AD-30V Parts Manual
24 VAC / Phase 5
American Dryer Corporation
88 Currant Road
Fall River, MA 02720-4781
Telephone: (508) 678-9000 / Fax: (508) 678-9447
E-mail: techsupport@amdry.com
www.amdry.com
ADC Part No. 450343-4
Retain This Manual In A Safe Place For Future Reference
American Dryer Corporation products embody advanced concepts in engineering, design, and safety . If this product
is properly maintained, it will provide many years of safe, efficient, and trouble free operation.
ONL Y qualified technicians should service this equipment.
OBSERVE ALL SAFETY PRECAUTIONS displayed on the equipment or specified in the installation manual included
with the dryer.
The following “FOR YOUR SAFETY” caution must be posted near the dryer in a prominent location.
FOR YOUR SAFETY
Do not store or use gasoline or
other flammable vapors and
liquids in the vicinity of this or
any other appliance.
We have tried to make this manual as complete as possible and hope you will find it useful. ADC reserves the right to
make changes from time to time, without notice or obligation, in prices, specifications, colors, and material, and to
change or discontinue models.
Ne pas entreposer ni utiliser d’essence
ni d’autres vapeurs ou liquides
inflammables à proximité de cet appareil
ou de tout autre appareil.
POUR VOTRE SÉCURITÉ
Important
For your convenience, log the following information:
DATE OF PURCHASE ____________________________________________________ MODEL NO. ______________
RESELLER’S NAME _________________________________________________________________________________
Serial Number(s)_____________________________________________________________________________________
AD-30V
____________________________________________________________________________________________________
____________________________________________________________________________________________________
Replacement parts can be obtained from your reseller or the ADC factory . When ordering replacement part s from the
factory , you can FAX your order to ADC at (508) 678-9447 or telephone your order directly to the ADC Parts Department
at (508) 678-9000. Please specify the dryer model number and serial number in addition to the description and part
number, so that your order is processed accurately and promptly.
The illustrations on the following pages may not depict your particular dryer exactly . The illustrations are a composite
of the various dryer models. Be sure to check the descriptions of the parts thoroughly before ordering.
“IMPORT ANT NOTE T O PURCHASER”
Information must be obtained from your local gas supplier on the
instructions to be followed if the user smells gas. These
instructions must be posted in a prominent location near the dryer.
Table of Contents
Non-Coin Control Door Assembly for Models Mfd. as of July 1, 2002.......................................................................................... 4
Coin Control Door Assembly for Models Mfd. as of July 1, 2002.................................................................................................. 5
Control Door Assembly for Models Mfd. prior to July 1, 2002....................................................................................................... 6
Phase 5 Non-Coin Microprocessor Control Panel Assembly........................................................................................................ 7
Phase 5 Coin Microprocessor Control Panel Assembly................................................................................................................ 8
Coin and Non-Coin Control Box Assembly.................................................................................................................................. 10
Dual Timer “Tap Touch” Controls for Models Mfd. as of November 1, 2000 ................................................................................11
Dual Timer Control Panel Assembly for Models Mfd. prior to November 1, 2000 ...................................................................... 12
Non-Microprocessor Coin Meter Control Panel Assembly for Models Mfd. as of January 25, 2002 ......................................... 13
Non-Microprocessor Coin Meter Control Panel Assembly for Models Mfd. prior to January 25, 2002...................................... 14
Coin Vault Assembly..................................................................................................................................................................... 15
Front Panel Assembly for Models Mfd. with Steel Main Door as of July 1, 2002 ....................................................................... 16
Front Panel Assembly for Models Mfd. with Steel Main Door prior to July 1, 2002 .................................................................... 17
Front Panel Assembly for Models Mfd. with Plastic Main Door................................................................................................... 18
Main Door “Steel” Assembly ......................................................................................................................................................... 19
Plastic Main Door Assembly......................................................................................................................................................... 20
Main Door Switch Assembly for Models Mfd. with Steel Main Door ............................................................................................ 21
Main Door Switch for Models Mfd. with Plastic Main Door.......................................................................................................... 22
Tumbler / Support Assemblies ..................................................................................................................................................... 23
Sensor Bracket Assemblies for Models Mfd. as of July 1, 2002 ................................................................................................. 24
Sensor Bracket Assemblies for Models Mfd. prior to July 1, 2002.............................................................................................. 26
Drop Lint Door Assembly for Models Mfd. as of July 1, 2002 ..................................................................................................... 28
Lint Trap Assembly for Models Mfd. as of July 1, 2002 ............................................................................................................... 29
Lint Drawer / Lint Drawer Switch Assemblies for Models Mfd. between August 10, 2000 and July 1, 2002 ............................. 30
Lint Drawer / Lint Drawer Switch Assemblies for Models Mfd. prior to August 10, 2000............................................................ 31
Tumbler Bearing Assembly for Models Mfd. as of August 11, 2000............................................................................................ 32
Tumbler Bearing Assembly for Models Mfd. prior to August 11, 2000........................................................................................ 34
Idler Bearing Assembly ................................................................................................................................................................ 36
Gas Burner Assembly for Models Mfd. as of May 20, 2000 ........................................................................................................ 37
Direct Spark Ignition Burner Assembly for Models Mfd. prior to May 20, 2000 .......................................................................... 38
Sail Switch / Hi-Limit Assemblies................................................................................................................................................. 39
Non-Reversing Motor Mount Assembly ....................................................................................................................................... 40
Reversing T.E.F.C. Motor Mount Assembly.................................................................................................................................. 42
Electric Oven Assembly ............................................................................................................................................................... 44
Single-Phase (1ø) Motor, Electric Relay Panel Assembly........................................................................................................... 46
3-Phase (3ø) Motor, Electric Relay Panel Assembly ................................................................................................................... 47
460-480 VAC 3-Phase (3ø) Motor, Electric Relay Panel Assembly............................................................................................ 48
Reversing Electric Relay Panel Assembly................................................................................................................................... 49
460-480 VAC Reversing Electric Relay Panel Assembly ............................................................................................................ 50
Steam Coil / Air-Operated Steam Damper Assembly .................................................................................................................. 51
Steam Coil / Mechanical Steam Damper Assembly .................................................................................................................... 52
Outer Top / Back Guard Assemblies............................................................................................................................................ 53
Microprocessor Coin Acceptors Listing ....................................................................................................................................... 54
Coin Meter Replacement Parts .................................................................................................................................................... 55
Electrical Oven Component Application Chart ............................................................................................................................ 56
Additional Parts Available............................................................................................................................................................. 57
Non-Coin Control Door Assembly
For Models Mfd. as of July 1, 2002
Illus. No. Part No. Qty. Description
1 881053 1 ADC Logo with Tape
870011 1 Double Sided Tape Kit
2 883550 1 White Control Door Assembly
(includes illus. nos. 2 and 3)
883551 1 Ivory Control Door Assembly
(includes illus. nos. 2 and 3)
883552 1 Coral Blue Control Door Assembly
(includes illus. nos. 2 and 3)
3 117604 3 Sponge Tape (sold by the foot)
4 150317 2 #10-16 x 3/4” TORX PLUS
5 102603 1 Control Door Rod Support Catch
6 102601 1 Control Door Rod Retainer Clip
7 102502 1 Control Door Support Rod
8 150321 2 #10-32 x 1/2” Phillips Machine Screw
9 154011 2 #10-32 Multi-Thread U-Nut
4 American Dryer Corporation 450343-4
®
BTN Type 1
Coin Control Door Assembly
For Models Mfd. as of July 1, 2002
Illus. No. Part No. Qty. Description
1 160015 1 High Security Lock Assembly
160104 1 Key ONL Y
2 160016 1 Lock Cam ONLY
3 881053 1 ADC Logo with Tape
4 883477 1 White Control Door Assembly with Black Trim
(includes illus. nos. 4 through 7)
883478 1 Ivory Control Door with Black Trim
(includes illus. nos. 4 through 7)
883549 1 Coral Blue Control Door with Black Trim
(includes illus. nos. 4 through 7)
5 883476 1 Black Trim Strip with Lock Hole
6 117604 6 Sponge Tape (sold by the foot)
7 152014 4 1/4-20 Free Spin Wash Nut
8 150317 2 #10-16 x 3/4” TORX PLUS
9 102603 1 Control Door Rod Support Catch
10 102601 1 Control Door Rod Retainer Clip
11 102502 1 Control Door Support Rod
450343-4 www.amdry.com 5
®
BTN Type 1
Control Door Assembly
For Models Mfd. prior to July 1, 2002
Illus. No. Part No. Qty. Description
1 160015 1 High Security MK-100 Lock Assembly with Key (for coin models Only)
160017 1 Special Dummy Lock ONLY (for non-coin models Only)
160104 1 MK-100 Key ONL Y
2 160052 1 Lock Cam ONLY
3 881053 1 ADC Logo with Tape
870011 1 Double Sided Tape Kit
4 882511 1 White Control Door Assembly Less Lock
(includes illus. nos. 4 and 5)
882513 1 Almond B Control Door Assembly Less Lock
(includes illus. nos. 4 and 5)
882512 1 Coral Blue Control Door Assembly Less Lock
(includes illus. nos. 4 and 5)
5 117603 3 Noise Suppressor Tape (sold by the foot)
6 150300 2 #10-16 x 1/2” Hex Washer TEK Screw
7 102603 1 Control Door Rod Support Catch
8 150300 2 #10-16 x 1/2” Hex Washer TEK Screw
9 102502 1 Control Door Support Rod
10 102601 1 Control Door Rod Retainer Clip
6 American Dryer Corporation 450343-4
Phase 5 Non-Coin Microprocessor Control Panel Assembly
Illus. No. Part No. Qty. Description
1 112535 1 Non-Coin English Keypad Label Assembly
112276 1 Non-Coin Stick-On Labels (English Only) … Not Illustrated
112275 1 3-Language Non-Coin Stick-On Labels
(Spanish, Italian, and Hebrew) … Not Illustrated
112277 1 3-Language Non-Coin Stick-On Labels
(English, Spanish, and Hebrew) … Not Illustrated
112278 1 5-Language Non-Coin Stick-On Labels
(Italian, Dutch, French, German, and Chinese) … Not Illustrated
2 801255 1 Phase 5 Microprocessor Control Panel ONLY
801256 1 Phase 5 Microprocessor Control Panel ONLY with Battery Bracket
801206 1 Phase 5 Non-Coin Non-Reversing Microprocessor Control Panel Assembly Complete
(includes illus. nos. 1 through 5 and 7)
801207 1 Phase 5 Non-Coin Reversing Microprocessor Control Panel Assembly Complete
(includes illus. nos. 1 through 5 and 7)
3 137222 1 Phase 5 Non-Coin Non-Reversing Microprocessor Controller (computer) ONLY
137231 1 Phase 5 Non-Coin Reversing Microprocessor Controller (computer) ONLY
824998 1 Phase 5 Battery Clip
4 153010 2 #6 Star Washer
5 150005 2 #6-32 x 1/4” Phillips Round Head Machine Screw
6 150309 1 #10-16 x 1/2” Hex Head TEK Crimptite Screw
7 136048 1 1/8-Amp (Slo-Blo) Fuse ONLY
IMPORTANT: Check label on computer chip to verify correct part number for controller (computer).
