Addonics
T E C H N O L O G I E S
Jupiter Cipher ExDrive
For the following models:
JCEDIU64, JCEDIF64, JCEDIS64
JCEDIU128, JCEDIF128, JCEDIS128
JCEDIU192, JCEDIF192, JCEDIS192
User’s Guide
Version 1.0
FCC Warning Statement
This equipment has been tested and found to comply with the limits for a class
B digital device pursuant to Part 15 of the FCC rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy. If not installed and used in accordance with the instructions,
it may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If the
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment on and off, the user is
encouraged to try and correct the interference by one or more of the following
suggestions.
• Reorient or relocate the receiving antenna
• Increase the distance between the equipment and the receiver
• Connect the equipment to a different power outlet other than the
one where receiver is connected
• Consult a certified television or radio technician
LIMITED WARRANTY
Addonics guarantees that every product is free from physical defects in material
and workmanship dur ing the warranty period specified for each product when
used within the limits set forth in the Specifications section in the user guide.
Unauthorized tampering of the product or using it outside the scope of the
product specifications will result in voiding th e warranty. If the product proves
defective during this warranty period, call Addonics Technical Support to
obtain a Return Authorization number. BE SURE TO HAVE YOUR PROOF
OF PURCHASE ON HAND WHEN CALLING. RETURN REQUESTS
CANNOT BE PROCESSED WITHOUT PROOF OF PURCHASE. When
returnin g a product, mark the Return Authorization number clearly on the
outside of the package and include your original p roof of purchase. Customers
are responsible for paying the shipping and handling of the products to
Addonics warran ty service location.
IN NO EVENT SHALL ADDONICS’ LIABILITY EXCEED THE PRICE
PAID FOR THE PRODUCT FROM DIRECT, INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES RESULTING FROM
THE USE OF THE PRODUCT, ITS ACCOMPANYING SOFTWARE, OR
ITS DOCUMENTATION. Addonics makes no warranty or representation,
expressed, implied, or statuary, with respect to its products or the contents or
use of the user guide and all accompanying software, and specifically disclaims
its quality, performance, merchantability, or fitness for any particular purpose.
Addonics reserves the right to revise or update its products, software, or
documentation without obligation to notify any individual or entity.
Addonics Technologies – Jupiter Cipher ExDrive User’s Guide v1.0 1
Contents
FCC Warning...................................................................................1
Limited Warranty............................................................................ 1
Contents............................................................................................ 2
Chapter 1 General Information .........................................................3
Features................................ ............................................3
Jupiter Cipher Models ......................................................4
Chapter 2 Jupiter Cipher ExDrive key...............................................5
Chapter 3 Keeping track of the hard drive.........................................6
Chapter 4 Jumper Setting for Jupiter Cipher ExDrive .......................7
Chapter 5 Hardware Installation Guide........................................8-10
Chapter 6 Attaching USIB Interface Cable ..................................... 11
Chapter 7 USB2.0 USIB Interface Cable Driver Installation ......12-13
Serial ATA USIB Interface Cable Driver Installation .... 14
Firewire USIB Interface Cable Driver Install ation ......... 15
How to use Disk Management ...................................16-17
Technical Support & Contact Information................................ …18
Addonics Technologies – Jupiter Cipher ExDrive User’s Guide v1.0 2
Chapter 1
General Information
The Addonics Technologies Jupiter Cipher ExDrive is a portable 2.5” Hard
Disk Drive kit. The unit is external an d uses the USB2.0, Firewire/iLink, and
Serial ATA interfaces.
Features
• Stylished and rugged black anodized aluminum housing
• Compact size and light weight
• Shock proof - up to 3 feet drop damage protection for the hard drive
• Easy hard drive installation
• Choice of standard or encryption drive enclosure
• The most versatile hard drive kit in the market
• Connect as an External Hard drive to any computer via USB2.0, CardBus,
Firewire/iLink and Serial ATA port (only one of these cables is included in
• Turn an y 2.5” hard drives into external hard drive or removable hard drive
• Use as a removable Hard Drive on Desktops PC with an optional IDE drive
cradle.
