INSTRUCTION MANUAL
LR-2
ADJUSTABLE HEATED PLATE LOWERATOR
2 TUBE 8”-12”
This manual contains importatant information regarding your Adcraft unit. Please read this
manual thoroughly prior to equipment set-up, operation and maintenance. Failure to comply with
regular maintenance guidelines outlined in this manual may void the warranty.
May 2015
WARNINGS
• Do not touch any hot surfaces
• Do not immerse unit, cord or plug in liquid at any time
• Unplug cord from outlet when not in use and before cleaning
• Plug only into a 3-hole grounded electrical outlet of appropriate voltage
• Do not operate unattended
• Do not use this unit for anything other than intended use
• Do not use outdoors
• Always use on a fi rm, dry and level surface at least 12” from walls or any other obstruction
• Do not use if unit has a damaged cord or plug, in the event the appliance malfunctions, or has been damaged in any
manner
• Keep children and animals away from unit
• Any incorrect installation, alterations, adjustments and/or improper maintenance can lead to property loss and
injury. All repairs should be done by authorized professionals only
• Ensure that the designated power supply is adequate for continual usage
TO INSTALL:
1. Remove unit from box and make sure all plastic, tape and packing materials are removed.
2. Place the unit on a fl at, secure surface with at least 12” of open space around all sides.
3. Check to make sure the outlet of the correct voltage for this item (120V) is near. Do not use an extension cord, this
item must be plugged directly into an outlet.
SPRING ADJUSTMENT - The adjustable tubes are set to a factory default. To adjust the tube size follow these steps:
1. Lift up the limited post and rotate it to desired position.
2. Put the post down and insert it into the locating hole below.
3. Stack a couple of plates on the holder and check to see if they fi t.
TO USE:
1. Plug the unit into an outlet of the appropriate voltage.
2. Turn the thermostat dial clockwise to heat up the unit.
3. Once the unit is warmed up, set the thermostat to the desired temperature.
During the fi rst time use of this unit, it is normal for a slight odor to be present. When moving the unit, always use the cart
NOTE:
handle. Remember to lock the castors once the unit is in place and ready for use.
CLEANING - NOTE: To maintain cleanliness and increase service life, this item should be cleaned daily. Do not immerse
the unit in water or any other liquid, if liquid enters the electrical compartment it may cause a short circuit or electrical
shock.
1. Before cleaning or attempting to move this item, turn off, unplug and let the unit cool completely.
2. Wipe the entire unit with a clean soft cloth until it is completely dry.
3. To avoid damage to the unit, do not use abrasive cleaners or scouring pads.
4. If soap or chemical cleaners are used, be sure they are completely rinsed away with clean water immediately after
cleaning. Chemical residue could damage or corrode the surfaces of the unit.
To avoid serious injury or damage, never attempt to repair or replace a damaged power cord yourself. Contact a professional repair
service.
May 2015
TROUBLESHOOTING
Problem Possible Causes Solution
Power light is on but the unit
is not getting hot when you
turn the thermostat up
Temperature keeps rising on
it’s own
Power is connected, heat
is working but the indicator
light is not on
Unit is plugged in but no
indicator light or heat is
working
It’s either a defective
thermostat or a burnt out
heating element
The thermostat is
malfunctioning
The indicator light is
defective
The electrical connection is
not connected well or the
fuse is blown
Replace the broken part
Replace the thermostat
Replace the indicator light
Check the electrical
connection to ensure it’s
connected properly. Replace
the fuse if it’s blown.
Wiring Diagram for the Plate Lowerator
May 2015
Parts Diagram for the Electric Salamanders
May 2015
ACE
Equipment
One Year Limited
Warranty
Admiral Craft Equipment Corp. (ACE) warrants its equipment against defects in materials and workmanship, subject
to the following conditions:
ACE Equipment is warranted for one year, effective from the date of purchase by the original owner. A copy of the
original receipt or other proof of purchase is required to obtain warranty coverage. This warranty applies to the original
owner only, and is not assignable.
Should any product fail to function in its intended manner under normal use within the limits defined in this
warranty, at ACE’s discretion, such product will be repaired, replaced with a refurbished unit, or replaced with a new
unit by ACE, after defective unit has been inspected and defect has been confirmed. ACE does not assume any liability
for extended delays in replacing any item beyond its control. This warranty does not apply to rubber and non-metallic
synthetic parts that may need to be replaced due to normal usage, wear or lack of preventative maintenance.
This warranty covers products shipped into the 48 contiguous United States, Hawaii, and metropolitan areas of Alaska
and Canada. Warranty coverage on products used outside the 48 contiguous United States, Hawaii and metropolitan
areas
of Alaska and Canada may vary. Contact ACE for details at 1-800-223-7750
The following conditions are not covered by warranty:
•
Equipment failure relating to improper installation, improper utility connection or supply and problems due to
improper ventilation.
•
Equipment that has not properly been maintained, damage from improper cleaning, and water damage
to controls.
•
Equipment that has not been used in an appropriate manner, or has been subject to misuse, neglect, abuse,
accident, alteration, negligence, damage during transit, delivery or installation, fire, flood, riot, or act of God.
•
Equipment that has the model number or serial number removed or altered.
•
Equipment on which the security seal has been broken.
If the equipment has been changed, altered, modified, or repaired without express written permission from ACE, then the
manufacturer shall not be liable for any damages to any person or to any property, which may result from the use of this
equipment thereafter.
This equipment is intended for commercial use only and this warranty is void if equipment is used in other than a
commercial application.
For warranty and non-warranty related issues, technical support, purchase replacement parts and warranty registration
visit
www.admiralcraft.com
. Please have your model number, serial number and proof of purchase ready. It is not
necessary to contact the place where you originally purchased your product from.
“THE FOREGOING WARRANTY IS IN LIEU OF ANY AND ALL WARRANTIES EXPRESSED OR IMPLIED
INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILTY OR FITNESS FOR PARTICULAR
PURPOSES AND CONSTITUES THE ENTIRE LIABILITY OF ACE. IN NO EVENT DOES THE LIMITED
WARRANTY EXTEND BEYOND THE TERMS STATED HEREIN.”
VER1212
May 2015
