D6 Branch

Introduction:

Congratulations and thank you for purchasing the American DJ D6 Branch. The D6 Branch is a great inexpensive, DMX
signal splitter. Typically a DMX signal should not be split but, the D6 Branch allows you to split a DMX signal into six
separate signal outputs. This unit will also boost your DMX signal for extensive cable runs that are usually associated
with permanent installations. This unit is perfect for contractors, installers, and professional light companies. This unit
is ready to be installed or hung and powered right out of the box. There is no assembly required. Please refer to your
units user manual for its individual DMX setup and traits.

Customer Support: American DJ® provides a toll free customer support line, to provide set up help and to answer any
question should you encounter problems during your set up or initial operation. You may also visit us on the web at www.
americandj.com for any comments or suggestions. For service related issue please contact American DJ®. Service Hours

are Monday through Friday 8:00 a.m. to 4:30 p.m. Pacic Standard Time.

Voice: [phone]
Fax: [phone]
E-mail: [e-mail]
To purchase parts online visit http://parts.americandj.com

Caution! There are no user serviceable parts inside this unit. Do not attempt any repairs yourself, doing so will void
your manufactures warranty. In the unlikely event your unit may require service please contact American DJ customer
support.

Fuse Replacement: Disconnect the unit from its power source. Remove the power cord from the unit. Once
the cord has been removed, you will find that the fuse holder is located inside the power socket. Insert a flat­head screw driver into the power socket and gently pry out the fuse holder. Remove the bad fuse and replace
with a new one. The fuse holder also has a holder for a spare fuse.

SET UP: When using the D6 Branch please refer to your units user manual for its DMX setup and individual DMX traits.

1. Connect your desired DMX intelligent units to one of the six individual DMX outputs.

2. Once you have connected your unit, connect your DMX controller to the DMX input.

3. Follow your units DMX set up instructions to address your unit.

Specifications:

Voltage......................................................................................................................................................100~240V, 50/60Hz

Fuse..............................................................................................................................................................1A

Dimensions.........................................................................................................................................6” (L) x 4.7” (W) x 4.8” (H)

Weight................................................................................................................................................................2.8lbs / 1.3Kg

The D6 Branch carries a 1 Year (365 days) limited warranty. Please fill out the enclosed warranty card to validate your
purchase. All returned service items whether under warranty or not, must be freight pre-paid and accompany a return
authorization (R.A.) number. If the unit is under warranty you must provide a copy of your proof of purchase invoice.
Please contact American DJ® customer support for a R.A. number. For additional warranty info please visit our website.