450343-4 www.amdry.com 7
Phase 5 Coin Microprocessor Control Panel Assembly
8 American Dryer Corporation 450343-4
Phase 5 Coin Microprocessor Control Panel Assembly
Illus. No. Part No. Qty. Description
1 112526 1 Coin Keypad Label Assembly
2 883537 1 Phase 5 Coin Control Panel Assembly
(for models mfd. as of June 25, 2002)
(includes illus. nos. 1, 2, and 4 through 6)
883538 1 Phase 5 Coin Control Panel Assembly with Battery Option
(for models mfd. as of June 25, 2002)
(includes illus. nos. 1, 2, and 4 through 6)
883582 1 Phase 5 Coin Control Panel Assembly with Battery Option
(for models mfd. prior to June 25, 2002)
(includes illus. nos. 1, 2, and 4 through 6)
883581 1 Phase 5 Coin Control Panel Assembly
(for models mfd. prior to June 25, 2002)
(includes illus. nos. 1, 2, and 4 through 6)
883539 1 Coin Control Panel ONLY
(for models mfd. as of June 25, 2002)
883540 1 Coin Control Panel ONLY with Battery Bracket
(for models mfd. as of June 25, 2002)
883580 1 Coin Control Panel ONLY
(for models mfd. prior to June 25, 2002)
883579 1 Coin Control Panel ONLY with Battery Bracket
(for models mfd. prior to June 25, 2002)
3 150309 1 #10-16 x 1/2” Hex Head TEK Crimptite Screw
4 137213 1 Phase 5 Coin Controller ONLY
824998 1 Phase 5 Battery Clip
5 153010 2 #6 Star Washer
6 150005 2 #6-32 x 1/4” Phillips Round Head Machine Screw
7 –––––– 1 Microprocessor Coin Acceptor
(refer to Microprocessor Coin Acceptors Listing on page 54)
8 –––––– 1 Optic Switch ONLY
(refer to Microprocessor Coin Acceptors Listing on page 54)
9 137023 1 Optic Switch Connector ONLY
10 137021 3 Microprocessor Socket ONLY
880772 1 Single Coin Optical Switch Harness
122800 1 Microprocessor (female) Pin Extraction Tool
11 136048 1 1/8-Amp (Slo-Blo) Fuse
IMPORTANT: Check label on computer chip to verify correct part number of controller (computer).
450343-4 www.amdry.com 9
Coin and Non-Coin Control Box Assembly
Illus. No. Part No. Qty. Description
1 132002 1 Transformer (for mechanical steam dampers 208 VAC and higher)
2 150300 2 #10-16 x 1/2” Hex Washer TEK Screw
3 150301 2 #8 x 7/16” Phillips Pan Head TEK Screw
4 131931 1 Steam Valve Relay (for mechanical steam damper models Only) 24 VAC
5 137035 1 Motor Capacitor (for mechanical steam damper models Only)
6 323583 1 Capacitor Bracket (for mechanical steam damper models Only)
7 150300 2 #10-16 x 1/2” Hex Washer TEK Screw
8 122641 1 15-Pin Microprocessor Connector
9 122706 * Socket Terminal ONLY
— 122801 1 Pin / Socket Extraction Tool
* As required.
10 American Dryer Corporation 450343-4
Dual Timer “Tap Touch” Controls
For Models Mfd. as of November 1, 2000
Illus. No. Part No. Qty. Description
1 824298 1 15 Minute Timer – 24 VAC
2 824299 1 60 Minute Timer – 24 VAC
3 824175 1 Red Pilot Light – 24 VAC
4 122301 1 “Tap Touch” Switch
5 131932 3 Relay SPST 24v
6 120730 1 30-Position Terminal Block
7 151000 6 #6-32 Pal Nut
8 882903 1 Dual Timer Panel Complete
(includes illus. nos. 1 through 15)
850392 – Dual Timer Panel ONLY
9 153010 2 #6 Star Washer
10 152000 3 #6-32 Hex Nut
11 150207 2 #10-24 x 1/2” Phillips Pan Head Machine Screw
12 150110 4 #8-32 x 1/4” Phillips Round Head Machine Screw
13 112563 1 Dual Timer Panel Overlay
14 124104 1 Pure Touch Knob with Red Pointer
15 124105 1 Pure Touch Knob with Blue Pointer
450343-4 www.amdry.com 11
Dual Timer Control Panel Assembly
For Models Mfd. prior to November 1, 2000
Illus. No. Part No. Qty. Description
1 123005 1 Red Indicator Light – 24 VAC
2 122400 1 Rocker Heat Selector Switch
3 882596 1 Dual Timer Control Panel Assembly Complete – 24 VAC
(includes illus. nos. 1 through 16)
882600 1 Dual Timer Reversing Control Panel Assembly Complete – 24 VAC
(includes illus. nos. 1 through 17)
850456 1 Dual Timer Control Panel ONLY
4 131917 1 Push-To-Start Relay – 24 VAC
5 150207 2 #10-24 x 1/2” Phillips Pan Head Machine Screw
6 154001 2 #10-24 Speed Nut
7 152000 2 #6-32 Hex Nut
8 153010 2 #6 Star Washer
9 120730 1 30-Position Terminal Block
10 150110 4 #8-32 x 1/4” Phillips Round Head Machine Screw
11 131932 1 Dual Timer Relay – 24 VAC
12 151000 4 #6-32 Pal Nut
13 112050 1 Dual Timer Label ONLY
14 124103 2 Arrow Timer Knob
15 124025 1 60 Minute Timer – 24 VAC
16 124030 1 15 Minute Timer – 24 VAC
17 132198 1 Reversing Timer – 24 VAC
— 882540 1 Panel Wiring (non-reversing panel) … Not Illustrated
— 882573 1 Panel Wiring (reversing panel) … Not Illustrated
12 American Dryer Corporation 450343-4
Non-Microprocessor Coin Meter Control Panel Assembly
For Models Mfd. as of January 25, 2002
Illus. No. Part No. Qty. Description
1 123005 1 Red Indicator Light – 24 VAC
2 122400 1 Rocker Heat Selector Switch
3 824172 1 Coin Meter Control Panel Assembly Less Coin Meter
(includes illus. nos. 2 through 5, 7, and 8)
824109 1 Coin Meter Control Panel ONLY
4 131932 1 24 VAC Relay
154001 2 #10-24 Speed Nut (used on P/N: 131932, 24 VAC relay)
5 123225 1 Green Push-To-Start Button
6 125601 1 25¢ Coin Meter – 24 VAC (specify timing)
7 153010 2 #6 Star Washer
8 152016 2 #4-40 Hex Nut
9 120712 1 12-Position Terminal Block
10 150300 1 #10-16 x 1/2” Hex Washer TEK Screw
11 122602 1 9-Pin Connector
12 122700 7 Pin Terminal ONLY
— 122801 1 Pin Extraction Tool
NOTE: For Coin Meter Replacement Parts refer to page 55.