• Plug & Play Operation under Windows 98SE, Me, 2000, XP and 2003
Server
• Portable: Fits any Briefcase or Notebook PC Case.
Encryption
• Hardware based 64-bit DES and 128-bit or 192-bit TDES full disk
encryption
• High performance - Data is encrypted and decrypted on the fly by a
certified cryptographic engine inside an ASIC without takin g any CPU
resources
• Encryption / Decryption via a hardware key, just like using a r egular key to
open a door.
• Simple to deploy with no training required, no software to install and no
password to remember
• Platform independency - There is no software or driver to install to use
Addonics encryption products. As a result, i t can be deployed in any
systems running any OS. This is important in organization with multi
platform computing and legacy systems.
Addonics Technologies – Jupiter Cipher ExDrive User’s Guide v1.0 3
Jupiter Ciph er ExDrive
Item Number Product Description
JCEDIU64 Jupiter Cipher ExDrive 64-bit for 2.5” IDE hdd, USB 2.0
JCEDIF64 Jupiter Cipher ExDrive 64-bit for 2.5” IDE hdd,
Firewire/iLink
JCEDIS64 Jupiter Cipher ExDrive 64-bit for 2.5” IDE hdd, SATA
JCEDIU128 Jupiter Cipher ExDrive 128-bit for 2.5” IDE hdd, USB 2.0
JCEDIF128 Jupiter Cipher ExDrive 128-bit for 2.5” IDE hdd,
Firewire/iLink
JCEDIS128 Jupiter Cipher ExDrive 128-bit for 2.5” IDE hdd, SATA
JCEDIU192 Jupiter Cipher ExDrive 192-bit for 2.5” IDE hdd, USB 2.0
JCEDIF192 Jupiter Cipher ExDrive 192-bit for 2.5” IDE hdd,
Firewire/iLink
JCEDIS192 Jupiter Cipher ExDrive 192-bit for 2.5” IDE hdd, SATA
Addonics Technologies – Jupiter Cipher ExDrive User’s Guide v1.0 4
Chapter 2 Jupiter Cipher ExDrive key
128
Check to make sure you have the correct version of Jupiter Cipher ExDrive key.
The key should match the label at the bottom of the drive enclosure.
Yellow label DES-64 stands
for Jupiter Cipher ExDrive
64-bit key
Green label TDESstands for Jupiter
Cipher ExDrive 128bit key
Red label TDES-192
stands for Jupiter
Cipher ExDrive 192bit key
IMPORTANT
There is no back door for the Jupiter Cipher ExDrive encrypted hard drive if
the key is lost or stolen.
To ensure that there is a spare key, your Jupiter Cipher ExDrive bundled kit
comes with one pair of Jupiter Cipher ExDrive keys. These 2 keys have
identical encryption code. One of these keys should be kept in a safe and secure
location and can be sent back to Addonics for duplicating additional keys. If
you are down to the last key, be sure to make a back up of all the data stored
inside your encrypted hard drive prior to sending the last key to Addonics.
Addonics is not responsible for key lost in the mail or r etrieval of the data
inside the encrypted hard drive.
Ø The CIPHER key MUST be inserted at t he front of the drive enclosure
in order for the drive to be ACTIVATED.
Ø Once the drive is INITIALIZED using the Cipher Key that comes with
the kit, the drive can only be accessed by the original key.
Ø The 2 keys that come with each Jupiter Cipher ExDrive bundled kit
has their own unique encryption code. So the keys among different
kits are not interchangeable.
If you have multiple sets of Jupiter Cipher ExDri ve kits and would like all the
keys to have the same encryption code, you may make this request at the time
of your order or mail the keys together with master key back to Addonics to
recode them for you. Again be sure that you keep a spare key with you. Make a
back up of your data if you are mailing i n your last key.
Addonics Technologies – Jupiter Cipher ExDrive User’s Guide v1.0 5
Chapter 3 Keeping track of the hard drive
If you are using the Jupiter Cipher ExDrive drive enclosure to encrypt multiple
hard drives, it is important to label your hard drive if you are taking the drive
out of the enclosure. The hard drive with Jupiter Cipher ExDrive encryption
will look like a brand new drive when attach directly to the IDE or SATA
controller of a computer. There will be no partition or any hint to indicate that
the drive contains encrypted data. When the drive is partitioned, all the
encrypted data will be lost.
