INDOOR
Instruction Manual
Digital Thermometer
model 00609SBLA1
ACU>RITE
CONTENTS
Unpacking Instructions ........... 2
Package Contents .................. 2
Product Registration ............... 2
Features & Benets: Sensor..... 2
Features & Benets: Display.... 3
Setup .................................... 4
Install or Replace Batteries...... 4
Placement Guidelines ............. 5
Questions? Contact Customer Support at
(877) 221-1252 or visit www.AcuRite.com
Using the Thermometer........... 6
Troubleshooting ..................... 7
Care & Maintenance.............. 8
Specications......................... 8
FCC Information .................... 8
Customer Support .................. 9
Warranty............................... 9
SAVE THIS MANUAL FOR FUTURE REFERENCE.
~CU
►
RITE®
Congratulations on your new AcuRite product. To ensure the best
possible product performance, please read this manual in its entirety
and retain it for future reference.
Unpacking Instructions
Remove the protective lm that is applied to the LCD screen prior to using this
product. Locate the tab and peel off to remove.
Package Contents
1. Display with Tabletop Stand
2. Outdoor Sensor
3. Instruction Manual
IMPORTANT
PRODUCT MUST BE REGISTERED
TO RECEIVE WARRANTY SERVICE
PRODUCT REGISTRATION
Register online to receive 1 year warranty protection
www.AcuRite.com
Features & Benets
1111
1
2
3
OUTDOOR SENSOR
1. Integrated Hanger
For easy placement.
2. Wireless Signal Indicator
Flashes when data is being sent to
the display.
3. Battery Compartment Cover
2
Features & Benets
2
t
OUT
1
l
1
IOOR
□
OF
3
4
5
6
7
,o~
!.
:2e\ a]
INDOOR E---------,-
ACU
DISPLAY
1. Current Outdoor Temperature
Arrow icon indicates the direction the
temperature is trending.
2. High Outdoor Temperature Record
3. Low Outdoor Temperature Record
4. High Outdoor Humidity Record
5. Current Outdoor Humidity
Arrow icon indicates the direction the
humidity is trending.
6. Low Outdoor Humidity Record
7. Current Indoor Temperature
Arrow icon indicates the direction the
temperature is trending.
T11II
►
ITE
8 9
8. Low Indoor Temperature and
Humidity Record
9. High Indoor Temperature and
Humidity Record
10. Current Indoor Humidity
Arrow icon indicates the direction the
humidity is trending.
11. Display Low Battery Indicator
12. Outdoor Sensor Low
Battery Indicator
13. Outdoor Sensor Signal Strength
13
12
11
10
3
SETUP
Install or Replace Batteries
AcuRite recommends high quality alkaline batteries for the best product
performance. Heavy duty or rechargeable batteries are not recommended.
The outdoor sensor requires lithium batteries in low temperature conditions.
Cold temperatures can cause alkaline batteries to function improperly. Use
lithium batteries in the outdoor sensor for temperatures below -4ºF / -20ºC.
Outdoor Sensor
1. Slide off the battery compartment cover.
2. Insert 2 x AA batteries into the battery
compartment, as shown. Follow the
polarity (+/-) diagram in the battery
compartment.
3. Replace the battery cover.
(70°C) 158°F I
(70°C) 158°F I
=
B~~f~~~S
ALKALINE
BATTERIES
e l•JR +wa•
Display
1. Slide off the battery compartment cover.
2. Insert 3 x AAA batteries into the
battery compartment, as shown.
Follow the polarity (+/-) diagram in
the battery compartment.
3. Replace the battery cover.
Select Degrees Fahrenheit or Celsius
To select between degrees Fahrenheit (ºF) or Celsius (ºC) temperature units,
press the “ºF/ºC” button located on the back of display.
PLEASE DISPOSE OF OLD OR DEFECTIVE BATTERIES IN AN ENVIRONMENTALLY SAFE
WAY AND IN ACCORDANCE WITH YOUR LOCAL LAWS AND REGULATIONS.
used for an extended period of time. Follow the polarity (+/-) diagram in the battery compartment. Promptly remove dead batteries from the device. Dispose of used
batteries properly. Only batteries of the same or equivalent type as recommended are to be used. DO NOT incinerate used batteries. DO NOT dispose of batteries in fire,
as batteries may explode or leak. DO NOT mix old and new batteries or types of batteries (alkaline/standard). DO NOT use rechargeable batteries. DO NOT recharge
non-rechargeable batteries. DO NOT short-circuit the supply terminals.
BATTERY SAFETY: Clean the battery contacts and also those of the device prior to battery installation. Remove batteries from equipment which is not to be
4
Placement for Maximum Accuracy
AcuRite sensors are sensitive to surrounding environmental conditions. Proper
placement of both the display and outdoor sensor are critical to the accuracy
and performance of this product.
