Adam Equipment AAA Specification

05.02.2022 Adam Equipment Scales, Balances and Weighing Equipment
The prices below were the Manufacturer's List prices in 2004. Clarkson Laboratory Supply offers a 20% Discount with free shipping in the Continental United States. Click here for Current Prices.
AAA Series Analytical Balances
The AAA series of analytical balances combines precision weighing technology with the latest processing software.
Adam AAA balances combine precision weighing technology with modern processing software to provide the laboratory user with a reliable weighing instrument incorporating all of the features required for efficient analytical work.
AAA are available in two different versions AAA-L with motorised internal calibration weight and AAA-LE with manual external calibration via the keypad. The AAA-L balance will also calibrate automatically when the temperature changes in excess of a preset amount.
The GLP compliant software package enables print out of full calibration details, providing documentation to mark the audit trail. Weighing data can be transmitted to a computer or printer and the balance can be controlled using commands from a PC via a standard RS232C interface.
There are seven selectable weighing units in every AAA balance (mg, g, ct, GN, mo, oz, dwt). For working in an unstable environment digital filters and suppression of the last digit on the display optimise response time and speed up weighing operations. Features include parts counting and percentage weighing.
A large, clear LCD display and sealed keypad with a positive feel .click. make it easy to operate the AAA.
All balances feature full range tare and the TARE key is highlighted in yellow for quick recognition and use.
Basic Specifications
Capacity Readability Pan size Price
AAA 100L 100g 0.1mg 100mm Ø / 3.9″ Ø $USD 1,650.00
AAA 160L 160g 0.1mg 100mm Ø / 3.9″ Ø $USD 1,750.00
AAA 250L 250g 0.1mg 100mm Ø / 3.9″ Ø $USD 1,950.00
AAA 300L 300g 0.1mg 100mm Ø / 3.9″ Ø $USD 2,400.00
Detailed specifications
AAA 100L AAA 160L AAA 250L AAA 300L
Maximum capacity 100g 160g 250g 300g
Readability 0.1mg 0.1mg 0.1mg 0.1mg
Units of measure g, mg, ct, GN, mo, oz, dwt
Interface Bi-directional RS-232
Power supply 10V AC adapter (supplied)
Calibration Motorised internal except LE versions which are external
Display 16mm LCD digital display
Pan size 100mm Ø / 3.9″ Ø
Overall dimensions 185×470×280 mm / 7.3×18.5×11″
Chamber dimensions 172×170×230 mm / 6.8×6.7×9.1″
Gross weight 12kg / 26.5lb
ACBplus Compact Balances
The ACBplus is a lightweight, rugged precision compact balance suitable for a wide range of weighing applications.
Large and very stable case in modern attractive design Capacity tracker Height adjustable feet Rechargeable battery / mains adapter (adapter supplied as standard) Automatic calibration via the keypad Low battery indicator RS-232 interface Large, clear backlit LCD 15 weighing units Auto power off Weighing, percentage weighing and parts counting Stainless steel pan Windshield as standard on all models Integral security bracket
The ACBplus has 7 models in the range, with capacities from 150g up to 3kg and readabilities from 0.005g to 0.1g.
www.clarksonlab.com/ada/ae_data/ae_data.htm 1/16
05.02.2022 Adam Equipment Scales, Balances and Weighing Equipment
The balances have the ability to display 15 different weighing units such g, ct, lb, oz, d, GN, oz t, dwt, mommes, TL.T, TL.C, TL.t, ti, N, g2. and functions include parts counting and percentage weighing.
The new ACBplus has a lot of new features such as a large and very stable case in a modern attractive design, an integral security bracket, capacity tracker and a low battery indicator.
As well as being supplied with a mains adapter these scales also have an internal rechargeable battery making them totally portable.
Standard features are a draughtshield for precision weighing and RS-232 interface.
To ensure consistent accuracy and tip-top performance the ACBplus can be easily calibrated using the auto calibration function through the keypad.