450343-4 www.amdry.com 13
Non-Microprocessor Coin Meter Control Panel Assembly
For Models Mfd. prior to January 25, 2002
Illus. No. Part No. Qty. Description
1 123005 1 Red Indicator Light – 24 VAC
2 122400 1 Rocker Heat Selector Switch
3 824020 1 Coin Meter Control Panel Assembly Complete – 24 VAC
(includes illus. nos. 1 through 6 and 8 through 12)
800054 1 Coin Meter Control Panel ONLY
4 131917 1 Push-To-Start Relay – 24 VAC
5 150207 2 #10-24 x 1/2” Round Head Machine Screw
6 154001 2 #10-24 Speed Nut
7* 125601 1 25¢ Coin Meter – 24 VAC (specify timing)
8 150303 2 #4 x 3/4” Pan Head “A” Screw
9 120712 1 12-Position Terminal Block
10 150309 1 #10-16 x 1/2” Hex Head TEK Crimptite Screw
11 122602 1 9-Pin Connector ONLY
12 122700 9 Pin Terminal ONLY
— 122801 1 Pin / Socket Extraction Tool
* Consult factory for coin meters not listed.
NOTE: For Coin Meter Replacement Parts refer to page 55.
14 American Dryer Corporation 450343-4
Coin Vault Assembly
Illus. No. Part No. Qty. Description
1 802112 1 Microprocessor Coin Vault Assembly Complete
(includes illus. nos. 1 through 5)
802117 1 Microprocessor Coin Vault ONLY
802110 1 Non-Microprocessor Coin Vault Assembly Complete
(includes illus. nos. 1 through 5)
802115 1 Non-Microprocessor Coin Vault ONLY
2 160028 1 Cam for 1/4 Turn Lock ONLY
3 875061 1 1/4 Turn Lock with Key and Cam
160105* 1 1/4 Turn Mer-Pel Key ONLY
4 802020 1 1/4 Turn Coin Box Assembly
(includes illus. nos. 2 through 4)
5 152014 4 1/4-20 Free Spin Wash Nut
6 102502 1 Control Door Support Rod
7 102601 1 Control Door Rod Retainer Clip
8 102603 1 Control Door Rod Catch
* Specify key number when ordering.
450343-4 www.amdry.com 15
Front Panel Assembly
For Models Mfd. with Steel Main Door as of July 1, 2002
Illus. No. Part No. Qty. Description
1 883567 1 White Front Panel Assembly
(includes illus. nos. 1, 5, and 6)
883568 1 Ivory Front Panel Assembly
(includes illus. nos. 1, 5, and 6)
883569 1 Coral Blue Front Panel Assembly
(includes illus. nos. 1, 5, and 6)
2 150313 11 #10-16 x 1/2” TORX PLUS
150318 1 25 IP TORX PLUS
3 –––––– 1 Main Door Hinge
(refer to Main Door “Steel” Assembly on page 19)
4 122002 1 Lint Drawer Switch
5 170330 1 Friction Door Latch
6 154215 2 5/32” Pop Rivet
16 American Dryer Corporation 450343-4
®
®
BTN Type 1
Bit 1/4 Hex (for removal of TORX® head screw)
Front Panel Assembly
For Models Mfd. with Steel Main Door prior to July 1, 2002
Illus. No. Part No. Qty. Description
1 883137 1 White Front Panel Assembly
(includes illus. nos. 1, 5, and 6)
883138 1 Coral Blue Front Panel Assembly
(includes illus. nos. 1, 5, and 6)
883139 1 Ivory Front Panel Assembly
(includes illus. nos. 1, 5, and 6)
2 150313 11 #10-16 x 1/2” TORX PLUS
150318 1 25 IP TORX PLUS
3 –––––– 1 Main Door Hinge
(refer to Main Door “Steel” Assembly on page 19)
4 –––––– 1 Lint Drawer Switch
(refer to Lint Drawer / Lint Drawer Switch Assemblies on page 30 and page 31)
5 170330 1 Friction Door Latch
6 154215 2 5/32” Pop Rivet
450343-4 www.amdry.com 17
®
®
BTN Type 1
Bit 1/4 Hex (for removal of TORX® head screw)
Front Panel Assembly
For Models Mfd. with Plastic Main Door
Illus. No. Part No. Qty. Description
1 882525 1 White Front Panel Assembly
(includes illus. nos. 1, 3, 5, and 6)
882527 1 Almond B Front Panel Assembly
(includes illus. nos. 1, 3, 5, and 6)
882528 1 Coral Blue Front Panel Assembly
(includes illus. nos. 1, 3, 5, and 6)
2 150309 11 #10-16 x 1/2” Hex Head TEK Crimptite Screw
3 121405 1 Rubber Grommet
4 –––––– 1 Lint Drawer Switch
(refer to Lint Drawer / Lint Drawer Switch Assemblies on page 30 and page 31)
5 170330 1 Friction Door Latch
6 154215 2 5/32” Pop Rivet
18 American Dryer Corporation 450343-4
Main Door “Steel” Assembly
Illus. No. Part No. Qty. Description
1 881150 1 Black Main Door Assembly Complete
(includes illus. nos. 1, 2, and 8 through 15)
2 102354 1 Door Gasket
170731 1 Black Gasket Adhesive (10.7 oz. cartridge)
3 881152 1 Black Top Hinge Block Assembly
(includes illus. nos. 3 and 4)
4 150445 2 1/4-20 x 3/4” Black Cap Head Setscrew
5 153031 1 1/4” Nylon Washer
6 881151 1 Black Bottom Hinge Block Assembly
(includes illus. nos. 5 through 7)
7 150445 2 1/4-20 x 3/4” Black Cap Head Setscrew
8 150683 3 1/4-20 x 5/8” Black Carriage Bolt
9 152014 3 1/4-20 Free Spin Wash Nut
10 151010 1 #10-32 Black Hex Acorn Nut
11 150120 1 Door Latch Screw
12 150683 3 1/4-20 x 5/8” Black Carriage Bolt
13 152014 3 1/4-20 Free Spin Wash Nut
14 881210 1 Black Main Door Handle ONLY
15 102211 1 20-7/16” Door Glass
170731 1 Black Glass Adhesive (10.3 oz. cartridge)
450343-4 www.amdry.com 19
Plastic Main Door Assembly
Illus. No. Part No. Qty. Description
1 881422 1 Black Plastic Main Door Assembly Complete with Mechanical Fasteners
(includes illus. nos. 1 and 5 through 9)
2 800448 1 12-1/2” Stainless Steel Main Door Hinge Assembly
3 150410 4 #10-24 x 3/8” Phillips Pan Head Taptite Screw
4 152014 4 1/4-20 Free Spin Wash Nut
5 102349 1 Main Door Gasket
6 102212 1 20-7/16” Door Glass with 4 Holes
170730 1 Main Door Gasket / Glass Adhesive (10.3 oz. cartridge)
7 150448 4 1/2” Stainless Steel Flat Head Allen Screw
8 170319 4 Door Glass (nylon) Spacer
9 150431 1 Main Door Latch Screw (#10 x 7/16” dome hex head screw)
20 American Dryer Corporation 450343-4
Main Door Switch Assembly
For Models Mfd. with Steel Main Door
Illus. No. Part No. Qty. Description
1 150006 2 #6-32 x 7/8” Phillips Pan Head Machine Screw
2 152013 2 #6-32 Hex Nut
3 153010 2 #6 Star Washer
4 137005 1 Door Switch
5 122636 2 Flag Terminal
6 881211 1 Black Main Door Switch Housing ONLY
881153 1 Black Main Door Switch Housing Complete
(includes illus. nos. 1 through 4 and 6)
7 150301 2 #8-18 x 7/16” Phillips Pan Head TEK Screw
450343-4 www.amdry.com 21
Main Door Switch
For Models Mfd. with Plastic Main Door
Illus. No. Part No. Qty. Description
1 152013 2 #6-32 Hex Nut
2 153008 2 #6 Lock Washer
3 137005 1 Single-Pole Door Switch
4 121028 2 Insulated Female Terminal
5 154281 2 3/8” Standard Nylon Spacers
6 800448 1 12-1/2” Stainless Steel Main Door Hinge Assembly
(includes illus. nos. 6 and 7)
7 153565 2 #6-32 x 1” Self-Clinching Stud
8 881246 1 Main Door Switch Housing
9 150201 2 #10-32 x 1/4” Phillips Pan Head Screw
10 121405 1 Rubber Grommet
22 American Dryer Corporation 450343-4
Tumbler / Support Assemblies
Illus. No. Part No. Qty. Description
1* 882519 1 Galvanized Tumbler ONLY (without felt collar)
882520 1 Stainless Steel Tumbler ONLY (without felt collar)
882521 1 Polished Stainless Steel Tumbler ONLY (without felt collar)
882522 1 Galvanized Tumbler / Support Assemblies
(includes illus. nos. 1 through 10)
882524 Stainless Steel Tumbler / Support Assemblies
(includes illus. nos. 1 through 10)
882523 Polished Stainless Steel Tumbler / Support Assemblies ONLY (without felt collar)
2 150309 40 #10-16 x 1/2” Hex Head TEK Crimptite Screw
3 301304 4 Galvanized Tumbler Rib ONLY
322002 2 Galvanized Taper Tumbler Rib
322003 2 Galvanized Straight Tumbler Rib
322001 2 Stainless Steel Straight Tumbler Rib
322000 2 Stainless Steel Tapered Tumbler Rib
322066 2 Polished Stainless Steel Tumbler Rib
322067 2 Polished Stainless Steel Tapered Tumbler Rib
4 150518 1 5/16-18 x 3/8” Socket Button Head Screw
5 100918 4 3/8-16 x 26-3/4” Tie Rod
6 153004 4 5/16” Flat Washer
7 882517 1 Tumbler Support ONLY
8 152005 4 3/8-16 Hex Nut
9 153005 4 3/8” Lock Washer
10 153004 4 3/8” Flat Washer
11 116002 1 Felt Collar ONLY
— 401010 1 #847 Adhesive for Felt Collar (5.0 oz. tube)
* Felt collar is not included and must be ordered separately.
