ADATA PD10 User Manual

Hi-Speed USB 2.0 Flash Disk

User Manual

Content

Introduction…………………………………………………………………………2

Features and Specifications .………………………………………………….2 System Requirements……….………………………………………..………….3 For Your Safety…….……………………………………………………………...3

Installation of USB Driver…………………………………………………….…..4

Installing in Windows98/98SE OS Environment……………………………4~5

Installation of USB Flash Disk Utility Program……………………………….6

Disk Partition and Security Setup Function………………………………..7~10 Log in Security Disk……………………………………………………………..11 Partition Change and Password Setup………………………………………..12 Change Password…………………………………………………………..13~14 Disk Format………………………………………………………………….15~16 Make Bootable Disk………………………………………………………...17~18

Introduction

Congratulations on your purchase of this Hi-Speed USB Portable Flash Disk! This Hi-Speed USB Flash Disk is your friendly, secure, and lightweight removable mass storage device disk. It plugs thru the USB port so your computer will quickly detect and configure the disk without needing to restart the computer. You read, write, copy and delete files just the same way as you use a disk drive. And since it is a large capacity disk, you can also play MP3 files, run program applications or play videos directly from the disk. The most importance is that the disk also supports Ready Boost function for Windows Vista. No need to modify the PC/Hardware, you can simply improve the OS performance only plugging the disk thru the USB port.

This Hi-Speed USB Flash Disk also provides great flexibility and data security with disk partitioning and password security features. The USB Flash Disk (UFD) Utility allows you to easily manage your USB Flash Disk and protect your personal important data.

Features & Specifications

 Smart and secure removable data storage for business and personal use  Full Compliance with the Universal Serial Bus Specification v2.0 and v1.1  Data Write-Protect Switch  Support Windows Vista Ready Boost Function  Mass Storage Device class compatible so no driver needed in Windows

ME, 2000, XP, Mac 9.1 or above. Includes manufacturer driver for Windows 98

 USB Flash Disk Utility Program for security and partitioning functions (No

additional drivers needed)

 Bus Powered – no separate power supply or battery required  State-of-the-art NAND Flash Memories  Shock resistant, noise-free and longer data retention  Advanced power management mechanism

System Requirements

 Pentium Desktop PC & Laptop PC with high power USB port hub  Windows 98/ 98SE, ME, 2000, XP, Vista  Mac OS 9.X or above  Linux Kernal 2.4 or above

For Your Safety

 Keep your Hi-Speed USB Flash Disk away from all kinds of sources of

high temperature and moisture, and also avoid using it on sunlight exposure.

 To make sure your Hi-Speed USB Flash Disk’s performance stability and

increase its life time cycle, please do not plug/unplug your Hi-Speed USB Flash Disk while transferring data to avoid the permanent damage of Hi-Speed USB Flash Disk.

 To properly unplug the Hi-Speed USB Flash Disk, you must follow the

Safely Remove Hardware Steps. Once Windows show that the USB Mass Storage Device can now be safely removed. You can then unplug the disk from the USB port.

Installation of USB Driver

Before using your Hi-Speed USB Flash Disk, please confirm which version of OS you install into your computer. To use the Hi-Speed USB Flash Disk, you simply plug it into your computer’s USB port. Windows ME, 2000, XP and Vista, Mac 9.X or above, Linux Kernal 2.4 or above versions all support the Microsoft USB Mass Storage driver needed to detect and run the device.

However, if you have a Windows 98/98SE, you will need to run the USB Flash Disk Utility Setup that will also install the needed USB mass storage driver. Please follow the below procedure to do the installation;

1. Please insert the CD and double-click on “USB 2.0 Flash Disk Driver “.

After that, please double-click “USB 2.0 Flash Disk Driver“. When driver download into OS/computer, then plug in the Hi-Speed USB Flash Disk.

2. After executing “USB Mass Storage Disk Windows 98 Driver install” driver,

the message will appear like as below：

3. Please click on “ Next” to continue the setup of USB 2.0 Flash Disk driver.

4. When appearing “You need to un-plug and re-plug the device” message,

please click on “OK” to finish the setup of USB Mass Storage Disk driver. After re-plugging, OS will detect the USB Flash Disk and run the disk driver automatically.