Display Placement
Place the display in a dry area free of dirt and dust. Display stands
upright for tabletop use or is wall-mountable.
Outdoor Sensor Placement
Sensor must be placed outside to observe outdoor conditions.
Sensor is water resistant and is designed for general outdoor use,
l
however, to extend its life place the sensor in an area protected
from direct weather elements.
'"
Hang the sensor using the integrated hang holes or hanger, or by
using string (not included) to hang it from a suitable location, like a
well covered tree branch. The best location is 4 to 8 feet above the
ground with permanent shade and plenty of fresh air to circulate
around the sensor.
Important Placement Guidelines
• To ensure accurate temperature measurement, place units out of direct
sunlight and away from heat sources or vents.
• Display and outdoor sensor must be within 165 ft (50 m) of each other.
• To maximize wireless range, place units away from large metallic items, thick
walls, metal surfaces, or other objects that may limit wireless communication.
• To prevent wireless interference, place both units at least 3 ft (.9 m) away
from electronic devices (TV, computer, microwave, radio, etc.)
Setup is Complete
The sensor will now synchronize with the display. It may take a few minutes for
synchronization to complete. Please refer to the troubleshooting section of this
manual if anything appears to be functioning improperly.
(.9m) -
ii
18'"
(165 feet maximum)
(50 meters)
5
~
3 feet lf"ll'-
OPERATION
Using the Thermometer
High & Low Records
High and low records reect the minimum and maximum temperature and
humidity recorded since the unit was powered on, since the batteries were
replaced, or since the records were manually reset (whichever was most
recent).
To view the LOW records, press and release the “▼” button. The “ ” icon
appears on the display next to the low records.
To view the HIGH records, press and release the “▲” button. The “ ” icon
appears on the display next to the high records.
To reset the LOW records, press AND HOLD the “▼” button while viewing the
low records. Dashes will display to conrm all low records have been reset.
To reset the HIGH records, press AND HOLD the “▲” button while viewing the
high records. Dashes will display to conrm all high records have been reset.
6
Troubleshooting
Problem Possible Solution
No outdoor sensor
reception
no bars
T111I
Outdoor
temperature
is ashing or
showing dashes
If the wireless signal indicator shows no bars:
• Relocate the display and/or the outdoor sensor. The
units must be within 165 ft (50 m) of each other.
• Make sure both units are placed at least 3 feet (.9 m)
away from electronics that may interfere with the
wireless communication (such as TVs, microwaves,
computers, etc).
• Use standard alkaline batteries (or lithium batteries
in sensor when temperature is below -4ºF/-20ºC). Do
not use heavy duty or rechargeable batteries. NOTE:
It may take a few minutes for display and sensor to
synchronize after batteries are replaced.
Flashing of the outdoor temperature is generally an
indication of wireless interference.
1. Bring both the sensor and display indoors and
remove at least one battery from each.
2. Reinstall the battery in the outdoor sensor.
3. Reinstall the battery in the display.
4. Let the units sit within a couple feet of each other
for a few minutes to gain a strong connection.
Inaccurate
temperature
Display screen
not working
• Make sure both the display and sensor are placed out
of direct sunlight and away from any heat sources or
vents (see page 5).
• Check that the batteries are installed correctly.
Batteries may need to be replaced.
If your AcuRite product does not operate properly after trying
the troubleshooting steps, visit www.AcuRite.com or call
(877) 221-1252 for assistance.
7
Care & Maintenance
Display Care
Clean with a soft, damp cloth. Do not use caustic cleaners or abrasives. Keep
away from dust, dirt and moisture. Clean ventilation ports regularly with a
gentle puff of air.
Outdoor Sensor Care
Clean with a soft damp cloth. Do not use caustic cleaners or abrasives.
Specications
TEMPERATURE RANGE
Outdoor: -40ºF to 158ºF; -40ºC to 70ºC
Indoor: 32ºF to 122ºF; 0ºC to 50ºC
HUMIDITY RANGE
WIRELESS RANGE
WIRELESS FREQUENCY
POWER
1% to 99% RH
165 ft / 50 m depending on home construction materials
433 MHz
Display: 3 x AAA alkaline batteries
Sensor: 2 x AA alkaline or lithium batteries
DATA REPORTING
Outdoor data: 30 second updates
Indoor data: 60 second updates
FCC Information
This device complies with part 15 of FCC rules. Operation is subject to the following two conditions:
1- This device may NOT cause harmful interference, and
2- This device must accept any interference received, including interference that may cause undesired operation.
WARNING: Changes or modications to this unit not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equip
ment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modications to this equipment.
Such modications could void the user authority to operate the equipment.