Basic Specifications
Capacity Readability Platform size Price
ACBplus 150 150g / 0.3lb 0.005g / 0lb 120mm Ø / 4.7″ Ø $USD 345.00
ACBplus 300 300g / 0.7lb 0.01g / 0lb 120mm Ø / 4.7″ Ø $USD 345.00
ACBplus 600 600g / 1.3lb 0.02g / 0lb 120mm Ø / 4.7″ Ø $USD 345.00
ACBplus 600H 600g / 1.3lb 0.01g / 0lb 120mm Ø / 4.7″ Ø $USD 395.00
ACBplus 1000 1000g / 2.2lb 0.01g / 0lb 120mm Ø / 4.7″ Ø $USD 480.00
ACBplus 1500 1500g / 3.3lb 0.05g / 0.0001lb 144×124mm / 5.7×4.9″ $USD 345.00
ACBplus 3000 3000g / 6.6lb 0.1g / 0.0002lb 144×124mm / 5.7×4.9″ $USD 345.00
Detailed specifications
ACBplus 150 ACBplus 300 ACBplus 600 ACBplus 600H ACBplus 1000 ACBplus 1500 ACBplus 3000
Maximum capacity 150g 300g 600g 600g 1000g 1500g 3000g
Readability 0.005g 0.01g 0.02g 0.01g 0.01g 0.05g 0.1g
Units of measure g, ct, lb, oz, d, GN, oz t, dwt, mommes, TL.T, TL.C, TL.t, ti, N, g2
Interface RS-232 output
Power supply 9V/800 mA
Calibration Automatic external
Display 16mm / 0.6" high 6 digits LCD with auto backlight and loading bar graph
Pan size 120mm Ø / 4.7″ Ø 144×124mm / 5.7×4.9″
Overall dimensions 195×240×70 mm / 7.7×9.4×2.8″
Gross weight 2.5kg / 5.5lb
ADK Precision Balances
The ADK with its large weighing pan and cast aluminium base is ideal for heavy capacity weighing.
Force restoration mechanism
www.clarksonlab.com/ada/ae_data/ae_data.htm 2/16
05.02.2022 Adam Equipment Scales, Balances and Weighing Equipment
Robust
construction with heavy duty casing Stainless steel weighing pan Full range tare Push-button calibration Vacuum fluorescent display RS-232 interface Simple key operation Anti-shock protection Below pan weighing facility
ADK balances are designed to provide the user with fast, accurate, high capacity weighing.
The balance has a large stainless steel weighing pan and cast aluminium base and all the basic features for an ideal laboratory workhorse which stands up to the rigours of routine daily use.
Basic Specifications
Capacity Readability Platform size Price
ADK 10 10kg / 22lb 0.1g / 0.0002lb 300×340mm / 11.8×13.4″ $USD 1,750.00
ADK 20 20kg / 44lb 0.1g / 0.0002lb 300×340mm / 11.8×13.4″ $USD 2,000.00
Detailed specifications
ADK 10 ADK 20
Maximum capacity 10kg 20kg
Readability 0.1g 0.1g
Units of measure g
Interface RS232 output
Power supply Power cord 240V or 115V option via switch on unit
Calibration Automatic external
Display LED
Pan size 300×340mm / 11.8×13.4″
Overall dimensions 314×460×164 mm / 12.4×18.1×6.5″
Gross weight 23kg / 51lb
www.clarksonlab.com/ada/ae_data/ae_data.htm 3/16
05.02.2022 Adam Equipment Scales, Balances and Weighing Equipment
AEA Series Analytical Balances
The AEA series are the professional series of analytical balances in the Adam range.
Large graphical LCD display with backlight and function icons Motorised internal calibration weight Standard applications include weighing, parts counting, percentage weighing, check weighing, averaging, filling guide, statistics, animal weighing, formulation mode and density determination Large weighing pan and chamber with 3 door windshield 15 weighing units including a user programmable custom unit Bi-directional RS-232 interface for GLP compliant reports and connection to a computer or printer Automatic temperature compensation Selectable automatic calibration due to temperature variations Die cast aluminium housing Easy to use keypad Date and time Capacity tracker Below pan weighing facility Interface for standard PC keyboard, remote display, or tare and print foot switches
The AEA series are the professional series of analytical balances in the Adam range.