The same holds true if a hard drive already has data on it is installed into the
Jupiter Cipher ExDrive drive enclosure. The computer detects the hard drive as
a brand n ew drive or a drive that is unallocated. Once you proceed to partition
the drive, the data that was on the hard drive will be erased and cannot be
recovered.
A Jupiter Cipher ExDrive encrypted hard drive can be moved to another Jupiter
Cipher ExDrive drive enclosure. But the same key used in encrypting the hard
drive must be used in the new drive enclosure in order to access the drive.
If you are installing multiple Jupiter Cipher ExDrive drive kits into a large
organization, it is important to keep track of the drive and the encryption
key. Once it gets mixed up, there is no possible way to recover the data on
the encrypted hard drive.
Addonics Technologies – Jupiter Cipher ExDrive User’s Guide v1.0 6
Chapter 4
Jumper settings inside the Jupiter Cipher ExDrive Drive Case
A. If the Jupiter Cipher ExDrive will be used externa lly with the external AC
adapter, the switch from the case must be switch to the right, labeled EXT
to grab power from external power supply.
Application: Jupiter Cipher ExDrive can be set to receive power EXT and be
used with all three types of USIB cables.
B. If the Jupiter Cipher ExDrive will be used externally without the external
AC adapter, the switch from the case must be switch to the left, labeled
INT to gra b power from system.
Application: Jupiter Cipher ExDrive can be set to receive power INT and be
used with the following types of USIB cables: USB2.0 USIB & Firewire USIB
Note: We recommend setting the hard drive to MASTER mode/setting at all
times. (Default setting)
J4 Pin Definition for Master Setting
Hard Drive Brand Master Setting
Hitachi
NEC
Fujitsu
Toshiba
Seagate Pin 3 - Pin 4 Short
Pin 1~6 Open
J1 Pin Definition for USIB Interface
Hard Drive Setting J1 Jumper Setting
Master Pin 3 - Pin 5 Short
Addonics Technologies – Jupiter Cipher ExDrive User’s Guide v1.0 7
Chapter 5
Hardware Installation Guide
Exploded View of Enclosure shown with various components
top cover
hard drive
shock
absorbers
switch
screw cipher slot
PCB
bottom cover
Step 1
Separate the t op from the bottom cover
of the drive enclosure by loosening the
screw as shown on the photo.
Addonics Technologies – Jupiter Cipher ExDrive User’s Guide v1.0 8
Step 2
Align the male IDE connector on the
2.5” har d drive with the female IDE
connector on the PCB. Push the hard
drive till the connector pins on the hard
drive is fully seated inside the
connector on the PCB.
Step 3
Wrap the shock absorber around the
hard drive and PCB.
Step 4
Turn over the PCB and secure the
hard drive to the PCB with the
mounting screws that come with the
kit.
Step 5
Mount the board to the bottom cover.
Addonics Technologies – Jupiter Cipher ExDrive User’s Guide v1.0 9
Step 6
Put the top cover on by holding it in near
vertical position and sliding the two
metal clips inside the two small slots on
the rear of the bottom cover.
Step 7
Lower the front of the top cover and
making sure the two covers lined up
properly. Tighten the small retaining
screw on the front of the bottom cover
to close the enclosure.
Addonics Technologies – Jupiter Cipher ExDrive User’s Guide v1.0 10
Chapter 6 Attaching USIB interface cable
jack (for use as external
USIB connector for
use with the
Addonics USIB
interface cable
External power input
hard drive)
Addonics USIB
interface cable
Be sure the Jupiter Cipher ExDrive key is inserted into the drive enclosure prior
to turnin g on the power or attaching the USIB interface cable to the computer.
Hard drive will not be detected if the interface cable is attached to the computer
without the Cipher key inserted first. Under such condition, the power to the
drive enclosure will have to be turned off and turned back on with the Cipher
key already inserted into the drive enclosure in order for the hard drive to be
detected by the system.
