Eect Lighting, Intelligent Lighting, UV lighting, Strobes, Fog Machines, Bubble
Machines, Mirror Balls, Par Cans, Trussing, Lighting Stands etc. excluding Laser Products, lamps,

and Star Tec Series)

• American DJ Laser Products and Star Tec Products = 90-Day Limited Warranty

• American DJ L.E.D. Products = 3-year (1095 day) Limited Warranty (excluding motors which have
a 1-year (365 day Limited Warranty)

©American DJ® - www.Americandj.com - Flat Par CWWW9 User Manual Page 18©American DJ® - www.Americandj.com - Flat Par CWWW9 User Manual Page 17

Flat Par CWWW9 Specifications

Model:

Voltage: 100V ~ 240V/50~60Hz
LEDs: 9 x 3 Watt LED’s (4 Cool White & 5

Warm White)

Beam Angle: 40 Degrees
Working Position: Any safe working position
Power Consumption: 28.5W
Power Cord Daisy Chain: 20 Fixtures Max.
Fuse: 1 Amp
Weight: 5.5lbs./ 2.5Kgs.
Dimensions: 10.7” (L) x 9” (W) x 4” (H)
272 x 229 x 102mm
Colors: Cool White & Warm White
DMX Channels: 3 DMX Modes: 3 Channel Mode,
4 Channel Mode, & 5 Channel

Mode
Mode

Warranty: 3 Year (1,095 days)

Flat Par CWWW9

Auto Sensing Voltage: This xture contains a automatic volt-

age switch, which will auto sense the voltage when it is plugged
into the power source.

Please Note: Specications and improvements in the design of

this unit and this manual are subject to change without any prior
written notice.

©American DJ Supply

American DJ World Headquarters:

6122 S. Eastern Ave. Los Angeles, CA 90040 USA

Tel: [phone] / Fax: [phone]

Web: www.americandj.com / E-mail: [e-mail]

©American DJ® - www.Americandj.com - Flat Par CWWW9 User Manual Page 19

American DJ Europe

Junostraat 2

6468 EW Kerkrade

Netherlands

[e-mail] / www.americandj.eu

Tel: [phone] / Fax: [phone]