450343-4 www.amdry.com 23
Sensor Bracket Assemblies
For Models Mfd. as of July 1, 2002
24 American Dryer Corporation 450343-4
Sensor Bracket Assemblies
For Models Mfd. as of July 1, 2002
Illus. No. Part No. Qty. Description
1 882533 1 1/4” Temperature Sensor Probe Assembly
(includes illus. nos. 1 and 5 through 8)
2 130301 1 225° Manual Reset Thermostat
3 153010 2 #6 Star Washer
4 152000 2 #6-32 Hex Nut
5 121028 2 Insulated Terminal ONLY
6 122701 4 Socket Terminal ONLY
7 122605 1 4-Pin Socket Connector ONLY
8 154007 2 1/4” Tinnerman Push-On Fastener
9 150005 2 #6-32 x 1/4” Phillips Round Head Machine Screw
10 801425 1 Microprocessor Sensor Bracket Assembly Complete
(includes illus. nos. 1 through 10)
305007 1 Universal Sensor Bracket ONLY
11 122604 1 4-Pin Connector ONLY
12 122700 4 Pin Terminal ONLY
13 150301 2 #8-18 x 7/16” Phillips Pan Head TEK Screw
14 150005 5 #6-32 x 1/4” Phillips Round Head Machine Screw
15 130111 1 130° Thermostat
16 130100 1 150° Thermostat
17 130301 1 225° Manual Reset Thermostat
18 130101 1 180° Thermostat
19 153010 5 #6 Star Washer
20 152000 5 #6-32 Hex Nut
21 882535 1 Sensor Jumper
22 121028 4 Insulated Terminal ONLY
23 122701 4 Socket Terminal ONLY
24 122605 1 4-Pin Socket Connector ONLY
818007 1 Sensor Bracket Harness Assembly
(includes illus. nos. 22 through 24)
25 818321 1 Noncomputer Sensor Bracket Assembly Complete – Includes Thermostats
(includes illus. nos. 14 through 25)
305007 1 Universal Sensor Bracket ONLY
26 122604 1 4-Pin Connector ONLY
27 122700 4 Pin Terminal ONLY
122801 1 Pin / Socket Extraction Tool
28 150301 2 #8-18 x 7/16” Phillips Pan Head TEK Screw
450343-4 www.amdry.com 25
Sensor Bracket Assemblies
For Models Mfd. prior to July 1, 2002
26 American Dryer Corporation 450343-4
Illus. No. Part No. Qty. Description
1 882533 1 1/4” Temperature Sensor Probe Assembly
(includes illus. nos. 1 and 5 through 8)
2 130301 1 225° Manual Reset Thermostat
3 153010 2 #6 Star Washer
4 152000 2 #6-32 Hex Nut
5 121028 2 Insulated Terminal ONLY
6 122701 4 Socket Terminal ONLY
7 122605 1 4-Pin Socket Connector ONLY
8 154007 2 1/4” Tinnerman Push-On Fastener
9 150005 2 #6-32 x 1/4” Phillips Round Head Machine Screw
10 801425 1 Microprocessor Sensor Bracket Assembly Complete
(includes illus. nos. 1 through 10)
322062 1 Universal Sensor Bracket ONLY
11 122604 1 4-Pin Connector ONLY
12 122700 4 Pin Terminal ONLY
13 150301 2 #8-18 x 7/16” Phillips Pan Head TEK Screw
14 150005 5 #6-32 x 1/4” Phillips Round Head Machine Screw
15 130111 1 130° Thermostat
16 130100 1 150° Thermostat
17 130301 1 225° Manual Reset Thermostat
18 130101 1 180° Thermostat
19 153010 5 #6 Star Washer
20 152000 5 #6-32 Hex Nut
21 882535 1 Sensor Jumper
22 121028 4 Insulated Terminal ONLY
23 122701 4 Socket Terminal ONLY
24 122605 1 4-Pin Socket Connector ONLY
882534 1 Sensor Bracket Harness Assembly
(includes illus. nos. 22 through 24)
25 322062 1 Universal Sensor Bracket ONLY
882536 1 Noncomputer Sensor Bracket Assembly Complete – Includes Thermostats
(includes illus. nos. 14 through 25)
26 122604 1 4-Pin Connector ONLY
27 122700 4 Pin Terminal ONLY
122801 1 Pin / Socket Extraction Tool
28 150301 2 #8-18 x 7/16” Phillips Pan Head TEK Screw
Sensor Bracket Assemblies
For Models Mfd. prior to July 1, 2002
450343-4 www.amdry.com 27
Drop Lint Door Assembly
For Models Mfd. as of July 1, 2002
Illus. No. Part No. Qty. Description
1 802277 1 Drop Lint Door (for non-coin models)
(includes illus. nos. 1 through 3)
802265 1 Drop Lint Door (for coin models)
(includes illus. nos. 1, 2, and 4)
2 117604 5 Sponge Tape (sold by the foot)
3 170226 1 Slide Latch (for non-coin models)
4 160001 1 Lint Door AD-100 Lock (for coin models)
160103 1 Key ONL Y
28 American Dryer Corporation 450343-4
Lint Trap Assembly
For Models Mfd. as of July 1, 2002
Illus. No. Part No. Qty. Description
1 801070 1 Lint Trap Assembly Complete for 60 Hz Models ONLY
(includes illus. nos. 1 and 3 through 5)
800401 1 Lint Trap Assembly Complete for 50 Hz Models ONLY
(includes illus. nos. 1 and 3 through 5)
801069 1 Lint Trap ONLY (60 Hz)
800443 1 Lint Trap ONLY (50 Hz)
2 154200 6 5/32” Pop Rivet
3 150300 3 #10-16 x 1/2” Hex Washer TEK Screw
4 304100 1 Lint Screen Holder ONLY
5 800500 2 Lint Screen Assembly
450343-4 www.amdry.com 29
Lint Drawer / Lint Drawer Switch Assemblies
For Models Mfd. between August 10, 2000 and July 1, 2002
Illus. No. Part No. Qty. Description
1 883155 1 White Lint Drawer Assembly
(includes illus. nos. 1 and 2)
883156 1 Coral Blue Lint Drawer Assembly
(includes illus. nos. 1 and 2)
883157 1 Ivory Lint Drawer Assembly
(includes illus. nos. 1 and 2)
2 117605 5 Gasket (sold by the foot)
3 122116 1 Lint Drawer Switch
4 122605 2 4-Pin Socket Connector ONLY
5 122701 4 Socket Terminal ONLY
122801 1 Pin / Socket Extraction Tool
6 818087 1 Lint Drawer Switch Box Assembly
(includes illus. nos. 3 through 6)
304136 1 Lint Drawer Switch Box ONLY
7 150301 2 #8-18 x 7/16” Phillips Pan Head TEK Screw
8 122700 4 Pin Terminal ONLY
9 122604 2 4-Pin Connector ONLY
30 American Dryer Corporation 450343-4
Lint Drawer / Lint Drawer Switch Assemblies
For Models Mfd. prior to August 10, 2000
Illus. No. Part No. Qty. Description
1 882514 1 White Lint Drawer Assembly
(includes illus. nos. 1 and 2)
882515 1 Coral Blue Lint Drawer Assembly
(includes illus. nos. 1 and 2)
882516 1 Almond B Lint Drawer Assembly
(includes illus. nos. 1 and 2)
2 117605 5 Neoprene Sponge Tape (sold by the foot)
3 108224 1 Lint Screen Assembly
4 122116 1 Lint Drawer Switch
5 122605 2 4-Pin Socket Connector
6 122701 4 Socket Terminal ONLY
122801 1 Pin / Socket Extraction Tool
7 800478 1 Lint Drawer Switch Box Assembly
(includes illus. nos. 4 through 7)
304136 1 Lint Drawer Switch Box ONLY
8 150301 2 #8-18 x 7/16” Phillips Pan Head TEK Screw
9 122700 4 Pin Terminal ONLY
10 122604 2 4-Pin Connector ONLY
450343-4 www.amdry.com 31
32 American Dryer Corporation 450343-4
Tumbler Bearing Assembly
For Models Mfd. as of August 11, 2000
Tumbler Bearing Assembly
For Models Mfd. as of August 11, 2000
Illus. No. Part No. Qty. Description
1 880220 1 1-3/4” Flange Bearing
2 153025 4 9/16” Lock Washer
3 152050 4 9/16-12 Hex Nut
4 882544 1 Pillow Block Bearing Assembly Complete
(includes illus. nos. 4 through 16, 23, and 24)
882545 1 Pillow Block Bearing Assembly Complete with Rotational Sensor
(includes illus. nos. 4 through 18, 23, and 24)