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions:
(1) This device may not cause interference, and
(2) This device must accept any interference received, including interference that may cause undesired operation of the device.
-
8
Limited 1-Year Warranty
PURPOSE.
We expressly disclaim all liability for special, consequential,
Canada, please consult the policies applicable to the country in
9
State of Wisconsin.
Wisconsin; and purchaser consents to jurisdiction within the
federal or State courts having jurisdiction in Walworth County,
dispute relating to this Policy shall be brought exclusively in the
laws of the United States and the State of Wisconsin. Any
This Return, Refund, and Warranty Policy is governed by the
Governing Law
resale sites such as eBay or Craigslist.
refund, or warranty services if you buy products used or from
of our products. We cannot and do not offer any return,
Additionally, this Policy applies only to the original purchaser
which you made your purchase.
purchases made in a country other than the United States or
purchases made in the United States and Canada. For
This Return, Refund, and Warranty Policy applies only to
Applicability of Policy
original purchase price paid for the product.
products, your purchase or your use thereof, exceed the
In no case shall our liability for any claim relating to our
writing and signed by a duly authorized agent of ours.
to modify or waive the terms of this warranty unless done in
Furthermore, no person, rm or corporation is authorized
or liability in connection with the sale of our products.
or corporation is authorized to bind us to any other obligation
consequences arising from their use or misuse. No person, rm
any of our products, the purchaser assumes all liability for the
our products to the extent permitted by law. By acceptance of
We further disclaim liability from personal injury relating to
so the above limitation or exclusion may not apply to you.
exclusion or limitation of incidental or consequential damages,
from any breach of this warranty. Some states do not allow the
or incidental damages, whether arising in tort or by contract
AND THE IMPLIED WARRANTY OF FITNESS FOR A PARTICULAR
LIMITATION THE IMPLIED WARRANTY OF MERCHANTABILITY
ARE HEREBY EXPRESSLY DISCLAIMED, INCLUDING WITHOUT
OTHER THAN THE EXPRESS WARRANTY SET FORTH HEREIN
WARRANTIES, EXPRESS OR IMPLIED. ALL OTHER WARRANTIES
FOR THE PRODUCTS AND IS EXPRESSLY IN LIEU OF ALL OTHER
THE ABOVE-DESCRIBED WARRANTY IS THE SOLE WARRANTY
the amount of the original purchase price.
or replacement is not feasible, we may, at our option, refund
replacement of the defective item(s). If we determine that repair
Remedy for breach of this warranty is limited to repair or
than our authorized representatives.
abused, improperly installed, or repaired or altered by others
been damaged (including by acts of nature), tampered,
wear and tear not affecting the functionality of the product,
will give no credit for products which have received normal
costs and charges. This warranty will not be breached, and we
We hereby disclaim all responsibility for such transportation
charges for returned goods shall be paid for by the purchaser.
option, be repaired or replaced by us. Transportation costs and
from date of sale will, upon examination by us, and at our sole
to breach the warranty contained herein within ONE YEAR
Any product which, under normal use and service, is proven
period of one year from the date of purchase.
properly installed and operated, will be free of defects for a
warranty are of good material and workmanship and, when
We warrant that all products we manufacture under this
provides the benets and services set forth herein.
forth herein. For purchases of Chaney products, Chaney
products, AcuRite provides the benets and services set
Instrument Company. For purchases of AcuRite
AcuRite is a wholly owned subsidiary of Chaney
www.AcuRit e.com
PRODUCT REGIS TRATION
TO RECEIVE WARRANT Y SERVICE
PRODUCT MUS T BE REGIS TERED
Regist er online t o receive 1 year war ranty pro t ection
IMPORTANT
(877) 221-1252
► Replacement Parts ► Submit Feedback & Ideas
► Instruction Manuals ► Support User Forum
► Installation Videos ► Register your Product
Visit us at www.AcuRite.com
Q)
product available and contact us in any of the following ways:
class service. For assistance, please have the model number of this
AcuRite customer support is committed to providing you with best-in-
Customer Support
10
11
ACU
►
RITE®
Weather Temperature Weather Kitchen
Stations & Humidity Alert Radio Thermometers
It’s More than Accurate, it’s
AcuRite offers an extensive assortment of precision instruments,
designed to provide you with information you can depend on to
& Timers
ACU RITE.
Plan your day with condence
.
™
Clocks
www.AcuRite.com
©Chaney Instrument Co. All rights reserved. AcuRite is a registered trademark of
the Chaney Instrument Co., Lake Geneva, WI 53147. All other trademarks and copy-
Printed in China
00609 INST 060617 Visit www.AcuRite.com/patents for details.
rights are the property of their respective owners. AcuRite uses patented technology.
Loading...
