ADATA WLM01 Integration Instruction

Integration Instruction

General:

This modular approval is limited to OEM/Integrators installation only.

OEM integrators are responsible for ensuring that the end-user has no manual instructions to remove or install

module.

FCC Regulations:

To integrate this module into the host, the host manufacturer is responsible for the applicable FCC rules, including

the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules

In the user manual of the host device, the following statements are required to be included.

 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)

This device may not cause harmful interference, and (2) this device must accept any interference received,

including interference that may cause undesired operation.

 This device has been tested and found to comply with the limits for a Class B digital device, pursuant to Part

15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference

in a residential installation. This equipment generates, uses and can radiated radio frequency energy and, if

not installed and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a particular installation If

this equipment does cause harmful interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of

the following measures:

-Reorient or relocate the receiving antenna.

-Increase the separation between the equipment and receiver.

-Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

-Consult the dealer or an experienced radio/TV technician for help.

Changes or modifications not expressly approved by the party responsible for compliance could void the

user‘s authority to operate the equipment.

IMPORTANT NOTE:

FCC Radiation Exposure Statement:

This module has been certified by FCC as single module approval with the following restrictions:

1. For RF exposure compliance to FCC requirement, the module should be installed in the host to keep the

minimum of 2 mm separation to the user.

2. The chip antenna with antenna gain 0.43 dBi is permanently attached to the module, and for compliance the

antenna shall not be modified. A separate approval is required for all other operating configurations, including

different antenna configurations.

3. If any other simultaneous transmission radio is installed in the host platform together with this module, or the

separation distance of the module to the user cannot be kept equal or larger than 2 mm, a separate RF exposure

assessment and FCC equipment authorization is required.

When the module is installed in the host device, the FCC ID label must be visible through a window on the final

device or it must be visible when an access panel, door or cover is easily re-moved. If not, a second label must be

placed on the outside of the final device that contains the following text: “Contains FCC ID:

RLY-WLM01”.

IC Regulations:

To integrate this module into the host, the host manufacturer is responsible for the applicable Industry Canada

rules, including the limits for a Class B digital device, pursuant to ICES-003 of the Industry Canada Rules

In the user manual of the host device, the following statements are required to be included.

 This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the

following two conditions:

(1) this device may not cause interference, and

(2) this device must accept any interference, including interference that may cause undesired operation of

the device.

This Class B digital apparatus complies with Canadian ICES-003.

Pour intégrer ce module dans l'hôte, le fabricant hôte est responsable des règles applicables d'Industrie Canada, y

compris les limites d'un appareil numérique de classe B, conformément à la norme NMB-003 du règlement

d'Industrie Canada

Dans le manuel d'utilisation de l'appareil hôte, les énoncés suivants doivent être inclus.

 Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de

licence. L'exploitation est autorisée aux deux conditions suivantes:

(1) l'appareil ne doit pas produire de brouillage, et

(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est

susceptible d'en compromettre le fonctionnement."

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

IMPORTANT NOTE:

IC Radiation Exposure Statement:

This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled environment.

1. This device has been certified by IC RSS-102 as modular approval with the following restrictions:

2. For RF exposure compliance to IC requirement, the module should be installed in the host to keep the

minimum of 2 mm separation to the user.

3. The chip antenna with antenna gain 0.43 dBi is permanently attached to the module, and for compliance the

antenna shall not be modified. A separate approval is required for all other operating configurations, including

different antenna configurations.

4. If any other simultaneous transmission radio is installed in the host platform together with this module, or the

separation distance of the module to the user cannot be kept equal or larger than 2 mm, a separate RF exposure

assessment and RSS-102 equipment certification is required.

Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and

maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference

to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power

(e.i.r.p) is not more than necessary for successful communication.

Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne

d'un type et d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada. Dans le but de réduire

les risques de brouillage radioélectrique à l'intention des autres utilisateurs, il faut choisir le type d'antenne et son

gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à

l'établissement d'une communication satisfaisante.

Labeling Requirements for the Host Device (from Section 3.2.1, RSS-Gen, Issue 3, December 2010): The host

device shall be properly labeled to identify the module within the host device. The Industry Canada certification

label of a module shall be clearly visible at all times when installed in the host device, otherwise the host device

must be labeled to display the Industry Canada certification number of the module, preceded by the words

―Contains transmitter module, or the word ―Contains, or similar wording expressing the same meaning, as

follows: Contains transmitter module

IC: 10809A-WLM01.