882542 1 Pillow Block Bearing Platform ONLY
882543 1 Pillow Block Bearing Platform for Models with Rotational Sensor
5 880202 1 1-3/8” Pillow Block Bearing
880779 1 1-3/8” Pillow Block Bearing for Reversing Models ONLY
6 150601 2 3/8-16 x 2” Hex Bolt
7 153004 2 3/8” Flat Washer
8 153004 2 3/8” Flat Washer
9 153005 2 3/8” Lock Washer
10 152005 2 3/8-16 Hex Nut
11 154326 2 5/16-24 x 3/8” Setscrew
12 152004 2 5/16-18 Hex Nut
13 150621 2 5/16-18 x 1-1/2” Tap Bolt
14 153002 4 5/16” Lock Washer
15 153004 6 3/8” Flat Washer
16 150501 4 5/16-18 x 3/4” Tap Bolt
17 102120 1 Sintered 8 Magnet for Reversing Models ONLY
18 824807 1 Rotational Sensor Assembly
19 100724 1 Shaft Key
20 101100 1 18” Pulley for Non-Reversing Models ONLY
101118 1 18-3/4” Pulley for Reversing Models ONLY
21 101110 1 1” Taper Lock Bushing for Reversing Models ONLY
22 100100 1 5L-660 V-Belt (tumbler to idler) for Non-Reversing Models ONLY
100108 1 5L-680 V-Belt (tumbler to idler) for Reversing Models ONLY
23 150610 2 5/16-18 x 1-1/2 Allen Setscrew
24 152004 2 5/16-18 Hex Nut
450343-4 www.amdry.com 33
Tumbler Bearing Assembly
For Models Mfd. prior to August 11, 2000
34 American Dryer Corporation 450343-4
Tumbler Bearing Assembly
For Models Mfd. prior to August 11, 2000
Illus. No. Part No. Qty. Description
1 880220 1 1-3/4” Flange Bearing with Nylock Setscrew
2 153025 4 9/16” Lock Washer
3 152050 4 9/16-16” Hex Nut
4 150508 2 3/8-16 x 3/4” Hex Head Machine Bolt
5 153005 2 3/8” Lock Washer
6 152005 2 3/8-16” Hex Nut
7 150600 2 3/8-16 x 1-1/2” Hex Head Machine Bolt
8 153004 * 3/8” Flat Washer
9 153005 2 3/8” Lock Washer
10 152005 2 3/8-16 Hex Nut
11 150501 4 5/16-18 x 3/4” Hex Head Machine Bolt
12 153002 4 5/16” Lock Washer
13 153001 4 5/16” Flat Washer
14 150621 2 5/16-18 x 1-1/2” Hex Head Machine Bolt
15 152004 2 5/16-18 Hex Nut
16 801101 1 1-3/8” Bearing Box Assembly Complete for Models Mfd. without Rotational Sensor
(includes illus. nos. 4 through 20)
801103 1 1-3/8” Bearing Box and Support ONLY
(includes illus. nos. 4, 5, 6, 16, and 17)
801105 1 1-3/8” Bearing Box ONLY
17 801104 1 Pillow Block Bearing Support ONLY
18 880779 1 1-3/8” Pillow Block Bearing Assembly with Magnet for Models Mfd. with Rotational Sensor
880202 1 1-3/8” Pillow Block Bearing with Nylock Setscrew
19 152004 2 5/16-18 Hex Nut
20 150610 2 5/16-18 x 1-1/2” Allen Setscrew
21 101100 1 18” Pulley for Non-Reversing Models ONLY
101118 1 18-3/4” Pulley for Reversing Models ONLY
101110 1 1” Taper Lock Hub (key not included) for Reversing Models ONLY
100735 1 Shaft Key (for taper lock hub)
22 154301 2 5/16-18 x 1” Allen Setscrew
23 100713 1 1/4” x 1/4” x 7/8” Key
24 100100 1 5L-660 V-Belt (tumbler to idler) for Non-Reversing Models ONLY
100108 1 5L-680 V-Belt (tumbler to idler) for Reversing Models ONLY
25 824807 1 Rotational Sensor Assembly
* As required.
450343-4 www.amdry.com 35
Idler Bearing Assembly
Illus. No. Part No. Qty. Description
1 100100 1 5L-660 V-Belt (tumbler to idler) for Non-Reversing Models ONLY
100108 1 5L-680 V-Belt (tumbler to idler) for Reversing Models ONLY
2 101129 1 9” x 2-1/2” Compound Pulley
3 100105 1 4L-520 V-Belt (idler to motor) for Non-Reversing Models ONLY
100112 1 4L-610 V-Belt (idler to motor) for Reversing Models ONLY
4 154301 2 5/16-18 x 1” Allen Setscrew
5 100705 1 3/16” x 3/16” x 1-3/8” Key
6 882576 1 Idler Bearing Assembly Complete
(includes illus. nos. 5 through 12)
7 150617 2 3/8-16 x 1” Hex Head Machine Bolt
8 153005 2 3/8” Lock Washer
9 153004 2 3/8” Flat Washer
10 801009 1 Idler Square Washer
11 152004 1 5/16-18 Hex Nut
12 150509 1 5/16-18 x 3” Hex Head Machine Bolts
36 American Dryer Corporation 450343-4
Gas Burner Assembly
For Models Mfd. as of May 20, 2000
Illus. No. Part No. Qty. Description
1 141104 2 Small Tube Burner
2 151001 2 #8-32 Pal Nut
3 150108 2 #8-32 x 1/2” Phillips Pan Head Machine Screw
4 140820* 2 #29 Burner Orifice (natural gas)
140806* 2 #46 Burner Orifice (liquid propane gas)
5 141230 1 1/2” Direct Spark Ignition Manifold (2-port)
6 318714 1 1-Piece Gas Valve Bracket
7 150309 5 #10-16 x 1/2” Hex Head TEK Crimptite Screw
8 128927 1 Gas Valve
140411 1 Liquid Propane Conversion Kit for Gas Valve
9 809307 1 Ignitor-Probe Assembly
10 801048 1 ADC Direct Spark Ignition Johnson Module (3 tries)
11 810030 1 Johnson Direct Spark Ignition Module Mounting Bracket
12 150300 9 #10-16 x 1/2” Hex Washer TEK Screw
13 152013 2 #6-32 Hex Nut
14 142707 1 1/2” x 1-1/2” Long Black Nipple
15 142500 1 1/2” 90° Elbow
16 142800 1 1/2” x 18” Pipe
17 142600 1 1/2” Black Union
18 142818 1 1/2” x 9-1/2” B.I. Nipple
19 817060** 1 Direct Spark Ignition Burner Box (natural gas)
(includes illus. nos. 1 through 3 and 5 through 18)
817061** 1 Direct Spark Ignition Burner Box (liquid propane gas)
(includes illus. nos. 1 through 3 and 5 through 18)
850858 1 Direct Spark Ignition Burner Box ONLY
882269 1 AD-30V Liquid Propane Conversion Kit (includes orifices)
880603*** 1 Steam to Gas Interface Assembly
* Consult factory for elevations over 2,000 feet.
** Burner orifices are not included and must be ordered separately.
***Needed when converting steam heat to gas heat.
450343-4 www.amdry.com 37
Direct Spark Ignition Burner Assembly
For Models Mfd. prior to May 20, 2000
Illus. No. Part No. Qty. Description
1 141105 2 Large Tube Burner
2 151001 2 #8-32 Pal Nut
3 150108 2 #8-32 x 1/2” Phillips Pan Head Machine Screw
4* 140820 2 #29 Burner Orifice (natural gas)
140806 2 #46 Burner Orifice (liquid propane gas)
5 141230 1 1/2” Direct Spark Ignition Manifold (2-port)
6 318700 2 Pipe Bracket (bent)
7 150300 2 #10-16 x 1/2” Hex Washer TEK Screw
8 128927 1 Gas Valve
140411 Liquid Propane Valve Conversion Kit
880960 Direct Spark Ignition Gas Valve (liquid propane kit combination)
9 880134 1 Ignitor Probe Assembly
882537 1 Flame-Probe Wire ONLY
10 128935 1 Direct Spark Ignition Module (3 tries)
11 817027 1 Direct Spark Ignition / Hot Surface Ignition Module Mounting Bracket Assembly
12 150309 3 #10-16 x 1/2” Hex Head TEK Crimptite Screw
13 152013 2 #6-32 Hex Nut
14 141313 1 90° x 1/2” x 1” Gas Shutoff Assembly
15 142809 1 1/2” x 29-1/8” Pipe
16 318712 1 Gas Valve Pipe Bracket
17 150309 4 #10-16 x 1/2” Hex Head TEK Crimptite Screw
18 850858 1 Direct Spark Ignition Burner Box ONLY
— 882269* 1 AD-30V Liquid Propane Conversion Kit
— 882603** 1 Steam to Gas Transition Plate
* Consult factory for elevations over 2,000 feet.
