A&D TM-2655P, TM-2655 User Manual
Automatic Blood Pressure Monitor
© 2001 A&D Company Ltd. All rights reserved.
No part of this publication may be reproduced, transmitted, transcribed, or translated
into any language in any form by any means without the written permission of A&D
Company Ltd.
The contents of this manual and the specifications of the instrument covered by this
manual are subject to change for improvement without notice.
WARNING DEFINITIONS
The warnings described in this manual have the following meanings:
WARNING
Important information to alert you to a situation that might cause injury and/or damage to your
property if instructions are not followed.
CAUTION
Important information to alert you to a situation that might cause minor injury and/or damage to
your property if instructions are not followed.
Note
Important information that helps users operate the device.
i
COMPLIANCE
Compliance with the European Directive 93/42/EEC for Medical Products
This device conforms to the following requirements: European Directive 93/42/EEC for Medical Products
act; Medical Products Act; European Standards for Electrical Equipment EN 60601-1 (General Safety
Provisions), EN 60601-1-2 and EN 55011 (Electromagnetic Compatibility); European Standards
pertaining to Non Invasive Blood Pressure Instruments EN 1060-1(General Requirements), EN 1060-3
(Supplementary Requirements for Electromechanical Blood Pressure Measuring Systems).
This is evidenced by the CE mark of conformity accompanied by the reference number of a designated
authority.
This device was designed for use by adults only.
Compliance with the Australian EMC Frame Work
This device conforms to the following requirements: EMC Emission Standard for Industrial, Scientific and
Medical Equipment AS/NZS 2064-1997, EMC Generic Immunity standard AS/NZS 4252.1-1994. This is
evidenced by the C-Tick label.
Environment for use
The device is for use in offices, sports facilities, and hospitals (waiting rooms), etc.
NOTE
This device does not have the function of automatic cycling measurement.
Therefore, a part of this device does not conform to IEC60601-2-30.
ii
SAFETY PRECAUTIONS
WARNING
Grounding
To avoid electrical shock, connect the power cable to a medical electrical outlet having a ground
terminal for grounding the device.
Fuse
To avoid a fire hazard, use only a fuse of the proper type, voltage and current rating as specified on
the rear panel. Never bypass a fuse by shorting across the fuse holder and connectors.
Service
Internal service or adjustment to this device should be performed by a qualified person only. Do not
disassemble or modify the device
Device failure
If a device failure occurs, promptly stop using it. Remove the device from the patient and secure the
patient’s safety. Turn the power off and disconnect the power cable from the electrical outlet. Affix a
notice such as “Out of Order” and “Do Not Use” on the device. Ask the nearest dealer for services
To interpret blood pressure measurements
Only a trained medical professional is qualified to interpret the blood pressure measurements. No
device can replace regular medical checkups by a doctor. A doctor should verify the blood pressure
measurements before making adjustments to medication.
When the device gets wet because of a liquid spill
If the device gets wet, promptly stop using it. Remove the device from the patient and secure the
patient’s safety. Turn the power off and disconnect the power cable from the electrical outlet. Affix a
notice such as “Out of Order” and “Do Not Use” on the device. Ask the nearest dealer for service.
CAUTION
In case of emergency
Press the EMERGENCY STOP switch located on the front of the device. This will release the air in the
arm cuff so that the arm can be removed easily. It also operates if there is a power failure.
To stop the operation at any time
Press the START/STOP switch located on the display panel. The quick exhaust will release the air in
the arm cuff and the arm cuff will become loose.
Maintenance/Inspection
Check all functions periodically. Ask the nearest dealer for this inspection.
Do not disassemble or modify the device.
If the device is used for the first time after an extended period of storage, check the device for proper
operation.
iii
GENERAL PRECAUTIONS
Obey the following precautions for safe and correct usage.
Precautions unique to the TM-2655/TM-2655P appear on the relevant page in this manual. Read the
manual thoroughly before use.
When installing and storing the device
Install or store the device away from moisture.
