AcuRite 00606 Users guide
Instruction Manual
Wireless Thermometer
model 00606
1111
CONTENTS
Unpacking Instructions ........... 2
Package Contents .................. 2
Product Registration ............... 2
Features & Benets................. 3
Setup .................................... 4
Install or Replace Batteries...... 4
Set the Time & Units ............... 5
Placement Guidelines ............. 6
Using the Thermometer........... 7
Troubleshooting ..................... 8
Care & Maintenance.............. 9
Specications......................... 9
FCC Information .................... 9
Customer Support .................10
Warranty..............................10
Questions? Contact Customer Support at
(877) 221-1252 or visit www.AcuRite.com
SAVE THIS MANUAL FOR FUTURE REFERENCE.
Congratulations on your new AcuRite product. To ensure the best
possible product performance, please read this manual in its entirety
and retain it for future reference.
Unpacking Instructions
Remove the protective lm that is applied to the LCD screen prior to using this
product. Locate the tab and peel off to remove.
Package Contents
1. Display unit
2. Outdoor sensor
3. Instruction Manual
IMPORTANT
PRODUCT REGISTRATION
Register online
to receive 1 year
warranty protection
www.AcuRite.com
PRODUCT MUST BE REGISTERED
TO RECEIVE WARRANTY SERVICE
Archive~ Products
Register a Product
►
2
Features & Benets
2
3
4
ºF/ºC
5
DISPLAY UNIT
SET
1
MAX
MIN
+
11
12
10
9
8
13
7
6
OUTDOOR SENSOR
1. Current Outdoor Temperature
2. Clock
3. Current Indoor Temperature
4. “°F/°C” Button
Toggle between °F and °C.
5. “SET” Button
For clock setup.
6. “+” Button
For clock setup.
7. “MAX/MIN” Button
Press to view the lowest/highest
temperature recorded since midnight.
8. Display Low Battery Indicator
9. Outdoor Sensor Signal Strength
10. Outdoor Sensor Low Battery Indicator
3
11. Integrated Hanger
for easy placement.
12. Wireless Signal Indicator
Flashes when data is being sent to
the display unit.
13. Battery Compartment Cover
SETUP
Install or Replace Batteries
AcuRite recommends high quality alkaline batteries for the best product
performance. Heavy duty or rechargeable batteries are not recommended.
The outdoor sensor requires lithium batteries in low temperature conditions.
Cold temperatures can cause alkaline batteries to function improperly. Use
lithium batteries in the outdoor sensor for temperatures below -4ºF / -20ºC.
Outdoor Sensor
1. Slide off the battery compartment
cover.
2. Insert 2 x AA batteries into the
battery compartment, as shown.
Follow the polarity (+/-) diagram in
the battery compartment.
3. Replace the battery cover.
LITHIUM 4 -
BATTERIES iP'Jilili?'M
ALKALINE
BATTERIES
(70°C) 158°F I
(70°C) 1580f I
Display Unit
1. Slide off the battery compartment
cover.
2. Insert 2 x AAA batteries into the
battery compartment, as shown.
Follow the polarity (+/-) diagram in
the battery compartment.
3. Replace the battery cover.
PLEASE DISPOSE OF OLD OR DEFECTIVE BATTERIES IN AN ENVIRONMENTALLY SAFE
WAY AND IN ACCORDANCE WITH YOUR LOCAL LAWS AND REGULATIONS.
used for an extended period of time. Follow the polarity (+/-) diagram in the battery compartment. Promptly remove dead batteries from the device. Dispose of used
batteries properly. Only batteries of the same or equivalent type as recommended are to be used. DO NOT incinerate used batteries. DO NOT dispose of batteries in fire,
as batteries may explode or leak. DO NOT mix old and new batteries or types of batteries (alkaline/standard). DO NOT use rechargeable batteries. DO NOT recharge
non-rechargeable batteries. DO NOT short-circuit the supply terminals.
BATTERY SAFETY: Clean the battery contacts and also those of the device prior to battery installation. Remove batteries from equipment which is not to be
4