** Not illustrated … needed to convert dryer from steam to gas.
38 American Dryer Corporation 450343-4
Sail Switch / Hi-Limit Assemblies
Illus. No. Part No. Qty. Description
1 154004 1 Twin Speed Nut
2 150300 2 #10-16 x 1/2” Hex Washer TEK Screw
3 802799 1 Sail Switch Box Cover and Bracket
4 150303 2 #4 x 3/4” Pan Head “A” Machine Screw
5 122200 1 Sail Switch ONLY
6 105500 1 Sail Switch Actuator Rod
7 319202 1 Sail Switch Damper (flat)
8 154002 1 1/8” Push-On Fastener
9 802800 1 Sail Switch Box with Cover and Bracket
802801 1 Sail Switch Assembly Complete
(includes illus. nos. 1 through 9)
10 142809 1 1/2” x 29-1/8” Pipe
11 150300 2 #10-16 x 1/2” Hex Washer TEK Screw
12 319704 1 Hi-Limit Mounting Bracket
13 151000 2 #6-32 Pal Nut
14 150001 2 #6-32 x 1/2” Phillips Round Head Machine Screw
15 130201 1 330° Hi-Limit Manual Reset Thermostat
450343-4 www.amdry.com 39
40 American Dryer Corporation 450343-4
Non-Reversing Motor Mount Assembly
Non-Reversing Motor Mount Assembly
Illus. No. Part No. Qty. Description
1 100105 1 4L-520 V-Belt (to idler motor)
2 100701 1 3/16” x 3/16” x 1” Key (for use on 3ø – 60 Hz models Only)
3 101104 1 1/2” x 2” Motor Pulley (for use on 1ø – 60 Hz models Only)
101132 1 5/8” x 2” Motor Pulley (for use on 3ø – 60 Hz models Only)
101131 1 1/2” x 2-1/4” Motor Pulley (for use on 181049 motors Only)
101133 1 5/8” x 2-1/4” Motor Pulley (for use on 100066 motors Only)
4 150501 4 5/16-18 x 3/4” Hex Head Machine Bolt
5 153002 4 5/16” Lock Washer
6 153001 4 5/16” Flat Washer
7 100065 1 1/2 hp 120-230v 1ø 60 Hz 100v 50 Hz Totally Enclosed, Fan-Cooled Motor with Plug
181049 1 1/2 hp 240v 1ø 50 Hz Motor with Plug
(for models mfd. as of August 22, 2002)
100066 1 1/2 hp 240v 1ø 50 Hz Totally Enclosed, Fan-Cooled Motor with Plug
(for models mfd. prior to August 22, 2002)
8 122701 8 Socket Terminal ONLY
122801 1 Pin / Socket Extraction Tool
9 137030 1 8-Pin Housing Connector
10 152004 4 5/16-18 Hex Nut
11 153002 4 5/16” Lock Washer
12 153001 4 5/16” Flat Washer
13 117600 4 Noise Suppressor Tape (sold by the foot)
14 154000 4 5/16-18 Tinnerman Nut
15 850017 1 Non-Reversing Motor Mount ONLY (56Z frame)
803938* 1 1/2 hp 120-230v 1ø 50/60 Hz
Totally Enclosed, Fan-Cooled Motor Mount Assembly Complete with Plug Motor
(includes illus. nos. 2 through 7 and 13 through 20)
817076 1 1/2 hp 240v 1ø 50 Hz Non-Reversing
Totally Enclosed, Fan-Cooled Motor Mount Assembly Complete with Plug Motor
(includes illus. nos. 2 through 7 and 13 through 20)
803809* 1 1/2 hp 208/230/380/460v 3ø 60 Hz
Totally Enclosed, Fan-Cooled Motor Mount Assembly Complete
(includes illus. nos. 2 through 6 and 13 through 22)
803810* 1 1/2 hp 208/230/380/460v 3ø 50 Hz Non-Reversing
Totally Enclosed, Fan-Cooled Motor Mount Assembly Complete
(includes illus. nos. 2 through 6 and 13 through 22)
16 153050 2 1/2” S.A.E. Flat Washer
17 100604 1 12-1/2” Impellor with 1/2” Bore
18 100702 1 1/8” x 1/8” x 1-1/2” Key
19 153050 2 1/2” S.A.E. Flat Washer
20 152006 2 1/2-20 Left Hand Jam Nut
21 120200 1 3/8” 90° Connector
22 100007 1 1/2 hp 208-460 50/60 Hz Motor
* Specify volt age when ordering.
450343-4 www.amdry.com 41
Reversing T.E.F.C. Motor Mount Assembly
42 American Dryer Corporation 450343-4
Reversing T.E.F.C. Motor Mount Assembly
Illus. No. Part No. Qty. Description
1 100112 1 4L-610 V-Belt (to idler motor)
2 100701 1 3/16” x 3/16” x 1” Key
3 101132 1 5/8” x 2” Motor Pulley (for 60 Hz models Only)
101133 1 5/8” x 2-1/4” Motor Pulley (for 50 Hz models Only)
4 120200 1 3/8” x 90° Connector
5* 181003 1 1/2 hp 208/230/380/460v 3ø 50/60 Hz Motor (56Z frame)
6 150501 4 5/16-18 x 3/4” Hex Head Machine Bolt
7 153002 4 5/16” Lock Washer
8 153001 4 5/16” Flat Washer
9* 100007 1 1/2 hp 208/230/380/460v 3ø 50/60 Hz Totally Enclosed, Fan-Cooled Motor (56Z frame)
10 120200 1 3/8” x 90° Connector
11 150501 4 5/16-18 x 3/4” Hex Head Machine Bolt
12 153002 4 5/16” Lock Washer
13 153001 4 5/16” Flat Washer
14 154000 8 5/16-18 Tinnerman Nut
15 152004 4 5/16-18 Hex Nut
16 153002 4 5/16” Lock Washer
17 153001 4 5/16” Flat Washer
18 850070 1 Reversing Motor Mount ONLY (56Z frame)
(includes illus. nos. 18 and 19)
803802* 1 Reversing Totally Enclosed, Fan-Cooled Motor Mount Assembly Complete
For 60 Hz Models ONLY
(includes illus. nos. 2 through 14 and 18 through 24)
803803* 1 Reversing Totally Enclosed, Fan-Cooled Motor Mount Assembly Complete
For 50 Hz Models ONLY
(includes illus. nos. 2 through 14 and 18 through 24)
19 117604 4 Neoprene Sponge Tape (sold by the foot)
20 153050 2 1/2” S.A.E. Flat Washer
21 100702 1 1/8” x 1/8” x 1-1/2” Key
22 100604 1 12-1/2” Impellor with 1/2” Bore
23 153050 2 1/2” S.A.E. Flat Washer
24 152006 2 1/2-20 Left Hand Jam Nut
* Specify volt age when ordering.
450343-4 www.amdry.com 43
Electric Oven Assembly
44 American Dryer Corporation 450343-4
Illus. No. Part No. Qty. Description
1* 803007 1 Large Electric Oven Box ONLY
–––––– 1 Electric Oven Assembly Complete
2* –––––– – Electric Element
3 150300 2 #10-16 x 1/2” Hex Washer TEK Screw
4 802800 1 Sail Switch Box with Bracket and Cover ONLY
802801 1 Sail Switch Box Assembly Complete
(includes illus. nos. 4 through 12)
5 154004 1 Twin Speed Nut
6 150300 2 #10-16 x 1/2” Hex Washer TEK Screw
7 802799 1 Sail Switch Box Cover and Bracket ONLY
8 122200 1 Sail Switch ONLY
9 150303 2 #4 x 3/4” Pan Head “A” Machine Screw
10 105500 1 Sail Switch Actuator Rod
11 319202 1 Sail Switch Damper (flat)
12 154002 1 1/8” Push-On Fastener
13 150300 2 #10-16 x 1/2” Hex Washer TEK Screw
14 803100 1 Electric Oven Front Cover ONLY
15 320611 1 Large Relay Box Cover ONLY
16 150301 3 #8-18 x 7/16” Phillips Pan Head TEK Screw
17 130400 1 290° Hi-Limit Thermostat
18 150300 2 #10-16 x 1/2” Hex Washer TEK Screw
19 154001 1 #10-24 Speed Nut
20 121010 1 L-70 Ground Lug
21 152014 3 1/4-20 Free Spin Wash Nut
22 ––––––* 1 Oven Relay
23 ––––––* 1 Oven Relay Replacement Coil
24 120081 – Internal Ceramic Insulator (2 per element)
25 120080 – External Ceramic Insulator (2 per element)
26 152008 – #10-32 Hex Nut (4 per element)
27 121011 – Bus Bar (sold by the foot)
28 ––––––* – Oven Wire with Crimp Lug
29 153009 – #10 Star Washer (2 per element)
30 321301 1 Large Electric Oven Right Side Cover ONLY
31 150402 1 #10-24 x 5/8” Truss Head Machine Screw
— 882603** 1 Steam to Electric Transition Plate
Electric Oven Assembly
* Refer to Electrical Oven Component Application Chart on p age 56.