The balances have automatic calibration with internal calibration weight as well as a large graphic LCD display with back light and RS-232 interface for GLP compliant documentation.
They combine precision weighing technology with the latest processing software and offer many important features for the more demanding user.
The AEA series has 15 weighing units including a user programmable custom unit as well as built-in applications including weighing, parts counting, percent weighing, averaging, filling guide, animal weighing, formulation mode and density determination.
Additional features are automatic compensation for minor temperature variations, the facility to enter date and time and an easy to use keypad as well as an attachment for a standard keyboard. The balances also offer the possibility for a remote display, tare switch and print.
The range includes a dual range 4/5 decimal place and a semi-micro balance.
Basic Specifications
Capacity Readability Pan size Price
AEA 160DG 62g/160g 0.01mg/0.1mg 85mm Ø / 3.3″ Ø $USD 3,295.00
AEA 100SG 100g 0.01mg 85mm Ø / 3.3″ Ø $USD 3,595.00
AEA 100G 100g 0.1mg 100mm Ø / 3.9″ Ø $USD 1,995.00
AEA 160G 160g 0.1mg 100mm Ø / 3.9″ Ø $USD 2,095.00
AEA 250G 250g 0.1mg 100mm Ø / 3.9″ Ø $USD 2,395.00
Detailed specifications
AEA 160DG AEA 100SG AEA 100G AEA 160G AEA 250G
Maximum capacity
62g/160g 100g 100g 160g 250g
Readability 0.01mg/0.1mg 0.01mg 0.1mg 0.1mg 0.1mg
Units of measure
grams, milligrams, carats, pounds, ounces, troy ounces, pennyweight (dwt), Taels (Hong Kong), Taels (Singapore), Taels (Taiwan), tical, mommes, grains,
Newtons, custom unit - user programmable
Interface RS-232, bi-directional, 2400 - 19200 baud with handshaking and complete control of balance functions.
Power supply 11VAC-14VAC, 50/60Hz 400MA. or 16VDC to 20VDC @400MA External Module
Calibration Calibration with internal mass. Optionally the user can use an external mass.
Display
Graphics LCD with Backlight, 134mm x 40mm / 5.2″ x 1.6″. Displays weighing information, date, time, 0-100% capacity and special data for weighing
functions.
Pan size 85mm Ø / 3.3″ Ø 100mm Ø / 3.9″ Ø
Overall dimensions
185×470×280 mm / 7.3×18.5×11″
Chamber dimensions
172×170×230 mm / 6.8×6.7×9.1″
Gross weight 12kg / 26lb
AEP Precision Balances
The AEP series are the professional series of precision balances in the Adam range.
Large graphical LCD display with backlight and function icons Motorised internal calibration weight Standard applications include weighing, parts counting, check weighing, percentage weighing, averaging, filling guide, statistics, animal weighing, formulation mode and density determination 15 weighing units including a user programmable custom unit Bi-directional RS-232 interface for GLP compliant reports and connection to a computer or printer Automatic temperature compensation Selectable automatic calibration due to temperature variations Easy to use keypad Date and time Capacity tracker Below pan weighing facility Interface for standard PC keyboard, remote display, or tare and print foot switches Built-in security bracket All AEPs with 1mg readability include a square glass windshield as standard
The AEP series are the professional series of precision balances in the Adam range.
The balances have automatic calibration with an internal calibration weight as well as a large graphic LCD display with backlight and RS-232 interface for GLP compliant documentation.
www.clarksonlab.com/ada/ae_data/ae_data.htm 4/16
05.02.2022 Adam Equipment Scales, Balances and Weighing Equipment
They combine precision weighing technology with the latest processing software and offer many important features for the more demanding user.