The Jupiter Cipher ExDrive drive enclosure can be used as an internal
removable hard drive or as a drive cartridge by installing the optional drive
cradle in to the drive bay of a Desktop, Server or any computing equipment.
Addonics Technologies – Jupiter Cipher ExDrive User’s Guide v1.0 11
Chapter 7
7.1 USB2.0 USIB Cable (Model: AAUSBC-309)
Note: USB Jupiter Cipher ExDrive is Plug and Play under Windows XP,
2000 and 98Me. There is no thir d party driver needed.
• Since USB 2.0 Hi-Speed is an evolution of the existing USB 1.1
specification, it is fully forward and backward compatible with current
USB systems.
• If you do not h ave an USB2.0 port, you may install an optional USB2.0
adapter or controller
Driver Installation for Win98 and Win98SE
Downloading the USB2.0 USIB Cable Driver from the Addonics Driver
Disk
1. Insert the Addonics Driver Disk in the CDROM drive. The Addonics
Driver Disk window opens.
2. Select Drivers > Interface Cables Drivers > USB2.0 Cable (AAUSBC-309)
Win98/98SE Only.
3. The Winzip Self-Extractor –AT2LP.exe window opens. Unzip file in My
Documents.
Addonics Technologies – Jupiter Cipher ExDrive User’s Guide v1.0 12
Driver Installation for Win98 and Win98SE
1. Make sure your computer is up and running.
2. Insert the USB2.0 USIB cable to the USB Port.
3. A "New Hardware Found" message shall pop up, click Next.
4. “What do you want Windows to do?” message opens. Select “Search for
the best driver for your device,” click Next.
5. “Specify Location” message opens. Point to the locati on of C:\My
Documents\mass_storage_601where you unzip the files for the driver.
Click Next.
6. “Driver file search for the device %VID_ODBF&PID_0303%” then
Building a driver database message opens. Let Windows finish the
installation and click Finish.
Disk Management for Windows 98
1. Select Start > Setting > Control Panel > System. The System Properties
window opens.
2. Select the Device Manager tab, under Device type, Disk Drives, select your
new hard drive. Click the Properties button.
3. Select the Settings tab and under the Options box, click the Removable
check box. The Reserved drive letters box becomes active. Select the drive
letter for your new drive. Click Ok.
4. Click Yes to restart your system to make changes take effect.
5. Double click My Computer icon and there should be an extra drive letter
for the Jupiter Cipher ExDrive drive. You may now access the drive.
Addonics Technologies – Jupiter Cipher ExDrive User’s Guide v1.0 13
7.2 SATA USIB Cable (Model: AASAC-605)
For Win98SE, Me, 2000 and XP
Note: There ar e no drivers needed to use the Serial ATA cable as long as the
drivers are installed for the Serial ATA Controller card/chip. It is plug and
play.
Disk Management for Windows 98
Note: Refer to the SATARAID Management Utility Manual
SATARAID Manual V1.30 (for non-RAID5 Controllers) found in the
Addonics Technologies website
Addonics Technologies – Jupiter Cipher ExDrive User’s Guide v1.0 14
7.3 FIREWIRE USIB Cable (Model: AAFWC-406)
Note: Firewire Jupiter Cipher ExDrive is Plug and Play under Windows XP,
2000 and 98Me. There is no thir d party driver needed.
Driver Installation for Win98 and Win98SE
After plugging in the cable some system might prompt you for Win98SE CD,
in case you don’t have the Win98SE CD and the wizard prompts you for:
NTMAP.SYS please type C:\WINDOWS\SYSTEM32\DRIVERS
NTMAPHLP.PDR please type C:\WINDOWS\SYSTEM\IOSUBSYS
Reboot your system.
Disk Management for Window 98
1. Select Start > Setting > Control Panel > System. The System Properties
window opens.
2. Select the Device Manager tab, under Device type, Disk Drives, select QTS
FIREWIRE CABLE. Click the Properties button.
3. Select the Settings tab and under the Options box, click the Removable
check box. The Reserved drive letters box becomes active. Select the drive
letter for your new drive. Click Ok.