** Not illustrated … needed to convert dryer from steam to electric.
450343-4 www.amdry.com 45
Single-Phase (1ø) Motor, Electric Relay Panel Assembly
Illus. No. Part No. Qty. Description
1 151000 2 #6-32 Pal Nut
2 150300 2 #10-16 x 1/2” Hex Washer TEK Screw
3 150008 2 #6-32 x 1-1/4” Phillips Pan Head Machine Screw
4 120716 1 2-Position Terminal Block
5 322817 1 Mounting Plate ONLY
882662 1 Rear Electric Panel Assembly Complete – 120 Volt
(includes illus. nos. 1 through 14)
882663 1 Rear Electric Panel Assembly Complete – 208-240 Volt
for Gas and Steam Heated Models ONLY
(includes illus. nos. 1 through 14)
818395 1 Rear Electric Panel Assembly Complete – 208-240 Volt for Electric Heated Models ONLY
(includes illus. nos. 1 through 14)
6 882652 1 Transformer Assembly – 120 Volt
882653 1 Transformer Assembly – 208-240 Volt for Gas and Steam Heated Models ONLY
818396 1 Transformer Assembly – 208-240 Volt for Electric Heated Models ONLY
7 136008 1 or 2 Fuse Holder ONLY
8 136049 1 3/4-Amp (Slo-Blo) Fuse ONLY – 120 Volt
136057 2 1/2-Amp (Slo-Blo) Fuse ONLY – 208-240 Volt
9 150301 1 #8-18 x 7/16” Phillips Pan Head TEK Screw
10 150297 1 #10 x 1/2” Hex Washer TEK Screw (green)
11 152004 1 5/16-18 Hex Nut
12 121010 1 L-70 Ground Lug
13 153002 1 5/16” Lock Washer
14 132459 1 3-Pole Contactor
15 121300 3 Open / Closed Bushing
46 American Dryer Corporation 450343-4
3-Phase (3ø) Motor, Electric Relay Panel Assembly
Illus. No. Part No. Qty. Description
1 151000 2 #6-32 Pal Nut
2 150300 2 #10-16 x 1/2” Hex Washer TEK Screw
3 150008 2 #6-32 x 1-1/4” Phillips Pan Head Machine Screw
4 120701 1 4-Position Terminal Block (for models mfd. with 3ø motors)
120716 1 2-Position Terminal Block (for models mfd. with 1ø motors)
5 322817 1 Mounting Plate ONLY
882664 1 Rear Electric Panel Assembly Complete – 208-240 Volt for Gas and Steam Models ONLY
(includes illus. nos. 1 through 14)
818400 1 Rear Electric Panel Assembly – 208-240 Volt for Electric Heated Models ONLY
(includes illus. nos. 1 through 14)
882665 1 Rear Electric Panel Assembly Complete – 380-416 Volt for Gas and Steam Models ONLY
(includes illus. nos. 1 through 14)
818395 1 Rear Electric Panel Assembly Complete – 208-240 Volt for Electric Heated Models ONLY
For Models Mfd. with Single-Phase (1ø) Motor ONLY
(includes illus. nos. 1 through 14)
882667 1 Rear Electric Panel Assembly Complete – 380-416 Volt for Electric Heated Models ONLY
For Models Mfd. with Single-Phase (1ø) Motor ONLY
(includes illus. nos. 1 through 14)
6 882653 1 Transformer Assembly – 208-240 Volt for Gas and Steam Models ONLY
818396 1 Transformer Assembly – 208-240 Volt for Electric Heated Models ONLY
882654 1 Transformer Assembly – 380-416 Volt
7 136008 2 Fuse Holder ONLY
8 136057 2 1/2-Amp (Slo-Blo) Fuse ONLY
9 150301 2 #8-18 x 7/16” Phillips Pan Head TEK Screw
10 150297 1 #10 x 1/2” Hex Washer TEK Screw (green)
11 152004 1 5/16-18 Hex Nut
12 121010 1 L-70 Ground Lug
13 153002 1 5/16” Lock Washer
14 132459 1 3-Pole Contactor
15 121300 3 Open / Closed Bushing
450343-4 www.amdry.com 47
460-480 VAC 3-Phase (3ø) Motor, Electric Relay Panel Assembly
Illus. No. Part No. Qty. Description
1 150009 2 #6-32 x 1-1/2” Phillips Pan Head Machine Screw
2 120701 1 4-Position Terminal Block
3 830208 1 Transformer Assembly (460 VAC) for Micro Models ONLY
824161 1 Transformer Assembly (460 VAC) for Non-Micro Models ONLY
4 135501 1 1-Amp Double-Pole Circuit Breaker (460 VAC Only)
5 120768 2 35 x 15mm Din Rail
6 150301 4 #8-18 x 7/16” Phillips Pan Head TEK Screw
7 150297 2 #10 x 1/2” Hex Washer TEK Screw (green)
8 152004 1 5/16-18 Hex Nut
9 121010 1 L-70 Ground Lug
10 153002 1 5/16” Lock Washer
11 132459 1 24 VAC 3-Pole Contactor
12 322817 1 Mounting Plate ONLY
883332 1 Rear Panel Assembly Complete (460 VAC) for Micro Models ONLY
(includes illus. nos. 1 through 14)
830262 1 Rear Panel Assembly Complete (460 VAC) for Non-Micro Models ONLY
(includes illus. nos. 1 through 14)
13 151000 2 #6-32 Pal Nut
14 120765 4 End Stop
15 121300 1 Open / Closed Bushing
16 141403 1 Control Voltage Transformer (24V) for Micro Models ONLY
48 American Dryer Corporation 450343-4
Reversing Electric Relay Panel Assembly
Illus. No. Part No. Qty. Description
1 150300 2 #10-16 x 1/2” Hex Washer TEK Screw
2 150008 2 #6-32 x 1-1/4” Phillips Pan Head Machine Screw
3 120701 1 4-Position Terminal Block
4 132458 1 3-Pole Reversing Contactor
5 882653 1 Transformer Assembly – 208-240 Volt for Gas and Steam Models ONLY
825428 1 Transformer Assembly – 208-240 Volt for Electric Heated Models ONLY
882654 1 Transformer Assembly – 380-416 Volt
6 136008 1 Fuse Holder ONLY
7 136057 1 1/2-Amp (Slo-Blo) Fuse ONLY – 208-240 Volt
8 150301 1 #8-18 x 7/16” Phillips Pan Head TEK Screw
9 150297 1 #10 x 1/2” Hex Washer TEK Screw (green)
10 152004 1 5/16-18 Hex Nut
11 121010 1 L-70 Ground Lug
12 153002 1 5/16” Lock Washer
13 132459 1 3-Pole Contactor
14 322812 1 Mounting Plate ONLY
882673 1 Rear Electric Panel Assembly Complete – 208-240 Volt for Gas and Steam Models ONLY
(includes illus. nos. 1 through 16)
883335 1 Rear Electric Panel Assembly Complete – 208-240 Volt for Electric Heated Models ONLY
(includes illus. nos. 1 through 16)
882676 1 Rear Electric Panel Assembly Complete – 380-416 Volt
(includes illus. nos. 1 through 16)
15 151000 2 #6-32 Pal Nut
16 120765 1 Standard End Bracket
450343-4 www.amdry.com 49
460-480 VAC Reversing Electric Relay Panel Assembly
Illus. No. Part No. Qty. Description
1 132458 1 24 VAC Reversing Contactor
2 150297 1 #10 x 1/2” Hex Washer TEK Screw (green)
3 121010 1 L-70 Ground Lug
4 152004 1 5/16-18 Hex Nut
5 153002 1 5/16” Lock Washer
6 132459 1 24 VAC 3-Pole Blower Contactor
7 150300 4 #10-16 x 1/2” Hex Washer TEK Screw
8 830208 1 Transformer Assembly (460 VAC) for Micro Models ONLY
824161 1 Transformer Assembly (460 VAC) for Non-Micro Models ONLY
9 120765 2 End Stop
10 322817 1 Mounting Plate ONLY
883327 1 460 VAC Reversing Rear Electric Panel Assembly Complete for Micro Models ONLY
(includes illus. nos. 1 through 16)
––––––* 1 460 VAC Reversing Rear Electric Panel Assembly Complete for Non-Micro Models ONLY
(includes illus. nos. 1 through 16)
11 151000 2 #6-32 Pal Nut
12 150009 2 #6-32 x 1-1/2” Phillips Pan Head Machine Screw
13 120701 1 4-Position Terminal Block
14 135501 1 1-Amp Double-Pole Circuit Breaker
15 120768 2 35 x 15mm Din Rail (sold by the inch)
16 112068 1 3-Phase (3ø) Power Input Label
17 121300 1 Open / Closed Bushing
18 141403 1 Control Voltage Transformer (24V) for Micro Models ONLY
* Not available at time of printing. Contact factory for additional information.