The AEP series have 15 weighing units including a user programmable custom unit as well as built-in applications including weighing, parts counting, percent weighing, averaging, filling guide, animal weighing, formulation mode and density determination.
Additional features are automatic compensation for minor temperature variations, the facility to enter date and time and an easy to use keypad as well as an attachment for a standard keyboard. The balances also offer the possibility for a remote display, tare switch and print.
Basic Specifications
Capacity Readability Platform size Price
AEP 150G 150g / 0.3lb 0.001g / 0lb 128×128mm / 5×5″ $USD 1,325.00
AEP 250G 250g / 0.6lb 0.001g / 0lb 128×128mm / 5×5″ $USD 1,395.00
AEP 450G 450g / 1lb 0.001g / 0lb 128×128mm / 5×5″ $USD 1,595.00
AEP 650G 650g / 1.4lb 0.001g / 0lb 128×128mm / 5×5″ $USD 1,895.00
AEP 1500G 1500g / 3.3lb 0.01g / 0lb 165×165mm / 6.5×6.5″ $USD 1,325.00
AEP 2500G 2500g / 5.5lb 0.01g / 0lb 165×165mm / 6.5×6.5″ $USD 1,395.00
AEP 4500G 4500g / 9.9lb 0.01g / 0lb 165×165mm / 6.5×6.5″ $USD 1,650.00
AEP 6000G 6000g / 13.2lb 0.01g / 0lb 165×165mm / 6.5×6.5″ $USD 1,850.00
Detailed specifications
AEP 150G AEP 250G AEP 450G AEP 650G AEP 1500G AEP 2500G AEP 4500G AEP 6000G
Maximum capacity
150g 250g 450g 650g 1500g 2500g 4500g 6000g
Readability 0.001g 0.001g 0.001g 0.001g 0.01g 0.01g 0.01g 0.01g
Units of measure
grams, milligrams, carats, pounds, ounces, troy ounces, pennyweight (dwt), Taels (Hong Kong), Taels (Singapore), Taels (Taiwan), tical, mommes, grains,
Newtons, custom unit - user programmable
Interface RS-232, bi-directional, 2400 .19200 baud with handshaking and complete control of balance functions
Power supply 11VAC-14VAC, 50/60Hz 500ma. or 16VDC to 20VDC @500ma External Module
Calibration Calibration with internal mass. Optionally the user can use an external mass.
Display
Graphics LCD with Backlight, 134mm x 40mm / 5.2″ x 1.6″. Displays weighing information, date, time, 0-100% capacity and special data for weighing
functions
Pan size 128×128mm / 5×5″ 165×165mm / 6.5×6.5″
Overall dimensions
205×300×90 mm / 8.1×11.8×3.5″
Gross weight 10kg / 22lb
AFA Series Analytical Balances
The AFA series is a range of affordable analytical balances with all the features you need.
The AFA series is a range of affordable analytical balances with all the features you need for quality control, education and special applications in any laboratory.
The AFA balances offer a choice of 7 weighing units plus several features such as % weighing and parts counting as well as accessories for density determination and below pan weighing.
Additional features are motorised internal calibration and automatic temperature compensation, a large clear LCD display and dual tare keys for ease of operation.
Basic Specifications
Capacity Readability Pan size Price
AFA 120LC 120g 0.1mg 85mm Ø / 3.3″ Ø $USD 1,325.00
AFA 180LC 180g 0.1mg 85mm Ø / 3.3″ Ø $USD 1,550.00
AFA 210LC 210g 0.1mg 85mm Ø / 3.3″ Ø $USD 0.00
Detailed specifications
AFA 120LC AFA 180LC AFA 210LC
Maximum capacity 120g 180g 210g
Readability 0.1mg 0.1mg 0.1mg
Units of measure g, mg, ct, GN, mo, oz, dwt
Interface RS-232
Power supply 10VAC-12VAC, 50/60Hz 400ma. External module, 230VAC or 115VAC, 50/60Hz input
www.clarksonlab.com/ada/ae_data/ae_data.htm 5/16
