INSTRUCTION MANUAL
FW-1500W/C
FULL SIZE COOKER/WARMER
This manual contains importatant information regarding your Adcraft unit. Please read this
manual thoroughly prior to equipment set-up, operation and maintenance. Failure to comply with
regular maintenance guidelines outlined in this manual may void the warranty.
WARNINGS
• Do not touch any hot surfaces
• Do not immerse unit, cord or plug in liquid at any time
• Unplug cord from outlet when not in use and before cleaning
• Plug only into a 3-hole grounded electrical outlet of appropriate voltage
• Do not operate unattended
• Do not use this unit for anything other than intended use
• Do not use outdoors
• Always use on a fi rm, dry and level surface at least 12” from walls or any other obstruction
• Do not use if unit has a damaged cord or plug, in the event the appliance malfunctions, or has been damaged in
any manner
• Keep children and animals away from unit
• Any incorrect installation, alterations, adjustments and/or improper maintenance can lead to property loss and
injury. All repairs should be done by authorized professionals only.
• Ensure that the designated power supply is adequate for continual usage and the voltage is correct
• NEVER operate this unit without water
IMPORTANT NOTICE – THE LIGHT IS TURNED ON AS SOON AS THE UNIT IS PLUGGED IN. TURN SWITCH TO THE
MAXIMUM HEAT SETTING FOR 30 MINUTES TO PREHEAT. AFTER 30 MINUTES TURN THE DIAL BACK TO KEEP FOOD
WARM.
TO USE
1. Make sure the power supply you are using is adequate.
2. Fill the well with 4 quarts of water. (Do not fi ll with more than 4 quarts. If the water level is too high, water may
overfl ow when the food pan is inserted. Overfl ow will enter the electrical compartment and cause a short circuit
or electrical shock).
3. Plug the cord into a three hole grounded electrical outlet of appropriate voltage.
4. Preheat the water in the well by covering the well with an empty food container or cover. Set the heat control to
the maximum heat setting. Preheat for 30 minutes.
5. Place stainless steel food pan containing food into the food warmer.
6. Reduce the setting of the knob by ¼ and monitor food temperatures closely for food safety. The United States
Public Health Service recommends that food be held at a minimum of 140˚ F (and/or in compliance with local
health codes) to prevent bacteria growth. Maintain water level at 4 quarts. Periodically, (approximately every 2
hours) remove food pan and check the water level. Add hot water if needed and adjust up or down as required
by the food type.
HOT WATER AND STEAM IN THE WELL CAN SEVERELY BURN SKIN. USE PROTECTIVE GLOVES, MITTS OR POTHOLDERS WHEN
REMOVING FOOD CONTAINERS OR COVERS. HOT FOOD CAN ALSO CAUSE BURNS. HANDLE FOOD CAREFULLY.
CLEANING - NOTE: To maintain cleanliness and increase service life, the food warmer should be cleaned daily. Do not
immerse the food warmer in water or any other liquid, if liquid enters the electrical compartment it may cause a short
circuit or electrical shock.
1. Before cleaning or attempting to move food warmer, unplug and let the unit cool completely.
2. Carefully empty the water from the well.
3. Wipe the entire unit with a clean soft cloth until it is completely dry.
4. To avoid damage to the well, do not use abrasive cleaners or scouring pads.
5. If soap or chemical cleaners are used, be sure they are completely rinsed away with clean water immediately
after cleaning. Chemical residue could damage or corrode the surfaces of the unit.
There are no serviceable parts within this appliance. To avoid serious injury or damage, never attempt to repair the food warmer
or replace a damaged cord yourself. Contact a professional repair service.
November 2014
Wiring Diagram for the Full Size Cooker/Warmer
November 2014
Parts Diagram and Replacement Parts for the Full Size Cooker/Warmer
2
3
12
11
5
9
9
67
Reference
Number
Description
:DWHU3DQ
+HDWLQJ(OHPHQW
5HIOHFWRU3DQ
3RZHU&RUGDQG6WUDLQ5HOHLI
%RWWRP&RYHU
5XEEHU)RRW
6KHOO
7HPSHUDWXUH.QRE
,QGLFDWRU/LJKW5HG
7KHUPRVWDW
6WDQG
/LPLWLQJ7KHUPRVWDW6WDQG
/LPLWLQJ7KHUPRVWDW
November 2014
ACE
Equipment
18 Month
Warranty
Admiral Craft Equipment Corp. (ACE) warrants its equipment against defects in materials and workmanship, subject
to thefollowingconditions:
ACE Equipment is warranted for 18 months, effective fro m the date of purchase by the original owner. A copy of the
original receipt or other proof of purchase is required to obtain warrantycoverage. This warrantyapplies to the original
owner only, and is not assignable.
Should any product fail to function in its intended manner under normal use within the limits defined in this
warranty, at ACE’s discretion, such product will be repaired, replaced with a refurbished unit, or replaced with a new
unit by ACE, after defective unit has been inspected and defect has been confirmed. ACE does not assume any liability
for extended delays in replacing any item beyond its control. This warranty does not apply to rubber and non-metallic
synthetic parts that may need to be replaced due to normal usage, wear or lack of preventative maintenance.
This warranty covers products shipped into the 48 contiguous United States, Hawaii, and metropolitan areas of Alaska
and Canada. Warranty coverage on products used outside the 48 contiguous United States, Hawaii and metropolitan
areas of Alaska and Canada may vary. Contact ACE for details at 1-800-223-7750
The following conditionsare not covered by warranty:
•
Equipment failure relating t o improper installation, improper utility connection or supply and problems due to
improper ventilation.
•
Equipment that has not properly been maintained, damage from improper cleaning, and water damage
to controls.
•
Equipment that has not been used in an appropriate manner, or has been subject to misuse, neglect, abuse,
accident, alteration, negligence, damage during transit, delivery or installation, fire, flood, riot, or act of God.
•
Equipmentthat has the model numberor serial numberremoved or altered.
•
Equipmenton which the security seal has been broken.
If the equipment has been changed, altered, modified, or repaired without express written permission from ACE, then the
manufacturer shall not be liable for any damages t o any person or to any property, which may result from the use of this
equipmentthereafter.
This equipment is intended for commercial use only and this warranty is void if equipment is used in other than a
commercialapplication.
For warranty and non-warranty related issues, technical support, purchase replacement parts and warranty registration
visit
www.admiralcraft.com
. Please have your model number, serial number and proof of purchase ready. It is not
necessary to contact the place where you originally purchased your product from.
“THE FOREGOING WARRANTY IS IN LIEU OF ANY AND ALL WARRANTIES EXPRESSED OR IMPLIED
INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILTY OR FITNESS FOR PARTICULAR
PURPOSES AND CONSTITUES THE ENTIRE LIABILITY OF ACE. IN NO EVENT DOES THE LIMITED
WARRANTY EXTENDBEYOND THE TERMS STATED HEREIN.”
VER1114
November 2014