50 American Dryer Corporation 450343-4
Steam Coil / Air-Operated Steam Damper Assembly
Illus. No. Part No. Qty. Description
1 165008 1 Steam Coil Assembly
2 153002 6 5/16” Lock Washer
3 152004 6 5/16-18 Hex Nut
4 152002 4 1/4-20 Hex Nut
5 153007 4 1/4” Lock Washer
6 820321 2 Steam Damper Hinge Assembly
7 803416 1 Steam Damper Assembly
(includes illus. nos. 7, 10, and 11)
8 153007 4 1/4” Lock Washer
9 152002 4 1/4-20 Hex Nut
10 115995 60 Steam Damper Gasket (sold by the inch)
11 102350 1 Steam Damper Foam (68-1/2” length)
12 151006 1 5/16-24 Stainless Steel Acorn Nut
13 152051 1 5/16-24 Right Hand Jam Nut
14 100495 1 11/16” Dia. x 3” Stroke Piston
15 323365 2 Left and Right Piston Support
16 152002 2 1/4-20 Hex Nut
17 153007 2 1/4” Lock Washer
18 100472 1 1/4” x 1/8” Connector
19 143110 1 1/4” Tubing (sold by the foot)
20 100472 1 1/4” x 1/8” Connector
21 100496 1 1/8” Needle Valve
22 143238 1 1/8” Close Nipple
23 100498 1 3-Way Micro Valve – 24 VAC
24 150002 2 #6-32 x 1” Slotted Machine Screw
25 153010 2 #6 Star Washer
26 152000 2 #6-32 Hex Nut
27 330987 1 Micro Valve Support Bracket
28 152002 2 1/4-20 Hex Nut
29 153007 2 1/4” Lock Washer
30 100520 1 1/8” N.P.T. Silencer (muffler)
450343-4 www.amdry.com 51
Steam Coil / Mechanical Steam Damper Assembly
Illus. No. Part No. Qty. Description
1 165008 1 Steam Coil Assembly
2 153002 6 5/16” Lock Washer
3 152004 6 5/16-18 Hex Nut
4 152002 4 1/4-20 Hex Nut
5 153007 4 1/4” Lock Washer
6 820321 2 Steam Damper Hinge Assembly
7 880780 1 Steam Damper Assembly
(includes illus. nos. 7 through 10)
8 115995 60 Steam Damper Gasket (sold by the inch)
9 102350 1 68-1/2” Long Steam Damper Foam
10 309300 1 Rod Bracket
11 154300 1 1/2” x 3/32” Cotter Pin
12 153022 1 #10 Steel Burr
13 104052 1 Mechanical Steam Damper Actuator Rod
14 150110 2 #8-32 x 1/4” Phillips Head Machine Screw
15 153012 2 #8 Star Washer
16 312315 1 Mechanical Steam Damper Motor Mount
17 153022 1 #10 Steel Burr
18 154300 1 1/2” x 3/32” Cotter Pin
19 850268 1 Mechanical Steam Damper Arm
20 150110 2 #8-32 x 1/4” Phillips Head Machine Screw
21 153012 2 #8 Star Washer
22 312315 1 Mechanical Steam Damper Motor Mount
23 104054 1 Mechanical Steam Damper Motor
24 100511 1 Mechanical Steam Damper Switch Plate
25 122120 1 Mechanical Steam Damper Switch
26 150026 2 #4-40 x 5/8” Phillips Pan Head Machine Screw
27 122120 1 Mechanical Steam Damper Switch
28 150026 2 #4-40 x 5/8” Phillips Pan Head Machine Screw
29 153012 2 #8 Star Washer
30 150102 2 #8-32 x 3/8” Pan Head Machine Screw
31 ––––––* 1 Mechanical Steam Damper Motor Cam
* The mechanical steam damper motor cam is part of the mechanical steam damper motor.
52 American Dryer Corporation 450343-4
Outer Top / Back Guard Assemblies
Illus. No. Part No. Qty. Description
1 322809 1 Back Electrical Box Cover
2 150301 4 #8-18 x 7/16” Phillips Pan Head TEK Screw
3* 314424 1 Gas Top Back Guard
314422 1 Electric Top Back Guard
4 150301 7 #8-18 x 7/16” Phillips Pan Head TEK Screw
5 150300 10 #10-16 x 1/2” Hex Washer TEK Screw
6* 322015 1 Outer Top
7 322082 1 Bottom Back Guard (for models mfd. as of March 19, 2001)
322018 1 Bottom Back Guard (for models mfd. prior to March 19, 2001)
8 150301 13 #8-18 x 7/16” Phillips Pan Head TEK Screw
9 103500 4 Leveling Leg
10 882099 1 8” to 10” Transition Piece
(for models mfd. prior to March 19, 2001)
* There is no outer top or top back guard on steam models.
450343-4 www.amdry.com 53
Microprocessor Coin Acceptors Listing
NOTE: Coin acceptors listed include optical switch.
Replacement optic switch for Hanke acceptors is Part No. 881143.
Replacement optic switch for Greenwald acceptors is Part No. 137056.
Single Coin*
Part No. Nation Description
883363 United States 25¢ Hanke Optic Coin Acceptor with 4 Studs
(for models mfd. as of June 25, 2002)
882689 United States 25¢ Hanke Optic Coin Acceptor
(for models mfd. between June 15, 2000 and June 25, 2002)
125100 US and Canada 25¢ Greenwald Optic Coin Acceptor
(for models mfd. prior to June 15, 2000)
125107 Australia 20¢ Greenwald Australian Optic Coin Acceptor
881768 Australia $1 Hanke Australian Optic Coin Acceptor
881604 Japan 100 Yen Hanke Optic Coin Acceptor
125103 ——— 0.882 Token Greenwald Optic Coin Acceptor
125121 ——— 0.800 Token Greenwald Optic Coin Acceptor
125133 Hong Kong $1 Greenwald Hong Kong Optic Coin Acceptor
Dual Coin*
Part No. Nation Description
881842 Canada 25¢ / $1 Hanke Dual Optic Coin Acceptor
881542 United Kingdom 1£ / 20 Pence Hanke Dual Optic Coin Acceptor
881846 France 2 / 5 Franc Hanke Dual Optic Coin Acceptor
881541 Netherlands 25¢ / 1 Guilder Hanke Dual Optic Coin Acceptor
* Consult factory for coin acceptors not listed.
54 American Dryer Corporation 450343-4
Coin Meter Replacement Parts
Illus. No. Part No. Qty. Description
1 125541 1 1/60 RPM 24 VAC / 60 Hz Meter Motor
125540 1 1/30 RPM 24 VAC / 50 Hz Meter Motor
2 125500 1 2-Point Cam
125501 1 3-Point Cam
125502 1 4-Point Cam
125503 1 5-Point Cam
125504 1 6-Point Cam
125506 1 8-Point Cam
125507 1 9-Point Cam
125508 1 10-Point Cam
125510 1 12-Point Cam
3 125515 1 Meter Switch “B” with Arm
4 125516 2 Meter Switch “A” or “C”
450343-4 www.amdry.com 55
56 American Dryer Corporation 450343-4
Electrical Oven Component Application Chart
Oven
kW Voltage Phase Wire
30 208 3Ø 3 or 4 883603 6 5 120012 1 #2 882562 1 121010 1 DPA93 131358
30 240 3Ø 3 824972 6 5 120013 1 #4 882566 1 121010 1 DPA73 131376
30 416 3Ø 3 or 4 826391 6 5 120013 1 #8 882571 2 121010 1 DPA43 131357
30 460/480 3Ø 3 or 4 824 953 6 5 120013 1 #8 882572 1 121010 2 DPA43 131357
25 380 3Ø 3 or 4 826391 6 5 120013 1 #8 882571 1 121010 1 DPA43 131357
24 208 3Ø 3 or 4 883604 6 4 120010 1 #4 882566 1 121010 1 DPA73 131376
24 240 3Ø 3 883606 6 4 120011 1 #6 882568 1 121010 1 DPA63 131369
24 460/480 3Ø 3 or 4 883 602 6 4 120011 1 #8 882572 1 121010 2 DPA33 131352
20 208 1Ø 2 883607 5 4 120010 1 #2 883384 1 121010 2 DPA93 131358
20 240 1Ø 2 883608 5 4 120011 1 #4 883385 1 121010 2 DPA93 131358
20 380 3Ø 3 or 4 883601 6 4 120010 1 #8 882571 1 121010 2 DPA33 131352
15 240 3Ø 3 883605 3 5 120013 1 #8 882571 1 121010 2 DPA43 131357
Assemblyy
Part No.
Element
Qty. kW Par t No . Qty. Size Part No . Qty. Part No. Ca t. No. Part No.
Oven Wire
with C r imp Term inal
Terminal Lug
Bus Bar
Part No.
121011
Ove n Relay
Part No. Description
114006 “WARNING – Fire Hazards” Label
112280 “Clean Lint Screen” Label
114001 “CAUTION – Exhaust / Lint Screen” Label
112533 “Phase 5 Coin Program Location Summary” Label
112534 “Phase 5 OPL Program Location Summary” Label
120100 3/8” Straight (BX) Connector
120300 3/8” x 45° (BX) Connector
120400 3/8” Red Jacket (BX) Insulator
120500 3/8” Jiffy Clip (BX retainer clip)
120600 3/8” Greenfield (BX)
120707 2-Position Terminal Strip
120708 3-Position Terminal Strip
Additional Parts Available
120800 1/4” In-Line Connector
120802 Red Butt Connector
120902 #74B Wire Nut
120903 Crimp-On Wire Nut
121014 1/4” Insulated (female) Terminal
121026 Tab Receptacle Combination
121499 5-1/2” Harness Tie
121500 8” Harness Tie
122804 Manometer (hydro gauge) for Measuring Gas Pressure
404502 White Brush-In-Cap Bottle Touch-Up Paint
404516 Ivory Brush-In-Cap Bottle Touch-Up Paint
404515 Coral Blue Brush-In-Cap Bottle Touch-Up Paint
450343-4 www.amdry.com 57
ADC Part No. 450343 4 - 08/13/08 - 0
Loading...
