CPX SERIES™
2-way active high powered speaker
Exclusive Road Warrior Cabinet Design
CPX 8A
2-way active speaker
FEATURES
. 2-way Speaker with High
Efficiency Class D Amplifier
. 200W Built-in Bi-amplifier
. Time Aligned Electronic Crossover
. 5 M8 Rigging points
. Stand Mountable
. Heavy Duty steel grill
. Ergonomic handles
. Power and Clip LED Indicators
. XLR and RCA inputs
. XLR and TRS throughputs
. Clipping and Thermal Protection
SPECIFICATIONS
. S/N Ratio: Line 100dB, Mic 80dB
. Frequency Response: 30 Hz – 18 kHz
. Nominal Coverage: 90º x 60º
. Low Frequency:
8” (210mm), 2” (50mm) Voice Coil
. High Frequency:
25mm Voice Coil, 1”(25mm) Throat
. Input Sensitivity: 0.5V
. Output Sensitivity: 94dB(1m/1w¬¬)
. Max. SPL: 114dB
. Balanced Input Impedance:
Line 20KΩ, Mic 3.6KΩ
. Unbalanced Input Impedance:
Line 10KΩ, Mic 1.8KΩ
. Multi Voltage Switch:
AC 115V/60Hz or 230V/50Hz
. Dimensions (LxWxH):
11.75” x 10.5” x 18”/295 x 265 x 452mm
. Weight: 31 lbs. / 14 kgs.
CROSSOVER
. Low Pass: 2nd order filter 2.7KHz
. Low Cut: 2nd order filter 30Hz
CHANNEL EQUALIZER
. Bass: 100Hz +/- 12dB
. Treble: 10KHz +/- 12dB
CPX 10A
2-way active speaker
FEATURES
. 2-way Speaker with High
Efficiency Class D Amplifier
. 250W Built-in Bi-amplifier
. Time Aligned Electronic Crossover
. 5 M8 Rigging points
. Stand Mountable
. Heavy Duty steel grill
. Ergonomic handles
. Power and Clip LED Indicators
. XLR and RCA inputs
. XLR and TRS throughputs
. Clipping and Thermal Protection
SPECIFICATIONS
. S/N Ratio: Line 100dB, Mic 80dB
. Frequency Response: 30 Hz – 18 kHz
. Nominal Coverage: 90º x 60º
. Low Frequency: 10” (255mm), 2”
(50mm) Voice Coil
. High Frequency: 25mm Voice Coil,
1”(25mm) Throat
. Input Sensitivity: 0.5V
. Output Sensitivity: 94dB(1m/1w¬¬)
. Max. SPL: 114dB
. Balanced Input Impedance: Line 20KΩ,
Mic 3.6KΩ
. Unbalanced Input Impedance: Line
10KΩ, Mic 1.8KΩ
. Multi Voltage Switch: AC 115V/60Hz or
230V/50Hz
. Dimensions (LxWxH):
13.75” x 12.75” x 20.5”/ 347 x 320 x 516mm
. Weight: 40 lbs. / 17.95 kgs.
CROSSOVER
. Low Pass: 2nd order filter 2.7KHz
. Low Cut: 2nd order filter 30Hz
CHANNEL EQUALIZER
. Bass: 100Hz +/- 12dB
. Treble: 10KHz +/- 12dB
CPX 12A
2-way active speaker
FEATURES
. 2-way Speaker with High
Efficiency Class D Amplifier.
. 500W Built-in Bi-amplifier
. Time Aligned Electronic Crossover
. 5 M8 Rigging points
. Stand Mountable
. Heavy Duty steel grill
. Ergonomic handles
. Power and Clip LED Indicators
. XLR and RCA inputs
. XLR and TRS throughputs
. Clipping and Thermal Protection
SPECIFICATIONS
. S/N Ratio: Line 100dB, Mic 80dB
. Frequency Response: 30 Hz – 18 kHz
. Nominal Coverage: 90º x 60º
. Low Frequency:
12” (312mm), 2.5” (65mm) Voice Coil
. High Frequency:
34mm Voice Coil, 1”(25mm) Throat
. Input Sensitivity: 0.5V
. Output Sensitivity: 94dB(1m/1w¬¬)
. Max. SPL: 114dB
. Balanced Input Impedance:
Line 20KΩ, Mic 3.6KΩ
. Unbalanced Input Impedance:
Line 10KΩ, Mic 1.8KΩ
. Multi Voltage Switch:
AC 115V/60Hz or 230V/50Hz
. Dimensions (LxWxH):
15” x 14.25” x 23”/ 378 x 360 x 580mm
. Weight: 48 lbs. / 21.4 kgs.
CROSSOVER
. Low Pass: 2nd order filter 2.7KHz
. Low Cut: 2nd order filter 30Hz
CHANNEL EQUALIZER
. Bass: 100Hz +/- 12dB
. Treble: 10KHz +/- 12dB
CPX 15A
2-way active speaker
FEATURES
. 2-way Speaker with High
Efficiency Class D Amplifier.
. 500W Built-in Bi-amplifier
. Time Aligned Electronic Crossover
. 5 M8 Rigging points
. Stand Mountable
. Heavy Duty steel grill
. Ergonomic handles
. Power and Clip LED Indicators
. XLR and RCA inputs
. XLR and TRS throughputs
. Clipping and Thermal Protection
SPECIFICATIONS
. S/N Ratio: Line 100dB, Mic 80dB
. Frequency Response: 30 Hz – 18 kHz
. Nominal Coverage: 90º x 60º
. Low Frequency: 15”
(390mm), 2.5” (75mm) Voice Coil
. High Frequency:
44mm Voice Coil, 1”(25mm) Throat
. Input Sensitivity: 0.5V
. Output Sensitivity: 94dB(1m/1w¬¬)
. Max. SPL: 114dB
. Balanced Input Impedance:
Line 20KΩ, Mic 3.6KΩ
. Unbalanced Input Impedance:
Line 10KΩ, Mic 1.8KΩ
. Multi Voltage Switch:
AC 115V/60Hz or 230V/50Hz
. Dimensions (LxWxH):
18” x 15.5” x 27”/ 456 x 390 x 680mm
. Weight: 62 lbs. / 28 kgs.
CROSSOVER
. Low Pass: 2nd order filter 2.7KHz
. Low Cut: 2nd order filter 30Hz
CHANNEL EQUALIZER
. Bass: 100Hz +/- 12dB
. Treble: 10KHz +/- 12dB
