ADJ D-Light Sync Pak Operation Manual

American DJ

D-LIGHT SYNC PAK

D-Light Sync Pak Introduction

Introduction: Thank you for purchasing the D-Light Sync Pak by
American DJ®. The D-Light Sync Pak is a simple, plug and play light­ing effect. The D-Light connects to adaptable Sony® audio systems
that have the Sony® DLS-1 controller. The unit uses two lamps in each
light, and colored lenses to create bright, colorful, beams of light. This
unit is sound active and includes a built-in microphone. The D-Light
Sync Pak is designed for house partys, backyard parties, small gather­ings, and any area that requires a compact, light weight, easy to use
fixture.

Unpacking: Every D-Light Sync Pak has been thoroughly tested and
has been shipped in perfect operating condition. Carefully check the
shipping carton for damage that may have occurred during shipping. If
the carton appears to be damaged, carefully inspect your units for any
damage and be sure all accessories necessary to operate the system
have arrived intact. In the event damage has been found or parts are
missing, please contact our toll free customer support number for fur­ther instructions. Please do not return the system to your dealer with­out first contacting customer support.

3/06

User Instructions

American DJ®

4295 Charter Street

Los Angeles Ca. 90058

www.americandj.com

Customer Support: American DJ
port line, to provide set up help and to answer any question should you
encounter problems during your set up or initial operation. You may
also visit us on the web at www.americandj.com for any comments or
suggestions. Service Hours are Monday through Friday 9:00 a.m. to
5:00 p.m. Pacific Standard Time.
Voice: [phone]
Fax: [phone]
E-mail: [e-mail]
To purchase parts online visit http://parts.americandj.com

American DJ Europe Customer Support:
Voice: [phone]

Fax: [phone]
E-mail: [e-mail]

Warning! To prevent or reduce the risk of electrical shock or fire, do
not expose this unit to rain or moisture.

Do not discard the shipping cartoon in the trash. Please recycle when
ever possible.

©American DJ Supply® - www.americandj.com - D-Light Sync Pak User Manual Page 2

® provides a toll free customer sup-

D-Light Sync Pak General Instructions

To optimize the performance of this product, please read these
operating instructions carefully to familiarize yourself with the basic
operations of this unit. These instructions contain important safety
information regarding the use and maintenance of this unit. Please
keep this manual with the unit, for future reference.

D-Light Sync Pak Service Warning

There are no user serviceable parts inside this unit. Do not attempt any
repairs yourself, doing so will void your manufactures warranty. In the
unlikely event your unit may require service please contact your near­est American DJ dealer.

D-Light Sync Pak Features

D-Light Sync Pak Safety Guidelines

Safety Issues: This unit may blow a fuse if the maximum allotted load
of 4 amps is reached. If the fuse needs replacement, always replace
the fuse with same exact type that was remove, unless otherwise
instructed by an authorized American DJ® service technician. Use of a
different type fuse from that which is recommended may cause fire or
electric shock and will void the manufactures warranty.

• To reduce the risk of electrical shock or fire, do not expose this unit
rain or moisture

• Do not spill water or other liquids into or on to your unit

• Do not attempt to operate this unit if the power cord has been
frayed or broken

• Do not attempt to remove or break off the ground prong from the
electrical cord. This prong is used to reduce the risk of electrical

• Colored Beams

• Includes Built-In Hanging Yoke

• Sound-Active

• Easy Access Lamp Replacement

• Light Weight
Depending on area voltage

• 2 x LL-100DLS120 120V/100W Lamp

• 2 x LL-100DLS230 230V/100W Lamp

• 2 x LL-100DLS240 240V/100W Lamp

• DMX Compatiable

• Linkable to various other American DJ products with XLR connec­ tions

• 2 x XLR Cables

• 2 x Table or Floor Stands

D-Light Sync Pak Warranty Registration

The D-Light Sync Pak carries a 1 Year limited warranty. Please fill out
the enclosed warranty card to validate your purchase. All returned
service items whether under warranty or not, must be freight pre­paid and accompany a return authorization (R.A.) number. The R.A.
number must be clearly written on the outside of the return package.
A brief description of the problem as well as the R.A. number must
also be written down on a piece of paper and included in the ship

­ping container. If the unit is under warranty, you must provide a copy
of your proof of purchase invoice. You may obtain a R.A. number by
contacting customer support at [phone].

©American DJ Supply® - www.americandj.com - D-Light Sync Pak User Manual Page 3 ©American DJ Supply® - www.americandj.com - D-Light Sync Pak User Manual Page 4

shock and fire in case of an internal short

• Disconnect from main power before making any type of connection

• Do not remove the cover under any conditions. There are no user
serviceable parts inside

• Never plug this unit in to a dimmer pack

• Always be sure to mount this unit in an area that will allow proper
ventilation. Allow about 6” (15cm) between this device and a wall

• Do not attempt to operate this unit, if it becomes damaged

• This unit is intended for indoor use only, use of this product out­ doors voids all warranties

• During long periods of non-use, disconnect the unit’s main power

• Always mount this unit in safe and stable matter

• Power cords should be routed so they are not likely to be walked
on, pinched by items placed upon or against them.

• Cleaning -The fixture should be cleaned only as recommended by
the manufacturer. See page 9 for cleaning details

• Heat -The appliance should be situated away from heat sources
such as radiators, heat registers, stoves, or other appliances
(including amplifiers) that produce heat.

• The fixture should be serviced by qualified service personnel when:
A. The power-supply cord or the plug has been damaged.
B. Objects have fallen, or liquid has been spilled into the unit.
C. The unit has been exposed to rain or water.
D. The unit does not appear to operate normally or exhibits a
marked change in performance.