Do not install or store the device where the device may be badly affected by extreme temperature,
humidity, direct sunlight, draft, dust, salinity or sulfur content in the air.
Do not install or store the device where chemicals, and corrosive or explosive gases are stored or
present.
Install or store the device in a secure, level and stable location.
Install or store the device where adequate power is provided. (Where a me dical 3P electrical outlet
is provided.)
Before use
Check to make sure the device operates safely and accurately.
Check all cables for proper connection.
When other medical equipment is used at the same time, a diagnostic error or dangerous situation
may occur. Check all connections to make sure they do not interfere with each other.
When other telemeters are used, check that mutual interference will not cause a problem.
During use
Check the patient and the device during use.
If medical or operational problems are found in the device or the patient, stop using the device
immediately, check the status of the patient and take proper action.
Do not use the device during MRI scanning.
Do not use the device on a patient using a heart-lung machine.
High frequency interference by electrosurgery or energy discharged by a defibrillator may damage
the device. Follow the precautions described in the manual for each device.
Do not use a cellular telephone near the device. It could affect the device’s operation.
The personal computer and medical equipment connected to the device are n ot allowed to be in the
patient area.
The personal computer used must conform to IEC60950
After use
Follow the predetermined procedure to return the operation switches to their original pos itions, and
then turn off the power.
Do not forcibly pull out the cables. Hold the connector with your hand when disconnecting the
cable.
Keep the device clean and in proper operating condition so that it can be used without problem
during the next operation.
Clean the accessories and arrange th em before storage.
Environmental protection
Remove the built-in lithium battery from the device when the device is to be disposed of.
This device, any part of, and the built-in lithium battery are not treated as ordinary household waste,
iv
and must be disposed of according to the applicable regulations.
v
CONTENTS
WARNING DEFINITIONS.......................................................................................................I
COMPLIANCE....................................................................................................................... II
SAFETY PRECAUTIONS.....................................................................................................III
GENERAL PRECAUTIONS.................................................................................................IV
1. INTRODUCTION ...............................................................................................................3
1-1 Features.......................................................................................................................................................3
1-2 Unpacking and Inspection...........................................................................................................................
1-3 Specifications...............................................................................................................................................
4
5
2. PART NAMES ...................................................................................................................6
2-1 Main Unit......................................................................................................................................................6
2-2 Rear Panel...................................................................................................................................................
2-3 Symbols.......................................................................................................................................................
7
7
3. INSTALLATION.................................................................................................................8
4. OPERATION...................................................................................................................... 9
5. SETTING THE CLOCK ...................................................................................................
5-1 Clock Adjustment Mode.............................................................................................................................11
5-2 A Setting Example......................................................................................................................................
11
11
6. INSTALLING THE PRINTER PAPER..............................................................................13
7. SETTING THE FUNCTIONS...........................................................................................14
7-1 Function Setting Mode...............................................................................................................................14
7-2 Description of the Functions......................................................................................................................
7-3 Printing Samples........................................................................................................................................
15
16
8. COMMUNICATION SPECIFICATIONS...........................................................................17
8-1 Channel 1 : Miniature DIN 8-pin................................................................................................................17
8-2 Channel 2: D-sub 9-pin..............................................................................................................................
1
18
9. MAINTENANCE...............................................................................................................19
9-1 Replacing the Arm Cuff Cover.................................................................................................................. 19
9-2 Replacing the Fuses.................................................................................................................................
9-3 Checking the Counter...............................................................................................................................
Displaying the counter.................................................................................................................................
Resetting the counter..................................................................................................................................
9-4 Error Codes ..............................................................................................................................................
9-5 Maintenance.............................................................................................................................................
9-6 Cleaning....................................................................................................................................................
9-7 Options and Consumables .......................................................................................................................
20
20
20
20
20
21
21
22
10. TROUBLESHOOTING...................................................................................................23
11. EXTERNAL DIMENSIONS.............................................................................................24
2