4. Click Yes to restart your system to make changes take effect.
5. Double click My Computer icon and there should be an extra drive letter
for the Jupiter Cipher ExDrive drive. You may now access the drive.
Addonics Technologies – Jupiter Cipher ExDrive User’s Guide v1.0 15
For Windows 2000 & XP Operating Systems
How to use Disk Management
To start Disk Management:
1. Log on as administrator or as a member of the Administrators group.
2. Click Start, click Run, type compmgmt.msc, and then click OK. In the
console tree, click Disk Management. The Disk Management window
appears. Your disks and volumes appear in a graphical view and list view.
3. To customize how you view your disks and volumes in the upper and lower
panes of the window, point to Top or Bottom on the View menu, and then
click the view that you want to use
How to create a new partition or a new logical drive
To create a new partition or logical drive on a basic disk:
1. In the Disk Management window, complete one of the following
procedures, and then continue to step 2:
• To create a new partition, right-click unallocated space on the basic
disk where you want to create the partition, and then click New
Partition.
• To create a new logical drive in an extended partition, right-click free
space on an extended partition where you want to create the logical
drive, and then click New Logical Drive.
2. In the New Partition Wizard, click Next.
3. Click the type of partition th at you want to create (either Primary
partition, Extended partition, or Logical drive), and then click Next.
4. Specify the size of the partition in the Partition size in MB box, and then
click Next.
5. Decide whether to manually assign a drive letter, let the system
automatically enumerate the drive, or do not assign a drive letter to the
new partition or logical drive, and then click Next.
6. Specify the formatting options you want to use by using one of the
following procedures:
• If you do not want to format the partition, click Do not format this
partition, and then click Next.
• If you want to format the partition, click Format this partition with
the following settings, and then complete the following procedure in
the Format dialog box:
a. Type a name for the volume in the Volume label box. This is an
optional step. Click the file system that you want to use in the File
system box.
b. You can change the disk allocation unit size, and then specify
whether to perform a quick format, or enable file and folder
compression on NTFS volumes.
Click Next.
Addonics Technologies – Jupiter Cipher ExDrive User’s Guide v1.0 16
7. Confirm that the options that selected are correct, and then click Finish.
The new partition or logical drive is created and appears in the appropriate
basic disk in th e Disk Management window. If you chose to format t he volume
in step 6, the format process now starts.
How to format a basic volume
To format a partition, logical drive or basic volume:
1. In the Disk Management window, right-click the partition or logical drive
that you want to format (or reformat), and then click Format.
2. In the Format dialog box, type a name for the volume in the Volume label
box. This is an optional step.
3. Click the file system that you want to use in the File system box. If you
want, you can also change the disk allocation unit size, specify whether you
want to perform a quick format, or enable file and folder compression on
NTFS volumes.
4. Click OK.
5. Click OK when you are prompted to format the volume. The format
process starts.
Addonics Technologies – Jupiter Cipher ExDrive User’s Guide v1.0 17
Technical Support
If you need assistance to get your unit functioning properly, please call
Addonics Technical Support. Our technical staff will be happy to assist you,
but they will need your help to do so. Calling the technical support staff
without all the proper information can be both time consuming and frustrating.
Here are some tips to help you out:
(1) MODEL NUMBER – Please have this number on hand.
(2) SYSTEM INFORMATION – Type of computer, peripherals, etc.
(3) OPERATING SYSTEM – What version of Windows
(4) WHAT’S THE TROUBLE? – Give enough information
About your problem so that we can recreate and diagnose it.
FREE Software Drivers for all Addonics Technologies
Products are available 24 hours per day at the
World Wide Web Site: www.addonics.com.
Contact Information
Addonics Technologies
2466 Kruse Drive
San Jose CA, 95131
Phone: 408-433-3899
Fax: 408-433-3898
Email: sales-team@addonics.com
Internet: http://www.addonics.com
TECHNICAL SUPPORT
Phone: 408-433-3855
Hours: 9:00-6:00 PST
Email: techinfo@addonics.com
Addonics Technologies – Jupiter Cipher ExDrive User’s Guide v1.0 18
Loading...
